Palladium(II)-Catalyzed meta-C-H Olefination: Constructing Multisubstituted Arenes through Homo-Diolefination and Sequential Hetero-Diolefination

Article abstract of DOI:10.1002/anie.201503112

Divinylbenzene derivatives represent an important class of molecular building blocks in organic chemistry and materials science. Reported herein is the palladium-catalyzed synthesis of divinylbenzenes by meta-C-H olefination of sulfone-based arenes. Successful sequential olefinations in a position-selective manner provided a novel route for the synthesis of hetero-dialkenylated products, which are difficult to access using conventional methods. Additionally, 1,3,5-trialkenylated compounds can be generated upon successful removal of the directing group. Jockeying for position: Reported herein is the palladium-catalyzed synthesis of mono- and divinylbenzenes by meta-C-H olefination of benzyl sulfones. Successful sequential olefinations in a position-selective manner provided a novel route for the synthesis of hetero-dialkenylated products, which are difficult to access using conventional methods. DG=directing group.

Full text of DOI:10.1002/anie.201503112

Angewandte
Chemie
International Edition: DOI: 10.1002/anie.201503112
German Edition: DOI: 10.1002/ange.201503112
À
C H Activation
À
Palladium(II)-Catalyzed meta-C H Olefination: Constructing
Multisubstituted Arenes through Homo-Diolefination and Sequential
Hetero-Diolefination**
Milan Bera, Arun Maji, Santosh K. Sahoo, and Debabrata Maiti*
Abstract: Divinylbenzene derivatives represent an important
class of molecular building blocks in organic chemistry and
materials science. Reported herein is the palladium-catalyzed
substrates, and that the flexible nature of the sulfonyl (SO2),
compared to carbonyl (CO) moiety, in the scaffold would
enhance the directing power of the nitrile (Scheme 1).[7] We
À
synthesis of divinylbenzenes by meta-C H olefination of
sulfone-based arenes. Successful sequential olefinations in
a position-selective manner provided a novel route for the
synthesis of hetero-dialkenylated products, which are difficult
to access using conventional methods. Additionally, 1,3,5-
trialkenylated compounds can be generated upon successful
removal of the directing group.
Scheme 1. Development of a new scaffold.
À
T
ransition-metal-catalyzed functionalization of arene C H
bonds has been extensively investigated over the last two
decades by using a variety of directing groups (DGs).[1] In the
C H activation realm, directing groups are almost universally
were particularly interested in the synthesis of di-alkenylated
benzylsulfonyl scaffolds because of the importance of dio-
lefinated compounds in organic synthesis and materials
chemistry.[8] However the second olefination reaction is
expected to be challenging since the electronic and steric
properties of mono-olefinated species is completely different
from those of the starting materials.[9] Such challenges were
overcome and we herein disclose an approach for meta-
selective homo-diolefination and sequential hetero-diolefina-
À
ortho-selective.[2] Compared to ortho-functionalization, the
related meta-selective reactions pose a significant challenge.
In this regard, examples of meta-selective functionalization
have only recently been reported and are based on steric and
electronic bias.[3] An alternate template-based approach,
initiated by the group of Yu[4] and subsequently extended by
Tan and co-workers[5] as well as our group,[6] demonstrated
meta-selective functionalization in the presence of a suitable
À
tion of C H bonds of sulfone-based arenes (Scheme 2).
[10]
À
À
directing group. These meta-selective C H functionalizations
are usually independent of the substitution pattern and
electronic nature of the substrate. Importantly, activation of
meta C H bonds hinges upon the combined use of a weakly
coordinating nitrile-based template with a protected amino-
acid ligand.
Although ortho-C H olefination of benzyl sulfonamides
and ortho-selective hetero-diolefinations have been docu-
mented,[9] meta-selective hetero-diolefination is yet to be
reported.
À
Initially, benzylsulfonyl ester derivatives were tested with
various of nitrile-based directing groups (Scheme 3; for
structures see Figure 1).[6,11] Upon optimization, 2-hydroxy-
benzonitrile successfully delivered the diolefination product
During our previous work on palladium-catalyzed meta-
C H olefination with arylacetic acid derived scaffolds,
[6]
À
a number of limitations were encountered: 1) unsuccessful
diolefination, 2) transesterification of the directing group
with the solvent hexafluoroisopropanol (HFIP), and 3) mod-
erate to good meta-selectivity. Some of these drawbacks
probably originate from the conformational and electronic
bias of arylacetic acid based substrates. We reasoned that
a more electron-withdrawing SO2 group may reduce electron
density at the ortho- and para-position of the sulfone-based
[*] Dr. M. Bera, A. Maji, Dr. S. K. Sahoo, Prof. D. Maiti
Department of Chemistry, Indian Institute of Technology Bombay
Powai, Mumbai-400 076 (India)
E-mail: dmaiti@chem.iitb.ac.in
[**] This activity is supported by SERB, India (SB/S5/GC-05/2013).
Financial support was received from DST under the Fast Track
Scheme (M.B.), CSIR (A.M.), and IIT-B (S.S.).
Supporting information for this article is available on the WWW
under http://dx.doi.org/10.1002/anie.201503112.
Scheme 2. Outline of this work.
Angew. Chem. Int. Ed. 2015, 54, 8515 –8519
ꢀ 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
8515

.
Angewandte
Communications
Scheme 3. Development of directing group. Yields and selectivities
1
determined by H NMR analysis of crude reaction mixture.
Scheme 5. Advantages of the present scaffold.
Figure 1. X-ray structures[15] of SM1, 1 f, and 4q.
in 88% yield and with high selectivity (meta/other > 20:1).
Further optimization of the reaction parameters delivered
two different catalytic conditions (A: with 10 mol% Pd in
dichloroethane solvent and B: with 2 mol% Pd in HFIP
solvent) for mono-olefination (Scheme 4).[11] The major
Scheme 4. Two protocols for mono-olefination. DCE=1,2-dichloro-
1
ethane. Yields and selectivities determined by H NMR analysis of the
crude reaction mixture.
advantages of the benzylsulfonate (our present scaffold) are
as follows (Scheme 5): 1) the directing group is commercially
available, simple, and has a low molecular weight. Notably,
the templates of both Yu and Tan are synthesized through
five- and four-step procedures, respectively; 2) in general,
selectivity is very high (even for unbiased substrates). In
a number of cases, exclusive mono-olefinated products were
obtained. 3) two different robust conditions were developed
for mono-olefination; 4) the SO2-X unit (DG) can be
Scheme 6. The meta-selective mono-olefination. Yields and selectivi-
ties determined by 1H NMR analysis of crude reaction mixture. See
Figure 1 for X-ray structure.
exclusively (1 f–h). Complete mono-selectivity was also
obtained with both the ortho-methyl- and ortho-chloro-
substituted benzylsulfonyl ester (1i–l) under the reaction
conditions A. The meta-chloro- and fluoro-substituted ben-
zylsulfonyl esters were olefinated selectively at the 5-position
with different olefins (1m–p). In addition, this protocol is
compatible with electron-donating and electron-withdrawing
para substituents such as methyl (1q and 1r), chloro (1s and
1t), and fluoro (1u–1w). All para-substituted benzylsulfonyl
esters produced 10–15% of the diolefination product along
with monoalkenylated products. The 2,6-difluoro sulfonyles-
converted into
a number of interesting groups (see
Schemes 11 and 12).
Different acrylates and a,b-unsaturated ketones produced
the desired mono-olefination products in moderate to good
yields (1a–e; Scheme 6) with excellent meta-selectivity (meta/
others > 20:1). Olefins with amide, phosphonate, and sulfone
moieties resulted in meta-selective mono-olefination products
8516
www.angewandte.org
ꢀ 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Angew. Chem. Int. Ed. 2015, 54, 8515 –8519

Angewandte
Chemie
Scheme 7. Substrate scope with internal olefins. Yields and selectiv-
ities determined by 1H NMR analysis of crude reaction mixture.
ter was olefinated to exclusively afford the meta-selective
mono-olefinated products (1x and 1y).
Interestingly under the reaction conditions C (Scheme 7),
di-substituted trans-olefins (e.g. fumarate, crotonate, cinna-
mate, and cinnamaldehyde) were successfully employed.[12]
Notably, exclusive mono-selectivities were observed in all the
entries. Although, a mixture of E and Z isomers were
detected, the E isomer was generated as the major product
(2a–c and 2e). With a cis-olefin such as dimethyl maleate,
E isomers were formed exclusively (2d and 2 f). These
phenomena indicate that the stereoselectivity is thermody-
namic in origin.[13]
Similarly, reaction with methacrylate and cyclic trisubsti-
tuted olefins proceeded to provide meta-selective monoallyl
benzene derivatives in good yields under the reaction
conditions B (3a–c; Scheme 8). Formation of these allyl
benzene derivatives could be explained by the regioselective
b-Hb elimination rather than b-Ha elimination.[11,14] Unfortu-
nately this reaction is not compatible with electron-neutral or
electron-rich olefins such as substituted styrenes.
Scheme 9. Substrate scope for homo-diolefination. Yields and selectiv-
ities determined by 1H NMR analysis of crude reaction mixture. See
Figure 1 for X-ray structure.
The trisubstituted cyclic olefins also reacted well under the
reaction conditions C to afford the meta-selective diallylben-
zene derivatives in good yields (4p and 4q).
To obtain sequential olefination in a position-selective
manner, mono-olefinated products were utilized. With the
prefunctionalized olefinated product (Scheme 6), acrylates,
methylvinyl ketone, ethylvinyl ketone, vinylsulfone, vinyl
phosphonate, amide, and disubstituted olefins were incorpo-
rated at the remaining meta-position in an exclusive manner
with good to excellent yields under the reaction conditions C
(5a–p; Scheme 10). Hetero-diolefination reactions by
sequential addition of two different olefins in a one-pot
process gave the desired product (e.g., 5c, 58% and 5k, 52%)
along with formation of other mono-olefinated and homo-
diolefinated products.[11]
Scheme 8. Formation of meta-allyl benzene. Yields and selectivities
determined by H NMR analysis of crude reaction mixture.
The 2-hydroxybenzonitrile group is easily removed by
hydrolysis at room temperature by using KOH in methanol to
produce the meta-substituted diacid 6 in excellent yield
(Scheme 11).
1
We subsequently explored homo-diolefination at the
meta positions under the reaction conditions C (Scheme 9).
Different acrylates, a,b-unsaturated ketones, and disubsti-
tuted internal olefins produced dialkenylated products in
good yields (4a–g). Notably, chloro, fluoro, and methyl
benzylsulfonyl esters gave dialkenylated products (4h–o).
Additionally, the SO2-DG scaffold can be easily cleaved
by a modified Julia olefination. All mono-, di-, and hetero-
diolefinated products, 1a, 4a, and 5c were reacted with
benzaldehyde in presence of LDA at À788C to afford the
corresponding 1,3-divinyl and 1,3,5-trivinylbenzene deriva-
tives, 7, 8, and 9 in good yields (Scheme 12).
Angew. Chem. Int. Ed. 2015, 54, 8515 –8519
ꢀ 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.angewandte.org
8517

.
Angewandte
Communications
Scheme 13. Proposed catalytic cycle.
make a 12-membered cyclophane-like pre-transition state
(A). Because of the high electrophilicity, the nitrile-bound
PdII center is likely to be reactive towards the meta-C H
bond. Formation of the mono-olefinated product E from B
À
Scheme 10. Sequential hetero-diolefination. Yields and selectivities
determined by H NMR analysis of crude reaction mixture.
1
À
will involve 1) C H activation, 2) olefin binding, 3) 1,2-
migratory insertion, and 4) b-hydride elimination.
In summary, we have developed complementary methods
for meta-selective mono-, di-, and sequential hetero-diolefi-
nations of sulfone-based arene motifs with a 2-hydroxyben-
zonitrile template. Substituents are tolerated at all positions
À
on the arene framework. The strategy for sequential meta-C
H olefination provides a novel route for the synthesis of meta-
selective bis(alken)ylated compounds having two different
olefins, compounds which are difficult to access using conven-
tional methods.
Scheme 11. Hydrolysis of directing group.
À
Keywords: C H activation · olefination · palladium · sulfur ·
synthetic methods
How to cite: Angew. Chem. Int. Ed. 2015, 54, 8515–8519
Angew. Chem. 2015, 127, 8635–8639
À
[1] For selected examples on functionalization of arene C H bonds,
see: a) I. Moritani, Y. Fujiwara, Tetrahedron Lett. 1967, 1119;
b) C. Jia, T. Kitamura, Y. Fujiwara, Acc. Chem. Res. 2001, 34,
633; c) D. Alberico, M. E. Scott, M. Lautens, Chem. Rev. 2007,
107, 174; d) I. V. Seregin, V. Gevorgyan, Chem. Soc. Rev. 2007,
36, 1173; e) D.-H. Wang, K. M. Engle, B.-F. Shi, J.-Q. Yu, Science
2010, 327, 315; f) C.-L. Sun, B.-J. Li, Z.-J. Shi, Chem. Rev. 2011,
111, 1293; g) G. Rousseau, B. Breit, Angew. Chem. Int. Ed. 2011,
50, 2450; Angew. Chem. 2011, 123, 2498; h) T. Brückl, R. D.
Baxter, Y. Ishihara, P. S. Baran, Acc. Chem. Res. 2012, 45, 826;
i) S. R. Neufeldt, M. S. Sanford, Acc. Chem. Res. 2012, 45, 936;
j) L. Ackermann, Chem. Rev. 2011, 111, 1315; k) J. Wencel-
Delord, F. Glorius, Nat. Chem. 2013, 5, 369; l) J. Gallardo-
Donaire, R. Martin, J. Am. Chem. Soc. 2013, 135, 9350; m) L.
Zhou, W. Lu, Chem. Eur. J. 2014, 20, 634.
Scheme 12. Modified Julia olefination of 1a, 4a, and 5c. [a] 7a
(Z isomer) 13%, 7b (E isomer) 60%. [b] 8a (Z isomer) 6%, 8b
(E isomer) 64%. [c] 9 (E isomer) 77%, (Z isomer) trace.[11] LDA=
lithium diisopropylamide, THF=tetrahydrofuran.
Kinetic experiments conducted on SM1 to obtain the di-
olefinated product 4a distinctly showed the intermediacy of
the mono-olefinated product 1a.[11] A separate set of studies
for the formation of 4a from the mono-olefinated compound
revealed a first-order rate dependency with respect to 1a.[11]
A proposal on the reaction course is presented in
Scheme 13 on the basis of previous reports.[4–6] The linear
weakly binding nitrile group in the substrate is proposed to
À
[2] For selected reviews on metal-catalyzed directed C H activation
reactions, see: a) S. Murai, Activation of Unreactive Bonds and
Organic Synthesis, Springer, Berlin, 1999; b) G. Dyker, Hand-
À
book of C H Transformations, Wiley-VCH, Weinheim, 2005;
c) R. Giri, B. F. Shi, K. M. Engle, N. Maugel, J. Q. Yu, Chem. Soc.
Rev. 2009, 38, 3242; d) L. Ackermann, R. Vicente, A. R. Kapdi,
8518
www.angewandte.org
ꢀ 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Angew. Chem. Int. Ed. 2015, 54, 8515 –8519

Angewandte
Chemie
Angew. Chem. Int. Ed. 2009, 48, 9792; Angew. Chem. 2009, 121,
9976; e) L. Ackermann, Chem. Commun. 2010, 46, 4866;
f) I. A. I. Mkhalid, J. H. Barnard, T. B. Marder, J. M. Murphy,
J. F. Hartwig, Chem. Rev. 2010, 110, 890; g) C. S. Yeung, V. M.
Dong, Chem. Rev. 2011, 111, 1215; h) C.-L. Sun, B.-J. Li, Z.-J.
Shi, Chem. Rev. 2011, 111, 1293; i) L. McMurray, F. OꢀHara, M. J.
Gaunt, Chem. Soc. Rev. 2011, 40, 1885; j) J. Wencel-Delord, T.
Droge, F. Liu, F. Glorius, Chem. Soc. Rev. 2011, 40, 4740; k) S. H.
Cho, J. Y. Kim, J. Kwak, S. Chang, Chem. Soc. Rev. 2011, 40,
5068; l) P. B. Arockiam, C. Bruneau, P. H. Dixneuf, Chem. Rev.
2012, 112, 5879; m) G. Song, F. Wang, X. Li, Chem. Soc. Rev.
2012, 41, 3651; n) L. Louillat, F. W. Patureau, Chem. Soc. Rev.
2014, 43, 901; o) A. Ros, R. Fernandez, J. M. Lassaletta, Chem.
Soc. Rev. 2014, 43, 3229; p) D. J. Musaev, T. M. Figg, A. L.
Kaledin, Chem. Soc. Rev. 2014, 43, 5009; q) F. Zhang, D. R.
Spring, Chem. Soc. Rev. 2014, 43, 6906; r) J. Schranck, A. Tlili,
M. Beller, Angew. Chem. Int. Ed. 2014, 53, 9426; Angew. Chem.
2014, 126, 9580.
Chataigner, C. Panel, H. GØrard, S.-R. Piettre, Chem. Commun.
2007, 3288.
[8] a) J. H. Burroughes, D. D. C. Bradley, A. R. Brown, R. N. Marks,
K. Mackay, Nature 1990, 347, 539; b) A. C. Grimsdale, K. L.
Chan, R. E. Martin, P. G. Jokisz, A. B. Holmes, Chem. Rev. 2009,
109, 897.
À
[9] For rare examples of sequential C H activation, see: a) N. P.
Grimster, C. Gauntlett, C. R. A. Godfrey, M. J. Gaunt, Angew.
Chem. Int. Ed. 2005, 44, 3125; Angew. Chem. 2005, 117, 3185;
b) A. García-Rubia, R. G. Arrayas, J. C. Carretero, Angew.
Chem. Int. Ed. 2009, 48, 6511; Angew. Chem. 2009, 121, 6633;
c) E. M. Beck, R. Hatley, M. J. Gaunt, Angew. Chem. Int. Ed.
2008, 47, 3004; Angew. Chem. 2008, 120, 3046; d) M. Nakano, H.
Tsurugi, T. Satoh, M. Miura, Org. Lett. 2008, 10, 1851; e) S.
Yanagisawa, K. Ueda, H. Sekizaawa, K. Itami, J. Am. Chem. Soc.
2009, 131, 14622; f) N. Umeda, K. Hirano, T. Satoh, M. Miura, J.
Org. Chem. 2009, 74, 7094; g) K. M. Engle, D.-H. Wang, J.-Q. Yu,
Angew. Chem. Int. Ed. 2010, 49, 6169; Angew. Chem. 2010, 122,
6305; h) A. Deb, S. Bag, R. Kancherla, D. Maiti, J. Am. Chem.
Soc. 2014, 136, 13602; i) N. Schrçder, F. Lied, F. Glorius, J. Am.
Chem. Soc. 2015, 137, 1448.
À
[3] For meta-C H functionalization using other approaches, see:
a) J.-Y. Cho, M. K. Tse, D. Holmes, Jr., R. E. Maleczka, M. R.
Smith III, Science 2002, 295, 305; b) T. Ishiyama, J. Takagi, K.
Ishida, N. Miyaura, N. R. Anastasi, J. F. Hartwig, J. Am. Chem.
Soc. 2002, 124, 390; c) R. J. Phipps, M. J. Gaunt, Science 2009,
323, 1593; d) Y.-H. Zhang, B.-F. Shi, J.-Q. Yu, J. Am. Chem. Soc.
2009, 131, 5072; e) O. Saidi, J. Marafie, A. E. W. Ledger, P. M.
Liu, M. F. Mahon, G. Kociok-Kohn, M. K. Whittlesey, C. G.
Frost, J. Am. Chem. Soc. 2011, 133, 19298; f) L. Zhou, W. Lu,
Organometallics 2012, 31, 2124; g) N. Hofmann, L. Ackermann,
J. Am. Chem. Soc. 2013, 135, 5877; h) C. Cheng, J. F. Hartwig,
Science 2014, 343, 853; i) J. Luo, S. Preciado, I. Larrosa, J. Am.
Chem. Soc. 2014, 136, 4109; j) A. J. Martínez-Martínez, A. R.
Kennedy, R. E. Mulvey, C. T. OꢀHara, Science 2014, 346, 834.
[10] H.-X. Dai, A. F. Stepan, M. S. Plummer, Y.-H. Zhang, J.-Q. Yu, J.
Am. Chem. Soc. 2011, 133, 7222.
[11] See the Supporting Information for detailed descriptions.
[12] a) M. D. K. Boele, G. P. F. Van Strijdonck, A. H. M. De Vries,
P. C. J. Kamer, J. G. De Vries, P. W. N. M. Van Leeuwen, J. Am.
Chem. Soc. 2002, 124, 1586; b) G. Cai, Y. Fu, Y. Li, X. Wan, Z.
Shi, J. Am. Chem. Soc. 2007, 129, 7666.
[13] a) C. Gürtler, S. L. Buchwald, Chem. Eur. J. 1999, 5, 3107; b) P.
Wucher, L. Caporaso, P. Roesle, F. Ragone, L. Cavallo, S.
Mecking, I. Gçttker-Schnetmann, Proc. Natl. Acad. Sci. USA
2011, 108, 8955; c) S.-R. Ban, H.-N. Wang, V. Toader, D. S.
Bohle, C.-J. Li, Org. Lett. 2014, 16, 6282.
À
[4] For palladium-catalyzed template-directed remote meta-C H
functionalization, see: a) D. Leow, G. Li, T.-S. Mei, J.-Q. Yu,
Nature 2012, 486, 518; b) H.-X. Dai, G. Li, X.-G. Zhang, A. F.
Stepan, J.-Q. Yu, J. Am. Chem. Soc. 2013, 135, 7567; c) R.-Y.
Tang, G. Li, J.-Q. Yu, Nature 2014, 507, 215; d) G.-J. Cheng, Y.-F.
Yang, P. Liu, P. Chen, T.-Y. Sun, G. Li, X. Zhang, K. N. Houk, J.-
Q. Yu, Y.-D. Wu, J. Am. Chem. Soc. 2014, 136, 894; e) Y.-F. Yang,
G.-J. Cheng, P. Liu, D. Leow, T.-Y. Sun, P. Chen, X. Zhang, J.-Q.
Yu, Y.-D. Wu, K. N. Houk, J. Am. Chem. Soc. 2014, 136, 344;
f) G. Yang, P. Lindovska, D. Zhu, J. Kim, P. Wang, R.-Y. Tang, M.
Movassaghi, J.-Q. Yu, J. Am. Chem. Soc. 2014, 136, 10807; g) Y.
Deng, J.-Q. Yu, Angew. Chem. Int. Ed. 2015, 54, 888; Angew.
Chem. 2015, 127, 902.
[14] a) G. T. Crisp, Chem. Soc. Rev. 1998, 27, 427; b) A. F. Littke,
G. C. Fu, J. Am. Chem. Soc. 2001, 123, 6989; c) V. Caló, A. Nacci,
A. Monopoli, A. Detomaso, P. Iliade, Organometallics 2003, 22,
4193; d) P. Fristrup, S. L. Quement, D. Tanner, P.-O. Norrby,
Organometallics 2004, 23, 6160; e) E. W. Werner, M. S. Sigman,
J. Am. Chem. Soc. 2010, 132, 13981.
[15] CCDC 1043571 (SM1), 1043569 (1 f), and 1043570 (4q) contain
the supplementary crystallographic data for this paper. These
data can be obtained free of charge from The Cambridge
Crystallographic Data Centre via www.ccdc.cam.ac.uk/data_
request/cif.
[16] P. R. Blakemore, J. Chem. Soc. Perkin Trans. 1 2002, 2563.
À
[5] Another template-directed meta-C H functionalization, see: S.
Lee, H. Lee, K. L. Tan, J. Am. Chem. Soc. 2013, 135, 18778.
À
[6] For meta-C H functionalization of phenylacetic acid by using
cyanophenol derived ester, see: M. Bera, A. Modak, T. Patra, A.
Maji, D. Maiti, Org. Lett. 2014, 16, 5760.
[7] a) F. G. Bordwell, Acc. Chem. Res. 1988, 21, 456; b) I.-H. Um, S.-
M. Chun, S.-K. Bae, Bull. Korean Chem. Soc. 2005, 26, 457; c) I.
Received: April 5, 2015
Revised: April 29, 2015
Published online: June 9, 2015
Angew. Chem. Int. Ed. 2015, 54, 8515 –8519
ꢀ 2015 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.angewandte.org
8519
