Ploypradith et al.
1748, 1696, 1615, 1522, 1035 cm-1
.
1H NMR (200 MHz,
recrystallized from MeOH to furnish the desired product 16a
(67%) or 16b (55%) as yellow-orange solids.
CDCl3): δ 1.27 (t, 3H, J ) 7.0 Hz), 3.05 (apparent t, 2H, J )
6.4 Hz), 3.40 (s, 3H), 3.42 (s, 3H), 3.69 (s, 3H), 3.84 (s, 3H),
3.86 (s, 3H), 3.87 (s, 3H), 4.08 (apparent t, 2H, J ) 6.4 Hz),
4.21 (q, 2H, J ) 7.0 Hz), 6.43 (s, 1H), 6.67 (s, 1H), 6.70 (s,
1H), 6.77 (s, 1H), 6.85 (d, 1H, J ) 1.2 Hz), 6.86 (s, 1H), 6.87-
6.91 (m, 2H). 13C NMR (50 MHz, CDCl3): δ 14.2, 29.4, 44.7,
55.2, 55.5, 55.8 (2 carbons), 55.85, 55.91, 64.4, 105.4, 107.4,
111.0, 111.2, 111.8, 113.9, 114.2, 118.0, 119.4, 120.1, 122.1,
123.2, 123.9, 125.5, 129.0, 141.7, 146.1, 146.7, 147.0, 147.3,
147.4, 148.7, 153.6. LRMS (EI) m/z (rel intensity) 590 (M +
H+, 34), 589 (M+, 100), 543 (61), 529 (14), 516 (19), 500 (13),
485 (12), 338 (10), 181 (19), 165 (15). FAB-HRMS calcd for
C33H36NO9 (M + H+) 590.2390, found 590.2387.
Ethyl 3-(2,4-Bisbenzyloxy-5-methoxyphenyl)-2-nitro-
acrylate (16a). mp (MeOH) 103-104 °C (lit.9c mp 104-105
°C). IR (KBr): νmax 2938, 1754, 1714, 1608, 1573, 1522, 1268,
1225 cm-1. 1H NMR (200 MHz, CDCl3): δ 1.34 (t, 3H, J ) 7.2
Hz), 3.79 (s, 3H), 4.34 (q, 2H, J ) 7.2 Hz), 5.00 (s, 2H), 5.12 (s,
2H), 6.50 (s, 1H), 6.83 (s, 1H), 7.27-7.36 (m, 10 H), 7.99 (s,
1H). 13C NMR (50 MHz, CDCl3): δ 14.0, 56.2, 62.5, 70.9, 71.6,
100.4, 110.3, 110.5, 127.1 (2 carbons), 127.4, 128.2, 128.66,
128.70 (2 carbons), 135.8, 136.0, 137.9, 144.2, 152.9, 153.8,
159.9. LRMS (EI) m/z (rel intensity) 464 (M + H+, 7), 463 (M+,
40), 326 (28), 236 (29), 181 (36), 91 (100). HR-MS (FAB) calcd
for C26H26NO7 (M + H+) 464.1709, found 464.1699. Anal. Calcd
for C26H25NO7: C, 67.38; H, 5.44; N, 3.02. Found: C, 67.51;
H, 5.62; N, 2.98. These spectroscopic data are identical to those
reported previously.9c
Ethyl 3-(2-Benzyloxy-4,5-dimethoxyphenyl)-2-nitroacry-
late (16b). mp (MeOH) 132-133 °C. IR (KBr): νmax 2924,
1733, 1707, 1609, 1576, 1524, 1466, 1440, 1275, 1226, 1044
cm-1. 1H NMR (200 MHz, CDCl3): δ 1.35 (t, 3H, J ) 7.0 Hz),
3.78 (s, 3H), 3.86 (s, 3H), 4.35 (q, 2H, J ) 7.0 Hz), 5.15 (s,
2H), 6.52 (s, 1H), 6.82 (s, 1H), 7.41 (m, 5H), 8.03 (s, 1H). 13C
NMR (50 MHz, CDCl3): δ 14.0, 56.0, 56.1, 62.5, 71.7, 98.2,
109.8, 109.9, 127.2, 127.4, 128.2, 128.7, 136.0, 137.8, 143.7,
153.9, 154.1, 159.9. LRMS (EI) m/z (rel intensity) 388 (M +
H+, 2), 387 (M+, 9), 251 (12), 250 (74), 222 (16), 91 (100), 65
(11). FAB-HRMS calcd for C20H22NO7 (M + H+) 388.1397,
found 388.1396. Anal. Calcd for C20H21NO7: C, 62.01; H, 5.46;
N, 3.62. Found: C, 61.98; H, 5.41; N, 3.72.
E. General Procedure for Pyrrole Formation from 11
with r-Nitrocinnamates (Mi-RC). To a stirred solution of
11 (1.2 equiv) in acetonitrile (10 mL/mmol of 11) at room
temperature was added the base (1.1 equiv) and R-nitrocin-
namate (16a or 16b; 1 equiv). The resulting mixture was
heated to reflux for 18 h. At that time, if polymer-supported
reagent was employed, the reaction was filtered, the polymer
washed with DCM and EtOAc, and the resulting mixture
concentrated under reduced pressure. If NaHCO3 was used,
water was added and the two phases were separated. The
organic layers were washed with brine, dried over Na2SO4,
filtered, and concentrated under reduced pressure. The residue
was purified by column chromatography to furnish the desired
product 17a (50%, using NaHCO3; 44%, using Amberlyst A-26
NaCO3-) or 17b (60%).
C. General Procedure for the Acid-Mediated Friedel-
Crafts Transacylation/Lactonization. 2H-Pyrrole carbon-
ate (12a or 12b; 1 equiv) was dissolved in solvent (40
mL/mmol) as indicated in Table 3, at room temperature. An
acid (equiv as indicated in Table 3) was then added, and the
resulting mixture was stirred at temperature and for the
amount of time indicated in Table 3. If polymer-supported
reagent was employed, the reaction was filtered, the polymer
washed with DCM and EtOAc, and the crude concentrated
under reduced pressure. If p-TsOH was used, the reaction was
neutralized by Et3N. The resulting mixture was concentrated
under reduced pressure. The crude material was purified by
recrystallization from MeOH/hexanes to furnish the desired
lamellarins 13a or 13b (see Table 3 for yields).
14-(3,4-Dimethoxyphenyl)-11,12-dimethoxy-8,9-dihydro-
6H-chromeno[4′,3′:4,5]pyrrolo[2,1-a]isoquinolin-6-one
(13a). mp (MeOH) 244-245 °C. IR (Nujol): νmax 3028, 1696,
1
1515, 1485, 1432, 1339 cm-1. H NMR (200 MHz, CDCl3): δ
3.12 (apparent t, 2H, J ) 7.0 Hz), 3.37 (s, 3H), 3.86 (s, 3H),
3.89 (s, 3H), 3.99 (s, 3H), 4.82 (apparent t, 2H, J ) 7.0 Hz),
6.65 (s, 1H), 6.76 (s, 1H), 6.97-7.07 (m, 4H), 7.22-7.39 (m,
3H). 13C NMR (50 MHz, CDCl3): δ 28.7, 42.5, 55.2, 55.9, 56.1
(two carbons), 108.8, 110.0, 112.1, 113.9, 114.5, 115.8, 117.1,
118.3, 120.0, 123.4, 123.7, 126.6, 127.3, 127.5, 127.9, 136.1,
147.5, 149.0, 149.9, 151.3, 155.2. LRMS (EI) m/z (rel intensity)
484 (M + H+, 30), 483 (M+, 100), 469 (4), 468 (13), 226 (19),
189 (10), 141 (3), 139 (12). FAB-HRMS calcd for C27H26NO5
(M + H+) 484.1760, found 484.1760. Anal. Calcd for C27H25-
NO5: C, 72.02; H, 5.21; N, 2.90. Found: C, 71.60; H, 5.23; N,
2.71.
14-(3,4-Dimethoxyphenyl)-2,3,11,12-tetramethoxy-8,9-
dihydro-6H-chromeno[4′,3′:4,5]pyrrolo[2,1-a]isoquinolin-
6-one (13b; Lamellarin G Trimethyl Ether). mp (MeOH)
245-246 °C (lit.8e mp 235 °C (no range given), lit.8l mp 239.1-
240.7 °C). IR (Nujol): νmax 3025, 1699, 1522, 1485, 1444, 1425,
1342, 1250 cm-1. 1H NMR (200 MHz, CDCl3): δ 3.09 (apparent
t, 2H, J ) 6.6 Hz), 3.35 (s, 3H), 3.45 (s, 3H), 3.82 (s, 3H), 3.86
(s, 6H), 3.94 (s, 3H), 4.75 (apparent t, 2H, J ) 6.6 Hz), 6.64 (s,
1H), 6.69 (s, 1H), 6.74 (s, 1H), 6.84 (s, 1H), 7.05-7.15 (m, 3H).
13C NMR (50 MHz, CDCl3): δ 28.6, 42.3, 55.1, 55.4, 55.85,
55.88, 56.09, 56.13, 100.3, 104.3, 108.5, 110.1, 110.8, 111.7,
113.6, 113.8, 114.7, 119.9, 123.5, 126.6, 127.9, 128.0, 135.8,
145.3, 145.9, 147.3, 148.6, 148.7, 148.8, 149.6, 155.4. LRMS
(EI) m/ z (rel intensity) 543 (M+, 100), 528 (6), 496 (7), 470 (3),
454 (4), 440 (3), 271 (20), 248 (6), 227 (11). These spectroscopic
data are identical to those reported previously.8e,f
D. General Procedure for the Knoevenagel Reaction.
A round-bottomed flask equipped with a Dean-Stark ap-
paratus was charged with the appropriately substituted al-
dehyde (1 equiv), Et2NH‚HCl (1.5 equiv), ethyl nitroacetate
(1.25 equiv), and toluene (12 mL/mmol of aldehyde) at room
temperature. The mixture was refluxed under argon for 48 h.
Toluene was removed, and water and CH2Cl2 were added. Two
phases were separated, and the aqueous phase was extracted
with CH2Cl2 (3×). The combined organic layers were washed
with brine, dried over Na2SO4, filtered, and concentrated under
reduced pressure to give the crude product, which was
Ethyl 1-(3,4-Dimethoxyphenyl)-2-(2,4-dibenzyloxy-5-
methoxy)-8,9-dimethoxy-5,6-dihydropyrrolo[2,1-a]iso-
quinoline-3-carboxylate (17a). mp (EtOAc/hexanes) 165-
166 °C. IR (CHCl3): νmax 3018, 2935, 1686, 1610, 1482, 1422,
1398, 1335, 1255, 1214, 1176, 1130, 1064, 1027 cm-1. 1H NMR
(200 MHz, CDCl3): δ 0.84 (t, 3H, J ) 7.0 Hz), 3.07 (apparent
t, 2H, J ) 6.6 Hz), 3.36 (s, 3H), 3.53 (s, 3H), 3.65 (s, 3H), 3.83
(s, 3H), 3.88 (s, 3H), 4.00 (q, 2H, J ) 7.0 Hz), 4.64 (br m, 2H),
4.75 (s, 2H), 5.03 (s, 2H), 6.43 (s, 1H), 6.60 (s, 1H), 6.68 (s,
1H), 6.73 (m, 4H), 7.05-7.15 (m, 2H), 7.20-7.38 (m, 8H). 13C
NMR (50 MHz, CDCl3): δ 13.7, 29.1, 42.7, 55.2, 55.6, 55.8 (2
carbons), 56.4, 59.5, 71.1, 71.6, 102.9, 108.6, 110.5, 110.7,
113.9, 116.0, 118.7, 119.1, 121.0, 121.6, 123.0, 125.8, 126.7,
127.2, 127.3, 127.7, 128.1, 128.2, 128.4, 130.8, 137.0, 137.8,
143.4, 146.9, 147.1, 147.4, 147.8, 148.3, 150.5, 162.0. LRMS
(EI) m/z (rel intensity) 756 (M + H+, 4), 755 (M+, 12), 679 (6),
664 (8), 588 (10), 500 (8), 91 (100), 65 (25). FAB-HRMS calcd
for C46H46NO9 (M + H+) 756.3172, found 756.3177. Anal. Calcd
for C46H45NO9: C, 73.10; H, 6.00; N, 1.85. Found: C, 73.31;
H, 6.02; N, 1.94.
Ethyl 1-(3,4-Dimethoxyphenyl)-2-(2-benzyloxy-4,5-di
methoxy)-8,9-dimethoxy-5,6-dihydropyrrolo[2,1-a]iso-
quinoline-3-carboxylate (17b). IR (CHCl3): νmax 3019, 2937,
2837, 1684, 1610, 1583, 1500, 1335, 1215, 1130, 1064, 1026
cm-1. 1H NMR (200 MHz, CDCl3): δ 0.93 (t, 3H, J ) 7.0 Hz),
3.08 (apparent t, 2H, J ) 6.6 Hz), 3.35 (s, 3H), 3.56 (s, 3H),
3.66 (s, 3H), 3.76 (s, 3H), 3.83 (s, 3H), 3.90 (s, 3H), 4.06 (q,
5124 J. Org. Chem., Vol. 70, No. 13, 2005
