264
Helvetica Chimica Acta – Vol. 96 (2013)
b) b-Iodone (6 g) was condensed with cyanoacetic acid (1.1 equiv.) in piperidine (20 ml) and benzene
(20 ml) under reflux (Dean-Stark apparatus): (2E,4E)/(2Z,4E)-3 4 :1 (nearly quant.). This mixture was
separated by CC (SiO2, CH2Cl2).
(2E,4E)- and (2Z,4E)-3-Methyl-5-(2,6,6-trimethylcyclohex-1-en-1-yl)penta-2,4-dienal (4). At 08, 1,2m
DIBAL-H in toluene (23.5 ml, 28.2 mmol, 1.1 equiv.) was added slowly to 3 (5.06 g) in toluene (20 ml).
After 30 min, the reaction was quenched with 1m H2SO4. The salts were filtered off, and Et2O (40 ml) and
H2O (20 ml) were added. The org. layer was washed twice with brine, dried (MgSO4), and concentrated.
The crude (2E,4E)/(2Z,4E)-4 49 :1 was separated by CC (SiO2, CH2Cl2): (2E,4E)-4 (82%). Yellow oil.
IR: 1668. 1H-NMR1): 10.11 (d, J ¼ 8.16, HꢀC(11)); 6.73 (d, J ¼ 16.2, HꢀC(7)); 6.20 (d, J ¼ 16.2, HꢀC(8));
5.92 (d, J ¼ 8.16, HꢀC(10)); 2.3 (s, MeꢀC(9)); 2.03 (m, CH2(4)); 1.71 (s, MeꢀC(5)); 1.6 (m, CH2(3)); 1.47
(m, CH2(2)); 1.03 (s, 2 MeꢀC(1)). 13C-NMR: 135.7 (CH); 135.4 (CH); 128.7 (CH); 39.7 (CH2); 33.4
(CH2); 19.4 (CH2); 28.9 (Me); 21.6 (Me); 12.9 (Me).
(3E)-4-(2,3,6-Trimethylphenyl)but-3-en-2-one (5). retro-a-Ionone (9.62 g; 50 mmol) and 2,3-di-
chloro-5,6-dicyano-1,4-benzoquinone (DDQ; 34 g, 3 equiv.) in 1,2-dichloroethane (100 ml) were heated
for 1 h at 658. The mixture was filtered, the filtrate concentrated, and the crude product purified by CC
(SiO2, pentane/1,2-dichloroethane 1:1): 5 (50%). Yellow oil. IR (film): 1680. 1H-NMR1): 7.72 (d, J ¼ 16,
HꢀC(7)); 7.05, 6.95 (2d, J ¼ 7, HꢀC(3), HꢀC(4)); 6.25 (d, J ¼ 16, HꢀC(8)); 2.40, 235, 2.30, 2.25 (4s, 4 Me).
13C-NMR (CDCl3): 188.0 (C¼O); 134.6 (C); 134.5 (C); 133.5 (C); 143.1 (CH); 133.4 (CH); 129.8 (CH);
127.5 (CH); 27.4 (Me); 20.8 (Me); 16.9 (Me).
(4E)-3-Methyl-5-(2,3,6-trimethylphenyl)penta-2,4-dienenitrile (6). In a DeanꢀStark apparatus, a soln.
of 5 (6 g) and cyanoacetic acid (8.21 g, 3 equiv.) in benzene (30 ml) was cooled to 08, and piperidine
(25.43 ml, 8 equiv.) was slowly added. Then, the mixture was refluxed for 4 h. The benzene was
evaporated, the crude product extracted with Et2O, the org. layer washed with brine and H2O, dried
(MgSO4), and concentrated, the crude product extracted with CH2Cl2, and this extract quickly filtered
over a mixture of basic alumina and SiO2 40 :60: (2E,4E)/(2Z,4E)-6 95 :5 (96%; ratio determined by
1H-NMR). Yellow ochre crystals which were purified by recrystallization from Et2O/pentane 30 :70:
major isomer (2E,4E)-6. M.p. 628. IR (film): 2206. 1H-NMR1): 7.02 (d, J ¼ 16.3, HꢀC(7)); 6.98 (d, J ¼ 7.5,
HꢀC(3)); 6.96 (d, J ¼ 7.5, HꢀC(4)); 6.28 (d, J ¼ 16.3, HꢀC(8)); 5.25 (s, HꢀC(10)); 2.32 (s, MeꢀC(2)); 2.26
(s, MeꢀC(9)); 2.25 (s, MeꢀC(5)); 2.2 (s, MeꢀC(1)). 13C-NMR (CN): 118.0; 157.1 (C); 136.0 (C); 134.9
(C); 134.7 (C); 133.8 (C); 135.9 (CH); 134.5 (CH); 129.7 (CH); 127.8 (CH); 98.3 (CH); 21.2 (Me); 20.7
(Me); 17.4 (Me); 16.9 (Me).
(4E)-(2,3,6-Trimethylphenyl)penta-2,4-dienal (7). At 08, 1.2m DIBAL-H in toluene (24 ml, 1.2
equiv.) was slowly added under vigorous stirring to 6 (5 g) in toluene. The mixture was stirred for 2 h and
then hydrolyzed by 2m H2SO4. After filtration of the aluminium salts, Et2O (50 ml) and H2O (50 ml)
were added. The org. layer was washed with brine and H2O, dried (MgSO4), and concentrated and the
crude product purified by CC (SiO2, CH2Cl2): major isomer (2E,4E)-7 (85%). Yellow oil. IR (film):
1659. 1H-NMR1): 10.20 (d, J ¼ 8.1, HꢀC(11)); 7.18 (d, J ¼ 16.4, HꢀC(7)); 7.01 (2d, J ¼ 7.6, HꢀC(3),
HꢀC(4)); 6.36 (d, J ¼ 16.4, HꢀC(8)); 6.14 (d, J ¼ 8.1, HꢀC(10)); 2.44 (s, MeꢀC(9)); 2.26 (s, MeꢀC(1),
MeꢀC(2)); 2.23 (s, MeꢀC(5)). 13C-NMR: 191.3 (C¼O); 154.1 (C); 135.9 (C); 134.5 (C); 134.4 (C); 133.5
(C); 137.2 (CH); 135.2 (CH); 129.7 (CH); 129.2 (CH); 127.5 (CH); 20.8 (Me); 20.4 (Me); 13.0 (Me); 9.7
(Me).
(2E,4E,6E)- and (2Z,4E,6E)-2-Cyano-3,7,11-trimethydodeca-2,4,6,10-tetraenoic Acid (8) and
(2E,4E,6E)- and (2Z,4E,6E)-3,7,11-Trimethydodeca-2,4,6,10-tetraenenitrile (9). At 08, a mixture of citral
(1.52 g) and methyl cyano(isopropylidene)acetate (¼ methyl 2-cyano-3-methylbut-2-enoate; 3; 2.325 g,
1.5 equiv.) was added to tBuOK (1.12 g, 1 equiv.) in MeOH (25 ml). The soln. was allowed to stay at r.t.
for 24 h. The MeOH was evaporated and ice (100 g) was added. The mixture was extracted with Et2O, the
aq. layer acidified and extracted with Et2O, and this extract washed with H2O, dried (MgSO4), and
concentrated: crude 8 as a mixture of isomers.
A soln. of crude 8 (1 g) in piperidine (50 ml) and pyridine (50 ml) was refluxed until the flow of CO2
ceased (2 – 3 h). The bases were evaporated and the crude product was extracted with Et2O. The extract
was washed successively with a 1m HCl and H2O, dried (MgSO4) and concentrated: (2E,4E,6E)/
(2Z,4E,6E)-9 7:3. This mixture was separated by CC (SiO2, CH2Cl2).
