Microwave-Accelerated Spiro-Cyclizations of
o-Halobenzyl Cyclohexenyl Ethers by
Palladium(0) Catalysis
Andreas Svennebring, Peter Nilsson, and Mats Larhed*
Organic Pharmaceutical Chemistry, Department of Medicinal
Chemistry, Uppsala Biomedical Centre, Uppsala UniVersity,
Box 574, SE-751 23 Uppsala, Sweden
mats@orgfarm.uu.se
ReceiVed May 2, 2007
SCHEME 1. Preparation of Heck Cyclizations Substrates
1-6
A number of new spiro[cyclohexane-1,1′-isobenzofuran]-
based compounds was synthesized by palladium(0)-catalyzed
5-exo cyclization of a series of cyclohexenyl o-halobenzyl
ethers. Controlled microwave heating was found to promote
both product yield and reaction rate without compromising
the selectivity. Heck cyclization of aryl iodide 6, 2-(2-
iodobenzyloxy)cyclohex-2-enyl acetate, proceeded selectively
without involvement of the allylic acetate functionality.
New methods in preparation of constrained products are of
importance in both natural product synthesis and in medicinal
chemistry applications. In drug discovery, the use of restricted
analogues serves as an important method to allow determination
of bioactive conformations.1 Palladium(0)-catalyzed Heck cou-
pling reactions have emerged as one of the most versatile
carbon-carbon bond forming processes.2-6 The reaction is
attractive for the synthetic chemist since (a) it provides a unique
method for arylation or vinylation of double bonds, (b) it
proceeds under mild conditions, and c) it tolerates the presence
of a wide variety of functional groups. Although the traditional
intermolecular Heck coupling has found wide utility, the
intramolecular version of the Heck arylation constitutes perhaps
the most important development of the Heck arylation reaction
in recent times.7,8 Unfortunately, the optimization of Heck
reaction conditions is typically demanding and reaction times
are generally long.9
Preparation of Cyclization Precursors. The required ethers
1-6 were all prepared from commercially available 1,2-
cyclohexanedione (Scheme 1). Ketones 1 and 2 were prepared
by treating the appropriate o-halobenzyl alcohol with an excess
of 1,2-cyclohexanedione and a catalytic amount of p-toluene-
sulfonic acid (PTSA). The condensation reaction was carried
out in dry benzene, and the produced water was continuously
removed via azeotropic distillation. This process afforded 1 and
2 in good yields (83% and 77%, respectively). Alcohols 3 and
4, were smoothly synthesized by the sodium borohydride
reduction of 1 and 2, respectively. Finally, allylic esters 5 and
6 were prepared in 90% and 89% yield by acetylation of 3 and
4, using acetic anhydride and 4-dimethylaminopyridine (DMAP).
Vinyl ethers 7 and 8 were synthesized via an acid-catalyzed
transetherification reaction from methyl 1-cyclohexenyl ether
and the appropriate o-halobenzyl alcohol (Scheme 2). The
