First organophosphorus nonlinear-optical media

Full text of DOI:10.1023/B:DOCH.0000017272.85421.34

Doklady Chemistry, Vol. 394, Part 2, 2004, pp. 34–35. Translated from Doklady Akademii Nauk, Vol. 394, No. 6, 2004, pp. 773–774.
Original Russian Text Copyright © 2004 by Sukhov, Malysheva, Martynovich, Illarionov, Tirskii, Starchenko, Dubrovina, Belogorlova, Gusarova, Trofimov.
CHEMISTRY
First Organophosphorus Nonlinear-Optical Media
B. G. Sukhov*, S. F. Malysheva*, E. F. Martynovich**, A. I. Illarionov***,
V. V. Tirskii**, A. A. Starchenko**, M. A. Dubrovina***, N. A. Belogorlova*,
N. K. Gusarova*, and Academician B. A. Trofimov*
Received September 17, 2003
Molecular crystals occupy a place among nonlinear-
The Z,Z,Z isomers 2a and 2b were synthesized
optical materials owing to their high nonlinear suscep- under mild temperature conditions (20–100°ë) by a
tibilities [1–4]. This feature depends directly on the known method [6] involving oxidation (or sulfonyla-
degree of charge transfer in the molecules that form the tion) of Z,Z,Z-tristyrylphosphine (3), readily available
crystal [1]. Systems with intramolecular charge transfer through the direct reaction between elemental phospho-
are usually heteroatomic and functional organic com- rus and phenylacetylene [7, 8]. The E,E,E isomers 1a
pounds with extended electron conjugation [2]. By and 1b were prepared by heating (100–150°ë) of phos-
varying the nature of the heteroatom or the function phine 3 in DMSO or in an elemental sulfur–toluene sys-
incorporating the heteroatom, it is possible to vary the tem, respectively.
degree of charge transfer and, thus, to perform con-
trolled synthesis of new highly efficient nonlinear-opti-
cal materials [2–4]. To the best of our knowledge, no
data on the use of organophosphorus compounds as
nonlinear-optical media have been published.
Thus, the discovery of nonlinear-optical properties
in compounds 1 and 2 is a real prerequisite for con-
trolled synthesis of their structural analogues with a
specified degree of intramolecular charge transfer, i.e.,
new classes of organophosphorus nonlinear-optical
materials with controlled characteristics.
Using the powder method [5], we found for the first
time that the crystals of the E,E,E and Z,Z,Z isomers of
tristyrylphosphine oxide (1a, 2a) and tristyrylphos-
phine sulfide (1b, 2b) generate the second harmonics of
the radiation from a neodymium laser with an effi-
ciency comparable to that for a classical nonlinear-opti-
cal material, lithium iodate. The intramolecular charge
transfer in compounds 1 and 2 is made possible by the
conjugation of the π-electron-donating benzene rings
with the electron-withdrawing phosphoryl (or thio-
phosphoryl) group through the double bonds of the
styryl fragments.
E,E,E-Tristyrylphosphine oxide (1a). Phosphine 3
was heated (100°ë, 50 h) in DMSO, and the solvent
was evaporated in a vacuum to give phosphine oxide 1a
(80%) as colorless crystals, mp 246–248°C (DMSO).
1
The spectroscopic characteristics (IR, ç NMR, 31P
NMR) of phosphine oxide 1a were identical to those for
an authentic sample [9].
E,E,E-Tristyrylphosphine sulfide (1b). Phosphine 3
was heated (145–150°C, 12 h) with an equimolar
amount of elemental sulfur in xylene, the solvent was
distilled off, and the residue was recrystallized from
hexane to give phosphine sulfide 1b (40%) as light yel-
1
low crystals, mp 226–228°C (DMSO). H NMR
X
(CDCl3, δ, ppm): 6.68 (dd, 3H, H–C-1, 3JHH = 16.8 Hz,
2JPH = 21.5 Hz), 7.35–7.37 (m, 9H, p,m-Ph), 7.51–7.52
(m, 6H, o-Ph), 7.53 (dd, 3H, H–C-2, 3JPH = 22.9 Hz). IR
(KBr, cm–1): 3061, 3022, 2983 (ν, C–H); 1610, 1573,
1494, 1447 (ν, C=C, Ph); 1320, 1290, 1232, 1191, 1174
(δ, C–H); 997, 977, 880 (δ, HC=CH); 845, 834
(ν, P=S); 798 (ν, P–C); 743, 689 (δ, C–H arom); 610
(δ, C–P–C).
2
P
X
1
P
1a, 1b
2a, 2b
X = O (‡), S (b)
For C24H21PS anal. calcd. (%): C, 77.42; H, 5.65; P,
8.33; S, 8.60.
* Favorsky Institute of Chemistry, Siberian Division,
Russian Academy of Sciences, ul. Favorskogo 1,
Irkutsk, 664033 Russia
** Institute of Laser Physics (Irkutsk Branch),
Siberian Division, Russian Academy of Sciences,
Irkutsk, Russia
Found (%): C, 77.80; H, 5.36; P, 8.74; S, 8.50.
Z,Z,Z-Tristyrylphosphine oxide (2a) and sulfide
(2b) were prepared by treating Z,Z,Z-tristyrylphos-
phine with aqueous hydrogen peroxide or elemental
sulfur according to a known procedure [6].
The generation of the second harmonics was studied
by the powder method using the radiation from a
*** Irkutsk State University of Communications,
Irkutsk, Russia
