Bioreversible derivatives of phenol. 2. Reactivity of carbonate esters with fatty acid-like structures towards hydrolysis in aqueous solutions

Article abstract of DOI:10.3390/12102396

A series of model phenol carbonate ester prodrugs encompassing derivatives with fatty acid-like structures were synthesized and their stability as a function of pH (range 0.4-12.5) at 37°C in aqueous buffer solutions investigated. The hydrolysis rates in aqueous solutions differed widely, depending on the selected pro-moieties (alkyl and aryl substituents). The observed reactivity differences could be rationalized by the inductive and steric properties of the substituent groups when taking into account that the mechanism of hydrolysis may change when the type of pro-moiety is altered, e.g. n-alkyl vs. t-butyl. Hydrolysis of the phenolic carbonate ester 2-(phenoxycarbonyloxy)-acetic acid was increased due to intramolecular catalysis, as compared to the derivatives synthesized from ω-hydroxy carboxylic acids with longer alkyl chains. The carbonate esters appear to be less reactive towards specific acid and base catalyzed hydrolysis than phenyl acetate. The results underline that it is unrealistic to expect that phenolic carbonate ester prodrugs can be utilized in ready to use aqueous formulations. The stability of the carbonate ester derivatives with fatty acid-like structures, expected to interact with the plasma protein human serum albumin, proved sufficient for further in vitro and in vivo evaluation of the potential of utilizing HSA binding in combination with the prodrug approach for optimization of drug pharmacokinetics.

Full text of DOI:10.3390/12102396

Molecules 2007, 12, 2396-2412
molecules
ISSN 1420-3049
© 2007 by MDPI
www.mdpi.org/molecules
Full Paper
Bioreversible Derivatives of Phenol. 2. Reactivity of Carbonate
Esters with Fatty Acid-like Structures Towards Hydrolysis in
Aqueous Solutions
Jesper Østergaard* and Claus Larsen†
Department of Pharmaceutics and Analytical Chemistry, Faculty of Pharmaceutical Sciences,
University of Copenhagen, Universitetsparken 2, DK-2100 Copenhagen O, Denmark; †E-mail:
csl@farma.ku.dk
* Author to whom correspondence should be addressed. E-mail: joe@farma.ku.dk
Received: 28 September 2007; in revised form: 29 October 2007 / Accepted: 29 October 2007 /
Published: 30 October 2007
Abstract: A series of model phenol carbonate ester prodrugs encompassing derivatives
with fatty acid-like structures were synthesized and their stability as a function of pH
(range 0.4 – 12.5) at 37oC in aqueous buffer solutions investigated. The hydrolysis rates in
aqueous solutions differed widely, depending on the selected pro-moieties (alkyl and aryl
substituents). The observed reactivity differences could be rationalized by the inductive
and steric properties of the substituent groups when taking into account that the mechanism
of hydrolysis may change when the type of pro-moiety is altered, e.g. n-alkyl vs. t-butyl.
Hydrolysis of the phenolic carbonate ester 2-(phenoxycarbonyloxy)-acetic acid was
increased due to intramolecular catalysis, as compared to the derivatives synthesized from
ω-hydroxy carboxylic acids with longer alkyl chains. The carbonate esters appear to be less
reactive towards specific acid and base catalyzed hydrolysis than phenyl acetate. The
results underline that it is unrealistic to expect that phenolic carbonate ester prodrugs can
be utilized in ready to use aqueous formulations. The stability of the carbonate ester
derivatives with fatty acid-like structures, expected to interact with the plasma protein
human serum albumin, proved sufficient for further in vitro and in vivo evaluation of the
potential of utilizing HSA binding in combination with the prodrug approach for
optimization of drug pharmacokinetics.

Molecules 2007, 12
2397
Keywords: Bioreversible derivatives, carbonate ester, hydrolysis kinetics, prodrug,
reactivity
Introduction
A major cause of failures in early drug development is, together with toxicological issues, poor
drug pharmacokinetics. The high affinity ligands generated in drug discovery are rarely endowed with
physical chemical properties favorable for drug transport to the target site within the body. In recent
years efforts have been made to improve the drug-like properties of the leads generated in the drug
screening facilities [1-5]. However, concurrent optimization of pharmacodynamic and
pharmacokinetic properties may not always be achievable. In such cases, the prodrug approach [6-11]
may be feasible, enabling transient modification of pharmacokinetic properties and thus improving the
drug performance of chemical entities characterized by suitable in vitro activity but poor transport
properties. Human serum albumin (HSA) is the major plasma protein, interacting with a variety of
endogenous and exogenous substances, and in particular with lipophilic organic anions such as fatty
acids and non-steroidal anti-inflammatory drugs [12-17]. It is generally recognized that HSA binding
plays a major role in determining the in vivo fate of many drug substances [17-20]. Despite this fact,
reversible drug-HSA binding has been used deliberately to improve drug pharmacokinetics a few cases
only, e.g. [21-25].
With the overall objective of assessing the potential of utilizing plasma protein binding interactions
in combination with the prodrug approach for improving pharmacokinetics we have studied a series of
bioreversible derivatives of phenol [26]. Phenolic drugs may be subject to extensive first-pass
metabolism [27]. Thus, phenol was selected as a model drug substance because the metabolism has
been studied extensively [28-31]. Further, it has been used previously as a model compound in prodrug
related studies aiming at the circumvention of first-pass metabolism [32-35]. A series of carbonate
ester bioreversible derivatives of phenol (Table 1) was synthesized, including derivatives possessing a
fatty acid-like structure as a means for building in affinity for HSA in the structures. Since carbonate
esters have been subject of much less attention than carboxylic acid ester derivatives in the prodrug
context, it was found of interest to investigate in more detail the hydrolysis kinetics and reactivity of
phenolic carbonate ester derivatives of potential interest in prodrug design. In the current work we
present the synthesis procedures and the obtained pH rate profiles for the hydrolysis of a series of
carbonate esters of phenol encompassing derivatives with fatty acid-like structures. Aspects pertaining
to the binding of the carbonate esters derivatives to HSA and the effects of HSA on the carbonate ester
stability are reported in the accompanying communication [26].

Molecules 2007, 12
2398
Results and Discussion
Synthesis
The carbonate esters with fatty acid-like structure were synthesized from phenyl chloroformate and
the appropriate ω-hydroxycarboxylic acids or ethyl ester of the ω-hydroxycarboxylic acids, essentially
following the procedures described by King et al. [36] (see Experimental section for details). In
addition to the carbonate esters with fatty acid-like structure listed in Table 1, attempts were made to
synthesize 4-(phenoxycarbonyloxy)-butyric acid. These efforts were however unsuccessful,
presumably due to rapid formation of γ-butyrolactone.
Table 1. Rate constants for the hydrogen ion catalyzed (kH), the spontaneous (ko), and
hydroxide ion catalyzed (kOH) hydrolysis of various carbonate esters and phenyl acetate
and estimated ionization constants at 37oC and μ = 0.50 M.
O
O
C O R
kH
(M-1s-1)
1.4 × 10-6
1.8 × 10-3
ko
(s-1)
kOH
(M-1s-1)
1.3
Compound
R
pKa
1
2
3
4
-C2H5
6.8 × 10-8
4.1 × 10-4
1.2 × 10-5
4.7 × 10-6
3.7 × 10-4a)
6.5 × 10-8
-C(CH3)3
-C6H5
3.3 × 10-2
12.6
-CH2COOH
1.0
2.6; 2.42b)
5
6
7
8
9
-(CH2)5COOH
-(CH2)7COOH
-(CH2)11COOH
-(CH2)15COOH
Phenyl acetate
1.7 × 10-6
3.2 × 10-4
1.0
1.0
1.0
4.70b)
4.79b)
3.9 × 10-8
4.1
a) k’o (cf. Equation 2)
b) pKa was determined by capillary electrophoresis at 25oC and μ = 0.050 M
Kinetics of chemical hydrolysis
As a part of the pharmaceutical chemical characterization the kinetics of hydrolysis of the
bioreversible derivatives of phenol was investigated in aqueous buffer solutions of ionic strength (μ)
0.50 M at 37oC. The stability of carbonate esters has been subject to less attention than carboxylic acid
esters. Thus, the influence of pH on hydrolysis in aqueous solutions was studied in some detail. The
structures of the compounds included in the study are depicted in Table 1 and comprise eight carbonate
esters and phenyl acetate (9). Hydrolysis experiments were started by adding an acetonitrile stock
solution to the preheated buffer solutions providing initial carbonate ester concentrations of about 1 ×

Molecules 2007, 12
2399
10-4 M. The stability of bioreversible derivatives 1-5 was investigated in the pH range 0.4 – 12.5. Due
to solubility limitations, derivatives 6 and 7 were only studied in alkaline solution (pH ranges 8.4 –
12.4 and 10 – 12.4, respectively) whereas hydrolysis studies of 8 were not performed.
Under the experimental conditions employed the hydrolysis reactions were found to obey first-
order kinetics. In most cases general acid/base catalysis of the buffer substances were negligible. In
cases where buffer catalysis was observed the pseudo-first-order rate constants at zero buffer
concentration (k) were determined from the y-intercept of linear plots of the observed pseudo-first-
order rate constants versus total buffer concentration. The pH of the hydrochloric acid and sodium
hydroxide solutions was calculated according to [37]. Rate constants obtained by the UV
spectrophotometric method and HPLC agreed within 5%. Especially the fatty acid-like structure
carbonate esters with long alkyl chains may be expected to be endowed with amphiphilic properties.
However, the adherence to first-order kinetics indicates that aggregation or micellization was not
occurring in the concentration range studied or did not affect aqueous stability. The effect of pH on
hydrolysis rates at 37oC is depicted in Figure 1. The stability of the bioreversible derivatives in
solution at 37oC varied widely as reflected in the half-lives (in hours) of the esters 1-5 and 9 at their
rate minimum in the pH range investigated, which were 2800 (120 days), 0.47, 17, 30, 3000 (125
days), and 3700 (150 days), respectively.
Figure 1. pH-rate profiles for the hydrolysis of compounds 1 (U), 2 (V), 3 („), 4 (z), 5
(-), and 9 ({) in aqueous solution at 37oC (μ = 0.50 M).
0
-2
-4
-6
-8
0
2
4
6
8
10
12
14
pH
In the pH range investigated, the shape of the pH-rate profiles of compounds 1, 2 and 9 indicates
that the pseudo-first-order rate constant at zero buffer concentration can be adequately described by
specific acid, specific base, and spontaneous or water catalyzed hydrolysis reactions:

Molecules 2007, 12
2400
Kw
aH
k = kH aH + ko + kOH
(1)
where aH is the hydrogen ion activity, Kw is the autoprotolysis constant of water, and ko, is the rate
constant for the spontaneous reaction. kH and kOH refer to the second-order rate constants for the
hydrogen ion and hydroxide ion catalyzed reactions, respectively. The hydroxide ion activity, aOH, is
given by the ratio Kw/aH. For diphenyl carbonate (3) specific acid catalysis was not observed in the
investigated pH range, thus, only the last two terms of Equation 1 was used to describe the pH-rate
profile.
The rate expression necessary to describe the overall hydrolysis of 5 is given by:
aH
aH
Ka
Kw
Ka
k = kH aH
+ ko
+ ko´
+ kOH
(2)
aH + Ka
aH + Ka
aH + Ka
aH aH + Ka
where Ka is the apparent ionization constant of the carbonate ester, kH is the second-order rate constant
for the hydrogen ion catalyzed reaction of the neutral form of the ester, and kOH represents the second-
order rate constant for the hydroxide ion catalyzed reaction of the ionized form of the ester. ko and k’o
are macro reaction constants [38] with ko related to the two kinetically equivalent reactions, viz.
spontaneous reaction of the neutral form of the ester and specific acid catalyzed hydrolysis of the
anionic species; k’o is associated to the following kinetically equivalent reactions, viz. the spontaneous
reaction of the deprotonated form of the ester and the specific base catalyzed hydrolysis of the neutral
form. From the present data, it is not possible to distinguish between the various processes associated
with ko and k’o. However, the obtained rate data may suggest that the neutral and anionic (5) exhibit
quite similar susceptibility to undergo hydrolysis in the pH range 3-6, most likely because the
carboxylic acid group of the hexanoic acid derivative (5) is placed far away from the reactive center of
the molecule. Thus, the constants presented in Table 1 for 5 were obtained by fitting to Equation 1. For
the acetic acid derivative (4), specific acid catalysis of hydrolysis was not observed in the pH range
studied, thus only the three last terms of Equation 2 were required to describe the hydrolysis kinetics of
4. For the derivative 4, stability was assessed in hydrochloric solutions with μ > 0.5 M. Rate and
ionization constants were determined from regression analysis and are compiled in Table 1.
Reactivity of carbonate esters
The reactivity differences observed among the carbonate esters must be ascribed to either polar or
steric effects of the R-groups. The proposed mechanisms for hydrolysis of the carbonate esters
catalyzed by specific acid, water, and specific base are outlined in Scheme 1. Apparently, the
hydroxide ion catalyzed hydrolysis has been studied the most. The hydrolysis of alkyl carbonates in
the presence of hydroxide ions has been shown to be a two-step process; a second-order reaction is
followed by a slow first-order decomposition of a monoalkyl carbonate [39-41].
A similar reaction scheme has been proposed for diaryl carbonates, though, the cleavage of the
monophenyl carbonate anions was suggested to be extremely fast [42]. Cooper et al. [43] determined
the second-order rate constants for the alkaline hydrolysis of a series of symmetric substituted diaryl
carbonates. The rate of reaction was increased by the presence of electron-withdrawing and decreased

Molecules 2007, 12
2401
by electron-donating substitutents, respectively. Rate data for diaryl esters with meta and para
substituents were fitted to the Hammett equation [44]. The significance of steric effects were apparent
by comparison of hydrolysis rates of ortho carbonate esters with meta and para substituted carbonates
[43]. As for carboxylate esters [45], carbonate ester hydrolysis is expected to proceed through a
tetrahedral intermediate by a stepwise mechanism [46]. The rate limiting step being the formation of
the tetrahedral intermediate by addition of the hydroxide ion [46,47].
Scheme 1. Proposed reaction mechanisms for (A) specific acid catalyzed, (B) water
catalyzed, and (C) specific base catalyzed hydrolysis of carbonate esters.
Tentatively, inductive effects of the R-groups may be suggested to account for the reactivity of the
carbonate esters towards hydroxide ion catalyzed hydrolysis shown in Table 1. To aid interpretation of
the rate data, the Taft polar substituent parameter σ* (values taken from [48]) of the R-moieties may
be useful. Ethyl phenyl carbonate (1, σ* = -0.10) is slightly more susceptible to alkaline hydrolysis
than 5, 6, and 7, which have larger electron-donating capabilities (the σ*-value of 5-7 were taken to be
similar to that of the n-alkyl substituents with similar number of carbons, i.e. around -0.16). The t-

Molecules 2007, 12
2402
butyl derivative is the least reactive of the derivatives, this may be expected due to the bigger electron-
donating power of branched alcohols (σ* = -0.30). However, the main contribution to the stability of 2
may be steric hindrance. The high reactivity of 3 as compared to 1 is expected from the electron-
withdrawing properties of the phenyl ring (σ* = -0.60) and in excellent agreement with the work of
Cooper and Williams [42]. The kOH obtained for the acetic acid derivative (4) is similar to that of 5, 6,
and 7; from the Taft polar substituent constant σ* (σ* = -0.06 for CH2COO-) reactivity was expected
to be higher than that of 1, however, steric hindrance and electrostatic repulsion due to the nearby
carboxylate anion may most likely lower the reactivity. The carboxylate anions of 5, 6, and 7 are
thought to be positioned too far away from the carbonyl carbon to provide a significant shielding
effect.
Analogous accounts for the structure-reactivity relations found for the hydroxide ion catalyzed
hydrolysis of various alkyl aryl and diaryl carbonate esters have been set forward. The reactivity of
ethyl p-nitrophenyl carbonate, ethyl phenyl carbonate and diethyl carbonate was found to be governed
by the polar effects of the alcohol and phenol moieties, as reflected by their pKa values [49]. The
relative hydrolysis rates of four alkyl carbonate esters of salicylic acid at pH 12 were rationalized by
the electron-donating capabilities of the alkyl substituents [50]. The ethyl derivative was slightly more
reactive (~20-30% more reactive) than esters possessing longer alkyl chains as found in the present
study. Similarly differences in the specific base catalyzed hydrolysis of four alkyl carbonates of
acetaminophen (paracetamol) were accounted for by the inductive properties of the alcohol moieties
[51], as was the hydrolysis of 11 carbonate esters of acetaminophen studied at pH 7.4 [52].
As for carboxylic acid esters, the catalytic coefficient for the specific acid catalyzed process is
much smaller than that of the base catalyzed reaction. The hydrogen ion catalyzed hydrolysis is
thought to occur through a multistage process (AAc2 [53]) (Scheme 1A). A rapid preequilibrium
protonation step is followed by a slow bimolecular reaction, the attack of a water molecule, and
carbonyl-oxygen fission [54-56] and subsequently by a fast unimolecular acyl-oxygen fission of the
alkyl hydrogen carbonate [55,57]. Ethyl phenyl carbonate [42] has previously been found to be subject
to specific acid catalysis. However, in contrast to the earlier studies [42,54] conducted in mixed
organic solvent-aqueous solutions and elevated temperature, specific acid catalysis was not observed
for diphenyl carbonate in the present study. Specific acid catalyzed hydrolysis of carboxylic acid esters
is governed primarily by steric effects [58]. Thus, in contrast to the obtained results, the hydrogen ion
catalyzed hydrolysis of 1 was expected to be slightly higher than that for 5. The rate constant
determined for the t-butyl derivative 2 is several orders of magnitude higher than expected from steric
considerations. However, acid catalyzed hydrolysis of t-butyl carboxylic acid esters has been found to
proceed through a different mechanism than esters of primary and secondary alcohols involving
cleavage of the alkyl-oxygen bond (AAL1) [58-60]. An alternative mechanism may also be the cause of
the high susceptibility of carbonate ester 2 towards hydrogen ion catalyzed hydrolysis.
The spontaneous or water catalyzed hydrolysis of carbonate esters has been proposed to proceed
through the same mechanism as the hydroxide ion catalyzed reaction (BAc2) (Scheme 1B), a water
molecule being the nucleophile instead of the hydroxide ion [42,43]. Water catalyzed hydrolysis of
meta substituted [43] and para substituted [46] diaryl carbonates has been found to fit the Hammett
equation, i.e. reactivity is governed by polar effects in a fashion similar to the hydroxide ion catalyzed

Molecules 2007, 12
2403
hydrolysis [43]. However, the spontaneous reactivity of the investigated carbonate esters in Table 1
does not parallel the reactivity towards specific base catalysis for various reasons. Compared to the
other derivatives, the t-butyl derivative (2) is relatively more susceptible to water catalyzed hydrolysis
than specific base catalysis, i.e. the kOH:ko ratio is much smaller. The hydrolysis of t-butyl acetate has
been found proceed through a different mechanism (BAL1) involving the formation of t-butyl
carbonium ion [61]. Thus, increased reactivity of 2 might be ascribed to the hydrolysis reaction
proceeding through a different mechanism. The increased spontaneous degradation of 2-
(phenoxycarbonyloxy)-acetic acid (4) is presumably due to intramolecular catalysis by the carboxylate
anion. Intramolecular catalysis of carbonate ester hydrolysis by the carboxylate anion may also be the
cause of the high lability of the salicylic acid carbonate esters studied by Dittert et al. at pH 7.4 as
compared to pH 12 [50]. Other examples of intramolecular catalysis involved in carbonate ester
hydrolysis can be found [47,62]. Further investigations are required to distinguish whether the
increased rate of hydrolysis is due to intramolecular nucleophilic catalysis or general base catalysis
involving the carboxylic acid group. This topic has been discussed elsewhere, e.g. [63-66]. Attempts to
synthesize 4-(phenoxycarbonyloxy)-butyric acid were unsuccessful most probably due to the favored
cyclization of the ω-hydroxy butyric acid leading to γ-butyrolactone. For the hexanoic acid derivative
(5), the spontaneous hydrolysis proceeded with similar rates at the plateau around the pKa value of the
compound (4.70), indicating that the reactivity of the neutral and ionized form of the carbonate ester is
similar.
The effects of structural variations in carbonate esters on reactivity in aqueous solution have been
found largely to parallel the effects of similar variations in the alcohol moiety of carboxylic acid esters
[51,52]. Phenyl acetate (9) was included in the study allowing comparison between the two ester types.
It appears that the carboxylic acid ester is more prone to specific acid and base catalysis than the
corresponding carbonate esters, e.g. 1 and 5, but less sensitive towards water catalyzed hydrolysis. In a
study designing prodrugs of the opioid analgesic ketobemidone for buccal delivery 4 carboxylic acid
and 5 carbonate ester prodrugs were investigated. The same trend in reactivity, as observed here, was
found for the ethyl carbonate and acetate ester of the phenolic drug [67]. In line with these findings are
the rate constants for the hydroxide ion catalyzed hydrolysis of carbonate and carboxylic acid ester
prodrugs of paracetamol [51]. The ethyl and i-butyl carbonates being more stable than the acetate and
butyrate esters, the kOH being 68 and 70 versus 310 and 155 M-1 min-1, respectively.
Conclusions
The obtained results confirm that carbonate ester derivatives may constitute a feasible platform for
designing prodrugs of phenolic drug substances and that widely varying hydrolysis rates in aqueous
solutions may be achieved depending on the selected pro-moiety. The observed reactivity may be
rationalized from the inductive and steric effects exerted by the substituent groups when considering
that the mechanism of hydrolysis may vary depending on the specific pro-moieties. Hydrolysis of the
phenolic carbonate ester 2-(phenoxycarbonyloxy)-acetic acid was facilitated by intramolecular
catalysis in contrast to derivatives prepared from ω-hydroxy carboxylic acids with longer alkyl chains.
The carbonate esters appear to be less reactive towards specific acid and base catalysis than

Molecules 2007, 12
2404
corresponding carboxylic acid ester derivatives (phenyl acetate). Results underline that it is very
unlikely that phenolic carbonate ester prodrugs can be utilized in ready to use aqueous drug
formulations. However, the stability of the carbonate ester derivatives with fatty acid-like structure is
sufficient for further evaluation in vitro and in vivo of the potential of utilizing HSA binding in
combination with the prodrug approach for optimization of drug pharmacokinetics.
Experimental
Chemicals
Ethyl phenyl carbonate was obtained from Sigma Chemical Co. (St. Louis, MO, USA). Ethyl
glycolate and phenyl acetate were obtained from Acros Organics (Geel, Belgium). Diphenyl carbonate,
ethyl 6-hydroxyhexanoate, 12-hydroxydodecanoic acid, 16-hydroxyhexadecanoic acid, phenol, phenyl
chloroformate, 20 % technical grade solution poly(diallyldimethylammonium chloride) (PDMAC) Mw
400,000-500,000, 25 % technical grade solution poly(vinylsulfonate) sodium salt (PVS) Mw 4,000-
6,000, and t-butyl phenyl carbonate were obtained from Aldrich-Chemie (Steinheim, Germany). 8-
Hydroxyoctanoic acid and pyridine were obtained from Fluka Chemie GmbH (Buchs, Switzerland).
Silica gel 60 was obtained from Merck (Darmstadt, Germany). All other chemicals and solvents were
of analytical grade or better. Purified water from a Milli-Q deionization unit (Millipore, Bedford, MA,
USA) was used throughout.
Apparatus
An Aquarius CE7200 UV-spectrophotometer (Cecil Instruments, Cambridge, England) equipped
with a thermostatted cell compartment, using 10 mm quartz cuvettes, was used for kinetic
measurements. Data was collected and transferred to Microsoft Excel using HyperAccess Ver. 8.4
software (Hilgraeve, Monroe, MI, USA). HPLC was generally performed using a Merck-Hitachi L-
6200 pump, a L-4000 UV-detector, and a D-2000 Chromato-Integrator (Merck-Hitachi, Tokyo, Japan)
equipped with a Rheodyne 7125 injection valve with a 20 μL loop. ChromSpher C18 (150 × 4.6 mm; 5
μm particles) columns (Chrompack Varian, The Netherlands) were used. The mobile phases consisted
of acetonitrile and 0.1 % v/v H3PO4 in suitable proportions (10 to 70 % v/v of acetonitrile). The flow
rate was set at 1 ml/min and the effluent was monitored at 200 nm. Melting points were obtained on a
capillary melting-point apparatus and are uncorrected. Measurements of pH were conducted with a
Metrohm 744 pH Meter (Metrohm Ltd., Herisau, Switzerland). CE experiments were performed on a
Hewlett-Packard 3DCE (Avondale, PA, USA) equipped with a diode-array detector. Mass spectrometry
(MS) was performed on an ion trap (MSD Trap) from Agilent Tecnologies equipped with an
electrospray ion source operated in positive ion mode with the following settings: Capillary voltage: -
3000 V; drying gas temperature: 325oC; nebulizer gas 10 psi; drying gas: 4 L/min; skimmer 1: 15 V;
1
trap drive: 40. H-NMR spectra were recorded on a Varian Gemini 2000 (300 MHz) instrument in
CDCl3 solutions. Spectra were analyzed using gNMR 5.0.

Molecules 2007, 12
2405
Preparation of carbonate esters
The compounds were synthesized by procedures modified from those reported by King et al. [36].
HPLC was used to monitor progress of reactions.
2-(Phenoxycarbonyloxy)-acetic acid (4). Phenyl chloroformate (5.0 mL, 39.8 mmol) and ethyl
glycolate (4.15 mL, 39.8 mmol) were added to diethyl ether (200 mL) under continuous stirring in an
ice bath. Pyridine (3.2 mL, 39.8 mmol) in diethyl ether (200 mL) was then added dropwise over 3 h.
The mixture was stirred overnight at room temperature. The reaction mixture was filtered to remove
pyridine hydrochloride followed by rotary evaporation. The obtained residue was dissolved in 0.5 M
HCl-acetone (1:1, v/v, 200 mL) at 60oC under stirring. Progress of hydrolysis to obtain the desired
product was monitored by HPLC. Upon completion acetone was removed by rotary evaporation. The
remaining aqueous solution was extracted twice with diethyl ether. After drying over anhydrous
sodium sulphate the organic phase was evaporated in vacuo. The obtained residue was recrystallized
from diethyl ether – petroleum ether to give the title compound. m.p. 95.5-96.5oC (lit. [68]100-102oC);
Anal. calc. for C9H8O5: C, 55.11; H, 4.11; found: C, 55.12; H, 4.00; N, 0; MS: [M + Na]+ m/z = 219.0;
1
calculated monoisotopic mass m/z = 219.0; H-NMR: δ 7.21 (2H, m, J = 8.7, 0.5, 1.1, 2.0 Hz), 7.40
(2H, m, J = 8.7, 7.8, 0.5, 2.0 Hz), 7.27 (1H, m, J = 7.8, 1.1 Hz), 4.81 (2H, s).
6-(Phenoxycarbonyloxy)-hexanoic acid (5). Phenyl chloroformate (5.0 mL, 39.8 mmol) and ethyl 6-
hydroxyhexanoate (6.5 mL, 39.8 mmol) were added to diethyl ether (200 mL) under continuous
stirring on an ice bath. Pyridine (3.2 mL, 39.8 mmol) in diethyl ether (200 mL) was then added
dropwise over 4 h. The mixture was stirred overnight at room temperature. The reaction mixture was
filtered to remove pyridine hydrochloride, followed by rotary evaporation. The residue was dissolved
in acetone (120 mL), a portion of 1M HCl (40 mL) was added and the solution was heated to 70oC for
4 h under stirring. The reaction mixture was poured into toluene (100 mL), the organic phase washed
twice with water (50 mL) and once with saturated sodium chloride solution (20 mL) followed by
drying over anhydrous sodium sulphate. Precipitation occurred upon standing. Dry column flash
chromatography [69] (glass filter Ø 45 mm pore size 3, silica gel 60) was performed on the product the
fractions were eluted with ethyl acetate – hexane mixtures. The fractions containing the products were
collected and evaporated in vacuo, followed by recrystallization from hot diethyl ether; m.p. 68.5-
71oC; Anal. calc. for C13H16O5: C, 61.90; H, 6.39; found: C, 62.05; H, 6.46; N, 0; MS: [M + Na]+ m/z
1
= 275.2; calculated monoisotopic mass m/z = 275.1; H-NMR: δ 7.18 (2H, m, J = 8.7, 0.0, 1.3, 2.4
Hz), 7.39 (2H, m, J = 8.7, 7.9, 0.0, 2.8 Hz), 7.24 (1H, m, J = 7.9, 1.3 Hz), 4.26 (2H, t, J = 6.6 Hz), 2.40
(2H, t, J = 7.7 Hz), 1.74-1.79 (2H, m, J = 6.6, 6.6 Hz), 1.71 (2H, m; J = 7.7, 6.6 Hz), 1.28-1.35 (2H, m,
J = 6.6, 6.6 Hz).
8-(Phenoxycarbonyloxy)-octanoic acid (6). Phenyl chloroformate (0.39 mL, 3.12 mmol) and 8-
hydroxyoctanoic acid (0.50 g, 3.12 mmol) were added to diethyl ether (60 mL) under continuous
stirring on an ice bath. Pyridine (0.25 mL, 3.12 mmol) in diethyl ether (200 mL) was added dropwise
over 4 h. The mixture was stirred overnight at room temperature. The reaction mixture was filtered to

Molecules 2007, 12
2406
remove pyridine hydrochloride followed by rotary evaporation. The obtained solid was subjected to
dry column flash chromatography [69] (glass filter Ø 45 mm pore size 3, silica gel 60) was performed
on the product the fractions were eluted with ethyl acetate – hexane mixtures. The fractions containing
the products were collected and evaporated in vacuo, followed by recrystallization from hot diethyl
ether; m.p. 51-52oC; Anal. calc. for C15H20O5: C, 64.27; H, 7.19; found: C, 664.32; H, 7.23; N, 0; MS:
[M + H]+ m/z = 281.2; [M + Na]+ m/z = 303.3; calculated monoisotopic mass m/z = 281.1 (303.1); 1H-
NMR: δ 7.18 (2H, m, J = 8.1, 0.6, 1.1, 2.6 Hz), 7.38 (2H, m, J = 8.1, 7.8, 0.6, 1.8 Hz), 7.24 (1H, m, J =
7.8, 1.1 Hz), 4.25 (2H, t, J = 6.9 Hz), 2.36 (2H, t, J = 7.5 Hz), 1.75 (2H, m, J = 6.6, 6.9 Hz), 1.65 (2H,
m, J = 7.5, 6.6 Hz), 1.35-1.45 (6H, m).
12-(Phenoxycarbonyloxy)-dodecanoic acid (7). Carbonate ester 7 was prepared as 6, using 12-
hydroxydodecanoic acid (4.83 g, 22.3 mmol) initially dissolved in diethyl ether (200 mL); m.p. 67.5-
70oC; Anal. calc. for C19H28O5: C, 67.83; H, 8.39; found: C, 67.86; H, 8.50; N, 0; MS: [M + H]+ m/z =
1
337.4; [M + Na]+ m/z = 359.3; calculated monoisotopic mass m/z = 337.2 (359.2); H-NMR: δ 7.18
(2H, m, J = 9.1, 1.1, -0.1, 2.7 Hz), 7.39 (2H, m, J = 9.1, 7.6, -0.1, 1.6 Hz), 7.24 (1H, m, J = 7.6, 1.1
Hz), 4.25 (2H, t, J = 6.9 Hz), 2.36 (2H, t, J = 7.8 Hz), 1.74 (2H, m, J = 6.9, 6.6 Hz), 1.63 (2H, m, J =
7.8, 6.6 Hz), 1.35-1.45 (14H, m).
16-(Phenoxycarbonyloxy)-hexadecanoic acid (8). Carbonate ester 8 was prepared as 6, using 16-
hydroxyhexadecanoic acid (5.01 g, 18.3 mmol) initially suspended in diethyl ether (200 mL); m.p. 81-
82oC; Anal. calc. for C23H36O5: C, 70.38; H, 9.24; found: C, 70.15; H, 9.21; N, 0; MS: [M + H]+ m/z =
1
393.4. [M + Na]+ m/z = 415.4; calculated monoisotopic mass m/z = 393.3 (415.2); H-NMR: δ 7.18
(2H, m, J = 9.1, 1.4, 0.0, 2.9 Hz), 7.39 (2H, m, J = 9.1, 7.4, 0.0, 2.2 Hz), 7.24 (1H, m, J = 7.4, 1.4 Hz),
4.25 (2H, t, J = 6.9 Hz), 2.35 (2H, t, J = 7.7 Hz), 1.74 (2H, m, J = 6.9, 6.6 Hz), 1.63 (2H, m, J = 7.7,
6.6 Hz), 1.32-1.40 (22H, m).
Kinetic measurements
Stability of the phenol derivatives was studied in aqueous buffer solutions at 37 ± 0.2oC. Buffers
used were acetate, phosphate, borate and carbonate at total concentrations between 0.01 and 0.10 M.
At strongly acidic and alkaline pH, hydrochloric acid and sodium hydroxide solutions were used,
respectively. A constant ionic strength (μ) of 0.50 M was obtained by adding a calculated amount of
potassium chloride. Degradation was followed by direct UV-spectrophotometry or HPLC. Reactions
followed by UV-spectrophotometry in a thermostatted quartz cuvette containing aliquots (2.5 mL) of
preheated buffer solution, were initiated by addition of a 25 μL stock solution. Progress of reactions
was monitored by measuring the increase in absorbance at 269 or 287 nm, local absorption maxima for
phenol and phenolate, respectively. Pseudo-first-order rate constants were determined from slopes of
linear plots of ln (A∞ – At) versus time t, where A∞ and At are the absorbance measured at time infinity
and t, respectively [70] or by applying Guggenheim´s method to the absorbance readings [70,71]. For
experiments followed by HPLC, the reaction solutions were kept at constant temperature in a water
bath, and at appropriate time intervals samples were withdrawn and chromatographed immediately.

Molecules 2007, 12
2407
The experiments were initiated by addition of stock solutions in acetonitrile to buffer solutions giving
an organic solvent concentration of 1% or less, the initial carbonate ester concentration was 1 · 10-4 M.
Pseudo-first-order rate constants were determined by linear plots of the logarithm of residual
derivative versus time or by using the initial rate method [70]. Rate constants were obtained from
measurements done in (at least) triplicate. The relative standard deviation was below 5% in most cases.
Determination of pKa values by capillary electrophoresis
Fused-silica capillaries were obtained from Polymicro Technologies (Phoenix, AZ, USA) and
dynamically coated with PDMAC and PVS as described previously [72]. The PDMAC/PVS coated
capillary of 32 cm × 50 μm ID, with a length of 24 cm to the detector was used. UV detection was
performed at 200, 214, 230, and 250 nm. Injection was performed from the short end of the capillary
by applying pressure (50 mbar) for 2 s. The capillary cassette temperature was set to 20oC. The applied
voltage in the normal polarity mode was adjusted (6.5-20 kV) to give a mean capillary temperature of
25oC as calculated by the method of Kok [73]. Between measurements the capillary was flushed with
0.1 % PVS solution and electrophoresis buffer solution for 1 min each. Stock solutions of the
carbonate esters were prepared in dimethylsulfoxide (DMSO). Sample solutions were obtained by
dilution of the stock solutions with water to give a DMSO content of 1 % (v/v) and carbonate ester
concentrations of ~20 µg/mL. Buffer solutions covering the range from pH 1.3 to 8.0 were prepared by
mixing stock solutions to give the desired pH and an ionic strength of 0.05 M essentially as described
by [74]. CE buffer solutions were filtered through 0.45 μm nylon filters (Chromacol LTD, Herts, UK)
prior to use.
The effective electrophoretic mobility μeff was calculated from
⎛
⎞
lcld
V
1
1
⎜
⎜
⎟
⎟
μeff
=
−
(3)
t
t0
⎝
⎠
where lc is the total capillary length; ld is the length of the capillary from the inlet end to the detector; V
is the applied voltage; t and t0 are the measured migration times of the analyte and the electroosmotic
flow, respectively . Subsequently, the pKa values were determined from Eq. 4 by non-linear regression
analysis using the SigmaPlot 2000 software package (SPSS Inc. Chicago, IL, USA).
pH − pKa
10(
1+10(
) μB−
μeff
=
(4)
pH − pKa
)
where pKa is the apparent ionization exponent and μB- is the electrophoretic mobility of the fully
deprotonated species.
Acknowledgements
Drs. Jørgen Olsen and Claus Cornett of the Department of Pharmaceutics and Analytical
Chemistry at Faculty of Pharmaceutical Sciences, University of Copenhagen are acknowledged for
conducting the MS analysis and analyzing the NMR spectra, respectively.

Molecules 2007, 12
2408
References
1. Lipinski, C. A.; Lombardo, F.; Dominy, B. W.; Feeney, P. J. Experimental and computational
approaches to estimate solubility and permeability in drug discovery and development settings.
Adv. Drug Del. Rev. 1997, 23, 3-25.
2. Avdeef, A. Physicochemical profiling (Solubility, permeability and charge state). Curr. Topics
Med. Chem. 2001, 1, 277-351.
3. Muegge, I. Selection criteria for drug-like compounds. Med. Res. Rev. 2003, 23, 302-321.
4. van de Waterbeemd, H.; Smith, D. A.; Beumont, K.; Walker, D. K. Property-based design:
optimization of drug absorption and pharmacokinetics. J. Med. Chem. 2001, 44, 1313-1333.
5. Walters, W. P.; Murcko, A.; Murcko, M. A. Recognizing molecules with drug-like properties.
Curr. Opin. Chem. Biol. 1999, 3, 384-387.
6. Bundgaard, H. Design of prodrugs: Bioreversible derivatives for various functional groups and
chemical entities. In Design of prodrugs, Bundgaard, H., Ed.; Elsevier: Amsterdam, 1985; pp. 1-
92.
7. Larsen, C. S.; Østergaard, J. Design and application of prodrugs. In Textbook of drug design and
discovery, 3rd ed.; Krogsgaard-Larsen, P., Liljefors, T., Madsen, U., Eds.; Taylor & Francis:
London, 2002; pp. 410-458.
8. Testa, B.; Mayer, J. M. Concepts in prodrug design to overcome pharmacokinetic problems. In
Pharmacokinetic optimization in drug research, Testa, B., van de Waterbeemd, H., Folkers, G.,
Guy, R., Eds.; Verlag Helvetica Chimica Acta/Wiley-VCH: Zürich, 2001; pp. 85-95.
9. Testa, B.; Mayer, J. M. Hydrolysis in drug and prodrug metabolism. Chemistry, biochemistry, and
enzymology; Verlag Helvetica Chimica Acta: Zürich, 2003.
10. Stella, V. J.; Borchardt, R. T.; Hageman, M. J.; Oliyai, R.; Maag, H.; Tilley, J. W., Eds. Prodrugs:
challenges and rewards. Part 1; Springer-AAPS Press: New York, 2007.
11. Testa, B.; Caldwell, J. Prodrugs revisited: "Ad hoc" approach as a complement to ligand design.
Med. Res. Rev. 1996, 16, 233-241.
12. Carter, D. C.; Ho, J. X. Structure of serum albumin. Adv. Protein Chem. 1994, 45, 153-203.
13. Kragh-Hansen, U. Molecular aspects of ligand binding to serum albumin. Pharmacol. Rev. 1981,
33, 17-53.
14. Kragh-Hansen, U. Structure and ligand binding properties of human serum albumin. Dan. Med.
Bull. 1990, 37, 57-84.
15. Kragh-Hansen, U.; Chuang, V. T. G.; Otagiri, M. Practical aspects of the ligand-binding and
enzymatic properties of human serum albumin. Biol. Pharm. Bull. 2002, 25, 695-704.
16. Peters, T. Jr. All about albumin. Biochemistry, genetics, and medical applications; Academic
Press: San Diego, 1996.
17. Vallner, J. J. Binding of drugs by albumin and plasma protein. J. Pharm. Sci. 1977, 66, 447-465.
18. Jusko, W. J.; Gretch, M. Plasma and tissue protein binding of drugs in pharmacokinetics. Drug
Metab. Rev. 1976, 5, 43-140.
19. Kwong, T. C. Free drug measurements: methodology and clinical significance. Clin. Chim. Acta
1985, 151, 193-216.

Molecules 2007, 12
2409
20. Meyer, M. C.; Guttmann, D. E. The binding of drugs by plasma proteins. J. Pharm. Sci. 1968, 57,
895-918.
21. Kurtzhals, P.; Havelund, S.; Jonassen, I.; Kiehr, B.; Larsen, U. D.; Ribel, U.; Markussen, J.
Albumin binding of insulins acylated with fatty acids: characterization of the ligand-protein
interaction and correlation between binding affinity and timing of the insulin effect in vivo.
Biochem. J. 1995, 312, 725-731.
22. Kurtzhals, P.; Havelund, S.; Jonassen, I.; Markussen, J. Effect of fatty acids and selected drugs on
the albumin binding of a long-acting, acylated insulin analogue. J. Pharm. Sci. 1997, 86, 1365-
1368.
23. Markussen, J.; Havelund, S.; Kurtzhals, P.; Andersen, A. S.; Halstrøm, J.; Hasselager, E.; Larsen,
U. D.; Ribel, U.; Schäffer, L.; Vad, K.; Jonassen, I. Soluble, fatty acid acylated insulins bind to
albumin and show protracted action in pigs. Diabetologia 1996, 39, 281-288.
24. Knudsen, L. B.; Nielsen, P. F.; Huusfeldt, P. O.; Johansen, N. L.; Madsen, K.; Pedersen, F. Z.;
Thøgersen, H.; Wilken, M.; Agersø, H. Potent derivatives of glucagon-like peptide-1 with
pharmacokinetic properties suitable for once daily administration. J. Med. Chem. 2000, 43, 1664-
1669.
25. Oku, N.; Yamashita, S.; Sakuragi, n.; Doi, K.; Okada, S.; Shimidzu, K.; sumi, M.; Nadai, T.;
Kusumoto, S.; Suda, Y. Therapeutic efficacy of 5-fluorouracil prodrugs using endogenous serum
proteins as drug carriers: A new strategy in drug delivery system. Biol. Pharm. Bull. 1995, 18,
181-184.
26. Østergaard, J.; Larsen, C. Bioreversible derivatives of phenol. I. The role of human serum albumin
as related to the stability and binding properties of carbonate esters with fatty acid-like structures
in aqueous solution and biological media. Molecules 2007, 12, 2380-2395.
27. Pond, S. M.; Tozer, T. N. First-pass elimination. Basic concepts and clinical consequenses. Clin.
Pharmacokinet. 1984, 9, 1-25.
28. Ballinger, L. N.; Cross, S. E.; Roberts, M. S. Availability and mean transit times of phenol and its
metabolites in the isolated perfused rat liver: normal and retrograde studies using tracer
concentrations of phenol. J. Pharm. Pharmacol. 1995, 47, 949-956.
29. Scott, D. O.; Lunte, C. E. In vivo microdialysis sampling in the bile, blood, and liver of rats to
study the disposition of phenol. Pharm. Res. 1993, 10, 335-342.
30. Cassidy, M. K.; Houston, J. B. In vivo assessment of extrahepatic conjugative metabolism in first
pass effects using the model compound phenol. J. Pharm. Pharmacol. 1980, 32, 57-59.
31. Cassidy, M. K.; Houston, J. B. In vivo capacity of hepatic and extrahepatic enzymes to conjugate
phenol. Drug Metab. Disp. 1984, 12, 619-624.
32. Hansen, J.; Mørk, N.; Bundgaard, H. Phenyl carbamates of amino acids as prodrug forms for
protecting phenols against first-pass metabolism. Int. J. Pharm. 1992, 81, 253-261.
33. Fredholt, K.; Mørk, N.; Begtrup, M. Hemiesters of aliphatic dicarboxylic acids as cyclization-
activated prodrug forms for protecting phenols against first-pass metabolism. Int. J. Pharm. 1995,
123, 209-216.
34. Thomsen, K. F.; Bundgaard, H. Cyclization-activated phenyl carbamate prodrug forms for
protecting phenols against first-pass metabolism. Int. J. Pharm. 1993, 91, 39-49.

Molecules 2007, 12
2410
35. Thomsen, K. F.; Strøm, F.; Sforzini, B. V.; Begtrup, M.; Mørk, N. Evaluation of phenyl
carbamates of ethyl diamines as cyclization-activated prodrug forms for protecting phenols against
first-pass metabolism. Int. J. Pharm. 1994, 112, 143-152.
36. King, S. W.; Lum, V. R.; Fife, T. H. Interaction of carboxypeptidase A with carbamate and
carbonate esters. Biochemistry 1987, 26, 2294-2230.
37. Harned, H. S.; Hamer, W. J. The ionization constant of water and the dissociation of water in
potassium chloride solutions from electromotive forces of cells without liquid junction. J. Am.
Chem. Soc. 1933, 55, 2194-2206.
38. van der Houwen, O. A. G. J.; de Loos, M. R.; Beinen, J. H.; Bult, A.; Underberg, W. J. M.
Systematic interpretation of pH-degradation profiles. A critical review. Int. J. Pharm. 1997, 155,
137-152.
39. Nøring, I.; Jensen, A.; Faurholt, C. Studies on monoalkyl carbonates. XII. The monoalkyl
carbonates of ethylene glycol and ethylene chlorohydrin. Acta Chem. Scand. 1952, 6, 404-410.
40. Miller, N. F.; Case, L. O. The kinetics of the alkaline hydrolysis of ethyl carbonate and potassium
ethyl carbonate. J. Am. Chem. Soc. 1935, 57, 810-814.
41. Faurholt, C. Studien über monoalkylkarbonate. III. Über die Kinetik bei der Zersetzung der
Monoalkylcarbonate und bei der bildung der Monoalkylkarbonate aus Bikarbonat in wässerigen
alkalishen Lösungen. Z. Physik. Chem. 1927, 126, 211-226.
42. Cooper, G. D.; Williams, B. Hydrolysis of simple aromatic esters and carbonates. J. Org. Chem.
1962, 27, 3717-3719.
43. Cooper, G. D.; Johnson, H. T.; Williams, B. Substituent effects in hydrolysis of diaryl carbonates.
J. Org. Chem. 1965, 30, 3989-3991.
44. Jaffé, H. H. A reexamination of the Hammett equation. Chem. Rev. 1953, 53, 191-261.
45. Johnson, S. L. General base and nucleophilic catalysis of ester hydrolysis and related reactions.
Adv. Phys. Org. Chem. 1967, 5, 237-330.
46. Marlier, J. F.; O'Leary, M. H. Carbon kinetic isotope effects on the hydrolysis of aryl carbonates.
J. Am. Chem. Soc. 1990, 112, 5996-5998.
47. Fife, T. H.; Hutchins, J. E. C. Effect of nucleophile basicity on intramolecular nucleophilic
aminolysis reactions of carbonate diesters. J. Am. Chem. Soc. 1981, 103, 4194-4199.
48. Hansch, C.; Leo, A.; Hoekman, D. Exploring QSAR. Hydrophobic, electronic, and steric
constants; 1 ed.; ACS: Washington, 1995; Vol. 2.
49. Dittert, L. W.; Higuchi, T. Rates of hydrolysis of carbamate and carbonate esters in alkaline
solution. J. Pharm. Sci. 1963, 52, 852-857.
50. Dittert, L. W.; Caldwell, H. C.; Ellison, T.; Irwin, G. M.; Rivard, D. E.; Swintosky, J. V.
Carbonate ester prodrugs of salicylic acid. Synthesis, solubility characteristics, in vitro enzymatic
hydrolysis rates, and blood levels of total salicylate following oral administration to dogs. J.
Pharm. Sci. 1968, 57, 828-831.
51. Rattie, E. S.; Shami, E. G.; Dittert, L. W.; Swintosky, J. V. Acetaminophen prodrugs III.
Hydrolysis of carbonate and carboxylic acid esters in aqueous buffers. J. Pharm. Sci. 1970, 59,
1738-1741.

Molecules 2007, 12
2411
52. Dittert, L. W.; Irwin, G. M.; Chong, C. W.; Swintosky, J. V. Acetaminophen prodrugs II. Effect of
structure and enzyme source on enzymatic and nonenzymatic hydrolysis of carbonate esters. J.
Pharm. Sci. 1968, 57, 780-783.
53. March, J. Advanced organic chemistry. Reactions, mechanisms, and structure; 4 ed.; John Wiley
& Sons: New York, 1992.
54. Nicholls, P. H.; Tillett, J. G. The acid-catalysed hydrolysis of diaryl carbonates. J. Chem. Soc.,
Perkin Trans. 2 1972, 1970-1971.
55. Levin, I.; Pohoryles, L. A.; Sarel, S.; Usieli, V. Organic carbonates. Part VIII. The acid catalysed
hydrolysis of ethylene, trimethylene, and tetramethylene carbonate. J. Chem. Soc. 1963, 3949-
3954.
56. Sarel, S.; Levin, I.; Pohoryles, L. A. Organic carbonates. Part V. The mechanism of hydrolysis of
cyclic carbonates: tracer studies. J. Chem. Soc. 1960, 3079-3082.
57. Faurholt, C.; Gjaldbæk, J. C. Studier over monoalkylkarbonater. VIII. Propylalkoholernes
monoalkylkarbonater. Dansk Tidskr. Farm. 1943, 17, 213-227.
58. Taft, R. W. Polar and steric substituent constants for aliphatic and o-benzoate groups from rates of
esterification and hydrolysis of esters. J. Am. Chem. Soc. 1952, 74, 3120-3128.
59. Cohen, S. G.; Schneider, A. Cleavage of the alkyl-oxygen bond in the hydrolysis of esters. t-butyl
2,4,6-trimethylbenzoate. J. Am. Chem. Soc. 1941, 63, 3382-3388.
60. Bunton, C. A.; Wood, J. L. Tracer studies on ester hydrolysis. Part II. The acid hydrolysis of tert.-
butyl acetate. J. Chem. Soc. 1955, 1522-1525.
61. Salomaa, P. Kinetics of the uncatalyzed hydrolysis of tertiary butyl acetate. Suom. Kemi. 1969,
B42, 134-135.
62. Tillett, J. G.; Wiggins, D. E. Neighbouring hydroxyl group catalysis of carbonate esters.
Tetrahedron Lett. 1971, 14, 911-914.
63. Bruice, T. C.; Pandit, U. K. The effect of geminal substitution ring size and rotamer distribution
on the intramolecular nucleophilic catalysis of the hydrolysis of monophenyl esters of dibasic
acids and the solvolysis of intermediate anhydrides. J. Am. Chem. Soc. 1960, 82, 5858-5865.
64. St Pierre, T.; Jencks, W. P. Intramolecular catalysis in the reactions of nucleophilic reagents with
aspirin. J. Am. Chem. Soc. 1968, 90, 3817-3827.
65. Connors, K. A. Reaction mechanisms in organic analytical chemistry; John Wiley & Sons: New
York, 1973.
66. Fersht, A. Structure and mechanism in protein science: a guide to enzyme catalysis and protein
folding; W. H. Freeman and Company: New York, 1998.
67. Hansen, L. B.; Christrup, L. L.; Bundgaard, H. Ketobemidone prodrugs for buccal delivery. Acta
Pharm. Nord. 1991, 3, 77-82.
68. Honkanen, E. Synthesis of some phenyl carboxymethyl esters of carbonic acid and its sulphur
analogues. Acta Chem. Scand. 1970, 24, 1120-1122.
69. Leonard, J.; Lygo, B.; Procter, G. Advanced practical organic chemistry; 2 ed.; Blackie Academic
& Professional: London, 1995.
70. Connors, K. A. Chemical kinetics. The study of reaction rates in solution; VCH Publishers: New
York, 1990.

Molecules 2007, 12
2412
71. Guggenheim, E. A. XLVI. On the determination of the velocity constant of a unimolecular
reaction. Phil. Mag. 1926, 2, 538-543.
72. Østergaard, J.; Hansen, S. H.; Larsen, C.; Schou, C.; Heegaard, N. H. H. Determination of
octanol-water partition coefficients for carbonate esters and other small organic molecules by
microemulsion electrokinetic chromatography. Electrophoresis 2003, 24, 1038-1046.
73. Kok, W. Th. Thermal management. joule heating in CE. Chromatographia Suppl. 2000, 51, S-24-
S-27.
74. Ishihama, Y.; Oda, Y.; Asakawa, N. Microscale determination of dissociation constants of
multivariant pharmaceuticals by capillary electrophoresis. J. Pharm. Sci. 1994, 83, 1500-1507.
Sample Availability: Samples of the carbonate esters are available from the authors.
© 2007 by MDPI (http://www.mdpi.org). Reproduction is permitted for noncommercial purposes.
