Yang and Denny
Na2S2O3 and stirred at room temperature for 15 min. The
reaction mixture was extracted with EtOAc (3 × 100 mL),
dried, and concentrated under reduced pressure, and the
residue was purified by column chromatography on silica gel.
Elution with CH2Cl2 and crystallization from EtOAc/petroleum
ether afforded 12 (9.46 g, 81%) as a brown solid: mp 154-
A similar synthesis gave cinnamate analogue 19 in 9%
overall yield (the lower yield being largely due to a lower
yield in the deallylation reaction. However, the original14
preparation of this compound was also of lower yield, due
to a longer route.
In summary, the above synthesis of 3-substituted
5-amino-1-(chloromethyl)-1,2-dihydro-3H-benzo[e]in-
doles from Martius Yellow, involving three efficient
regioselective reactions (iodination, 5-exo-trig aryl radi-
cal-alkene cyclization, and carboxylation), is a consider-
able improvement (shorter and higher-yielding) over the
original method.9
1
156 °C (dec); H NMR (CDCl3) δ 8.65 (s, 1 H), 8.12 (m, 1 H),
7.76 (m, 1 H), 7.52 (m, 1 H), 7.45 (m, 1 H), 7.19 (s, 1 H), 6.83
(s, 1 H), 1.57 (s, 9 H), 1.55 (s, 9 H); 13C NMR δ 153.1, 152.6,
138.2, 134.8, 134.6, 132.6, 128.2, 125.3, 124.8, 121.3, 113.5,
81.3, 81.0, 28.3. Anal. Calcd for C20H25IN2O4: C, 49.6; H, 5.2;
N, 5.8. Found: C, 49.8; H, 5.2; N, 5.8.
N,N′-Bis[a llyl(ter t-bu tyloxyca r bon yl)]-1-iod o-2,4-n a p h -
th a len ed ia m in e (13). A solution of 12 (4.86 g, 10.0 mmol) in
anhydrous DMF (150 mL) under nitrogen was treated with
NaH (1.2 g, 30 mmol, 60% oil dispersion), and the reaction
mixture was stirred for 30 min at 0 °C. Allyl bromide (12.1 g,
100 mmol) was added dropwise over 5 min, and the solution
was allowed to warm to room temperature and stirred for 2
h. Saturated aqueous NaHCO3 (100 mL) was added, and the
aqueous phase was extracted with EtOAc (3 × 100 mL), dried,
and concentrated under reduced pressure; the residue was
purified by column chromatography on silica gel. Elution with
EtOAc/petroleum ether (from 1:10 to 1:5) and crystallization
from EtOAc/petroleum ether afforded 13 (5.64 g, 100%) as a
Exp er im en ta l Section
2,4-Din itr o-1-n a p h th yl Tr iflu or om eth a n esu lfon a te (9).
A solution of Martius Yellow (8) (5.0 g, 21.4 mmol) in CH2Cl2
(100 mL) was treated with Et3N (8 mL, 57 mmol), and the
resulting solution was cooled in an ice-salt bath and treated
dropwise with trifluoromethanesulfonic anhydride (5 mL, 28
mmol). After the mixture was stirred at room temperature for
2 h, 0.5 N HCl (100 mL) was added in one portion, and the
mixture was stirred for 30 min. The aqueous phase was
separated and extracted with CH2Cl2 (2 × 50 mL). The
combined organic phases were washed with saturated NaHCO3
and brine, dried, and concentrated under reduced pressure,
and the residue was purified by column chromatography on
silica gel. Elution with CH2Cl2, gave 9 (7.0 g, 89%) as yellow
needles: mp (EtOAc/CH2Cl2) 105-107 °C; 1H NMR [(CD3)2-
SO] δ 8.90 (s, 1 H), 8.59 (m, 1 H), 8.55 (m, 1 H), 7.98 (m, 1 H),
7.78 (m, 1 H); 13C NMR δ 158.2, 135.1, 133.2, 127.9, 127.9,
127.7, 127.3, 125.5, 123.3, 122.4. Anal. Calcd for C11H5F3N2O7S:
C, 36.1; H, 1.4; N, 7.7. Found: C, 36.0; H, 1.3; N, 7.6.
1-Iod o-2,4-d in itr on a p h th a len e (10). A solution of 9 (5.0
g, 13.7 mmol) and NaI (7.0 g) in EtOAc (200 mL) was heated
under reflux for 2 h. After cooling to room temperature, the
reaction mixture was washed with saturated Na2S2O3, dried,
and concentrated under reduced pressure, and the residue was
purified by column chromatography on silica gel. Elution with
CH2Cl2 gave 10 (4.3 g, 91%) as yellow needles: mp (EtOAc/
CH2Cl2) 194-195 °C; 1H NMR [(CD3)2SO] δ 8.76 (s, 1 H, H-3),
8.54 (m, 1 H), 8.33 (m, 1 H), 8.00 (m, 2 H); 13C NMR δ 151.8,
147.1, 135.0, 132.2, 131.2, 123.9, 123.3, 117.5, 102.7. Anal.
Calcd for C10H5IN2O4: C, 34.9; H, 1.5; N, 8.1. Found: C, 34.8;
H, 1.2; N, 7.9.
1
white solid: mp 150-152 °C; H NMR (CDCl3) δ 8.23 (m, 1
H), 7.77 (m, 1 H), 7.58 (m, 2 H), 7.10 (m, 1 H), 5.93 (m, 2 H),
5.07 (m, 4 H), 4.62 (m, 2 H), 3.87 (m, 2 H), 1.33 (m, 10 H),
1.25 (m, 8 H); 13C NMR δ 154.7, 153.7, 133.6, 133.5, 131.6,
128.1, 127.3, 127.3, 123.4, 123.3, 120.5, 118.3, 80.4, 52.8, 28.1.
Anal. Calcd for C26H33IN2O4: C, 55.3; H, 5.9; N, 5.0. Found:
C, 55.6; H, 5.9; N, 5.1.
5-[Allyl(ter t-b u t yloxyca r b on yl)a m in o]-3-(ter t-b u t yl-
oxyca r bon yl)-1-{[(2′,2′,6′,6′-tetr a m eth ylp ip er id in o)oxy]-
m eth yl}-1,2-d ih yd r o-3H-ben zo[e]in d ole (14). A solution of
13 (2.82 g, 5.0 mmol) in benzene (200 mL) was treated
sequentially with TEMPO (3.0 equiv) and Bu3SnH (1.0 equiv),
and the reaction mixture was warmed to 60 °C and kept there
for an additional 135 min. Additional Bu3SnH (1 equiv) was
added after 30, 60, and 90 min, and additional TEMPO (2
equiv) was added after 60 and 90 min. The solvent was then
removed by evaporation, and the residue was purified by
column chromatography on silica gel. Elution with EtOAc/
petroleum ether (from 1:20 to 1:5) afforded 12 (2.97 g, 100%),
which was sufficiently pure for the next step reaction as a pale
1
N,N′-Bis(ter t-b u t yloxyca r b on yl)-1,3-n a p h t h a len ed i-
a m in e (11). A suspension of 10 (1.0 g, 2.9 mmol) and SnCl2‚
2H2O (9.8 g, 43.6 mmol) in EtOAc (100 mL) was heated under
reflux for 30 min. The white suspension was poured onto ice
(ca. 100 g), and NaHCO3 was added until the aqueous layer
was basic to litmus. The mixture was extracted with EtOAc;
the organic layer was washed with water and dried, and the
solvent was removed under reduced pressure to give crude 1,3-
naphthalenediamine. This was dissolved in THF (30 mL) and
treated with (BOC)2O (3.0 g), and then the mixture was heated
under reflux for 5 h. The solvent was removed, and the residue
was purified by column chromatography on silica gel. Elution
with CH2Cl2 gave 11 (0.916 g, 88%) as a brown solid: mp
yellow gum: H NMR (CDCl3) δ 8.09 (vbr, 1H), 7.76 (m, 2 H),
7.43 (m, 1 H), 7.32 (m, 1 H), 5.95 (m, 1 H), 5.07 (m, 2 H), 4.40-
4.23 (m, 3 H), 4.09 (m, 2 H), 3.86 (m, 2 H), 1.59-1.0 (m, 36
H); 13C NMR δ 152.5, 134.0, 133.8, 129.9, 128.9, 126.4, 126.0,
123.8, 123.4, 117.5, 80.0, 59.9, 52.4, 39.7, 33.1, 28.5, 28.2, 20.1,
17.1; HRMS m/z required for C35H51N2O8 593.3828, found
593.3819.
5-[Allyl(ter t-b u t yloxyca r b on yl)a m in o]-3-(ter t-b u t yl-
oxyca r bon yl)-1-(h yd r oxym eth yl)-1,2-d ih yd r o-3H-ben zo-
[e]in d ole (15). A solution of 14 (2.97 g, 5.0 mmol) in THF/
AcOH/H2O (3:1:1, 200 mL) was treated with Zn powder (30 g,
80 equiv), and the mixture was warmed at 70 °C for 10 h. The
Zn powder was removed by filtration through Celite, and the
mixture was concentrated under reduced pressure. The residue
was extracted with CH2Cl2 (3 × 100 mL), dried, and concen-
trated under reduced pressure, and the crude product was
purified by column chromatography on silica gel. Elution with
EtOAc/petroleum ether (from 1:4 to 1:1), and crystallization
from EtOAc/petroleum ether afforded 15 (2.13 g, 94%): mp
125-128 °C; 1H NMR (CDCl3) δ 8.14 (vbr, 1 H), 7.75 (m, 1 H),
7.43 (m, 1 H), 7.34 (m, 1 H), 5.98 (m, 1 H), 5.11 (m, 2 H), 4.20
(m, 2 H), 4.11 (m, 2 H), 3.90 (m, 2 H), 3.70 (m, 2H), 1.59 (m,
12 H), 1.26 (m, 6 H); 13C NMR δ 153.0, 152.5, 133.9, 128.9,
126.8, 126.0, 124.4, 123.9, 117.6, 64.7, 60.4, 52.1, 28.5, 28.2,
21.0. Anal. Calcd for C26H34N2O5: C, 68.7; H, 7.5; N, 6.2.
1
(petroleum ether) 129-131 °C; H NMR (CDCl3) δ 7.94 (s, 1
H), 7.78 (s, 1 H), 7.74 (m, 2 H), 7.41 (m, 2 H), 6.94 (s, 1 H),
6.69 (s, 1 H), 1.55 (s, 9 H), 1.54 (s, 9 H); 13C NMR δ 153.1,
152.8, 135.8, 134.8, 133.7, 128.5, 126.5, 124.4, 122.3, 119.7,
110.6, 110.5, 80.9, 80.6, 28.3. Anal. Calcd for C20H26N2O4: C,
67.0; H, 7.3; N, 7.8. Found: C, 67.0; H, 7.3; N, 7.8.
N,N′-Bis(ter t-b u t yloxyca r b on yl)-1-iod o-2,4-n a p h t h a -
len ed ia m in e (12). A solution of 11 (8.63 g, 24.1 mmol) in
THF/CH3OH (200 mL, 1:1) at -78 °C was treated with
N-iodosuccinimide (NIS, 8.5 g, 33.7 mmol) in THF (10 mL)
followed by TsOH‚H2O (9.5 g, 50.2 mmol) in CH3OH (10 mL).
The reaction mixture was allowed to slowly warm to room
temperature over 4 h and then diluted with 5% aqueous
