Regioselective ketone α-alkylation with simple olefins via dual
activation
Fanyang Mo and Guangbin Dong
Science 345, 68 (2014);
DOI: 10.1126/science.1254465
This copy is for your personal, non-commercial use only.
If you wish to distribute this article to others, you can order high-quality copies for your
colleagues, clients, or customers by clicking here.
Permission to republish or repurpose articles or portions of articles can be obtained by
following the guidelines here.
The following resources related to this article are available online at
www.sciencemag.org (this information is current as of July 3, 2014 ):
Updated information and services, including high-resolution figures, can be found in the online
version of this article at:
http://www.sciencemag.org/content/345/6192/68.full.html
Supporting Online Material can be found at:
http://www.sciencemag.org/content/suppl/2014/07/02/345.6192.68.DC1.html
This article cites 51 articles, 1 of which can be accessed free:
http://www.sciencemag.org/content/345/6192/68.full.html#ref-list-1
This article appears in the following subject collections:
Chemistry
http://www.sciencemag.org/cgi/collection/chemistry
Science (print ISSN 0036-8075; online ISSN 1095-9203) is published weekly, except the last week in December, by the
American Association for the Advancement of Science, 1200 New York Avenue NW, Washington, DC 20005. Copyright
2014 by the American Association for the Advancement of Science; all rights reserved. The title Science is a
registered trademark of AAAS.

RESEARCH
| REPORTS
REFERENCES AND NOTES
18. A. G. Markowitz, M. Krumpe, R. Nikutta, Mon. Not. R. Acad. Sci.
439, 1403–1458 (2014).
19. D. Proga, T. R. Kallman, Astrophys. J. 616, 688–695
(2004).
Foundation (1163/10), and Israeli Centers of Research Excellence
program (1937/12); the Swiss National Science Foundation; the
Agenzia Spaziale Italiana grant INAF I/037/12/0-011/13 and
INAF/Project for International Scientific Cooperation; NSF grant
AST-1008882; and European Union Marie Curie contract
FP-PEOPLE-2012-IEF-331095. We thank S. Paniagua for help
with Fig. 4.
1. C. S. Reynolds, Mon. Not. R. Acad. Sci. 286, 513–537 (1997).
2. D. M. Crenshaw et al., Astrophys. J. 516, 750–768 (1999).
3. J. S. Kaastra et al., Astron. Astrophys. 534, A36 (2011).
4. J. S. Kaastra et al., Astron. Astrophys. 539, A117 (2012).
5. See supplementary materials on Science Online.
6. K. C. Steenbrugge et al., Astron. Astrophys. 434, 569–584 (2005).
7. K. T. Korista et al., Astrophys. J. 97 (suppl.), 285 (1995).
8. D. M. Crenshaw et al., Astrophys. J. 698, 281–292 (2009).
9. A. Pancoast et al. (2013), http://arxiv.org/abs/1311.6475.
10. G. Risaliti, M. Elvis, F. Nicastro, Astrophys. J. 571, 234–246 (2002).
11. G. Lamer, P. Uttley, I. M. McHardy, Mon. Not. R. Acad. Sci. 342,
L41–L45 (2003).
12. D. M. Crenshaw, S. B. Kraemer, Astrophys. J. 659, 250–256 (2007).
13. T. J. Turner, J. N. Reeves, S. B. Kraemer, L. Miller, Astron.
Astrophys. 483, 161–169 (2008).
14. S. Bianchi et al., Astrophys. J. 695, 781–787 (2009).
15. G. Risaliti et al., Astrophys. J. 696, 160–171 (2009).
16. A. L. Longinotti et al., Astrophys. J. 766, 104 (2013).
17. G. Miniutti et al., Mon. Not. R. Acad. Sci. 437, 1776–1790 (2014).
20. S. Gallagher et al., Astrophys. J. 644, 709–724 (2006).
ACKNOWLEDGMENTS
The data used in this research are stored in the public archives
of the international space observatories involved: XMM-Newton,
HST, Swift, NuSTAR, INTEGRAL, and Chandra. We acknowledge
support by the International Space Science Institute in Bern; the
Netherlands Organization for Scientific Research; NASA HST
program 13184 from the Space Telescope Science Institute, which
is operated by Association of Universities for Research in
Astronomy, Incorporated, under NASA contract NAS5-26555; the UK
Science and Technology Facilities Council; the French Centre National
d’Etudes Spatiales, CNRS/Project International de Coopération
Scientific and CNRS/Programme National Hautes Énergies;
SUPPLEMENTARY MATERIALS
www.sciencemag.org/content/345/6192/64/suppl/DC1
Materials and Methods
Figs. S1 to S4
Tables S1 to S3
References (21–38)
Movie S1
24 March 2014; accepted 9 June 2014
Published online 19 June 2014;
10.1126/science.1253787
Vicerrectoría de Investigación y Desarrollo Tecnológico (Chile);
Israel’s Ministry of Science, Technology, and Space, Israel Science
coupling, known as the Conia-ene reaction (12),
requires high temperature (>250°C), giving mod-
erate yields with limited functional-group toler-
ance; the catalytic version was first reported by
Widenhoefer (13) using palladium and recently
by Che (14) using gold. In contrast, intermolecular
ketone-olefin couplings are rare and mainly in-
volve addition of stoichiometric metal enolates or
enamides across olefins (8, 15, 16). To our knowl-
edge, base-catalyzed additions of metal enolates
to styrene derivatives (likely facilitated by forma-
tion of delocalized charges) (17, 18) and a Mn/Co-
initiated oxidative radical process for nonaromatic
olefins (19) are the only approaches reported to
date. Recently, enamine radical cation-mediated
couplings with olefins emerged as an attractive
catalytic strategy for a-functionalization of car-
bonyl compounds, albeit requiring oxidative con-
ditions (20, 21). Therefore, a general activation
mode for coupling of simple ketones and un-
activated olefins remains to be developed. Here,
we describe our development of a catalytic dual-
activation strategy for addition of normal ketone
a-C–H bonds across unactivated olefins, which al-
lows for direct ketone alkylation by simple olefins
under both pH- and redox-neutral conditions.
We targeted a bifunctional catalyst capable of
activating the ketone a-C–H bonds and the ole-
fin simultaneously, which would incorporate
a secondary amine and a low-valent transition
metal complex. Seminal work by Jun and co-
workers showed that metal-organic cooperative
catalysis enables activation of aldehyde ipso-
C−H bonds through imine formation with a
bifunctional primary amine, i.e., 2-amino-3-
picoline (22). We hypothesized that, by using a
secondary amine, the ketone a-C–H bonds would
instead be activated by enamine formation. As
depicted in Fig. 2, first, the catalyst would bind
the ketone substrate to form an enamine (step a),
which would consequently convert the ketone a
sp3 C–H bond into a sp2 C–H bond, thus en-
hancing the reactivity toward oxidative addition
by a low-valent transition metal (23, 24). Mean-
while, if a proper directing group (DG) were linked
to the amine domain, the DG could facilitate
insertion of a low-valent transition metal (e.g.,
RhI) into the resulting enamine C–H bonds, giving
C–H BOND ACTIVATION
Regioselective ketone a-alkylation
with simple olefins via
dual activation
Fanyang Mo and Guangbin Dong*
Alkylation of carbonyl compounds is a commonly used carbon-carbon bond–forming
reaction. However, the conventional enolate alkylation approach remains problematic
due to lack of regioselectivity, risk of overalkylation, and the need for strongly basic
conditions and expensive alkyl halide reagents. Here, we describe development of a
ketone-alkylation strategy using simple olefins as the alkylating agents. This strategy
employs a bifunctional catalyst comprising a secondary amine and a low-valent
rhodium complex capable of activating ketones and olefins simultaneously. Both cyclic
and acyclic ketones can be mono-a-alkylated with simple terminal olefins, such as
ethylene, propylene, 1-hexene, and styrene, selectively at the less hindered site; a large
number of functional groups are tolerated. The pH/redox neutral and byproduct-free nature
of this dual-activation approach shows promise for large-scale syntheses.
he a-alkylation of carbonyl compounds, an
old but fundamental organic transforma-
tion, is still widely used in complex molecule
syntheses (1). Conventionally, carbonyl alkyl-
ation involves generation of metal enolates
hand, the Stork enamine reaction (5, 6) (Fig. 1B)
affords monoalkylation with high regioselectivity
at the less hindered a carbons under less basic
conditions; however, use of reactive alkylating
agents (alkyl halides or Michael acceptors) is still
required due to the reduced nucleophilicity of
enamines versus metal enolates.
We foresaw substantial advantages in the pro-
spective use of simple unactivated olefins as
alkylating agents (Fig. 1C). Adding the ketone
a-C–H bond across a C–C double bond under
neutral conditions would furnish no byproducts
and tolerate a broad range of functionality. This
approach would also have economic advantages
because olefins are much cheaper and more readily
available feedstock than the corresponding alkyl
halides (Fig. 1D); in fact, most terminal alkyl
halides are ultimately prepared from olefins (4, 7).
Although adding a-C−H bonds of activated
methylene compounds across olefins and alkynes
has been established (8–11), there are fewer exam-
ples of direct coupling of simple ketones and unac-
tivated olefins. The intramolecular ketone-olefin
T
followed by addition of an alkylating agent, often
alkyl halides (Fig. 1A). Although effective, as doc-
umented in almost all organic chemistry text-
books, this enolate alkylation approach suffers
from many drawbacks (1), including (i) the need
for stoichiometric strong metallic bases (e.g.,
lithium diisopropylamide) and cryogenic con-
ditions (to avoid homolytic couplings); (ii) the
challenge in controlling regioselectivity for unsym-
metrical ketones and curtailing overalkylation to
di- or trisubstituted products ; (iii) the expense of
alkyl halide reagents (2–4); and (iv) the formation
of stoichiometric metal halides and conjugate
acids of the bases as byproducts. On the other
Department of Chemistry, University of Texas at Austin,
Austin, TX 78712, USA.
*Corresponding author. E-mail: gbdong@cm.utexas.edu
68 4 JULY 2014 • VOL 345 ISSUE 6192
sciencemag.org SCIENCE

RESEARCH
| REPORTS
metal hydride species (M–H, step b). Upon olefin
coordination to the metal, subsequent M–H mi-
gratory insertion (step c) and reductive elimination
(step d) would provide an alkylated enamine, which
upon hydrolysis would lead to a-alkylation and
catalyst regeneration (step e).
site of ketones; thus, this bifunctional catalyst
would be expected to provide high regiocontrol
for monoalkylation of unsymmetrical ketones.
Moreover, as documented in enamine catalysis
(25), enamine formation and hydrolysis can exist in
equilibrium, but the less-hindered ketone (starting
material) preferentially forms enamine over the
more-hindered ketone (product), and thus pro-
duct inhibition can be avoided. In addition,
enamine formation/hydrolysis is known to be
compatible with the RhI to RhIII catalytic cycle
(26). Therefore, both the amine and the metal
components can be employed catalytically. [For
our preliminary study of alkylation with 1,2-cyclic
diketones using stoichiometric aminopyridine
as the cofactor, see (27).]
In the Stork enamine reaction (5, 6), enamine
formation is regioselective for the less-hindered
To examine the feasibility of the proposed
strategy, we tested 3-phenylcyclopentanone (1a)
and ethylene (2a) as model substrates. A variety
of rhodium precatalysts/dative ligands, bifunc-
tional ligands, solvents, additives, and pressure
of ethylene were examined (see table S1). Given
the crucial role of the bifunctional ligands in the
proposed catalytic cycle, seven secondary amine
compounds (L1 to L7 in table S1) containing an
adjacent DG were designed and explored under the
ethylation conditions. To our delight, 7-azaindoline
(L1) exhibited unique and high catalytic activi-
ties, whereas others were inactive. In the presence
of 2.5 mole percent (mol %) chlorobis(cyclooctene)
rhodium(I) dimer {[Rh(coe)2Cl]2}, 5 mol % 1,3-
bis(2,4,6-trimethylphenyl)imidazol-2-ylidene (IMes)
ligand, 10 mol % p-toluenesulfonic acid mono-
hydrate (TsOH·H2O), and 25 mol % L1 in toluene,
the desired ethyl-substituted product 3a was
isolated in 82% yield using ethylene gas as the
alkylating agent (table S1, entry 4). Subsequently,
the role of each reactant was investigated through
a series of control experiments. The absence of
the RhI complex or bifunctional ligand L1 com-
pletely eliminates the reactivity (table S1, entries
5 and 6), supporting our hypothesis that enamine
formation and low-valent metal are key for the
C–H/olefin coupling reaction. To promote en-
amine formation, 10 mol % TsOH·H2O was pur-
posely employed as an acid catalyst; indeed,
without this additive, no desired alkylation pro-
duct was observed (table S1, entry 7). The bulky
electron-rich N-heterocyclic carbene (NHC) lig-
and (IMes) was used to promote oxidative addi-
tion of enamine C–H bonds to Rh and subsequent
olefin insertion (28). Considerably diminished
yields were found in the absence of this ligand
or using Wilkinson’s catalyst instead (table S1,
entries 8 and 20). The reaction exhibited complete
regioselectivity for the less-hindered 5 position
of cyclopentanone; neither alkylation at the 2
position nor multiple alkylations was observed
for ketone 1a. Moreover, while the reaction re-
quires 2 days at toluene reflux temperature
when 2.5 mol % [Rh(coe)2Cl]2, 5 mol % IMes,
and 25 mol % L1 were employed, increasing the
catalyst loading can result in a full conversion
within 12 to 24 hours (table S1, entries 1 and 2).
With the optimized conditions in hand, we
examined the substrate scope. A wide range of
different functional groups were tolerated under
the alkylation conditions (Fig. 3A). Ethers, aryl
bromides, carboxylic esters, methylenedioxys,
nitriles, and thioethers proved compatible (3b
to 3h). Substrates containing competitive alkylation
sites, such as secondary amides (3i), malonates
(3j) and aliphatic esters (3k and 3t), gave chemo-
and regioselective ethylation exclusively at the
ketone C5 position. Furthermore, reactive functional
Fig. 1. Different approaches to ketone alkylation. (A) Enolate alkylation. (B) Stock enamine
reaction. (C) Simple olefins as alkylating agents. (D) Cost of alkylating agents.
Fig. 2. Design of a bifunctional catalyst and proposed catalytic cycle. (a) Enamine formation;
(b) Oxidative addition of enamine C–H bond; (c) Migratory insertion into olefins; (d) Reductive
elimination to form C–C bond; (e) Enamine hydrolysis.
SCIENCE sciencemag.org
4 JULY 2014 • VOL 345 ISSUE 6192 69

RESEARCH
| REPORTS
groups, including free tertiary and primary al-
cohols (3l and 3m), free phenols (3n), unpro-
tected indoles (3o), and amines (3p), survived,
giving moderate to high yields of ketone-alkylation
products. Acid-sensitive substrates, such as those
containing a tert-butyldimethyl silyl (TBS) ether
(3q), a tertiary alcohol (3l), and a trimethylsilyl
(TMS) group (3ad in Fig. 3C), were also suitable
for this transformation. Furthermore, enolizable
preexisting stereocenters were preserved dur-
ing the reaction (3t) because no strong base was
involved. Thus, this method provides comple-
mentary compatibility to the conventional eno-
late alkylation chemistry.
On a 2-mmol scale (2.0 M), the reaction of ketone
1a provided full conversion and 96% isolated yield
with a lower catalyst loading (versus the 0.2-mmol
scale). In addition, using 10 mmol (0.98 g) 3-methyl-
cyclopentanone as the starting material, we ob-
tained the desired ethylation product (3s) in nearly
quantitative yield [determined by 1H nuclear
Fig. 3. Regioselective ketone a-alkylation with simple olefins. (A) Ethyl-
ation of various cyclopentanones. Unless otherwise mentioned, the reactions
were run on a 0.2-mmol scale; the data are reported as percent isolated yield.
Diastereomeric ratio (dr) was determined by 1H NMR. *[Rh(coe)2Cl]2 (1 mol %),
IMes (2 mol %), TsOH·H2O (5 mol %), toluene 1 mL (2.0 M). †[Rh(coe)2Cl]2
(0.5 mol %), IMes (1 mol %), TsOH·H2O (2 mol %), L1 (15 mol %), toluene 3.0 mL
(3.3 M). (B) Ethylation of various ketones. ‡Condition A: ketone 1 mL, ethylene
300 pounds per square inch, L1 (0.2 mmol), [Rh(coe)2Cl]2 (0.005 mmol),
IMes (0.01 mmol), TsOH·H2O (0.02 mmol), 2,4,4-trimethylpentan-2-amine
(0.1 mmol), neat, 130°C, 48 hours. The TON are based on [Rh] monomer, which
are determined by GC with dodecane as an internal standard. §No 2,4,4-
trimethylpentan-2-amine, but with H2O (10 mL); 2,5-diethyl-cyclopentanones
were also obtained (TON 29). ||180°C. (C) Alkylation of cyclopentanone with
various olefins. ¶Condition B: cyclopentanone (0.5 mL), olefin (0.5 mL, propene
~1 mL), L1 (0.2 mmol), [Rh(coe)2Cl]2 (0.005 mmol), IMes (0.01 mmol),
TsOH·H2O (0.02 mmol), 2,4,4-trimethylpentan-2-amine (0.1 mmol), H2O (10 mL),
neat, 130°C, 48 hours. The TON are based on [Rh] monomer, which are
determined by GC with dodecane as an internal standard.
70 4 JULY 2014 • VOL 345 ISSUE 6192
sciencemag.org SCIENCE

RESEARCH
| REPORTS
magnetic resonance (NMR)] with only 0.5 mol %
of the Rh-dimer catalyst and 15 mol % of L1 (75%
isolated yield due to the volatility of 3s). This
reaction can tolerate a range of concentrations
(from 0.2 M to 3.3 M), which can be critical for
large-scale applications. Structures of the products
were unambiguously characterized by 1H/13C
NMR, infrared (IR), and high-resolution mass
spectrometry (HRMS); x-ray structures of sev-
eral hydrazone derivatives were also obtained. For
all substrates, the products were obtained as a pair
of diastereoisomers with the cis-isomer predom-
inating. It is likely that in the last step (enamine
hydrolysis), the proton preferentially attacks
the less-hindered face of the enamine, resulting
in cis disposition of the two substituents. The di-
astereomeric ratio (dr) of the alkylation product
can be enhanced by conversion to the correspond-
ing silyl enol ether followed by treatment with a
chiral Lewis acid (supplementary materials).
cies toward enamine formation (29). By further in-
vestigating the reaction conditions, we discovered
that a catalytic amount of an additional amine,
such as triethylamine, 1,4-diazabicyclo[2.2.2]octane
(DABCO), or 2,4,4-trimethylpentan-2-amine, could
increase the efficiency of the ketone a-alkylation.
Although the exact reason remains unclear, with
the help of the amine additive, simple aliphatic
ketones, such as acetone and 2-pentanone, coupled
with ethylene to afford the desired monoalkylation
products. It is well established that aromatic ke-
tones, such as acetophenone, can undergo metal-
catalyzed C–H/olefin couplings through activation
of the ortho aromatic C–H bond, initially reported
by Murai and co-workers (30). In contrast, our strat-
egy completely switched the chemoselectivity from
the normal aromatic C–H bond to the ketone
a-C–H bond, providing homologated ketone 3y.
Using cyclopentanone as the ketone substrate,
different classes of terminal olefins were also ex-
plored. All these a-olefins provided the desired mono-
alkylation products with complete regioselectivity for
the anti-Markovnikov addition products. Sterically
hindered and less-hindered, isomerizable and non-
isomerizable, aliphatic and aromatic olefins all
reacted, suggesting a broad scope of this method-
ology. Through this investigation, dialkylation
was only observed when coupling the unsubsti-
tuted cyclopentanone (1u) with ethylene (Fig.
3B); however, we discovered that simply adding
water to the reaction enhanced the selectivity
for monoalkylation (supplementary materials).
For examples exhibited in Fig. 3, B and C, the
ketones were employed as the solvents for op-
timal performance, and the turnover numbers
(TON) based on the Rh monomer were used to
measure the efficiency of these reactions. Given
the volatility of these alkylation products, their
accurate yields were determined by gas chro-
matography (GC) or 1H NMR analysis; a portion
of the pure products could be isolated via silica
gel chromatography and fully characterized (sup-
plementary materials), although compounds 3w
and 3x were identified by comparison of their
crude 1H NMR, GC, and GC–mass spectrometry
data with authentic samples.
To gain more mechanistic insight into this bi-
functional catalyst-mediated ketone/olefin coupling,
we conducted several additional experiments
(Fig. 4). First, we isolated a key Rh-enamine
complex (4) from enamine 5 and [Rh(coe)2Cl]2
(Fig. 4A). The x-ray structure of 4 shows that
the azaindoline plane is twisted 62.5° (compared
with the x-ray structure of free enamine 5) to
allow chelation of the metal with the pyridine
and the olefin, suggesting a preactivated confor-
mation for the subsequent C–H insertion (see
step a in Fig. 2). Second, attempts to capture the
metal-hydride intermediate incorporating an IMes
ligand were unfruitful; however, we successfully
isolated and obtained the x-ray structure of Rh–H
complex 6 with PMe3 as the dative ligand (Fig. 4B).
Although complex 6 did not react with ethyl-
ene, it demonstrated the feasibility of insertion
of a low-valent transition metal into enamine
vinyl C–H bonds by oxidative addition (see step
b in Fig. 2). Third, two deuterium-labeling exper-
iments (Fig. 4C) were carried out to examine the
proposed metal-hydride migratory insertion and
reductive elimination steps (see steps c and d in
Fig. 2). Following the proposed sequence, an a
hydrogen of the ketone substrate should be
transferred to the terminal position of the ethyl
substituent of the alkylation product. Indeed,
when the a and a′-deuterated (at the 93% D level)
3-methylcyclopentanone (1s′) was subjected to
the standard reaction conditions, more than 82%
deuterium incorporation was observed at the C2
position of the ethyl group. In addition, a stable
conjugated enamine (8) could be isolated in good
yield through coupling cyclopentanone (1u′ a and
a′-92% deuterated), amine L1, and diphenylace-
tylene. Similarly, significant deuterium incorpo-
ration (68%) was observed at the vinyl hydrogen
of compound 8. X-ray diffraction analysis con-
firmed the E olefin geometry, further supporting a
syn-migratory insertion pathway (see step c in
Fig. 2). The erosion in deuterium incorporation
for both labeling experiments is likely caused by
proton exchange with the NH hydrogen of L1
and/or the protons of TsOH·H2O (for more de-
tails, see the supplementary materials, section 3.6).
Altogether, these results are consistent with our
proposed mechanism in Fig. 2.
We next explored the scope of ketones and
olefins for this transformation. Both cyclic and
acyclic ketones could be directly coupled with
ethylene gas to afford the ethyl-substituted ke-
tones (Fig. 3B). In general, cyclopentanones were
more reactive than cyclohexanones and acyclic
ketones, consistent with the established tenden-
Fig. 4. Preliminary mechanistic studies. (A) Structure of the enamine-Rh complex. (B) Synthesis
of a Rh‒H complex. (C) Deuterium-labeling experiments.
SCIENCE sciencemag.org
4 JULY 2014 • VOL 345 ISSUE 6192 71

RESEARCH
| REPORTS
REFERENCES AND NOTES
SEPARATION MEMBRANES
1. M. B. Smith, J. March, March’s Advanced Organic Chemistry
(Wiley, New York, 2001).
2. Y. Ono, Pure Appl. Chem. 68, 367 (1996).
3. T. Anastas, J. C. Warner, Green Chemistry: Theory and Practice
(Oxford Univ. Press, Oxford, 1998).
4. W. F. von Oettingen, The Halogenated Hydrocarbons of
Industrial and Toxicological Importance (Elsevier, Amsterdam,
New York, 1964).
5. G. Stork, R. Terrell, J. Szmuszkovicz, J. Am. Chem. Soc. 76,
2029–2030 (1954).
6. G. Stork, H. Landesman, J. Am. Chem. Soc. 78, 5128–5129
(1956).
Interfacial microfluidic processing of
metal-organic framework hollow
fiber membranes
Andrew J. Brown,1 Nicholas A. Brunelli,2,3 Kiwon Eum,2 Fereshteh Rashidi,2
7. R. C. Larock, Comprehensive Organic Transformations
(Wiley, New York, 1999).
J. R. Johnson,2 William J. Koros,2 Christopher W. Jones,1,2* Sankar Nair2*
8. F. Dénès, A. Pérez-Luna, F. Chemla, Chem. Rev. 110,
2366–2447 (2010).
9. T. Pei, R. A. Widenhoefer, J. Am. Chem. Soc. 123,
11290–11291 (2001).
10. X. Yao, C.-J. Li, J. Am. Chem. Soc. 126, 6884–6885 (2004).
11. J. J. Kennedy-Smith, S. T. Staben, F. D. Toste, J. Am.
Chem. Soc. 126, 4526–4527 (2004).
12. J. M. Conia, P. Le Perchec, Synthesis 1975, 1–19 (1975).
13. X. Wang, T. Pei, X. Han, R. A. Widenhoefer, Org. Lett. 5,
2699–2701 (2003).
14. Y.-P. Xiao, X.-Y. Liu, C.-M. Che, Angew. Chem. Int. Ed. 50,
4937–4941 (2011).
15. M. Nakamura, T. Hatakeyama, E. Nakamura, J. Am. Chem. Soc.
126, 11820–11825 (2004).
16. L. S. Hegedus, R. E. Williams, M. A. McGuire, T. Hayashi, J. Am.
Chem. Soc. 102, 4973–4979 (1980).
Molecular sieving metal-organic framework (MOF) membranes have great potential for
energy-efficient chemical separations, but a major hurdle is the lack of a scalable and
inexpensive membrane fabrication mechanism. We describe a route for processing MOF
membranes in polymeric hollow fibers, combining a two-solvent interfacial approach for
positional control over membrane formation (at inner and outer surfaces, or in the bulk,
of the fibers), a microfluidic approach to replenishment or recycling of reactants, and an
in situ module for membrane fabrication and permeation. We fabricated continuous
molecular sieving ZIF-8 membranes in single and multiple poly(amide-imide) hollow fibers,
with H2/C3H8 and C3H6/C3H8 separation factors as high as 370 and 12, respectively.
We also demonstrate positional control of the ZIF-8 films and characterize the
contributions of membrane defects and lumen bypass.
17. A. L. Rodriguez, T. Bunlaksananusorn, P. Knochel, Org. Lett. 2,
3285–3287 (2000).
18. S. Majima, Y. Shimizu, M. Kanai, Tetrahedron Lett. 53,
4381–4384 (2012).
19. T. Iwahama, S. Sakaguchi, Y. Ishii, Chem. Commun. (23):
2317–2318 (2000).
20. R. J. Comito, F. G. Finelli, D. W. C. MacMillan, J. Am.
Chem. Soc. 135, 9358–9361 (2013).
21. T. D. Beeson, A. Mastracchio, J. B. Hong, K. Ashton,
D. W. C. Macmillan, Science 316, 582–585 (2007).
22. Y. J. Park, J.-W. Park, C.-H. Jun, Acc. Chem. Res. 41, 222–234
(2008).
23. L. N. Lewis, J. F. Smith, J. Am. Chem. Soc. 108, 2728–2735
(1986).
24. D. A. Colby, R. G. Bergman, J. A. Ellman, Chem. Rev. 110,
624–655 (2010).
25. B. List, Chem. Rev. 107, 5413–5415 (2007).
26. C.-H. Jun, C. W. Moon, Y.-M. Kim, H. Lee, J. H. Lee, Tetrahedron
Lett. 43, 4233–4236 (2002).
olecular sieving membranes have created
interest as high-performance separation
systems for production of petro-based and
renewable fuels and chemicals. Compared
to thermodynamically driven separation
(12), we synthesized ZIF-90 membranes by seeded
growth on the outer surfaces of porous poly-
meric poly(amide-imide) (Torlon) hollow fibers
of ~250-mm outer diameter by immersion in a
methanolic precursor solution at mild condi-
tions (65°C). Free-standing MOF films can also
be synthesized at the interfaces between two im-
miscible solvents (13). However, molecular siev-
ing membranes on the inner surfaces of hollow
fibers also have advantages for rapid, scalable fab-
rication due to the ability to be bundled in close
proximity while avoiding membrane-membrane
contact points and interfaces that lead to defects
during synthesis. Synthesis of selective membranes
in microscopic confined spaces faces a number
of challenges: reactant availability and transport,
positional control of the membrane, and scal-
ability. As the bore size (and hence volume) is
decreased to microscopic dimensions, film for-
mation becomes limited by reactant availability
and local inhomogeneities (14).
We report a methodology for fabricating mo-
lecular sieving MOF membranes (specifically,
ZIF-8), which we refer to as interfacial micro-
fluidic membrane processing (IMMP) (Fig. 1).
IMMP thus combines three key concepts: (i)
in situ ZIF-8 film synthesis in the membrane mod-
ule (Fig. 1A); (ii) a two-solvent interfacial approach
(Fig. 1, B and C) that can be tuned to achieve po-
sitional control over membrane formation (at in-
ner and outer surfaces, as well as inside the bulk,
of the porous fiber); and (iii) the controlled sup-
ply, replenishment, and recycling of reactants at
microfluidic conditions in the hollow fiber bore.
Our approach can be applied more generally to
other MOF materials, but we demonstrate our
key findings here with the example of ZIF-8, which
has been identified as a promising candidate for
important separations such as H2 from hydro-
carbons and propylene from propane (3, 15). To
study the IMMP concept, we designed and fabri-
cated a reusable flow module that serves as
M
methods such as distillation, membrane-based
processes can substantially reduce the energy
and capital costs of separating molecules on a
large scale. Membranes composed of molecular
sieving materials such as zeolites (1), layered ze-
olites (2), or metal-organic frameworks (MOFs)
(3) have intrinsic advantages over polymeric mem-
branes, such as a simultaneously high perme-
ability and selectivity. Despite their performance
limitations, polymeric membranes have contin-
ued to dominate industrial membrane separa-
tions owing to their relative ease of processing
into morphologies such as hollow fibers (4). One
challenge facing molecular sieving membranes is
the lack of an easily scalable, reliable, and benign
fabrication process (5–7). Zeolite membranes are
further hampered by the need for hydrothermal
synthesis on high-cost support materials. MOFs
consist of metal centers connected by coordina-
tion bonds to organic linker molecules. They have
been used to grow crystalline membranes on disk
and tubular substrates through techniques sim-
ilar to those developed for zeolitic membranes
(8). The zeolitic imidazolite framework (ZIF) sub-
class of MOFs is of particular interest for mem-
brane fabrication because of its tunable pore size
and chemistry (9) and relatively good thermal
and chemical stability (10, 11). In an early dem-
onstration of scalable ZIF membrane processing
27. Z. Wang, B. J. Reinus, G. Dong, J. Am. Chem. Soc. 134,
13954–13957 (2012).
28. J. Kwak, Y. Ohk, Y. Jung, S. Chang, J. Am. Chem. Soc. 134,
17778–17788 (2012).
29. D. Sánchez et al., Org. Lett. 14, 536–539 (2012).
30. S. Murai et al., Nature 366, 529–531 (1993).
ACKNOWLEDGMENTS
We thank the University of Texas at Austin and Cancer
Prevention and Research Institute of Texas (R1118) for a start-up
fund and the Welch Foundation (F-1781) and NSF (CAREER:
CHE-1254935) for research grants. A provisional patent based
on this work has been filed by the University of Texas at Austin.
G.D. is a Searle Scholar. We thank V. Lynch for x-ray
crystallography. Metrical parameters for the crystal structures
of compounds S3a to S3g, S3j, S3r, S3s, 4 to 6, and 8 are
available free from the Cambridge Crystallographic Data Centre
under reference numbers CCDC-1003268 to -1003281,
respectively. We thank J. L. Sessler, M. J. Krische, and
D. R. Siegel for loaning chemicals; B. A. Shoulders, S. Sorey, and
A. Spangenberg for NMR advice; Y. Xu for thoughtful suggestions;
A. Dermenci and H. Lim for proofreading the manuscript; and
Z. Dong for checking and repeating the experimental procedure.
SUPPLEMENTARY MATERIALS
1School of Chemistry and Biochemistry, Georgia Institute of
Technology, Atlanta, GA 30332, USA. 2School of Chemical &
Biomolecular Engineering, Georgia Institute of Technology,
Atlanta, GA 30332, USA. 3Department of Chemical and
Biomolecular Engineering, The Ohio State University,
Columbus, OH 43210, USA.
www.sciencemag.org/content/345/6192/68/suppl/DC1
Materials and Methods
Supplementary Text
Table S1
References (31–58)
7 April 2014; accepted 27 May 2014
10.1126/science.1254465
*Corresponding author. E-mail: sankar.nair@chbe.gatech.edu
(S.N.); christopher.jones@chbe.gatech.edu (C.W.J.)
72 4 JULY 2014 • VOL 345 ISSUE 6192
sciencemag.org SCIENCE
