Cyclization of 1,6-Enynes Catalyzed by
Gold Nanoparticles Supported on TiO2:
Significant Changes in Selectivity and
Mechanism, as Compared to
Homogeneous Au-Catalysis
Charis Gryparis, Christina Efe, Christos Raptis, Ioannis N. Lykakis,† and
Manolis Stratakis*
Department of Chemistry, University of Crete, Voutes 71003 Iraklion, Greece
stratakis@chemistry.uoc.gr
Received April 5, 2012
ABSTRACT
Gold nanoparticles supported on TiO2 (1.2 mol %) catalyze, for the first time under heterogeneous conditions, the cycloisomerization of a series of
1,6-enynes in high yields. In several cases, the product selectivity differs significantly as compared to homogeneous Au(I)-catalysis. Based on
product analysis and stereoisotopic studies it is proposed that the major or exclusive pathway involves a 5-exo cyclization mode to form
stereoselectively gold cyclopropyl carbenes that undergo a single cleavage pathway, in contrast to homogeneous Au-catalysis where the double
cleavage pathway operates substantially.
