Please do not adjust margins
Catalysis Science & Technology
DOI: 10.1039/C5CY01493J
ARTICLE
Catalysis Science &Technology
ratios and RC, they exhibited comparable reaction activity. This This was mainly attributed to the different adsorption properties and
indicated that either CTAB or TPABr could be used as an additive protective effects upon zeolites of both alkylammonium cations.
during alkaline treating ZSMꢀ11, but different CNaOH was preferred
for both additives. By the way, all tested samples had a similar hierarchical zeolites obtained from alkaline treatment in the presence
product distribution (not shown). of CTAB as well as TPABr, aided our understanding of their
Our results provided valuable insights regarding the
2
2
J. PérezꢀRamírez et al. reported that USY and beta treated physiochemical implication, and highlighted their potential in
with NaOH and TPABr (nonꢀmicelle forming) did not lead to catalyzed reactions. Furthermore, it is very important to develop a
composites but highly crystalline hierarchical zeolites, while those sustainable approach to prepare hierarchical zeolites. In the further
prepared with NaOH and CTAB (micelle forming) displayed the work, we will take advantage of the costly zeolite removed by
composites (zeolite/OMMs) generation. The former exhibited alkaline treatment, recycle the waste streams and prevent the organic
58
superior performance than the latter in the alkylation of toluene with compounds from combustion as J. PérezꢀRamírez et al. stated.
ꢀpropanol or benzyl alcohol. That was somehow different from our
work. It may be ascribed to the different intrinsic qualities of CTAB
2
21
and TPABr and different alkaline treatment conditions, which had
evident effects on the acidity and structural properties of resultant
Acknowledgements
samples, just as MCMꢀ49 based micro–mesoporous composites and The guidance and help of Professor Yide Xu is greatly
hierarchical MCMꢀ49 zeolite with intracrystalline mesopores could appreciated.
be obtained by treating MCMꢀ49 in solution with NaOH and CTAB
3
3, 57
under different treatment conditions, respectively
. Under our
treatment conditions, the ZSMꢀ11 samples alkaline treated with
assistance of CTAB were hierarchical ZSMꢀ11 with intracrystalline
References
mesopores, well protected micropores meanwhile without OMMs 1 Y. Tao, H. Kanoh and K. Kaneko, Adsorption, 2006, 12, 309ꢀ316.
production, in spite of the micelle forming nature of CTAB.
2
1
3
H. Zhu, Z. Liu, D. Kong, Y. Wang and Z. Xie, J. Phys. Chem. C, 2008,
12, 17257ꢀ17264.
J. Li, X. Li, G. Zhou, W. Wang, C. Wang, S. Komarneni and Y. Wang, Appl.
Conclusion and Outlook
Catal. A, 2014, 470, 115ꢀ122.
The facile alkaline treatment of ZSMꢀ11 zeolites by mixed NaOH 4 J. Kim, M. Choi and R. Ryoo, J. Catal. , 2010, 269, 219ꢀ228.
and CTAB (ZꢀxatꢀyCTAB) was performed. Physiochemical 5 J. PérezꢀRamírez, S. Abelló, A. Bonilla and J.C. Groen, Adv. Funct. Mater. ,
2
properties showed that ZꢀxatꢀyCTAB zeolites had higher Si/Al ratio
and RC, uniform mesoporosity and well protective microporosity
compared with the pure NaOH treated zeolites.
The composite effects of NaOH and CTAB on mesoporosity
formation were proposed. NaOH mainly induces desilication and
produces extraꢀframework Al, while the CTAB has two roles of
2
6
4
7
009, 19, 164ꢀ172.
D.P. Serrano, J.M. Escola and P. Pizarro, Chem. Soc. Rev. , 2013, 42, 4004ꢀ
035.
K. Mlekodaj, K. Tarach, J. Datka, K. GóraꢀMarek and W. Makowski,
Microporous Mesoporous Mater. , 2014, 183, 54ꢀ61.
drilling effect and protective effect in the alkaline solution. 8 F. Schmidt, C. Hoffmann, F. Giordanino, S. Bordiga, P. Simon, W. Carrilloꢀ
2
9
Combined with the TEM images, BJH curves as well as Si and Cabrera and S. Kaskel, J. Catal. , 2013, 307, 238ꢀ245.
27
Al MAS NMR results, the synergetic and competitive effects
9
F. Schmidt, M.R. Lohe, B. Büchner, F. Giordanino, F. Bonino and S. Kaskel,
Microporous Mesoporous Mater. , 2013, 165, 148ꢀ157.
0 W.C. Yoo, X. Zhang, M. Tsapatsis and A. Stein, Microporous Mesoporous
Mater. , 2012, 149, 147ꢀ157.
between the CTAB and NaOH during alkaline treatment were
proposed. As for CTAB with a certain concentration, if CNaOH was
too low, the drilling effect would not show, however, if CNaOH was
too high, the protective effect of CTAB would be broken.
1
The acidity of ZꢀxatꢀyCTAB series samples was investigated 11 K. Tarach, K. GóraꢀMarek, J. Tekla, K. Brylewska, J. Datka, K. Mlekodaj,
systematically. PyridineꢀIR measurement revealed the B/L ratios of W. Makowski, M.C. Igualada López, J. Martínez Triguero and F. Rey, J.
total acidity for all the samples obtained were quite similar to each
other, while those with strong strength slowly increased with the
Catal. , 2014, 312, 46ꢀ57.
1
2 K. Sadowska, A. Wach, Z. Olejniczak, P. Kuśtrowski and J. Datka,
Microporous Mesoporous Mater. , 2013, 167, 82ꢀ88.
3 K. Sadowska, K. GóraꢀMarek and J. Datka, J. Phys. Chem. C
Besides, PivalonitileꢀIR measurement exhibited that all Zꢀxatꢀ 9237ꢀ9244.
yCTAB (x > 0) zeolites had the similar B/L ratios of external surface 14 K. Sadowska, K. GóraꢀMarek and J. Datka, Vib. Spectrosc. , 2012, 63,
C
CTAB/(CCTAB+CNaOH). As to the B/L ratios with weakꢀmedium
strength for Zꢀ0.5atꢀyCTAB and Zꢀxatꢀ0.05CTAB, they firstly
increased and then decreased with the increasing CCTAB or CNaOH
1
, 2013, 117,
.
acidity. In addition, the evolutions of AF with an increase of CNaOH
and CCTAB of ZꢀxatꢀyCTAB were in line with those of mesoporosity.
When ZꢀxatꢀyCTAB series samples were used as catalysts in the
alkylation of benzene with DME, they presented significantly better
reaction stability compared to ZSMꢀ11 treated with pure NaOH, in
4
1
1
1
18ꢀ425.
5 S. Abelló, A. Bonilla and J. PérezꢀRamírez, Appl. Catal. A, 2009, 364,
91ꢀ198.
6 Y. He, M. Liu, C. Dai, S. Xu, Y. Wei, Z. Liu and X. Guo, Chin. J. Catal. ,
spite of the roughly similar product distributions. For ZꢀxatꢀyCTAB 2013, 34, 1148ꢀ1158.
catalysts the B/L ratio with weakꢀmedium strength displayed well 17 J. GarciaꢀMartinez, M. Johnson, J. Valla, K. Li and J.Y. Ying, Catal. Sci.
correlation with the reaction stability, meanwhile the mesoporosity
did not make a great difference. Perhaps, the interplay of NaOH and
CTAB modification weakened the effect of structural property and
regulated the acidity properly of ZꢀxatꢀyCTAB samples.
TPABr could also be used as an additive during alkaline
treating ZSMꢀ11, but NaOH concentration was different from the
Technol.
8 V.V. Ordomsky, I.I. Ivanova, E.E. Knyazeva, V.V. Yuschenko and V.I.
Zaikovskii, J. Catal. , 2012, 295, 207ꢀ216.
, 2012, 2, 987ꢀ994.
1
1
2
9 W. Tjandra, J. Yao and K.C. Tam, Langmuir, 2006, 22, 1493ꢀ1499.
0 J. Jung, C. Jo, F.M. Mota, J. Cho and R. Ryoo, Appl. Catal. A, 2015, 492,
case of using CTAB as the additive to obtain resultant samples with 68ꢀ75.
comparable solid yield, Si/Al ratio, RC and alkylation performance.
2
1
2 | Catal. Sci. Technol.
This journal is © The Royal Society of Chemistry 2015
Please do not adjust margins
