T. Janeczko et al. / Journal of Molecular Catalysis B: Enzymatic 82 (2012) 24–31
25
2. Materials and methods
CrysAlis CCD and CrysAlis Red programs [13]. Structure was solved
by direct methods (program SHELXS97) and refined by the full
matrix least-squares method on all F2 data using the SHELXL97
programs [14]. Non-hydrogen atoms were refined with anisotropic
displacement parameters; hydrogen atoms were placed in cal-
culated positions or found in ꢁꢂ maps. Before the last cycle of
refinement all H atoms were fixed and were allowed to ride on their
parent atoms. The Friedel pairs were merged before the final refine-
ment. The absolute structure was chosen on the basis of known
absolute configuration of the substrate. Crystallographic data for
crystal 18 in this paper have been deposited with the Cambridge
Crystallographic Data Center as supplementary publication CCDC
869598. Copies of the data can be obtained, free of charge, on appli-
cation to CCDC, 12 Union Road, Cambridge CB2 1EZ, UK (Tel.: +44
2.1. Materials
The substrates: 17-hydroxyandrost-4-en-3-one (1), androst-
4-en-3,17-dione (2), 17␣-methyl-17-hydroxyandrost-4-en-3-
one (6), 3-hydroxyandrost-5-en-17-one (10), pregnan-4-en-
3,20-dione (13) and 3-hydroxypregnan-5-en-20-one (14) were
purchased from Sigma–Aldrich. The microorganism D. igniaria KCH
6670 used in this study was obtained from the collection of the
Department of Forest Phytopathology of the University of Agricul-
ture in Kraków, Poland. It was isolated from forest environment
(south Poland) from dead parts of leafy plants. The strain was
maintained on Sabouraud 4% dextrose-agar slopes and freshly sub-
cultured before use in the transformation experiments.
2.2. Screening procedure
2.5. Spectral data of isolated metabolites
Erlenmeyer flasks (300 ml), each containing 100 ml of the
medium consisting of 3 g glucose and 1 g aminobac dissolved in
water, were inoculated with a suspension of microorganisms and
then incubated for 3 days at 25 ◦C on a rotary shaker. After full
growth of the culture (about 12 g of cell dry weight/l) 20 mg of
a substrate dissolved in 1 ml of acetone was added. After 1, 3, 6
and 9 days of incubation under the above conditions, portions of
10 ml of the transformation mixture were taken out and extracted
with CHCl3 (3× 10 ml). The extracts were dried over MgSO4, con-
centrated in vacuo and analyzed by GC. All the experiments were
repeated three times.
analysis, 1H NMR, 13C NMR and correlation spectroscopy. 13C NMR
spectra of all the products obtained are summarized in Table 1. For
compound 18 was additionally performed crystallographic analysis
(Fig. 1).
2.5.1. 7˛-Hydroxytestosterone (3)
After 3 days of incubation of testosterone (1) (100 mg) and
androstenedione (2) (100 mg), 52 mg and 17 mg of compound 3
were isolated respectively. Anal. Calcd. for C19H28O3: C 74.96, H
9.27%; found: C 75.02, H 9.37%. Mass spectrum indicated a molec-
ular ion at m/z 305 of composition C19H
26O3; 1H NMR (CDCl3)
2.3. Preparative biotransformation
ı (ppm): 0.78 (s, 3H, 18-CH3); 1.19 (s, 3H, 19-CH3); 3.69 (t, 1H,
J = 8.47 Hz, H-17); 3.96 (m, 1H, Wh = 9.6 Hz, H-7); 5.78 (s, 1H, H-4).
The same transformations were performed on the preparative
scale in 2000 ml flasks, each containing 500 ml of the cultivation
medium. The cultures were incubated under the same conditions
and then 200 mg of substrate dissolved in 2 ml of acetone was added
to the grown cultures. After 3–9 days of incubation the mixtures
were extracted with CHCl3 (3× 300 ml), dried (MgSO4) and con-
centrated in vacuo. The transformation products were separated
by column chromatography and analyzed (TLC, GC, GC–MS).
2.5.2. 7˛-Hydroxyandrostenedione (4)
After
3 days of incubation of testosterone (1) (100 mg),
androstenedione (2) (100 mg) and DHEA (10) (100 mg), 16 mg,
39 mg and 21 mg of compound 4 were isolated respectively. Anal.
Calcd. for C19H26O3: C 75.46, H 8.67%; found: C 75.49, H 8.69%.
Mass spectrum indicated a molecular ion at m/z 303 of composition
C
19H26O3; 1H NMR (CDCl3) ı (ppm): 0.91 (s, 3H, 18-CH3); 1.21 (s,
2.4. Analytical methods
3H, 19-CH3); 4.09 (br s, Wh = 10.6 Hz, 1H, H-7); 5.82 (s, 1H, H-4).
The course of biotransformation was controlled by means of
TLC. Composition of product mixtures was established by GC. Prod-
ucts were separated by column chromatography using silica gel
(Kieselgel 60, 230–400 mesh, Merck) and hexane/acetone mix-
ture (2:1, v/v) as eluent. Analytical TLC was carried out on silica
gel G (Merck). Compounds were detected by spraying the plates
with H2SO4/CH3OH mixture (1:1, v/v). GC analysis was performed
using a Hewlett-Packard 5890A (Series II) GC instrument fitted with
a flame ionization detector (FID). The HP-5 (crosslinked phenyl
methyl siloxane) capillary column (30 m × 0.32 mm × 0.25 m)
was used to determine the composition of product mix-
tures. The following temperature programme was used: 200 ◦C
(0 min)/10 ◦C/min/270 ◦C (0 min)/30 ◦C/min/300 ◦C (5 min). The
NMR spectra were recorded on DRX 500 MHz Bruker spectrometer
and measured in CDCl3. MS analyses were performed on a Varian
Chrompack GC CP-3800 Saturn 2000GC/MS/MS with an ionizing
energy of 70 eV. Elemental analysis was carried out on the Vario
EL III CHNS (Elementor). Crystallographic measurement was per-
formed at 100 K using an Oxford Cryosystem device on a Kuma
KM4CCD -axis diffractometer with a graphite-monochromated
2.5.3. 3ˇ,17ˇ-Dihydroxy-5˛-androstane (5)
After
3 days of incubation of testosterone (1) (100 mg),
androstenedione (2) (100 mg) and DHEA (10) (100 mg), 6 mg, 5 mg
and 4 mg of compound 5 were isolated respectively. Anal. Calcd.
for C19H32O2: C 78.03, H 11.03%; found: C 77.89, H 11.19%. Mass
spectrum indicated a molecular ion at m/z 293 of composition
C19H32O2; 1H NMR (CDCl3) ı (ppm): 0.80 (s, 3H, 19-CH3); 0.83 (s,
3H, 18-CH3); 3.58–3.68 (m, 2H, H-3␣ and H-17␣).
2.5.4. 12ˇ-Hydroxy-17˛-methyltestosterone (7)
Six-day transformation of 17␣-methyltestosterone (6) (100 mg)
yielded 32 mg of compound 7. Anal. Calcd. for C20H30O3: C 75.43, H
9.50%; found: C 75.31, H 9.79%. Mass spectrum indicated a molec-
ular ion at m/z 319 of composition C20H30O3; 1H NMR (CDCl3) ı
(ppm): 0.95 (s, 3H, 18-CH3); 1.19 (s, 3H, 19-CH3); 1.34 (s, 3H, 17␣-
CH3); 3.74 (dd, 1H, J = 16.8, 7.2 Hz, H-12␣); 5.72 (s, 1H, H-4).
2.5.5. 7˛-Hydroxy-17˛-methyltestosterone (8)
Six-day transformation of 17␣-methyltestosterone (6) (100 mg)
yielded 25 mg of compound 8. Anal. Calcd. for C20H30O3: C 75.43, H
9.50%; found: C 75.59, H 9.28%. Mass spectrum indicated a molec-
ular ion at m/z 319 of composition C20H30O3; 1H NMR (CDCl3) ı
˚
Mo K␣ radiation (ꢀ = 0.71073 A). The data were corrected for
Lorentz and polarization effects. No absorption correction was
applied. Data reduction and analysis were carried out with the
