Structural basis for selective inhibition of Cyclooxygenase-1 (COX-1) by diarylisoxazoles mofezolac and 3-(5-chlorofuran-2-yl)-5-methyl-4-phenylisoxazole (P6)

Article abstract of DOI:10.1016/j.ejmech.2017.06.045

The diarylisoxazole molecular scaffold is found in several NSAIDs, especially those with high selectivity for COX-1. Here, we have determined the structural basis for COX-1 binding to two diarylisoxazoles: mofezolac, which is polar and ionizable, and 3-(5

Full text of DOI:10.1016/j.ejmech.2017.06.045

Accepted Manuscript
Structural basis for selective inhibition of Cyclooxygenase-1 (COX-1) by
diarylisoxazoles mofezolac and 3-(5-chlorofuran-2-yl)-5-methyl-4-phenylisoxazole
(P6)
Gino Cingolani, Andrea Panella, Maria Grazia Perrone, Paola Vitale, Giuseppe Di
Mauro, Cosimo G. Fortuna, Roger S. Armen, Savina Ferorelli, William L. Smith,
Antonio Scilimati
PII:
S0223-5234(17)30491-9
10.1016/j.ejmech.2017.06.045
EJMECH 9540
DOI:
Reference:
To appear in: European Journal of Medicinal Chemistry
Received Date: 3 May 2017
Revised Date: 21 June 2017
Accepted Date: 23 June 2017
Please cite this article as: G. Cingolani, A. Panella, M.G. Perrone, P. Vitale, G. Di Mauro, C.G.
Fortuna, R.S. Armen, S. Ferorelli, W.L. Smith, A. Scilimati, Structural basis for selective inhibition
of Cyclooxygenase-1 (COX-1) by diarylisoxazoles mofezolac and 3-(5-chlorofuran-2-yl)-5-
methyl-4-phenylisoxazole (P6), European Journal of Medicinal Chemistry (2017), doi: 10.1016/
j.ejmech.2017.06.045.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Structural basis for selective inhibition of Cyclooxygenase-1 (COX-1) by diarylisoxazoles
mofezolac and 3-(5-chlorofuran-2-yl)-5-methyl-4-phenylisoxazole (P6)
Gino Cingolania,b†, Andrea Panellac†, Maria Grazia Perronec, Paola Vitalec, Giuseppe Di Maurod,
Cosimo G. Fortunad, Roger S. Armene, Savina Ferorellic, William L. Smithf, Antonio Scilimati*,c
a Department of Biochemistry and Molecular Biology, Thomas Jefferson University, Philadelphia, PA
19107, USA;
b
Institute of Biomembranes and Bioenergetics, National Research Council, Via Amendola 165/A,
70125 Bari, Italy;
c Department of Pharmacy - Pharmaceutical Sciences, University of Bari “Aldo Moro”, Via E. Orabona
4, 70125 Bari, Italy;
d Department of Scienze Chimiche, Università di Catania, Viale Andrea Doria 6, 95125 Catania, Italy;
e
Department of Pharmaceutical Sciences, College of Pharmacy, Thomas Jefferson University,
Philadelphia, PA 19107, USA;
f Department of Biological Chemistry, University of Michigan, Ann Arbor, MI 48109, USA.
Corresponding Author. Department of Pharmacy-Pharmaceutical Sciences, University of Bari Aldo
Moro, Bari 70125. E-mail: antonio.scilimati@uniba.it Tel. +390805442753. Fax +390805442724.

ACCEPTED MANUSCRIPT
ABSTRACT
The diarylisoxazole molecular scaffold is found in several NSAIDs, especially those with high
selectivity for COX-1. Here, we have determined the structural basis for COX-1 binding to two
diarylisoxazoles: mofezolac, which is polar and ionizable, and 3-(5-chlorofuran-2-yl)-5-methyl-4-
phenylisoxazole (P6) that has very low polarity. X-ray analysis of the crystal structures of COX-1
bound to mofezolac and 3-(5-chlorofuran-2-yl)-5-methyl-4-phenylisoxazole allowed the identification
of specific binding determinants within the enzyme active site, relevant to generate structure/activity
relationships for diarylisoxazole NSAIDs.
Keywords Cyclooxygenase-1 inhibition, mofezolac, P6, diarylisoxazole, X-ray crystallography,
molecular modelling.

ACCEPTED MANUSCRIPT
ABBREVIATIONS:
COXIB, selective cyclooxygenase-2 inhibitor;
FLAP, Finger Print for Ligands and Proteins;
MBD, membrane binding domain;
PGHS -1 and -2, Prostaglandin endoperoxide H synthase-1 and -2;
PGG2, prostaglandin G2;
PGH2, prostaglandin H2;
POX, peroxidase;
SI, selectivity index.
3

ACCEPTED MANUSCRIPT
INTRODUCTION
Prostaglandin endoperoxide H synthase-1 and -2 (PGHS -1 and -2) also known as cyclooxygenases
(COXs) - are bifunctional, membrane-bound and heme-containing enzymes that catalyze the
conversion of free arachidonic acid (AA) into Prostaglandin H2 (PGH2), which represents the
committed step of prostanoid biosynthesis [1-3]. COX isoenzymes are inhibited through the action of
non-steroidal anti-inflammatory drugs (NSAIDs), which bind the COX active site, preventing AA
binding.
NSAIDs are a broad and heterogeneous group of drugs that belong to different chemical classes.
NSAIDs can be classified on the basis of their mechanisms of COX inhibition in three groups: (a) rapid
and reversible competitive inhibitors (e.g. ibuprofen and naproxen); (b) rapid, lower affinity, reversible
inhibitors followed by time-dependent, higher affinity, slowly reversible binding (e.g. indomethacin
and flurbiprofen); (c) rapid, reversible inhibitors followed by irreversible, covalent modification of the
enzyme (e.g. acetylation by aspirin) [4]. Another recurring classification of COX inhibitors is based on
their relative inhibitory potency for COX isoforms, quantitatively expressed as IC50 and selectivity
index (SI = COX-2 IC50 /COX-1 IC50). In this context, COX inhibitors can be divided into five main
groups: (a) compounds capable of producing full inhibition of both COX-1 and COX-2 with poor
selectivity; (b) compounds capable of producing full inhibition of COX-1 and COX-2 with preference
toward COX-2; (c) compounds that strongly inhibit COX-2 with only weak activity against COX-1; (d)
compounds that strongly inhibit COX-1 with only weak activity against COX-2; and (e) compounds
that are weak inhibitors of both COX-1 and COX-2 [4-5]. Finally, from a chemical point of view,
NSAIDs are grouped into three main classes: (a) carboxylic acids (salicylic acid and its esters, acetic
acids, propionic acids, fenamic acids), (b) phenazones (pyrazolones, oxicams) and (c) non-acidic
compounds [5].
4

ACCEPTED MANUSCRIPT
At the core of COX-1 catalytic activity is the ability to trap AA between residues R120/Y355 and the
catalytic Y385. Similar to the substrate AA, the majority of NSAIDs containing a carboxylic acid
interacts with COXs forming a salt bridge with the guanidinium group of the conserved R120, located
at the entrance of the hydrophobic active site channel. This residue orients the aromatic portion of
NSAIDs toward the catalytic Y385, located at the top of the COX active site. A tyrosyl radical at Y385,
generated upon transfer of an electron to the heme, removes a hydrogen atom from the carbon-13 of
AA: the AA-radical intermediate is then converted into prostaglandine G2 (PGG2) and prostaglandine
H2 (PGH2) by COX cyclooxygenase- and peroxidase-activities, respectively [1-3]. Aspirin, the only
irreversible COXs inhibitor, is recognized by R120 through its benzoic acid moiety and covalently
modifies both COX-1 and COX-2 through acetylation of S530. Acetylation renders COXs completely
inactive [6], preventing AA access to the catalytic site. Unlike aspirin, other NSAIDs reversibly inhibit
COX activity with different selectivity for the two isoforms.
Over the last two decades, limited effort has been devoted to developing selective COX-1 inhibitors [7-
9], possibly due to the scarce knowledge of COX-1 biology and its involvement in human diseases
[10]. In contrast, many COX-2 inhibitors (COXIBs) have been identified and characterized at the
molecular level, and found in most cases to contain a diarylheterocycle bearing either a sulfonamide or
a methylsulfamoyl group. The development of COXIBs solved in part the selectivity problem in favor
of COX-2 [4-5]. This effort was undertaken to reduce the gastrointestinal (GI) adverse effects
associated with the poor COXs selectivity of most traditional NSAIDs, which was mistakenly
associated with selective COX-1 inhibition [11-13]. Our discovery of 3-(5-chlorofuran-2-yl)-5-methyl-
4-phenylisoxazole (P6) [7] (Fig. 1) as a highly selective COX-1 inhibitor lacking GI toxicity [11]
5

ACCEPTED MANUSCRIPT
prompted us to attempt in-depth structural modifications of this inhibitor, in order to understand how
replacement of chemical moieties affects COX-1 selectivity [5,14-16]. Overall, the selectivity of
NSAIDs for COXs remains an open target, mainly due to the similarity between COX isoforms and the
complex chemistry of NSAIDs binding to the active site [4,5].
Crystallographic studies on COX-1 and COX-2 have elucidated the detailed architecture and
active site organization of these vital enzymes. COXs contain a long hydrophobic channel that spans
~25 Å from the membrane binding domain to the active site [4,5]. The entry of this channel contains a
‘lobby’ that narrows down into a constriction formed by three crucial residues: R120, Y355 and E524.
This constriction opens up to allow substrates or inhibitors to entry into the channel, which is mainly
hydrophobic. Crystal structures of COX-1 and COX-2 in complex with AA found that as many as
nineteen amino acids in this channel make fifty close contacts with the substrate [1-4], underscoring a
remarkably complex chemistry of substrate-binding. As of 2017, twenty-one of the twenty-seven
crystal structures of COX-1 deposited in the RCSB database include complexes with NSAIDs. In all
these structures, which were determined between 2.0 and ~3.4 Å resolution, the carboxylate moiety of
acidic NSAIDs is always found to interact with the guanidinium group of R120. Consistently, binding
of AA and NSAIDs containing a carboxylic moiety to COX-1 is greatly perturbed when R120 is
mutated to a smaller uncharged residue [17-18]. Although most classical NSAIDs are non-selective
inhibitors, in general, they seem to bind more tightly to COX-1 than COX-2, possibly due to the
strength of the ionic interaction between the inhibitor carboxylate anion and the guanidinium cation of
COX-1 R120 [3]. In this paper, we report an optimized synthetic procedure for mofezolac and 1 (P6),
and the identification of their interactions with COX-1 active site through X-ray crystallographic
analysis and molecular modeling. This work paves the way to decipher the structural basis for selective
inhibition of COX-1 by diarylisoxazole-moiety containing compounds.
6

ACCEPTED MANUSCRIPT
RESULTS AND DISCUSSION
Two diarylisoxazoles were selected for this study (Fig. 1): mofezolac, a polar and ionizable NSAID,
and 1 (P6) that has very low overall polarity. In mofezolac, the isoxazole group is linked to two mildly
polar 4-methoxyphenyl groups at position C3 and C4 and to a highly polar acetic moiety at C5.
Figure 1. Chemical structures of mofezolac and 1 (P6), and their IC50 for COX-1 and COX-2 obtained
using a colorimetric inhibitor screening assay [21].
In contrast, 1 (P6) isoxazole is linked to a moderately polar 5-chlorofuranyl group at position C3 and
two apolar groups, a phenyl at C4 and a methyl at C5. Mofezolac is clinically used as an analgesic drug
in Japan, and preferentially inhibits COX-1 [19,20]. It functions like a time-dependent/slowly
reversible inhibitor, similar to indomethacin [8] and its IC50 values are 0.0079 and >50 µM for COX-1
and COX-2, respectively [21]. In contrast, 1 (P6) is a weaker, time-independent/competitive reversible
inhibitor similar to ibuprofen [8], for which we measured IC50 values of 19 and >50 µM for COX-1 and
COX-2, respectively [21].
Docking studies of selected diarylisoxazole NSAIDs with COX-1 revealed several equally plausible
binding poses [5,10]. This ambiguity, which is a direct consequence of the large number of bonding
7

ACCEPTED MANUSCRIPT
groups in the COX-1 channel, hinders optimization and rational design of new diarylisoxazole NSAIDs
with enhanced therapeutic properties. To gain insights into the chemistry of binding and inhibition of
COX-1, we have determined crystal structures of the ovine COX-1 (oCOX-1) in complex with
mofezolac and 1 (P6). oCOX-1:mofezolac and oCOX-1:1 (P6) complexes were solved by molecular
replacement and refined to an Rwork/free of 18.60/22.96% and 21.09/24.27%, at 2.75 Å and 2.93 Å
resolution, respectively (Table S1). Unlike previous structures of oCOX-1 [22-24], the current crystals
do not suffer from twinning, allowing for an accurate structural analysis of mofezolac and 1 (P6)
binding to oCOX-1 even at moderate resolution.
Figure 2. Crystallographic analysis of mofezolac and 1 (P6) bound to oCOX-1. (A, B) Right panel:
surface representation oCOX-1 with the two chains colored in cyan and yellow. Fe3+-protoprophyrin IX
(blue), carbohydrates moieties and βOG (green) are also shown. Left panel: Fo-Fc polder OMIT map
for mofezolac (A) and 1 (P6) (B) contoured at 2σ (cyan) and 4σ (purple) above background. The OMIT
maps were calculated using all reflections between 15 - 2.75 Å resolution for mofezolac and 15 - 2.93
Å for 1 (P6) and are overlaid to the final refined atomic models.
8

ACCEPTED MANUSCRIPT
The overall architecture of oCOX-1 in our crystallographic complexes (Fig. 2A and 2B) is similar to
previously reported structures of the enzyme [22]. oCOX-1 crystallizes as a homodimer in the
asymmetric unit, though the two subunits are thought to function as a heterodimer in vivo [22]. oCOX-
1 consists of two ∼72 kDa subunits tightly packed against each other via an extensive binding interface
spanning ~2,500 Å2. Each COX-1 protomer contains an epidermal growth factor-like domain, a
membrane binding domain (MBD), and a large catalytic core bound to a Fe3+-protoprophyrin IX ring
(heme group) that harbors both COX and peroxidase (POX) enzymatic activities. The COX active site
lies on the opposite side of the POX active site, which activates the heme necessary for the
cyclooxygenase reaction. The two active sites are connected via a ~25 Å long L-shaped hydrophobic
channel that originates in the MBD and is partially accessible to NSAIDs. Mofezolac and 1 (P6) were
identified in unbiased Fo-Fc OMIT maps at the entry of the COX-1 hydrophobic channel in the
proximity of R120 and Y355, where NSAIDs are known to interact with COXs [23,24]. Fig. 2A shows
a representative Fo-Fc OMIT electron density map for mofezolac contoured at 4σ(purple) and 2σ
(cyan) above background and overlaid to the final refined model of mofezolac that has an overall B-
factor of ~75 Å2, comparable to that of oCOX-1 atoms. The orientation of mofezolac inside oCOX-1
active site was unambiguously determined due to the excellent electron density and asymmetric shape
of this compound that has a carboxyl group above the diarylisoxazole (Fig. 2A).
In contrast, the electron density for 1 (P6) was less continuous and could be unambiguously identified
only after excluding the bulk solvent around the omitted region (Fig. 2B). An Fo-Fc polder OMIT map
countered at 2σ above background revealed a ‘V-shaped’ density consistent with the expected quasi-2-
fold symmetric structure of 1 (P6) (Fig. 1). At higher contour, the density breaks off into three peaks
(colored in purple in Fig. 2B), two of which are connected (right hand side in Fig. 2B) and one that is
9

ACCEPTED MANUSCRIPT
more spherical (left hand side in Fig. 2B) and visible up to 6 σ We assigned the central density to the
isoxazole group of 1 (P6), and the globular peak on the left that lacks continuity with the isoxazole
group to the more electron-dense chlorine atom of the 5-chlorofuranyl group at position C3. In turn, the
density peak continuous to the isoxazole was assigned to the phenyl ring at position C4 that has
delocalized π-electrons. No density was observed for the methyl group at position C5 of the isoxazole.
The refined B-factor of 1 (P6) (~115 Å2) is much higher than oCOX-1 atoms and mofezolac,
underscoring the high isotropic displacement of 1 (P6) atoms inside the active site channel. 1 (P6)
atoms move dynamically around the positions defined by the atomic model and thus the electron
density in Fig. 2B represents the resultant of different conformations averaged over all COX-1:1 (P6)
complexes in the crystallographic lattice.
The crystal structure of COX-1 bound to mofezolac, refined at 2.75 Å resolution, reveals the drug binds
the enzyme active site in a planar conformation, with one methoxyphenyl group inserted deep inside
the active site channel facing Y385 and the other methoxyphenyl group sandwiched between Y355 and
F518 (Fig. 3A). The carboxyl moiety at position 5 of the isoxazole group faces the active site channel
entry point, occupied by an n-octyl-β-D-glucoside (βOG) in our structure. Hence, mofezolac makes
two sets of interactions with COX-1 residues lining the active site channel. First, the anionic
carboxylate makes a salt bridge with the cationic guanidinium group of R120. This salt bridge is the
combination of an electrostatic contact between opposite charges (e.g. both mofezolac and guanidinium
are charged at the pH of crystallization) and three close-distance (e.g. 2.5-2.8 Å) hydrogen bonds (H-
bonds), namely two H-bonds between mofezolac carboxylate and R120 ε- and η-nitrogen atoms and
one H-bond with Y355 hydroxyl group (Fig. 3C). Second, mofezolac makes 83 non-bonded, mainly
van der Waals and hydrophobic contacts with 17 residues in the COX-1 channel in a distance range
between 3.5-4.5 Å (Fig. 3A). Notably, the two methoxyphenyl groups see different chemical
10

ACCEPTED MANUSCRIPT
environments. The methoxyphenyl at C3 is surrounded by almost exclusively hydrophobic residues
(Y385, W387, F381, L384 and G526), including the catalytic Y385, while the methoxyphenyl group at
C4 makes van der Waals interactions with more polar residues such as Q192, S353, H90 and Y355, as
well as hydrophobic contacts with I523, F518 and L352. Overall, the combination of electrostatic, H-
bonds, hydrophobic and van der Waals contacts results in a remarkable surface complementarity that
cements mofezolac inside the COX-1 active site channel, explaining its low IC50 (Fig. 1).
Figure 3. Structural determinants for mofezolac and 1 (P6) binding to oCOX-1 active site. Residues in
oCOX-1 active site within 2.5 - 4.5 Å bonding distance for (A) mofezolac and (B) 1 (P6). The semi-
11

ACCEPTED MANUSCRIPT
transparent spheres around mofezolac, 1 (P6) and heme represent van der Waals radii. An n-octyl-β-D-
glucoside (βOG) molecule located at the entrance of the channel is shown in magenta. (C) Comparing
the position of mofezolac and 1 (P6) isoxazole group with AA bound to the COX-1 active site.
In the crystal structure of COX-1 bound to 1 (P6), the chlorofuranyl group of 1 (P6) faces down toward
the active site channel entry point (Fig. 3B) at a position occupied by the bulkier carboxyl group in the
COX-1:mofezolac complex (Fig. 3A). The 1 (P6) chlorine atom is coordinated by Y355 and R120,
similar to the free chlorine atom found in the active site of the RNA phosphatase PIR1, which is also
coordinated by a Y/R pair [25]. Analysis of the chemical interactions between 1 (P6) and COX-1 in a
distance range 2.5 - 4.5 Å reveals that the drug is stabilized by two H-bonds and 56 non-bonded
contacts with 9 residues of COX-1 (Fig. 3B). The H-bonds involve the ε-nitrogen of COX-1 R120 and
1 (P6) chlorine atom (2.4 Å distance) and the hydroxyl group of Y355 with the furanyl oxygen atom of
1 (P6) (Fig. 3C). 1 (P6) isoxazole group makes van der Waals and hydrophobic contacts with S353,
L352, V349, I517 and I523 (Fig. 3B) and the phenyl ring engages in hydrophobic interactions with
I517, L352, V349 and F518. However, COX-1 aromatic residues F381, Y385 and W387, which are
important binding determinants for mofezolac, are located more than 5 Å away from 1 (P6), and thus
unlikely to significantly contribute to the overall energetics of interaction. The binding free energies
(∆G) of mofezolac and 1 (P6) for oCOX-1 calculated from atomic coordinates are -10.2 and -6.9
kcal/mol, respectively (Table S2). A free energy difference of ~3 kcal/mol is in good agreement with
the structural data, supporting the notion that mofezolac binds oCOX-1 with much higher affinity than
1 (P6).
12

ACCEPTED MANUSCRIPT
Both mofezolac and 1 (P6) are isoxazole-derivatives, but the position of the isoxazole-group differs
greatly in the two complexes. 1 (P6)-isoxazole is rotated by 180° as compared to mofezolac, with the
phenyl ring occupying a position almost superimposable to the methoxyphenyl group of mofezolac
(Fig. 3C). In both drugs, this hydrophobic moiety mimics the aliphatic chain of AA, which, however, is
longer and inserts itself deeper inside the COX-1 hydrophobic channel (Fig. 3C). Thus, 1 (P6) weak
inhibition of COX-121 as compared to mofezolac (IC50 ~19 vs 0.0079 µM, respectively) can be
explained by the lack of an ionic interaction with R120, at the mouth of the COX-1 tunnel, and fewer
hydrophobic contacts with COX-1 channel residues facing the heme, especially F381, Y385 and W387.
This imperfect complementarity may cause 1 (P6) to ‘wobble’ or even partially rotate inside the COX-
1 substrate/inhibitor-binding channel, explaining the high B-factor of 1 (P6) atoms observed in our
structure. Despite these differences, mofezolac and 1 (P6) do not make water-mediated contacts with
COX-1 residues [26] and in both structures the conformation of Leu531 is consistent with the closed
conformation of the enzyme [27].
13

ACCEPTED MANUSCRIPT
Figure 4. Schematic representation of the structural differences between mofezolac and 1 (P6) bound
to the substrate/inhibitor-binding channels of (A) COX-1 and docked inside (B) COX-2. Adapted from
reference [28].
The IC50 values of mofezolac and 1 (P6) for COX-1 are over two orders of magnitude lower than for
COX-2 (mofezolac and 1 (P6) SI is ~ 3 and 6,300, respectively) (Fig. 1). Comparing the structure of
human COX-2 [29] with the crystallographic complexes of oCOX-1 described in this paper provides
clues to decipher the structural basis for this selectivity. COX-2 has a 20-25% larger and more
accessible substrate/inhibitor-binding channel than COX-1 [3], and contains an additional hydrophilic
side-pocket in the proximity of F518 (Fig. 4A,B). Access to this pocket is restricted in COX-1 by three
aminoacid substitutions: I523 and I434, both replaced by valines in COX-2, and H513 (R513 in COX-
2) that fills the pocket. 1 (P6) poor IC50 for COX-2 (>50 µM) can be explained by the larger
substrate/inhibitor-binding channel of this isoform and the more hydrophilic nature of the drug-binding
site, which provides an energetically unfavorable chemical environment for a poorly polar molecule
like 1 (P6) (Fig. 4B). Though more polar and ionizable, mofezolac inserts one of the two
methoxyphenyl group toward F518, making a stacking interaction with I523 (Fig. 4A). This contact is
likely weaker in COX-2 where I523 is replaced by the smaller and less hydrophobic V523. In
summary, mofezolac and 1 (P6) selectivity for COX-1 are a direct consequence of the snugger fit
between these diarylisoxazole NSAIDs and the smaller active site channel of this isoform.
14

ACCEPTED MANUSCRIPT
Figure 5. Difference in cavities (yellow) in COX-1 bound to mofezolac (purple) versus 1 (P6) (blue).
To investigate how mofezolac and 1 (P6) affect the overall structure of oCOX-1, we performed
molecular modelling studies using the software FLAP (Finger Print for Ligands and Proteins) [30]. We
removed all ligands from the atomic coordinates of the oCOX-1:mofezolac and oCOX-1:1 (P6)
complexes and calculated all binding cavities in oCOX-1 for each structure (Fig. 5). Interestingly, we
identified eleven internal cavities in the structure of oCOX-1 bound to mofezolac and only nine in the
complex with 1 (P6). As the two complexes were crystallized under identical conditions, have equal
crystal contacts and are crystallographically isomorphous, the difference in internal cavities is
presumably caused by bound inhibitors and may reflect the way different NSAIDs affect the enzyme
breathing motion. The larger, more polar and potent mofezolac fits tightly inside the oCOX-1 channel,
bridging the Y355/R120 pair at the channel entry with the catalytic Y385 (Fig. 4A), thereby reducing
the enzyme breathing motion and freezing its internal cavities. On the contrary, 1 (P6) is smaller, lacks
contacts with the aromatic residues next to the heme (Fig. 3B) and moves dynamically inside COX-1
substrate channel allowing the enzyme to breathe more dynamically. This is consistent with the lower
resolution of oCOX-1:1 (P6) crystals and smaller number of internal cavities identified by FLAP.
15

ACCEPTED MANUSCRIPT
CONCLUSION
In recent years, there has been a growing interest in developing selective inhibitors of COX-1. This
isoform is proven to play a critical role in the inflammatory processes that lead to many
neurodegenerative diseases and cancers, mainly ovarian cancer. In addition, low dose aspirin, a
commonly used antithrombotic drug and a selective and irreversible inhibitor of platelet COX-1, is a
poor drug that fails to prevent as many as 80% of non-fatal and fatal cardiovascular events [31].
Incomplete suppression of platelet thromboxane A2 (TXA2) biosynthesis by aspirin has also been
implicated in aspirin resistance [32]. Thus, the development of novel and potent COX-1 inhibitors is a
major focus of modern pharmaceutical research. A number of highly selective COX-1 inhibitors share
a diarylisoxazole scaffold [7,8]. This study describes the structural basis for selective inhibition of
COX-1 by diarylisoxazoles mofezolac and 1 (P6). Our structural data suggest the low IC50 of
mofezolac for COX-1 depends on the snug fit of this drug with the enzyme active site, whereas 1 (P6)
lower potency correlates with the smaller size of this NSAID and its wobble inside the active site
channel. In turn, the selectivity of both diarylisoxazoles for COX-1 appears to be a direct consequence
of the smaller substrate/inhibitor-binding channel of this isoform that has greater van der Waals
complementarity than COX-2. We validate the importance of a carboxylic group in mofezolac, or a
halogen in 1 (P6), essential to make contacts with Arg120/Try355 at the entry of the active site
channel, while the bulkiness and chemical features of substituents linked to the central heterocycle
appears to control the avidity for the COX-1 channel [5]. In summary, this work paves the way for the
development of novel COX-1 inhibitors with enhanced potency, greater selectivity and reduced
toxicity.
16

ACCEPTED MANUSCRIPT
EXPERIMENTAL SECTION
Reagents and procedures. AA was purchased from Cayman Chemical Co (Ann Arbor, MI). Hemin
(heme) was purchased from Frontier Scientific (Logan, UT). N-octyl β-D-glucopyranoside (β-OG) and
C10E6 were purchased from Anatrace (Maumee, OH). BCA protein reagent was purchased from
Pierce (Thermo Scientific). EDTA free protease inhibitor was purchased from Roche Applied Science.
Nickel-NTA Agarose beads were purchased from Gold Biotechnology. All other chemicals (reagents
and solvents) were purchased from Sigma Life Science. Mofezolac was prepared by us following a
known procedure [33] with a slight modification. Briefly, desoxyanisoin oxime was prepared by
reacting desoxyanisoin (10 g, 39 mmol) and NH2OH•HCl (76 mmol) in methanol/water (60 and 50 mL,
respectively). NaOH (0.12 mol) was, then, slowly added. The reaction mixture was stirred for 15
minutes and then heated to 70°C. After 1h, methanol was added to the hot mixture until dissolution was
almost complete. The mixture was filtered and the methanol distilled under reduced pressure. The
residue was cooled by adding ice-water, filtered and the resulting solid dissolved in ethyl acetate
(EtOAc) and treated with brine. The organic layer was dried over anhydrous Na2SO4, filtered and
concentrated to obtain the oxime as a yellow solid (9 g, 85% yield). It was used without any further
purification to prepare the 3,4-di(4-methoxyphenyl)-5-methylisoxazole direct precursor of mofezolac.
Hence, 2.4 N n-BuLi (3.1 mL, 7.4 mmol) was slowly added to a solution of the oxime (1 g, 3.7 mmol)
in tetrahydrofuran (THF) (40 mL) kept at -15 °C and under argon atmosphere. The reaction mixture
was stirred at 0°C for 30 minutes, and then ethyl acetate (0.15 g, 2 mmol) in THF (15 mL) was added.
After 15 minutes, 6 N HCl (100 mL) was added and the reaction mixture refluxed with stirring by an
oil-bath for 18h, cooled and the layers separated. The aqueous layer was extracted with EtOAc (3 x 100
mL). The combined organic layers were dried with Na2SO4, filtered and the solvent removed under
17

ACCEPTED MANUSCRIPT
reduced pressure. Methanol was added to the reaction crude, cooled and the crystalline desoxyanisoin
removed by filtration. The filtrate was concentrated and then treated with warm ethanol (5 mL). On
cooling in a freezer overnight the 3,4-di(4-methoxyphenyl)-5-methylisoxazole was obtained as a
1
colorless solid. Mp 95-98 °C after recrystallization from ethanol (307 mg, 50% yield). H-NMR (300
MHz, CDCl3, δ): 7.37 (d, 2H, J = 9.0 Hz); 7.09 (d, 2H, J = 9.0 Hz); 6.90 (d, 2H, J = 9.0 Hz); 6.83 (d,
2H, J = 9.0 Hz); 3.80 (s, 3H); 3.83 (s, 3H); 2.40 (s, 3H). 3,4-Di(4-methoxyphenyl)isoxazol-5-acetic
acid (mofezolac) was prepared by dropwise adding 1.6 N n-BuLi (5 mL) to a stirred cold (dry ice–
acetone bath) solution of 3,4-di(4-methoxyphenyl)-5-methylisoxazole (2 g, 7 mmol) in THF (30 mL)
under an argon atmosphere. After stirring for 1h at -75 °C, anhydrous gaseous CO2 was flushed into the
stirred red colored reaction mixture till the disappearance of the colour. Then, the stirred reaction
mixture was allowed to warm to room temperature, concentrated, and the residue dissolved in water.
The resulting solution was twice extracted with EtOAc. The organic phase was cooled and acidified
with concentrated HCl. The layers were separated and the aqueous phase extracted with ethyl acetate.
The combined organic extracts were dried over anhydrous Na2SO4, filtered and the solvent removed
under reduced pressure. The obtained sticky foam residue was recrystallized from toluene to give
1
mofezolac as a colorless solid (1.68 g, 71% yield). Mp 142-143 °C. H-NMR (300 MHz, CDCl3, δ):
9.55 (bs, 1H: exchanges with D2O); 7.40-7.38 (d, 2H, J = 8.8 Hz, aromatic protons); 7.15-7.13 (d, 2H, J
= 8.8 Hz, aromatic protons); 6.93-6.91 (d, 2H, J = 8.8 Hz, aromatic protons); 6.84-6.82 (d, 2H, J = 8.8
Hz, aromatic protons); 3.83 (s, 3H); 3.81 (s, 2H); 3.79 (s, 3H).
3-(5-Chlorofuran-2-yl)-5-methyl-4-phenylisoxazole
was
synthesized
starting
from
2-
furancarbaldehydoxime, in turn prepared from the reaction of the 2-furancarbaldehyde and
NH2OH•HCl in aqueous/EtOH (1:1) in the presence of NaOH. 2-Furancarbaldehydoxime (0.5 g, 4.5
mmol) dissolved in anhydrous dimethyl formamide (DMF) (5 mL), contained in a round-bottom flask
18

ACCEPTED MANUSCRIPT
equipped with magnetic stirrer, was cooled to 0°C. N-Chlorosuccinimide (NCS) (1.2 g, 9.0 mmol) was
slowly added, and the obtained suspension was stirred for 5 h to room temperature. Then, ethyl ether
was added and the solution was washed three times with water to remove DMF. The combined organic
extracts were dried over anhydrous Na2SO4, and then the solvent was evaporated under vacuum. The
residue was dissolved in EtOAc. A pale yellow solid of 5-chloro-2-furancarbohydroximoyl chloride
formed (75% yield) by slow addition of petroleum ether (ethyl acetate/petroleum ether = 1:1). The
obtained 5-chloro-2-furancarbohydroximoyl chloride (3.87 mmol) was then converted into the nitrile
oxide by NEt3 (3.87 mmol), that after NEt3•HCl removal by filtration, was added dropwise to a yellow
suspension of NaH (95% w/w, 4.26 mmol) and phenylacetone (0.518 mL, 3.87 mmol) in THF (20 mL)
at 0 °C for 1h under nitrogen atmosphere, using a nitrogen-flushed, three-necked flask equipped with a
magnetic stirrer, a nitrogen inlet, and two dropping funnels. The reaction mixture was allowed to reach
room temperature and stirred overnight. The reaction was quenched by adding aqueous NH4Cl
solution. The reaction product was extracted three times with ethyl acetate. The combined organic
phases were dried over anhydrous Na2SO4 and then the solvent distilled under vacuum affording 1 (P6)
in 60% yield. Mp 71-73 °C (yellow crystals). FT-IR (KBr): 3147, 3051, 2927, 2848, 1633, 1520, 1435,
1
1412, 1236, 1204, 1134, 1020, 985, 940, 926, 897, 796, 775 cm-1. H-NMR (300 MHz, CDCl3, δ):
7.40-7.47 (m, 3H, aromatic protons); 7.25-7.30 (m, 2H, aromatic protons); 6.25-6.27 (d, 1H, J = 3.6
Hz); 6.11-6.12 (d, 1H, J = 3.6 Hz); 2.36 (s, 3H). 13C-NMR (75 MHz, CDCl3, δ): 11.41, 108.14, 113.87,
114.99, 128.58, 129.01, 129.63, 130.20, 138.59, 143.76, 152.42, 167.10. GC-MS (70 eV) m/z (rel int):
261 [M(37Cl)+, 5], 259 [M(35Cl)+, 15], 219 (11), 217 (36), 154 (17), 127 (10), 89 (14), 77 (9), 63 (10),
51 (12), 43 (100). If 3-(5-chlorofuran-2-yl)-5-hydroxy-5-methyl-4-phenyl-2-isoxazoline [direct 1 (P6)
precursor] is present in the ethyl acetate extracts (TLC analysis) obtained after quenching the reaction
mixture with NH4Cl, it can be separated by column chromatography (silica gel, petroleum ether/ethyl
19

ACCEPTED MANUSCRIPT
acetate = 15/1) of the reaction crude and converted into 1 (P6) by Na2CO3/methanol under reflux for
2h.
Protein expression and purification. The gene encoding oCOX-1 was cloned in a modified pFastBac
vector (Invitrogen) engineered with an N-terminal 8X-his tag and a TEV protease cleavage. Generation
of recombinant baculovirus, expression of recombinant his-tagged oCOX-1, and purification of
untagged oCOX-1 were carried out as previously described [22]. O2 consumption (see functional assay
paragraph) was measured at each step of purification and increased from 136,165 to 210,998 nmol/min:
the final purified oCOX-1 had specific activity of 40,000 unit/mg ± 0.49. Purified oCOX-1was
concentrated using a Millipore Ultrafree-15 spin concentrator to 5-6 mg/ml (as assessed by BCA
protein assay, Pierce, Rockford, IL) in HEPES pH = 7.0, 40 mM NaCl and 0.4% ß-OG and used for
crystallization.
Crystallographic methods - oCOX-1 was reconstituted with a 2-fold molar excess of heme (Fe3+-
protoprophyrin IX) and 2-fold molar excess of mofezolac [or 1 (P6) ]and allowed to incubate at room
temperature for 10 min before setting up crystallization trays. Crystallization trials were set up at 25°C
using the sitting-drop vapor diffusion method. 1 µL of protein was mixed with 1 µL of drop solution
consisting of 0.5-0.9 M LiCl, 0.7 M sodium citrate pH 6.5, 1 mM sodium azide and 0.3 %(w/v) β-OG
and was equilibrated within a reservoir containing 0.6-0.85 M LiCl, 0.7 and 0.85 M sodium citrate pH
6.5 and 1mM sodium azide. Crystals appeared within 2-3 weeks. Prior to data collection, crystals were
harvested, briefly soaked in a solution containing 1M sodium citrate, 1M LiCl, 0.15% β-OG, and 1mM
sodium malonate as a cryo-protectant and flash-frozen in liquid nitrogen. Diffraction data were
collected at beam line 21-ID-F, Life Science-Cat (Argonne National Laboratory, Argonne, IL) on a
MARMOSAIC 225 CCD detector and processed using HKL2000 [34]. The structure was solved by
molecular replacement (MR) using the program PHASER [35] and oCOX-1 (PDB 3KK6) as a search
20

ACCEPTED MANUSCRIPT
model. For both crystal structures, the hexagonal asymmetric unit contains a dimer of oCOX-1 that was
subjected to iterative cycles of positional and B-factor refinement using distinct TLS groups using
phenix.refine [36]. Ligands and water molecules in the structure were identified in Fo-Fc electron
density difference maps. Mofezolac and 1 (P6) were identified in Fo-Fc polder maps, as implemented
in phenix.polder. Visualization and model building were done using Coot [37]. The final models
consist of residues 32-584, Fe3+-protoprophyrin IX, carbohydrates moieties linked to N68, N144 and
N410, four βOGs and mofezolac or 1 (P6) bound in the oCOX-1 active site of each monomer and a few
water molecules (Table S1). Figures were generated using PYMOL [38].
Functional analysis of oCOX-1 - COX activity was monitored by O2 consumption using a Clark-type
O2 sensitive electrode (YSI 5300 A, Yelow Springs, Ohio). A typical assay consisting of 100 mM Tris-
HCl (pH 8.0) containing 1 mM phenol, 1.5 µL of 1 mM heme, 50 µL of 100 µM AA, 50 µL of protein
(3 mL final volume). Mofezolac and 1 (P6) inhibition of COXs was measured using a colorimetric
inhibitor screening assay, as described in reference [21].
Computational Methods - The computational tools employed in this work are mainly part of FLAP
package [30]. FLAP was employed in structure-based mode using the crystallographic structures of
COX-1:mofezolac and COX-1:1 (P6) as templates. Binding free energies were computed from atomic
coordinates as described in reference [39].
Funding Sources. This work was supported by research funds through the University of Bari; MIUR
(Rome - Italy) for Progetti di Ricerca Industriale nell'ambito del Programma Operativo Nazionale R&C
2007-2013 e Project "Research, Application, Innovation, Services in Bioimaging (R.A.I.SE.)" code
PON01_03054; First AIRC Grant-MFAG2015 (Project Id. 17566). GC was supported in part by a
DTSA intramural award. Research in this publication includes work carried out at the SKCC X-ray
21

ACCEPTED MANUSCRIPT
Crystallography and Molecular Interaction Facility at Thomas Jefferson University, which is supported
in part by NCI Cancer Center Support Grant P30 CA56036 and S10 OD017987.
Acknowledgment
We thank Dr. Sidhu at Cayman Chemical Company for help throughout the project. Coordinates and
structure factors have been deposited in the protein data bank (PDB id 5HQK and 5U6X). Authors will
release the atomic coordinates and experimental data upon article publication.
REFERENCES
[1] W.L. Smith, R.M. Garavito, D.L. DeWitt, Prostaglandin endoperoxide H synthases
(cyclooxygenases) -1 and -2, J. Biol. Chem. 271 (1996) 33157-33160.
[2] L.J. Marnett, S.W. Rowlinson, D.C. Goodwin, A.S. Kalgurtkar, C.A. Lanzo, Arachidonic acid
oxygenation by COX-1 and COX-2 – Mechanism of catalysis and inhibition, J. Biol. Chem. 274 (1999)
22903-22906.
[3] W.L. Smith, D.L. DeWitt, R.M. Garavito, Cyclooxygenase: structural, cellular, and molecular
biology, Annual Rev. Biochem. 69 (2000) 149-182.
[4] M.G. Perrone, A. Scilimati, L. Simone, P. Vitale, Selective COX-1 inhibition: a therapeutic target
to be reconsidered, Curr. Med. Chem. 17 (2010) 3769-3805.
[5] P. Vitale, A. Scilimati, M.G. Perrone, Update on SAR studies toward new COX-1 selective
inhibitors, Curr. Med. Chem. 22 (2015) 4271-4292.
[6] J.R. Vane, R.M. Botting, The mechanism of action of aspirin, Thromb. Res. 110 (2003) 255-258.
22

ACCEPTED MANUSCRIPT
[7] L. Di Nunno, P. Vitale, A. Scilimati, S. Tacconelli, P. Patrignani, Novel synthesis of 3,4-
diarylisoxazole analogues of valdecoxib: reversal cyclooxygenase-2 selectivity by sulfonamide group
removal, J. Med. Chem. 47 (2004) 4881-4890.
[8] P. Vitale, S. Tacconelli, M.G. Perrone, P. Malerba, L. Simone, A. Scilimati, A. Lavecchia, M.
Dovizio, E. Marcantoni, A. Bruno, P. Patrignani, Synthesis, pharmacological characterization, and
docking analysis of a novel family of diarylisoxazoles as highly selective cyclooxygenase-1 (COX-1)
inhibitors, J. Med. Chem. 56 (2013) 4277-4299.
[9] M.J. Uddin, A.V. Elleman, K. Ghebreselasie, C.K. Daniel, B.C. Crews, K.D. Nance, T. Huda, L.J.
Marnett, Design of fluorine-containing 3,4-diarylfuran-2(5H)-ones as selective COX-1 inhibitors, ACS
Med. Chem. Lett. 5 (2014) 1254-1258.
[10] M.G. Perrone, P. Vitale, A. Panella, A. Scilimati, COX-1 inhibitors: beyond structure towards
therapy, Med. Rev. Res. 36 (2016) 641-671.
[11] M.G. Perrone, D.D. Lofrumento, P. Vitale, F. De Nuccio, V. La Pesa, A. Panella, R. Calvello, A.
Cianciulli, M.A. Panaro, A. Scilimati, Selective cyclooxygenase-1 inhibition by P6 and gastrotoxicity:
preliminary investigation, Pharmacol. 95 (2015) 22-28.
[12] H. Kakuta, X. Zheng, H. Oda, S. Harada, Y. Sugimoto, K. Sasaki, A. Tai, Cyclooxygenase-1-
selective inhibitors are attractive candidates for analgesics that do not cause gastric damage. Design
and in vitro/in vivo evaluation of a benzamide-type cyclooxygenase-1 selective inhibitor, J. Med.
Chem. 51 (2008) 2400-2411.
[13] H. Kakuta, R.Fukai, Z.Xiaoxia, F.Ohsawa, T.Bamba, K.Hirata, A. Tai Identification of urine
metabolites of TFAP, a cyclooxygenase-1 inhibitor, Bioorg. Med. Chem. Lett. 20 (2010) 840-843.
23

ACCEPTED MANUSCRIPT
[14] M.G. Perrone, P. Vitale, P. Panella, C.G. Fortuna, A. Scilimati, General role of the amino and
methylsulfamoyl groups in selective cyclooxygenase(COX)-1 inhibition by 1,4-diaryl-1,2,3-triazoles
and validation of a predictive pharmacometric PLS model, Eur. J. Med. Chem. 94 (2015) 252-264.
[15] P. Vitale, M.G. Perrone, P. Malerba, A. Lavecchia, A. Scilimati, Selective COX-1 inhibition as a
target of theranostic novel diarylisoxazoles, Eur. J. Med. Chem. 74 (2014) 1-13.
[16] M.G. Perrone, P. Vitale, A. Panella, S. Ferorelli, M. Contino, A. Lavecchia, A. Scilimati,
Isoxazole-based scaffold inhibitors targeting cyclooxygenase(COX)s. Chem. Med. Chem. 11 (2016)
1172-1187.
[17] D. Picot,; P.J. Loll,; R.M. Garavito, The X-ray crystal structure of the membrane protein
prostaglandin H2 synthase-1, Nature 367 (1994) 243-249.
[18] J.A. Mancini, D. Riendeau, J.P. Falgueyret, P.J. Vickers, G.P. O'Neill, Arginine 120 of
prostaglandin G/H synthase-1 is required for the inhibition by nonsteroidal anti-inflammatory drugs
containing a carboxylic acid moiety, J. Biol. Chem. 270 (1995) 29372-29377.
[19] K. Goto, H. Ochi, Y. Yasunaga, H. Matsuyuki, T. Imayoshi, H. Kusuhara, T. Okumoto, Analgesic
effect of mofezolac, a non-steroidal anti-inflammatory drug, against phenylquinone-induced acute pain
in mice
-
A
new antiinflammatory agent, selectively inhibits prostaglandin G/H
synthase/cyclooxygenase (COX-2) activity in vitro. Prostaglandins & Other Lipid Mediator 56 (1998)
245-254.
[20] T. Kitamura, T. Kawamori, N. Uchiya, M. Itoh, T. Noda, M. Matsuura, T Sugimura, K.
Wakabayashi, Inhibitory effects of mofezolac, a cyclooxygenase-1 selective inhibitor, on intestinal
carcinogenesis, Carcinogenesis 23 (2002) 1463-1466.
[21] M.G. Perrone, P. Vitale, A. Panella, S. Ferorelli, M. Contino, A. Lavecchia, A. Scilimati, Isoxazole-
Based-Scaffold Inhibitors Targeting Cyclooxygenases (COXs), ChemMedChem 11 (2016) 1172-1187.
24

ACCEPTED MANUSCRIPT
[22] R.S. Sidhu, J.Y. Lee, C. Yuan, W.L. Smith, Comparison of cyclooxygenase-1 crystal structures:
cross-talk between monomers comprising cyclooxygenase-1 homodimers. Biochemistry 49 (2010)
7069-7079.
[23] K. Gupta, B.S. Selinsky, C.J. Kaub, A.K. Katz, P.J. Loll, The 2.0 A resolution crystal structure of
prostaglandin H2 synthase-1: structural insights into an unusual peroxidase, J. Mol. Biol. 335 (2004)
503-518.
[24] S. Xu, D.J. Hermanson, S. Banerjee, K. Ghebreselasie, G.M. Clayton, R.M. Garavito, L.J.
Marnett, Oxicams bind in a novel mode to the cyclooxygenase active site via a two-water-mediated H-
bonding Network. J. Biol. Chem. 289 (2014) 6799-6808.
[25] S.R. Sankhala, K.R. Lokareddy, G. Cingolani, Structure of human PIR1, an atypical dual
specificity phosphatase. Biochemistry 53 (2014) 862-871.
[26] S. Xu, D.J. Hermanson, S. Banerjee, K. Ghebreselasie, G.M. Clayton, R.M. Garavito, L.J.
Marnett, Oxicams bind in a novel mode to the cyclooxygenase active site via a two-water-mediated H-
bonding Network. J. Biol. Chem, 289 (2014) 6799-6808.
[27] Y.S. Khan, M. Kazemi, H. Gutiérrez-de-Terán, J. Åqvist, Origin of the enigmatic stepwise tight-
binding inhibition of cyclooxygenase-1, Biochemistry 54 (2015) 7283-7291.
[28] T. Grosser, S. Fries, G.A. FitzGerald, Biological basis for the cardiovascular consequences of
COX-2 inhibition: therapeutic challenges and opportunities, J. Clin. Invest. 116 (2006) 4-15.
[29] C. Luong, A. Miller, J. Barnett, J. Chow, C. Ramesha, M.F. Browner, Flexibility of the NSAID
binding site in the structure of human cyclooxygenase-2, Nat. Struct. Biol. 3 (1996) 927-933.
[30] M. Baroni, G. Cruciani, S. Sciabola, F. Perruccio, J.S. Mason, A common reference framework for
analyzing/comparing proteins and ligands. Fingerprints for ligands and proteins (FLAP): theory and
application J. Chem. Inf. Model. 47 (2007) 279-294.
25

ACCEPTED MANUSCRIPT
[31] Antithrombotic Trialists Collaboration. Collaborative meta-analysis of randomized trials of
antiplatelet therapy for prevention of death, myocardial infarction, and stroke in high risk patients. Brit.
Med. J. 324 (2002) 71-86.
[32] P. Patrignani, Aspirin insensitive eicosanoid biosynthesis in cardiovascular disease. Thromb. Res.
110 (2003) 281-286.
[33] R.G. Micetich, C.C. Shaw, R.B. Rastogi, Eur Patent 26928 (1981).
[34] Z. Otwinowski,; W. Minor, Processing of X-ray diffraction data collected in oscillation mode.
Methods Enzymol. 276 (1997) 307-326. Macromolecular Crystallography (part A, C.W. Carter, Jr. &
R.M. Sweet, Eds., Academic Press).
[35] A.J. McCoy, R.W. Grosse-Kunstleve, P.D. Adams, M.D. Winn, L.C. Storoni, R.J. Read, Phaser
crystallographic software. J. Appl. Crystallogr. 40 (2007), 658-674.
[36] P.D. Adams, R.W. Grosse-Kunstleve, L.W. Hung, T.R. Ioerger, A.J. McCoy, N.W. Moriarty, R.J.
Read, J.C. Sacchettini, N.K. Sauter, T.C. Terwilliger, PHENIX: building new software for automated
crystallographic structure determination, Acta Crystallogr. D. Biol. Crystallogr. 58 (2002) 1948-1954.
[37] Emsley, P.; Cowtan, K. Coot: model-building tools for molecular graphics. Acta Crystallogr. D.
Biol. Crystallogr. 60 (2004) 2126-2132.
[38] W.L. DeLano, The PyMOL Molecular Graphics System. (2002) World Wide Web
http://www.pymol.org.
[39] O. Rahaman, T.P. Estrada, D.J. Doren, M. Taufer, C.L.3rd Brooks, R.S. Armen, Evaluation of
several two-step scoring functions based on linear interaction energy, effective ligand size, and
empirical pair potentials for prediction of protein-ligand binding geometry and free energy, J. Chem.
Inf. Model. 51 ( 2011) 2047-2065.
26

ACCEPTED MANUSCRIPT
Highlights
X-ray analysis of the crystal structure of COX-1 bound to mofezolac
X-ray analysis of the crystal structure of COX-1 bound to P6
Binding determinants for highly selective COX-1 inhibition
Selective diarylisoxazole scaffold inhibitors as tools to study COX-1 active site
