Evaluation of substituted n-phenylpiperazine analogs as D3 vs. D2 dopamine receptor subtype selective ligands

Article abstract of DOI:10.3390/molecules26113182

N-phenylpiperazine analogs can bind selectively to the D3 versus the D2 dopamine receptor subtype despite the fact that these two D2-like dopamine receptor subtypes exhibit substantial amino acid sequence homology. The binding for a number of these receptor subtype selective compounds was found to be consistent with their ability to bind at the D3 dopamine receptor subtype in a bitopic manner. In this study, a series of the 3-thiophenephenyl and 4-thiazolylphenyl fluoride substituted N-phenylpiperazine analogs were evaluated. Compound 6a was found to bind at the human D3 receptor with nanomolar affinity with substantial D3 vs. D2 binding selectivity (approximately 500-fold). Compound 6a was also tested for activity in two in-vivo assays: (1) a hallucinogenic-dependent head twitch response inhibition assay using DBA/2J mice and (2) an L-dopa-dependent abnormal involuntary movement (AIM) inhibition assay using unilateral 6-hydroxydopamine lesioned (hemiparkinsonian) rats. Compound 6a was found to be active in both assays. This compound could lead to a better understanding of how a bitopic D3 dopamine receptor selective ligand might lead to the development of pharmacotherapeutics for the treatment of levodopa-induced dyskinesia (LID) in patients with Parkinson’s disease.

Full text of DOI:10.3390/molecules26113182

molecules
Article
Evaluation of Substituted N-Phenylpiperazine Analogs as D3
vs. D2 Dopamine Receptor Subtype Selective Ligands
Boeun Lee 1 , Michelle Taylor 2, Suzy A. Griffin 2, Tamara McInnis 2, Nathalie Sumien 2 , Robert H. Mach 1
and Robert R. Luedtke 2,
*
1
2
Department of Radiology, Perelman School of Medicine, University of Pennsylvania,
Philadelphia, PA 19104, USA; boeunlee@pennmedicine.upenn.edu (B.L.);
rmach@pennmedicine.upenn.edu (R.H.M.)
Department of Pharmacology and Neuroscience, University of North Texas Health Science Center-Fort Worth,
Fort Worth, TX 76107, USA; michelle.taylor@unthsc.edu (M.T.); suzy.griffin@unthsc.edu (S.A.G.);
tamara.mcinnis@unthsc.edu (T.M.); nathalie.sumien@unthsc.edu (N.S.)
Correspondence: robert.luedtke@unthsc.edu
*
Abstract: N-phenylpiperazine analogs can bind selectively to the D3 versus the D2 dopamine receptor
subtype despite the fact that these two D2-like dopamine receptor subtypes exhibit substantial amino
acid sequence homology. The binding for a number of these receptor subtype selective compounds
was found to be consistent with their ability to bind at the D3 dopamine receptor subtype in a
bitopic manner. In this study, a series of the 3-thiophenephenyl and 4-thiazolylphenyl fluoride
substituted N-phenylpiperazine analogs were evaluated. Compound 6a was found to bind at
the human D3 receptor with nanomolar affinity with substantial D3 vs. D2 binding selectivity
(approximately 500-fold). Compound 6a was also tested for activity in two in-vivo assays: (1) a
hallucinogenic-dependent head twitch response inhibition assay using DBA/2J mice and (2) an
L-dopa-dependent abnormal involuntary movement (AIM) inhibition assay using unilateral 6-
hydroxydopamine lesioned (hemiparkinsonian) rats. Compound 6a was found to be active in
both assays. This compound could lead to a better understanding of how a bitopic D3 dopamine
receptor selective ligand might lead to the development of pharmacotherapeutics for the treatment
of levodopa-induced dyskinesia (LID) in patients with Parkinson’s disease.
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Citation: Lee, B.; Taylor, M.; Griffin,
S.A.; McInnis, T.; Sumien, N.; Mach,
R.H.; Luedtke, R.R. Evaluation of
Substituted N-Phenylpiperazine
Analogs as D3 vs. D2 Dopamine
Receptor Subtype Selective Ligands.
Molecules 2021, 26, 3182. https://
doi.org/10.3390/molecules26113182
Keywords: D2-like dopamine receptors; D3 dopamine receptor subtype; G-protein coupled receptor
(GPCR); dopamine receptor subtype selective ligands; bitopic ligands
Academic Editor: Ingebrigt Sylte
Received: 27 April 2021
Accepted: 21 May 2021
Published: 26 May 2021
1. Introduction
Dopamine is a neurotransmitter that controls a variety of physiological functions in
both the periphery and in the central nervous system (CNS). In the periphery, dopamine
receptors have been implicated in the modulation of renal sodium excretion, urinary
output, inhibition of norepinephrine release, vasodilatory activity of blood vessels and the
regulation of insulin secretion in pancreatic
also been reported to be expressed on regulatory T cells and antigen-presenting dendritic
cells associated with the immune system [ ]. Dopaminergic pathways in the brain have
Publisher’s Note: MDPI stays neutral
with regard to jurisdictional claims in
published maps and institutional affil-
iations.
β-cells [1,2]. Dopamine receptor expression has
3,4
been implicated in the reward system, psychostimulant seeking behaviors, movement,
memory and learning, sleep regulation, feeding, attention, olfaction, vision, hormonal
regulation, and emotional tone [5].
There are five human dopamine receptor subtypes classified into two major categories:
D1-like (D1 and D5) and D2-like (D2, D3 and D4) dopamine receptor subtypes. The D1-like
and D2-like dopamine receptor classes have been categorized based upon similarities in
genomic organization, amino acid sequence homology and pharmacological properties [6].
All five of the dopamine receptor subtypes are members of the G protein-coupled receptor
(GPCR) protein superfamily. The two genes which encode for the D1 and D5 are both
Copyright:
© 2021 by the authors.
Licensee MDPI, Basel, Switzerland.
This article is an open access article
distributed under the terms and
conditions of the Creative Commons
Attribution (CC BY) license (https://
creativecommons.org/licenses/by/
4.0/).
Molecules 2021, 26, 3182. https://doi.org/10.3390/molecules26113182
https://www.mdpi.com/journal/molecules

Molecules 2021, 26, 3182
2 of 16
intronless genes, whereas the D2, D3 and D4 dopamine receptor genes contain exons and
introns. The length, organization, and amino acid homology of the two D1-like dopamine
receptors are similar, with the D1-like receptors having a shorter third intracellular loop
and a longer carboxy terminus compared to D2-like dopamine receptor subtypes. The
three-dimensional structures of all three D2-like dopamine receptors has been determined
by x-ray diffraction [7–9]. The structure of the D2 dopamine receptor in complex with
a Gi-protein has recently been reported using cryo-electron microscopy [10]. The three-
dimensional structure of the D1-like receptors has not been reported.
Agonist stimulation of the D1-like dopamine receptors has been shown to increase
the production of cAMP, whereas D2-like receptor agonists inhibit forskolin-dependent
stimulation of adenylyl cyclase [11
,12]. Agonist binding at both the D1-like and D2-like
dopamine receptors leads to -arrestin recruitment [13
β
,
14]. Dopamine receptor agonists are
used therapeutically to treat Parkinson’s disease and restless legs syndrome, but adverse
side effects can include nausea, orthostatic hypotension, hallucinations and impulse control
disorders. Chronic administration of dopaminergic agonists that are used of L-dopa for
the treatment of Parkinson’s disease in humans can lead to L-dopa-induced dyskinesia
(LIDs). In preclinical studies, selective blockade of the D3 dopamine receptor has been
reported to reduce L-dopa dependent dyskinesia-like movements, without affecting the
antiparkinsonian efficacy of L-dopa [15,16].
Despite having similar amino acid sequences and pharmacologic profiles, the D2
and D3 dopamine receptor subtypes exhibit differences in how they couple to signal
transduction pathways. For example, agonist stimulation of the D2 receptor activates ERK
via a Giα-dependent pathway, whereas D3 receptors activate ERK by a mechanism that
is Gβγ dependent [17]. In addition, sigma-1 receptors have been reported to selectively
interact with D2 dopamine receptors, but not with the D3 or D4 receptor subtypes [18].
Further, the S100B calcium binding protein has been reported to interact with the D2, but
not the D3, dopamine receptor [19].
Since the orthosteric binding site of D2-like dopamine receptors is constructed by
conserved amino acid residues in the transmembrane helical spanning regions, it is not
surprising that many of the original D2 vs. D1 selective ligands bind nonselectively at the
D2 and D3 dopamine receptor subtypes. Ligands that can simultaneously interact with
two different regions (an orthosteric and secondary binding site (SBS) on a single GPCR
have been described as bitopic ligands [20–24]. The ability of some N-phenylpiperazine
benzamides to bind selectively at the D3 dopamine receptor subtype has been attributed
to the ability of the N-phenylpiperazine moiety to occupy either the D2 or D3 dopamine
orthosteric binding site, while the benzamide moiety interacts with an SBS that is unique to
the D3 dopamine receptor subtype [21,24]. Consequently, a number of research groups have
been able to develop D3 vs. D2 dopamine receptor selective ligands using a substituted
N-phenylpiperazine benzamide template to identify ligands that bind selectively and with
high affinity at the D3 dopamine receptor subtype [25–28].
Previously we reported how incorporating a 4-(thiophen-3-yl)benzamide could lead
to compounds that bind to the D3 receptor subtype with high affinity and with D3 vs. D2
receptor binding selectivity. Maintaining the thiophene moiety while varying the composi-
tion or position of substituents on the phenyl ring of the N-phenylpiperazine moiety leads
to a panel of compounds with varying D2/D3 dopamine receptor subtype affinity and
binding selectivity [22,23]. In this communication we explored the effect of varying the ben-
zamide portion of our compounds while maintaining the fluorinated N-phenylpiperazine
portion. The result of this study provides further insight into how structural variation in
the dopaminergic ligands might impact ligand binding affinity and binding selectivity of
N-phenylpiperazine benzamide at human D2 and D3 dopamine receptors.

Molecules 2021, 26, 3182
3 of 16
2. Results
2.1. Chemistry
The structure and binding affinities (Ki values) for several previously published N-
phenylpiperazines at the human D2 and D3 dopamine receptor are shown in Figure 1.
These compounds exhibit varying binding affinities at the D3 dopamine receptor and
varying D3 vs. D2 binding selectivity [29–33]. Compound LS-3-134 exhibits high affinity
binding at the D3 receptor (Ki value of approximately 0.2 nM) with >150-fold D3 vs. D2
dopamine receptor binding selectivity, whereas WW-III-55 exhibits a higher level of D3 vs.
D2 dopamine receptor binding selectivity (>800-fold) but with lower binding affinity at
the D3 dopamine receptor (Ki values approximately 20 nM). It is noteworthy that LS-3-134
and WW-III-55 both contain an N-phenylpiperazine and a 4-(thiophen-3-yl)benzamide
moiety, while KX-2-67 binds with low affinity predominantly to the SBS of the D2 and D3
dopamine receptor [21,22].
Figure 1. Chemical structures and binding data of a variety of arylamide phenylpiperazine D3 dopamine receptor
selective compounds are shown. KX-2-67 binds with low affinity to the secondary binding site of the D3 dopamine
receptor [19,20,26,27,30].
The synthesis strategy for the compounds described in this communication is outlined
in Scheme 1. Briefly, the orthosteric N-phenylpiperazine moieties 2a
one-pot Pd-catalyzed Buchwald-Hartwig amination reaction of six different aryl halides
with piperazine [34]. The N-alkylation of aryl piperazines 2a with 1-bromobutane in
acetone using potassium carbonate as a base provided fragments of D3 dopamine receptor
selective compounds, 3a . Butyl amine compounds 5a , which were used for conjugation
with substituted benzoic acids, were synthesized using a Gabriel amine synthesis reaction.
N-arylpiperazine compounds 2a were reacted with N-(4-bromobutyl)phthalimide in
acetonitrile to give butyl phthalimide compounds 4a and the hydrazinolysis of these
compounds gave the corresponding amines 5a in high yields (70–95%). The free amines
5a were coupled with 4-(thien-3-yl)benzoic acid or 4-(1,3-thiazol-4-yl)benzoic acid using 1-
ethyl-3-(3-dimethylaminopropyl)carbodiimide (EDC) and 1-hydroxybenzotriazole (HOBt)
hydrate in dichloromethane to give the targeted benzamide compounds 6a (52–88%
yields) and 7a (64–84% yields). The final products were converted to the corresponding
–f were afforded by a
–
f
–
f
–f
–
f
–
f
–
f
–
f
–
f
–f
hydrochloride salts. Detailed synthesis procedure and chemical analysis of synthesized
compounds (1H, 13C NMR, and Mass) were reported in Supplementary Material.

Molecules 2021, 26, 3182
4 of 16
Scheme 1. Synthesis of Thiophenephenyl and Thiazolylphenyl Substituted Phenylp◦iperazine Analogs. Reagents and
conditions: (a) Aryl halide (1a–f), piperazine, NaOtBu, Pd2(dba)3, RuPhos, dioxane, 100 C, 1 h; (b) 1-bromobutane, K2CO3,
acetone, rt, overnight; (c) N-(4-bromobutyl)phthalimide, Et3N, acetonitrile, rt, overnight; (d) hydrazine hydrate, ethanol,
80 ◦C, 2 h; (e) 4-(thien-3-yl)benzoic acid, EDC, HOBt hydrate, CH2Cl2, rt, 1 h; (f) 4-(1,3-Thiazol-4-yl)benzoic acid, EDC,
HOBt hydrate, CH2Cl2, rt, 1 h.
2.2. Pharmacological Studies
2.2.1. D2-Like Dopamine Receptors
Competitive radioligand binding techniques were used to determine the Ki values of
ligands at human D2 and D3 dopamine receptors expressed in stably transfected HEK cells
(Table 1). As anticipated, compounds 3a–f exhibited the lowest binding affinities for the
human D2 (Ki values = 349–7522 nM) and D3 (Ki values = 96–1413 nM) dopamine receptor
subtypes. These compounds bound essentially nonselectively at the D2 and D3 dopamine
receptor subtypes (binding selectivity ratio = 1.0–7.5-fold). The 4-thiophene-3-yl-benzamide
N-phenylpiperazines (6a
–f) and corresponding 4-thiazolyl-4-ylbenzamide N-piperazine
analogs (7a ) exhibited a similar range of binding affinities at the D3 dopamine receptor
–f
(Ki = 1.4–43 nM and 2.5–31 nM, respectively) and a similar range of D3 vs. D2 receptor
binding selectivity (67–1831-fold vs. 73–1390-fold, respectively). Representative examples
of competitive radioligand binding curves of compound 6a–c and 7a–c at human D2 and
D3 dopamine receptors are shown in Supplementary Material.

Molecules 2021, 26, 3182
5 of 16
Table 1. Binding Affinity and cLogP Values for Compounds.
R2
H
N
N
N
N
N
O
R1
R1
3a-f
6a-f, 7a-f
Structure
Ki Values (nM) 1
#
cLogP 2
D2:D3 Selectivity
R1
R2
D2 Receptor
D3 Receptor
3a
3b
3c
3d
3e
3f
2-F
3-F
4-F
384 ± 39.6
2516 ± 252
3091 ± 269
5431 ± 1059
7522 ± 466
349 ± 21.1
96.2 ± 16.9
1003 ± 118
1176 ± 240
726 ± 101
4.0
2.5
2.6
7.5
5.3
1.0
4.06
4.06
4.06
3.78
5.13
4.31
−
2-F, 5-CN
2-F, 4-CF3
2-OC2H4F, 4-F
1413 ± 59.1
351 ± 42.1
6a
6b
6c
6d
6e
6f
2-F
3-F
4-F
648 ± 100
2334 ± 485
7200 ± 215
4502 ± 565
>75,000
1.4 ± 0.2
7.9 ± 1.4
12.4 ± 1.6
15.5 ± 1.3
43.3 ± 9.2
6.1 ± 0.2
467
296
579
290
>1800
67.4
5.15
5.15
5.15
4.87
6.22
5.40
S
2-F, 5-CN
2-F, 4-CF3
2-OC2H4F, 4-F
411 ± 27.3
7a
7b
7c
7d
7e
7f
2-F
3-F
4-F
478 ± 71.0
3946 ± 146
4012 ± 694
7717 ± 1497
>40,000
2.5 ± 0.22
24.0 ± 5.5
28.6 ± 2.1
28.1 ± 0.8
30.9 ± 2.6
4.8 ± 0.28
190
165
140
274
1390
72.9
4.16
4.16
4.17
3.89
5.24
4.42
N
S
2-F, 5-CN
2-F, 4-CF3
2-OC2H4F, 4-F
349 ± 50.3
The Ki values for the binding of test compound at human D2 and D3 dopamine receptors are shown. The D3 vs. D2 dopamine receptor
binding selectivity and cLogP values of the test compound are also shown. Mean
experiments. cLogP values were calculated using ChemDraw Professional 15.1.
1
±
S.E.M.; Ki values were determined by at least three
2
A comparison of the binding affinity and binding selectivity of the N-phenylpiperazine
orthosteric ligands (compounds 3a ) with the longer thiophene-containing (compounds
6a ) and thiazole-containing (compounds 7a ) analogs further suggest that the benzamide
–f
–
f
–f
N-phenylpiperazine class of compound likely engage the D3 dopamine receptor, but not
the D2 dopamine receptor, in a bitopic binding mode, leading to enhanced affinity at the D3
receptor subtype and consequently increased D3 vs. D2 binding selectivity. In general, the
thiophene analogs (compounds 6a–f) bound with slightly higher affinity at D3 dopamine
receptors and/or with slightly greater D3 vs D2 binding selectivity than the corresponding
thiazole analogs (compounds 7a–f).
2.2.2. 5-HT1A Receptor Binding
Because the 5-HT1A receptor is a commonly observed off-site binding site for benza-
mide N-phenylpiperazine ligands, compounds were simultaneously screened for binding
of our compounds at the human 5-HT1A receptor expressed in CHO-K1 cells, using the
radioligand [3H]-8-hydroxy-DPAT (8-OH-DPAT) (Table 2). Based upon the analysis of
the displacement assay shown in Table 2, the orthosteric compounds 3c–f appeared to
bind with low affinity at human 5-HT1A receptors. However, at a concentration of 91 nM
compounds 3a and 3b appeared to be able to partially displace the 5-HT1A selective radi-
oligand. Compounds 6b, 7a, 7b and 7f displaced tritiated 8-OH-DPAT binding in a manner
that suggested substantial affinity for the 5-HT1A receptor.

Molecules 2021, 26, 3182
6 of 16
Table 2. Screen for Binding Affinity at the 5-HT1A Receptor.
R2
H
N
N
N
N
N
O
R1
R1
3a-f
6a-f, 7a-f
Structure
5-HT1A Receptor Inhibition (%)
#
R1
R2
3a
3b
3c
3d
3e
3f
2-F
3-F
4-F
20.3 ± 16.2
36.1 ± 2.1
5.1 ± 11.2
−
2-F, 5-CN
2-F, 4-CF3
2-OC2H4F, 4-F
−18.0 ± 11.1
−11.6 ± 15.4
1.7 ± 21.7
6a
6b
6c
6d
6e
6f
2-F
3-F
4-F
−3.3 ± 15.1
74.7 ± 1.9
−7.7 ± 23.5
2.5 ± 3.5
2-F, 5-CN
2-F, 4-CF3
2-OC2H4F, 4-F
6.1 ± 6.8
16.9 ± 24.4
7a
7b
7c
7d
7e
7f
2-F
3-F
4-F
65.8 ± 5.0
74.1 ± 5.3
12.2 ± 3.1
−5.6 ± 18.3
7.6 ± 6.5
2-F, 5-CN
2-F, 4-CF3
2-OC2H4F, 4-F
37.1 ± 24.4
Phenylpiperazine ligands 3a–f, 6a–f, and 7a–f
were screened for the binding activity of [3H]-8-hydroxy-DPAT at
human 5-HT1A receptors expressed in CHO-K1 cells using a single point radioligand displacement assay. The
radioligand displacement percentages were determined by at least three experiments using 91 nM concentration
of test compound. Nonspecific binding was defined using 10 µM metergoline. Compounds 3a and 3b exhibited
moderate displacement of the radioligand at the 5-HT1A receptor. Thiophenyl compound 6b and thiazolyl
compounds 7a, 7b, and 7f exhibited a greater percentage of radioligand displacement. Data is presented as
percent displacement of radioligand (n ≥ 3) ± S.E.M.
A comparison of the effect of compounds 3a, 6a and 7a on [3H]-8-hydroxy-DPAT
binding was conducted. Based upon the radioligand displacement assessment the orthos-
teric ligand (compound 3a) exhibited moderate affinity at 5-HT1A receptors. The thiazole
analog of compound 3a (compound 7a) exhibited increased affinity at 5-HT1A, while the
thiophene analog (compound 6a) appeared to exhibit decreased binding affinity at the
5-HT1A receptor compared to compound 3a.
Compound 6a bound at the D3 dopamine receptor with high affinity (Ki value = 1.4
±
0.21 nM) and exhibited >400-fold D3 vs. D2 receptor binding selectivity, while exhibiting
a low level of radioligand displacement at 5-HT1A receptors, suggesting that it bound
with low affinity at the 5-HT1A receptor binding site. To verify the low affinity binding of
compound 6a at the 5-HT1A receptor, a dose dependent competitive radioligand binding
curve was performed. Compound 6a was found to bind to the 5-HT1A receptor with a Ki
value of 199 nM (Figure 2), which is approximately 140-fold lower than its affinity at the
D3 dopamine receptor. The rank order of affinity of these analogs at the 5-HT1A receptor
was found to be 7a > 3a > 6a (Figure 2).

Molecules 2021, 26, 3182
7 of 16
Figure 2. Competitive Radioligand Binding Assay for the Inhibition of [3H]-8-hydroxy-DPAT with 2-
fluorophenyl Compounds at 5-HT1A Receptors
(– –), and 7a (– –) were evaluated for their affinity at 5-HT1A receptor using competitive radioligand
binding techniques. Ki values were determined by at least three experiments. Compound 7a exhibited
the highest affinity for the 5-HT1A receptor (Ki = 14.3 7.1 nM) while compound 6a had the lowest
affinity for the receptor (Ki = 199 34.3 nM). The orthosteric fragment, compound 3a, exhibited
an intermediate affinity for 5-HT1A receptors (Ki = 67.8 4.6 nM). This rank-order of affinity is
.
2-Fluorophenyl piperazine compounds 3a (–•–)
, 6a
ꢀ
N
±
±
±
consistent with the results obtained in affinity displacement screen shown in Table 2.
2.2.3. Off-Target Binding Assessment
Further evaluation of the off-target binding of compound 6a was provided by the
Psychoactive Drug Screening Program (PDSP) for a range of receptors including serotonin
receptor subtypes, α-adrenergic receptor subtypes, β-adrenergic receptor subtypes, his-
taminergic receptor subtypes, muscarinic receptor subtypes, opioid receptor subtypes and
the two sigma receptor subtypes. The PDSP evaluation confirmed the high affinity binding
of compound 6a at the D3 dopamine receptor (0.2 nM) and the low affinity binding at
the D1, D2, D4 (>1500 nM) and D5 dopamine receptor subtypes, as well as the dopamine
transporter (DAT) (>190 nM), the norepinephrine transporter (NET) (>650 nM) and the
serotonin transporter (SERT) (>750 nM). The highest off-site binding affinity was observed
for the several of the alpha-adrenergic receptor subtypes (α1a, 9.8 nM; α2a, 15.2 nM; α1d,
16.6 nM; α2c, 27.1 nM), with lower affinity at the α2b (>100 nM) and α1b(>100 nM) recep-
tor subtypes. Off-site binding was observed for three of the serotonin receptor subtypes
(5-HT1A, 27 nM; 5-HT2B, 36.3 nM; 5-HT7A, 73.6 nM). Off-site binding affinity was higher
at the sigma-2 receptor (33.1 nM) compared to the sigma-1 receptor (>175 nM).
2.2.4. Ligand Efficacy Analysis
Compounds exhibiting high affinity binding at the D3 dopamine receptor were subse-
quently evaluated for efficacy at the D3 dopamine receptor subtype using both a forskolin-
dependent inhibition of adenylyl cyclase assay and a β-arrestin binding assay (Figure 3).
Quinpirole was used as a reference prototypic full agonist and haloperidol was used as
a reference prototypic antagonist. Compounds 7e and 6d were found to be antagonists
in both assays. Compound 6c was found to be functionally selective because it was a
weak partial agonist for the adenylyl cyclase assay while being a very weak partial ag-
onist/antagonist in the β-arrestin binding assay. Compounds 6a and 6b were found to
be weak partial agonists in both the adenylyl cyclase inhibition assay and the
binding assay.
β-arrestin

Molecules 2021, 26, 3182
8 of 16
Figure 3. Comparison of the Efficacy of Phenylthiophene Analogs for Adenylyl Cyclase Inhibition
and
pounds 6a
Values were normalized to reference full agonist quinpirole (10,000 nM). The concentration of the
test compound was equal to 10 the Ki value as determined from competitive radioligand binding
β-Arrestin Binding at Human D3 Dopamine Receptors
.
A comparison of the efficacy of com-
–
d
and 7e for the inhibition of adenylyl cyclase and the binding of
β-arrestin is shown.
×
studies, therefore 90% of the binding sites were occupied.
2.3. In-Vivo Analysis of Compound 6a
Based upon the data indicating that compound 6a bound with high affinity to the
human D3 dopamine receptor and with low affinity at both the human D2 dopamine
receptor subtype (Table 1) and the 5-HT1A receptor (Table 2 and Figure 2), two in-vivo
assays were performed to determine if compound 6a was capable of in-vivo engagement
of the D3 receptor in the brain. While we do appreciate the potential that possible in-
vivo differences in pharmacological responses for the same drug in experimental animals
and humans of sex differences, these initial in-vivo studies were primarily conduced to
assess the ability of compound 6a to cross the blood brain barrier (BBB) and engage the
pharmacologically relevant target. Further sex differences in the pharmacological response
of animals to compound 6a will be conduction as further in-vivo studies are necessitated.
First, we have previously published that D3 receptor selective compounds could atten-
uate a hallucinogen-dependent head twitch response (HTR) in male DBA/2J mice [20,33]
.
Figure 4 indicates that at a dose of 10 mg/kg compound 6a attenuated the number of head
twitches induced by 5 mg/kg of the hallucinogen 2,5-dimethoxy-4-iodoamphetamine (DOI)
over a 30 min time period. A two-way ANOVA with repeated measures revealed a main
effect of Group (F2,18 = 6.49; p = 0.008), a main effect of Time (F5,90 = 348.16; p < 0.001) and
an interaction between Time and Group (F10,90 = 14.92; p < 0.001). Second, we previously re-
ported that D3 vs. D2 dopamine receptor subtype selective ligands could attenuate L-dopa
dependent abnormal involuntary movement (AIM) scores in unilaterally lesioned (hemi-
parkinsonian) male rats, which is a model for L-dopa-Induced Dyskinesia (LID) [35,36].
Figure 5 indicates that at a dose of 10 mg/kg compound 6a could attenuate the AIM scores
induced by 8 mg/kg of L-dopa and benserazide (each) in unilaterally lesioned rats. A
two-way ANOVA with repeated measures revealed a main effect of Group (F1,10 = 26.98;
p < 0.001), a main effect of Time (F7,70 = 15.61; p < 0.001) and an interaction between Time
and Group (F7,70 = 7.44; p < 0.001).

Molecules 2021, 26, 3182
9 of 16
Figure 4. Inhibition of the Murine DOI-Dependent Head Twitch Response by Compound 6a. The
inhibition of the DOI-dependent Head Twitch Response (HTR) by compound 6a as a function of
time (minutes) is shown. Male DBA/2J mice were dosed with 5 mg/kg of DOI in the presence of
10 mg/kg of compound 6a. The vehicle control studies were performed either one week before
(–
ꢁ
–), or one week after (–
#
–) the compound 6a (–
N–) was evaluated. The data shown is the mean
number of head twitches
±
S.E.M. averaged by two observers cumulatively at 5 min. Intervals
for n = 7 mice. * A p < 0.05 was observed compared to both controls at times 15–30 min (one-way
ANOVAs revealed main effects of Groups (F2,18 ranging from 5.1 to 10.4 with p < 0.019) and were
followed by post-hoc analyses).
Figure 5. The Effect of Compound 6a on Abnormal Involuntary Movement (AIM) Scores in Hemi-
parkinsonian Rats. Male hemiparkinsonian rats were purchased from Charles Rivers Laboratories.
After a 21 daily intraperitoneal injection regimen of 8 mg/kg of L-dopa and benserazide (each) the
animals were administered L-dopa/benserazide (8 mg/kg each) either with vehicle (10% DMSO
in sterile water) or compound 6a at a dose of 10 mg/kg. Animals were scored on a scale from 0 to
4 for a) dystonic torsion of the trunk and neck contralateral to the lesion, b) dystonic movements
of the forelimb contralateral to the lesion, c) orolingual movements with protrusion of the tongue
and d) increased locomotion activity. Average AIM scores
±
S.E.M. is shown for n = 6 animals in
the presence (– –) or absence (– –) of compound 6a. * A p < 0.05 value compared to vehicle control
•
ꢀ
was observed for time points 15–120 min (one-way ANOVAs revealed main effects of Groups (F1,10
ranging from 11 to 38.4 with p < 0.009).

Molecules 2021, 26, 3182
10 of 16
3. Discussion
This communication describes part of our ongoing studies on the development of dopamine
receptor selective ligands in vivo to dissect the role of the D2 and D3 dopamine receptor sub-
types in the rewarding and motivational aspects of psychostimulant abuse [35,37–39], the
treatment of neurological and neurodegenerative disorders [36,40] and for the develop-
ment of selective imaging agents [41].
We previously reported that structural variations in the aryl portion of 4-(thiophen-
3-yl)benzamides play an important role in D3 dopamine receptor affinity, D3 vs. D2
receptor binding selectivity and D3 dopamine receptor functional selectivity (biased ago-
nism) [20–22,30,35,42]. The structural templates for these studies included LS-3-134 and
WW-III-55 (Figure 1). Both compounds possess a common 4-(thiophen-3-yl)benzamide
with a saturated four-carbon chain adjacent to a substituted phenylpiperazine moiety. LS-3-
134 was found to bind at the human D3 dopamine receptor with high affinity (Ki = 0.17 nM
)
and demonstrated >150-fold D3 vs. D2 dopamine receptor binding selectivity [30]. LS-
3-134 was found to be a partial agonist at the D3 dopamine receptor (35% of maximum
efficacy) using an adenylyl cyclase inhibition assay. While WW-III-55 exhibits only moder-
ate binding affinity (approximate Ki of 20 nM) at D3 dopamine receptors, this compound
binds with high (>800-fold) D3 vs. D2 dopamine receptor binding selectivity. Using an
adenylyl cyclase assay, WW-III-55 was found to be a strong partial agonist (67.6
±
12.5%
of maximum efficacy) while LS-3-134 was found to be a weak partial agonist (34.4 ± 1.7%).
Therefore, we projected that structurally related analogs of WW-III-55 and LS-3-134 might
be identified that could exhibit high affinity binding at the D3 dopamine receptor, substan-
tial D3 vs. D2 receptor binding selectivity and varying efficacy for G-protein and
mediated signaling.
β-arrestin
This expectation was verified when we examine the binding properties of a panel
of structural analogs of WW-III-55 and LS-3-134, where the 4-(thiophen-3-yl)benzamide
structure, which we project interacts with the SBS, was invariant while substituents on the
phenyl moiety of the phenylpiperazine (the structure binding to the orthosteric binding
site) were varied. This synthetic strategy led to the identification of several compounds that
exhibited subnanomolar affinity (Ki values < 1.0 nM) at the human D3 dopamine receptor
subtype with high D3 vs. D2 dopamine receptor binding selectivity (
In the context of a dynamic ensemble theory of GPCR structure and activation [43
≥
1000-fold) [22].
45],
–
this observation suggests that each of the 4-(thiophen-3-yl)benzamide analogs used in
that study interacts with the D3 dopamine receptor protein in a slightly different manner
(depending on the position and chemical properties of the substituent), stabilizing a unique
ensemble of receptor structures resulting in a collection of ligand-dependent structural
variations in the D3 dopamine receptor energy landscape [42–45].
In this communication our initial goal was first to characterize a number of synthetic
analogs in which the 4-(thiophen-3-yl)benzamide group and the adjacent saturated four
carbon chain was invariant, while the substitution pattern on the phenyl ring of the
phenylpiperazine moiety substituted at the 2nd, 3rd and 4th position with a fluorine. Once
we established that the 2nd position was optimal for a fluoride substitution (compounds
3a and 6a), our second goal was to attempt to further optimize ligand binding affinity by
exploring additional substitutions on the phenyl ring of the N-phenylpiperazine moiety
(compounds 6d–f). Compound 6a remained our best candidate, with the highest affinity
at the D3 receptor subtype (Ki value = 1.4 nM), while it exhibited substantial D3 vs. D2
receptor binding selectivity (>450-fold). Our third synthetic strategy was to substitute the
thiophene ring (6a–f) with a thiazole ring (7a–f). In general, this structural alteration led to
a decrease in D3 vs. D2 receptor binding selectivity.
Using the aforementioned strategy, we were able to identify a number of ligands
which exhibited high affinity binding at the D3 dopamine receptor or substantial D3 vs.
D2 dopamine receptor binding selectivity. However, compound 6a remained of particular
interest because it bound at the D3 dopamine receptor with high affinity (Ki value = 1.4 nM
)
and exhibited substantial D3 vs. D2 binding selectivity (>400-fold).

Molecules 2021, 26, 3182
11 of 16
A direct comparison of the binding affinities for compounds 3a
–f
and 6a
–f
suggests
that compound 6a–f likely bound at the D3 dopamine receptor subtype, but not the D2
dopamine receptor, in a bitopic mode. This observation was similar to what we previously
reported [23]. While the identification of a ligand that can interact with a dualistic ligand
binding mode may not be applicable for the development of receptor subtype selective
ligands for every GPCR subfamily, it appears not to be unique to the dopamine receptor
subtypes. Bitopic ligands have also been reported for other GPCRs, including the mus-
carinic and angiotensin II receptors [46–48]. Furthermore, binding data provided by NIMH
Psychoactive Drug Screening Program (PSDP) indicated that compound 6a had reduced
affinity at the 5-HT1A receptor, which is a common off-site binding component that has
limited the development of in-vivo D3 dopamine receptor selective imaging agents. How-
ever, this binding data indicated that several alpha-adrenergic receptor subtypes bound
compound 6a.
The studies in this communication also demonstrated that after intraperitoneal injec-
tion compound 6a was capable of engaging CNS D3 dopamine receptors in vivo leading
to a significant decrease in the DOI-dependent head twitch response in mice and AIM
scores in dyskinetic hemiparkinsonian rats. These observations suggest that compound
6a was capable of traversing the blood-brain barrier in a manner such that a therapeutic
concentration could be achieved. We anticipate that studies such as those reported in this
communication could lead to a better understanding of how the development of bitopic
ligands might be designed and used to selectively target structurally similar GPCR receptor
subtypes in vivo.
4. Materials and Methods
4.1. Chemistry
All reagents and solvents for synthesis were purchased and used without further
1
purification. Structures of synthesized chemicals were identified using H and 13C nu-
1
clear magnetic resonance (NMR) spectra, and mass spectroscopy. H and 13C NMR were
recorded in
δ
units relative to deuterated solvent (CDCl3) as an internal reference by Bruker
1
DMX 500 MHz NMR instrument (Bruker, Billerica, MA, USA). H chemical shifts are
reported in parts per million (ppm) and measured relative to tetramethylsilane (TMS).
Mass spectra were acquired using a 2695 Alliance LC/MS (Milford, MA, USA). Purifi-
cation of synthesized chemicals was conducted on Biotage Isolera One (Biotage, Salem,
NH, USA) with a dual-wavelength UV-VIS detector. A detailed description of the syn-
thesis and characterization of the compounds described in this paper can be found in the
Supporting Information.
4.2. D2 and D3 Dopamine Receptor Competitive Radioligand Binding Assays
For these competitive binding studies, transfected HEK293 cell homogenates were
suspended in homogenization buffer and incubated with radioligand [125I]IABN, in the
presence or absence of inhibitor at 37 ◦C for 60 min (total volume = 150
µL), as previously
described [49]. The final radioligand concentration was approximately equal to the Kd
value for the binding of the radioligand. Nonspecific binding was defined as the binding
of the radioligand in the presence of 25 µM (+)-butaclamol. For each competition curve,
triplicates were performed using two concentrations of inhibitor per decade over five
orders of magnitude. Binding was terminated by the addition of cold wash buffer (10 mM
Tris–HCl/150 mM NaCl, pH = 7.5) and filtration over a glass-fiber filter (Pall A/B filters,
#66198). A Packard Cobra Gamma Counter (PerkinElmer, Waltham, MA, USA) was used
to measure the radioactivity of [125I]IABN.
The competition curves were modeled for a single binding site using
Bs = Bo − ((Bo + L)/(IC50 + L))
where Bs is the amount of ligand bound to receptor and Bo is the amount of ligand bound
to receptor in the absence of competitive inhibitor. L is the concentration of the competitive

Molecules 2021, 26, 3182
12 of 16
inhibitor. The IC50 value is the concentration of competitive inhibitor that inhibits 50%
of the total specific binding. IC50 values were determined using non-linear regression
analysis with TableCurve 2D v 5.01 (Jandel, SYSTAT, Systat Software, Inc., San Jose, CA,
USA). The values for Bs and Bo were constrained using experimentally derived values.
The IC50 values were converted to equilibrium dissociation constants (Ki) [50,51]. Mean Ki
values ± S.E.M. are reported for at least three independent experiments.
4.3. 5-HT1A Receptor Binding Assays
10 µg of membranes from CHO-K1 cells expressing the human 5-HT1A receptor
were suspended in 50 mM Tris-HCl, 10 mM MgSO4, 0.5 mM EDTA, and 0.1% (w/v)
ascorbic acid, pH 7.4 and test ligands (91 nM for single point radioligand displacement
assay and 1 nM to 1
hydroxy-DPAT (PerkinElmer, Boston, MA, USA) for 60 min at room temperature. The
nonspecific binding was determined using 10 M metergoline (Sigma, St. Louis, MO,
µ
M for full competition assay) were incubated with 0.25 nM [3H]8-
µ
USA). After incubation, the bound ligands were filtered using an M-24 Brandel filtration
system (Brandel, Gaithersburg, MD, USA), collected on glass fiber papers (Whatman grade
934-AH, GE Healthcare Bio-Sciences, Pittsburgh, PA, USA), and the radioactivity was
quantitated using a MicroBeta2 Microplate scintillation counter 2450 (PerkinElmer, Boston,
MA, USA).
4.4. Ligand Efficacy Analysis
4.4.1. Cyclase Inhibition Assay
The forskolin-dependent adenylyl cyclase inhibition assay was performed using a
cAMP-Glo Assay kit (Promega). For this assay cAMP stimulates protein kinase A (PKA)
activity, which leads to a decrease in ATP levels and a decrease in the luciferase-coupled
production of light. This is a 96 well plate assay using HEK cells stably transfected to
express the human D3 dopamine receptor (10,000 cells/well/0.1 mL complete media).
After removing media and rinsing with phosphate buffered saline, cells were incubated
with 20 µL of forskolin (6000 nM) and test compound or vehicle. The dose of test compound
was equal to 10x the Ki value obtained from our competitive radioligand binding studies,
such that 90% of the binding sites are occupied. After cells, test compound (or vehicle) and
forskolin (or vehicle) were incubated for 15 min, cells were lysed using 20
(provided with the kit) and mixed for 15 min at room temperature. A cAMP Detection
Solution (40 L) was added to each well, gently mixed for 60 s and incubated at room
temperature for 20 min. The Kinase-Glo Solution was added (40 L) to terminate the PKA
µL lysis buffer
µ
µ
reaction. The reaction mixture was gently mixed for 60 s and then incubated at room tem-
perature for 10 min. The remaining ATP was detected via a luciferase reaction. The plates
were read using an Enspire Alpha 2390 Multilabel Reader/Luminometer. Haloperidol
(200 nM) and quinpirole (10,000 nM) was used as a prototypic reference antagonist and full
agonist, respectively.
4.4.2. β-Arrestin Binding Assay
The
according to the manufacturer’s instructions. PathHunter® eXpress
are engineered to co-express the ProLink (PK) tagged GPCR and the Enzyme Acceptor
(EA) tagged -Arrestin. Activation of the GPCR-PK induces -Arrestin-EA recruitment,
forcing complementation of the two -galactosidase enzyme fragments (EA and PK). The
β
-arrestin binding assay was performed using a DiscoverX Pathhunter® kit
-Arrestin GPCR cells
β
™
β
β
β
resulting functional enzyme hydrolyzes substrate to generate a chemiluminescent signal.
DRD3-U2OS cells were seeded according to kit instructions into white plastic 96-well
plates (provided with the kit) 48 h prior to the assay in a volume of 100 µL/well using
the Cell Plating Reagent (CPR) provided. Vehicle or test drug, diluted in CPR, was added
to the designated wells and incubated for 90 min at 37 ◦C. Working detection solution (a
component provided with the kit) was added to the wells and incubated for 1 h in the dark
at room temperature. As discussed for the cyclase assay, an Enspire Alpha 2390 Multilabel

Molecules 2021, 26, 3182
13 of 16
Reader/Luminometer was used to detect the luminescent signal with haloperidol and
quinpirole used as reference antagonist and full agonist, respectively.
4.5. In-Vivo Studies
The treatment of the animals and the experimental procedures were approved by
the UNTHSC Institutional Animal Care and Use Committee (IACUC). Animal care and
housing were in adherence with the conditions set forth in the “Guide for the Care and
Use of Laboratory Animals” (Institute of Laboratory Animal Resources on Life Sciences,
National Research Council, 1996).
4.5.1. Head Twitch Response
Upon arrival DBA/2J mice (Jackson Labs) were allowed to acclimate for at least
one week prior to testing. Mice were housed at
access to food and fresh water. The protocol for the HTR assessment has been previously
reported [32]. Briefly, on the day of testing mice were weighed and placed individually
≤
4 animals per cage with unlimited
in an open-ended Plexiglas cylinder (21
×
34 cm) with a clean paper towel on the floor
in a dimly lighted room. Animals were allowed to habituate to the cylinder for 10 min
prior to the intraperitoneal (i.p.) injection of vehicle (90% sterile deionized water and 10%
dimethylsulfoxide (DMSO: Sigma) in sterile deionized water) or test drug (10 mg/kg). Five
minutes later DOI (5 mg/kg) was administered, and the mouse was immediately returned
to the cylinder.
The mice exhibited various responses to DOI administration including a vertical
jerking movement. However, a head twitch was defined as a rapid movement of the head,
without the involvement of the front paws during grooming. We estimate that the HTR
lasted approximately 0.6 s. At least two observers counted the number of head twitches by
visual examination and the number of head twitches was recorded in 5-min cumulative
intervals. The data points are presented as the mean values obtained by two observers.
The effect of Group was assessed using two-way analysis of variance (ANOVA) with
Time as the repeated measure. The data was further analyzed at each time point with a
one-way ANOVA with Group as the factor followed by planned individual comparisons
between different groups using a single degree-of-freedom F test involving the error term
from the overall ANOVA when the Time and Group interaction was significant. The alpha
level was set at 0.05 and Systat 13 statistical package was used.
4.5.2. AIMs Studies
The Abnormal Involuntary Movement (AIMs) studies were performed using male
Sprague-Dawley rats that were unilaterally lesioned, using injections of 6-hydroxydopamine
(6-OHDA) in the medial forebrain bundle (MFB) by the commercial vendor (Charles River
Laboratories). Upon arrival to our vivarium, the lesioned rats were housed under a 12-h
light: 12-h dark cycle. The animals were housed singly with unlimited access to food
and water. 8 mg/kg L-dopa with 8 mg/kg benserazide was administered to each rat as a
daily i.p. injection for 21 consecutive days to induce the development of dyskinesia-like
movements. Benserazide was included because it is a peripherally-acting aromatic L-amino
acid decarboxylase inhibitor which prevents the peripheral metabolism of L-dopa. The
L-dopa/benserazide solutions were dissolved in water. Test drug (compound 6a) was
prepared using 90% sterile water with 10% DMSO.
8 mg/kg of L-dopa combined with 8 mg/kg benserazide was administered via in-
traperitoneal injection followed by either the vehicle control or test drug (compound 6a
,
10 mg/kg). Experiments were designed such that animals received test drug only once per
week. Throughout the course of these studies each animal received a minimum of one dose
of L-dopa/benserazide (8 mg/kg each) per week to maintain the involuntary movements.
AIMs ratings were performed as previously described [31,38,52]. The severity of the
AIMs was quantified using lesioned rats that were observed individually in their home
cages at 15 min intervals, starting 15 min after the injection of L-dopa for approximately 2 h.

Molecules 2021, 26, 3182
14 of 16
The AIMs were scored in four categories: (1) axial AIMs, including dystonic or choreiform
torsion of the trunk and neck towards the side contralateral to the lesion; (2) limb AIMs,
including jerky and/or dystonic movements of the forelimb contralateral to the lesion;
(3) orolingual AIMs, including twitching of orofacial muscles with empty masticatory
movements and protrusion of the tongue towards the side contralateral to the lesion and
(4) locomotive AIMs, including increased locomotion with contralateral side bias. Each of
the four categories were scored on a severity scale from 0 to 4, where 0 = absent, 1 = present
for less than half of the observation time, 2 = present for more than half of the observation
time, 3 = present all the time but suppressible by external stimuli and 4 = present all the
time and not suppressible by external stimuli. For these experiments the external stimuli
that was used was gentle tapping on the cage with a pencil.
The change in crossovers from controls was calculated for each test compound dosage
group by subtracting the average number of crossovers of the respective vehicle group
from the number of crossovers of individual subjects in the test compound dosage groups.
The latter measure is graphed to illustrate the effects of the compounds on locomotion.
The effect of Group was assessed using two-way analysis of variance (ANOVA) with
time as the repeated measure. The data was further analyzed at each time point with a
one-way ANOVA with Group as the factor. The alpha level was set at 0.05 and Systat
13 statistical package was used.
Supplementary Materials: The following are available online, procedure of synthesis; chemical
analysis of synthesized compounds (1H, 13 C NMR, and Mass); Figure S1: representative examples of
competitive radioligand binding studies for human D2 and D3 dopamine receptors (compound 6a
–c
and 7a–c).
Author Contributions: Conceptualization, R.H.M. and R.R.L.; methodology, B.L., M.T., S.A.G., N.S.
and T.M.; software, B.L., M.T. and R.R.L.; validation, R.H.M. and R.R.L.; formal analysis, B.L., R.H.M.
and R.R.L.; investigation, R.H.M. and R.R.L.; resources, R.H.M. and R.R.L.; data curation, R.H.M.
and R.R.L.; writing—original draft preparation, B.L., R.H.M., M.T. and R.R.L.; writing—review and
editing, R.H.M., M.T. and R.R.L.; visualization, R.H.M.; supervision, R.H.M. and R.R.L.; project
administration, R.H.M. and R.R.L.; funding acquisition, R.H.M. and R.R.L. All authors have read and
agreed to the published version of the manuscript.
Funding: This research was funded by National Institute on Drug Abuse, grant number, DA029840
(R.H.M.) and DA023957 (R.R.L.).
Institutional Review Board Statement: This study was conducted according to the guidelines of
the Declaration of Helsinki and approved by the Institutional Review Board of the University of
North Texas Health Science, protocol codes 2017-0006 and 2019-0008 (approved 3 July 2017 and 6
June 2019, respectively).
Informed Consent Statement: Not applicable.
Data Availability Statement: The article contains complete data used to support the findings of
this study.
Conflicts of Interest: The authors declare no conflict of interest.
Sample Availability: Samples of the compounds described in this paper are available from the authors.
References
1.
2.
3.
4.
5.
Ustione, A.; Piston, D.W. Dopamine synthesis and D3 receptor activation in pancreatic beta-cells regulates insulin secretion and
intracellular [Ca2+] oscillations. Mol. Endocrinol. 2012, 26, 1928–1940. [CrossRef] [PubMed]
Jose, P.A.; Soares-da-Silva, P.; Eisner, G.M.; Felder, R.A. Dopamine and G protein-coupled receptor kinase 4 in the kidney: Role in
blood pressure regulation. Biochim. Biophys. Acta 2010, 1802, 1259–1267. [CrossRef] [PubMed]
Basu, S.; Dasgupta, P.S. Dopamine, a neurotransmitter, influences the immune system. J. Neuroimmunol. 2000, 102, 113–124.
[CrossRef]
Toth, B.E.; Vecsernyes, M.; Zelles, T.; Kadar, K.; Nagy, G.M. Role of peripheral and brain-derived dopamine (DA) in immune
regulation. Adv. Neuroimmune Biol. 2012, 3, 111–155. [CrossRef]
Roeper, J. Dissecting the diversity of midbrain dopamine neurons. Trends Neurosci. 2013, 36, 336–342. [CrossRef]

Molecules 2021, 26, 3182
15 of 16
6.
7.
Jaber, M.; Robinson, S.W.; Missale, C.; Caron, M.G. Dopamine receptors and brain function. Neuropharmacology 1996, 35, 1503–1519.
[CrossRef]
Chien, E.Y.; Liu, W.; Zhao, Q.; Katritch, V.; Han, G.W.; Hanson, M.A.; Shi, L.; Newman, A.H.; Javitch, J.A.; Cherezov, V.; et al.
Structure of the human dopamine D3 receptor in complex with a D2/D3 selective antagonist. Science 2010, 330, 1091–1095.
[CrossRef]
8.
9.
Wang, S.; Wacker, D.; Levit, A.; Che, T.; Betz, R.M.; McCorvy, J.D.; Venkatakrishnan, A.J.; Huang, X.P.; Dror, R.O.; Shoichet, B.K.;
et al. D4 dopamine receptor high-resolution structures enable the discovery of selective agonists. Science 2017, 358, 381–386.
[CrossRef] [PubMed]
Wang, S.; Che, T.; Levit, A.; Shoichet, B.K.; Wacker, D.; Roth, B.L. Structure of the D2 dopamine receptor bound to the atypical
antipsychotic drug risperidone. Nature 2018, 555, 269–273. [CrossRef] [PubMed]
10. Yin, J.; Chen, K.M.; Clark, M.J.; Hijazi, M.; Kumari, P.; Bai, X.C.; Sunahara, R.K.; Barth, P.; Rosenbaum, D.M. Structure of a D2
dopamine receptor-G-protein complex in a lipid membrane. Nature 2020, 584, 125–129. [CrossRef]
11. Kebabian, J.W.; Greengard, P. Dopamine-sensitive adenyl cyclase: Possible role in synaptic transmission. Science 1971, 174,
1346–1349. [CrossRef] [PubMed]
12. Monsma, F.J., Jr.; Mahan, L.C.; McVittie, L.D.; Gerfen, C.R.; Sibley, D.R. Molecular cloning and expression of a D1 dopamine
receptor linked to adenylyl cyclase activation. Proc. Natl. Acad. Sci. USA 1990, 87, 6723–6727. [CrossRef]
13. Corvol, J.C.; Valjent, E.; Pascoli, V.; Robin, A.; Stipanovich, A.; Luedtke, R.R.; Belluscio, L.; Girault, J.A.; Herve, D. Quantitative changes
in Galphaolf protein levels, but not D1 receptor, alter specifically acute responses to psychostimulants. Neuropsychopharmacology 2007
,
32, 1109–1121. [CrossRef] [PubMed]
14. Neve, K.A.; Seamans, J.K.; Trantham-Davidson, H. Dopamine receptor signaling. J. Recept. Signal Transduct. Res. 2004, 24, 165–205.
[CrossRef]
15. Allen, J.A.; Yost, J.M.; Setola, V.; Chen, X.; Sassano, M.F.; Chen, M.; Peterson, S.; Yadav, P.N.; Huang, X.P.; Feng, B.; et al. Discovery
of β-arrestin-biased dopamine D2 ligands for probing signal transduction pathways essential for antipsychotic efficacy. Proc. Natl.
Acad. Sci. USA 2011, 108, 18488–18493. [CrossRef]
16. Beom, S.; Cheong, D.; Torres, G.; Caron, M.G.; Kim, K.M. Comparative studies of molecular mechanisms of dopamine D2 and D3
receptors for the activation of extracellular signal-regulated kinase. J. Biol. Chem. 2004, 279, 28304–28314. [CrossRef] [PubMed]
17. Navarro, G.; Moreno, E.; Bonaventura, J.; Brugarolas, M.; Farre, D.; Aguinaga, D.; Mallol, J.; Cortes, A.; Casado, V.; Lluis, C.; et al.
Cocaine inhibits dopamine D2 receptor signaling via sigma-1-D2 receptor heteromers. PLoS ONE 2013, 8, e61245. [CrossRef]
[PubMed]
18. Liu, Y.; Buck, D.C.; Neve, K.A. Novel interaction of the dopamine D2 receptor and the Ca2+ binding protein S100B: Role in D2
receptor function. Mol. Pharmacol. 2008, 74, 371–378. [CrossRef]
19. Lane, J.R.; Sexton, P.M.; Christopoulos, A. Bridging the gap: Bitopic ligands of G-protein-coupled receptors. Trends Pharmacol. Sci.
2013, 34, 59–66. [CrossRef] [PubMed]
20. Rangel-Barajas, C.; Malik, M.; Mach, R.H.; Luedtke, R.R. Pharmacological modulation of abnormal involuntary DOI-induced head
twitch response movements in male DBA/2J mice: II. Effects of D3 dopamine receptor selective compounds. Neuropharmacology
2015, 93, 179–190. [CrossRef]
21. Hayatshahi, H.S.; Xu, K.; Griffin, S.A.; Taylor, M.; Mach, R.H.; Liu, J.; Luedtke, R.R. Analogues of arylamide phenylpiperazine
ligands to investigate the factors influencing D3 dopamine receptor bitropic binding and receptor subtype selectivity. ACS Chem.
Neurosci. 2018, 9, 2972–2983. [CrossRef] [PubMed]
22. Chen, P.J.; Taylor, M.; Griffin, S.A.; Amani, A.; Hayatshahi, H.; Korzekwa, K.; Ye, M.; Mach, R.H.; Liu, J.; Luedtke, R.R.; et al.
Design, synthesis, and evaluation of N-(4-(4-phenyl piperazin-1-yl)butyl)-4-(thiophen-3-yl)benzamides as selective dopamine D3
receptor ligands. Bioorg. Med. Chem. Lett. 2019, 29, 2690–2694. [CrossRef] [PubMed]
23. Lane, J.R.; Donthamsetti, P.; Shonberg, J.; Draper-Joyce, C.J.; Dentry, S.; Michino, M.; Shi, L.; Lopez, L.; Scammells, P.J.; Capuano,
B.; et al. A new mechanism of allostery in a G protein-coupled receptor dimer. Nat. Chem. Biol. 2014, 10, 745–752. [CrossRef]
24. Newman, A.H.; Beuming, T.; Banala, A.K.; Donthamsetti, P.; Pongetti, K.; LaBounty, A.; Levy, B.; Cao, J.; Michino, M.; Luedtke,
R.R.; et al. Molecular determinants of selectivity and efficacy at the dopamine D3 receptor. J. Med. Chem. 2012, 55, 6689–6699.
[CrossRef] [PubMed]
25. Furman, C.A.; Roof, R.A.; Moritz, A.E.; Miller, B.N.; Doyle, T.B.; Free, R.B.; Banala, A.K.; Paul, N.M.; Kumar, V.; Sibley, C.D.;
et al. Investigation of the binding and functional properties of extended length D3 dopamine receptor-selective antagonists. Eur.
Neuropsychopharmacol. 2015, 25, 1448–1461. [CrossRef] [PubMed]
26. Keck, T.M.; John, W.S.; Czoty, P.W.; Nader, M.A.; Newman, A.H. Identifying medication targets for psychostimulant addiction:
Unraveling the dopamine D3 receptor yypothesis. J. Med. Chem. 2015, 58, 5361–5380. [CrossRef]
27. Mach, R.H.; Luedtke, R.R. Challenges in the development of dopamine D2- and D3-selective radiotracers for PET imaging studies.
J. Label. Comp. Radiopharm. 2018, 61, 291–298. [CrossRef]
28. Pilla, M.; Perachon, S.; Sautel, F.; Garrido, F.; Mann, A.; Wermuth, C.G.; Schwartz, J.C.; Everitt, B.J.; Sokoloff, P. Selective inhibition
of cocaine-seeking behaviour by a partial dopamine D3 receptor agonist. Nature 1999, 400, 371–375. [CrossRef] [PubMed]
29. Bettinetti, L.; Schlotter, K.; Hubner, H.; Gmeiner, P. Interactive SAR studies: Rational discovery of super-potent and highly
selective dopamine D3 receptor antagonists and partial agonists. J. Med. Chem. 2002, 45, 4594–4597. [CrossRef]

Molecules 2021, 26, 3182
16 of 16
30. Chu, W.H.; Tu, Z.; McElveen, E.; Xu, J.B.; Taylor, M.; Luedtke, R.R.; Mach, R.H. Synthesis and in vitro binding of N-phenyl
piperazine analogs as potential dopamine D-3 receptor ligands. Bioorg. Med. Chem. 2005, 13, 77–87. [CrossRef] [PubMed]
31. Kumar, R.; Riddle, L.; Griffin, S.A.; Grundt, P.; Newman, A.H.; Luedtke, R.R. Evaluation of the D3 dopamine receptor selective
antagonist PG01037 on L-dopa-dependent abnormal involuntary movements in rats. Neuropharmacology 2009, 56, 944–955.
[CrossRef] [PubMed]
32. Rangel-Barajas, C.; Malik, M.; Taylor, M.; Neve, K.A.; Mach, R.H.; Luedtke, R.R. Characterization of [3H]LS-3-134, a novel
arylamide phenylpiperazine D3 dopamine receptor selective radioligand. J. Neurochem. 2014, 131, 418–431. [CrossRef]
33. Malik, M.; Rangel-Barajas, C.; Mach, R.H.; Luedtke, R.R. The effect of the sigma-1 receptor selective compound LS-1-137 on the
DOI-induced head twitch response in mice. Pharmacol. Biochem. Behav. 2016, 148, 136–144. [CrossRef]
34. Reilly, S.W.; Mach, R.H. Pd-Catalyzed synthesis of piperazine scaffolds under aerobic and solvent-free conditions. Org. Lett. 2016
,
18, 5272–5275. [CrossRef]
35. Cheung, T.H.; Loriaux, A.L.; Weber, S.M.; Chandler, K.N.; Lenz, J.D.; Schaan, R.F.; Mach, R.H.; Luedtke, R.R.; Neisewander,
J.L. Reduction of cocaine self-administration and D3 receptor-mediated behavior by two novel dopamine D3 receptor-selective
partial agonists, OS-3-106 and WW-III-55. J. Pharmacol. Exp. Ther. 2013, 347, 410–423. [CrossRef]
36. Powell, G.L.; Bonadonna, J.P.; Vannan, A.; Xu, K.Y.; Mach, R.H.; Luedtke, R.R.; Neisewander, J.L. Dopamine D3 receptor partial
agonist LS-3-134 attenuates cocaine-motivated behaviors. Pharmacol. Biochem. Behav. 2018, 171, 46–53. [CrossRef] [PubMed]
37. Cenci, M.A. Dopamine dysregulation of movement control in L-DOPA-induced dyskinesia. Trends Neurosci. 2007, 30, 236–243.
[CrossRef] [PubMed]
38. Riddle, L.R.; Kumar, R.; Griffin, S.A.; Grundt, P.; Newman, A.H.; Luedtke, R.R. Evaluation of the D3 dopamine receptor selective
agonist/partial agonist PG01042 on L-dopa dependent animal involuntary movements in rats. Neuropharmacology 2011, 60,
284–294. [CrossRef] [PubMed]
39. Neisewander, J.L.; Cheung, T.H.; Pentkowski, N.S. Dopamine D3 and 5-HT1B receptor dysregulation as a result of psychos-
timulant intake and forced abstinence: Implications for medications development. Neuropharmacology 2014, 76 Pt B, 301–319.
[CrossRef]
40. Tu, Z.; Li, S.; Cui, J.; Xu, J.; Taylor, M.; Ho, D.; Luedtke, R.R.; Mach, R.H. Synthesis and pharmacological evaluation of
fluorine-containing D3 dopamine receptor ligands. J. Med. Chem. 2011, 54, 1555–1564. [CrossRef] [PubMed]
41. Doot, R.K.; Dubroff, J.G.; Labban, K.J.; Mach, R.H. Selectivity of probes for PET imaging of dopamine D3 receptors. Neurosci. Lett.
2019, 691, 18–25. [CrossRef]
42. Taylor, M.; Grundt, P.; Griffin, S.A.; Newman, A.H.; Luedtke, R.R. Dopamine D3 receptor selective ligands with varying intrinsic
efficacies at adenylyl cyclase inhibition and mitogenic signaling pathways. Synapse 2010, 64, 251–266. [CrossRef] [PubMed]
43. Kenakin, T. New concepts in pharmacological efficacy at 7TM receptors: IUPHAR review 2. Br. J. Pharmacol. 2013, 168, 554–575.
[CrossRef] [PubMed]
44. Kobilka, B.K.; Deupi, X. Conformational complexity of G-protein-coupled receptors. Trends Pharmacol. Sci. 2007, 28, 397–406.
[CrossRef]
45. Kenakin, T. Drug efficacy at G protein-coupled receptors. Annu. Rev. Pharmacol. Toxicol. 2002, 42, 349–379. [CrossRef]
46. Bock, A.; Bermudez, M.; Krebs, F.; Matera, C.; Chirinda, B.; Sydow, D.; Dallanoce, C.; Holzgrabe, U.; De Amici, M.; Lohse, M.J.;
et al. Ligand binding ensembles determine graded agonist efficacies at a G protein-coupled receptor. J. Biol. Chem. 2016, 291,
16375–16389. [CrossRef]
47. Bock, A.; Schrage, R.; Mohr, K. Allosteric modulators targeting CNS muscarinic receptors. Neuropharmacology 2018, 136, 427–437.
[CrossRef]
48. Reinecke, B.A.; Wang, H.; Zhang, Y. Recent advances in the drug discovery and development of dualsteric/bitopic activators of G
protein-coupled receptors. Curr. Top. Med. Chem. 2019, 19, 2378–2392. [CrossRef]
49. Luedtke, R.R.; Freeman, R.A.; Boundy, V.A.; Martin, M.W.; Huang, Y.; Mach, R.H. Characterization of 125I-IABN, a novel
azabicyclononane benzamide selective for D2-like dopamine receptors. Synapse 2000, 38, 438–449. [CrossRef]
50. Kharkwal, G.; Brami-Cherrier, K.; Lizardi-Ortiz, J.E.; Nelson, A.B.; Ramos, M.; Del Barrio, D.; Sulzer, D.; Kreitzer, A.C.; Borrelli, E.
Parkinsonism driven by antipsychotics originates from dopaminergic control of striatal cholinergic interneurons. Neuron 2016, 91,
67–78. [CrossRef]
51. Cheng, Y.; Prusoff, W.H. Relationship between the inhibition constant (K1) and the concentration of inhibitor which causes 50 per
cent inhibition (I50) of an enzymatic reaction. Biochem. Pharmacol. 1973, 22, 3099–3108. [CrossRef] [PubMed]
52. Dekundy, A.; Lundblad, M.; Danysz, W.; Cenci, M.A. Modulation of L-DOPA-induced abnormal involuntary movements by
clinically tested compounds: Further validation of the rat dyskinesia model. Behav. Brain Res. 2007, 179, 76–89. [CrossRef]
[PubMed]
