ABSTRACT: The canonical WNT pathway plays an important role in cancer pathogenesis.
Inhibition of poly(ADP-ribose) polymerase catalytic activity of the tankyrases (TNKS/TNKS2)
has been reported to reduce the Wnt/β-catenin signal by preventing poly ADP-ribosylation
dependent degradation of AXIN, a negative regulator of Wnt/β-catenin signaling. With the goal
of investigating the effects of tankyrase and Wnt pathway inhibition on tumor growth, we set out
to find small molecule inhibitors of TNKS/TNKS2 with suitable drug-like properties. Starting
from 1a, a high-throughput screening hit, the spiroindoline derivative 40c (RK-287107) was
discovered as a potent TNKS/TNKS2 inhibitor with >7,000-fold selectivity against the PARP1
enzyme, which inhibits WNT-responsive TCF reporter activity and proliferation of human
colorectal cancer cell line COLO-320DM. RK-287107 also demonstrated dose-dependent tumor
growth inhibition in a mouse xenograft model. These observations suggest that RK-287107 is a
promising lead compound for the development of novel tankyrase inhibitors as anticancer agents.
