Direct Observation of the Benzyl Radical and the
Benzyl Anion within Cation-Exchanged Zeolites. A
Nanosecond Laser Study
Our belief was that the ill-defined spectra generated upon
photolysis of dibenzyl ketone within the cavities of zeolites was
due, at least in part, to the initial generation of a radical pair within
the supercage instead of a single “free” benzyl radical.23,24 Thus,
our approach was to utilize a precursor, phenylacetic acid,20,25-27
that upon 266-nm laser photolysis would generate a zeolite
supercage with only one radical species.
Frances L. Cozens,* Wendy Ortiz, and Norman P. Schepp
Department of Chemistry, Dalhousie UniVersity
Halifax, NoVa Scotia, Canada B3H 4J3
Figure 1 shows the transient diffuse reflectance spectrum
generated upon 266-nm laser28 excitation of phenylacetic acid
incorporated into dry NaY under reduced pressure (10-3 Torr).29
The spectrum shows a strong absorption band centered at 315-
nm and a shoulder at 305-nm that coincide nicely with the known
absorption spectrum for the benzyl radical in solution.26 The
transient species at 315-nm is completely quenched by the addition
of oxygen to the sample, which is characteristic of radical
species.30,31 Consistent with the formation of the benzyl radical
is that one of major products upon steady-state photolysis in NaY32
in the absence of oxygen is bibenzyl,33 the product from radical-
radical coupling. The proposed mechanism for the generation of
the benzyl radical is shown in eq 1, path a. Upon incorporation
into the nonacidic Y zeolite, phenylacetic acid deprotonates to
the phenylacetate anion,34 which undergoes photoionization20,25,35
upon 266-nm laser excitation to give the acyloxy radical that then
rapidly loses CO2 to yield the benzyl radical.
ReceiVed August 12, 1998
In recent years, there has been considerable interest in the
generation and reactivity of simple monoaryl benzylic radicals
within the cavities of zeolites.1-5 The majority of these studies
have determined the ratio of products upon steady-state photolysis
of dibenzyl ketone and its methylated derivatives. Both the
reactivity and mobility of the monoaryl radicals within the zeolite
framework have been inferred from the yield and distribution of
the product mixtures, with the conclusion that simple monoaryl
benzyl radicals are highly mobile within the zeolite framework
and that coupling reactions are very fast.4
The direct detection of reactive intermediates within the cavities
of zeolites has given important information about the reactivity
of transients species in the unique environment provided by the
zeolite.6-21 Surprisingly, however, no time-resolved studies of the
benzyl radical produced upon photolysis of dibenzyl ketone within
the cavities of zeolites have been reported. Presumably, the lack
of time-resolved results is due to the ill-defined transient diffuse
reflectance spectra generated upon laser excitation of dibenzyl
ketone within zeolites.22 We now report the direct observation of
photogenerated benzyl radicals within cation-exchanged Y fau-
jasites using nanosecond diffuse reflectance spectroscopy. Evi-
(1) Turro, N. J.; Lei, X.; McDermott, A.; Abrams, L.; Ottaviani, M. F.;
Beard, H. S. Chem. Commun. 1998, 695-696.
(2) Turro, N. J.; McDermott, A.; Lei, X.; Li, W.; Abrams, L.; Ottaviani,
M. F.; Beard, H. S.; Houk, K. N.; Beno, B. R.; Lee, P. S. Chem. Commun.
1998, 697-698.
A second weaker absorption band at 350 nm is also clearly
observed, (Figure 1). The decay rate constant for the 350-nm band,
k350 ) 5 × 105 s-1, is significantly faster than that for the 315-
nm band,36 k315 ) 2 × 105 s-1, indicating that these absorption
bands do not belong to the same transient species. The 350-nm
(3) Garcia-Garibay, M. A.; Lei, X. G.; Turro, N. J. J. Am. Chem. Soc.
1992, 114, 2749-2751.
(4) Garcia-Garibay, M. A.; Zhang, Z.; Turro, N. J. J. Am. Chem. Soc. 1991,
113, 6212-6218.
(5) Ramamurthy, V.; Corbin, D. R.; Eaton, D. F.; Turro, N. J. Tetrahedron
Lett. 1989, 30, 5833-5836.
(6) Liu, X.; Iu, K.-K.; Thomas, J. K. J. Phys. Chem. 1994, 98, 7877-
(23) The generation of radical pairs within the same cavity could lead to
the rapid formation of coupling products with absorption near 330-350-nm.
(24) Langhals, H.; Fischer, H. Chem. Ber. 1978, 111, 543-553.
(25) Meiggs, T. O.; Grossweiner, L. I.; Miller, S. I. J. Am. Chem. Soc.
1972, 94, 7981-7986.
(26) Meiggs, T. O.; Grossweiner, L. I.; Miller, S. I. J. Am. Chem. Soc.
1972, 94, 7986-7991.
(27) Meiggs, T. O.; Miller, S. I. J. Am. Chem. Soc. 1972, 94, 1989-1994.
(28) Continuum Nd: YAG laser 266-nm, <10 mJ/pulse, <8 ns/pulse.
(29) The sample was prepared in a glovebox and was permanently sealed
under vacuum prior to photolysis to ensure that no water would be coadsorbed
during the course of the experiment.
(30) Kelly, G.; Willsher, C. J.; Wilkinson, F.; Netto-Ferreira, J. C.; Olea,
A.; Weir, D.; Johnston, L. J.; Scaiano, J. C. Can. J. Chem. 1990, 68, 812-
819.
(31) Cozens, F. L.; Garcia, H.; Scaiano, J. C. J. Am. Chem. Soc. 1993,
115, 11134-11140.
(32) Product analyses of phenylacetic acid within dry NaY after steady-
state photolysis using a mercury lamp equipped with a quartz filter were carried
out under a variety of conditions. Products were extracted from the zeolite
framework using continuous liquid-solid extraction with dichloromethane
as the solvent.
(33) Photolysis of phenylacetic acid in NaY (loading level of 1 molecule/2
cavities) under dry conditions with a stream of dry nitrogen purged over the
sample throughout the photolysis time gave toluene (60%) and bibenzyl (20%)
after 50% conversion of starting materials.
(34) IR spectra of phenylacetic acid within the cation-exchanged Y zeolite
showed a strong carbonyl band centered at 1620 cm-1 and no signal above
1700 cm-1, which is consistent with the carboxylate ion being the predominate
species in the zeolite environment.
7884.
(7) Yonemoto, E. H.; Kim, Y. I.; Schmehl, R. H.; Wallin, J. O.; Shoulders,
B. A.; Richardson, B. R.; Haw, J. F.; Mallouk, T. E. J. Am. Chem. Soc. 1994,
116, 10557-10563.
(8) Haw, J. F.; Nicholas, J. B.; Xu, T.; Beck, L. W.; Ferguson, D. B. Acc.
Chem. Res. 1995, 29, 259-267.
(9) Xu, T.; Haw, J. F. J. Am. Chem. Soc. 1994, 116, 10188-10195.
(10) Kim, Y. I.; Mallouk, T. E. J. Phys. Chem. 1991, 96, 2879-2885.
(11) Yoon, K. B.; Hubig, S. M.; Kochi, J. K. J. Phys. Chem. 1994, 98,
3865-3871.
(12) Yoon, K. B.; Park, Y. S.; Kochu, J. K. J. Am. Chem. Soc. 1996, 118,
12710-12718.
(13) Sun, H.; Frei, H. J. Phys. Chem. B 1997, 101, 205-209.
(14) Vasenkov, S.; Frei, H. J. Am. Chem. Soc. 1998, 120, 4031-4032.
(15) Pitchumani, K.; Lakshminarasimhan, P. H.; Prevost, N.; Corbin, D.
R.; Ramamurthy, V. J. Chem. Soc., Chem. Commun. 1997, 181-182.
(16) Brancaleon, L.; Brousmiche, D.; Rao, V. J.; Johnston, L. J.; Rama-
murthy, V. J. Am. Chem. Soc. 1998, 120, 4926-4933.
(17) Cano, M. L.; Corma, A.; Forne´s, V.; Garc´ıa, H. J. Phys. Chem. 1995,
99, 4241-4246.
(18) Cozens, F. L.; O’Neill, M.; Schepp, N. P. J. Am. Chem. Soc. 1997,
119, 7583-7584.
(19) Cozens, F. L.; Bogdanova, R.; Re´gimbald, M.; Garc´ıa, H.; Mart´ı, V.;
Scaiano, J. C. J. Phys. Chem. 1997, 101, 6927-6928.
(20) Cozens, F. L.; Cano, M. L.; Garc´ıa, H.; Schepp, N. P. J. Am. Chem.
Soc. 1998, 120, 5667-5673.
(21) Cano, M. L.; Cozens, F. L.; Vicente, F.; Garc´ıa, H.; Scaiano, J. C. J.
Phys. Chem. 1996, 18145-18151.
(22) Laser photolysis of dibenzyl ketone in NaY in the absence of oxygen
leads to a broad absorption located around 330-350-nm. This absorption
hinders the observation of the photogenerated benzyl radicals.
(35) Bockman, M. T.; Hubig, S. M.; Kochi, J. K. J. Org. Chem. 1997, 62,
2210-2221.
10.1021/ja982892x CCC: $15.00 © 1998 American Chemical Society
Published on Web 12/30/1998

13544 J. Am. Chem. Soc., Vol. 120, No. 51, 1998
Communications to the Editor
Figure 2. Transient decay traces at 315 nm for the benzyl radical
