Developing cellulosic waste products as platform chemicals: protecting group chemistry of α-glucoisosaccharinic acid

Article abstract of DOI:10.1016/j.carres.2017.11.013

Alpha and beta-glucoisosaccharinic acids ((2S,4S)-2,4,5-trihydroxy-2-(hydroxymethyl)pentanoic acid and (2R,4S)-2,4,5-trihydroxy-2-(hydroxymethyl)pentanoic acid) which are produced when cellulosic materials are treated with aqueous alkali are potentially v

Full text of DOI:10.1016/j.carres.2017.11.013

Accepted Manuscript
Developing cellulosic waste products as platform chemicals: Protecting group
chemistry of α-glucoisosaccharinic acid
Michael Almond, Mustapha G. Suleiman, Matthew Hawkins, Daniel Winder, Thomas
Robshaw, Megan Waddoups, Paul N. Humphreys, Andrew P. Laws
PII:
S0008-6215(17)30768-1
10.1016/j.carres.2017.11.013
CAR 7491
DOI:
Reference:
To appear in: Carbohydrate Research
Received Date: 13 October 2017
Revised Date: 20 November 2017
Accepted Date: 20 November 2017
Please cite this article as: M. Almond, M.G. Suleiman, M. Hawkins, D. Winder, T. Robshaw, M.
Waddoups, P.N. Humphreys, A.P. Laws, Developing cellulosic waste products as platform chemicals:
Protecting group chemistry of α-glucoisosaccharinic acid, Carbohydrate Research (2017), doi: 10.1016/
j.carres.2017.11.013.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT
Graphical Abstract
P2O
O
O
OH
HO
P6O
O
O
Cellulose
Alkali
HO
Saccharinic acid
P5O
P2/P5/P6= H or Protecting Group

ACCEPTED MANUSCRIPT
1
2
3
4
Developing Cellulosic Waste Products as Platform Chemicals:
Protecting Group Chemistry of α-Glucoisosaccharinic Acid.
5
6
Michael Almonda, Mustapha G. Suleimana, Matthew Hawkinsa, Daniel Windera, Thomas
Robshawa, Megan Waddoupsa, Paul N. Humphreysb, Andrew P. Lawsa*
7
8
9
aDepartment of Chemical Sciences, School of Applied Sciences, University of
Huddersfield, Queensgate Huddersfield HD1 3DH, United Kingdom.
10
11
bDepartment of Biological Sciences, School of Applied Sciences, University of
Huddersfield, Queensgate Huddersfield HD1 3DH, United Kingdom.
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
*Corresponding author. Tel.: +44(0) 1484 472668; fax: +44(0) 1484 472182
Email address: a.p.laws@hud.ac.uk
28
1

ACCEPTED MANUSCRIPT
29
Abstract
30
31
32
33
34
35
36
37
Alpha and beta-glucoisosaccharinic acids ( (2S,4S)-2,4,5-trihydroxy-2-
(hydroxymethyl)pentanoic acid and (2R,4S)-2,4,5-trihydroxy-2-(hydroxymethyl)pentanoic
acid) which are produced when cellulosic materials are treated with aqueous alkali are
potentially valuable platform chemicals. Their highly functionalised carbon skeleton, with
fixed chirality at C-2 and C-4, makes them ideal starting materials for use in synthesis. In
order to assess the potential of these saccharinic acids as platform chemicals we have
explored the protecting group chemistry of the lactone form of alpha-glucoisosaccharinic
acid (α-GISAL). We report here the use of single and multiple step reaction pathways
38
39
40
41
42
leading to the regioselective protection of the three different hydroxyl groups of α-GISAL.
We report strategies for protecting the three different hydroxyl groups individually or in
pairs. We also report the synthesis of a range of tri-O-protected α-GISAL derivatives
where a number of the products contain orthogonal protecting groups.
43
44
45
Key words:
Saccharinic acids; Isosaccharinic acid; Glucoisosaccharinic acid; protecting groups.
2

ACCEPTED MANUSCRIPT
46
47
1. Introduction
48
49
50
51
52
53
54
55
56
57
58
59
60
Saccharinic acids[1, 2] are a group of branched-chain polyhydroxyl acids which are
generated in large quantities when cellulosic materials are treated with aqueous alkali[3].
The mechanism for saccharinic acid production has been studied in detail and the base
catalysed depolymerisation of cellulose is known to proceed via a ‘peeling’ reaction[4, 5]
[6-8]. Depending on the reaction conditions (type of alkali, length of reaction and
temperature) a large number of different hydroxy acids can be formed but the main
saccharinic acids formed from cellulose, accounting for up to 80% of the total organic
matter, are a pair of C-2 epimeric six carbon glucoisosaccharinic acids (GISA) [9-11].
Whistler and Bemiller have reported that the calcium salt of the 2S-epimer, alpha-
glucoisosaccharinic acid (α-GISA (1); (2S,4S)-2,4,5-trihydroxy-2-(hydroxymethyl)pentanoic
acid) can be economically manufactured by heating lactose with a saturated aqueous
calcium hydroxide solution[12]; on cooling, the 2S-epimer precipitates whilst the 2R-epimer
and other impurities remain in solution. The salts of α-GISA are highly polar and have
61
62
63
limited solubility in most organic solvents. However, in the presence of mild acids α-GISA
(1) undergoes an internal esterification reaction to give the less polar α-
glucoisosaccharino-1,4-lactone (α-GISAL (2)):
64
Scheme 1.
65
66
67
68
69
Despite the ease of preparation of α-GISA (1) and its ready conversion to its less polar
lactone (2) the two have rarely been exploited as starting materials in synthesis. Florent et
al[13] and Monneret et al [14] have incorporated α-GISA (1) into the synthesis of a range
of anthracycline analogues. Monneret et al have incorporated α-GISA (1) into the
synthesis of nucleoside analogues with antiviral or antitumor activity[15]. Hanessian and
3

ACCEPTED MANUSCRIPT
70
71
72
Roy have utilised α-GISA (1) in the synthesis of the antibiotic spectinomycin[16].
Thomassigny et al have incorporated α-GISA (1) into the synthesis of a small number of
heterocycles including variously protected pyrrolidines[17] and piperidines[18].
73
74
75
76
77
78
79
80
81
82
83
It has been estimated that many millions of metric tons of saccharinic acids are produced
each year as by products in the alkaline pulping of wood[19-22]. Currently, this large
reservoir of potentially valuable organic molecules is combusted within pulping mills to
recover their calorific value. Ideally, wood pulping companies would like to be able to
extract extra value from these saccharinic acids and one way this could be achieved is by
employing them as staring materials in synthetic chemistry. For this ambition to be realised
and to determine the true synthetic utility of GISAs it will be necessary to develop
strategies for the regioselective protection of the different hydroxyl groups, either
individually or in groups. In this paper we report our studies of the protecting group
chemistry of α-GISAL (2), including the regioselective protection of different combinations
of the three hydroxyl groups.
84
85
86
87
It should be noted that whilst the gluco-prefix identifies GISAs as being derived from a 1,4-
glucan such as cellulose , in the early scientific literature and also in current literature
describing environmental aspects of GISA’s properties[23-26] these molecules are
frequently referred to as isosaccharinic acids (ISA).
88
89
4

ACCEPTED MANUSCRIPT
90
91
2. Results and Discussion
2.1 Preparation of 2,5,6-tri-O-protected-α-GISALs in a single step procedure.
92
93
In the first set of experiments, attempts were made to protect all three hydroxyls of GISA
as ester derivatives (Fig. 1, 3a-5a). We have previously reported the synthesis of the
tribenzoyl-ester of α-GISAL (2) which was achieved by reaction of α-GISAL (2) with a
large excess of benzoyl chloride with pyridine as solvent and employing
94
95
96
dimethylaminopyridine as an acyl-transfer catalyst[27]. When an acetylation reaction was
performed with an excess of acetic anhydride with sodium acetate as a base a near
quantitative yield of the 2,5,6-tri-O-acetyl-α-GISAL (3a, 99%) was recovered. However,
when an attempt was made to reduce the quantity of the bulkier acylating reagents to
nearer stoichiometric amounts (3.3 equivalents) a mixture of di and triacylated products
was obtained. The trisubstituted derivative 4a could only be produced as a single
compound when a large excess of benzoyl chloride was used (10 equivalents).
97
98
99
100
101
102
103
Figure 1.
104
105
106
107
108
109
110
111
A similar picture emerged with the attempted synthesis of sulfonate esters. Reaction of 2
with six equivalents of methanesulfonyl chloride in the presence of pyridine gave the
trimesylated product 5a in reasonable yield (61%). In contrast, when 2 was reacted with a
large excess of p-toluenesulfonyl chloride a crude product was isolated which, after
column chromatography, gave the 5,6-di-O-tosylated derivative 6b (55%) and only a small
amount (<10%) of the desired 2,5,6-trisubstituted α-GISAL was produced. Further
attempts to form triprotected derivatives of 2, as either benzyl, trityl or silyl ethers, all led to
the isolation of 5,6-di-O-protected derivatives (see section 2.2).
112
113
It is clear that derivatisation of all three hydroxyl groups in a single step procedure was
only possible when using either forcing conditions (large excess of reagent), or when small
5

ACCEPTED MANUSCRIPT
114
115
116
sterically undemanding protecting groups (acetyl or mesyl) were employed. It is of note
that Kumar and Alen have reported the synthesis of mixtures of mono and di-esters in the
of a-glucoisosaccharino-1,4-lactone with tall oil fatty acids[28].
117
2.2. Preparation of 5,6-di-O-protected-α-GISALs in single step procedures.
118
119
120
121
122
123
124
125
It was expected that the greater reactivity of the hydroxymethylene groups compared with
that of the tertiary alcohol in 2 would allow direct access to the 5,6-di-O-protected-α-GISAL
derivatives. Reaction of the lactone with two equivalents of acetyl chloride in pyridine and
also the reaction of the lactone with two equivalents of p-toluenesulphonyl chloride in
pyridine produced the desired 5,6-di-O-protected lactones 3b (63%) & 6b (55%) in
reasonable yields. Reaction of the lactone with the larger trityl chloride generated a
mixture of di-O-protected and mono-O-protected products which were easy to separate by
column chromatography to give a very low yield of the desired 5,6-di-O-trityl-α-GISAL 7b
126
(13%), a similar amount of the 5-mono-O-trityl-α-GISAL 7e (12%) and a very small
127
128
129
130
131
132
133
134
135
136
amount of the 6-mono-O-trityl-α-GISAL 7f ( <2%).
Attempts to prepare the 5,6-di-O-benzylated derivative 8b using sodium hydride as a base
in DMF failed and only ring opened lactone products were obtained. Giordano and
Iadonisi[29] have recently reported the regioselective benzylation of primary alcohols in
carbohydrate based polyols using a combination of benzyl bromide and the base
diisopropylethylamine in the presence of a di-tert-butyltin oxide catalyst. When the reaction
was applied to the lactone 2 a reasonable yield of the desired 5,6-di-O-benzylated product
8b (59%) was recovered.
Reaction of 2 with an excess of TBDMSCl in pyridine gave, after column chromatography,
5,6-di-O-TBDMS-α-GISAL 9b as the major product (69%). In a similar reaction, treatment
137
138
of the lactone with TIPDSCl in pyridine afforded a high yield (82%) of the 5,6-TIPDS-α-
GISAL (14) in which the protecting group bridges between the 5 and 6-positions. The 5,6-
6

ACCEPTED MANUSCRIPT
139
140
141
142
143
144
145
146
147
148
149
150
151
152
arrangement of the protecting group was confirmed by acetylating the remaining hydroxyl
group and identifying strong NOE contacts between the protons of the isopropyl groups
and the methylene protons at 5 and 6 in the acetylated product (15).
Scheme 2.
In order to expand the range of protecting groups, an attempt was made to introduce acid
stable carbonates at the 5 and 6-positions. Gioeli and Chattopadhyaya[30] have reported
the use of the FMOC-carbonate group to protect the hydroxyl groups of ribose, however,
when the lactone 2 was reacted with a large excess of FMOCCl, either in the presence or
absence of an acyl transfer catalyst, a mixture of di-protected and mono-protected
products were obtained. Despite using longer reaction times and up to ten equivalents of
the 9-fluorenylmethoxycarbonyl chloride, the maximum yield of the desired di-protected
product 10b never exceeded 27%. From these studies, it was clear that the reaction had
reached equilibrium in which the diprotected, monoprotected and unreacted FMOCCl were
all present. As was the case with trityl-O-protection, pure samples of the desired 5,6-di-O-
153
154
FMOC-α-GISAL10b, the 5-mono-O-protected 10e and small amounts of the 6-mono-O-
protected-α-GISAL 10f were isolated by column chromatography.
155
2.3. Preparation of 2,6-di-O-protected-α-GISALs in single step procedures.
156
157
158
159
160
161
162
163
The combined protection of the primary alcohol at the 6-position and the tertiary alcohol at
the 2-position using an isopropylidene group has previously been reported by Florent et
al[13]. In a similar reaction, the lactone 2 was condensed with freshly distilled
benzaldehyde in the presence of an acid catalyst to give the 2,6-O-benzylidene protected
lactone 12b (78%) as a pair of diastereoisomers in a 1:3.5 ratio (7R:7S; scheme 2).
Reaction of the 2,6-acetal protected substrates with either FMOCCl or benzoyl chloride in
pyridine provided mixtures of starting materials and products, with only moderate yields of
the desired products being obtained after column chromatography (11c 14% and 12c
7

ACCEPTED MANUSCRIPT
164
165
166
167
20%). The low yields are consistent with steric crowding reducing access to tri-O-protected
products, especially when bulky protecting groups are employed.
Scheme 3,
2.4 Preparation of 2,5,6-tri-O-protected-α-GISALs in two step procedures.
168
169
170
171
172
173
174
175
176
The ease of formation of the 5,6-di-O-protected-α-GISALs (6b-10b) provided an
opportunity to introduce orthogonal protection at the tertiary hydroxyl groups albeit with the
requirement for the use of a small protecting group. Both the 5,6-di-O-dibenzyl-α-GISAL
8b and the 5,6-O-diTBDMS-α-GISALs 9b were converted in variable but not optimised
yields to their 2-O-acetyl-5,6-di-O-protected-α-GISALs (8c 30%, 9c 80%) on reaction with
acetic anhydride using sodium acetate as a base catalyst (Fig 2; reagents a). In a similar
manner, treatment of the 5,6-O-diFMOC-α-GISAL 10b with acetic anhydride in the
presence of zinc dichloride afforded the 2-O-acetyl-5,6-di-O-protected-α-GISAL 10c (Fig.
2; reagents b, 55%).
177
Scheme 4.
178
179
180
181
182
Reaction of the 2,6-O-isopropyliene-α-GISALs 11b with FMOCCl provided the opportunity
to place orthogonal protecting groups onto the primary alcohols, 5-OH versus 6-OH, and
gave the 2,6-O-isopropyliene-5-O-FMOC-α-GISAL 11c but in low yield (14%). In a similar
reaction, treatment of 12b with benzoyl chloride in pyridine gave the 2,6-O-benzilydene-5-
O-benzoyl-α-GISALs 12c also in low yield (20%).
183
184
2.5 Preparation of the mono-O-protected α-GISAL derivatives.
Figure 2.
185
186
In most cases, attempts to directly add a single protecting group to the lactone 2 did not
give single products: the similar reactivity of the two primary hydroxyls meant that in the
8

ACCEPTED MANUSCRIPT
187
188
189
190
191
192
193
194
195
majority of cases mixtures of the 5,6-di-O-protected, 5-mono-O-protected and small
amounts of the 6-mono-O-protected-α-GISALs were recovered. However, in the majority
of the reactions, more of the 5-mono-O-protected product was obtained and when using
the relatively bulky TBSDMSCl as reagent the reaction took place exclusively at the 5-
position. As the starting lactone was easy to prepare and because it proved to be relatively
straight forward to separate the different mono-O-protected lactones, this route provided
an opportunity to prepare a range of mono-O-protected-α-GISAls (Fig. 3) including the
mono-substituted trityl-ethers (7f, 13% & 7e, 2%) the silyl ether (9e, 46%) and the
carbonates (10e, 24% and 10f, 56%).
196
197
198
199
200
201
202
203
A number of additional mono-protected products were synthesised by three step
procedures in which the required regioselective protection was achieved by first generating
a di-O-protected product, followed by the addition of a small orthogonal protecting group at
the remaining free-hydroxyl and then removal of the original protecting group. Treatment of
the 5,6-di-O-FMOC-2-O-acetyl-α-GISAL with triethylamine generated the 2-O-acetyl-α-
GISAL 3d in near quantitative yield. Likewise, treatment of the 5,6-O-isopropylidene-2-O-
FMOC lactone 12c with aqueous acid generated the 5-FMOC-α-GISALs 10e in
quantitative yield.
204
205
2.6 Preparation of a 5,6-di-O-protected-α-GISALs in a two-step one pot procedure
Scheme 5.
206
207
208
209
The greater reactivity of 5-OH towards the silylating agent TBDMSCl meant that it is was
possible to add orthogonal protecting groups onto the primary alcohols in a sequential
reaction series in a one pot reaction (Scheme 3). Reaction of α-GISAL 2 with one
equivalent of TBDMSCl in pyridine followed by the addition of 1.1 equivalent of acetic
9

ACCEPTED MANUSCRIPT
210
211
anhydride led to the isolation, after column chromatography, of the 6-O-acetyl-5-O-
TBDMS-α-GISAL (13).
212
213
214
215
216
217
218
219
220
221
222
223
224
225
3. Conclusion:
Many of the reactions used in this study to generate protected glucoisosaccharinic acids
derivatives are the same as those that are applied to protect hydroxyls in
monosaccharides. The main difference in their outcome is related to the steric demands of
trying to put bulky protecting groups on a tertiary alcohol which is alpha to a carbonyl
carbon. In order to get reaction at the tertiary alcohol either forcing conditions or the use of
small sterically undemanding protecting groups was required. Unsurprisingly, the
attempted synthesis of mono-protected glucoisosaccharinic acids led to the isolation of
mixtures of products. However, the higher reactivity of the C-5 primary hydroxyl group
makes this the preferred initial point of reaction and this was particularly true when
reaction was with a bulky-silylating agent. Despite these difficulties, the use of multiple
steps and the employment of orthogonally protected hydroxyls have provided access to a
wide range of novel α-glucoisosaccharinio-1,4-lactone derivatives which we hope will be
employed in the synthesis of value added products.
226
10

ACCEPTED MANUSCRIPT
227
228
229
4. Experimental
4.1 General Methods
230
231
232
233
234
235
236
237
238
239
All reagents were purchased from commercial sources unless otherwise stated and were
used without further purification. Anhydrous solvents were dried over molecular sieves
(activated under vacuum at 200 oC) and stored under an inert atmosphere before use. The
solvents used for column chromatography were GPR grade. Analytical TLC was
performed on Silica Gel 60-F254 (Merck) and detection was either by charring following
immersion in 5% H2SO4/H2O and/or fluorescence. 1D 1H and 13C-NMR spectra were
recorded on a Bruker Avance 400 MHz spectrometer operating at ambient temperature.
2D-NMR (COSY, HSQC, HMBC or NOESY spectra) were recorded at 500 MHz using
Bruker pulse sequences. NMR samples were dissolved in either D2O, deuterated acetone
or CDCl3 and referenced to either internal tetramethylsilane (δ = 0 ppm), internal CDCl3 (1H
240
241
δ = 7.23 ppm and 13C δ = 77.00 ppm) or internal HOD (1H δ = 4.65 ppm, 303K). Chemical
shifts are given in parts per million.
242
243
244
245
246
247
High resolution mass spectra (HRMS) were recorded either by direct injection on an
Agilent 6210 ToF spectrometer or by HPLC-MS (Agilent 1200 series HPLC coupled to an
Agilent 6210 ToF Spectrometer). The HPLC employed a Phenomenex Luna 5µ C18 2.4 x
250 mm column and samples were eluted using an acetonitrile and water mobile phase
operating with gradient elution: starting at 30% acetonitrile climbing to 95% acetonitrile
over 15 mins. The mobile phase flow rate was 0.2 ml.min-1.
248
249
Stocks of the calcium salt of α-glucoisosaccharinic acid 1 and α-glucoisosaccharino-1,4-
lactone 2 were prepared using the procedures described by Whistler and Bemiller[12].
250
4.2 Synthesis of tri-O-protected lactone derivatives: 3a, 4a and 5a.
11

ACCEPTED MANUSCRIPT
251
4.2.1 2,5,6-Tri-O-acetyl-α-D-glucoisosaccharino-1,4-lactone (3a).
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
α-D-Glucoisosaccharino-1,4-lactone (1.0 g; 6.17 mmol) was added whilst stirring to an ice
cooled solution of acetic anhydride (10 mL), once the lactone had dissolved sodium
acetate (0.5 g) was added and the reaction was heated to 100 oC for 4 h. The reaction was
halted by addition of the contents of the round bottom flask to ice cold water (100 mL) and
the solution was stirred at room temperature for a further 1 h. The organic products were
then extracted into chloroform (3 x 60 mL) and the combined organic extracts were dried
over anhydrous magnesium sulphate and concentrated at reduced pressure to give a
golden crystalline syrup (1.77 g; 6.14 mmol; Yield: 99%).IR (ATR) υ 2959 (C-H), 1781 &
1
1737 (C=O), 1437, 1370 (C-H), 1202, 1045 (C-O). H NMR (400 MHz, CDCl3): 5.01-4.95
(m, 1H, H-4), 4.30 (s, 2H, H-6s), 4.27 (dd, 1H, J5’,4 = 3.4 Hz, J5’,5 = 12.3 Hz, H-5’), 4.13 (dd,
1H, J5,4 = 6.7 Hz, J5,5’ = 12.3 Hz, H-5), 2.50 (dd, 1H, J3,4 = 9. 0 Hz, J3,5 = 14.7 Hz, H-3),
2.25 (dd, 1H, J3’,4 = 6.3 Hz, J3’,5 = 14.7 Hz, H3’), 2.11, 2.10, 2.08 (3s, 9H, 3 x CH3CO); 13C
NMR (100 MHz, CDCl3): δ 172.0 (C1), 170.6, 170.0, 169.9 (3 x CH3-CO), 77.9 (C2), 74.7
(C4), 65.3 (C6), 64.8 (C5), 32.1 (C3), 20.7, 20.6, 20.5 (3 x Me-CO). HRMS (m/z) Calcd for
C12H16O8 [M+NH4]+: 306.1183, Found:306.1187.
267
4.2.2 2,5,6-Tri-O-benzoyl-α-D-glucoisosaccharino-1,4-lactone (4a).
268
269
270
271
272
273
274
The procedure used to prepare 4a was identical to that used to prepare 2,5,6-tri-O-
benzoyl-β-D-glucoisosacharino-1,4-lactone reported by Shaw et al[27] and the product
was recovered from a crude mixture by column chromatography (pale yellow syrup, 4.93g
starting from 20g of GISAL(2)) (TLC Hex/EtOAc 1:1; RF 0.34). IR (ATR) υ 1771 & 1722
(C=O), 1451 (Ar C-C), 1262, 1233, 1092 & 1062 (C-O), 701 & 684 (Ar C-H). 1H NMR (400
MHz, CDCl3): δ 8.08-7.48 (m, 15H, 3 x Ph), 5.40 (m, 1H, H-4), 4.93 (d, 1H, J6,6’ = 11.2 Hz,
H-6), 4.70 (d, 1H, J6,6’ = 11.2 Hz, H-6’), 4.65 (dd, 1H, J5,4 = 3.4 Hz, J5,5’ = 12.3 Hz, H-5),
12

ACCEPTED MANUSCRIPT
275
276
277
278
279
4.53 (dd, 1H, J5’,4 = 6.5 Hz, J5’,5 = 12.3 Hz, H-5’), 2.82 (dd, 1H, J3,4 = 8.8 Hz, J3,3' = 15.2
Hz, H-3), 2.62 (dd, 1H, J3’,4 = 7.2 Hz, J3,3’ = 15.2 Hz, H-3’). 13C NMR (100 MHz, CDCl3): δ
171.96 (C1), 166.20, 165.74, 165.47 (3 x PhCO) 130.00, 129.96, 128.90, 134.24, 134.07,
130.12, 129.96, 129.20, 128.90, 128.71 (ArC), 78.46 (C2), 75.45 (C4), 66.09 (C6), 65.39
(C5), 32.65 (C3). HRMS (m/z) Calcd for C27H22O8 (M+Na)+: 497.1207, Found: 497.1236.
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
4.2.3 2,5,6-Tri-O-methylsulphonyl-α-D-glucoisosaccharino-1,4-lactone (5a).
The method used to prepare 5a was adapted from that reported by Kabalka et al[31]. A
solution of α-D-glucoisosaccharino-1,4-lactone (1.0 g; 6.17 mmol) in anhydrous pyridine
(10 mL) was added to a round bottomed flask and cooled to 0 oC whilst stirring.
Methanesulphonyl chloride (3 mL; 38.8 mmol) was added cautiously over a period of 10
min. The reaction mixture was kept at 0 oC for a further 5 min before continuing to stir at
room temperature for 16 h. The reaction was halted by addition of ice cold water (25 mL)
and dichloromethane (50 mL). The organic and aqueous layers were separated and any
remaining organic product in the aqueous layer was extracted with dichloromethane (2 ×
25 mL). The organic extracts were combined, washed with 5 % sodium bicarbonate (2 ×
25 mL) and saturated brine (2 × 25 mL) before being dried over anhydrous magnesium
sulphate. The solvent was removed at room temperature on a rotary evaporator to give a
cream-orange coloured solid as the crude product (2.44 g). The product was purified by
column chromatography (100% EtOAc). Fractions containing the desired product 5a were
combined and reduced by rotary evaporation to give 5a as a white solid (1.50 g; yield: 61
%) (Rf: 0.48, EtOAc). IR (ATR) υ 773.6 (CO), 1347.5, 1172.0 (SO2). 1H NMR (400 MHz,
d-DMSO): δ 5.02 (m, 1H, H-4), 4.52 (dd, 1H, J5,5’ = 11.7 Hz, J5,4 = 2.6 Hz, H-5), 4.37 (dd,
1H, J5’,4 = 6.3 Hz, J5’,5 = 11.7 Hz, H-5’), 4.01 (2 x d, 2H, J6,6’ = 7.0 Hz, H-6,6’), 3.24, 3.29,
3.39 (3s, 9H, 3 x Me-SO3), 2.89-2.47 (m, 2H, H-3,3’). 13C NMR (100 MHz, d-DMSO):
296
297
298
13

ACCEPTED MANUSCRIPT
299
300
301
302
δ 169.9 (C1), 83.7 (C2), 32.1 (C3), 76.1 (C4), 69.8 (C5), 70.0 (C6), 41.0, 37.4, 37.3 (3 x
Me-SO3). HRMS (m/z) Calcd for C9H16O11S3 (M+NH4)+: 414.0193, Found: 414.0188.
4.3 Synthesis of 5,6-di-O-protected lactone derivatives (3b, 6b-10b)
303
304
305
306
307
308
309
310
311
312
4.3.1. 5,6-Di-O-acetyl-α-D-glucoisosaccharino-1,4-lactone (3b)
α-D-Glucoisosaccharino-1,4-lactone (2, 500 mg; 3.09 mmol) was dissolved in pyridine (5
mL) while stirring at room temperature for 10 min. Acetyl chloride (470 µL; 6.48 mmol, 2.1
eq) was added cautiously at room temperature. The reaction was allowed to proceed
uninterrupted for 3 h at room temperature. The reaction was halted by adding
dichloromethane (30 mL) followed by ultra-pure water (30 mL), the organic layer was
separated and the aqueous layer was further extracted with dichloromethane (2 x 30 mL).
The combined organic layer was washed with 1% copper sulphate solution (2 x 50 mL)
and dried over anhydrous magnesium sulphate, then concentrated to give 3b (1.20 g; 5.61
mmol; Yield: 55%) IR (ATR) υ 3079 (O-H), 1781 &1743 (C=O), 1482, 1373 (C-H), 1233,
1196 (C-O).1H NMR (400 MHz, CDCl3) δ 4.82-4.76 (m, 1H, H-4), 4.22 (dd, 1H, J5,4 = 2.88
Hz, J5’,5 = 12.4 Hz, H-5), 4.20 (2d, 2H, J6,6’ = 1.16 Hz, H-6 & 6’), 4.04 (dd, 1H, J5’,4 = 6.28
Hz, J5’,5 = 12.4 Hz, H-5’), 2.23 (dd, 1H, J3,4 = 6.20 Hz, J3,3’ = 13.54 Hz, H-3), 2.07 (dd, 1H,
J3’,4 = 9.32 Hz, J3’,3 = 13.52 Hz, H-3’) 1.94 & 1.89 (2s, 6H, 2 x CH3CO); 13C NMR (100
MHz, CDCl3): 175.4 (C1), 170.4 & 170.1 (2 x CH3CO), 74.9 (C4), 74.0 (C2), 65.0 (C6),
64.6 (C5), 35.1 (C3), 20.6 & 20.5 (2 x CH3CO). HRMS (m/z): Calcd for C10H14O7 (M+NH4)+:
269.0748, Found: 269.0740.
313
314
315
316
317
318
319
320
14

ACCEPTED MANUSCRIPT
321
322
323
324
325
326
327
328
329
4.3.2. 5,6-Di-O-p-toluenesulphonyl-α-D-glucoisosaccharino-1,4-lactone (6b)
p-Toluenesulphonyl chloride (2.58 g; 13.6 mmol; 2.1 eq.) was reacted with α-D-
glucoisosaccharino-1,4-lactone (1.06 g; 6.51 mmol) in anhydrous pyridine (5 mL) using the
same procedure described in section 4.3.1 except that after the addition was complete, the
solution was stirred at room temperature for a further 60 h. The crude product 5,6-di-O-
tosyl-α-glucoisosaccharino-1,4-lactone was purified by column chromatography eluting
with a solvent system with a starting composition of hexane and EtOAc (3:1) rising to 100
% EtOAc. The purified compound 6b (RF= 0.35; hexane/ether, 1:1) was isolated as a pale
yellow syrup (1.69 g; yield: 55 %). IR (ATR) υ 3460.1 (OH), 1782.1 (CO) 1597.1, 1354.3,
330
331
332
333
334
335
1171.3, 810.6. 1H NMR (400 MHz, CDCl3): δ 7.80-7.78 (m, 4H, 2 x Ar-H), 7.39-7.36 (m,
4H, 2 x Ar-H), 4.83 (m, 1H, H-4), 4.24-4.11 (m, 2H, H-5s), 4.16 (d, 1H, J6,6’ = 10.6Hz, H-
6), 4.07 (d, 1H, J6’,6 = 10.6 Hz, H6’), 2.48-2.44 (m, 6H, CH3-Ph), 2.37 (m, 1H, H-3), 2.22
(m, 1H, H-3’). 13C NMR (100 MHz, CDCl3): 173.3 (C1), 145.6, 145.7, 130.2, 130.2, 131.8,
132.0, 128.1, 128.1, (8 x ArC), 74.7 (C4), 74.3 (C2), 70.2 (C6), 68.7 (C5), 34.2 (C3), 21.7
(2 x CH3Ar); HRMS (m/z): Calcd for C20H22O9S2 (M+NH4)+: 488.1043, Found: 488.1049.
336
337
338
4.3.3. 5,6-Di-O-triphenylmethyl-α-D-glucoisosaccharino-1,4-lactone (7b) , 6-O-
triphenylmethyl-α-D-glucoisosaccharino-1,4-lactone (7e) and 5-O-triphenylmethyl-α-
D-glucoisosaccharino-1,4-lactone (7f)
339
340
341
342
343
344
345
The following synthetic procedure was adapted from the work by Choudhary and
Hernandez[32]. Triphenylmethyl chloride (25.07 g; 89.9 mmol) and α- D-
glucoisosaccharino-1,4-lactone 2 (6.82 g; 41.9 mmol) were dissolved in pyridine (300 mL)
and a catalytic amount of DMAP (1 g; 8.19 mmol) was added. The resulting solution was
stirred at 25 oC for 12 h under an atmosphere of nitrogen. After the reaction was complete,
the solution was added to an equal volume of water and then extracted into chloroform (2
× 200 mL). The two layers were separated and the organic layers were washed with
15

ACCEPTED MANUSCRIPT
346
347
348
349
350
saturated brine (100 ml) a saturated solution of sodium bicarbonate (100 ml) and dried
over anhydrous sodium sulphate. Evaporation of solvent produced a beige coloured solid
(13.9 g). Subsequent TLC analysis showed the presence of three compounds of interest.
Following separation by column chromatography eluting with Hex/EtOAc (2:1), the
desired compounds were identified as 2,5-di-O-trityl-α-GISAL 7b (Rf 0.79; Hex/EtOAc (
351
352
353
(2:1)); 3.34 g; yield: 12 %, followed by the 6-mono-O-trityl-α-GISAL 7e (Rf 0.29;
Hex/EtOAc,1:2 v/v)); 0.20 g; yield: <2 % and 5-mono-O-trityl-α-GISAL 7f was recovered
from a chloroform wash (Rf 0.16; Hex/EtOAc, (1:2)); 2.25 g; yield: 13 %.
354
355
356
357
358
359
360
7b IR (ATR) υ 1779 (CO) 762.2, 745. 1H NMR (400 MHz, CDCl3) δ 7.48-7.27 (m, 30H, 6 x
PhH), 4.82 (m, 1H, H-4), 3.41 (d, 1H, J6,6’ = 9.1Hz, H-6), 3.30 (d, 1H, J6’,6 = 9.1 Hz, H-6’),
3.36 (dd, 1H, J5,4 = 6.0 Hz, J5,5’ = 10. 5 Hz, H-5), 3.28 (dd, 1H, J5’,4 = 3.8 Hz, J5’,5 = 10.5
Hz, H-5’), 2.20 (m, 2H, H-3); 13C NMR (100 MHz, CDCl3): 176.4 (C1), 143.3, 143.6, 128.7,
128.7, 128.0, 128.0, 127.3, 127.2, 86.9 & 87.2 (TrC*), 77.4 (C4), 75.5 (C2), 65.4 (C5),
65.3 (C6), 35.0 (C3).HRMS (m/z) Calcd for C44H38O5 (M+Na)+: 669.2611, Found:
669.2592.
361
362
363
364
365
366
367
7e IR (ATR) υ 3353.1 (OH) 1774.0 (CO) 763.4, 745.8, 697.7. 1H NMR (400 MHz, CDCl3) δ
7.46-7.27 (m, 15H, 3 x PhH), 4.77 (m, 1H, H-4), 3.91 (dd, 1H, J5,4 = 2.8 Hz, J5,5’ = 12.7 Hz,
H-5), 3.65 (dd, 1H, J5’,4 = 5.1 Hz, J5’,5 = 12.7 Hz, H-5’), 3.42 (d, 1H, J6,6’ = 9.2 Hz, H-6),
3.32 (d, 1H, J6’,6 = 9.2 Hz, H-6’), 2.33 (dd, 1H, J3,4 = 7.1 Hz, J3,3’ = 13.8 Hz, H-3), 2.21 (dd,
1H, J3’,4 = 8.5 Hz, J3’,3 = 13.8 Hz, H-3’); 13C NMR (100 MHz, CDCl3): 176.2 (C1), 143.2 ,
128.7, 128.0, 127.3, 87.3 (TrC), 75.9 (C2), 78.2 (C4), 65.3 (C6), 63.6 (C5), 33.6 (C3).
HRMS (m/z) Calcd for C25H24O5 [M+Na]+: 427.1516, Found: 427.1513.
368
369
7f IR (ATR) υ 3365.8 (OH) 1772.8. (CO) 763.6, 746.0, 697.2. 1H NMR (400 MHz, CDCl3):
δ 7.46-7.27 (m, 15H, 3 x PhH,), 4.89 (m, 1H, H-4), 3.84 (d, 1H, J6,6’ = 11.7 Hz, H-6), 3.71
16

ACCEPTED MANUSCRIPT
370
371
372
373
374
(d, 1H, J6’,6= 11.7 Hz, H-6’), 3.43 (dd, 1H, J5,4 = 3.3 Hz, J5,5’ = 10.5 Hz, H-5), 3.22 (dd, 1H,
J5’,4 = 5.0 Hz, J5’,5 = 10.5 Hz, H-5’), 2.22 (dd, 1H, J3,4 = 6.7 Hz, J3,3’ = 13.7 Hz, H-3), 2.12
(dd, 1H, J3’,4 = 8.6 Hz, J3,3’ = 13.7Hz, H-3’); 13C NMR (100 MHz, CDCl3): 177.7 (C1) 143.4,
128.6, 128.0, 127.3, 86.9 (TrC), 77.7 (C4), 73.6 (C2), 65.5 (C6), 64.2 (C5), 34.0(C3).
HRMS (m/z) Calcd for C25H24O5 (M+Na)+: 427.1516, Found: 427.1506.
375
4.3.4. 5,6-Di-O-dibenzyl-α-D-glucoisosaccharino-1,4-lactone (8b)
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
The dibenzyl derivative 8b was synthesised using a method adapted from that described
by Giordano and Iadonisi [29]. Dried α-glucoisosaccharino-1,4-lactone 2 (1.0 g, 6.17
mmol) was dissolved in N,N-diisopropylethylamine (DIPEA) (2.3mL, 4 eq), and a catalytic
amount of dibutyltin oxide (154 mg, 0.1 eq) and tetrabutylammonium bromide (597 mg, 0.3
eq) were added while stirring. Benzyl bromide (BnBr) (6 mL, 8 eq), was added slowly and
the reaction was allowed to proceed for 4 h at 90 oC. A second portion of BnBr and DIPEA
(2 eqs each) were added and the reaction continued for further 2 h at 90 oC. The reaction
was halted by pouring the reaction solution into a mixture of DCM (50 mL) and water (50
mL). The organic layer was separated, and the aqueous phase was extracted with DCM (2
x 50 mL). The combined organic extracts was dried over anhydrous sodium sulphate and
concentrated to dryness to give crude 8b as a golden syrup which was purified by column
chromatography (EtOAc:Hexane 1/1 v/v); to give the product as a transparent oil 1.24 g;
1
yield: 59% . H NMR (400 MHz, CDCl3) 7.34-7.29 (m, 10H, ArH), 4.83-4.77 (m, 1H, H-4),
4.54 (AB, 4H, J7,7’ = 6.08 Hz, H-7, H-7’), 3.67 (dd, 1H, J5,4 = 3.48 Hz, J5,5’ = 10.97 Hz, H-5),
3.62 (m, 2H, H-6, H-6’), 3.57 (dd, 1H, J5’,4 = 5.20 Hz, J5’,5 = 10.98 Hz, H-5’), 2.33 (2 x dd,
13
2H, J3,4 = 2.12 Hz, J3,3’ = 7.50 Hz, H-3, H-3’); C NMR (100 MHz, CDCl3) 176.79 (C1),
137.59, 137.39 (ArCq), 128.50, 127.89, 127.84, 127.79 (ArC), 76.78 (C4), 75.34(C2),
73.73, 73.56 (C7), 72.05 (C6), 70.88 (C5), 34.61 (C3). HRMS (m/z) Calcd for C20H22O5
[M+Na+]: 365.1359, Found: 365.1358.
17

ACCEPTED MANUSCRIPT
395
4.3.5. 5,6-Di-O-tert-butyldimethylsilyl-α-D-glucoisosaccharino-1,4-lactone (5a)
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
The di-tert-butyldisilyl derivative 9b was synthesised using a method adapted from that
described by Iadonisi et al[33] employing only a minimal amount of solvent. Dried α-
glucoisosaccharino-1,4-lactone 2 (1.0 g, 6.17 mmol) was suspended in anhydrous pyridine
(5 mL) whilst stirring for 20 min at room temperature. It was then added cautiously to a
mixture of tert-butyldimethylsilyl chloride (TBDMSCl) (2.1 g, 13.93 mmol, 2.2 eq) while
stirring at room temperature. The reaction was allowed to proceed for 4 h after which time
DCM (50 mL) and water (50 mL) were added. The organic layer was separated and
aqueous layer was further extracted with DCM (2 x 50 mL). The combined organic layer
was washed with a 1% CuSO4 solution (2 x 50 mL), dried over anhydrous sodium sulphate
and concentrated to give a crude sample of 9b as a white solid. The product was purified
by chromatography (elution with EtOAc/Hexane; 3:1 v/v) and the early fractions contained
pure 9b (1.66 g; 4.26 mmol; 69 %) (Rf = 0.722; Hexane/EtOAc 3:1 v/v) were combined
and the solvent evaporated. IR (ATR) υ 3259 (O-H), 2952, 2928, 2886, 2857 (C-H), 1770
(C=O), 1471, 1462, 1360 (C-H), 1255, 1200, 1168 (C-O), 1097, 1044 (Si-OR) 833, 814,
775. 1H NMR (400 MHz, CDCl3) 4.68-4.60 (m, 1H, H-4), 3.78 (dd, 1H, J5,4 = 3.79 Hz, J5,5’
=
11.55 Hz, H-5), 3.76 (d, 1H, J6,6’ = 9.85 Hz, H-6), 3.69 (dd, 1H, J5’,4 = 4.74 Hz, J5’,5 = 11.55
Hz, H-5’), 3.65 (d, 1H, J6’,6 = 9.85 Hz, H-6’), 2.32 (dd, 1H, J3,4 = 8.30 Hz, J3,3’ = 14.02 Hz,
H-3), 2.17 (dd, 1H, J3’,4 = 7.40 Hz, J3’,3 = 14.02 Hz, H-3’), 0.86 (2s, 18H , 2 x TBDMS), 0.05
(m, 12H, 2 x TBDMS); 13C NMR (100 MHz, CDCl3): 176.92 (C1), 77.77 (C4), 76.35(C2),
65.42 (C6), 64.30 (C5), 33.72 (C3), 25.82 & 25.78 (TBDMS), 18.31& 18.24 (TBDMS).
HRMS (m/z) Calcd for C18H38Si2O5 [M+Na]+ : 413.2150, Found: 413.2152.
417
418
4.3.6 (1’,1’,3’,3’-Tetraisopropyldisiloxane-1,3-diyl)-5,6-α-D-glucoisosaccharino-1,4-
lactone (14)
18

ACCEPTED MANUSCRIPT
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
Dried α-
D
-glucoisosaccharino-1,4-lactone 2 (1.0 g, 6.17 mmol) was dissolved in pyridine
(6 mL) at room temperature and the solution was added cautiously to 1,3-dichloro-1,1,3,3-
tetraisopropyl-1,3-disiloxane (TIPDS-Cl2) (2.17 mL; 6.78 mmol; 1.1 eq) whilst stirring at
room temperature. The reaction was allowed to proceed for 4 h. After 4 h it was halted with
the addition of DCM (60 mL) and water (60 mL). The organic layer was separated and the
aqueous layer was further extracted with DCM (2 x 50 mL). The combined organic layer
was washed with an aqueous CuSO4 solution (1%, 2 x 50 mL) dried over anhydrous
sodium sulphate and concentrated to give crude 14 (4.14 g) as a brown crystalline syrup
which was purified using column chromatography to give the desired product as a pale
yellow syrup (2.05 g; 5.07 mmol; 82% yield) (RF: 0.68, Hexane/EtOAc 4/1 v/v). IR (ATR)
1
υ 2945, 2867, 1771 (C=O), 1464, 1387, 1084, 1042 (R3Si-O-SiR3), 1012. H NMR (400
MHz, CDCl3) 4.70-4.62 (m, 1H, H-4), 4.07 (d, 1H, J6,6’ = 10.6 Hz, H-6) 3.94-3.85 (m, 2H, H-
5, H-5’), 3.83 (d, 1H, J6’,6 = 10.6 Hz, H-6’), 2.82 (dd, 1H, J3,3’ = 13.9 Hz, J3,4 = 2.4 Hz, H-3),
2.30 (dd, 1H, J3’,3 = 13.9 Hz, J3’,4 =10.1 Hz, H-3’), 1.1-0.9 (m, 28H, TIPDS).
13C (100 MHz, CDCl3) 178.2 (C1), 76.7(C2), 76.3 (C4), 66.9 (C6), 63.6 (C5), 31.8 (C3),
17.19, 17.11, 17.09 & 17.07 (TIP(CH)DS), 13.5, 13.1, 12.6 & 12.4 (TIP(CH3)DS)
435
HRMS (m/z) calculated mass for C18H36O6Si2 [M+NH4]+ 422.2389 found 422.2407
436
437
438
439
440
441
442
To confirm the location of the protecting group, 14 (1.5g, 3.71mmol) was acetylated using
the procedure described in section 4.5.1 to give, after chromatography, the product 15 as
a white semi-crystalline syrup (680 mg, 1.53 mmol; 41% yield); (Rf: 0.721, Hexane/EtOAc
3:1, v/v). IR (ATR) υ 2944.6, 2867.5, 1779.5 & 1742.1 (C=O), 1463.9, 1369.8, 1084,
1
1252.1, 1215.1, 1082.5, 1043.2 (R3Si-O-SiR3), 883.1. H NMR (400 MHz, CDCl3) 4.82-
4.78 (m, 1H, H-4), 4.09 (dd, 1H, J5,5’ = 12.02 Hz, J5,4 = 3.56 Hz, H-5), 4.05 (d, 1H, J6,6’
=
11.6 Hz, H-6), 4.00 (d, 1H, J6,6’ = 11.6 Hz, H-6’), 3.85 (dd, 1H, J5’,5 = 12.0 Hz, J5’,4 = 2,16
19

ACCEPTED MANUSCRIPT
443
444
Hz, H-5’), 2.75 (dd, 1H, J3,3’ = 13.61 Hz, J3,4 = 3.52 Hz, H-3), 2.41 (dd, 1H, J3’,3 = 13.61 Hz,
J3’,4 = 9.9 Hz, H-3’) 2.12 (s, 3H, OCH3) 1.1-1.0 (m, 28H, TIPDS).
445
446
447
448
13C (100 MHz, CDCl3) 173.6 (C1), 170.4 (COCH3), 81.7 (C2), 77.0(C4), 64.7 (C5), 64.5
(C6), 30.0 (C3), 20.8 (COCH3), 17.19, 17.15, 17.12 & 17.08 (TIPDS), 13.6, 13.5, 12.6 &
12.3 (TIPDS)
HRMS (m/z) calculated mass for C20H38O7Si2 [M+NH4]+ 464.2494 found 464.2503.
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
4.3.7. 5,6-Di-O-fluorenylmethoxycarbonyl-α-D-glucoisosaccharino-1,4-lactone
(10b)
α-D-Glucoisosaccharino-1,4-lactone 2 (2.01 g, 12.4 mmol) and dimethylaminopyridine
(DMAP, 0.50 g) were dissolved in anhydrous pyridine (40 mL) and stirred under an
atmosphere of nitrogen for 20 min. The mixture was slowly added to a second reaction
vessel, cooled to 0°C, containing fluorenylmethoxycarbonyl chloride (7.05 g, 273 mmol,
2.2 eq). After the addition was complete, the reaction was allowed to reach room
temperature and was stirred, under an atmosphere of nitrogen, for a further 3 h. During
this time a large quantity of colourless pyridinium hydrochloride precipitated from solution.
The reaction was quenched by adding ice-cold water (100 mL), followed by ice-cold diethyl
ether (100 mL). The organic layer was separated and the aqueous phase was extracted
with diethyl ether (3 x 100 mL). The combined organic fractions were washed with a large
quantity of brine (3 x 100 mL) to remove pyridine. The resulting solution was dried over
anhydrous sodium sulphate, before being concentrated under reduced pressure. The
crude product was a bright yellow crystalline syrup (3 g) The product was separated via
chromatography (eluting with a mobile phase compose of Hexane/EtOAc 1:1 v/v). The
target compound 10b (RF = 0.47 Hexane/EtOAc; 1:1v/v) was recovered as a pale yellow
solid (yield: 1.47 g, 2.45 mmol, 19.8 %). IR (ATR) υ 2945, 2867, 1771 (C=O), 1464, 1387,
467
1084, 1042 (R3Si-O-SiR3), 1012.1H NMR (400 MHz, CDCl3), δ 7.90-7.84 (m, 4H, ArH),
20

ACCEPTED MANUSCRIPT
468
469
470
471
472
473
7.65-7.59 (m, 4H, ArH), 7.43-7.37 (m, 4H, ArH), 7.34-7.28 (m, 4H, ArH), 4.92 (m, 1H, H-
4), 4.03-4.52 (m, 10H, 2 x H-5s, 2 x H-6s, 4 x H-8s & 2 x H-9s), 2.44 (dd, 1H, J3’,4 = 6.95
Hz, J3,3’ = 14.2 Hz, H-3’), 2.24 (dd, 1H, J3,4 = 5.67 Hz, J3,3’ = 14.2 Hz, H-3); 3C NMR (100
MHz,CDCl3): 175 (C1), 155 (C7), 143,141,128,127,125,120 (ArC), 75.0 (C2), 74.5 (C4),
70.4 (C8), 68.9 (C6), 67.8 (C5), 46.8 (C9), 34.7 (C3). Melting point: 76-77 OC. HRMS
(m/z): Calcd for C36H30O9 [M+NH4]+ 624.2228 ,Found: 624.2228.
474
475
4.4
Synthesis of 2,6-di-O-protected lactone derivatives (11b and 12b) and their
conversion to 2,5,6-tri-O-protected lactone derivatives (11c and 12c).
476
477
478
479
480
481
482
483
484
485
486
487
488
4.4.1 5-O-Fluorenylmethoxycarbonyl-2,6-O-isopropyliene-α-D-glucoisosaccharino-
1,4-lactone (11c)
2,6-O-Isopropylidene-α-D-glucoisosaccharino-1,4-lactone 11b, prepared using the
procedures described by Florent et al[13] (1.38 g, 6.83 mmol), was dissolved in anhydrous
pyridine (20 ml). The solution was cautiously added to a flask, maintained at 0o C,
containing crystalline FMOCCl (2.66 g, 0.01 mmol). The reaction was allowed to proceed
for 4 h at room temperature after which time it was carefully added to a beaker containing
ice cold water (60 ml) and diethyl ether (60 ml). The organic layer was separated and the
aqueous phase was extracted with diethyl ether (3 x 60 ml). The combined organic
extracts were washed with a saturated solution of brine (50 mL), water (50 mL) and then
dried over anhydrous sodium sulphate before removing the solvent at reduced pressure to
give the desired product 11c as a yellow solid (570 mg, 1.34 mmol; Yield: 19.68%); (Pet.
ether/EtOAc 3:1 v/v). IR (ATR) υ 2945, 2867, 1771 (C=O), 1464, 1387, 1084, 1042
1
489
490
491
492
(R3Si-O-SiR3), 1012. H NMR (400 MHz, CDCl3) δ: 7.78-7.68 (m, 2H, ArH), 7.59-7.50 (m,
2H, ArH), 7.45-7.40 (m, 2H, ArH), 7.36-7.31 (m, 2H, ArH), 4.88-4.82 (m, 1H, H-4), 4.50-
4.37 (m, 4H, 2 x H-5 & 2 x H-6), 4.28-4.08 (m, 3H, H-8 & H-9), 2.20 (dd, 1H, J3,3’ = 14.38
Hz, J3,4 = 7.05 Hz, H-3), 2.55 (dd, 1H, J3,3’ = 14.07 Hz, J3’,4 = 7.47 Hz, H-3’); 1.49 (bs, 6H,
21

ACCEPTED MANUSCRIPT
493
494
495
496
2 x CH3). 13C NMR (100 MHz, CDCl3): 174.8 (C1), 154.6 (FMOCCO): 142.8, 141.3, 127.9,
127.1, 125.0, 119.9 (ArC), 112.7 (C7), 80.8 (C2), 74.4 (C4), 72.0 (C6), 70.1 (C5), 67.7 (
FMOCCH) 46.4 (FMOCCH2) 36.5 (C3), 26.7 (C8), 25.3 (C9). HRMS (m/z) Calcd for
C24H24O7 [M+Na+]: 447.1414, Found: 447.1415.
497
498
4.4.2 5-O-Benzoyl-2,6-O-benzylidene-α-D-glucoisosaccharino-1,4-lactone (12c)
Synthesis of (7S)- and (7R)-2,6-O-benzylidene-α-D-glucoisosaccharino-1,4-lactone 12b -
499
500
501
502
503
504
505
506
507
508
509
510
Freshly distilled benzaldehyde (50 mL; 492 mmol) was added to a round bottomed flask
(100 mL) containing α-glucoisosaccharino-1,4-lactone 2 (1.02 g; 6.27 mmol), p-TSA (20
mg) and ~ 30 4Å molecular sieves. The mixture was left to reflux under a slight vacuum for
4 h at 85 °C. After cooling to room temperature, the mixture was gravity filtered to remove
the molecular sieves and excess benzaldehyde was removed by vacuum distillation to
give the crude product as a semi-crystalline syrup. The crude mixture was purified by
column chromatography (fractions were eluted with chloroform with increasing portions of
methanol: 1-10%). The product eluted in two distinct bands which, after evaporating to
dryness gave 0.90 g and 0.26 g of the required diastereoisomers with a combined yield of
78 %. Using NOESY NMR spectra, it was determined that the first fraction (Rf: 0.17,
CHCl3/MeOH 95:5 v/v) was the 7R- diastereomer of 12b whilst the second fraction (Rf:
0.26, CHCl3/MeOH 95:5 v/v) contained the 7S-diastereomer of 12b.
511
512
513
514
515
516
1H NMR 7S-diastereomer of 12b (400 MHz, d-DMSO): 7.35-7.55 (m, 5H, ArH), 5.98 (s,
1H, PhCH), 5.25 (s, 1H, OH), 4.71 (m, 1H, H-4), 4.33 (d, 1H, J6,6’ = 9.0 Hz, H-6), 4.16 (d,
1H, J6’,6 = 9.0 Hz, H-6’), 3.67 (dd, 1H, J5,4 = 2.0 Hz, J5,5’= 12.1 Hz, H-5), 3.49 (dd, 1H, J5’,4
= 3.2 Hz, J5’,5 = 12.2 Hz, H-5’) 2.49 (m, 2H, H-3,3’) . 13C NMR (100 MHz, d-DMSO): 176.4
(C1), 136.7, 127.4, 128.8, 130.2 (ArC), 104.9 (C7), 81.2 (C2), 78.7 (C4), 35.4 (C3), 62.5
(C5), 72.9 (C6).
22

ACCEPTED MANUSCRIPT
517
518
519
520
521
522
1H NMR 7R-diastereoisomer 12b (400 MHz, d-DMSO): 7.38-7.60 (m, 5H, ArH), 5.91 (s,
1H, PhCH), 5.21 (s, 1H, OH), 4.68 (m, 1H, H-4), 4.44 (d, 1H, J6,6’ = 9.5 Hz, H-6), 4.04 (d,
1H, J6’,6 = 9.5 Hz, H-6’), 3.68 (m, 1H, H-5), 3.49 (dd, 1H, J5’,4 = 3.4 Hz, J5’,5 12.3 Hz, H-5’),
2.60 (dd, 1H, J3,4 = 7.7 Hz, J3,3’ = 13.8 Hz, H-3), 2.33 (dd, 1H, J3’,4 = 6.0 Hz, J3’,3 = 14.0 Hz,
H-3’). 13C NMR (100 MHz, d-DMSO): 175.8 (C1), 136.9, 130.2,127. 9, 128.7 (ArC), 105.0
(C7), 81.0 (C2), 78.5 (C4), 73.3 (C6), 62.5 (C5), 34.5 (C3).
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
Synthesis of 5-O-benzoyl-(7R)-2,6-O-benzylidene-α-D-glucoisosaccharino-1,4-lactone
12c. Compound 12b (0.90 g; 3.60 mmol) was dissolved in pyridine (50 mL) and benzoyl
chloride (1.5 g; 1.3 mL; 10.7 mmol) and a catalytic quantity of DMAP (20 mg) were added.
The reaction was stirred at room temperature for 2 h. The pyridine was removed by rotary
evaporation and the resulting brown residue was dissolved in diethyl ether (50 mL) and
washed with a saturated sodium hydrogen carbonate solution (2 x 20 mL) and then with
saturated sodium chloride (20 mL). The organic layer was reduced to dryness, the crude
product was dissolved in sodium dried ether (20 mL) and this was once again dried on the
rotary evaporator. This process was repeated with sodium dried ether until the odour of
pyridine had disappeared to give a mixture of the desired product and pyridinium
hydrochloride as a semi-solid syrup. Finally, a small amount of the desired product was
obtained by recrystallization from petroleum ether, the residue was dissolved in petroleum
ether (bpt 40-60 oC,10 mL) and the volume of the solvent was reduced slowly until a white
cloudy solution was first observed. After cooling to room temperature, the mixture was
chilled at 5 °C for 3 h until white crystals were visible which were filtered under gravity and
dried at room temperature in a desiccator to isolate the crystalline product 12c as white
needles (0.26 g; yield: 20 %). IR (ATR) υ 1766.9 & 1727.2 (CO) 759.4, 708.6., 695.0. 1H
NMR (400 MHz, d-DMSO): 8.05-7.35 (m, 10H, ArH), 5.98 (s, 1H, PhCH), 5.06 (m,1H, H-
4), 4.46 (dd, 1H, J5,4 = 6.7 Hz, J5,5’ = 12.4 Hz, H-5), 4.57 (dd, 1H, J5’,4 = 2.7 Hz, J5’,5 = 12.4
23

ACCEPTED MANUSCRIPT
542
543
544
545
Hz, H-5’), 4.33-4.31 (2 x d, 2H, J6,6’ = 8.8 Hz, H-6, H-6’), 2.64 (m, 2H, H-3, H-3’). 13C NMR
(100 MHz, d-DMSO): 175.2 (C1), 165.9 (PhCO), 136.4, 134.1,130.3, 129.8, 129.7, 129.3,
128.8 & 127.5 (ArC), 104.9 (C7), 80.9 (C2), 76.1 (C4), 71.4 (C6), 65.7 (C5), 34.9 (C3).
HRMS (m/z) Calcd for C20H18O6 [M+K]+: 393.0735, Found: 393.0735.
546
547
4.5 Preparation of orthogonally protected trisubstituted 2-α-D-glucoisosaccharino-
1,4-lactone
548
4.5.1 2-O-Acetyl-5,6-di-O-benzyl-α-D-glucoisosaccharino-1,4-lactone (8c)
549
550
551
552
553
554
555
556
557
558
559
560
561
5,6-di-O-Dibenzyl-D-glucoisosaccharino-1,4-lactone 8b (1.0 g, 2.92 mmol) was reacted
with acetic anhydride (10 m) and sodium acetate (0.5 g) employing the procedure
described in section 4.2.1 to give a brown crystalline syrup which was purified by column
chromatography ( EtOAc/hexane 5/1-1:1 v/v ) providing 8c as a colourless oil (330 mg;
0.86 mmol; 29.4%); (Rf: 0.211; EtOAc/hexane 1:1 v/v). IR (ATR) υ 2866, 1775 & 1740
1
(C=O), 1453, 1369, 1205 & 1096 (C-O), 736, 697. H NMR (400 MHz, CDCl3) 7.33-7.26
(m, 10H, ArH), 4.96-4.90 (m, 1H, H-4), 4.52-4.49 (2d, 4H, J7,7’ = 4.72 Hz, H-7s), 3.70 (m,
2H, H-6), 3.63 (dd, 1H, J5,4 = 3.96 Hz, J5,5’ = 10.7 Hz, H-5), 3.57 (dd, 1H, J5’,4 = 5.04, J5’,5
=
10.7 Hz, H-5’), 2.60 (dd, 1H, J3,4 = 5.84 Hz, J3,3’ = 14.3 Hz, H-3), 2.42 (dd, 1H, J3’,4 = 5.12
13
Hz, J3’,3 = 14.3 Hz, H-3’), 2.10 (s, 3H, CH3CO). C NMR (100 MHz, CDCl3): 173.66 (C1),
170.00 (CH3CO), 137.72 & 137.20 (PhCq), 128.48, 128.46, 127.89, & 127.78 (PhC), 79.44
(C2), 76.51 (C1), 73.86 & 73.46 (PhCH2), 71.59 (C6), 71.10 (C5), 31.96 (C3), 20.63
(CH3CO). HRMS (m/z) Calcd for C22H24O6 [M+NH4]+
: 402.1911, Found: 402.1910.
562
563
564
4.5.2. 2-O-Acetyl-5,6-di-O-tert-butyldimethylsilyl-α-D-glucoisosaccharino-1,4-
lactone (9c)
The same procedure as described above for the synthesis of 8c was used to prepare 9c.
565
566
After chromatography, the product 9c was recovered as a white crystalline semi-solid
(900 mg, 2.08 mmol; 81%; Rf: 0.821, Hexane/EtOAc 3:1, v/v). IR (ATR) υ 2954, 2929,
24

ACCEPTED MANUSCRIPT
1
567
568
569
570
571
572
573
574
2857, 1783 &1747 (C=O), 1472, 1369, 1251, 1209 (C-O), 832, 776. H NMR (400 MHz,
CDCl3) 4.37-4.70 (m, 1H, H-4), 3.79 (d, 1H, J6,6’ = 9.80 Hz, H-6), 3.72 (d, 1H, J6’,6 = 9.80
Hz, H-6’), 3.70-3.64 (m, 2H, H-5), 2.48 (dd, 1H, J3,4’ = 6.30 Hz, J3,3’ = 14.50 Hz, H-3), 2.24
(dd, 1H, J3’,4 = 5.65 Hz, J3’,3 = 14.48 Hz, H-3’), 2.01 (s, 3H, CH3CO), 0.82 (2s, 18H, 2 x
13
TBDMS), 0.00 (4s, 12H, 2 x TBDMS). C NMR (100 MHz, CDCl3): 173.70 (C1), 169.74
(CH3CO), 80.31 (C2), 77.57 (C4), 65.36 (C6), 64.54 (C5), 31.57 (C3), 25.70, 25.63, 25.57
(TBDMS), 20.43 (CH3CO), -5.23, -5.55, -5.60 (TBDMS). HRMS (m/z) Calcd for
C20H40Si2O6 [M+Na]+
: 455.2256, Found: 455.2257.
575
576
577
578
579
4.5.3 2-O-Acetyl-5,6-di-O-fluorenylmethoxycarbonyl-α-D-glucoisosaccharino-1,4-
lactone (10c).
5,6-di-O-FMOC-α-GISAL (10b, 2.34 g, 3.86 mmol) was added to a round bottom flask
containing acetic anhydride (12.5 ml, 0.13 mol) and ZnCl2 (0.5 g). The solution was heated
to 100 oC and the reaction was allowed to proceed for 4 h at 100 oC. After 4h the sample
was cooled to room temperature and the contents of the flask were poured cautiously onto
ice cool water (100mL) to give the product as a semisolid. The suspension was stirred for
30 min over which time the product solidified. The solid was filtered and the residue dried
at room temperature overnight to give 10c as a white powder (1.5 g; 2.14 mmol, 55%). IR
(ATR) υ 1784, 1745 & 1709 (C=O), 1253, 1206 (C-O), 784, 759, 739. 1H NMR (400 MHz,
CDCl3) 7.77-7.73 (m, 4H, ArH), 7.61-7.56 (m, 4H, ArH), 7.42- 7.36 (m, 4H, ArH), 7.34-7.27
(m, 4H, ArH), 5.13-5.05 (m, 1H, H-4), 4.53-4.40 (m, 6H, 4 x H-8 & 2 x H-5), 4.32-4.22 (m,
580
581
582
583
584
585
586
587
588
589
590
591
592
593
3H, 2 x H-6 & H-9), 2.60 (dd, 1H, J3,4 = 9.38 Hz, J3,3’ = 14.32 Hz, H-3), 2.43 (dd, 1H, J3’,4
5.93, J3’,3 =14.32 Hz, H-3’), 2.17 (s, 3H, CH3CO). 13C NMR (100 MHz, CDCl3): 177.6,
=
177.1 (FMOCO), 171.7 (C1), 170.1 (CH3CO), 143.2 & 141.1 (ArCq), 128.5, 127.2, 125.1 &
120.5 (ArC), 77.6 (C2), 74.7 (C4), 70.7 (C8), 68.8 (C6), 67.7 (C5), 31.7 (C3), 21.1
(COCH3). HRMS (m/z) Calcd for C38H32O10 [M+ Na]+ 648.1995, found 648.1992.
25

ACCEPTED MANUSCRIPT
594
4.6
Preparation of mono-protected lactone derivatives (7e-f, 9e and 10e-10f)
595
596
4.6.1 The single step preparation of the mono-protected lactones 7e and 7f was described
597
598
in section 4.3.3
4.6.2 5-O-tert-Butyldimethylsilyl-α-D-glucoisosaccharino-1,4-lactone (9e).
599
600
601
602
603
604
605
606
607
608
609
610
611
612
613
614
615
α-D-Glucoisosaccharino-1,4-lactone 2 (1.0 g 6.17 mmol) was dissolved in pyridine (5 mL)
and the resulting solution was cautiously added dropwise to TBDMSCl (1.02 g, 6.79
mmol, 1.1 eq) while stirring. The reaction was allowed to proceed for 4 h at room
temperature. After 4h the contents of the flask were added to DCM (50 mL) and water (50
mL) and the two layers were separated. The aqueous layer was further extracted with
DCM (2 x 50 mL) and the combined organic layer was washed with 1% CuSO4, dried over
anhydrous sodium sulphate and concentrated to give a white crystalline syrup 9e (780 mg;
2.83 mmol; Yield: 46%); ( RF: 0.35, Hexane/EtOAc 3:1 v/v). IR (ATR) υ 3407 (O-H), 2952,
2929, 2856 (C-H), 1761 (C=O), 1463, 1361 (C-H), 1254, 1201, 1122 (C-O), 1034 (Si-OR)
833, 776. 1H NMR (400 MHz, CDCl3) 4.72- 4.69 (m, 1H, H-4), 3.87 (dd, 1H, J5,4 = 3.20 Hz,
J5,5’ = 11.70 Hz, H-5) 3.78 (d, 1H,J6,6’ = 11.80 Hz, H-6), 3.69 (d, 1H, J6’,6 = 11.83 Hz, H-6’),
3.66 (dd, 1H, J5’,4 = 3.76 Hz, J5’,5 = 11.74 Hz, H-5’), 2.21 (m, 2H, H-3, H3’), 0.85 (s, 9H,
13
TBDMS), 0.04 & 0.03 (2s, 6H, TBDMS). C NMR (100 MHz, CDCl3): 177.76 (C1), 78.57
(C4), 75.61(C2), 65.36 (C6), 63.56 (C5), 33.31 (C3), 25.70 (TBDMS), -5.42, -5.49
(TBDMS). HRMS (m/z) Calculated mass for C12H24SiO5 [M+Na]+ 299.1285, found
299.1284.
.
616
617
618
4.6.3 5-O-Flourenylmethoxycarbonyl-α-D-glucoisosaccharino-1,4-lactone (10e)
and 6-O-flourenylmethoxycarbonyl-α-D-glucoisosaccharino-1,4-lactone (10f)
26

ACCEPTED MANUSCRIPT
619
620
621
622
623
624
625
626
627
628
Dry α-
D
-Glucoisosaccharino-1,4-lactone (1.0 g, 6.17 mmol) was dissolved in 3-picoline (20
o
mL) and the resulting solution was added cautiously, whilst stirring, to cooled 0 C
crystalline 9-flourenylmethyloxycarbonyl chloride (FMOCCl) (3.35 g, 13 mmol). The
reaction was allowed to proceed for 3 h at room temperature. Cold water (60 mL) followed
by diethyl ether (60 mL) were added. The organic layer was separated and the aqueous
layer was extracted with diethyl ether (2 x 60 mL). The combined extracts was washed
with 2M HCl (2 x 100 mL), brine (2 x 100 mL) and dried over sodium sulphate,
concentrated to dryness to give a pale yellow crystalline crude syrup (3.62 g). The crude
was separated using column chromatography to give 10e (0.56 g, 1.46 mmol, 24% yield,
RF = 0.120) and 10f (1.32 g, 3.44 mmol, 56% yield, RF= 0.170). IR (ATR) υ
1
629
630
631
632
633
634
635
636
(10 e) IR (ATR) υ 3460 (O-H), 1747 (C=O), 1450, 1193 & 1256 (C-O), 738 (Ar C-H). H
NMR (400 MHz, CDCl3, 10e) 7.78-7.33 (m, 8H, ArH), 5.0-4.93 (m, 1H, H-4), 4.47-4.42 (m,
3H, H-8, H-8’ & H-9), 4.29-4.24 (m, 2H, H-5, H-5’), 3.86 (d, 1H, J6,6’= 11.9 Hz, H-6), 3.73
(d, 1H J6’,6 = 11.9 Hz, H-6), 2.35 (dd, 1H, J3,3’ =13.17 Hz, J3,4 = 7.0 Hz, H-3), 2.07 (dd, 1H,
J3’,3 = 13.17 Hz, J3’,4 =8.56 Hz, H-3’).13C (100 MHz, CDCl3) 177.4 (C1), 155.1 (C7), 143.3 ,
141.7 , 128.3 , 127.2 , 125.6, 120.5 (ArC), 76.0 (C2), 75.2 (C4), 70.9 (C8), 67.6 (C5), 65.2
(C6), 46.7 (C9), 33.6 (C3). HRMS (m/z) Calcd for C21H20O7 [M+Na]+: 407.1101, Found:
407.1101.
637
638
639
640
641
642
(10 f) IR (ATR) υ 3442 (O-H), 1747.5 (C=O), 1450, 1195 & 1256, (C-O), 727 (Ar C-H).1H
NMR (400 MHz, CDCl3, 10f) 7.74-7.30 (m, 8H, ArH), 4.83-4.75 (m, 1H, H-4) 4.49 (d, 1H,
J6,6’ = 12.0 Hz, H-6), 4.41 (m, 2H, H-8, H-8’), 4.33 (d, 1H, J6’,6 = 12.0 Hz, H-6), 4.23 (t, 1H,
J9,8= 8.37 Hz H-9), 3.92 (dd, 1H, J5,5’ = 12.98, J5,4 =2.50 Hz, H-5) 3.62 (dd, 1H, J5’,5
=
13
12.98 Hz, J5’,4 = 4.12 Hz, H-5’), 2.31 (2 x d, 2H, J3,3’ = 7.31 Hz, H3, H3’). C (100 MHz,
CDCl3) 175.8 (C1), 154.9 (C7), 143.1, 141.7, 128.6, 127.2, 125.4, 120.3 (ArC), 79.2 (C2),
27

ACCEPTED MANUSCRIPT
643
644
74.9 (C4), 70.6 (C8), 69.0 (C6), 63.6 (C5), 46.4 (C9), 33.8 (C3). HRMS (m/z) Calcd for
C21H20O7 [M+K]+: 423.0841, Found: 423.0854.
645
646
4.7 Preparation of 5,6-diprotected lactone derivative (13) in a one pot sequential
reactions
647
648
649
650
651
652
653
654
655
656
657
658
659
660
661
662
663
664
665
666
4.7.1 5-O-tert-Butyldimethylsilyl-6-O-acetyl-α-D-glucoisosacharino-1,4-lactone (13)
Dried α-D-glucoisosaccharino-1,4-lactone 2 (500 mg, 3.09 mmol) was dissolved in pyridine
(6 mL) whilst stirring for 10 min at room temperature. It was then added cautiously to tert-
butyldimethylsilyl chloride (TBDMSCl) (520 mg; 3.45 mmol; 1.1 eq) while stirring at room
temperature. The reaction was allowed to proceed for 1h, then acetyl chloride (250 µL;
3.40 mmol; 1.1 eq) was added cautiously. The reaction was allowed to continue for a
further 2 h at room temperature. After 2 h, the reaction was halted with DCM (50 mL),
followed by water (50 mL). The aqueous layer was further extracted with DCM (2 x 30 mL)
and the combined organic layer was dried over anhydrous sodium sulphate and
concentrated to give a crude 13 (3.30 g) as a brown syrup which was purified using
column chromatography to give the desired product as a white solid (300 mg; 0.754 mmol;
Yield: 24 %); (RF: 0.42; Hexane/EtOAc 5:1 v/v). IR (ATR) υ 3420 (O-H), 2954, 2930, 2857,
1750 (C=O), 1463, 1377 (C-H), 1203, 1129 (C-O), 1044 (Si-OR), 1011, 833, 777.
1H NMR (400 MHz, CDCl3) 4.72-4.68 (m, 1H, H-4), 4.37 (d, 1H, J6,6’ = 11.56Hz, H-6), 4.19
(d, 1H, J6’,6 = 11.56 H-6’), 3.92 (dd, 1H, J5,5’ = 11.72, J5,4 = 3.12 Hz, H-5 ), 3.66 (dd, 1H,
J5’,5 = 11.72, J5’,4 = 3.36 Hz, H-5’), 2.38 (dd, 1H, J3,3’ = 13.83, J3’,4 = 8.08 Hz, H-3), 2.23
(dd, 1H, J3’,3 = 13.83, J3’,4 = 6.88 Hz, H-3’), 2.08 (CH3CO), 0.87 (s, 9H, TBDMS), 0.06 &
0.05 (2s, 6H TBDMS). 13C (100 MHz, CDCl3) 175.5 (C1), 170.8 (C7), 77.97(C4), 74.9
(C2), 65.6 (C6), 63.3 (C5), 33.7 (C3), 25.8 (TBDMS), 20.7 (C8), -5.4, -5.5 (TBDMS).
HRMS (m/z): Calculated mass for C14H26O6Si [M+Na]+ 341.1391, Found: 341.1390.
667
28
