COMMUNICATIONS
DOI: 10.1002/adsc.200800032
Palladium-Catalyzed Stille Cross-CouplingReaction of Aryl
Chlorides usinga Pre-Milled Palladium Acetate and XPhos
Catalyst System
John R. Nabera and Stephen L. Buchwalda,*
a
Department of Chemistry, Massachusetts Institute of Technology, Cambridge, Massachusetts, 02139, USA
Fax : (+1)-617-253-3297; e-mail: sbuchwal@mit.edu
Received: January 16, 2008; Revised: February 14, 2008; Published online: March 12, 2008
This paper is dedicated to our good friend Andreas Pfaltz on the occasion of his 60th birthday and in recogni-
tion of his numerous seminal contributions to the field of organic chemistry.
Supporting information for this article is available on the WWW under http://asc.wiley-vch.de/home/.
Abstract: A highly active catalyst system based
upon a biaryl monophosphine ligand, XPhos, for
the palladium-catalyzed Stille reaction has been de-
veloped. This method allows for the coupling of
aryl chlorides with a range of tributylarylstannanes
to produce the corresponding biaryl compounds in
good to excellent yields (61–98%) in short reaction
sures its continued relevance, particularly as a tool for
discovery chemists[5] and in natural product synthe-
sis.[6] Herein, we describe a highly active catalyst
system for the coupling of aryl chlorides with aryl-
stannanes.
A family of air-stable biaryl monophosphine ligands
has been developed in our laboratories and have
proven useful as components of highly active catalyst
times (4 h). Palladium(II) acetate [Pd(OAc)2] and
A
À
À
XPhos in a 1:1.1 ratio were milled into a fine
powder that was used as pre-catalyst for these reac-
tions.
systems for C C and C N bond-forming reac-
tions.[3b,c,7] Based on previous work in our group and
initial screening results, XPhos (Figure 1) was chosen
as a supporting ligand and was combined with Pd-
À
Keywords: aryl chlorides; biaryls; C C coupling;
(OAc)2 to generate a highly active catalyst system
that was used for further optimization.
palladium; phosphine ligands; Stille reaction
Recent work has shown that the addition of a
fluoride source increases the reactivity of arylstan-
nanes and results in a significant rate enhancemen-
t.[4a–c,f–h] While the use of TBAF and KF provided
The Stille cross-coupling reaction has proven to be a moderate results, CsF provided the greatest enhance-
powerful method for combining aryl halides and ment in the reaction rate (Table 1, entries 1–4). A fur-
arylstannanes to give a ready access to biaryl motifs,[1] ther optimization showed that reactions in ethereal
which are found in numerous biologically active com- solvents or tert-butanol provided the desired biaryl in
pounds including both natural products and pharma- a greater yield. Dimethoxyethane (DME) was chosen
ceutically interesting molecules.[2] Recent advances in over tert-butanol as the solvent for further studies due
the general area of cross-coupling have led to the de- to the high melting point of tert-butanol. We found
velopment of highly active catalyst systems that were that very similar results were obtained with ligand:Pd
capable of transforming aryl chlorides, which are less ratios of 1:1, 2:1 and 3:1, thus reactions were conduct-
expensive and more readily available than aryl io-
dides and bromides.[1f] While considerable research
has been devoted to the Suzuki–Miyaura reaction,[1f,3]
there have been fewer reports of catalytic methods
for the reaction of aryl chlorides with organostan-
nanes.[4] Although the tin by-products generated in
the Stille reaction tend to have relatively high molec-
ular weights and are toxic, the air- and moisture-sta-
bility of organostannanes combined with the broad
functional group tolerance of the Stille reaction en- Figure 1.
Adv. Synth. Catal. 2008, 350, 957 – 961
ꢀ 2008 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
957

John R. Naber et al.
COMMUNICATIONS
Table 1. Screen of solvents for the palladium-catalyzed
Table 2. Stille cross-coupling reactions of unactivated aryl
cross-coupling of 4-chloroanisole and mesitylstannane.[a]
chlorides and deactivated chlorides.[a]
[a]
Reaction conditions: 1.0 equiv of Ar-Cl, 1.1 equiv of (n-
Bu)3Sn-Ar, 1.0 mol% of Pd(OAc)2, 3.0 mol% of XPhos,
G
1.0 mL of solvent/mmol of Ar-Cl, DCE=1,2-dichloro-
ethane, NMP=N-methylpyrrolidine, DME=dimethoxy-
ethane, DEM=diethoxymethane.
[b]
GC Yield.
ed with only a slight excess of ligand (1.1:1, L:Pd). A
mixture of palladium acetate and XPhos, in the afore-
mentioned ratio, was milled with a mortar and pestle
to give a fine, beige powder that was used in subse-
quent reactions. The milling process allowed for ex-
cellent control of the palladium to ligand ratio and fa-
cilitated precision when weighing samples for reac-
tions. The results of reaction run with the powder
were identical to those performed with separate Pd-
[a]
Reactions conditions: 1.0 equiv of Ar-Cl, 1.1 equiv of (n-
Bu)3Sn-Ar, 2.2 equiv of CsF, 1.0 mol% of pre-milled Pd-
A
[b]
[c]
[d]
Isolated yields (average of two runs).
2.0 mol% of pre-milled Pd(OAc)2:XPhos (1:1.1)
(OAc)2 and 1.1 mol% XPhos added as sepa-
AHCTREUNG
1.0 mol% Pd
rate solids.
ACHTREUNG
A
powder could be stored in a benchtop dessicator with
no loss of activity over a six-month period.
Encouraged by these results, we sought to examine chlorobenzo[d][1,3]dioxole (Table 2, entries 3 and 4),
G
the scope of this process. The results are shown in could be coupled in excellent yields with both aryl-
Table 2. These conditions constitute the lowest and heteroarylstannanes. Previously, this substrate has
temperature reactions and shortest reaction times re- been used in the Stille reaction to form a biaryl in
ported for the coupling of unactivated aryl chlorides only one other instance in which longer reaction
with arylstannanes reported to date. Chloroanilines, times and higher temperatures (45 h and 1108C) were
as a class of compounds, have not previously been required.[4h]
used to generate biaryl compounds via the Stille reac-
While the results in Table 3 do not represent the
tion.[8] One example of this class of compounds, N,N- lowest temperature reaction conditions reported for
dimethyl-3-chloroaniline, using our conditions, was Stille reactions with activated aryl chlorides,[9] they do
successfully coupled with a both aryl- and heteroaryl- represent a significant decrease over most of the reac-
stannanes (Table 2, entries 5 and 6). Similarly, while tion times reported and one of lowest operating tem-
4-chloroanisole has been combined with arylstan- peratures of available Stille methods with these sub-
nanes, the best reported conditions required that the strates. For instance, the coupling 2-chlorobenzonitrile
reactions be conducted at 1008C for 48 h.[4a,c] Employ- has been previously reported at temperatures greater
ing our catalyst system this substrate, in combination than 1008C with reaction times longer than 24 h.[4h,10]
with both a hindered arylstannane and a heteroaryl- By using our standard protocol, 2-chlorobenzonitrile
stannane, provided excellent yields of product in 4 h was efficiently coupled with aryl, heteroaryl and elec-
at 808C (Table 2, entries 1 and 2). Additionally, 5- tron-rich arylstannanes (Table 3, entries 1–3). En-
958
asc.wiley-vch.de
ꢀ 2008 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Adv. Synth. Catal. 2008, 350, 957 – 961

Palladium-Catalyzed Stille Cross-Coupling Reaction of Aryl Chlorides
COMMUNICATIONS
Table 3. Stille cross-coupling reactions of aryl chlorides and
tries 4–7 of Table 3 show coupling reactions with
methyl 4-chlorobenzoate and a variety of stannanes
including allyl, heteroaryl and sterically-demanding
arylstannanes. While the importance of fluorinated ar-
omatic rings in pharmaceutically active compounds as
a means to alter a molecule’s pharmacokinetics is well
known,[11] examples of Stille reactions of fluoride-con-
taining aryl chlorides are relatively scarce. In the lone
example of coupling an aryl chloride with an ortho-
trifluoromethyl group, the process was carried out at
for 48 h at 1508C;[12] only one example was found for
a Stille coupling of fluorinated aryl chlorides.[13] By
using our conditions, both o-chlorobenzotrifluoride
and p-fluorochlorobenzene could be efficiently cou-
pled with arylstannanes (Table 3, entries 8 and 9). Ad-
ditionally, we found that by increasing the reaction
temperature to 1008C and choosing 1,4-dioxane as a
solvent to accommodate the increased temperature, it
was possible to couple heteroaryl chlorides (Table 3,
heteroaryl chlorides.[a]
entries 10 and 11) with tributyl
(phenyl)stannane.[14]
A
With regard to the arylstannane component: heter-
oaryl (Table 2, entries 1 and 3, Table 3, entries 2, 4
and 6), electron-rich aryl (Table 3, entries 3 and 9),
electron-deficient aryl (Table 2, entry 6) and allylstan-
nanes (Table 3, entry 5) were all coupled in high
yields. It is noteworthy to mention that 2,6-
dimethoxyphenyltributylstannane, which has not pre-
G
viously been used in Stille cross-coupling reactions,[15]
was found to perform well under our conditions
(Table 3, entries 3 and 9).
In conclusion, we have developed a highly active
catalyst system for the reaction of a diverse range of
aryl chlorides with a variety of arylstannanes. The use
of CsF as an activator allows for a reduction of the
temperatures commonly used in Stille reactions, and
the use of ethereal solvents such as DME along with
XPhos as a ligand allow for the reduction of the reac-
tion times regularly used in these reactions.
Experimental Section
Catalyst System
Palladium acetate (225 mg, 1.00 mmol) and XPhos (524 mg,
1.10 mmol) were ground together using a mortar and pestle
until a fine beige powder was formed. This powder (effec-
tive molecular weight: 749 gmolÀ1) was stored in a bench-
top dessicator for up to six months with no loss of activity
and was used as the pre-catalyst for all reactions described
in this paper.
[a]
Reactions conditions: 1.0 equiv of Ar-Cl, 1.1 equiv of (n-
Bu)3Sn-Ar, 2.2 equiv of CsF, 1.0 mol% of pre-milled Pd-
A
[b]
[c]
[d]
Isolated yields (average of two runs).
2.0 mol% of pre-milled Pd(OAc)2:XPhos (1:1.1).
Reactions run in dioxane at 1008C, with 2.0 mol% pre-
milled Pd(OAc)2:XPhos (1:3).
N,N-Dimethyl-2’-(trifluoromethyl)biphenyl-3-amine
(Table 2, entry 5)
Pre-milled palladium acetate and XPhos (15.0 mg, 2.0
mol%) and cesium fluoride (334 mg, 2.20 mmol) were added
to an oven-dried test tube. The tube was fitted with a rubber
Adv. Synth. Catal. 2008, 350, 957 – 961
ꢀ 2008 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
asc.wiley-vch.de
959

John R. Naber et al.
COMMUNICATIONS
septum, sealed with electrical tape, and evacuated and back-
filled with argon (this process was repeated a total of 3
times). Dimethoxyethane (DME, 1.0 mL), 3-chloro-N,N-di-
methylaniline (137 mL, 1.00 mmol) and tributyl[2-(trifluoro-
methyl)phenyl]stannane (389 mL, 1.10 mmol) were added
via syringe to the tube. The reaction was heated to 808C
with stirring for 4 h. At this time the reaction vessel was re-
moved from the oil bath, allowed to cool to room tempera-
ture, diluted with ethyl acetate (5 mL) and filtered through
a pad of silica gel eluting with ethyl acetate (150 mL). The
solvent was removed with the aid of a rotary evaporator,
and the residue was taken up in dichloromethane (20 mL)
and added to silica gel (~1 g). The solvent was concentrated
under reduced pressure and the residue (adsorbed on silica)
was loaded onto the top of a Biotage 25M column and puri-
fied by flash chromatography using a Biotage SP4 to pro-
vide the titled compound as pale yellow oil; yield: 229 mg
(87%).
Org. Biomol. Chem. 2006, 4, 3197–3210; i) T. C. Rob-
erts, P. A. Smith, R. T. Cirz, R. E. Romesberg, J. Am.
Chem. Soc. 2007, 129, 15830–15838.
[3] a) O. Navarro, R. A. Kelly, S. P. Nolan, J. Am. Chem.
Soc. 2003, 125, 16194–16195; b) S. D. Walker, T. E.
Barder, J. R. Martinelli, S. L. Buchwald, Angew. Chem.
2004, 116, 1907–1912; Angew. Chem. Int. Ed. 2004, 43,
1871–1876; c) T. E. Barder, S. D. Walker, J. R. Marti-
nelli, S. L. Buchwald, J. Am. Chem. Soc. 2005, 127,
4685–4696; d) N. Marion, O. Navarro, J. Mei, E. D.
Stevens, N. M. Scott, S. P. Nolan, J. Am. Chem. Soc.
2006, 128, 4101–4111.
[4] a) A. F. Littke, G. C. Fu, Angew. Chem. 1999, 111,
2568–2570; Angew. Chem. Int. Ed. 1999, 38, 2411–
2413; b) G. A. Grasa, S. P. Nolan, Org. Lett. 2001, 3,
119–122; c) A. F. Littke, G. C. Fu, J. Am. Chem. Soc.
2002, 124, 6343–6348; d) R. B. Bedford, S. L. Hazel-
wood, Chem. Commun. 2002, 2608–2609; e) R. B. Bed-
ford, S. L. Hazelwood, M. E. Limmert, D. A. Albisson,
S. M. Draper, P. N. Scully, S. J. Coles, M. B. Hursthouse,
Chem. Eur. J. 2003, 9, 3216–3227; f) S. P. H. Mee, V.
Lee, J. E. Baldwin, Angew. Chem. 2004, 116, 1152–
1156; Angew. Chem. Int. Ed. 2004, 43, 1132–1136;
g) W. Su, S. Urgaonkar, J. G. Verkade, Org. Lett. 2004,
6, 1421–1424; h) W. Su, S. Urgaonkar, P. A. McLaugh-
lin, J. G. Verkade, J. Am. Chem. Soc. 2004, 126, 16433–
16439; i) V. Calo, A. Nacci, A. Monopoli, F. Montigelli,
J. Org. Chem. 2005, 70, 6040–6044; j) M. L. Kantam, S.
Roy, M. Roy, B. Sreedhar, B. M. Choudary, Adv. Synth.
Catal. 2005, 347, 2002–2008; k) S. P. H. Mee, V. Lee,
J. E. Baldwin, Chem. Eur. J. 2005, 11, 3294–3308.
[5] For a selection of recent applications of the Stille reac-
tion in drug discovery, see: a) D. Amans, V. Bellosta, J.
Cossy, Org. Lett. 2007, 9, 4761–4764; b) M. D. Cullen,
B. L. Deng, T. L. Hartman, K. M. Watson, R. W. Buck-
heit, C. Pannecouque, E. DeClercq, M. Cushman, J.
Med. Chem. 2007, 50, 4854–4867; c) V. Uchil, B. Seo,
V. Nair, J. Org. Chem. 2007, 72, 8577–8579.
[6] For a selection of recent applications of the Stille reac-
tion in natural product synthesis, see: a) S. Lopez, J.
Montenegro, C. Saa, J. Org. Chem. 2007, 72, 9572–
9581; b) D. Schweitzer, J. J. Kane, D. Strand, P. Mc-
Henry, M. Tenniswood, P. Helquist, Org. Lett. 2007, 9,
4619–4622; c) V. Sofiyev, G. Navarro, D. Trauner, Org.
Lett. 2008, 10, 149–152.
[7] For a selection of recent applications of biaryl mono-
phosphine ligands see: a) J. E. Milne, S. L. Buchwald, J.
Am. Chem. Soc. 2004, 126, 13028–13032; b) T. E.
Barder, S. L. Buchwald, J. Am. Chem. Soc. 2007, 129,
12003–12010; c) K. Billingsley, S. L. Buchwald, J. Am.
Chem. Soc. 2007, 129, 3358–3366; d) T. Ikawa, T. E.
Barder, M. R. Biscoe, S. L. Buchwald, J. Am. Chem.
Soc. 2007, 129, 13001–13007; e) R. Martin, S. L. Buch-
wald, J. Am. Chem. Soc. 2007, 129, 3844–3845.
Acknowledgements
We thank the National Institutes of Health (GM 46059) for
G
support of this work. BASF is thanked for a gift of palladium
acetate and Merck, Amgen, and Boehringer Ingelheim are
thanked for additional support.
References
[1] For reviews of the Stille reaction see: a) J. K. Stille,
Pure Appl. Chem. 1985, 57, 1771–1780; b) M. Pereyre,
J. P. Quintard, A. Rahm, Tin in Organic Synthesis, But-
terworth, London, 1987, pp 185–210; c) V. Farina, V.
Krishnamurthy, W. J. Scott, Org. React. 1997, 50, 1–
652; d) V. Farina, V. Krishnamurthy, W. J. Scott, The
Stille Reaction, John Wiley & Sons, New York, NY,
1998, pp 1–652; e) J. Hassa, M. Svignon, C. Gozzi, E.
Schulz, M. Lemaire, Chem. Rev. 2002, 102, 1359–1470;
f) A. F. Littke, G. C. Fu, Angew. Chem. 2002, 114,
4350–4386; Angew. Chem. Int. Ed. 2002, 41, 4176–
4211; g) T. N. Mitchell, in: Metal-catalyzed Cross-cou-
pling Reactions, 2nd edn., (Eds.: A. de Meijere, F. Die-
derich), Wiley-VCH, Weinheim, 2004, pp 125; h) P. Es-
pinet, A. M. Echavarren, Angew. Chem. 2004, 116,
4808–4839; Angew. Chem. Int. Ed. 2004, 43, 4704–
4734.
[2] a) P. Manitto, Biosynthesis of Natural Products, Ellis
Horwood, Chichester, 1981, pp 365–429; b) M. Gill, in:
The Chemistry of Natural Products, 2nd edn., (Ed.:
R. H. Thomson), Blackie Academic & Professional,
Glasgow, 1993, pp 60–105; c) G. B. Smith, G. C.
Dezeny, D. L. Hughes, A. O. King, T. R. Verhoeven, J.
Org. Chem. 1994, 59, 8151–8156; d) R. S. Coleman,
M. L. Madaras, in: The Chemical Synthesis of Natural
Products, (Ed.: K. J. Hale), Sheffield Academic Press,
Sheffield, 2000, pp 144–179; e) G. Bringmann, D.
Menche, Acc. Chem. Res. 2001, 34, 615–624; f) S.
Kotha, K. Lahiri, D. Kashinath, Tetrahedron 2002, 58,
9633–9695; g) G. Bringmann, Y. Reichert, V. V. Kane,
Tetrahedron 2004, 60, 3539–3574; h) T. W. Wallace,
[8] The coupling of 4-chloroaniline with vinyltributylstan-
nane in 61% yield has been reported, see ref.[4c]
[9] A general method for the coupling of activated aryl
chlorides at 608C has been reported, see ref.[4h]
[10] C. Wolf, R. Lerebours, J. Org. Chem. 2003, 68, 7551–
7554.
[11] a) S. M. Abel, D. J. Back, J. L. Maggs, B. K. Park, J. Ste-
roid Biochem. Mol. Biol. 1993, 46, 833–839; b) B. K.
960
asc.wiley-vch.de
ꢀ 2008 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Adv. Synth. Catal. 2008, 350, 957 – 961

Palladium-Catalyzed Stille Cross-Coupling Reaction of Aryl Chlorides
COMMUNICATIONS
Park, N. R. Kitteringham, Drug Metab. Rev. 1994, 26,
605–643; c) S. B. Rosenblum, T. Huynh, A. Afonso,
H. R. Davis, Jr., N. Yumibe, J. W. Clader, D. A. Bur-
nett, J. Med. Chem. 1998, 41, 973–980.
[14] The coupling of 2-chloropyridine with tributyl-
(phenyl)stannane did not proceed to completion under
AHCTREUNG
these conditions. With a prolonged reaction time, 12 h
at 1008C a yield of 41% was achieved.
[15] A trimethylstannyl version has been reported as a cou-
pling partner in two instances, see: a) J. M. Saa, G.
Martorell, J. Org. Chem. 1993, 58, 1963–1966; b) A. M.
Echavarren, N. Tamayo, D. J. Cardenas, J. Org. Chem.
1994, 59, 6075–6083.
[12] M. V. Ncube, M. H. Norman, V. I. Ognyanov, L. H.
Pettus, US Patent 2005,165,015, 2005.
[13] M. P. Wentland, (Sterling Drug Inc., USA), US Patent
4,959,363, 1990.
Adv. Synth. Catal. 2008, 350, 957 – 961
ꢀ 2008 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
asc.wiley-vch.de
961
