Two-Dimensional Porous Molecular Networks of
Dehydrobenzo[12]annulene Derivatives via Alkyl Chain
Interdigitation
Kazukuni Tahara,† Shuhei Furukawa,‡ Hiroshi Uji-i,‡ Tsutomu Uchino,†
Tomoyuki Ichikawa,† Jian Zhang,‡ Wael Mamdouh,‡ Motohiro Sonoda,†
Frans C. De Schryver,‡ Steven De Feyter,*,‡ and Yoshito Tobe*,†
Contribution from the DiVision of Frontier Materials Science, Graduate School of Engineering
Science, Osaka UniVersity, Toyonaka, Osaka 560-8531, Japan, and Department of Chemistry,
DiVision of Molecular and Nanomaterials, Laboratory of Photochemistry and Spectroscopy, and
Institute of Nanoscale Physics and Chemistry, Katholieke UniVersiteit LeuVen (KULeuVen),
Celestijnenlaan 200 F, B-3001 LeuVen, Belgium
Received August 1, 2006; E-mail: Steven.DeFeyter@chem.kuleuven.be; tobe@chem.es.osaka-u.ac.jp.
Abstract: The self-assembly of a series of hexadehydrotribenzo[12]annulene (DBA) derivatives has been
scrutinized by scanning tunneling microscopy (STM) at the liquid-solid interface. First, the influence of
core symmetry on the network structure was investigated by comparing the two-dimensional (2D) ordering
of rhombic bisDBA 1a and triangular DBA 2a (Figure 1). BisDBA 1a forms a Kagome´ network upon
physisorption from 1,2,4-trichlorobenzene (TCB) onto highly oriented pyrolytic graphite (HOPG). Under
similar experimental conditions, DBA 2a shows the formation of a honeycomb network. The core symmetry
and location of alkyl substituents determine the network structure. The most remarkable feature of the
DBA networks is the interdigitation of the nonpolar alkyl chains: they connect the π-conjugated cores and
direct their orientation. As a result, 2D open networks with voids are formed. Second, the effect of alkyl
chain length on the structure of DBA patterns was investigated. Upon increasing the length of the alkyl
chains (DBAs 3c-e) a transition from honeycomb networks to linear networks was observed in TCB, an
observation attributed to stronger molecule-substrate interactions. Third, the effect of solvent on the structure
of the nonpolar DBA networks was investigated in four different solvents: TCB as a polar aromatic solvent,
1-phenyloctane as a solvent having both aromatic and aliphatic moieties, n-tetradecane as an aliphatic
solvent, and octanoic acid as a polar alkylated solvent. The solvent dramatically changes the structure of
the DBA networks. The solvent effects are discussed in terms of factors that influence the mobility of
molecules at the liquid-solid interface such as solvation.
Introduction
copy (STM) is a powerful technique for the investigation of
two-dimensional (2D) crystal structures of π-electron-conjugated
The control of the spatial organization of functional π-electron-
conjugated systems1 has led to major advances in the field of
organic materials, such as liquid crystal materials, molecular-
scale electronics,2 and molecular devices.3 Recently, the struc-
tural control of organic monolayers has been presented as a
further important step to achieve highly ordered organic
nanostructures and also as an opportunity to fabricate molecular
scale devices on flat substrates.1b,4 Scanning tunneling micros-
systems with atomic scale resolution. STM not only operates
under ultrahigh vacuum conditions but also at the interface
between two condensed media; one is an atomically flat
conducting solid and the other is a gas, a liquid, a liquid
crystalline material, or a gel.
One of the useful approaches is to decorate the surface with
molecules that form regular 2D periodic patterns by self-
assembly at the liquid-solid interface.5 In such systems, it is
essential to control the competition between the following four
modes of interaction to construct the desired molecular patterns;
molecule-molecule, molecule-substrate, molecule-solvent, and
solvent-substrate interactions. Especially, the control of mol-
† Osaka University.
‡ Katholieke Universiteit Leuven.
(1) (a) Hoeben, F. J. M.; Jonkheijm, P.; Meijer, E. W.; Schenning, A. P. H. J.
Chem. ReV. 2005, 105, 1491-1546. (b) Grimsdale, A. C.; Mu¨llen, K.
Angew. Chem., Int. Ed. 2005, 44, 5592-5629.
(2) (a) Joachim, C.; Gimzewski, J. K.; Aviram, A. Nature 2000, 408, 541-
548. (b) Nitzan, A.; Ratner, M. A. Science 2003, 300, 1384-1389.
(3) Collier, C. P.; Mattersteig, G.; Wong, E. W.; Luo, Y.; Beverly, K.; Sampaio,
J.; Raymo, F. M.; Stoddart, J. F.; Heath, J. R. Science 2000, 289, 1172-
1175.
(4) (a) Samor´ı, P.; Severin, N.; Simpson, C. D.; Mu¨llen, K.; Rabe, J. P. J. Am.
Chem. Soc. 2002, 124, 9454-9457. (b) Piot, L.; Marchenko, A.; Wu, J.;
Mu¨llen, K.; Fichou, D. J. Am. Chem. Soc. 2005, 127, 16245-16250. (c)
Okawa, Y.; Aono, M. Nature 2001, 409, 683-684.
(5) For recent reviews on STM measurements at the liquid-solid interface,
see, for example: (a) De Feyter, S.; De Schryver, F. C. Chem. Soc. ReV.
2003, 32, 139-150. (b) De Feyter, S.; De Schryver, F. C. J. Phys. Chem.
B 2005, 109, 4290-4302. (c) Samor´ı, P.; Rabe, J. P. J. Phys.: Condens.
Matter 2002, 14, 9955-9973. (d) Giancarlo, L. C.; Flynn, G. W. Acc. Chem.
Res. 2000, 33, 491-501. (e) Wan, L.-J. Acc. Chem. Res. 2006, 39, 334-
342. (f) Hermann, B. A.; Scherer, L. J; Housecroft, C. E.; Constable, E. C.
AdV. Funct. Mater. 2006, 16, 221-235.
9
10.1021/ja0655441 CCC: $33.50 © 2006 American Chemical Society
J. AM. CHEM. SOC. 2006, 128, 16613-16625
16613

A R T I C L E S
Tahara et al.
Figure 1. Structures of (a) decadehydrotetrabenzo[12]annuleno[12]annulene (bisDBAs, 1a,b), (b) hexadehydrotribenzo[12]annulene (DBA, 2a-b and 3a-
f), and (c) triphenylene (4a,b) derivatives.
ecule-molecule interactions is crucial for the formation of
molecular networks: typically, discrete molecular building-
blocks are ‘connected’ to each other by virtue of directional
intermolecular interactions such as hydrogen bonding or metal
coordination. Being able to correlate molecular features such
as shape, position of interacting sites, as well as electronic
properties with the resulting topology of the molecular archi-
tectures would enable us to design and construct the network
structures and their functions. This strategy is already well-
known as “crystal engineering” in three-dimensional (3D) crystal
systems.6 Of special interest are 2D molecular porous net-
works.7,8
In 2D systems, the molecule-substrate interaction is an
important issue to regulate network topologies in terms of
symmetry matching of the molecules with the substrate. The
strength of the molecule-substrate interactions can be controlled
by adjusting the van der Waals interaction between molecules
and substrate. For example, the molecule-substrate interaction
on graphite linearly increases with the length of the alkyl
chains.9,10
hydrogen bonding, van der Waals interactions) between the
solvent and the other molecules.13 The solvent also affects the
mobility of the molecules14 at the liquid-solid interface, e.g.,
by affecting the adsorption-desorption dynamics. In this
dynamic process, the mobility of the molecules is affected by
the solvation energy (molecule-solvent interaction) and possibly
also by solvent viscosity.15 Hence, for a successful rational
construction of 2D molecular networks, an accurate molecular
design taking into account these four interactions is essential.
In this contribution, we systematically study the formation
of 2D molecular networks of dehydrobenzo[12]annulene (DBA)
derivatives on highly oriented pyrolytic graphite (HOPG). Our
strategy to form 2D regular networks is based on choosing rigid
π-electron-conjugated frameworks with long alkyl chains as
molecular building-blocks. In this respect, DBA derivatives are
good candidates because of their planar π-electron-conjugated
framework, unique molecular shape, suitable core size to
favor directional alkyl chain interdigitation, and core symmetry
which fits the graphite lattice (Figure 1).16 Furthermore, their
synthetic versatility allows chemical modification of their
periphery.17
At the liquid-solid interface, solvent molecules play a
significant role in the network formation and have therefore a
strong effect on the network structures. Sometimes solvent
molecules are coadsorbed in the molecular network (solvent-
substrate interaction).11 Coadsorption of solvent molecules
critically depends among other factors on the size and shape of
the solvent molecules12 as well as the mode of interaction (e.g.,
Instead of using hydrogen bonds,5,7,18 we focus on directional
alkyl chain interdigitation and tune the strength of molecule-
molecule and molecule-substrate interactions by stepwise
elongation of the alkyl chains. For that purpose, in addition to
the previously synthesized decyl-substituted rhombic-shaped
bisDBA 1a and triangular-shaped DBA 2a, a series of DBA
derivatives with alkoxy chains of variable length 3a-e were
synthesized (Figure 1).
