Experimental Section
thank Prof. Bornscheuer for his continuous support and the
ability to use his lab equipment. PM thanks the Deutsche
Forschungsgemeinschaft for funding (DFG grant number
HO4754/4-1).
Enzyme preparation was done as described previously.[7c, 12] Activities
were determined by a continuous photometric NADPH assay: in
contrast to NADP+, NADPH absorbs light at a wavelength of 340 nm
(in the microplate with a path length of 5 mm, a value of ε340 = 3.2
mM-1 was determined in a calibration experiment. For calculation of
enzyme activity, the slope of a control reaction without enzyme was
substracted. One U corresponds to a NADPH consumption of 1
µmol/min. The screening was performed under the following reaction
conditions: 200 mM amine buffer (the pH of the aqueous amine
solution was adjusted with HCl to pH 9.5), 10 mM ketone, 0.5 mM
NADH and 0.1-0.15 mg/ml enzyme concentration. For an efficient
screening, a master deep-well plate contained every keto substrate as
duplicate in DMSO at a concentration of 200 mM. The reaction
mixture was prepared on a microtiter plate, 10 µl of each substrate
was added and the reaction was followed for 10 min at 30°C after
addition of the enzyme. For establishing the assay using purified
enzymes and crude extract, 7 replicates were measured and a
detection limit of 15 mU/mg was found. For the subsequent in-depth
characterization, measurements were performed in duplicates. The
Deamination of the high-concentrated substrate amines were assayed
separately by adding enzyme solution and NADP+ to the amine
buffers and obtained the absorbance at 340 nm. An increase of
absorbance, which would indicate an undesirable deamination, was
not observed.
Keywords: enzyme catalysis, amines, imine reductase
reductive amination, photometric assay
[1]
[2]
a) M. Breuer, K. Ditrich, T. Habicher, B. Hauer, M. Keßeler, R.
Stürmer, T. Zelinski, Angew. Chem. Int. Ed. 2004, 43, 788-824; b) D.
Ghislieri, D. Houghton, A. P. Green, S. C. Willies, N. J. Turner, ACS
Catal 2013, 3, 2869-2872; c) J. H. Schrittwieser, S. Velikogne, W.
Kroutil, Adv. Synth. & Catal. 2015, 357, 1655-1685.
a) H. Alinezhad, H. Yavari, F. Salehian, Curr. Org. Chem. 2015, 19,
1021-1049; b) M. K. Ghorai, D. P. Tiwari, A. Bhattacharyya, Vol. 2,
John Wiley & Sons, Inc., 2013, pp. 1173-1210; c) L. Legnani, B. N.
Bhawal, B. Morandi, Synthesis 2017, 49, 776-789; d) T. C. Nugent,
M. El-Shazly, Adv. Synth. & Catal. 2010, 352, 753-819; e) T. C.
Nugent, S. M. Marinova, Synthesis 2013, 45, 153-166; f) D. L.
Silverio, S. Torker, T. Pilyugina, E. M. Vieira, M. L. Snapper, F.
Haeffner, A. H. Hoveyda, Nature 2013, 494, 216-221.
[3]
[4]
G. Grogan, N. J. Turner, Chem. Eur. J. 2016, 22, 1900-1907.
H. Kohls, F. Steffen-Munsberg, M. Höhne, Curr. Opin. Chem. Biol.
2014, 19, 180-192.
For confirming selected activities with GC,
biotransformations were performed with purified enzymes for
1
ml scale
a
[5]
[6]
[7]
B. R. Lichman, J. X. Zhao, H. C. Hailes, J. M. Ward, Nat Commun
2017, 8.
reaction time of 20 h under the following conditions: 200 mM amine
buffer, pH 9.5, 10 mM carbonyl substrate, 0.5 mg/mL purified IRED,
and for recycling of NADPH, the reaction contained 0.1 mg/mL of
glucose dehydrogenase (Codexis GDH-105), 60 mM D-glucose, and
0.5 mM NADPH. The reaction was stopped with concentrated sodium
hydroxide (end concentration 1.7 M). 240 µl of the solution was
extracted twice with 120 µL ethyl acetate before analysis in GC-MS.
The GC analytics was performed on a BPX-5 column with following
program: 60°C hold for 10 min, 220°C (10°C/min) hold for 5.5 min,
260°C (5°C/min). The inlet pressure and temperature was set to 78.9
kPa and 300°C. Chromatograms are shown in the Supporting
Information. For analysing stereoselectivity, we synthesized the
racemic product standards according to an established protocol.[13]
The 1H and 13C-NMR spectra and GC-MS analysis confirmed the
product identity. Separation of the diastereomers was achieved by GC
(please see Fig. S4 in the Supporting Information).
M. Gand, C. Thöle, H. Müller, H. Brundiek, G. Bashiri, M. Höhne, J.
Biotechnol. 2016, 230, 11-18.
a) P. N. Scheller, M. Lenz, S. C. Hammer, B. Hauer, B. M. Nestl,
ChemCatChem 2015, 7, 3239-3242; b) P. N. Scheller, B. M. Nestl,
Applied Microbiology and Biotechnology 2016, 100, 10509-10520;
c) D. Wetzl, M. Gand, A. Ross, H. Müller, P. Matzel, S. P. Hanlon, M.
Müller, B. Wirz, M. Höhne, H. Iding, ChemCatChem 2016, 8, 2023–
2026.
[8]
[9]
P. Matzel, M. Gand, M. Höhne, Green Chemistry 2017, 19, 385-389.
a) G. A. Aleku, H. Man, S. P. France, F. Leipold, S. Hussain, L.
Toca-Gonzalez, R. Marchington, S. Hart, J. P. Turkenburg, G.
Grogan, N. J. Turner, ACS Catal. 2016, 6, 3880-3889; b) S. Hussain,
F. Leipold, H. Man, E. Wells, S. P. France, K. R. Mulholland, G.
Grogan, N. J. Turner, ChemCatChem 2015, 7, 579-583; c) P. N.
Scheller, S. Fademrecht, S. Hofelzer, J. Pleiss, F. Leipold, N. J.
Turner, B. M. Nestl, B. Hauer, ChemBioChem 2014, 15, 2201-2204.
[10] G. A. Aleku, S. P. France, H. Man, J. Mangas-Sanchez, S. L.
Montgomery, M. Sharma, F. Leipold, S. Hussain, G. Grogan, N. J.
Turner, Nat. Chem. 2017, DOI: 10.1038/nchem.2782
Acknowledgements
[11] D. Wetzl, M. Berrera, N. Sandon, D. Fishlock, M. Ebeling, M. Müller,
S. Hanlon, B. Wirz, H. Iding, ChemBioChem 2015, 16, 1749-1756.
[12] M. Gand, H. Müller, R. Wardenga, M. Höhne, J. Mol. Catal. B. 2014,
110, 126-132.
We thank our partners of the IRED research consortium Dr.
Dennis Wetzl and Dr. Hans Iding (Hoffman-La Roche Ltd.),
Prof. Dr. Michael Müller, and Prof. Dr. Dörte Rother for
inspiring and fruitful discussions. We also thank Ina Menyes
and Gabriele Thede for analytical support, and Dr. Bettina
Appel for assistance with the product purification. We like to
[13] K. A. Neidigh, M. A. Acery, J. S. Williamson, S. Bhattacharyya, J.
Chem. Soc., Perkin Trans. 1, 1998, 2527-2531
