10.1002/chem.201803032
Chemistry - A European Journal
COMMUNICATION
two-fold higher concentrations of 6 found in cells treated with the
reactants 8 and 9, compared to cells treated with pre-synthesized
6, indicate that over half of the molecules of 6 in lysates of cells
treated with the mixture of 8 and 9 must be formed by intracellular
iSPAAC. In the hypothetical scenario where 8 and 9 undergo
iSPAAC exclusively in the tissue culture medium, with a 100 %
yield, the maximum possible intracellular concentration of 6 would
be equal to that observed in cells treated with pre-synthesized 6.
The results of the cell-based assays can only be explained by the
reactants 8 and 9 having a superior cell permeability as compared
to 6, with a major proportion of iSPAAC occuring inside the cell.
possibilities to label biomolecules in living cells. The isomer-free
variant iSPAAC, using symmetrical strained cycloalkynes such as
SYPCO, could similarly become widely used for the intracellular
generation of bioactive molecules with higher molecular weights,
via smaller and thus more cell-permeable components. Potential
applications of this methodology include the isomer-free,
intracellular synthesis of large bioactive molecules such as
protein-protein interaction inhibitors, protein dimerizers,[22]
,
bivalent ligands that target two separate domains within the same
protein,[23] and PROTACS consisting of both a ligand of E3
ubiquitin ligases and of the protein targeted for degradation.[24]
Since the concept of iSPAAC doubles most of the cut-off
parameters defined by the Lipinski rules for orally bioavailable
drugs, it may enable fundamentally new avenues in the
development of drugs against challenging molecular targets.[10]
Future challenges will involve the development of iSPAAC
reagents with optimized steric demands, electronic properties,
and inherent reactivities for the respective applications.
Acknowledgements
This work was generously supported by the Deutsche
Forschungsgemeinschaft (BE 4572/2-1), and the European Union
and the Free State of Saxony, European Regional Development
Fund. We thank the Core Unit Fluorescence-Technologies of the
Interdisciplinary Centre for Clinical Research (IZKF) Leipzig at the
Faculty of Medicine of the University of Leipzig (Kathrin Jꢀger and
Andreas Lꢁsche). We extend our thanks to the NMR core facility
(Lothar Hennig) for support with the NMR-based kinetic analysis.
Keywords: apoptosis • bioorthogonal chemistry • cyclooctynes •
inhibitors • protein-protein interactions
[1]
[2]
[3]
a) A. T. Blomquist, L. H. Liu, J. Am. Chem. Soc. 1953, 75, 2153-2154;
b) G. Wittig, A. Krebs, Chem. Ber. 1961, 94, 3260-3275.
N. J. Agard, J. A. Prescher, C. R. Bertozzi, J. Am. Chem. Soc. 2004,
126, 15046-15047.
a) E. M. Sletten, C. R. Bertozzi, Acc. Chem. Res. 2011, 44, 666-676; b)
J. Dommerholt, F. P. Rutjes, F. L. van Delft, Top. Curr. Chem. 2016,
374, 16.
Figure 4. a) Rate of apoptosis in K562 cells treated with the individual SPAAC
reactants 8 or 9, the ABT-737 mimetic 6, or a mixture of 8 and 9 (n = 3). Error
bars represent standard deviations (SD). ** p < 0.01 (t-test, two-tailed, paired).
b) HPLC analysis of lysates from cells treated with either 8, 9, 6, or a mixture of
8 and 9 at 80 µM of each component. c) Relative concentrations of 6 in lysates
from cells treated with either pre-synthesized 6 (80 µM) or a mixture of the
iSPAAC reactants 8 and 9 (80 µM each) in parallel experiments (n = 4). Error
bars represent standard deviations (SD). **p < 0.01 (t-test, two-tailed, paired).
[4]
[5]
a) V. V. Rostovtsev, L. G. Green, V. V. Fokin, K. B. Sharpless, Angew.
Chem. Int. Ed. 2002, 41, 2596-2599; b) C. W. Tornoe, C. Christensen,
M. Meldal, J. Org. Chem. 2002, 67, 3057-3064.
a) M. Boudjemeline, C. D. McNitt, T. A. Singleton, V. V. Popik, A. P.
Kostikov, Org. Biomol. Chem. 2018, 16, 363-366; b) B. R. Varga, M.
Kallay, K. Hegyi, S. Beni, P. Kele, Chemistry 2012, 18, 822-828; c) X.
Ning, J. Guo, M. A. Wolfert, G. J. Boons, Angew. Chem. Int. Ed. 2008,
47, 2253-2255.
In summary, we present iSPAAC as a method by which to form
large bioactive molecules from two smaller components in cells in
an isomer-free manner. We demonstrate the application of this
method by using the symmetrical cycloalkyne SYPCO (1) to
[6]
J. Dommerholt, S. Schmidt, R. Temming, L. J. Hendriks, F. P. Rutjes, J.
C. van Hest, D. J. Lefeber, P. Friedl, F. L. van Delft, Angew. Chem. Int.
Ed. 2010, 49, 9422-9425.
[7]
[8]
C. Gröst, T. Berg, Org. Biomol. Chem. 2015, 13, 3866-3870.
P. Parvatkar, N. Kato, M. Uesugi, S. Sato, J. Ohkanda, J. Am. Chem.
Soc. 2015, 137, 15624-15627.
generate
a rationally designed inhibitor of protein-protein
interactions mediated by Bcl-xL, both in vitro and in living cells, via
isomer-free SPAAC. To our knowledge, our data represent the
first isomer-free generation of a bioactive molecule by SPAAC.
The first application of SPAAC to living systems by the
Bertozzi group[2] triggered a large number of research studies in
bioorthogonal chemistry, leading to today’s vastly expanded
[9]
J. A. Wells, C. L. McClendon, Nature 2007, 450, 1001-1009.
[10] C. A. Lipinski, F. Lombardo, B. W. Dominy, P. J. Feeney, Adv. Drug
Deliv. Rev. 2001, 46, 3-26.
[11] H. T. You, A. C. Grosse, J. K. Howard, C. J. Hyland, J. Just, P. P.
Molesworth, J. A. Smith, Org. Biomol. Chem. 2011, 9, 3948-3953.
[12] T. Oltersdorf, et al., Nature 2005, 435, 677-681.
