Ir-Catalyzed ortho-Borylation of Phenols Directed by
Substrate-Ligand Electrostatic Interactions: A Combined
Experimental/in Silico Strategy for Optimizing Weak Interactions
Buddhadeb Chattopadhyay, Jonathan E Dannatt, Ivonne L. Andújar-de Sanctis,
Kristin A. Gore, Robert E. Maleczka, Daniel A. Singleton, and Milton R. Smith
J. Am. Chem. Soc., Just Accepted Manuscript • Publication Date (Web): 28 Apr 2017
Downloaded from http://pubs.acs.org on April 28, 2017
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a free service to the research community to expedite the
dissemination of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts
appear in full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been
fully peer reviewed, but should not be considered the official version of record. They are accessible to all
readers and citable by the Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered
to authors. Therefore, the “Just Accepted” Web site may not include all articles that will be published
in the journal. After a manuscript is technically edited and formatted, it will be removed from the “Just
Accepted” Web site and published as an ASAP article. Note that technical editing may introduce minor
changes to the manuscript text and/or graphics which could affect content, and all legal disclaimers
and ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors
or consequences arising from the use of information contained in these “Just Accepted” manuscripts.
Journal of the American Chemical Society is published by the American Chemical
Society. 1155 Sixteenth Street N.W., Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 11
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
Ir-Catalyzed ortho-Borylation of Phenols Directed by
Substrate-Ligand Electrostatic Interactions: A Combined
Experimental/in Silico Strategy for Optimizing Weak
Interactions
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Buddhadeb Chattopadhyay,†,§ Jonathan E. Dannatt,† Ivonne L. Andujar-De Sanctis,‡ Kristin A.
Gore,† Robert E. Maleczka, Jr.†,* Daniel A. Singleton, ‡,* and Milton R. Smith, III†,*
†Department of Chemistry, Michigan State University, 578 South Shaw Lane, East Lansing, Michigan 48824-1322 USA
‡Department of Chemistry, Texas A&M University, PO Box 30012, College Station, Texas 77842
§Center of Bio-Medical Research, Division of Molecular Synthesis & Drug Discovery, Sanjay Gandhi Post Graduate
Institute of Medical Sciences, Raebareli Road, Lucknow, Uttar Pradesh 226014, India
Supporting Information Placeholder
Abstract: A strategy for affecting ortho versus meta/para selectivity in Ir-catalyzed C–H borylations (CHBs) of phenols is
described. From selectivity observations with ArylOBpin (pin = pinacolate), it is hypothesized that an electrostatic
interaction between the partial negatively charged OBpin group and the partial positively charged bipyridine ligand of the
catalyst favors ortho selectivity. Experimental and computational studies designed to test this hypothesis support it. From
further computational work a second generation, in silico-designed catalyst emerged, where replacing Bpin with Beg (eg =
ethylene glycolate) was predicted to significantly improve ortho selectivity. Experimentally, reactions employing B2eg2
gave ortho selectivities >99%. Adding triethylamine significantly improved conversions. This ligand-substrate
electrostatic interaction provides a unique control element for selective C–H functionalization.
Introduction
Catalytic C-H functionalization is a powerful synthetic tool that offers innate synthetic advantages in terms of step, atom
and redox economy, provided that the catalytic functionalization is both active and selective.1 Simultaneously obtaining
both high activity and high selectivity, however, can be challenging. It might be supposed that strong catalyst-substrate
interactions are best for obtaining selectivity. However, strong interactions can be a death knell for activity. Yu’s work, for
example, has demonstrated that the involvement of highly stable metallacycle intermediates significantly limits the range
of reactive substrates; weak coordination leads to higher reactivity, providing access to a large variety of
functionalizations.2,3 Weak interactions can be fully sufficient for selectivity, since a ΔΔG‡ of 2.7 kcal·mol–1 is sufficient
for 99:1 selectivity at 25 °C.
C–H functionalizations using non-covalent direction for uncharged substrates have been identified in hydrophobic-
hydrophobic interactions between cyclodextrins and steroids in C–H hydroxylations,4–7 host-guest size-differentiated C–H
activations,8,9 and hydrogen bond directed C–H functionalizations.10–14 Hydrogen bonding has also proven effective in
directing the hydroformylation of alkenes15,16 and the hydrometalation of unsymmetrical alkynes.17,18 Recently, significant
progress has been made in demonstrating the viability of anion-π interactions for directing catalysis,19,20 though
experimental quantification of these interactions is challenging.21 The importance of non-covalent interactions is routinely
seen in organocatalysis and biological systems.22,23
The regioselectivity of metal catalyzed C–H borylations (CHBs) of the sp2-hybridized C–H bonds in arenes is usually
sterically determined.24 To complement this selectivity, the direction of CHBs toward sterically encumbered positions has
been of great interest.25–27 The most common approach makes use of strong substrate-catalyst interactions, particularly
chelation of a directed metalating group (DMG) to the metal center to achieve ortho borylation (Scheme 1). This has been
accomplished using surface supported phosphines,28 certain monodentate ligands,29 hemilabile bidentate ligands,30 and
P,Si- N,Si- and N,B-bidentate anionic ligands.31,32 Alternative approaches to ortho borylation shown in Scheme 1 include
relay direction with silanes,33 which is also useful in directed C–H silylations.34,35
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 2 of 11
1
2
3
Scheme 1. Selected Mechanisms for Directed Borylation
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Weaker interactions have been exploited in CHBs as well. For example, the N–H protons in aniline carbamates can
hydrogen bond to the oxygen atoms of Bpin ligands, favoring ortho borylation. Similar interactions were exploited in
traceless ortho borylations of anilines and aminopyridines.36,37 Recently, meta-selective borylations of imines have been
proposed to proceed via a related outer-sphere mechanism.38 These hydrogen bonding concepts have been extended to
meta-selective CHBs where pendant ureas on dipyridyl ligands function as dual hydrogen bond donors (Scheme 1).39
Kanai and coworkers described ortho borylation of aryl thioethers directed by a Lewis acid-base interaction between the
thiol ether in the substrate and a boron glycolate linked to the bipyridine ligand.40,41 Interestingly, high meta selectivity was
achieved only for glycolates bearing trifluoromethyl groups. Both Kanai and Phipps’ recent approaches rely on
interactions between pendant groups on the bipyridine ligand with matching functionality in the substrate to direct CHB to
the desired site.
While extending traceless protection chemistry to phenols, where the OH group would be converted to OBpin prior to
C–H borylation, enhanced ortho borylation was observed. In this paper, experimental and computational results implicate
a subtle electrostatic attraction between O–Bglycolate and bipyridyl groups as the origin for ortho direction (Scheme 1).
Calculated stabilizations of ortho transition states were sensitive to the steric nature of the boryl ligand; thus, greatly
enhanced selectivities resulted by redesigning the diboron reagent.
Results and Discussion
We first examined the borylation of phenol with two equivalents of HBpin, expecting that C6H5OBpin would form
rapidly, and the ensuing borylation of this intermediate would afford a mixture of m- and p-HOC6H4Bpin upon workup
(Scheme 2).
Scheme 2. Phenol Borylation with Traceless Protection
Using the commonly employed ligand/precatalyst combination dtbpy/[Ir(OMe)(cod)]2 (dtbpy = 4,4´-tert-butyl-2,2´-
bipyridine, cod = 1,5-cyclooctadiene),42 a striking amount of ortho borylation was found (o:m+p = 15:85). This was
surprising since anisole affords only 4% of the ortho borylation product and an OBpin group is sterically larger than an
2
ACS Paragon Plus Environment

Page 3 of 11
Journal of the American Chemical Society
1
2
3
OMe group.
4
5
6
7
8
9
The propensity for borylation ortho to OBpin was more apparent in comparisons between 4-substituted phenols and 4-
substituted anisoles. Chart 1 clearly shows that borylation ortho to OBpin relative to OMe is preferred.43 Borylation of 4-
chlorophenol was highly ortho selective, while the CHB for 4-cyanophenol was not. However, CHB ortho to OBin was
more pronounced than CHB ortho to OMe in 4-cyanoanisole, where borylation ortho to CN is preferred. Borylation ortho
to F predominated for both 4-fluoro substrates, although borylation ortho to OBpin increased slightly. With these results in
hand, CHB for a range of phenols was surveyed. The results are shown in Table 1.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Chart 1. C-–H Borylation of 4-Substituted Phenols and Anisoles
The yields for the products in Table 1 range from excellent to moderate. This process is operationally simpler than the
relay-directed approach highlighted in Scheme 133,44 as the relay directed approach requires (i) catalyzed O–silylation of
the phenol with Et2SiH2 to generate ArOSiEt2H, (ii) conversion of Bpin intermediates to BF3K salts, and (iii) removal of
the O–SiEt2H directing groups affording high yields of pure BF3K phenols. The Bpin to BF3K conversion was required
because protodeborylation45 of C–Bpin occurred when Si–O cleavage of Bpin products were attempted.
The loadings in Table 1 are higher than we normally employ because the reactions were run at small scale with weighed
amounts of catalyst (see SI for details). To test for scalability at lower catalyst loadings compound 1a was prepared from
2.0 g of 4-chorophenol, 1.1 equiv HBpin, and 0.7 equiv B2pin2, using 1.5 mol % [Ir(OMe)(cod)]2 and 3 mol% dtbpy. After
workup, 2.9 g (74% yield) of 1a was isolated as a colorless solid.
With the exception of products 1c, 1o, and 1p, ortho selectivity is high (>99%) and is not degraded by substitution ortho
to OH. However, the substrates in Table 1 where high selectivity is observed have substituents at the 4-position that are
larger than CN or F. This indicates that the unusual OBpin directing effect is not strong enough to overcome standard
steric control. While the traceless CHB transformation in Table 1 is simpler than Hartwig’s relay-directed ortho CHBs of
phenols, the ortho selectivity for their protocol was high for all substrates, including phenol. This motivated us to better
identify features that contribute to the selectivities in the traceless reaction. The reaction of 4-methoxyphenol is
particularly perplexing because the catalyst exclusively selects the position ortho to OBpin yielding 1d when given a
choice of CHB ortho to the smaller OMe substituent. To gain further insight into this unusual directing effect, we turned to
theory.
3
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 4 of 11
1
2
3
a
Table 1. Ortho Borylation of Substituted Phenols with B2pin2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
aFor details see SI, yields are isolated. bEntry 1a was obtained in 74% yield on a 2 g scale using 1.5 mol% Ir-catalyst, 3.0 mol% dtbpy and 0.7
equiv B2pin2. The Bpin product was converted to the BF3K salt for isolation. Conversion and isomer ratio based on GC-FID. Approximately
18% diborylated product was observed.
c
d
e
Our initial computational model substrate was 4-MeO-C6H4OBpin´ (3), where pin´ = meso-butylene glycolate. The
OBpin´ model was chosen because its methyl groups can partially reflect the steric interactions present in the full catalytic
system. A series of transition structures for the borylation of 3 with (bpy)Ir(Beg)2(Bpin´) were located in M06 calculations
employing an SDD basis set on Ir and a 6-31G* basis set on the other atoms. The lowest-energy structures for borylation
ortho to OBpin´ (TS3-OBpin´anti) and ortho to OMe (TS3-OMeanti) are shown in Figure 1. The “anti” designation in these
structures refers to the arrangement of the methyl or Bpin´ groups relative to the bpy ligand; a structure with the Bpin´ syn
to the bpy (TS3-OBpin´syn, see the SI) was higher in energy. A striking observation was that TS3-OBpin´anti is
enthalpically favored over TS3-OMeanti by 5.2 kcal·mol–1. The steric interaction of the two pin´ groups in TS3-OBpin´anti
restricts their motion, so that TS3-OMeanti is entropically favored, but TS3-OBpin´anti remains favored in free-energy by
1.8 kcal·mol–1. From the model, the isomer ratio is predicted to be 92:8, favoring 1d. Since the minor isomer is not
experimentally detected in borylation of 4-methoxyphenol, the model underestimates Grel for TS3-OMe.
4
ACS Paragon Plus Environment

Page 5 of 11
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 1. Transition state structures, and their calculated electrostatic potential surfaces, for borylation of 4-MeO-
C6H4OBpin´ with (bpy)Ir(Beg)2(Bpin´).
We sought to identify the structural effect responsible for the stunning enthalpic preference for TS3-OBpin´anti over
TS3-OMeanti. An unusual feature of both structures is a rotation of the OBpin´ or OMe groups out of the plane of the
aromatic ring when ortho to the C–H insertion. The B27–O26–Cipso–Ca and the CMe–O30–Cipso–Ca dihedral angles in TS3-
OBpin´anti and TS3-OMeanti are ≈ 90°. This rotation is not present in the ground state of 4-MeO-C6H4OBpin´ nor when
the OBpin or OMe groups are meta to the C-H insertion. In the orthogonal orientations, the dipoles associated with the
B27–O26–Cipso, B27-O43-C, and CMe–O30–Cipso angles are oriented towards the proximal bpy pyridine ring, suggesting an
electrostatic interaction. To assess the role of this electrostatic interaction in the selectivity, the NPA (Natural Population
Analysis) charges were calculated with selected values given in Figure 1 (see SI for full listing). The NPA charges on O43
and O26 in TS3-OBpin´anti are significantly more negative than O30 in TS3-OMeanti, and O43 has the shortest contacts to
H47 and H49, which are partially positively charged. Electrostatic potential maps were calculated and are shown in Figure
1. From the maps, O43 is best positioned to maximize attraction to the positive charge of H47 and H49, while it is
expected that O26 and O30 offer similar degrees of electrostatic stabilization to their respective transition states. In Figure
1, the sum of all charges on C, H, and N on the pyridine ring closest OBpin´ and OMe in the two TSs are 0.12 and 0.11,
respectively. A crude electrostatic model can be constructed for TS3-OBpin´anti and TS3-OMe where the charge on the
pyridine ring for both transition states is approximated as a point charge at its centroid, pycent. For OBpin’, a charge
corresponding to the sum of B and its surrounding O atoms is placed at B. For TS3-OMeanti, the OMe is simply
represented by the charge on O. These models predict ~ 3 kcal·mol–1 stabilization of TS3-OBpin´anti over TS3-OMe,
which would be sufficient for the observed selectivity. The O26–pycent distance in TS3-OBpin´anti is 0.31 Å shorter than
the O30–pycent distance in TS3-OMe. If the electrostatic model is correct, electronic alteration of the bipyridine ligand
should affect selectivities. To test this, borylations of phenol were performed with 4,4´-substituted bipyridines 4a–d. As
shown in Chart 2, there is a clear trend for increasing ortho selectivity as the bipyridine ligand is made more electron
deficient. Moreover, plots of log10[o/(m + p)] vs. the Hammett parameters of the 4,4´ substituents on the bipyridine ligands
are linear and have a positive slope (Chart 2).
5
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 6 of 11
1
2
3
Chart 2. Ligand Effects on Borylation Selectivity
4
5
6
7
1. 1.1 equiv HBpin, rt, 10 min
2. 0.25 equiv B2pin2,1.5 mol %
[Ir(cod)(OMe)]2, 3 mol %
OH
OH
Bpin
R
R
8
9
N
N
CyH, 80 oC, 2-24 h
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
R
conversion
o:(m + p)
NMe2
t-Bu
CN
98%
92%
26%
68%
6:94
15:85
45:55
35:65
CF3
Although this provides experimental evidence to the proposed electrostatic interactions, the improved ortho selectivity
for 4d comes at the expense of catalytic activity.42 Thus, we sought another solution for improving borylation selectivities
that provided synthetically useful reactivity and selectivity for substrates like 4-fluorophenol.
A closer inspection of the calculated TSs revealed significant distortions of the arene geometries for TS3-OBpin´anti and
TS3-OMeanti (Fig. 2). Specifically, steric pressure from the Bpin´ groups pushes the arene away from the activating Beg
…
group in TS3-OBpin´anti. This results in elongation of Hact Bact in TS3-OBpin´anti (2.360 Å) relative to TS3-OMeanti
(2.159 Å), which translates to a 23% reduction in the natural bond order between Hact and Bact. Since Beg is the smallest
glycolatoboryl ligand, we hypothesized that transition states with Beg ligands should be less distorted, allowing for TS
stabilization by removing the steric clash between Bpin groups, which simultaneously would allow for maximum TS
stabilization from Hact Bact interactions. To test this hypothesis, 4-F-C6H4OBeg was chosen to assess borylation ortho to
OBeg or F, which is the smallest non-hydrogen substituent. TSs for borylation ortho to F (TS5-F) and ortho to OBeg
(TS5-OBeganti) were calculated and are shown in Figure 3.
…
Figure 2. Calculated inner coordination spheres, selected metrical parameters, and natural bond orders for TS3-OBpin´anti
and TS3-OMeanti (left) and TS5-OBeganti and TS5-F (right).
The geometries of the inner coordination sphere for borylation ortho to OBeg or F are nearly identical as seen by the
equivalent Cipso-Ir-Bact angles for TS5-OBeganti and TS5-F (Fig. 2). This indicates that the reduced repulsion between Beg
groups restores the Hact Bact interaction in TS5-OBeganti. Further, TS5-OBeganti has short contacts between O31–H43 and
O31–H54 (Fig. 3). The OBeg B to pyridine centroid distance in TS5-OBeganti is 0.3 Å shorter than the corresponding
distance in TS3-OBpin´anti, thus increasing the strength of the electrostatic interaction and further stabilizing TS5-
OBeganti. Interestingly, TS5-OBegsyn, where the OBeg is directly below a pyridine ring in the dtbpy ligand, is 1.6
kcal·mol–1 above the anti configuration. We attribute this to the significant distortion of the bipyridine ligand which is seen
in the 22.2° dihedral between the dtbpy nitrogens compared to the 5.6° dihedral in TS5-OBeganti. This twisting of the
dtbpy ligand results in a small elongation of the Ir–N bond (0.03 Å), but more importantly, N8 has poorer overlap with the
Ir center. Stabilizing Lewis acid/base interactions between a boryl ligand and the substrate were considered as well.
…
6
ACS Paragon Plus Environment

Page 7 of 11
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 3. Transition states for borylation of 4-F-C6H4OBeg with (dtbpy)Ir(Beg)3.
There is a distance of 3.22 Å between an O of Bact and B of the OBeg group in TS5-OBeganti. The energy of this
interaction is below the 0.05 kcal·mol–1 threshold for second order perturbation theory analysis of the Fock matrix in the
NBO basis. Although a TS was located (Fig. 3, TS5-OBegsyn-Beg) with a short B…O contact, 2.76 Å, between O26 in the
OBeg group and B14 in a spectator boryl ligand, it lies 2.3 kcal·mol–1 above TS5-OBeganti. Despite searching, no Lewis
acid/base interaction could be found which provided a lower TS than TS5-OBeganti. Overall, TS5-OBeganti is favored over
TS5-F by 1.5 kcal·mol–1, which is due to OBeg…dtbpy electrostatic interactions. This corresponds to a 93:7 isomer ratio
favoring borylation ortho to OBeg at 25 °C.
We tested the computational prediction by preparing B2eg2 from B2(OH)4 and ethylene glycol (see SI for details). The
room temperature rates were too slow for direct comparison to the computational “conditions,” so CHBs were performed
at 80 °C (Table 2). The Beg products were converted to pinacolate esters, which were easier to purify. Most importantly,
CHB with B2eg2 as the boron source provided exclusively ortho borylated products. Such exclusive regiochemical
outcomes, validated the theoretically driven decision to employ B2eg2 in these reactions. That said, we were not
disappointed by the fact that that the experimentally observed ortho borylation of 4-fluorophenol (1r) was higher than that
predicted by theory.
a
Table 2. ortho-Borylation of Phenols with B2eg2
aFor details see SI. Yields are isolated mono-borylated products. Diborylated products were not isolated. bMono:o,o´-diborylation = 82:18. cB2eg2
used as 1.2 equiv, mono:o,o´-diborylation = 89:11. dMono:o,o´-diborylation = 81:19. eMono:o,o´-diborylation = 85:15.
Diborylated side products were observed for some of the substrates, but were readily separable by chromatography.
Given the previously reported difficulties in isolating ortho borylated phenols, the yields here of pure products are highly
satisfactory. Remarkably, toluene was an excellent solvent for the reactions, as competing solvent borylation was not
observed.
In addition to a change in the boron sources, the Table 2 conditions includes the addition of triethylamine, without
which CHB conversions for all phenols plateaued at 50%. Unlike HBpin, which is the most stable HBgly (gly = glycolate)
compound, HBeg rapidly disproportionates at room temperature to B2H6 and B2eg3 (Scheme 3). However, Shore showed
that HBeg reacts with NMe3 to afford HBeg·NMe3 which is stable at room temperature.46,47
7
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 8 of 11
1
2
3
4
5
6
7
8
9
Our initial hypothesis was that HBeg generated during the formation of ArylOBeg rapidly disproportionated, and the
B2H6 produced converted free ArylOH to B(OAryl)3 and H2, as shown in red in Scheme 3. Aryl borates rapidly hydrolyze
to phenols and boric acid upon work-up, which would account for the recovery of unreacted phenols (Scheme 3). It is
noteworthy that XBeg compounds (X = halogen) are not stable. They associate in solution, which has been attributed to
Lewis acid-interactions.48 Acid-catalyzed side reactions of B2H6 or HBeg could be deleterious. If this is the case,
triethylamine could trap these reactive species as their NEt3 adducts before they wreak havoc on the desired borylation
pathway (Scheme 3). Given the instability of HBeg, its addition to phenols to form ArylOBeg species is not synthetically
applicable. Thus, an important question is “Are ArylOBeg intermediates formed in the reaction?”
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 3. Minimizing B(OAryl)3 Formation
Owing to the stability of HBpin, we generate ArylOBpin and clearly demonstrate they are competent in the B2pin2 ortho
CHBs of phenols (Table 1). However, we wished to show that ArylOBpin species form without the addition of
pinacolborane. To demonstrate this, [Ir(dtbpy)(COE)(Bpin)3] (COE = cyclooctene) in cyclohexane-d12 was added to 4-
FC6H4OH which provided quantitative conversion to 4-FC6H4OBpin by 19F, 11B and H NMR. Proton resonances closely
1
matching previously reported [Ir(dtbpy)(H)(Bpin)2(COE)] were also observed.49 This shows that even without
pinacolborane ArylOBpin species form under the reaction conditions. Thus, indicating that HBpin pregeneration of
ArylOBpin is unnecessary; however, it should be noted that an extra equivalent of boron is needed as the first borylaiton
will occur at the phenolic hydrogen. More pertinent to the original question, this data provides support that ArylOBeg
species form without HBeg addition because borylations with B2eg2 proceed through a similar trisboryl species,
[Ir(dtbpy)Beg3].
To conclusively determine if the ArylOBeg species forms and assess whether formation of B(OAryl)3 led to the low
conversions, we prepared 2-F-C6H4OBeg from 2-fluorophenol and ClBeg, according to Lappert’s procedure.50 The
resonance at δ 22.9 in the 11B{1H} NMR spectrum of the product is typical for B(OR)3 species. However, 11B NMR is not
well-suited for quantifying how many B(OR)3 species are present. In contrast, 19F is an s = ½ nucleus with a broad NMR
spectral window. As such, by employing a fluorinated phenol as our substrate we could use 19F NMR to determine the
number of B(OR)3 species.
In practice the 19F resonance (δ –132.6) in the 19F{1H} spectrum prepared by Lappert’s route was relatively broad (22
Hz at half-maximum) and low levels of impurities were observed. Given that Lappert’s synthesis eliminates HCl we were
concerned that these impurities could deactivate the CHB catalyst and/or catalyze detrimental side-reactions. Thus, we
sought an alternative means for generating ArylOBeg species.
Based on our previous result with the isolated trisboryl catalyst and the fact that iridium is known to readily form Ir–
Bgly species, we theorized that [Ir(cod)(OMe)]2 could catalyze the formation of ArylOBeg with B2eg2 and phenol.
Excitingly, full conversion to 2-FC6H4OBeg was achieved with 1 mol % [Ir(cod)(OMe)]2 and B2eg2.
With a facile route to ArylOBeg species, 4-FC6H4OBeg was generated and spectra were collected. To test if this
species is formed under the reaction conditions 4-fluorophenol was added to an NMR tube containing a toluene-d8 solution
of B2eg2, [Ir(OMe)(cod)]2, and dtbpy (Scheme 4). As judged by 19F NMR, this resulted in rapid, quantitative conversion to
4-F-C6H4OBeg at room temperature. Interestingly, the 11B NMR spectrum displayed a doublet at 28.9 ppm, but this
doublet collapsed in the 11B{1H} spectrum. This is consistent with generation of HBeg. Ultimately, these experiments
confirmed two key pieces of information: (i) ArylOBeg species are rapidly formed under the reaction conditions and (ii)
diborane does not consume phenol substrates as we had originally hypothesized. As B2eg3 (5) and B2H6, the
disproportionation products from HBeg, are not known to be active for CHB, we propose amine stabilized HBeg
participates in Ir-catalyzed borylation.
Scheme 4. NMR Tube Reaction Showing ArylOBeg Species
Although our experiments supported the role of triethylamine as an HBeg stabilizer, we recognize that the change in
conditions between Tables 1 and 2 may also affect the selectivities. As a control, the borylation of 4-fluorophenol with
B2pin2 as the boron source was carried out in toluene with and without triethylamine (Chart 3). In toluene without
triethylamine, the meta product was more pronounced (m/o = 97:3) than that observed in cyclohexane (m/o = 90:10).
Given that the addition of triethylamine actually pushed the reaction toward the meta product, the selectivities in Table
8
ACS Paragon Plus Environment

Page 9 of 11
Journal of the American Chemical Society
1
2
3
2 must solely be due to the change in the boron source and not a change in the conditions (i.e. solvent or additives).
4
5
6
7
Chart 3. Control Experiments with B2pin2
1.5 mol% [Ir(cod)(OMe)]2
OH
OH
3.0 mol% dtbpy, 1.5 equiv B2pin2
PhMe, X equiv Et3N, 80 oC, 2h
8
9
X
0
1.5
conversion
m/o
97/3
>99/1
Bpin
45
40
F
F
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
B2eg2 was critical to the high ortho selectivity as selectivities for some substrates in Table 2 with B2pin2 were poor. The
directing difference between Bpin and Beg is best illustrated by the selectivity for 4-fluorophenol where borylation with
B2pin2 gives a 9:1 ratio favoring borylation ortho to F, while B2eg2 gives exclusive borylation ortho to O (Scheme 5).
Theory predicts the same trend.
Scheme 5. Boron Reagent Effects on Borylation of 4-Fluorophenol
It is important to recognize that disentangling the directing effect of substituents on the phenols and the electrostatic
interactions proposed herein is challenging. However, the borylation of phenol itself is instructional as phenol bears no
other substituent to affect regiochemical outcomes, and it is a substrate where the calculated electrostatic interaction
should be maximized. Yet, borylation with B2eg2 provided only ortho borylated products (1q), whereas with B2pin2 a ratio
of 15:85 (o:m+p) was observed.
Finally, electrostatic interactions with delocalized π-systems are well established. In most examples the π-system
interacts with a positively charge partner.51 Nevertheless, anion interactions and electron deficient π-systems can be
stabilizing.21,52 Moreover, in neutral pyridine-2,6-dicarboxylic acid dimers, the interaction of the electron-rich carboxylic
acid group of one pyridine with the electron-deficient pyridine π-system of its partner, is stabilizing by -7.3 kcal·mol–1.53
This further supports our hypothesis that electrostatic interactions dictate the regioselectivity observed experimentally and
supported by computational studies.
Conclusions
To summarize, iridium-catalyzed ortho directed borylation of phenols using the most commonly employed
ligand/precatalyst combination dtbpy/[Ir(OMe)(cod)]2 is reported. After traceless protection of phenols with Bpin, CHB
ortho to OBpin occurred in a higher than expected portion. This phenomenon was explored in various phenol substrates
which showed the requirement for a substrate larger than fluorine in the 4-position for good ortho selectivity. To further
understand the origins of this ortho selectivity, we turned to calculations which revealed an electrostatic interaction
between the partially positive bipyridine ligand and partially negative OBpin in the substrate. Seeking experimental
evidence for this calculated interaction, electron rich through electron poor bipyridine ligands were used in the borylation
of phenol. Electron poor ligands produced higher ortho selectivity thus supporting the calculations; however, the electron
poor ligands provided low reactivity. Further study of the calculations suggested that a steric interaction from the methyl
groups on the OBpin species distorted the transition state geometries, but by changing to OBeg these geometries
significantly restored. Thus, borylations with B2eg2 were conducted and high ortho selectivity was achieved. Overall, by
simply changing the boron source high ortho selectivity was achieved which we attribute to a unique electrostatic
interaction between the bipyridine ligand and OBeg group. While the interactions revealed here are fortuitous, the
demonstration that they can be both sterically and electronically modulated augurs favorably for deploying them in
specifically designed catalysts. Efforts towards this end are underway in our laboratories.
ASSOCIATED CONTENT
Supporting Information Available: Full characterization, copies of all spectral data, experimental procedures, and coordinates
of computed transition states. This material is available free of charge via the Internet at http://pubs.acs.org.
9
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 10 of 11
1
2
3
4
5
AUTHOR INFORMATION
Corresponding Authors
maleczka@chemistry.msu.edu, singleton@mail.chem.tamu.edu, smithmil@msu.edu.
Notes
R.E.M. and M.R.S. acknowledge a financial interest in BoroPharm, Inc.
6
7
8
9
ACKNOWLEDGMENT
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
We thank the NIH (GM63188) and BoroPharm, Inc. for supplying B2pin2 and B2(OH)4.
REFERENCES
(1) Gutekunst, W. R.; Baran, P. S. Chem. Soc. Rev. 2011, 40 (4), 1976.
(2) Engle, K. M.; Mei, T.-S.; Wasa, M.; Yu, J.-Q. Acc. Chem. Res. 2012, 45 (6), 788.
(3) Li, G.; Wan, L.; Zhang, G.; Leow, D.; Spangler, J.; Yu, J.-Q. J. Am. Chem. Soc. 2015, 137 (13), 4391.
(4) Breslow, R.; Zhang, X.; Huang, Y. J. Am. Chem. Soc. 1997, 119 (19), 4535.
(5) Breslow, R.; Huang, Y.; Zhang, X.; Yang, J. Proc. Natl. Acad. Sci. U. S. A. 1997, 94 (21), 11156.
(6) Yang, J.; Breslow, R. Angew. Chem. Int. Ed. 2000, 39 (15), 2692.
(7) Yang, J.; Gabriele, B.; Belvedere, S.; Huang, Y.; Breslow, R. J. Org. Chem. 2002, 67 (15), 5057.
(8) Leung, D. H.; Bergman, R. G.; Raymond, K. N. J. Am. Chem. Soc. 2006, 128 (30), 9781.
(9) Brown, C. J.; Toste, F. D.; Bergman, R. G.; Raymond, K. N. Chem. Rev. 2015, 115 (9), 3012.
(10) Das, S.; Incarvito, C. D.; Crabtree, R. H.; Brudvig, G. W. Science 2006, 312 (5782), 1941.
(11) Das, S.; Brudvig, G. W.; Crabtree, R. H. J. Am. Chem. Soc. 2008, 130 (5), 1628.
(12) Dydio, P.; Reek, J. N. H. Chem. Sci. 2014, 5 (6), 2135.
(13) Davis, H. J.; Phipps, R. J. Chem. Sci. 2017, 8 (2), 864.
(14) Butts, C. P.; Filali, E.; Lloyd-Jones, G. C.; Norrby, P.-O.; Sale, D. A.; Schramm, Y. J. Am. Chem. Soc. 2009, 131 (29), 9945.
(15) Šmejkal, T.; Breit, B. Angew. Chem. Int. Ed. 2008, 47 (2), 311.
(16) Dydio, P.; Dzik, W. I.; Lutz, M.; de Bruin, B.; Reek, J. N. H. Angew. Chem. Int. Ed Engl. 2011, 50 (2), 396.
(17) Rummelt, S. M.; Fürstner, A. Angew. Chem. Int. Ed Engl. 2014, 53 (14), 3626.
(18) Rummelt, S. M.; Radkowski, K.; Roşca, D.-A.; Fürstner, A. J. Am. Chem. Soc. 2015, 137 (16), 5506.
(19) Zhao, Y.; Domoto, Y.; Orentas, E.; Beuchat, C.; Emery, D.; Mareda, J.; Sakai, N.; Matile, S. Angew. Chem. Int. Ed Engl. 2013, 52 (38),
9940.
(20) Zhao, Y.; Cotelle, Y.; Sakai, N.; Matile, S. J. Am. Chem. Soc. 2016, 138 (13), 4270.
(21) Giese, M.; Albrecht, M.; Rissanen, K. Chem. Commun. 2016, 52 (9), 1778.
(22) Wheeler, S. E.; Seguin, T. J.; Guan, Y.; Doney, A. C. Acc. Chem. Res. 2016, 49 (5), 1061.
(23) Persch, E.; Dumele, O.; Diederich, F. Angew. Chem. Int. Ed. 2015, 54 (11), 3290.
(24) Mkhalid, I. A. I.; Barnard, J. H.; Marder, T. B.; Murphy, J. M.; Hartwig, J. F. Chem. Rev. 2010, 110 (2), 890.
(25) Ros, A.; Fernández, R.; Lassaletta, J. M. Chem. Soc. Rev. 2014, 43 (10), 3229.
(26) Saito, Y.; Segawa, Y.; Itami, K. J. Am. Chem. Soc. 2015, 137 (15), 5193.
(27) Haines, B. E.; Saito, Y.; Segawa, Y.; Itami, K.; Musaev, D. G. ACS Catal. 2016, 6 (11), 7536.
(28) Kawamorita, S.; Ohmiya, H.; Hara, K.; Fukuoka, A.; Sawamura, M. J. Am. Chem. Soc. 2009, 131 (14), 5058.
(29) Ishiyama, T.; Isou, H.; Kikuchi, T.; Miyaura, N. Chem. Commun. 2010, 46 (1), 159.
(30) Ros, A.; Estepa, B.; López-Rodríguez, R.; Álvarez, E.; Fernández, R.; Lassaletta, J. M. Angew. Chem. Int. Ed. 2011, 50 (49), 11724.
(31) Ghaffari, B.; Preshlock, S. M.; Plattner, D. L.; Staples, R. J.; Maligres, P. E.; Krska, S. W.; Maleczka, R. E., Jr; Smith, M. R., 3rd. J. Am.
Chem. Soc. 2014, 136 (41), 14345.
(32) Wang, G.; Liu, L.; Wang, H.; Ding, Y.-S.; Zhou, J.; Mao, S.; Li, P. J. Am. Chem. Soc. 2017, 139 (1), 91.
(33) Boebel, T. A.; Hartwig, J. F. J. Am. Chem. Soc. 2008, 130 (24), 7534.
(34) Ghavtadze, N.; Melkonyan, F. S.; Gulevich, A. V.; Huang, C.; Gevorgyan, V. Nat. Chem. 2014, 6 (2), 122.
(35) Simmons, E. M.; Hartwig, J. F. Nature 2012, 483 (7387), 70.
(36) Roosen, P. C.; Kallepalli, V. A.; Chattopadhyay, B.; Singleton, D. A.; Maleczka, R. E.; Smith, M. R. J. Am. Chem. Soc. 2012, 134 (28),
11350.
(37) Preshlock, S. M.; Plattner, D. L.; Maligres, P. E.; Krska, S. W.; Maleczka, R. E.; Smith, M. R. Angew. Chem. Int. Ed. 2013, 52 (49), 12915.
(38) Bisht, R.; Chattopadhyay, B. J. Am. Chem. Soc. 2016, 138 (1), 84.
(39) Kuninobu, Y.; Ida, H.; Nishi, M.; Kanai, M. Nat. Chem. 2015, 7 (9), 712.
(40) Davis, H. J.; Mihai, M. T.; Phipps, R. J. J. Am. Chem. Soc. 2016, 138 (39), 12759.
(41) Li, H. L.; Kuninobu, Y.; Kanai, M. Angew. Chem. Int. Ed Engl. 2017, 56 (6), 1495.
(42) Ishiyama, T.; Takagi, J.; Hartwig, J. F.; Miyaura, N. Angew. Chem. Int. Ed. 2002, 41 (16), 3056.
(43) Chotana, G. A.; Rak, M. A.; Smith, M. R. J. Am. Chem. Soc. 2005, 127 (30), 10539.
(44) Yamazaki, K.; Kawamorita, S.; Ohmiya, H.; Sawamura, M. Org. Lett. 2010, 12 (18), 3978.
(45) Cox, P. A.; Leach, A. G.; Campbell, A. D.; Lloyd-Jones, G. C. J. Am. Chem. Soc. 2016, 138 (29), 9145.
(46) Rose, S. H.; Shore, S. G. Inorg. Chem. 1962, 1 (4), 744.
(47) McAchran, G. E.; Shore, S. G. Inorg. Chem. 1966, 5 (11), 2044.
(48) Shore, S. G.; Crist, J. L.; Lockman, B.; Long, J. R.; Coon, A. D. J. Chem. Soc. Dalton Trans. 1972, No. 11, 1123.
(49) Boller, T. M.; Murphy, J. M.; Hapke, M.; Ishiyama, T.; Miyaura, N.; Hartwig, J. F. J. Am. Chem. Soc. 2005, 127 (41), 14263.
(50) Blau, J. A.; Gerrard, W.; Lappert, M. F. J. Chem. Soc. 1957.
(51) Salonen, L. M.; Ellermann, M.; Diederich, F. Angew. Chem. Int. Ed Engl. 2011, 50 (21), 4808.
(52) Gamez, P.; Mooibroek, T. J.; Teat, S. J.; Reedijk, J. Acc. Chem. Res. 2007, 40 (6), 435.
(53) Mirzaei, M.; Eshtiagh-Hosseini, H.; Karrabi, Z.; Molčanov, K.; Eydizadeh, E.; Mague, J. T.; Bauzá, A.; Frontera, A. CrystEngComm 2014,
10
ACS Paragon Plus Environment

Page 11 of 11
Journal of the American Chemical Society
1
2
3
16 (24), 5352.
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
11
ACS Paragon Plus Environment
