Synthesis of novel calixarenes having a tweezer-type structure
Yukihiro Okada,a,* Masashi Yoshidaa and Jun Nishimurab,*
aDepartment of Chemistry, Gunma University, Kiryu 376-8515, Japan
bDepartment of Nano-Material Systems, Gunma University, Kiryu 376-8515, Japan
Received 20 October 2004; revised 3 February 2005; accepted 4 February 2005
Available online 24 March 2005
Abstract—Monobromide was used as the starting material. The [2+2]photocycloaddition of diolefins directly gave all the calix[4]-
arene regioisomers having chiral and achiral structures in 20–47% yields. They formed a complex with alkali metal ions and
extracted large metal picrates rather than small ones.
ꢀ 2005 Elsevier Ltd. All rights reserved.
Intramolecular [2+2]photocycloaddition of styrene
derivatives is a powerful and convenient method for
the construction of a calixarene-like skeleton (e.g., trans-
formation of diolefin 4 into macrocycle 5).1–3 The cyclo-
butane ring maintained the desired conformation of
calix[4]arene analogs to suppress the benzene ring rota-
tion at the opposite 1,3-position.4–6 Accordingly, two
bisphenol units were forced to adopt a face-to-face con-
formation, forming a cage structure such as calix[4]-
arene. Although many calix[n]arenes were reported as
powerful host molecules, the molecular tweezer-type
calixarenes, especially those of chiral structures, are
scarcely known.7–11 Therefore, we were prompted to de-
velop a direct synthesis of three regioisomers of this type
of calixarene by using the same starting material. In this
paper, we report a simple synthesis of tweezer-type ca-
lix[4]arenes by the intramolecular photocycloaddition.
for 18 h. The vinylation of 3 was performed with tributyl
vinyl tin, PdCl2(PPh3)2, and LiCl in dry DMF at 80 ꢁC
for 6 h to give diolefins 4 in 38–45% yields. [2+2]Photo-
cycloaddition of 4 (0.11–1.2 mM) was carried out by
irradiation with a 400 W high-pressure Hg lamp (pyrex
filter) in dry benzene for 23 h. After evaporation, calix-
[4]arenes 5 were isolated in 41–47% yields by column
chromatography (SiO2, benzene/ethyl acetate = 2/1).
Calixarenes 8 having a crown ether (n = 3–5) close to the
cyclobutane ring were obtained as follows: dibromides 6
were obtained in 73–88% yields by etherification with
2b, the corresponding oligoethyleneglycol ditosylate,
and K2CO3 in dry DMF at 100 ꢁC for 18 h. The vinyl-
ation of 6 was performed with tributyl vinyl tin,
PdCl2(PPh3)2, and LiCl in dry DMF at 80 ꢁC for 6 h
to give diolefins 7 in 44–50% yields. [2+2]Photocycload-
dition of 7 was carried out by irradiation with a 400 W
high-pressure Hg lamp (pyrex filter) in dry benzene for
23 h. After evaporation, calix[4]arenes 8 were isolated
in 20–46% yields by column chromatography (SiO2,
benzene/ethyl acetate = 2/1).
The synthesis of all calix[4]arene analogs is shown in
Scheme 1. Monobromide 1 was used as the starting
material. Monoetherification of 1 was performed with
Li2CO3 and CH3I in dry DMF at rt for 12 h to give
monomethylether 2a and b in 68 and 17% yields, respec-
tively. Calixarenes 5 having a crown ether (n = 3–5)
apart from the cyclobutane ring were obtained as fol-
lows: dibromides 3 were obtained in 84–92% yields by
the etherification with 2a, the corresponding oligoethyl-
eneglycol ditosylate, and K2CO3 in dry DMF at 100 ꢁC
Chiral calixarenes 13 were obtained as follows: mono-
bromides 9 were obtained in quantitative yields by
etherification with 2b, the corresponding oligoethylene-
glycol monotosylate, and K2CO3 in dry DMF at 80–
90 ꢁC for 18 h. The tosylation of 9 was performed with
TsCl, triethylamine, 4-(dimethylamino)pyridine in dry
CH2Cl2 for 24 h to give tosylates 10 in quantitative
yields. Dibromides 11 were obtained in 79–83% yields
by etherification with 2a, 10, and K2CO3 in dry DMF
at 80–90 ꢁC for 18 h. The vinylation of 11 was per-
formed with tributyl vinyl tin, PdCl2(PPh3)2, and LiCl
Keywords: Calixarene; Cyclophane; Photocycloaddition; Alkali metal
ion.
*
Corresponding authors. Tel./fax: +81 277 30 1311; e-mail: okada@
chem.gunma-u.ac.jp
0040-4039/$ - see front matter ꢀ 2005 Elsevier Ltd. All rights reserved.
doi:10.1016/j.tetlet.2005.02.064

3262
Y. Okada et al. / Tetrahedron Letters 46 (2005) 3261–3263
OH
OH
OCH3 OH
OH
OCH3
Br
Li2CO3
CH3I
DMF, r.t., 12 h
Br
Br
+
1
2b
2a
n-1O
(n-Bu)3SnCH=CH2
PdCl2(PPh3)2
n-1
OCH3 O
O
OCH3
Br
TsO
O
K2CO3
OTs
Br
2a
DMF, LiCl
80 ˚C, 6 h
DMF, 100 ˚C, 18 h
3
O
O
n-1
OCH3
OCH3
OCH3
O
O n-1
O
hν (Pyrex)
dry benzene
23 h
O
OCH3
n=3-5
4
5
n-1
(n-Bu)3SnCH=CH2
OCH3
PdCl2(PPh3)2
n-1
OCH3
O
OTs
O
O
TsO
O
K2CO3
Br Br
2b
DMF, LiCl
80 ˚C, 6 h
DMF, 100 ˚C, 18 h
6
O
O
n-1
OCH3
O n-1
OCH3
OCH3
O
O
hν (Pyrex)
O
OCH3
dry benzene
23 h
n=3-5
7
8
n-1
O
n-1OTs
OCH3
O
OCH3
O
O
n-1OH
TsO
OH
O
K2CO3
Br
TsCl, N(CH2CH3)3
Br
2b
DMF, 80-90 ˚C,
18 h
CH2Cl2,
N
N
9
10
n-1
O
2a
OCH3
O
O
OCH3
(n-Bu)3SnCH=CH2
PdCl2(PPh3)2
Br
Br
K2CO3
DMF, 80-90 ˚C,
18 h
DMF, LiCl
80 ˚C, 6 h
11
O
n-1
CH3O
O
O n-1
O
OCH3
OCH3
O
hν (Pyrex)
dry benzene
23 h
O
OCH3
13
12
n=3-5
Scheme 1.
in dry DMF at 80 ꢁC for 6 h to give diolefins 12 in 43–
52% yields. [2+2]Photocycloaddition of 12 was carried
out by irradiation with a 400 W high-pressure Hg lamp
(pyrex filter) in dry benzene for 23 h. After evaporation,
calix[4]arenes 13 were isolated in 32–45% yields by col-
umn chromatography (SiO2, benzene/ethyl acetate = 2/1).
Each enantiomer of 13 could be separated by chiral
HPLC column (Chiralpak AD, hexane/2-propanol =
23/1 as an eluent).3,11
