2562 J. Phys. Chem. A, Vol. 114, No. 7, 2010
Zhu et al.
may break weak bonds between the photolysis products and the
surface, resulting in the release of the photolysis products, such as
NO2* and NO2, into the gas phase.
The ground state and the electronically excited states of NO2
can be monitored by their vibronic absorption and/or emission
in the visible region. Since there are four electronic states of
NO2 in the visible region (2A1, 2B2, 2B1, and 2A2) and each one
can interact with the other three electronic states, the visible
spectra of NO2 are very complex. Detailed description about
the visible spectra of NO2 can be found in the “Spectral Atlas
of Nitrogen Dioxide, 5530 to 6480 Å” by Hsu et al.13 and the
references within. The ground-state NO2 can be monitored by
its near UV-vis absorption14–19 in the 255-600 nm region with
peak absorption occurring at about 400 nm. Most of the
oscillator strength of the visible spectrum for the ground state
2
of NO2 comes from the X A1-2B2 transition.13 The excited
NO2 exhibits structured UV-vis absorption bands in the
350-650 nm region.14 In the study of Davidson et al.,14 the
excited NO2 was formed by heating the NO2 sample to 124 °C,
and the excited NO2 absorption spectrum was attributed to that
of the vibrationally excited ground-state NO2. As the wave
functions of the electronically excited NO2 and the high
vibrational levels of the ground-state NO2 are strongly mixed,
the excited NO2 spectrum in the 350-650 nm region can be
that of the electronically excited NO2 or that of the vibrationally
excited ground-state NO2, depending upon how the excited NO2
was generated. The electronically excited NO2 has “anoma-
lously” long radiative lifetime possibly caused by the interelec-
tronic level mixing with the ground state.20 Although there is a
strong transition moment between the vibrational levels of the
electronically excited NO2 and the high vibrational levels of
the ground-state NO2, the high vibrational levels of the ground
state have essentially no transition strength to the lowest
vibrational levels of the ground state. The lifetimes of the
electronically excited NO2 vary21 in the range of 55-90 µs as
the excitation wavelength is varied in the 3980-6000 Å range.
In this paper, we report results obtained from the 308 nm
excimer laser photolysis of HNO3 in the gas phase at 295 and
253 K, on Al surfaces at 295 and 253 K, and on ice films at
253 K, using cavity ring-down spectroscopy.22,23 The NO2*
quantum yields from the HNO3 photolysis on Al surfaces and
on ice films have been measured. In addition, the adsorbed
HNO3 absorption cross sections on Al surfaces and on ice films
at 308 nm have been directly determined. Atmospheric implica-
tions of the results are discussed.
Figure 1. Schematics of the stainless steel cells used for the gas-phase
study (above) and for the surface study (below).
cavity. The inner diameter of the jacketed gas cell is 4 in., and
the cell has an inner volume of 2.4 L. For this gas cell
configuration, the photolysis products detected by cavity ring-
down spectroscopy were those formed from the gas-phase
photolysis.
The stainless steel flow cell used for studying HNO3 pho-
tolysis on Al surfaces and on ice films (the surface-study cell)
has been described in detail elsewhere.27 It has the form of a
hollow rectangular prism (see Figure 1). The length of the cell
is 55 cm, and the cell’s cross section is 2.54 cm × 2.54 cm. A
pair of high-reflectance cavity mirrors vacuum-sealed the two
ends of the cell. Fused-silica windows were mounted to the front
and back of the cell, for transmission of the photolysis beam.
A pair of rectangular Al reflectors (∼47% measured reflectivity
inside the cell at 308 nm) were mounted inside the cell, along
its length. The photolysis beam entered the cell through the
window on the front side. The photolysis beam was subsequently
bounced back and forth by the Al reflectors, a number of times,
before it exited the cell through a window. The probe laser beam
entered the cell along the main optical axis. A fraction of the
probe laser pulse was injected into the cavity through the front
mirror, and the intensity decay of this fraction inside the cavity
was measured by monitoring the weak transmission of light
through the rear mirror, with a photomultiplier tube (PMT). The
amplified PMT signal was fitted to a single-exponential decay
function, from which the ring-down time constant and the total
loss per optical pass were calculated.
2. Experimental Technique
An excimer laser operating at 308 nm was used to photolyze
HNO3 in the gas phase, on Al surfaces, and on ice films; the
photolysis products formed from the HNO3 photolysis were then
probed by cavity ring-down spectroscopy. A stainless steel
reaction cell for gas-phase study (the gas cell) has been described
in detail elsewhere.24–26 It is shown in Figure 1 to enable
comparison with a cell used for the surface studies. Only the
essential features of the gas cell are summarized here. The gas
cell has a double-walled configuration to facilitate variation of
the cell temperature; it was vacuum-sealed by a pair of high-
reflectance cavity mirrors at both ends. The output from the
photolysis laser was propagated into the reaction cell at a 15°
angle to the main cell axis, through a side arm. The probe laser
pulse, delayed relative to the photolysis laser pulse and used to
detect NO2* (at 552.57 nm) and NO2 (at 352 nm),14–16 was
introduced into the cell along the main optical axis. The probe
laser beam overlapped the photolysis beam at the center of the
The surface-study cell is equipped with various reagent ports,
a pumping port, and pressure- and temperature-measurement
ports, all located on top of the cell. A rectangular viewport,
made of transparent plastic (acrylic) and installed on the top,
along the main optical path, allowed us to view the ice film
growth conditions and the photolysis beam. The bottom of the
cell had a cooling block, which was connected to a low-
temperature bath/circulator (Neslab ULT-80; ethanol was used
as the coolant). Temperature at the Al reflector surface was
measured with a thermocouple intact. Helium was bubbled
through a distilled water bubbler at 295 K, and water-vapor/
He mixture was admitted to the cell via four feedthroughs placed
at the bottom of the cell (Figure 1). At the other end of each
feedthrough was a length of stainless steel tubing, 13-14 cm
3
long, /16 in. o.d. diameter. On each length of tubing, a row of
precision holes was drilled, with 1 cm spacing. Four lengths of
stainless steel tubing were used to form two sets of internally
