Palladium catalyzed hydroesterification of substituted alkenes under microwave
conditions
Maretha du Plessis, Charlene Marais, and Barend C. B. Bezuidenhoudt*
Department of Chemistry, University of the Free State, P.O. Box 339, Bloemfontein, 9300, South Africa
Email: bezuidbc@ufs.ac.za/bcbbez@gmail.com
Received mm-dd-yyyy
Dates to be inserted by editorial office
Abstract
Accepted mm-dd-yyyy
Published on line mm-dd-yyyy
While several catalyst systems have been utilized in the hydroesterification or methoxycarbonylation of
alkenes or equivalent substrates, these reactions are conventionally performed in autoclave reactor systems
o
under high CO pressure (20 - 70 bar) and thermal heating (70 – 110 C). In this paper, the first
methoxycarbonylation reactions performed in a microwave reactor fitted with a gas-addition accessory
system are reported on and compared to the same reactions performed under conventional heating in an
autoclave reactor. Thus 1-octene, styrene, allylbenzene, o- and p-methoxyallylbenzene and β-methylstyrene
were subjected to methoxycarbonylation over a palladium acetate–aluminum triflate catalyst system at 12 bar
o
and 95 C. Results obtained indicated the methoxycarbonylation of these alkenes to be much faster under
microwave conditions when compared to conventional heating and improvements in conversion ranged
between 3 and 5% for the more reactive substrates (1-octene and styrene) and 6 – 20% for the allylbenzenes
and β-methylstyrene.
Keywords: Alkoxycarbonylation, hydroesterification, palladium catalyst, aluminum triflate, alkenes, microwave
heating.
DOI: https://doi.org/10.24820/ark.5550190.p011.198
Page 1
©AUTHOR(S)

Arkivoc 2020, iii, 0-0
du Plessis, M. et al.
Introduction
While the palladium catalyzed alkoxycarbonylation or hydroesterification of alkenes or equivalent substrates
has been well documented for a plethora of catalyst systems,1-16 these reactions are usually performed in
autoclave reactors at CO pressures ranging from ca. 1-70 bar and temperatures of ca. 70 – 110oC. During an
investigation into the electronic factors governing the regioselectivity (ratio of linear to branched to benzylic
products) of the addition of the ester entity to aromatic substituted alkenes over a palladium catalyst
system,17 it was found that the reactivity of the substituted allylbenzene (1) and β-methylstyrene (2) reactants
were rather low [Turn-over frequencies (TOF) of 7 – 30 h-1], so prolonged reactions times (up to 3 h) were
required to obtain decent yields (50 – 90%).
Since it is generally known that microwave heating has the ability to accelerate some chemical reactions18
and the hydroesterification reaction was found to be rather slow, it was decided to evaluate the effect of
microwave heating on the rate of the alkoxycarbonylation of substituted alkenes over a palladium acetate
catalyst system.
Results and Discussion
In order to be in a position to compare the results of the microwave mediated reactions with the results
o
obtained under conditions of ordinary heating at 95 C and the optimum pressure of 35 bar, as reported
earlier,5 the same Pd(II)/Al(OTf)3/PPh3 catalyst system, developed by Williams et al.,19,20 was utilized during the
current investigation. Furthermore, since the glass vessels of the microwave reactor are rated at 12 bar only,
o
the reactions in an autoclave reactor were also performed at 12 bar CO pressure (95 C), while the
investigation was started with the very reactive general hydroesterification substrates, 1-octene (3) and
styrene (4) (Scheme 1) for possible comparison with literature results.
Scheme 1: Methoxycarbonylation of 1-octene (3) and styrene (4). l and b refers to the ‘linear’ and ‘branched’
isomers, respectively.
As indicated in table 1, both substrates, 1-octene (3) and styrene (4) showed a substantial increase in
conversion of ca. 20% and 30%, respectively, even after only 10 minutes of reaction time for the microwave
Page 2
©AUTHOR(S)

Arkivoc 2020, iii, 0-0
du Plessis, M. et al.
reaction when compared to the autoclave reaction at the same pressure (12 bar). Furthermore, virtually
complete conversion of the starting material (99%) was observed after 30 minutes under microwave
irradiation, while the reactions under conventional heating conditions at the same pressure (12 bar) were not
fully completed (Table 1, entries 2 vs. 3 and 5 vs. 6). Even when compared to the reactions at 35 bar, the
microwave equivalents showed a slight improvement over those performed with conventional heating (Table
1, entries 1 vs. 3 and 4 vs. 6). The fact that the final yields for the microwave reactions are somewhat lower
than those of the reactions in the autoclave reactor under the same conditions (82% vs. 91% and 72% vs. 92%,
respectively) is probably explicable in terms of unwanted side-reactions. These could include reactions like
polymerization in the case of styrene (4), and/or subsequent hydrolysis of the ester products, 5, 6, 7 and 8, by
water present in the methanol, due to the extended exposure to the microwave heating conditions, since the
MW reactions were already 99% and 89% completed after only 10 minutes (Table 1, entries 3 and 6).
Table 1. Methoxycarbonylation of 1-octene (3) and styrene (4)
Entry Substrate CO Pressure
(bar)
Temp.
(oC)
95a
95a
Conversionc (%) Products
10 min 30 min
Yieldd (%)
10 min 30 min
Ratio
(l:b)
1
2
3
3
3
3
35
12
12
85
80
99
95
94
99
5 & 6
5 & 6
5 & 6
76
70
82
92
91
82
4:1
4:1
4:1
95
(MW)b
95a
4
5
6
4
4
4
35
12
12
77
58
89
96
96
99
7 & 8
7 & 8
7 & 8
64
53
71
93
92
72
4:1
4:1
4:1
95a
95
(MW)b
aConventional heating in an autoclave reactor. bMicrowave irradiation (150 W). Determined by GC analysis with xylene as internal
c
standard. dCombined yield determined by GC analysis (with xylene as internal standard).
When subjecting the aryl substituted alkenes, allylbenzene (9), 4-allylanisole (10), 2-allylanisole (11) and
trans-β-methylstyrene (12) to the methoxycarbonylation reaction, it should be kept in mind that these
substrates are prone to palladium catalyzed isomerization of the double bond between the internal and
terminal positions, so the same products, i.e. ‘linear’, ‘branched’ and ‘benzylic’ isomers, could be formed from
both the similarly substituted allylbenzene and β-methylstyrene derivatives (Scheme 2).
Page 3
©AUTHOR(S)

Arkivoc 2020, iii, 0-0
du Plessis, M. et al.
Scheme 2. Methoxycarbonylation and isomerization of allylbenzene (9) and β-methylstyrene (12)
When the 1- and 2-propenylaryl substrates (Scheme 3) were subjected to the methoxycarbonylation
reaction under microwave heating (150 W) over the standard catalyst system, Pd(OAc)2/Al(OTf)3/PPh3, it was
found that all the substrates reacted much slower than 1-octene (3) and styrene (4), so reaction times of up to
three hours were required to reach completion in both the MW and autoclave reactions at 35 bar. p-
Methoxyallylbenzene (10) proved to be even less reactive and gave conversions of only 40-60% after the 3
hours, with the better conversion (60%) observed for the autoclave reaction at 35 bar. When comparing the
reactions at 12 bar for this substrate (10), however, the MW method gave a better conversion (28% vs. 20%)
even after only 1 hour (Table 2, entry 5 vs. 6).
Scheme 3. Methoxycarbonylation of allylbenzenes (9 – 11) and β-methylstyrene (12).
A substantial improvement in conversion (70% vs. 86% and 29% vs. 65%, respectively) was also obtained
for the o-methoxy substituted allylbenzene analogue, 11 and β-methylstyrene (12), during conditions of MW
irradiation over conventional heating after 1 hour at the same pressure (Table2, entries 8 vs 9 and 11 vs 12).
After 3 hours at 12 bar (at nearly full conversion), improved conversion rates were obtained for all substrates
(9 - 12), with the more profound improvements (ca. 20%) for the less reactive substrates, p-methoxyallyl-
benzene (10) and β-methylstyrene (12), (Table 2, entries 2 vs 3, 5 vs 6, 8 vs 9 and 11 vs 12 respectively).
Page 4
©AUTHOR(S)

Arkivoc 2020, iii, 0-0
du Plessis, M. et al.
Table 2. Methoxycarbonylation of allylbenzenes (9 - 11) and β-methylstyrene (12)
Entry Substrate CO Pressure
(bar)
Temp.
(oC)
95a
95a
Conversionc (%)
Products
Yieldd
Ratio
(l:b:bn)
(%)
80
80
81
51
20
37
75
73
89
76
66
82
1 h
72
57
57
38
20
28
88
70
86
47
29
65
3 h
97
87
90
60
21
40
96
90
96
95
74
1
2
3
4
5
6
7
8
9
9
9
9
35
12
12
35
12
12
35
12
12
35
12
12
13, 14, 15
13, 14, 15
13, 14, 15
16, 17, 18
16, 17, 18
16, 17, 18
19, 20, 21
19, 20, 21
19, 20, 21
13, 14, 15
13, 14, 15
13, 14, 15
7:2:1
12:2:1
9:2:1
5:2:1
15:2:1
6:1:1
26:5:1
28:6:1
27:5:1
5:2:1
10:2:1
8:2:1
95 (MW)b
95a
10
10
10
11
11
11
12
12
12
95a
95 (MW)b
95a
95a
95 (MW)b
95a
10
11
12
95a
95 (MW)b
94
c
aConventional heating in an autoclave reactor. bMicrowave irradiation (150 W). Determined by GC analysis with xylene as internal
standard. dCombined yield determined by GC analysis (with xylene as internal standard) after 3 hours.
A comparison of the final product yields revealed that, apart from allylbenzene (9), MW irradiation
resulted in substantial increases (ca. 16%) for all substrates when compared to the conventional thermal
reactions at the same pressure (12 bar) (table 2, entries 5 vs 6, 8 vs 9 and 11 vs 12, respectively).
With regard to the regioselectivity of the reactions, a general decrease in selectivity was evident in the
microwave reactions when compared to the conventional heating experiments at the same CO pressure (Table
2, entry 2 vs. 3, 5 vs. 6, 8 vs. 9 and 11 vs. 12). Though still the major products, the lower selectivity towards
the linear products is probably explicable in terms of a more facile isomerization to the corresponding internal
olefins for the allylbenzene substrates under the microwave conditions, while isomerization of the β-
methylstyrene to the sterically less hindered allylbenzene isomer may be slower than the secondary terminal
to internal isomerization.
Conclusions
Finally, for 1-octene (3) and styrene (4), a definite reaction rate increasing effect was observed with the
conversion after 10 minutes under microwave conditions at 12 bar being almost the same or better than what
was obtained after 30 minutes at 35 bar with conventional heating in an autoclave reactor. Although no
dramatic reaction rate enhancing effect was observed for the other substrates, both the substituted
allylbenzene analogues (10 and 11) and β-methylstyrene (12) showed improvements in conversion and yield
under microwave conditions when compared to conventional heating at the same pressure. The fact that only
a very slight improvement in conversion and yield could be detected for allylbenzene (9) is currently
inexplicable.
Page 5
©AUTHOR(S)

Arkivoc 2020, iii, 0-0
du Plessis, M. et al.
Experimental Section
General. All the chemicals used were purchased from Sigma-Aldrich and used as received. Reactions were
performed in a 4590 Parr autoclave reactor (25 ml vessel) with mechanical stirring (500 rpm) and a CEM
Discover SP Microwave Reactor, equipped with a gas addition accessory and an internal IR temperature
sensor, in a sealed tube (10 ml tube) and stirred by a magnetic stirrer bar. 1H and 13C NMR as well as 2D
1
experiments were done on a 600 MHz Bruker AM FT spectrometer at 20°C at 600 MHz for H NMR and 151
1
MHz for 13C in CDCl3 as solvent. H NMR chemical shifts are given relative to the TMS signal at 0 ppm and 13C
NMR shifts are given relative to the CDCl3 peak at 77.16 ppm, coupling constants are measured in Hz and
chemical shifts in ppm. Mass spectrometry was performed on a Shimadzu GCMS QP-2010 instrument using
electron-impact (EI) ionization. Conversions, yields and product ratios were determined on a Shimadzu 2010
GC instrument with xylene as the internal standard. Methyl nonanoate (5) and methyl 2-methyloctanoate (6)
were purified by passing the reaction mixture through a pad of silica gel, while all the other products were
purified using flash column chromatography with silica gel 60 as stationary phase and obtained as mixtures of
linear, branched and, in the case of the allylbenzenes, benzylic isomers.
Autoclave procedure. Pd(OAc)2 (5 mol%), Al(OTf)3 (10 mol%), PPh3 (20 mol%), xylene (0.5 g) and the alkene (4
mmol) were added together in the Parr autoclave reactor and dissolved in MeOH (8 ml). The mechanical
stirrer was activated, the reactor purged with CO (purified by passing the gas through a CrO3 column) and
allowed to heat up to 95 °C, where after it was pressurized to 12 bar with CO.
Microwave procedure. Pd(OAc)2 (5 mol%), Al(OTf)3 (10 mol%), PPh3 (20 mol%), xylene (0.25 g) and the alkene
(2 mmol) were added together in a microwave vial (10 ml) and dissolved in MeOH (4 ml). The magnetic stirrer
was started and the reactor purged with CO (purified by passing the gas through a CrO3 column) and the CO
pressure set to 12 bar, where after irradiation at 150 W was initiated and the temperature kept at 95 °C by
utilizing the fixed power method.
Methyl nonanoate (5) and methyl 2-methyloctanoate (6).21 δH (600 MHz; CDCl3; Me4Si) 3.67 [0.7H, s, OMe,
(6)], 3.66 [3H, s, OMe, (5)], 2.44-2.41 [0.2H, m, H-2, (6)], 2.29 [2H, t, J 7.57 Hz, H-2, (5)], 1.64-1.59 [2H, m, H-3,
(5)], 1.32-1.22 [10H, m, H-4, H-5, H-6, H-7, H-8 (5)], 1.32-1.22 [2.2H, m, H-3, H-4, H-5, H-6, H-7, (6)], 1.13 [0.7H,
d, J 7.02 Hz, 2-CH3, (6)], 0.87 [0.7H, t, J 7.02 Hz, H-8, (6)], 0.87 [3H, t, J 7.02 Hz, H-9, (5)]; δC (151 MHz; CDCl3)
177.5 [C-1 (6)], 174.4 [C-1 (5)], 51.5 [OMe (5)], 51.3 [OMe (6)], 39.6 [C-2 (6)], 34.19 [C-2 (5)], 33.9 (6), 32.0 (5),
31.8, (6), 29.3 (5), 29.3 (6), 29.3 (5), 29.2 (5), 27.3 (6), 25.1 [C-3, (5)], 22.7 (5), 22.7 (6), 17.2 [2-CH3, (6)], 14.2
[C-9, (5)], 14.1 [C-8, (6)]; MS (EI) m/z 172 [M+, 2%, (5)], 172 [M+, 1%, (6)].
Methyl 3-phenylpropanoate22 (7) and methyl 2-phenylpropanoate23 (8). Rf = 0.595 (petroleum ether:ether
7:3); δH (600 MHz; CDCl3; Me4Si) 7.34-7.26 [2.7H, m, H-Ar, (7) and (8)], 7.22-7.19 [2.9H, m, CH aromatic, (7)
and (8)], 3.72 [0.2H, q, J 7.17 Hz, H-2, (8)], 3.67 [3H, s, OMe, (7)], 3.65 [0.5H, s, OMe, (8)], 2.95 [2H, t, J 7.89 Hz,
H-3, (7)] 2.63 [2H, t, J 7.89 Hz, H-2, (7)], 1.5 [0.5H, d, J 7.17 Hz, H-3, (8)]; δC (151 MHz; CDCl3) 175.1 [C-1, (8)],
173.5 [C-1, (7)], 140.7 [C-1', (8)], 140.6 [C-1', (7)], 128.8 [C-4', (8)], 128.6 [CH aromatic, (7)], 128.4 [CH
aromatic, (7)], 127.6 [CH aromatic, (8)], 127.3 [CH aromatic, (8)], 126.4 [C-4' (7)], 52.2 [-OMe, (8)], 51.7 [-OMe
(7)], 45.6 [C-2, (8)], 35.8 [C-2, (7)], 31.1 [C-3 (7)], 18.7 [C-3, (8)]; MS (EI) m/z 164 [M+, 35%, (7)], 164 [M+, 23%,
(8)].
Methyl 4-phenylbutanoate12 (13), methyl 2-methyl-3-phenylpropanoate24 (14) and methyl 2-
phenylbutanoate25 (15). Rf = 0.784 (hexane:toluene:acetone 4:4:2); δH (600 MHz; CDCl3; Me4Si) 7.33-7.24
[4.8H, m, CH aromatic, (13), (14) and (15)], 7.22-7.15 [4.5H, m, CH aromatic, (13), (14) and (15)], 3.66 [3H, s,
OMe (13)], 3.65 [1H, s, OMe (15)], 3.64 [1.7H, s, OMe (14)], 3.46 [0.3H, t, J 7.71 Hz, H-2, (15)], 3.03 [0.6H, dd, J
Page 6
©AUTHOR(S)

Arkivoc 2020, iii, 0-0
du Plessis, M. et al.
6.83 and 13.37 Hz, H-3a/b, (14)], 2.77-2.71 [0.6H, m, H-2, (14)], 2.66 [0.6H, dd, J 7.83 and 13.37 Hz, H-3a/b,
(14)], 2.65 [2H, t, J 7.56 Hz, H-4, (13)], 2.33 [2H, t, J 7.56 Hz, H-2, (13)], 2.14-2.06 [0.3H, m, H-3a/b, (15)], 1.96
[2H, p, J 7.56 Hz, H-3, (13)], 1.83-1.76 [0.3H, m, H3a/b, (15)], 1.15 [1.7H, d, J 6.92Hz, 2-CH3, (14)], 0.94 [1H, t, J
7.37 Hz, H-4, (15)]; C (151 MHz; CDCl3) 176.7 [C-1, (14)], 174.7 [C-1, (15)], 174.1 [C-1, (13)], 141.5 [C-1', (13)],
139.5 [C-1', (14)], 139.2 [C-1', (15)], 129.1, 128.7, 128.6, 128.51, 128.48, 128.1, 127.3, 126.4, 126.1, 53.5 [C-2,
(15)], 52.0 [OMe, (15], 51.72 [OMe, (14)], 51.65 [OMe (13)], 41.6 [C-2, (14)], 39.8 [C-3 (14)], 35.2 [C-4, (13)],
33.5 [C-2, (13)], 26.9 [C-3 (15)], 26.6 [C-3, (13)], 16.9 [2-CH3 (14)], 12.3 [C-4, (15)]; MS (EI) m/z 178 [M+, 37 %,
(13)], 178 [M+, 18 %, (14)], 178 [M+, 18 %, (15)].
Methyl 4-(4'-methoxyphenyl)butanoate12 (16), methyl 3-(4'-methoxyphenyl)-2-methylpropanoate24 (17) and
methyl 2-(4'-methoxyphenyl)butanoate26 (18). Rf 0.639 (petroleum ether:ether 7:3); δH (600 MHz; CDCl3;
Me4Si) 7.25 [0.2H, d, J 8.7 Hz, H-3' and H-5', (18)], 7.11 [2H, d, J 8.66 Hz, H-3' and H-5', (16)], 7.10 [0.4H, d, J
8.64 Hz, H-3' and H-5', (17)], 6.88-6.87 [0.2H, d, J 8.7 Hz, H-2' and H-6', (18)], 6.86-6.83 [0.4H, m, H-2' and H-6',
(17)], 6.85 [2H, d, J 8.66 Hz, H-2' and H-6', (16)], 3.81-3.80 [3.9H, s, 4'-OMe, (16), (17) and (18)], 3.68 [3H, s,
COOMe, (16)], 3.67 [0.3H, s, COOMe, (18)], 3.66 [0.6H, s, COOMe (17)], 3.43 [0.1H, t, J 7.73 Hz, H-2, (18)], 2.98
[0.2H, dd, J 6.94 and 13.53 Hz, H-3a/b, (17)], 2.75-2.69 [0.2H, m, H-2, (17)], 2.65-2.63 [0.2H, m, H-3a/b, (17)],
2.61 [2H, t, J 7.54 Hz, H-4, (16)], 2.34 [2H, t, J 7.54 Hz, H-2, (16)], 2.11-2.07 [0.1H, m, H-3a/b, (18)], 1.94 [2H, p,
J 7.54 Hz, H-3, (16)], 1.81-1.76 [0.1H, m, H-3a/b, (18)], 1.16 [0.6H, d, J 6.92 Hz, 2-CH3, (17)], 0.90 [0.3H, t, J 7.34
Hz, H-4, (18)]; δC (151 MHz, CDCl3) 176.7 [C-1, (17)], 174.8 [C-1, (18)], 174.0 [C-1, (16)], 158.7 [C-4', (18)], 158.1
[C-4', (17)], 157.9 [C-4', (16)], 133.4 [C-1', (16)], 131.4 [C-1', (17)], 131.2 [C-1', (18)], 129.9 [C-2' and C-6', (17)],
129.4 [C-2' and C-6', (16)], 128.9 [C-2' and C-6', (18)], 113.9 [C-3' and C-5', (18)], 113.8 [C-3' and C-5', (16)],
113.7 [C-3' and C-5', (17)], 55.2 [4'-OMe, (16), (17) and (18)], 52.5 [C-2, (18)], 51.9 [COOMe, (18)], 51.6
[COOMe, (17)], 51.5 [COOMe (16)], 41.7 [C-2, (17)], 38.9 [C-3 (17)], 34.2 [C-4, (16)], 33.3 [C-2, (16)], 26.8 [C-3
(18)], 26.7 [C-3, (16)], 16.7 [2-CH3 (17)], 12.2 [C-4, (18)]; MS (EI) m/z 208 [M+, 39 %, (16)], 208 [M+, 13 %,
(17)], 208 [M+, 21 %, (18)].
Methyl 4-(2'-methoxyphenyl)butanoate27 (19), methyl 3-(2'-methoxyphenyl)-2-methylpropanoate24 (20) and
methyl 2-(2'-methoxyphenyl)butanoate17 (21). Rf 0.583 (petroleum ether:ether 7:3); δH (600 MHz; CDCl3;
Me4Si) 7.25-7.23 [0.04H, m, H-4', (21)], 7.2-7.15 [1.2H, m, H-4', (19) and (20)], 7.11-7.07 [1.25H, m, H-6', (19),
(20) and (21)], 6.94-6.91 [0.04H, m, H-5', (21)], 6.88-6.84 [1.2H, m, H-5', (19) and (20)], 6.83-6.81 [1.25H, m, H-
3', (19), (20) and (21)], 3.8 [0.12H, s, 4'-OMe, (21)], 3.79 [0.6H, s, 4'-OMe, (20)], 3.78 [3H, s, 4'-OMe, (19)],
3.76-3.75 [0.04H, m, H-2, (21)], 3.64 [3H, s, COOMe, (19)], 3.63 [0.12H, s, COOMe, (21)], 3.61 [0.6H, s, COOMe
(20)], 2.98 [0.2H, dd, J 7.1 and 13.22 Hz, H-3a/b, (20)], 2.86-2.8 [0.2H, m, H-2, (20)], 2.7 [0.2H, dd, J 7.59 and
13.22 Hz, H-3a/b, (20)], 2.65 [2H, t, J 7.56 Hz, H-4, (19)], 2.32 [2H, t, J 7.56 Hz, H-2, (19)], 2.08-2.03 [0.04H, m,
H-3a/b, (21)], 1.92 [2H, p, J 7.56 Hz, H-3, (19)], 1.78-1.73 [0.04H, m, H-3a/b, (21)], 1.13 [0.6H, d, J 7 Hz, 2-CH3,
(20)], 0.89 [0.12H, t, J 7.39 Hz, H-4, (21)]; δC (151 MHz, CDCl3) 177.1 [C-1, (20)], 175.0 [C-1, (21)], 174.2 [C-1,
(19)], 157.6 [C-2', (20)], 157.5 [C-2', (19)], 156.9 [C-2', (21)], 130.8 [C-6', (20)], 131.0 [C-6', (19)], 129.7 [C-1',
(19)], 129.4, 128.4, 128.1, 127.72, 127.69 [C-4', (20)], 127.3 [C-4' (19)], 120.7 [C-5', (21)], 120.4 [C-5', (19)],
120.3 [C-5', (20)], 110.7 [C-3', (21)], 110.2 [C-3', (19) and (20)], 55.7 [2'-OMe, (21)], 55.2 [2'-OMe, (19) and
(20)], 51.8 [COOMe, (21)], 51.47 [COOMe, (20)], 51.45 [COOMe (19)], 45.7 [C-2, (21)], 39.5 [C-2, (20)], 34.6 [C-
3 (20)], 33.6 [C-2, (19)], 29.5 [C-4, (19)], 25.7 [C-3 (21)], 25.0 [C-3, (19)], 17.0 [2-CH3 (20)], 12.2 [C-4, (21)]; MS
(EI) m/z 208 [M+, 40 %, (19)], 208 [M+, 22 %, (20)], 208 [M+, 34 %, (21)].
Acknowledgements
Page 7
©AUTHOR(S)

Arkivoc 2020, iii, 0-0
du Plessis, M. et al.
Financial support by Sasol Ltd and the National Research Foundation of South Africa is greatly appreciated.
Supplementary Material
Available
References
1. Knifton, J.F. J. Org. Chem. 1976, 41, 2885-2890.
https://doi.org/10.1021/jo00879a020
2. Sugi, Y.; Bando, K. Chem. Lett. 1976, 727-730.
https://doi.org/10.1246/cl.1976.727
3. Cometti, G.; Chiusoli, G.P.; J. Organomet. Chem. 1982, 236, C31-C32.
https://doi.org/10.1016/S0022-328x(00)86766-2
4. Huh, K.-T.; Alper, H. Bull. Korean Chem. Soc. 1994, 15, 304-306.
5. Yun, H.S.; Lee, K.H.; Lee, J.S. J. Mol. Catal. A: Chem. 1995, 95, 1
https://doi.org/10.1016/1381-1169(94)00150-2
6. Lee, C.W.; Alper, H. J. Org. Chem. 1995, 60, 250-252.
https://doi.org/10.1021/jo00106a042
7. Oi, S.; Nomura, M.; Aiko, T.; Inoue, Y. J. Mol. Catal. Chem. 1997, 115, 289-295.
https://doi.org/10.1016/S1381-1169(96)00282-8
8. Nozaki, K.; Kantam, M.L.; Horiuchi, T.; Takaya, H. J. Mol. Catal. Chem. 1997, 118, 247-253.
https://doi.org/10.1016/S1381-1169(96)00385-8
9. Mukhopadhyay, K.; Sarkar, B.R.; Chaudhari, R.V. J. Am. Chem. Soc. 2002, 124, 9692-9693.
https://doi.org/10.1021/ja025991q
10. Rodrigues, C.J.; Foster, D.F.; Eastham, G.R.; Cole-Hamilton, D.J. Chem. Commun. 2004, 1720-1721.
https://doi.org/10.1039/B404783D
11. Kawashima, Y.; Okano, K.; Nozaki, K.; Hiyama, T. Bull. Chem. Soc. Jpn. 2004, 77, 347-355.
https://doi.org/10.1246/bcsj.77.347
12. Vieira, T.O.; Green, M.J.; Alper, H. Org. Lett. 2006, 8, 6143-6145.
https://doi.org/10.1021/ol062646n
13. Guiu, E.; Caporali, M.; Muñoz, B.; Müller, C.; Lutz, M.; Spek, A.L.; Claver, C. Van Leeuwen, P.W.N.M.
Organometallics, 2006, 25, 3102-3104.
https://doi.org/10.1021/om060121t
14. Muñoz, B.K.; Godard, C.; Marinetti, A.; Ruiz, A.; Benet-Buchholz, J.; Claver, C. Dalton Trans. 2007, 5524-
5530.
https://doi.org/10.1039/B705230H
15. Zolezzi, S.; Moya, S.A.; Valdebenito, G.; Abarca, G.; Parada, J.; Aguirre, P. Appl. Organomet. Chem. 2014,
28, 364-371.
https://doi.org/10.1002/aoc.3137
16. Schneider, C.; Jackstell, R.; Maes, B.U.W.; Beller, M. Eur. J. Org. Chem. 2020, 2020(8), 932–936.
https://doi.org/10.1002/ejoc.201901592
Page 8
©AUTHOR(S)

Arkivoc 2020, iii, 0-0
du Plessis, M. et al.
17. Du Plessis, M.; Marais, C.; Bezuidenhoudt, B.C.B. Synthesis, 2016, 48, 557-565.
https://doi.org/10.1055/s-0035-1560912
18. Hayes, B. L. Microwave Synthesis: Chemistry at the Speed of Light, CEM Publishing, 2002.
19. Williams, D.B.G.; Shaw, M.L.; Green, M.J.; Holzapfel, C.W. Angew. Chem. Int. Ed., 2008, 47, 560-563.
https://doi.org/10.1002/anie.200702889
20. Williams D.B.G.; Bredenkamp, T.; Chem. Cat. Chem., 2012, 4, 206-208.
https://doi.org/10.1002/cctc.201100238
21. Pfeffer, P. E.; Foglia, T. A.; Barr, P. A.; Obenauf, R. H. J. Org. Chem. 1978, 43, 3429–3431.
https://doi.org/10.1021/jo0041a051
22. Hayashi, M.; Kawabata, H.; Yoshimoto, K.; Tanaka, T. Phosphorus Sulfur Silicon Relat. Elem. 2007, 182,
433–445.
https://doi.org/10.1080/10426500600977296
23. Marsh, B. J.; Carbery, D. R. J. Org. Chem. 2009, 74, 3186–3188.
https://doi.org/10.1021/jo900237y
24. Liu, Y.; Mao, D.; Xu, D.; Xu, Z.; Zhang, Y. Synth. Commun. 2007, 37, 4389–4397.
https://doi.org/10.1080/00397910701577570
25. Shono, T.; Kashimura, S.; Nogusa, H. J. Org. Chem. 1984, 49, 2043–2045.
https://doi.org/10.1021/jo00185a052
26. Malézieux, B.; Gruselle, M.; Troitskaya, L.; Sokolov, V. Tetrahedron Asymmetry 1998, 9, 259–269.
https://doi.org/10.1016/S0957-4166(97)00636-8
27. Haine, M. E.; Dyson, J. Nature 1950, 166 (4216), 315–316.
https://doi.org/10.1038/166315a0
This paper is an open access article distributed under the terms of the Creative Commons Attribution (CC BY) license
(http://creativecommons.org/licenses/by/4.0/)
DEFINITIVE COPY. DO NOT DELETE THIS MESSAGE.
Please ensure that all changes are made in this copy.
All changes to this manuscript must be made on this copy, whether it is then uploaded into the Arkivoc
manuscript database or sent to the Scientific Editor.
The notifications in red here will be removed by the Publishing Editor at the Publication stage.
Page 9
©AUTHOR(S)
