A Readily Available Chiral Ag-Based N-Heterocyclic Carbene
Complex for Use in Efficient and Highly Enantioselective
Ru-Catalyzed Olefin Metathesis and Cu-Catalyzed Allylic
Alkylation Reactions
Joshua J. Van Veldhuizen, John E. Campbell, Russell E. Giudici, and
Amir H. Hoveyda*
Contribution from the Department of Chemistry, Merkert Chemistry Center,
Boston College, Chestnut Hill, Massachusetts 02467
Received January 11, 2005; E-mail: amir.hoveyda@bc.edu
Abstract: A new chiral bidentate N-heterocyclic carbene (NHC) ligand has been designed and synthesized.
The NHC ligand bears a chiral diamine backbone and an achiral biphenol group; upon metal complexation
(derived from Ag(I), Ru(II), or Cu(II)), the diamine moiety induces >98% diastereoselectivity such that the
biaryl unit coordinates to the metal center to afford the desired complex as a single atropisomer. Because
the ligand does not require optically pure biaryl amino alcohols, its synthesis is significantly shorter and
simpler than the related first generation ligands bearing a chiral binaphthyl-based amino alcohol. The chiral
NHC ligand can be used in the preparation of highly effective Ru- and Cu-based complexes (prepared and
used in situ from the Ag(I) carbene) that promote enantioselective olefin metathesis and allylic alkylations
with scope that is improved from previously reported protocols. In many cases, transformations promoted
by the chiral NHC-based complexes proceed with higher enantioselectivity and reactivity than was observed
with previously reported complexes.
Scheme 1. First Generation Bidentate Ru- and Ag-NHC
Complexes
Introduction
The development of efficient and practical chiral ligands and
catalysts is one of the most critical research objectives in modern
organic synthesis.1 Investigations in these laboratories during
the past several years have been focused on the identification
of various classes of optically pure chiral ligands that promote
a range of enantioselective C-C bond forming reactions.2 One
area of investigation has resulted in the synthesis of chiral
bidentate N-heterocyclic carbene (NHC) ligands,3 which have
led to Ru-based chiral complexes 1,2c shown in Scheme 1. These
chiral metal carbenes are noteworthy partly due to their ability
to promote highly enantioselective ring-opening metathesis/
cross-metathesis (AROM/CM) reactions4 that cannot be effected
with chiral Mo-based complexes;2d olefin metathesis reactions
catalyzed by 1 can be performed under conditions that do not
require rigorous exclusion of air, in the absence of solvent or
without the need for purified solvents. We have also disclosed
the synthesis of air-stable dimeric Ag(I) complex 2 (Scheme
1),5 which, in the presence of various Cu salts, can be used to
initiate enantioselective allylic alkylations with alkylzinc re-
(3) For additional examples of chiral NHC ligands in metal-catalyzed asym-
metric catalysis, see: (a) Powell, M. T.; Hou, D.-R.; Perry, M. C.; Cui,
X.; Burgess, K. J. Am. Chem. Soc. 2001, 123, 8878-8879. (b) Ma, Y.;
Song, C.; Ma, C.; Sun, Z.; Chai, Q.; Andrus, M. B. Angew. Chem., Int.
Ed. 2003, 42, 5871-5874. (c) Bonnet, L. C.; Douthwaite, R. E.; Kariuki,
B. M.; Organometallics 2003, 22, 4187-4189. (d) Alexakis, A.; Winn, C.
L.; Guillen, F.; Pytkowicz, J.; Roland, S.; Mangeney, P. AdV. Synth. Catal.
2003, 345, 345-348. (e) Jensen, D. R.; Sigman, M. S. Org. Lett. 2003, 5,
63-65. (f) Gade, L. H.; Cesar, V.; Bellemin-Laponnaz, S. Angew. Chem.,
Int. Ed. 2004, 43, 1014-1017. (g) Bappert, E.; Helmchen, G. Synlett 2004,
1789-1793. (h) Arnold, P. L.; Rodden, M.; Davis, K. M.; Scarisbrick, A.
C.; Blake, A. J.; Wilson, C. Chem. Commun. 2004, 1612-1613. (i)
Tominaga, S.; Oi, Y.; Kato, T.; An, D. K.; Okamoto, S. Tetrahedron Lett.
2004, 45, 5585-5588. For brief overviews, see: (j) Enders, D.; Gielen, H.
J. Organomet. Chem. 2001, 617-618, 70-80. (k) Perry, M. C.; Burgess,
K. Tetrahedron: Asymmetry 2003, 14, 951-961.
(1) ComprehensiVe Asymmetric Catalysis; Jacobsen, E. N., Pfaltz, A., Yama-
moto, H., Eds.; Springer: Berlin, Germany, 1999.
(2) For representative examples, see: (a) Cole, B. M.; Shimizu, K. D.; Krueger,
C. A.; Harrity, J. P.; Snapper, M. L.; Hoveyda, A. H. Angew. Chem., Int.
Ed. Engl. 1996, 35, 1668-1671. (b) Krueger, C. A.; Kuntz, K. W.; Dzierba,
C. D.; Wirschun, W. G.; Gleason, J. D.; Snapper, M. L.; Hoveyda, A. H.
J. Am. Chem. Soc. 1999, 121, 4284-4285. (c) Van Veldhuizen, J. J.; Garber,
S. B.; Kingsbury, J. S.; Hoveyda, A. H. J. Am. Chem. Soc. 2002, 124,
4954-4955. (d) Schrock, R. R.; Hoveyda, A. H. Angew. Chem., Int. Ed.
2003, 42, 4592-4633. (e) Josephsohn, N. S.; Snapper, M. L.; Hoveyda,
A. H. J. Am. Chem. Soc. 2003, 125, 4018-4019. (f) Mampreian, D. M.;
Hoveyda, A. H. Org. Lett. 2004, 6, 2829-2832. (g) Hoveyda, A. H.; Hird,
A. W.; Kacprzynski, M. A. Chem. Commun. 2004, 1779-1785.
(4) (a) Reference 2c. (b) Van Veldhuizen, J. J.; Gillingham, D. G.; Garber, S.
B.; Kataoka, O.; Hoveyda, A. H. J. Am. Chem. Soc. 2003, 125, 12502-
12508. (c) Gillingham, D. G.; Kataoka, O.; Garber, S. B.; Hoveyda, A. H.
J. Am. Chem. Soc. 2004, 126, 12288-12290.
9
10.1021/ja050179j CCC: $30.25 © 2005 American Chemical Society
J. AM. CHEM. SOC. 2005, 127, 6877-6882
6877

A R T I C L E S
Van Veldhuizen et al.
agents with unprecedented levels of generality (in terms of both
substrate and alkylzincs) and enantioselectivity.6
pure binaphthyl-based amino alcohol, we decided to employ a
readily available optically pure chiral diamine backbone as the
source of chirality. Thus, we surmised that the asymmetric
diamine structure could allow us to employ an achiral biphenyl-
based amino alcohol: diastereoselectivity would be induced
once the transition metal is inserted within the structure of the
bidentate ligand.9,10
As a result of the promising developments mentioned above
in connection with Ru- and Cu-catalyzed transformations, and
because N-heterocyclic carbenes are effective in initiating a
range of organic transformations as ligands7 or catalysts,8 we
set out to design, synthesize, and develop a new generation of
the chiral bidentate NHCs that can be prepared more readily.
Specifically, a significant drawback regarding the general utility
of the first generation ligands (cf., Scheme 1) arises from the
level of efficiency and practicality with which the requisite
optically pure axially chiral amino alcohols are typically
prepared.4
Herein, we describe the synthesis, structure, and utility of a
significantly more easily accessible chiral bidentate NHC and
the utility of the corresponding Ag(I) complex in promoting
Ru-catalyzed asymmetric olefin metathesis and Cu-catalyzed
allylic alkylations. We also demonstrate that metal complexes
derived from the new bidentate NHC often provide higher
reactivity and enantioselectivity in comparison to the chiral
complexes depicted in Scheme 1.
Synthesis of Chiral NHC Ligand and the Derived Ag(I)
Complex. The above hypothesis was brought to fruition in the
manner illustrated in Scheme 2. Treatment of commercially
available optically pure diamine 311 with aryliodide 412 in the
presence of 5 mol % Pd(OAc)2 and rac-BINAP with NaOt-Bu
(toluene, 110 °C, 24 h) leads to the formation of secondary
arylamine 5.13 At this point, the reaction mixture is charged
with 2 equiv of mesityl bromide (for 12 h), leading to the
formation of the desired diamine 6 in 65% overall yield for the
two-step, one-vessel procedure. Conversion of the methyl ether
to the corresponding phenol, followed by treatment with HCl
and triethylorthoformate, results in the generation of optically
pure imidazolinium salt 7 in 45% overall yield. Subjection of 7
to Ag2O at reflux for 3 h in a 1:1 mixture of THF and C6H6
leads to facile generation of Ag(I) complex 8 in >98% isolated
yield as a single diastereomer (>98% de, as judged by 400 MHz
1H NMR analysis). Thus, the diamine chirality is readily
transferred to the biphenol moiety, such that metal complexation
proceeds with complete control of stereoselectivity. The dia-
stereomer that is formed exclusively is one where the chelating
phenol moiety points away from the proximal phenyl unit of
the chiral diamine backbone. The structural assignment for
complex 8 is supported by an X-ray crystal structure, illustrated
in Scheme 2 (details in the Supporting Information).
