Unusual Photorearrangement of 1,7-Disubstituted
7-Azabenzonorbornadiene*
A. Altundaşa, E. Tepeb, N. Akbulutb, and Y. Karab
a Department of Chemistry, Faculty of Arts and Sciences, Gazi University, Ankara, 06500 Turkey
e-mail: aaltundas@gazi.edu.tr
b Department of Chemistry, Faculty of Arts and Sciences, Atatürk University, Erzurum, 25240 Turkey
Received December 5, 2007
Abstract—1-(11-Benzoyl-11-azatricyclo[6.2.1.02,7]undeca-2,4,6,9-tetraen-1-yl)ethanone was synthesized by
cycloaddition of 2-acetyl-N-benzoylpyrrole to benzyne. Direct photolysis of 1-(11-benzoyl-11-azatricyclo-
[6.2.1.02,7]undeca-2,4,6,9-tetraen-1-yl)ethanone in benzene gave N-(4-acetylnaphthalen-1-yl)benzamide. The
formation of this product is discussed in terms of radical-stabilizing and destabilizing effect of electron-with-
drawing group in the formation of cyclopropane ring.
DOI: 10.1134/S107042800904023X
Fusion of benzene ring to cyclic hydrocarbons was
widely reported in the literature [1–3]. The most
general method for the preparation of such compounds
involves cycloaddition of benzyne to appropriate con-
jugated dienes [4]. Benzyne is known to readily react
with pyrrole derivatives to form 1,4-epimino-1,4-dihy-
dronaphthalene (I, 7-azabenzonorbornadiene) [5, 6].
1,4-Epimino-1,4-dihydronaphthalene (I) attracts much
interest from the synthetic viewpoint due to its ability
to be readily converted into other types of compounds.
For example, Wolthuis et al. [6] studied reactions of
1,4-epimino-1,4-dihydronaphthalene with HCl in
MeOH and showed formation of different naphthalene
derivatives. It is also known that direct photolysis
of 1,4-epimino-1,4-dihydronaphthalenes I produces
3-benzoazepines II [7–9] (Scheme 1). Benzoazepines
and related compounds were found to exhibit impor-
tant pharmacological properties [10].
formation of benzofulvene derivatives via sensitized
irradiation of 7-azabenzonorbornadienes. Motyka [11]
described the conversion of 1,4-epimino-1,4-dihydro-
naphthalene having electron-donating substituents on
the nitrogen atom into indole derivatives by direct
photolysis. The configuration of the nitrogen atom in
7-azabenzonorbornadiene derivatives can be deter-
mined by spectral methods [12, 13]. We previously
studied photochemistry of bicyclic systems having het-
eroatoms and revealed very surprising results [14, 15];
it seemed interesting to examine photochemistry of aza
bicyclic compounds bearing electron-withdrawing sub-
stituents.
In the present article we report on the photolysis
of 7-azabenzonorbornadiene containing two electron-
withdrawing groups, one on the nitrogen atom, and the
other on the bridgehead carbon atom (C1). The sub-
strate structure differed from those reported in [7–9].
Our synthetic strategy was based on the Diels–Alder
reaction of benzyne with 2-acetyl-N-benzoylpyrrole
Scheme 1.
R
N
hν
Scheme 2.
N
R
O
O
Ph
, C2H4Cl2
I
II
N
N
Ph
Swenton et al. [9] reported the details of direct and
photosensitized rearrangements of 7-azabenzonorbor-
nadiene derivatives and proposed a mechanism for the
O
Me
O
Me
* The text was submitted by the authors in English.
III
IV
613

ALTUNDAŞ et al.
614
of 3-benzoazepine VIII, direct photolysis of 1,4-epi-
mino-1,4-dihydronaphthalene IV was performed at
λ 254 nm. Repeated experiments surprisingly showed
the formation of benzamide derivative VI. The product
differed from those obtained by Prinzbach [8] and
Swenton [9]. This can be attributed to the effect of
electron-withdrawing acetyl group at the bridgehead
carbon atom (C1). In keeping with published data,
electron-withdrawing groups destabilize formation of
cyclopropane ring [18]. As shown in Scheme 5, the
transformation of IV through di-π-methane rearrange-
ment or intramolecular [2+2] cycloaddition would
give product VII. Because of destabilizing effect of the
acetyl group, cyclopropane ring is not formed, and the
reaction does not follow path b. Instead, diradical A
undergoes rearrangement into more stable diradical B.
The subsequent hydrogen transfer to the nitrogen atom
from the adjacent carbon atom leads to product VI
through intermediate C (Scheme 5, path a).
(III) which was prepared according to the procedure
reported previously for analogous compounds [16].
New 1,4-epiminonaphthalene derivative (IV) was thus
obtained in 53% yield. Its NMR data indicated that it
exists as a single isomer (Scheme 2). The configura-
tion of IV was determined by further chemical reac-
tions and X-ray analysis of epoxide V. The latter was
synthesized by oxidation of 1-acetyl-N-benzoyl-1,4-
epiminonaphthalene (IV) with m-chloroperoxybenzoic
acid in methylene chloride; according to the X-ray dif-
fraction data, compound V has exo orientation of the
epoxy group [17] (Scheme 3).
Scheme 3.
O
O
Ph
Ph
O
3-ClC6H4CO3H
CH2Cl2
N
N
O
O
Thus we have demonstrated unusual rearrange-
ment of 1,4-epimino-1,4-dihydronaphthalene IV to
N-(4-acetylnaphthalen-1-yl)benzamide (VI) under con-
ditions of direct photolysis. Benzamide derivatives
exhibit various kinds of biological activity such as
antihelminthic, antihistaminic, antifungal, and antibac-
terial properties [19]. We presume that this unexpected
rearrangement takes place because of electron-with-
drawing nature of the carbonyl group at the bridgehead
position, which destabilizes cyclopropane ring. Our
results showed that benzamide derivatives can be syn-
thesized via photochemical transformations which
tolerate several functional groups.
Me
IV
Me
V
A solution of 1,4-epimino-1,4-dihydronaphthalene
IV (0.5 g, 1.73 mmol) in benzene (100 ml) was irra-
diated under nitrogen for 30 h in a quartz tube using
a mercury lamp (λ 240 nm). By thin-layer chromatog-
raphy we isolated N-(4-acetylnaphthalen-1-yl)benz-
amide (VI) in 30% yield (0.15 g, 0.52 mmol), as well
as 55% of unreacted starting compound (Scheme 4).
The structure of VI was determined on the basis of the
1H and C NMR spectra. In the H NMR spectrum of
VI, methyl protons in the acetyl group resonated at
δ 2.69 ppm, and aromatic proton signals appeared in
the region δ 7.27–8.87 ppm. Double resonance experi-
13
1
EXPERIMENTAL
13
ments and C NMR spectrum were also fully consist-
The melting points were determined on a Thomas
Hoover capillary melting apparatus. The IR spectra
were measured in KBr or from neat liquids on a Matt-
ent with the assumed structure.
Scheme 4.
1
son 1000 FT-IR spectrometer. The H and 13C NMR
O
spectra were recorded on a Varian spectrometer at 200
and 50 MHz, respectively. The mass spectra were ob-
tained on a VG Zabspec GC–MS instrument. Column
chromatography was performed on silica gel 60 (70–
230 mesh ATSM). Silica gel 60 F254 on 0.2-mm ana-
lytical aluminum plates (Merck) was used for thin-
layer chromatography.
NHCOPh
Ph
N
hν, PhH
O
COMe
VI
Me
IV
1-(1-Benzoylpyrrol-2-yl)ethanone (III) [16].
A mixture of 1.74 g (22 mmol) of acetyl chloride and
2.1 g (22 mmol) of anhydrous aluminum chloride in
70 ml of 1,2-dichloroethane was stirred for 15 min at
30°C, a solution of 3.44 g (22 mmol) of 1-benzoyl-
1,4-Epimino-1,4-dihydronaphthalenes bearing elec-
tron-withdrawing substituents on the nitrogen atom
were reported to undergo isomerization to benzoazep-
ines upon direct irradiation. Expecting the formation
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 45 No. 4 2009

UNUSUAL PHOTOREARRANGEMENT OF 1,7-DISUBSTITUTED 7-AZABENZO...
615
Scheme 5.
O
O
O
·
N
Ph
HN
Ph
H
Ph
N
·
hν
·
·
VI
·
Path a
·
O
Me
Me
O
Me
O
A
B
C
IV
O
Ph
O
N
hν
N
Ph
Path b
[2+2]
O
O
Me
VII
Me
D
pyrrole in 10 ml of dichloroethane was added, and the
mixture was stirred for 5 h at 30°C. The mixture was
cooled to 0°C, quenched with cold water, and extract-
ed with methylene chloride. The organic layer was
separated, washed with water (2×100 ml), and dried
over Na2SO4. The solvent was removed, and the
residue was purified by chromatography on silica gel
using hexane–ethyl acetate (9:1) as eluent. The prod-
uct was additionally recrystallized from diethyl ether–
hexane. Yield 3.10 g (70%), colorless crystals, mp 65–
66°C. IR spectrum (KBr), ν, cm–1: 3113, 3080, 2936,
2953, 2876, 1727, 1676, 1600, 1548, 1446, 1421, 1344,
raphy on silica gel using hexane–ethyl acetate (9:1) as
eluent. The product was additionally recrystallized
from diethyl ether–hexane. Yield 2.30 g (53%), color-
less crystals, mp 135–136°C. IR spectrum (KBr), ν,
cm–1: 3438, 3310, 3106, 3080, 3029, 2927, 1727, 1676,
1600, 1472, 1370, 1344, 1268, 1242, 1140, 1114,
1
1063, 961. H NMR spectrum (CDCl3), δ, ppm: 7.66–
7.26 m (8H, Harom), 7.09–7.04 quasi d.d (2H, 10-H,
H
arom, J = 5.5, 1.2 Hz), 6.25 d.d (1H, 9-H, J = 5.5,
2.2 Hz), 5.66 d (1H, 8-H, J = 2.2 Hz), 2.41 s (3H,
13
CH3). C NMR spectrum (CDCl3), δC, ppm: 201.32,
172.76, 148.04, 147.17, 144.58, 142.22, 133.67, 132.28,
128.93, 128.72, 126.00, 125.97, 121.07, 120.82, 82.91
(C1), 70.65 (C8), 29.99. High-resolution mass spec-
trum: m/z 289.1111 [M]+. Calculated: M 289.1102.
1
1319, 1268, 1217, 1191, 1089, 1038, 936. H NMR
spectrum (CDCl3), δ, ppm: 7.86 d.d (1H, 5-H, J = 2.0,
1.6 Hz), 7.77–7.60 m (5H, Ph), 7.27 d.d (1H, 3-H,
J = 3.4, 1.6 Hz), 7.27 d.d (1H, 4-H, J = 3.4, 2.0 Hz).
13C NMR spectrum (CDCl3), δC, ppm: 189.03, 171.31,
135.68 (2C), 135.56, 131.61, 130.81, 130.59, 123.03,
112.59, 28.34.
1-(11-Benzoyl-11-azatricyclo[6.2.1.02,7]undeca-
2,4,6,9-tetraen-1-yl)ethanone (IV) was prepared by
reaction of benzyne [20] with pyrrole III. 2-Carboxy-
benzenediazonium hydrochloride, 2.60 g (17 mmol),
and 2-methyloxirane, 1.7 g (40 mmol), were added
under stirring to a solution of 3.10 g (15.00 mmol) of
compound III in 70 ml of dichloroethane. The mixture
was heated for 3.5 h under reflux, cooled to room
temperature, and evaporated. The residue was treated
with 100 ml of diethyl ether, and the extract was
washed with 10% aqueous NaHCO3 (2×100 ml) and
water (100 ml) and dried over Na2SO4. After removal
of the solvent, the residue was subjected to chromatog-
Epoxidation of 1-(11-benzoyl-11-azatricyclo-
[6.2.1.02,7]undeca-2,4,6,9-tetraen-1-yl)ethanone (IV)
[17]. A solution of 0.5 g (1.74 mmol) of compound IV
and 0.36 g (2.09 mmol) of m-chloroperoxybenzoic
acid in 30 ml of methylene chloride was stirred for
20 h at room temperature in the presence of 1 g of
solid NaHCO3. The mixture was then filtered and
washed with 10% aqueous NaHCO3 (2×20 ml). The
organic layer was dried over sodium sulfate and evap-
orated under reduced pressure, and the residue was
recrystallized from methylene chloride–hexane to
obtain 0.48 g (78%) of 1-(11-benzoyl-9,10-epoxy-11-
azatricyclo[6.2.1.02,7]undeca-2,4,6-trien-1-yl)ethanone
(V) as colorless crystals with mp 208–209°C. IR spec-
trum (KBr), ν, cm–1: 3027, 2931, 2858, 1708, 1631,
1581, 1457, 1427, 1373, 1276, 1130, 1064, 1025, 944,
1
887, 848, 755,698. H NMR spectrum (CDCl3), δ,
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 45 No. 4 2009

ALTUNDAŞ et al.
616
3. Paquette, L.A., Kukla, M.J., and Stowell, J.C., J. Am.
Chem. Soc., 1972, vol. 94, p. 4920.
4. Moody, C.J. and Whitham, G.H., Reactive Inter-
mediates, Oxford; Oxford Univ., 1997, p. 81.
ppm: 7.68–7.12 m (9H, Harom), 5.09 s (1H, 8-H), 3.97 d
and 3.39 d (1H each, 9-H, 10-H, J = 3.5 Hz), 2.42 s
(3H, CH3). 13C NMR spectrum (CDCl3), δC, ppm:
201.20, 175.78, 145.79, 145.33, 136.07, 132.97, 130.47,
130.16, 129.64, 129.57, 123.49, 123.02, 82.11 (C1),
67.91 (C8), 58.54, 54.52, 29.77.
5. Wolthuis, E. and De Boer, A., J. Org. Chem., 1965,
vol. 30, p. 3225.
6. Wolthuis, E., Cady, W., Roon, R., and Weidenaar, B.,
J. Org. Chem., 1966, vol. 31, p. 2009.
7. Carpino, L.A. and Barr, D.E., J. Org. Chem., 1966,
vol. 31, p. 764.
8. Kaupp, G., Perreten, J., Leute, H., and Prinzbach, H.,
N-(4-Acetylnaphthalen-1-yl)benzamide (VI).
A solution of 0.50 g (1.73 mmol) of compound IV in
100 ml of benzene was placed into a quartz tube,
flushed with nitrogen under stirring with a magnetic
stirrer, and irradiated at λ 254 nm for 30 h. The solvent
was removed under reduced pressure, and the residue
was purified by thin-layer chromatography on silica
gel using hexane–ethyl acetate (4:1) as eluent. The
product was recrystallized from methylene chloride–
hexane. Yield 0.15 g (30%), yellow crystals, mp 156–
158°C. IR spectrum (KBr), ν, cm–1: 3285, 3080, 3004,
2927, 2851, 1702, 1651, 1600, 1523, 1497, 1446, 1370,
1293, 1242, 1191, 1114, 1012, 910. 1H NMR spectrum
(CDCl3), δ, ppm: 8.87 br.d (1H, 5-H, J = 8.1 Hz),
8.61 br.s (1H, NH), 8.10 (1H, 3-H) and 7.85 (1H, 2-H)
(AB system, J = 8.1 Hz), 7.97 d (2H, o-H, J = 7.4 Hz),
7.84 d (1H, 8-H, J = 8.6 Hz), 7.58-7.27 m (5H, 6-H,
Chem. Ber., 1970, vol. 103, p. 2288.
9. Swenton, J.S., Oberdier, J., and Rosso, P.D., J. Org.
Chem., 1974, vol. 39, p. 1038.
10. Cordero-Vargas, A., Quiclet-Sire, B., and Zard, S.Z.,
Bioorg. Med. Chem., 2006, vol. 14, p. 6165 (see also
references cited therein).
11. Motyka, L.A., Tetrahedron Lett., 1985, vol. 26, p. 2827.
12. Quin, L.D., Caster, K.C., Marsi, B.G., and Miller, J.A.,
J. Org. Chem., 1986, vol. 51, p. 3724.
13. Davies, J.W., Durrant, M.L., Walker, M.P., Belka-
cemi, D., and Malpass, J.R., Tetrahedron, 1992, vol. 48,
p. 861.
14. Altundaş, A., Kara, Y., Seçen, H., and Akbulut, N.,
J. Chem. Res., 2002, p. 361.
15. Kurbanoglu, N.I., Kara, Y., Seçen, H., and Akbulut, N.,
J. Chem. Res., Synop., 1997, p. 384.
16. Kakushima, M., Hamel, P., Frenette, R., and Rokach, J.,
13
7-H, m-H, p-H), 2.69 s (3H, CH3). C NMR spectrum
(CDCl3), δC, ppm: 201.77, 167.39, 138.56, 136.67,
133.99, 133.77, 133.26, 131.55, 130.78, 129.82, 129.4,
129.28, 128.49, 121.93, 119.72, 31.52. High-resolution
mass spectrum: m/z 289.1098 [M]+. Calculated:
M 289.1102.
J. Org. Chem., 1983, vol. 48, p. 3214.
17. Öztürk, S., Akkurt, M., Tepe, E., Heinemann, F.W.,
Altundaş, A., and Kara, Y., Acta Crystallogr., Sect. E,
2003, vol. 59, p. o635.
The authors thank Atatürk University for financial
support of this work. We also thank Dr. R. Altundaş
and Dr. H. Seçen (Atatürk University) for helpful dis-
cussion and critical reading of the manuscript.
18. Altundaş, R., Dastan, A., Ünaldi, N.S., Güven, K.,
Uzun, O., and Balci, M., Eur. J. Org. Chem., 2002,
p. 526.
REFERENCES
19. Ertan, T., Yildiz, I., Ozkan, S., Temiz-Arpaci, O., Kay-
nak, F., Yalcin, I., Aki-Sener, E., and Abbasoglu, U.,
Bioorg. Med. Chem., 2007, vol. 15, p. 2032 (see also
references cited therein).
1. Kessar, S.V., Acc. Chem. Res., 1978, vol. 11, p. 283.
2. Bryce, M.R. and Vernon, M., Advances in Heterocyclic
Chemistry, Katritzky, A.R., Ed., New York: Academic,
1981, vol. 28, p. 183.
20. Ziegler, G.R., J. Am. Chem. Soc., 1969, vol. 91, p. 446.
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 45 No. 4 2009
