Optical Properties of Fullerene/Ferrocene
A R T I C L E S
linear response (MLR) scheme for the time-dependent (TD) DFT.20
All the calculations were performed using the ABINIT code.21 The
calculation details are described in Supporting Information.
As a crystalline state, C60/Fc hybrid was first reported by Crane
et al. in 1992;18 they determined the crystal structure by
assuming motionless C60 molecules. These authors inferred that
Fc does not donate fully its electron to C60 and that contribution
of the weak intermolecular charge-transfer (CT) interaction to
the stability of the hybrid is very small.18 However, the
electronic properties of the hybrid are not still clear.
We herein report a simple method for the preparation of C60/
Fc hybrid hexagonal nanosheets with a size of ca. 9 µm by a
liquid-liquid interfacial precipitation (LLIP) method. This
method was introduced by our group for the preparation of C60
nanowhiskers at a toluene/isopropyl alcohol (IPA) interface.2a
In this paper, we also discuss the CT interaction between C60
and Fc in nanosheets on the basis of CT-band observations in
the solid state. Interestingly, the CT band disappears after heat
treatment, which is accompanied by the sublimation of Fc. After
the heat treatment, face-centered cubic (fcc) C60 nanosheets are
observed to be left behind.
Results and Discussion
Preparation and Structure of C60/Fc Nanosheets. In the
preparation of C60/Fc nanosheets by the LLIP method through
the formation of an interface between IPA and toluene solution
containing C60 and Fc, it is very interesting to note that the
concentration of Fc in toluene must be more than 30 mg/mL.
When the concentration of Fc is less than 20 mg/mL, C60
nanowhiskers are formed and Fc molecules just cover the
external surface of the C60 nanowhiskers, as explained in our
previous report.22 This indicates that, at low Fc concentrations,
Fc molecules cannot enter the C60 crystals due to the strong
interaction between the C60 molecules. Consequently, C60
nanowhiskers are surrounded by Fc molecules. However, at high
Fc concentrations, Fc and C60 form precipitates with quite
different morphologies. These precipitates are found to be C60/
Fc hybrid hexagonal nanosheets in the present study.
Experimental Section
SEM images of C60/Fc precipitates prepared at high Fc
concentrations are shown in Figure 1. These representative
images show the hexagonal morphology of the precipitates,
which are highly transparent to electron beams. The average
size of the precipitates is 9.1 ( 6.2 µm and the thickness is
about 250-550 nm, confirming the formation of hexagonal
nanosheets. It is very interesting to note that many self-standing
nanosheets are observed in the SEM images in Figure 1,
indicating rigid crystalline materials. The morphology of these
nanosheets is very similar to that of hexagonal C60 nanosheets
prepared solely from C60 molecules using the LLIP method,
which was reported by our group recently.6
To locate the doped Fc in the nanosheets, a STEM mapping
analysis was carried out (Figure 2). Carbon and iron atoms were
detected in the nanosheets, as shown in Figure 2, panels b and
c, respectively. The distribution and concentration of carbon
and iron were uniform in the nanosheets. This result confirms
the fine dispersion of iron atoms in the nanosheets, indicating
that the nanosheets are C60/Fc nanosheets.
The C60/Fc nanosheets were prepared by the LLIP method, in
which an interface containing C60 and excess Fc was formed
between IPA and toluene. An amount of 3 mL of C60-saturated
toluene was taken in a 10 mL glass bottle and 120 mg of Fc was
added to this solution. After 10-min ultrasonication at room
temperature, the C60/Fc solution was cooled to 10 °C in an
ice-water bath. To this toluene solution, 3 mL of IPA was added
slowly, and the mixture was maintained at 10 °C for 5 min without
disturbing the interface. The resulting mixture was stored at 10 °C
for 24 h for the growth of C60/Fc nanosheets. C60/Fc nanosheets
were obtained by filtering the solution and were heated at 80 °C
for 15 min to remove the excess Fc.18
The structure and morphology of the obtained nanosheets were
characterized using scanning transmission electron microscopy
(STEM; JEOL JEM-2100F, 200 kV), field emission scanning
electron microscopy (FE-SEM; Hitachi S-4800, 15 kV, FE-SEM;
JEOL JSM-6700F, 5 kV), and a micro-Raman system (NRS-3100,
JASCO, Japan) equipped with a semiconducting laser with a
wavelength of 532 nm. Diffuse reflectance spectra of the nanosheets
were measured by a UV-vis-NIR spectroscope (V-570, JASCO,
Japan) equipped with an integrating sphere. The prepared C60/Fc
nanosheets were taken on a quartz plate and dried at room
temperature prior to the measurement of the spectra. UV-vis-NIR
spectra of C60 and Fc powder samples were also measured in a
similar manner.
Figure 3 shows an HR-TEM image of C60/Fc nanosheets. A
clear lattice structure is observed. The distance between lattices,
d, is calculated to be 0.90 nm.
X-ray diffraction (XRD) patterns of the C60 powder and C60/
Fc nanosheets are shown in Figure 4. The XRD pattern of the
C60/Fc nanosheets is quite different from that of the C60 powder,
but identical to that of triclinic C60(Fc)2 prepared directly from
a solution of C60 in molten Fc.23 This observation indicates that
the C60/Fc nanosheets contain C60(Fc)2 units, which have two
Fc molecules near every C60 molecule.18 The inset in Figure 4
shows the selected-area electron diffraction pattern of a C60/Fc
nanosheet. The observed pattern is indexed for the (010) and
Calculations were carried out for ascertaining the structural
stability and determining the electronic states within the local
density approximation (LDA)19 to the density functional theory
(DFT). A plane wave basis set and a pseudopotential scheme were
adopted for the crystal system. For determining the CT excitation
energy, we used the Slater transition (ST) method and the modified
(12) Hauke, F.; Hirsch, A.; Liu, S. G.; Echegoyen, L.; Swartz, A.; Luo,
C. P.; Guldi, D. M. ChemPhysChem 2002, 3, 195–205.
j
(210) planes. The d value calculated from the HR-TEM image
(13) Guldi, D. M.; Rahman, G. M. A.; Marczak, R.; Matsuo, Y.; Yamanaka,
M.; Nakamura, E. J. Am. Chem. Soc. 2006, 128, 9420–9427.
(14) Marczak, R.; Wielopolski, M.; Gayathri, S. S.; Guldi, D. M.; Matsuo,
Y.; Matsuo, K.; Tahara, K.; Nakamura, E. J.Am. Chem. Soc. 2008,
130, 16207–16215.
in Figure 3 is indicated as the (010) plane.
(20) (a) Hu, C.; Sugino, O.; Miyamoto, Y. Phys. ReV. A 2006, 74, 032508.
(b) Hu, C.; Sugino, O. J. Chem. Phys. 2007, 126, 074112.
(21) Gonze, X.; Beuken, J.-M.; Caracas, R.; Detraux, F.; Fuchs, M.;
Rignanese, G.-M.; Sindic, L.; Verstraete, M.; Zerah, G.; Jollet, F.;
Torrent, M.; Roy, A.; Mikami, M.; Ghosez, Ph.; Raty, J.-Y.; Allan,
D. C. Comput. Mater. Sci. 2002, 25, 478–492.
(15) Even, M.; Heinrich, B.; Guillon, D.; Guldi, D. M.; Prato, M.;
Deschenaux, R. Chem.-Eur. J. 2001, 7, 2595–2604.
(16) Campidelli, S.; Vazquez, E.; Milic, D.; Prato, M.; Barbera, J.; Guldi,
D. M.; Marcaccio, M.; Paolucci, D.; Paolucci, F.; Deschenaux, R. J.
Mater. Chem. 2004, 14, 1266–1272.
(17) Matsuo, Y.; Muramatsu, A.; Kamikawa, Y.; Kato, T.; Nakamura, E.
J. Am. Chem. Soc. 2006, 128, 9586–9587.
(22) Wakahara, T.; Sathish, M.; Miyazawa, K.; Sasaki, T. Nano 2008, 3,
351–354.
(18) Crane, J. D.; Hitchcock, P. B.; Kroto, H. W.; Taylor, R.; Walton,
D. R. M. J. Chem. Soc., Chem. Commun. 1992, 1764–1765.
(19) Perdew, J. P.; Wang, Y. Phys. ReV. B 1992, 45, 13244–13249.
(23) Espeau, P.; Barrio, M.; Lopez, D. O.; Tamarit, J. L1.; Ceolin, R.;
Allouchi, H.; Agafonov, V.; Masin, F.; Szwarc, H. Chem. Mater. 2002,
14, 321–326.
9
J. AM. CHEM. SOC. VOL. 131, NO. 29, 2009 9941
