MBE Growth and Device Processing of
Journal of ELECTRONIC MATERIALS, Vol. 30, No. 6, 2001
Special Issue P7a1pe7r
MWIR HgCdTe on Large Area Si Substrates
MBE Growth and Device Processing
of MWIR HgCdTe on Large Area Si Substrates
G. BRILL,1 S. VELICU,2 P. BOIERIU,1 Y. CHEN,1 N.K. DHAR,3 T.S. LEE,4
Y. SELAMET,4 and S. SIVANANTHAN4
1.—EPIR Ltd., Bolingbrook, IL 60440. 2.—SPI Inc., Bolingbrook, IL 60440. 3.—Army Research
Laboratory, Adelphi, MD 20783. 4.—University of Illinois at Chicago, Chicago, IL 60607
The traditional substrate of choice for HgCdTe material growth has been lattice
matched bulk CdZnTe material. However, as larger array sizes are required for
future devices, it is evident that current size limitations of bulk substrates will
become an issue and therefore large area Si substrates will become a require-
ment for HgCdTe growth in order to maintain the cost-efficiency of future
systems. As a result, traditional substrate mounting methods that use chemical
compounds to adhere the substrate to the substrate holder may pose significant
technical challenges to the growth and fabrication of HgCdTe on large area
Si substrates. For these reasons, non-contact (indium-free) substrate mounting
was used to grow mid-wave infrared (MWIR) HgCdTe material on 3≤ CdTe/Si
substrates.InordertomaintainaconstantepilayertemperatureduringHgCdTe
nucleation, reflection high-energy electron diffraction (RHEED) was imple-
mented to develop a substrate temperature ramping profile for HgCdTe nucle-
ation. The layers were characterized ex-situ using Fourier transform infrared
(FTIR) and etch pit density measurements to determine structural characteris-
tics. Dislocation densities typically measured in the 9 ¥ 106 cm–2 to 1 ¥ 107 cm–2
range and showed a strong correlation between ramping profile and Cd compo-
sition, indicating the uniqueness of the ramping profiles. Hall and photoconduc-
tive decay measurements were used to characterize the electrical properties of
the layers. Additionally, both single element and 32 ¥ 32 photovoltaic devices
were fabricated from these layers. A RA value of 1.8 ¥ 106 W-cm2 measured at –
40 mV was obtained for MWIR material, which is comparable to HgCdTe grown
on bulk CdZnTe substrates.
Key words: HgCdTe, Si, molecular beam epitaxy (MBE), MWIR, alternative
substrate, infrared detectors, reflection high-energy electron dif-
fraction (RHEED)
and larger size FPAs necessary for higher image
resolution and system performance, growth on larger
area substrates will be a requirement so that cost
effectiveness can be maintained. For example, a
1024 ¥ 1024 array with a pitch of 18 mm requires only
a 2 ¥ 2 cm area substrate, but six such chips can be
grown and fabricated at one time if a 3≤ diameter
substrate is utilized instead. Additionally, as
the technology requirements advance toward the de-
velopment of even larger array sizes, such as
INTRODUCTION
Through the continued advancement of HgCdTe/Si
material growth and device fabrication processes, the
fabrication of large focal plane arrays (FPA) (512 ¥
512 and 1024 ¥ 1024) on Si substrates has been
demonstrated in recent years.1,2 In order to continue
the progress toward the everyday production of these
(ReceivedNovember25, 2000;acceptedDecember19, 2000)
717

718
Brill, Velicu, Boieriu, Chen, Dhar, Lee, Selamet, Sivananthan
2048 ¥ 2048, it is clear that only large area substrates
(3≤ diameter or greater) will be suitable for HgCdTe
growth.
sidual graphite from the back of the wafer prior to the
processing steps. The chance for material damage
during this process exists, which can result in serious
device-related issues. Furthermore, the future devel-
opmentofnon-equilibriumdevicestructuresrequires
very low-doped material4,5 and it is unknown at this
time what effect possible graphite contamination
might have on these types of layers. For all of these
reasons, it is necessary to move to non-contact meth-
ods of substrate mounting for MBE grown HgCdTe.
In this work, we report the growth of n-type
MWIR HgCdTe material on 3≤ diameter CdTe/Si
substrates, mounted on indium-free substrate hold-
ers utilizing an empirically derived substrate ramp-
ing profile obtained from reflection high energy elec-
tron diffraction (RHEED) observations. To demon-
strate the feasibility of such a growth method, both
single element and 32 ¥ 32 arrays were fabricated
from this material.
However, the mounting of larger area substrates
can pose significant technical challenges during mo-
lecular beam epitaxy (MBE) growth of HgCdTe that
are not present when small area substrates are uti-
lized. Currently, the standard mounting technique is
to use colloidal graphite or some other chemical com-
poundtoadherethesubstratetothesubstrateholder.
Once in place the graphite also acts as a good thermal
conductor that is able to efficiently transfer heat from
the substrate heater to the substrate surface. How-
ever, whenmountinglargeareasubstrates, itismuch
more difficult to apply the colloidal graphite uni-
formly. Therefore, the possibility of having areas on
the substrate that are not in good thermal contact
with the substrate holder is greatly enhanced. This
would cause non-uniformities in substrate tempera-
ture across the wafer guaranteeing that some regions
of HgCdTe growth would occur under poor growth
conditionsleadingtosectionsofhighlydefectedmate-
rial. These types of temperature non-uniformity is-
sues have already been reported for large area sub-
strates.3 In addition, the initial substrate tempera-
ture has been observed to vary from run-to-run as
measured by infrared pyrometry due to the graphite
mounting technique3 making it extremely difficult to
maintain HgCdTe layer reproducibility on a daily
basis. Besides substrate temperature related issues,
graphite mounting is also undesirable from a device
fabrication point of view. After the completion of
HgCdTe growth, it is necessary to remove any re-
EXPERIMENTAL DETAILS
HgCdTe growth was carried out in a Riber
32P MBE system equipped with CdTe, Te, and In
effusion sources and a valved Hg source. A simple
layer structure was grown for these studies, which
consisted of an approximate 8 mm thick mid-wave
infrared (MWIR) layer followed by the growth of an
approximate 1 mm short-wave infrared (SWIR) cap
layer. Both layers were n-type doped in-situ with
indium. Finally, an ~1000 Å CdTe cap layer was
grown.
Three-inch CdTe(211)B/Si substrates, grown in a
separate chamber by EPIR Ltd., were used as sub-
Fig. 1. RHEED images taken from a sample nucleated by maintaining a constant thermocouple set point. The layer goes from low temperature
growth (b and c) to high temperature growth (e and f) within approximately five minutes.

MBE Growth and Device Processing of
MWIR HgCdTe on Large Area Si Substrates
719
heating filament instead of remaining in thermal
contact with the substrate holder. Hence, maintain-
ing a constant surface temperature during the nucle-
ationofHgCdTeisnotastraight-forwardproposition.
It is known that the emissivity of the epilayer
will change as HgCdTe begins to nucleate on the
CdTe surface causing a subsequent change in surface
temperature. In addition to this effect, the difference
in substrate heating mechanisms (radiative as op-
posed to conductive) due to the non-contact mounting
method is also speculated to affect the substrate
surface temperature invariant of the substrate ther-
mocouple setting.
Figure 1 shows the RHEED evolution of a layer
nucleated by maintaining a constant thermocouple
temperature and substrate heater power. As clearly
seen in the figure, the RHEED pattern changes sig-
nificantly during the nucleation of this layer.
Figure 1a shows the surface before HgCdTe growth
hasbeeninitiated.ThelayerisexposedonlytoHgflux
at this point and the RHEED pattern indicates a
smooth surface. In Fig. 1b and c, one and two minutes
of HgCdTe nucleation have occurred, respectively.
Large spots are now visible on the streaks and even
faint twinning is observed. These RHEED patterns
are indicative of low temperature HgCdTe nucle-
ation. However, after 3 minutes of nucleation has
occurred, these features disappear and a streaky
RHEED image reappears, as shown in Fig. 1d, indi-
cating that HgCdTe growth is occurring within the
proper temperature window. Figure 1e was taken
after4minutesofHgCdTenucleationandtheRHEED
image now shows sign of surface deterioration due to
high temperature growth conditions. Note that the
streaks have become less bright and much shorter in
length.Finally,ahighlydisorderedsurfacewithsome
faceting is seen in Fig. 1f, which was taken after only
five and a half minutes of HgCdTe growth. Clearly,
within only 5 minutes the HgCdTe surface conditions
Fig. 2. RHEED images taken during a HgCdTe growth run utilizing the
substrate thermocouple ramping profile. RHEED images remained
constant throughout the nucleation and growth.
strates for these experiments. The wafers were pre-
pared by first degreasing in two separately heated
trichlorolethylene baths followed by rinses in two
methanol baths. A five second etch in an approximate
1%bromine/methanolsolutiontoremovethetopmost
~500 Å of CdTe was then performed, followed by
several methanol and deionized (DI) water rinses.
Finally, the substrate was dried with nitrogen and
loaded into the MBE system. Once inside the growth
chamber, the sample was heated slowly to the CdTe
growth temperature where a thin CdTe layer was re-
grown and annealed to ensure a smooth and clean
initial surface prior to HgCdTe nucleation. A 12 keV
RHEEDsystemwasusedtomonitorCdTeandHgCdTe
growthin-situ. Etchpitdensity(EPD)measurements
were conducted on selected samples to characterize
the structural properties of the HgCdTe material. To
characterize the electrical properties, Hall measure-
ments were made using the van der Pauw technique
for temperatures ranging from 300 K to 50 K on both
as-grown and annealed samples using a magnetic
field of 0.35 T. Sample annealing for Hall measure-
ments took place at 235∞C for 12 hours under a
Hg-saturated atmosphere. Finally, layer thickness
and x-value determination were calculated from fit-
tings of Fourier transform infrared transmission
(FTIR) measurements.
HgCdTe MATERIAL GROWTH
AND CHARACTERIZATION
By using indium-free mounting, the substrate is
not chemically adhered to a solid, opaque substrate
holder, but is, instead, held in place by a “snap-ring”
that clamps only the edge of the substrate to the edge
of the indium-free substrate holder. Since this is a
non-contact mounting method, all of the issues asso-
ciated with graphite mounting are removed. How-
ever, in this mounting configuration, the back of the
substrate is now directly exposed to the substrate
Fig. 3. Plot of etch pit density measurements versus Cd composition
for several layers nucleated with the same substrate ramping profile.

720
Brill, Velicu, Boieriu, Chen, Dhar, Lee, Selamet, Sivananthan
by using spectroscopic ellipsometry to monitor and
maintain a constant x-value with respect to growth
time.6 However, both the shape of the ramping profile
and the change in initial to final substrate tempera-
tures are expected to differ as the Cd composition is
decreased. As seen in Fig. 1, RHEED is a capable tool
for monitoring the surface growth conditions and
determining whether the growth is occurring in the
low temperature, optimized temperature, or high
temperature regimes. Through careful observation of
the RHEED pattern during the nucleation of several
HgCdTe growth runs, we were able to develop a
substrate ramping profile that successfully compen-
sated for the increase in surface temperature and
produced high quality MWIR material growth.
Figure 2 shows such a substrate ramping profile and
the resultant RHEED images. As seen in the figure,
the RHEED images from this growth run remained
constantthroughouttheentirenucleationandgrowth
process.
However, it is important to note that the proper
substrate ramping profile necessary to maintain a
constant surface temperature is dependent on the
x-value of the layer being grown. Figure 3, which is a
plot of EPD values versus Cd composition for layers
nucleated with virtually identical ramping profiles
and under similar growth conditions, depicts this
fact. In these growth runs, the EPD values reach a
minimumforHgCdTethatwasgrownwithanx-value
ranging from 0.28 to 0.31. Dislocation densities from
9 ¥ 106 cm–2 to 1 ¥ 107 cm–2 were routinely obtained for
HgCdTe nucleated within this range of x-value and
with this specific ramping profile. In contrast, as
higher x-value material was grown with this same
ramping profile, the EPD values of the material
increases almost linearly as a function of the devia-
tion from the proper x-value window (0.28–0.31) indi-
cating the degradation of the material quality.
Figure 4 depicts the corollary situation in which two
Fig. 4. Different substrate ramping profiles used to nucleate two
HgCdTe layers with nearly identical alloy compositions. The insets
show the respective surfaces at 800 times magnification after etch pit
dislocation revealing etches.
as determined by RHEED dramatically change from
a low temperature growth regime to a high tempera-
ture growth regime. The magnitude of this tempera-
ture change is due to the absence of any conducting
layer, such as graphite, between the substrate heater
and the substrate and to the fact the thermocouple is
no longer in direct contact with the substrate/holder
system. Therefore, if non-contact mounting methods
are to be used, a mechanism needs to be developed to
compensate for this effect.
To meet the needs of growing quality HgCdTe on
indium-free mounted CdTe/Si substrates, an empiri-
cally derived substrate ramping profile was devel-
opedtomaintainthepropergrowthconditionsduring
the initial nucleation stages. A similar method has
been successfully implemented in growing SWIR
HgCdTematerialonindium-freemountedsubstrates
a
b
Fig. 5. Plot of (a) carrier concentrations and (b) mobilities versus inverse temperature for several annealed HgCdTe layers nucleated using the
appropriate ramping profiles.

MBE Growth and Device Processing of
MWIR HgCdTe on Large Area Si Substrates
721
the current-voltage measurements for a typical
40 mm ¥ 40 mm single diode are shown in Fig. 6. The
cut-off wavelength of this specific diode is 5.8 mm at
77K. The300Kbackgroundphotocurrentatzerobias
ismeasuredtobe–0.75pAandthebreakdownvoltage
is in excess of –500 mV. A tunneling mechanism is
responsible for breakdown at the larger reverse bias.
The RA for this device was calculated using the
electrical junction area and was measured to be 1.8 ¥
106 W-cm2. This peak RA value is obtained, as ex-
pected, for a slightly negative voltage of –40 mV. The
majority of single element devices measured also
show very well behaved I-V curves, with electrical
properties comparable to HgCdTe processed on
CdZnTe bulk substrates.
The photomask used for single element device
fabrication included five different diode sizes:
40¥40mm2,100¥100mm2,250¥250mm2,500¥500mm2,
and 1000 ¥ 1000 mm2. The separation between indi-
vidual elements is larger than the diffusion length in
order to avoid any cross talk effects. An area depen-
dence study of these device characteristics suggests a
different ramping profiles were used to grow layers
with nearly identical x-values. Again, as deviations
occur from the near optimum ramping profile needed
to grow the appropriate x-value layer, the dislocation
density is seen to increase dramatically.
Although these results are not unexpected, they
highlight the importance of tailoring the substrate
ramping profile with the Cd composition of the layer.
In general, for each different x-value grown a unique
ramping profile will have to be derived. However, in
practice one ramping profile should be adequate to
grow HgCdTe material within a small range of Cd
composition. As the x-value is changed outside this
range of Cd composition, another ramping profile will
have to be utilized. Furthermore, these results indi-
cate the importance of developing a model to explain
and predict the change in the epilayer surface tem-
perature as a function of x-value and growth time
when using non-contact substrate mounting.
Hallmeasurementswereconductedtofurtherchar-
acterize the material grown using the empirically
derived substrate ramping profiles. Carrier concen-
trations in the 1014 cm–3 range were obtained for
several of the layers grown with mobilities in the low
to mid 104 cm2/Vsec range. Figure 5 shows both the
carrier concentration and mobility measurements of
several annealed layers. As seen in the figure, well
behaved Hall characteristics are observed with car-
rier concentrations increasing as the In cell tempera-
ture was increased, as expected, for similar x-value
material. Additionally, lifetime measurements were
conducted using photoconductive decay on one of the
samplesgrownusingtheappropriatesubstrateramp-
ing profile. At 80 K, a lifetime of 2.8msec was obtained
for an x = 0.37 sample. The electrical characteriza-
tions conducted during this study correlate well with
the EPD data and confirm that high quality HgCdTe
material can be grown by utilizing the substrate
ramping profiles to maintain a constant epilayer
temperature during the nucleation stages of HgCdTe
mounted on indium-free holders.
Fig. 6. Current-Voltage plot for an MWIR diode fabricated from a
HgCdTe layer grown using the appropriate substrate ramping profile.
RA measures 1.8 ¥ 106 W cm2 for this diode at –40 mV which is
comparabletodevicesfabricatedfromHgCdTegrownonbulkCdZnTe
substrates.
HgCdTe DEVICE FABRICATION
AND RESULTS
To further demonstrate the quality of the HgCdTe
materialandtheapplicabilityoftherampingprofiles,
both single element and 32 ¥ 32 photovoltaic devices
were fabricated from these layers using a planar
configuration. Each of the epitaxial structures was
processed into photodiodes using conventional photo-
lithographic techniques. Arsenic ion implantation at
350 keV using a dosage of 1014 ions/cm2 and a three-
step post implant annealing was used to form the
planar p-on-n junction. Sample passivation was con-
ducted using CdTe deposited by MBE. Ohmic
contacts were formed by e-beam evaporation on both
p-type top layer and n-type absorber layer using
Au and In, respectively.
Processed device characteristics were assessed by
measuring current-voltage curves and checking the
device response to external radiation. The results of
Fig. 7. Current-Voltage plots of several diodes from a 32 ¥ 32 MWIR
array showing good uniformity across the array near the operating
range of the device.

722
Brill, Velicu, Boieriu, Chen, Dhar, Lee, Selamet, Sivananthan
bulk limited behavior,7 with smaller area devices
showing better electrical properties. The tempera-
ture dependence of the R0A product for these devices
was also studied. Low breakdown voltage and zero
bias currents are maintained up to 200 K. Diffusion
limited behavior has been observed for temperatures
larger than 140 K.
theincreaseinthesurfacetemperatureoftheepilayer
during growth, we have empirically derived a sub-
strate ramping profile from RHEED observations
from several HgCdTe growth runs. This technique
has been successfully employed to nucleate and grow
device quality HgCdTe. Etch pit density measure-
mentsindicategoodmaterialqualityandalsodemon-
strate that the appropriate ramping profile is a func-
tion of HgCdTe alloy composition as well as growth
time. Single element and 32 ¥ 32 array devices have
been fabricated with characteristics that are compa-
rable to HgCdTe grown on bulk substrates.
32 ¥ 32 arrays have also been fabricated from
HgCdTe layers grown using the substrate ramping
profile. The arrays have been designed for use in the
backside-illuminated configuration where the array
is hybridized onto a silicon readout-integrated circuit
(ROIC) by an indium bump interconnect. The pitch
size is 53 mm and the separation between individual
pixels is 18 mm. Our mask design allowed for the
testing of ten diodes from every array. In Fig. 7 we
show the I-V characteristics for several individual
pixels from the array. The figure shows good unifor-
mity of the array near the operating range of the
device. The average 300 K background photocurrent
at zero bias for the tested diodes is 0.33 pA with a
standard deviation of 0.25 pA. The mean R0A product
is 5.9 ¥ 105 W-cm2 with a standard deviation of 5.4 ¥
105 W-cm2. The spread in R0A values indicates the
presence of bulk defects. By understanding and mod-
eling the mechanism for the epilayer surface tem-
perature increase during nucleation which will lead
to further optimization of the substrate ramping
profiles, we expect to substantially reduce material
defects induced during HgCdTe growth and improve
theoveralldevicequality. Theoperabilityofthearray
is reasonably good with an average of two failed test
pixels per array.
ACKNOWLEDGEMENTS
We wish to acknowledge the support and funding
from the Army Research Laboratory for this program
under contract number DAAL01-98-2-0079. Addi-
tionally, wewishtothankL.A. AlmeidaatNVESDfor
his assistance with some of the data acquisition.
REFERENCES
1. T.J. de Lyon, R.D. Rajavel, J.A. Vigil, J.E. Jensen, O.K. Wu,
C.A Cockrum, S.M. Johnson, G.M. Venzor, S.L. Bailey,
I. Dasai, W.L. Ahlgren, and M.S. Smith, J. Electron. Mater.
27, 550 (1998).
2. P.S. Wijewarnasuriya, M. Zandian, D.D. Edwall,
W.V. McLevige, C.A. Chen, J.G. Pasko, G. Hildebrandt,
A.C. Chen, J.M. Arias, A.I. D’Souza, S. Rujirawat, and
S. Sivananthan, J. Electron. Mater. 27, 546 (1998).
3. T.J. de Lyon, J.E. Jensen, M.D. Gorwitz, C.A. Cockrum,
S.M. Johnson, and G.M. Venzor, J. Electron. Mater. 28, 705
(1999).
4. T. Ashley and C.T. Elliot, Electron. Lett. 21, 451 (1985).
5. C.T. Elliot, N.T. Gordon, and A.M. White, Appl. Phys. Lett.
78, 2881 (1999).
6. L.A. Almeida, N.K. Dhar, M. Martinka, and J.H. Dinan,
J. Electron. Mater. 29, 754 (2000).
CONCLUSIONS
7. R. Ashokan, N.K. Dhar, B. Yang, A. Akhiyat, T.S. Lee,
S. Yusuf, and S. Sivanathan, J. Electron. Mater. 29, 636
(2000).
WehavedemonstratedthegrowthofMWIRHgCdTe
material on 3≤ CdTe/Si substrates mounted using
non-contact mounting techniques. To compensate for
