Pharmacological evaluation of imidazole-derived bisphosphonates on
RANKL-induced osteoclast differentiation and function
Jianguo Lin1,2, Ying Peng1, Qingzhu Liu1, Ke Li1, Gaochao Lv1, Yann Seimbille5，Gang Huang4,*,
Feng Gao3,*, Ling Qiu1,2*
1
NHC Key Laboratory of Nuclear Medicine, Jiangsu Key Laboratory of Molecular Nuclear Medicine, Jiangsu
Institute of Nuclear Medicine. Wuxi, Jiangsu, China
2
Department of Radiopharmaceuticals, School of Pharmacy, Nanjing Medical University, Nanjing, Jiangsu,
China
3 Department of Medical Imaging, Jinling Hospital, Medical School of Nanjing University, Nanjing, Jiangsu,
China
4
Shanghai Key Laboratory of Molecular Imaging, Shanghai University of Medicine and Health Sciences,
Shanghai, China
5
Department of Radiology and Nuclear Medicine, University Medical Center Rotterdam, Erasmus MC,
Rotterdam, The Netherlands
Corresponding authors ： qiuling@jsinm.org (Ling Qiu), rggaofeng@hotmail.com (Feng Gao),
huanggang@sumhs.edu.cn (Gang Huang)
Abstract: Bisphosphonates (BPs) have been commonly used in the treatment of osteolytic bone
lesions, such as osteoporosis and osteogenesis imperfecta. However, serious side effects can occur
This article has been accepted for publication and undergone full peer review but has not been
through the copyediting, typesetting, pagination and proofreading process, which may lead to
differences between this version and the Version of Record. Please cite this article as doi:
10.1111/cbdd.13767
This article is protected by copyright. All rights reserved

during the therapy. To search for novel potent BPs with lower side effects, a series of
imidazole-containing BPs (zoledronic acid (ZOL) ； ZOL derivatives by substitution of the
hydrogen at the 2-position on the imidazole ring with a methyl (MIDP), ethyl (EIDP), n-propyl
(PIDP) or n-butyl group (BIDP)) were developed and the effects on receptor activator of nuclear
factor-κB ligand (RANKL)-induced osteoclast differentiation were investigated using the murine
macrophage RAW 264.7 cells at the protein, gene, morphological and functional levels. Influences
of these BPs on the cell growth and proliferation of RAW 264.7 were also studied in order to
determine cytotoxicity. The results showed that PIDP significantly inhibited the RANKL-induced
osteoclast formation in a dose-dependent fashion without inducing cytotoxicity under the
concentration of 12.5 μM. It exerted remarkable suppressive effects on the development of actin
rings, the bone resorption and the expressions of osteoclastogenesis-related gene and protein
markers. The down-regulation of c-Jun N-terminal kinase (JNK), Protein kinase B (Akt) and
inhibitor of nuclear factor kappa-B (IκB) phosphorylation in the early signaling event and
subsequent inhibition of the expression of c-Fos and nuclear factor of activated T-cells (NFATc1)
might be involved in these effects. All these results indicated that PIDP might be a promising drug
to treat bone-related disorders.
Keywords: Pharmacology, bisphosphonate, RANKL, osteoclastogenesis, mechanism.
INTRODUCTION
Human bone homeostasis relies on a subtle balance between bone formation and resorption
regulated by osteoblasts and osteoclasts, respectively(Boyle et al., 2003). An inappropriate
osteoclast activity can result in bone disorders, such as osteopetrosis or excessive bone resorption.
The former is caused by the shortage of osteoclast activity, while the latter is the result of an
increased osteoclast activity leading to bone loss followed by several skeletal disorders, such as
osteoporosis, Paget’s disease, hypercalcemia, rheumatoid arthritis, osteoarthritis and lytic bone
metastases (Gough et al., 1998; Knowles, 2017; Krzeszinski and Wan, 2015). Thereby, it is crucial
to prevent a change in osteoclast activity to maintain bone homeostasis.
Osteoclasts are originated from the monocyte/macrophage lineage of hematopoietic stem
This article is protected by copyright. All rights reserved

cells(Boyle et al., 2003). After differentiation into multinucleated giant cells, osteoclasts adhere to
the bone surface and polarize to form a ruffled border and an actin-rich sealing zone with an
isolated resorptive microenvironment. Then, osteoclasts are involved in bone resorption activity
by excreting various acids and enzymes(Teitelbaum, 2011). Receptor activator of nuclear
factor-κB (NF-κB) ligand (RANKL) belongs to the super-family of tumor necrosis factor (TNF),
and it is considered as a key cytokine for the regulation of the differentiation and function of
human osteoclasts. Binding of RANKL to RANK receptor on osteoclast precursor cells leads to
the aggregation of TNF receptor-associated factors 6 (TRAF6), followed by the activation of
mitogen-activated protein kinase (MAPK) and transcription factors including NF-κB, c-Fos and
nuclear factor of activated T-cells (NFATc1). As a key regulator of osteoclastogenesis, NFATc1
regulates the expression of various genes related with osteoclast including matrix
metallopeptidase-9 (MMP-9), tartrate-resistant acid phosphatase (TRAP), cathepsin K and
integrin-β3(Fujisaki et al., 2007; Kim and Kim, 2014; Negishi-Koga and Takayanagi, 2009).
Bisphosphonates (BPs) are synthetic analogues of pyrophosphate with a P-C-P backbone.
Osteophilic accumulation is observed with BPs, and they possess inhibitory effect on osteoclastic
bone resorption(Widler et al., 2002). The third generation BPs, represented by zoledronic acid
(ZOL), hold higher anti-resorptive capacity than the previous BPs drugs. They have already been
commonly applied to treat osteoporosis, osteogenesis imperfecta, osteitis deformans,
tumor-induced osteolytic metastases and other bone fragility related diseases(Baykan et al., 2014;
Polascik, 2009; Ruza et al., 2013; Xu et al., 2017). However, ZOL also induces serious
side-effects. One of the main adverse effect of ZOL is osteonecrosis of the jaw (ONJ)(Kang et al.,
2013; Lee and Suzuki, 2015). In addition, ZOL may also cause bilateral retrobulbar optic
neuropathy(Lavado et al., 2017). Therefore, novel BPs drugs with a better pharmacological profile
are needed. Although the pathophysiology of ZOL-induced adverse effects, such as ONJ, is still
unclear, some studies showed that macrophages play a critical role during the development of ONJ.
Reduced number and function of monocytes and macrophages caused by repeated administration
of BPs could induce local immune dysfunction, infection and necrosis involved in ONJ(Pazianas,
2011). In addition, as farnesyl pyrophosphate synthase (FPPS) inhibitor, nitrogen-containing BPs
This article is protected by copyright. All rights reserved

especially ZOL possess worse effects on cell biology than non-nitrogen containing BPs by
blocking the mevalonate pathway (Ziebart et al., 2016). Considering that the macrophages RAW
264.7 can differentiate into multinucleated osteoclasts after RANKL stimulation, they are used as
model of osteoclast precursors(Odkhuu et al., 2012). Recently, we prepared a series of ZOL
derivatives by substitution of the hydrogen at the 2-position on the imidazole ring with a methyl
(MIDP), ethyl (EIDP), n-propyl (PIDP) or n-butyl group (BIDP)(Chen et al., 2009; Luo et al.,
2005; Niu et al., 2008; Wang et al., 2010) (Scheme 1), and the effects of these
imidazole-containing BPs on the proliferation of RAW 264.7 cells and the RANKL-stimulated
osteoclastogenesis in RAW 264.7 cells were examined. Due to the relatively low toxicity on
osteoclast precursors and high anti-osteoclastogenesis ability, PIDP was selected for further
investigations. The effect of PIDP on bone resorption activity, signaling pathways and osteoclastic
markers involved in differentiation of osteoclast in RAW 264.7 cells were studied. Our results
demonstrated that PIDP might be a promising drug for preventing osteolytic diseases.
MATERIAL AND METHODS
1. Reagents and antibodies
ZOL, MIDP, EIDP, PIDP and BIDP were prepared in our lab with the purity of over 98 %
according to our reported methods(Chen et al., 2009; Luo et al., 2005; Niu et al., 2008; Wang et al.,
2010). They were dissolved in H2O to yield 10 mM solutions and stored at -20 °C as the stock
solution. Dulbecco’s modified Eagle’s medium (DMEM), fetal bovine serum (FBS), antibiotics
and polyvinylidene fluoride (PVDF) membrane were obtained from Life Technologies (Grand
Island, NY, USA). Soluble recombinant RANKL was purchased from R&D (Lorton, VA, USA).
Recombinant mouse FPPS protein was purchased from Sino Biological Inc. (Beijing, P. R. China).
3-(4,5-dimethylthiazol-2-yl)-2,5-diphenyltetrazolium bromide (MTT), isopentenyl pyrophosphate
(IPP), geranyl pyrophosphate (GPP), pyrophosphatase, malachite green and phalloidin-fluorescein
isothiocyanate (FITC) were purchased from Sigma-Aldrich (St Louis, MO, USA).
Tartrate-resistant acid phosphatase (TRAP) activity assay kit, bicinchoninic acid (BCA) protein
assay kit, Beyozol, Hoechst 33258, anti-TRAF6 antibody and radioimmunoprecipitation assay
This article is protected by copyright. All rights reserved

(RIPA) lysis buffer were from Beyotime Institute of Biotechnology (Jiangsu, China). TRAP &
ALP (alkaline phosphatase) double-stain kit, Taq polymerase and SYBR-Green were obtained
from TaKaRa biotechnology Co. Ltd (Dalian, China). High Capacity cDNA Reverse Transcription
Kit was obtained from Applied biosystems (Carlsbad, CA, USA). PCR primers were synthesized
by Sangon Biotech Co., Ltd. (Shanghai, China). Anti-c-Fos antibody was purchased from Abcam.
Western blot antibodies for phospho-p38 mitogen-activated protein kinase (phospho-p38 MAPK),
p38 mitogen-activated protein kinase (p38 MAPK), phospho-c-Jun N-terminal kinase
(phospho-JNK), c-Jun N-terminal kinase (JNK), phospho-extracellular signal-related kinase
(phospho-ERK), extracellular signal-related kinase (ERK), phospho-protein kinase B
(phospho-Akt), protein kinase B (Akt) and NF-kappa-B inhibitor alpha (IκB-α) were purchased
from Cell Signaling Technology (Danvers, MA, USA). Anti-NFATc1, phospho-IκB-α, β-actin
antibodies, horse radish peroxidase (HRP)-conjugated secondary antibodies and western blot
luminol reagent were purchased from Santa Cruz Biotechnology, Inc. (Santa Cruz, CA, USA).
Protease and phosphatase inhibitors were obtained from Thermo Fisher Scientific Inc. (Waltham,
MA USA). The murine macrophage RAW 264.7 cells were purchased from the American Type
Culture Collection (ATCC) (Manassas, USA).
2. Cell culture
The cells were cultured in DMEM containing 10 % FBS, 100 mg/mL streptomycin, 100
unit/mL penicillin at 37 °C in a humidified 5 % CO2 atmosphere.
3. Cell viability assay
Cell viability was determined by the traditional MTT method. RAW 264.7 cells were placed
in 96-well plates with a density of 1 × 103 cells/well. After incubation for overnight, the medium
was removed and replaced by the indicated concentration of ZOL, MIDP, EIDP, PIDP and BIDP,
respectively. The medium was added to the control and blank wells. After 5 days, 20 µL of MTT
solution (5 mg/mL) was added and the cells were cultured for another 4 h. The supernatants were
then discarded, and cells were dissolved in 150 µL dimethylsulfoxide (DMSO). The optical
density (OD) of each well was measured at 490 nm by SpetraMax M5 microplate reader
(Molecular Devices, Sunnyvale, CA, USA). Cell viability was expressed as a percentage of the
This article is protected by copyright. All rights reserved

control.
4. TRAP staining and activity assay
RAW 264.7 cells (1 × 103 cells/well) were placed in a 96-well plate and further treated for 5
days with different concentrations of ZOL, MIDP, EIDP, PIDP or BIDP in the absence or
presence of RANKL (50 ng/mL). TRAP staining assay was used to identify osteoclasts by using
TRAP & ALP double-stain kit according to the instructions. TRAP-positive multinucleated cells
with 3 or more nuclei were counted as osteoclasts and captured using a microscope.
To measure the suppressive effect of BPs on TRAP activity, RAW 264.7 cells (1 × 104
cells/well) were seeded into a 24-well plate and incubated with different concentrations of PIDP
for 5 days in the absence and presence of RANKL (50 ng/mL). TRAP activity was then measured
using the TRAP activity assay kit according to the kit instructions and calculated as percent of the
control.
5. Actin rings and nucleus staining
RAW 264.7 cells were seeded at 1 × 104 cells/well with complete DMEM medium in 24-well
plates. After 24 h, cells were treated with RANKL (50 ng/mL). The medium was changed every 2
days. On the fourth day of differentiation, mature osteoclasts were obtained from RAW 264.7 cells
and further incubated with PIDP for 24 h. The cells were then washed twice with
phosphate-buffered saline (PBS), fixed with 3.7 % formalin for 10 min, and washed twice again
with PBS. Actin rings were stained by using 5 μg/mL phalloidin-FITC for 60 min at 37 °C away
from light. The cells were washed twice again with PBS and nuclei were stained with 10 μg/mL
Hoechst 33258 for 10 min. Fluorescent staining was examined using the fluorescence microscope
(IX51; Olympus).
6. Bone resorption pit assay
RAW 264.7 cells (5 × 103 cells/well) were seeded in Corning Osteo Assay Stripwell plate and
incubated overnight. Then different concentrations of PIDP with or without RANKL (50 ng/mL)
were added to the medium. The cells were cultured in a humidified atmosphere of 5 % CO2. The
medium was changed every 2 days. Seven days later, cells were washed with 10 % bleach solution.
Resorption pits were clearly visualized using a light microscope.
This article is protected by copyright. All rights reserved

7. FPPS inhibition assay
The inhibitory effect of ZOL and the derivatives on FPPS activity was evaluated using
previously described method with appropriate adjustments (Liu et al., 2020). Briefly, the assay
was carried out in 96-well plate with 100 μL reaction mixture containing 50 mM Tris-HCl (pH
7.5), 2 mM MgCl2, 5 mM GPP, 5 mM IPP, 0.1 U/mL pyrophosphatase and 1.5 μg FPPS in each
well. After FPPS and 0.5 μM BPs was pre-incubated in the assay buffer at room temperature for
10 min, GPP and IPP were added. 10 min later, the reaction was terminated by adding 25 μL
malachite green work solution containing 10 parts 0.1% malachite green in 3 N H2SO4, 2.5 parts
7.5% ammonium molybdate, and 0.2 parts 11% Tween 20. The plate was shaken for 20 min on a
plate shaker. The absorbance was measured at 630 nm using SpetraMax M5 microplate reader.
Reaction solution without BPs was used as negative control. Reaction solution without FPPS and
BPs was set as blank control.
8. Reverse transcription-quantitative polymerase chain reaction (RT-qPCR)
RAW 264.7 cells (4 × 104 cells/well) were seeded in a 6-well plate with complete DMEM
medium. After 24 h, different concentrations of PIDP with or without RANKL (50 ng/mL) were
added into the medium. Then the cells were cultured at 37 °C in a humidified 5 % CO2 atmosphere
for 5 days and the medium was changed every 2 days. Beyozol was used to extract total RNA
according to the manufacturer's instructions. The cDNA was generated from 1.5 μg total RNA by
using high capacity cDNA reverse transcription kit according to the instructions. The primers for
indicated genes and GAPDH were designed using Primer Premier software and shown in Table S1.
The PCR programs were as follows: 25-35 cycles of 1 min at 94 °C (denaturation), 1 min at 54-59
°C (annealing) and a 1 min at 72 °C (extension). The PCR products were analyzed through a 1 %
agarose gel, stained with SYBR-Green and analyzed using the Image J software (Scion Corp.,
Frederick, MD USA).
9. Western blot analysis
RAW 264.7 cells (4 × 104 cells/well) were seeded with complete DMEM medium in a 6-well
plate and cultured overnight. Then the cells were treated with different substances. The treated
cells were rapidly washed with ice-cold PBS and lysed with RIPA lysis buffer containing protease
This article is protected by copyright. All rights reserved

and phosphatase inhibitors according to the manufacturer's instructions. The densitometric of the
bands were analyzed by using the Image J software.
10. Statistical analysis
Data from at least three independent experiments were expressed as mean ± standard
deviation (SD). Statistical analysis was performed by GraphPad Prism software (version 5;
GraphPad Software, Inc., La Jolla, CA, USA). The statistical significance was identified by the
ANOVA test. p < 0.05 was regarded to be statistically significant.
RESULTS
1. Syntheses and toxicity of imidazole-containing BPs
All the BPs (ZOL and its derivatives MIDP, EIDP, PIDP and BIDP) were prepared with yield
over 35 % according to the strategy described as following (see Scheme 1). The specific synthesis
methods and the characteristics of BPs can be checked in supporting material (Fig. S1-10).
Cytotoxic effects of ZOL, one representative of the BPs clinical drugs, and its corresponding
derivatives (MIDP, EIDP, PIDP and BIDP) on RAW 264.7 cells were tested by MTT assay.
Toxicity of these imidazole-containing BPs on cell growth was found to be
concentration-dependent (Fig. 1). Among them, ZOL demonstrated the strongest toxicity on RAW
264.7 cells (Fig. S11). It is noteworthy that ZOL, MIDP, EIDP, PIDP and BIDP are nontoxic
towards RAW 264.7 cells at concentrations below 3.12, 6.25, 12.5 and 50 μM, respectively.
Therefore, a range of concentrations not exceeding these thresholds has been used to estimate the
inhibitory effect of these BPs on osteoclasts formation. Thus, we could warrant that the inhibition
on osteoclastogenesis could be observed independently from the cytotoxicity on the osteoclast
precursors.
This article is protected by copyright. All rights reserved

R1
R1
R1
N
N
N
BrCH2COOC2H5
H2O
COOC2H5
COOH
N
N
NH
OH
R1
O
ZOL : R1=H
MIDP : R1=CH3
EIDP : R1=CH2CH3
PIDP : R1=CH2CH2CH3
P
Cl
/ H3PO4
OH
OH
OH
N
PCl3
/
C
N
H2O
P
BIDP : R1=CH2CH2CH2CH3
O
OH
Scheme 1. Synthesis strategy of BPs
Fig. 1. Inhibition study of BPs on RAW 264.7 cells. Data from four groups of independent
experiment were expressed as mean ± SD. * p < 0.05, ** p < 0.01, *** p < 0.001, compared with
the respective control.
2. Effects of BPs on osteoclastogenesis
TRAP is a phenotype marker of osteoclasts, due to its high expression in osteoclasts. To
examine the suppressive effects of ZOL, MIDP, EIDP, PIDP and BIDP on RANKL-induced
osteoclastogenesis, RANKL-treated RAW 264.7 cells were incubated with different
concentrations of these imidazole-containing BPs and then the formation of osteoclasts was
determined using TRAP staining assay. As shown in Fig. 2a-c, ZOL, MIDP and EIDP had no
This article is protected by copyright. All rights reserved

obvious suppression effect on RANKL-stimulated osteoclastogenesis at all tested concentrations.
However, PIDP and BIDP showed a concentration dependent inhibition of RANKL-induced
osteoclastogenesis. PIDP significantly inhibited osteoclastogenesis at a relatively low
concentration compared to BIDP (1.56 μM vs. 6.25 μM) (Fig. 2d-e). PIDP also showed a higher
inhibitory effect than BIDP at the same concentrations of 6.25 μM and 12.5 μM (Fig. 2f). These
results indicated that PIDP possessed relatively high anti-osteoclastogenesis ability. Accordingly,
PIDP was chosen for further study in the following experiments.
Fig. 2. Effects of ZOL, MIDP, EIDP, PIDP and BIDP on RANKL-induced osteoclastogenesis.
(a-e) TRAP-positive multinucleated cells were counted and the results of independent experiments
(n = 3) were expressed as mean ± SD. ** p < 0.01, compared with the respective control. (f)
Comparison of PIDP and BIDP on RANKL-stimulated osteoclastogenesis. * p < 0.05, ** p < 0.01.
To further examine the inhibition of the formation of RANKL-stimulated osteoclast by PIDP,
RANKL-treated RAW 264.7 cells were incubated with varying concentrations of PIDP.
Concentrations which could not induce cytotoxicity were chosen in the study, and TRAP staining
assay was performed. As clearly exemplified on Fig. 3a, only RAW 264.7 cells cultured with
RANKL generated TRAP-positive multinucleated cells (nuclei > 3). However, we observed that
This article is protected by copyright. All rights reserved

addition of PIDP reduced the number of RANKL-stimulated osteoclasts and inhibited TRAP
activity (Fig. 3a-b).
Fig. 3. Investigation of PIDP on RANKL-stimulated osteoclast formation and bone resorption. (a)
RAW 264.7 cells were cultured with different concentrations of PIDP with or without 50 ng/mL
RANKL. Bar = 80 μm. (b) TRAP activity of RANKL-stimulated osteoclast. ## p < 0.01, in
comparison with untreated cells. ** p < 0.01, in comparison with cells only treated by 50 ng/mL
RANKL. (c) Actin filament staining of mature osteoclasts after incubation with varying
concentrations of PIDP for 24 h. Bar = 80 μm. (d) Morphology of RAW 264.7 cells cultured for 7
days with different concentrations of PIDP without or with 50 ng/mL RANKL. Bar = 200 μm.
This article is protected by copyright. All rights reserved

3. Effects of BPs on RANKL-induced bone resorption
By adhesion to the bone surface, the membrane of the multinucleated osteoclasts becomes
polarized and an isolated resorptive area surrounded by a tight actin-rich sealing zone is formed.
Actin rings are therefore considered as a marker of polarized osteoclasts. When mature osteoclasts
were incubated with phalloidin-FITC, actin rings with smooth peripheries were observed.
However, addition of PIDP disrupted the actin rings of the mature osteoclasts in a dose-dependent
manner, leading to morphological changes, such as irregular or even incomplete cell periphery and
a contracted cytoplasm (Fig. 3c).
Osteoclasts are known to excrete hydrogen ions and lytic enzymes to the lacuna, and then the
bone matrix is gradually dissolved(Jurdic et al., 2006; Soysa and Alles, 2016). Our results
demonstrated that both area and density of bone resorption pits were remarkably reduced by the
treatment of PIDP (Fig. 3d).
4. Effect of BPs on the activity of FPPS
Inhibition of FPPS is an important mechanism for the function of the third generation of BPs.
So, the inhibitory effect of the BPs on the activity of FPPS was studied. As shown in Fig. 4, the
inhibition rate of 0.5 μM ZOL to the enzyme activity of 1.5 µg FPPS was about 87.8%, while the
inhibition rates of 0.5 μM MIDP, EIDP, PIDP or BIDP to 1.5 µg FPPS were 47.5%, 39.1%, 36.1%
and 26.8%, respectively. The inhibition rates of MIDP, EIDP, PIDP or BIDP were all significantly
lower than that of ZOL.
This article is protected by copyright. All rights reserved

Fig. 4. Effect of BPs on the activity of FPPS. 0.5 μM BPs and 1.5 µg FPPS were pre-incubated for
10 min respectively. The inhibition of the BPs on the activity of FPPS was assayed. *** p < 0.001,
compared with the ZOL group.
5. Effect of PIDP on RANKL-induced signaling pathways
Distinct RANKL-induced signaling pathways were investigated by western blotting assay
after treatment with PIDP. PIDP inhibited the phosphorylation of JNK and strongly reduced the
phosphorylation of Akt and IκB (Fig. 5). However, no obvious influence on p38 and ERK
activation was observed after treatment of the RAW 264.7 cells with PIDP.
Fig. 5. Effect of PIDP on signal pathways induced by RANKL. (a) RAW 264.7 cells were
pretreated without or with 12.5 μM PIDP for 1 h prior to 50 ng/mL RANKL stimulation for a
period of time. (b) Statistical analysis of the western blot results. Bar graphs showed the relative
ratios of p-p38/p38, p-ERK/ERK, p-JNK/JNK, p-IκB/β-actin, p-Akt/Akt and IκB/β-actin. Data
from three groups of independent experiment were expressed as mean ± SD. * p < 0.05, ** p <
0.01, *** p < 0.001, compared with the respective vehicles.
6. Effect of PIDP on RANKL-induced expressions of TRAF6, NFATc1 and c-Fos
This article is protected by copyright. All rights reserved

The aggregation of TRAF6 is an early event induced by RANKL/RANK interaction. We
determined the effect of PIDP on RANKL-induced expression of TRAF6. As shown in Fig. 6a and
c, the expression level of TRAF6 was up-regulated upon exposure to RANKL, but suppressed by
PIDP, in a dose-dependent manner.
Transcription factor NFATc1 is involved in osteoclast differentiation and activation induced
by RANKL. To further investigate the function of PIDP in osteoclast differentiation, we
determined mRNA and protein expression of NFATc1 in RANKL-stimulated RAW 264.7 cells
with or without PIDP. The genes related to NFATc1 were also investigated, including MMP-9,
cathepsin K, RANK, integrin β3, and TRPV5. mRNA levels of MMP-9, cathepsin K, NFATc1,
RANK integrin β3 and TRPV5 were suppressed by PIDP during osteoclastogenesis in a
dose-dependent manner (Fig. 6b and d). The expression of NFATc1 protein was up-regulated
upon exposure to RANKL, but inhibited by additional treatment with PIDP (Fig. 6a and c). c-Fos
is another key transcription factor which is contributing in RANKL-stimulated osteoclastogenesis.
Our experiments showed that PIDP exerted inhibitory effects on the mRNA and protein
expressions of c-Fos (Fig. 6a-d).
Fig. 6. Effect of PIDP on osteoclastogenesis-related genes and proteins. (a) Suppressive effect of
PIDP on RANKL-stimulated TRAF6, c-Fos and NFATc1 protein expressions. (b) Inhibition effect
This article is protected by copyright. All rights reserved

of PIDP on RANKL-stimulated mRNA expression of MMP-9, cathepsin K, c-Fos, NFATc1,
RANK, integrin β3, and transient receptor potential vanilloid 5 (TRPV5). (c) Statistical analysis of
the western blot results in Fig. 6a. Bar graphs showed the relative levels of TRAF6, c-Fos and
NFATc1. (d) Statistical analysis of the results in Fig. 6b. Bar graphs showed the relative mRNA
expression levels of MMP-9, cathepsin K, c-Fos, NFATc1, RANK, integrin β3 and TRPV5. ### p
< 0.001, in comparison with untreated cells. * p < 0.05, ** p < 0.01, *** p < 0.001, in comparison
with cells only treated by 50 ng/mL RANKL.
DISCUSSION
To explore novel BPs drugs with high efficiency and low toxicity, a series of
imidazole-containing BPs including MIDP, EIDP, PIDP and BIDP were examined preliminarily in
the present study. ZOL was also investigated in parallel and served as the control. Our results
suggested that PIDP not only exerted lower cytotoxicity to RAW 264.7 cells than ZOL, but also
showed higher anti-bone-resorption capacity on RANKL-induced osteoclastogenesis than other
BPs. It was also noted that PIDP suppressed the expression of osteoclastogenesis-associated
molecules. These results supported the potential value of PIDP as a promising agent for treatment
of bone disorders involving increased osteoclastogenesis. Interestingly, 99mTc-labeled PIDP was
also proved as a potential radio-pharmaceutical for targeted bone imaging(Chen et al., 2009).
In addition to the phosphate groups, BPs also contain two side chains commonly known as
R1 and R2. The structure of P-C-P determines the high affinity of BPs to bone mineral. The
hydroxyl group at R1 position could enhanced the property of P-C-P structure(van Beek et al.,
1998), and the R2 chain was responsible for the properties and potency of each BP(Ruza et al.,
2013). It can be seen that the toxicity towards RAW 264.7 cells and the anti-bone-resorptive
activity of BPs were mainly related to the R2 side chain. ZOL, MIDP, EIDP, PIDP and BIDP
shared the same R1 chain (a hydroxyl group) and the different R2 chain (the group at the
2-position on the imidazole ring was a hydrogen (ZOL), methyl (MIDP), ethyl (EIDP), n-propyl
(PIDP) or n-butyl group (BIDP)). For these compounds, the carbon atom increased from 0 to 4 at
this specific position, gradually increased the upper limit of non-cytotoxic concentration, which
This article is protected by copyright. All rights reserved

suggested that the number of carbon atom at the 2-position on the imidazole ring of these BPs was
negatively correlated with their toxicity to RAW 264.7 cells. It has been shown that small
differences of substituents binding to carbon atom could lead to significant changes in the 3D
shape and atomic orientation of BPs, thus affecting its binding affinity with the target (Qiu et al.,
2014; Russell et al., 2008). Therefore, the different toxicity of ZOL, MIDP, EIDP, PIDP and BIDP
with similar structure may be related to a series of consequences caused by different R2 side
chains, including lipophilicity, binding ability to the targets, etc.
Because of the complex mechanism of these BPs, the relationship between the structure and
the anti-osteoclast-differentiation bioactivities is also complex. Previous studies have shown that
the inhibition of mevalonate pathway by targeting FPPS was related to the anti-osteoclastic
activity of BPs (Ebetino et al., 2011). According to our results, the substitution of the hydrogen at
the 2-position on the imidazole ring by a methyl, ethyl, n-propyl or n-butyl group reduced the
inhibitory activity of the compounds on FPPS and the number of carbon atom at the 2-position on
the imidazole ring was negatively correlated with their inhibition to FPPS to some extent.
However, PIDP showed more potent ability at inhibiting osteoclast differentiation than ZOL,
MIDP, EIDP and BIDP. These indicated that the anti-osteoclastic effects of PIDP may be caused
by other more important factors than the inhibition of FPPS.
The pathophysiology of ZOL-induced adverse effects, such as ONJ, remains unclear, but
evidences showed that macrophages could play a critical role in the development of ONJ(Pazianas,
2011). It is suggested that repeated administration of BPs could affect the immune system by
reducing the number and activity of monocytes and macrophages, and thus be responsible for
infection and necrosis(Hoefert et al., 2016). According to our results, no obvious effect on
osteoclast formation induced by RANKL was observed with ZOL when RAW 264.7 cells were
treated at concentrations below the cytotoxicity threshold. Consequently, inhibition of osteoclast
differentiation with ZOL was inevitably associated with toxicity to the precursors of osteoclasts.
However, PIDP can effectively inhibit RANKL-stimulated osteoclast formation at concentrations
without any cytotoxicity on RAW 264.7 cells. From the above results, we anticipated that PIDP
might have a potential effect on inhibiting bone resorption activity of osteoclasts without
This article is protected by copyright. All rights reserved

producing undesirable side effects. However, the concentration at which toxicity was observed
might not be relevant to the in vivo situation where the toxicity might actually arise at higher local
concentrations which are feasible upon treatment as these BPs presumably accumulate in bone.
Therefore, further in vivo experiments are still needed.
It is known that the actin rings are essential for bone resorption activity at the late stage of the
osteoclast maturation. It has been demonstrated that osteoclasts resulted in bone substrate
degradation only within actin ring-defined regions, and consequently the integrity of the actin
structure was crucial to osteoclasts-mediated bone resorption(Wagner and Karsenty, 2001). Hence,
PIDP was not only inhibiting osteoclast differentiation, but also suppressing bone resorption by
altering the morphological structure of osteoclasts.
As mentioned above, resorption lacunae and pit were formed by RANKL stimulated mature
osteoclasts(Hsu et al., 1999). Functionally, the pit formation assay is important for identifying the
osteoclast phenotype. In the present study, to investigate the effect of PIDP on osteoclastic bone
resorption, a commercial osteo assay strip well plate was used to detect the pit formation. The
results demonstrated that PIDP had a significant inhibition effect on the function of mature
osteoclast and it attenuated the bone resorption activity of osteoclasts.
RANKL/RANK interaction activated a variety of important signal transducing pathways such
as MAPKs, Akt and IκB. The MAPKs were related enzymes that selectively phosphorylated
threonine and serine residues upon stimulation with extracellular molecules and transmited the
stimuli into the nucleus. MAPKs and Akt pathways were involved in the transduction of RANK
signal and they were necessary for subsequent differentiation of osteoclast(Gingery et al., 2003;
Kong et al., 2015; Matsumoto et al., 2000). Inhibitors of MAPKs (i.e. p38, ERK, JNK) and Akt
disturbed osteoclast differentiation induced by RANKL(Cheng et al., 2012; Ikeda et al., 2009; Tao
et al., 2011; Yamanaka et al., 2013). The present study demonstrated that PIDP could inhibit the
RANKL-stimulated phosphorylation of JNK and Akt, suggesting that PIDP targeted JNK and Akt
cascades.
NF-κB is a key transcription factor, which plays a crucial role in osteoclast formation induced
by RANKL. Inhibition of NF-κB activation could block the osteoclastogenesis(Jimi et al., 2004).
This article is protected by copyright. All rights reserved

The binding of IκB with NF-κB prevents NF-κB to migrate to the cell nucleus. Phosphorylation of
IκB induces separation of these two proteins, allowing NF-κB to reach the nucleus and activate
target genes transcription(Hayden and Ghosh, 2004). Our results suggested that the inhibition
effect of PIDP on RANKL-stimulated RAW 264.7 cells might also be related to the reduction of
NF-κB.
NFATc1 can up-regulate various genes which are involved in osteoclast function and
degradation of bone matrix(Zhao et al., 2010). Osteoclasts cannot be differentiated by embryonic
stem cells in which NFATc1 was knocked out, and ectopic expression of NFATc1 resulted in
efficient formation of osteoclast from osteoclast precursors without RANKL
stimulation(Takayanagi et al., 2002). It is known that ZOL inhibited RANKL-stimulated
formation of osteoclast through the down-regulation of NFATc1 gene(Nakagawa et al., 2015).
NFATc1 also regulated the expression of many genes in relation with osteoclastogenesis, such as
MMP-9, cathepsin K and integrin β3(Crotti et al., 2008; Song et al., 2009). MMP-9 and cathepsin
K were found important for the degradation of the organic bone matrix, while integrin β3
contributed to bone resorption through the migration and adhesion of osteoclasts(Broadhead et al.,
2011; Costa et al., 2011). In the present study, PIDP decreased both mRNA and protein levels of
NFATc1. Additionally, treatment with PIDP suppressed the expression of MMP-9, cathepsin K
and integrin β3 genes. Therefore, PIDP inhibited osteoclast formation by down-regulating the
expression of these osteoclastogenesis-related genes through the inhibition of NFATc1.
RANKL/RANK interaction induced the aggregation of c-Fos, whereas the interaction of
c-Fos with the promoter of NFATc1 led to the NFATc1 expression(Song et al., 2009). Lack of
c-Fos in mice resulted in osteopetrosis and defective osteoclast differentiation(Wang et al., 1992).
Moreover, it is demonstrated that risedronate, one of the nitrogen-bearing BPs, could also inhibit
RANK-stimulated expression of c-Fos and NFATc1(Kwak et al., 2009). Our experiments showed
that PIDP exerted inhibitory effects on the mRNA and protein expressions of c-Fos. The results
indicated that PIDP might restrain RANKL-induced osteoclastogenesis via the down-regulation of
NFATc1 following the suppression of c-Fos. RANK could regulate the expression of c-Fos in
osteoclast precursors(Arai et al., 2012). We studied the expression of RANK and showed that
This article is protected by copyright. All rights reserved

PIDP inhibited the mRNA expression of RANK, and the result demonstrated that PIDP might
suppress the expression of c-Fos through its action on the signaling cascades involved in RANKL.
In addition, the effect of PIDP on the expression of TRPV5 (transient receptor potential
cation channel subfamily V member 5) was also studied. TRPV5 is known to be involved in
RANKL-stimulated Ca2+ spike. The inactivation of TRPV5 by siRNA completely inhibited the
concentration increase of the intracellular Ca2+ induced by RANKL (Chamoux et al., 2010).
Moreover, the inactivation of TRPV5 was also necessary to facilitate NF-κB nuclear translocation
and NFATc1 activation, and to maintain osteoclast survival and bone-resorption
activity(Komarova et al., 2005; Komarova et al., 2003). Our study demonstrated that the mRNA
levels of TRPV5 decreased in presence of PIDP, which suggested that the down-regulation of
RANKL-induced increase of intracellular Ca2+ concentration might be involved in the
anti-bone-resorptive effect of PIDP.
CONCLUSIONS
In summary, we demonstrated the effects of a series of imidazole-containing BPs on
RANKL-stimulated osteoclast differentiation and activation in RAW 264.7 cells. Therein, PIDP
attenuated RANKL-induced osteoclast differentiation and possessed low cytotoxicity on RAW
264.7 cells. Moreover, PIDP exerted suppression effects on the actin rings formation, bone
resorption, and the expression of gene and protein associated with osteoclastogenesis. The
down-regulation of JNK, Akt and IκB phosphorylation in the early signaling event and subsequent
inhibition of c-Fos and NFATc1 expressions might be involved in these effects (Fig. 7). Taken
together, our findings supported the potential value of PIDP as a promising agent for the treatment
of bone disorders involving increased osteoclastogenesis.
This article is protected by copyright. All rights reserved

Fig. 7. Potential mechanism of action of PIDP on the regulation of osteoclast differentiation and
activation.
CONFLICT OF INTEREST
The author(s) confirm that this article content has no conflicts of interest.
FUNDING
This work was supported by the National Natural Science Foundation of China (81803586),
the Natural Science Foundation of Jiangsu Province (BK20181128), the 333 Project of Jiangsu
Province (BRA2016518, LGY2018086), the Jiangsu Provincial Medical Youth Talent
(QNRC2016626 and QNRC2016629), Innovation Capacity Development Plan of Jiangsu Province
(BM2018023-5) and Jiangsu Provincial Key Medical Discipline (ZDXKA2016017).
REFERENCES
Arai, A., Mizoguchi, T., Harada, S., Kobayashi, Y., Nakamichi, Y., Yasuda, H., Penninger, J.M., Yamada, K.,
Udagawa, N., Takahashi, N. (2012). Fos plays an essential role in the upregulation of RANK expression in
This article is protected by copyright. All rights reserved

osteoclast precursors within the bone microenvironment. Journal of Cell Science, 125, 2910-2917.
doi:10.1242/jcs.099986
Baykan, E.K., Saygili, L.F., Erdogan, M., Cetinkalp, S., Ozgen, A.G., Yilmaz, C. (2014). Efficacy of zoledronic acid
treatment
in
Paget
disease
of
bone.
Osteoporosis
International,
25,
2221-2223.
doi:10.1007/s00198-014-2752-z
Boyle, W.J., Simonet, W.S., Lacey, D.L. (2003). Osteoclast differentiation and activation. Nature, 423, 337-342.
doi:10.1038/nature01658
Broadhead, M.L., Clark, J.C.M., Dass, C.R., Choong, P.F.M., Myers, D.E. (2011). Therapeutic targeting of osteoclast
function
and
pathways.
Expert
Opinion
on
Therapeutic
Targets,
15,
169-181.
doi:10.1517/14728222.2011.546351
Chamoux, E., Bisson, M., Payet, M.D., Roux, S. (2010). TRPV-5 mediates a receptor activator of NF-kappaB
(RANK) ligand-induced increase in cytosolic Ca2+ in human osteoclasts and down-regulates bone resorption.
Journal of Biological Chemistry, 285, 25354-25362. doi:10.1074/jbc.M109.075234
Chen, C., Luo, S., Lin, J., Yang, M., Ye, W., Qiu, L., Sang, G., Xia, Y. (2009). Preparation and biodistribution of
99Tcm-PIDP as bone imaging agent. Nuclear Science and Techniques, 20, 302-306.
doi:10.1002/9780470611807.ch2
Cheng, B., Li, J., Du, J., Lv, X., Weng, L., Ling, C. (2012). Ginsenoside Rb1 inhibits osteoclastogenesis by
modulating NF-κB and MAPKs pathways. Food and Chemical Toxicology, 50, 1610-1615.
doi:10.1016/j.fct.2012.02.019
Costa, A.G., Cusano, N.E., Silva, B.C., Cremers, S., Bilezikian, J.P. (2011). Cathepsin K: its skeletal actions and role
as
a
therapeutic target in osteoporosis. Nature Reviews Rheumatology, 7, 447-456.
doi:10.1038/nrrheum.2011.77
Crotti, T.N., Sharma, S.M., Fleming, J.D., Flannery, M.R., Ostrowski, M.C., Goldring, S.R., McHugh, K.P. (2008).
PU.1 and NFATc1 mediate osteoclastic induction of the mouse β3 integrin promoter. Journal of Cellular
Physiology, 215, 636-644. doi:10.1002/jcp.21344
Ebetino, F.H., Hogan, A.M., Sun, S., Tsoumpra, M.K., Duan, X., Triffitt, J.T., Kwaasi, A.A., Dunford, J.E., Barnett,
B.L., Oppermann, U., Lundy, M.W., Boyde, A., Kashemirov, B.A., McKenna, C.E., Russell, R.G. (2011).
The relationship between the chemistry and biological activity of the bisphosphonates. Bone, 49, 20-33.
This article is protected by copyright. All rights reserved

doi:10.1016/j.bone.2011.03.774
Fujisaki, K., Tanabe, N., Suzuki, N., Kawato, T., Takeichi, O., Tsuzukibashi, O., Makimura, M., Ito, K., Maeno, M.
(2007). Receptor activator of NF-kappaB ligand induces the expression of carbonic anhydrase II, cathepsin
K, and matrix metalloproteinase-9 in osteoclast precursor RAW264.7 cells. Life Sciences, 80, 1311-1318.
doi:10.1016/j.lfs.2006.12.037
Gingery, A., Bradley, E., Shaw, A., Oursler, M.J. (2003). Phosphatidylinositol 3-kinase coordinately activates the
MEK/ERK and AKT/NFκB pathways to maintain osteoclast survival. Journal of Cellular Biochemistry, 89,
165-179. doi:10.1002/jcb.10503
Gough, A., Sambrook, P., Devlin, J., Huissoon, A., Njeh, C., Robbins, S., Nguyen, T., Emery, P. (1998). Osteoclastic
activation is the principal mechanism leading to secondary osteoporosis in rheumatoid arthritis. The Journal
of Rheumatology, 25, 1282-1289. doi:10.1002/1529-0131(199807)41:7<1330::AID-ART34>3.0.CO;2-L
Hayden, M.S., Ghosh, S. (2004). Signaling to NF-kappaB. Genes
& Development, 18, 2195-2224.
doi:10.1101/gad.1228704
Hoefert, S., Sade Hoefert, C., Munz, A., Northoff, H., Yuan, A., Reichenmiller, K., Reinert, S., Grimm, M. (2016).
Altered macrophagic THP-1 cell phagocytosis and migration in bisphosphonate-related osteonecrosis of the
jaw (BRONJ). Clinical Oral Investigations, 20, 1043-1054. doi:10.1007/s00784-015-1584-3
Hsu, H., Lacey, D.L., Dunstan, C.R., Solovyev, I., Colombero, A., Timms, E., Tan, H.L., Elliott, G., Kelley, M.J.,
Sarosi, I., Wang, L., Xia, X.Z., Elliott, R., Chiu, L., Black, T., Scully, S., Capparelli, C., Morony, S.,
Shimamoto, G., Bass, M.B., Boyle, W.J. (1999). Tumor necrosis factor receptor family member RANK
mediates osteoclast differentiation and activation induced by osteoprotegerin ligand. Proceedings of the
National Academy of Sciences of the United States of America, 96, 3540-3545. doi:10.1073/pnas.96.7.3540
Ikeda, F., Matsubara, T., Tsurukai, T., Hata, K., Nishimura, R., Yoneda, T. (2009). JNK/c-Jun signaling mediates an
anti-apoptotic effect of RANKL in osteoclasts. Journal of Bone and Mineral Research, 23, 907-914.
doi:10.1359/jbmr.080211
Jimi, E., Aoki, K., Saito, H., D'Acquisto, F., May, M.J., Nakamura, I., Sudo, T., Kojima, T., Okamoto, F., Fukushima,
H., Okabe, K., Ohya, K., Ghosh, S. (2004). Selective inhibition of NF-kappa B blocks osteoclastogenesis and
prevents inflammatory bone destruction in vivo. Nature Medicine, 10, 617-624. doi:10.1038/nm1054
Jurdic, P., Saltel, F., Chabadel, A., Destaing, O. (2006). Podosome and sealing zone: specificity of the osteoclast
This article is protected by copyright. All rights reserved

model. European Journal of Cell Biology, 85, 195-202. doi:10.1016/j.ejcb.2005.09.008
Kang, B., Cheong, S., Chaichanasakul, T., Bezouglaia, O., Atti, E., Dry, S.M., Pirih, F.Q., Aghaloo, T.L., Tetradis, S.
(2013). Periapical disease and bisphosphonates induce osteonecrosis of the jaws in mice. Journal of Bone
and Mineral Research, 28, 1631-1640. doi:10.1002/jbmr.1894
Kim, J.H., Kim, N. (2014). Regulation of NFATc1 in osteoclast differentiation. Journal of Bone Metabolism, 21, 233.
doi:10.11005/jbm.2014.21.4.233
Knowles, H.J. (2017). Multiple roles of angiopoietin-like 4 in osteolytic disease. Front Endocrinol (Lausanne), 8, 80.
doi:10.3389/fendo.2017.00080
Komarova, S.V., Pereverzev, A., Shum, J.W., Sims, S.M., Dixon, S.J. (2005). Convergent signaling by acidosis and
receptor activator of NF-kappaB ligand (RANKL) on the calcium/calcineurin/NFAT pathway in osteoclasts.
Proceedings of the National Academy of Sciences of the United States of America, 102, 2643-2648.
doi:10.1073/pnas.0406874102
Komarova, S.V., Pilkington, M.F., Weidema, A.F., Dixon, S.J., Sims, S.M. (2003). RANK ligand-induced elevation
of cytosolic Ca2+ accelerates nuclear translocation of nuclear factor kappa B in osteoclasts. Journal of
Biological Chemistry, 278, 8286-8293. doi:10.1074/jbc.M206421200
Kong, X., Wu, W., Yang, Y., Wan, H., Li, X., Zhong, M., Zhao, H., Su, X., Jia, S., Ju, D., Lin, N. (2015). Total
saponin from Anemone flaccida Fr. Schmidt abrogates osteoclast differentiation and bone resorption via the
inhibition of RANKL-induced NF-κB, JNK and p38 MAPKs activation. Journal of Translational Medicine,
13, 1-12. doi:10.1186/s12967-015-0440-1
Krzeszinski, J.Y., Wan, Y. (2015). New therapeutic targets for cancer bone metastasis. Trends in Pharmacological
Sciences, 36, 360-373. doi:10.1016/j.tips.2015.04.006
Kwak, H.B., Kim, J.Y., Kim, K.J., Choi, M.K., Kim, J.J., Kim, K.M., Shin, Y.I., Lee, M.S., Kim, H.S., Kim, J.W.,
Chun, C.H., Cho, H.J., Hong, G.Y., Juhng, S.K., Yoon, K.H., Park, B.H., Bae, J.M., Han, J.K., Oh, J. (2009).
Risedronate directly inhibits osteoclast differentiation and inflammatory bone loss. Biological &
Pharmaceutical Bulletin, 32, 1193-1198. doi:10.1248/bpb.32.1193
Lavado, F.M., Prieto, M.P., Osorio, M.R.R., Gálvez, M.I.L., Leal, L.M. (2017). Bilateral retrobulbar optic neuropathy
as the only sign of zoledronic acid toxicity. Journal of Clinical Neuroscience, pii:
S0967-5868(0917)30619-30617. doi:10.1016/j.jocn.2017.06.048
This article is protected by copyright. All rights reserved

Lee, C.Y., Suzuki, J.B. (2015). Medication-related osteonecrosis of the jaws from once per year intravenous
zoledronic acid (Reclast): report of cases. Implant Dentistry, 24, 227-231.
doi:10.1097/ID.0000000000000227
4
Liu, Q., Miao, Y., Wang, X., Lv, G., Peng, Y., Li, K., Li, M., Qiu, L., Lin, J. (2020). Structure-based virtual screening
and biological evaluation of novel non-bisphosphonate farnesyl pyrophosphate synthase inhibitors. European
Journal of Medicinal Chemistry, 186, 111905. doi:10.1016/j.ejmech.2019.111905
Luo, S., Wang, H., Xie, M., Liu, X., Ye, W., Chen, Z., Feng, Y., Cao, G. (2005). The study on the preparation and
biodistribution of 99Tcm-MIDP. Chinese Journal of Nuclear Medicine, 25, 341-343.
doi:10.3760/cma.j.issn.2095-2848.2005.06.006
Matsumoto, M., Sudo, T., Saito, T., Osada, H., Tsujimoto, M. (2000). Involvement of p38 mitogen-activated protein
kinase signaling pathway in osteoclastogenesis mediated by receptor activator of NF-κB Ligand (RANKL).
Journal of Biological Chemistry, 275, 31155-31161. doi:10.1074/jbc.M001229200
Nakagawa, T., Ohta, K., Kubozono, K., Ishida, Y., Naruse, T., Takechi, M., Kamata, N. (2015). Zoledronate inhibits
receptor activator of nuclear factor kappa-B ligand-induced osteoclast differentiation via suppression of
expression of nuclear factor of activated T-cell c1 and carbonic anhydrase 2. Archives of Oral Biology, 60,
557-565. doi:10.1016/j.archoralbio.2014.09.012
Negishi-Koga, T., Takayanagi, H. (2009). Ca2+-NFATc1 signaling is an essential axis of osteoclast differentiation.
Immunological Reviews, 231, 241-256. doi:10.1111/j.1600-065X.2009.00821.x
Niu, G., Luo, S., Yan, X., Yang, M., Ye, W., Wang, H., Xia, Y. (2008). The preparation and biodistribution of
99Tcm-EIDP. Nuclear Techniques, 31, 698-701. doi:10.3321/j.issn:0253-3219.2008.09.013
Odkhuu, E., Koide, N., Haque, A., Tsolmongyn, B., Naiki, Y., Hashimoto, S., Komatsu, T., Yoshida, T., Yokochi, T.
(2012). Inhibition of receptor activator of nuclear factor-kappaB ligand (RANKL)-induced osteoclast
formation
by
pyrroloquinoline
quinine
(PQQ).
Immunology
Letters,
142,
34-40.
doi:10.1016/j.imlet.2011.12.001
Pazianas, M. (2011). Osteonecrosis of the jaw and the role of macrophages. Journal of the National Cancer Institute,
103, 232-240. doi:10.1093/jnci/djq516
Polascik, T.J. (2009). Bisphosphonates in oncology: evidence for the prevention of skeletal events in patients with
bone metastases. Drug Design Development and Therapy, 3, 27-40. doi: 10.2147/DDDT.S3169
This article is protected by copyright. All rights reserved

Qiu, L., Lin, J., Wang, L., Cheng, W., Cao, Y., Liu, X., Luo, S. (2014). A Series of Imidazolyl-Containing
Bisphosphonates with Abundant Hydrogen-Bonding Interactions: Syntheses, Structures, and Bone-Binding
Affinity. Australian Journal of Chemistry, 67, 192. doi:10.1071/ch13194
Russell, R.G., Watts, N.B., Ebetino, F.H., Rogers, M.J. (2008). Mechanisms of action of bisphosphonates: similarities
and differences and their potential influence on clinical efficacy. Osteoporosis International, 19, 733-759.
doi:10.1007/s00198-007-0540-8
Ruza, I., Mirfakhraee, S., Orwoll, E., Gruntmanis, U. (2013). Clinical experience with intravenous zoledronic acid in
the treatment of male osteoporosis: evidence and opinions. Therapeutic Advances in Musculoskeletal
Disease, 5, 182-198. doi:10.1177/1759720x13485829
Song, I., Kim, J.H., Kim, K., Jin, H.M., Youn, B.U., Kim, N. (2009). Regulatory mechanism of NFATc1 in
RANKL-induced osteoclast activation. FEBS Letters, 583, 2435-2440. doi:10.1016/j.febslet.2009.06.047
Soysa, N.S., Alles, N. (2016). Osteoclast function and bone-resorbing activity: An overview. Biochemical and
Biophysical Research Communications, 476, 115-120. doi:10.1016/j.bbrc.2016.05.019
Takayanagi, H., Kim, S., Koga, T., Nishina, H., Isshiki, M., Yoshida, H., Saiura, A., Isobe, M., Yokochi, T., Inoue,
J.-i., Wagner, E.F., Mak, T.W., Kodama, T., Taniguchi, T. (2002). Induction and Activation of the
Transcription Factor NFATc1 (NFAT2) Integrate RANKL Signaling in Terminal Differentiation of
Osteoclasts. Developmental Cell, 3, 889-901. doi:10.1016/s1534-5807(02)00369-6
Tao, H., Okamoto, M., Nishikawa, M., Yoshikawa, H., Myoui, A. (2011). P38 mitogen-activated protein kinase
inhibitor, FR167653, inhibits parathyroid hormone related protein-induced osteoclastogenesis and bone
resorption. PLoS One, 6, e23199. doi:10.1371/journal.pone.0023199
Teitelbaum, S.L. (2011). The osteoclast and its unique cytoskeleton. Annals of the New York Academy of Sciences,
1240, 14-17. doi:10.1111/j.1749-6632.2011.06283.x
van Beek, E.R., Löwik, C.W.G.M., Ebetino, F.H., Papapoulos, S.E. (1998). Binding and antiresorptive properties of
heterocycle-containing bisphosphonate analogs: structure-activity relationships. Bone, 23, 437-442.
doi:10.1016/s8756-3282(98)00120-3
Wagner, E.F., Karsenty, G. (2001). Genetic control of skeletal development. Current Opinion in Genetics &
Development, 11, 527-532. doi:10.1016/s0959-437x(00)00228-8
Wang, Y., Luo, S., Qiu, L., Lin, J., Zhai, H., Xia, Y. (2010). Synthesis and characterization of two new zoledronic
This article is protected by copyright. All rights reserved

acid derivatives. Journal of Jiangnan University (Natural Science Edition), 9, 592-596.
Wang, Z.Q., Ovitt, C., Grigoriadis, A.E., Mohle-Steinlein, U., Ruther, U., Wagner, E.F. (1992). Bone and
haematopoietic defects in mice lacking c-fos. Nature, 360, 741-745. doi:10.1038/360741a0
Widler, L., Jaeggi, K.A., Glatt, M., Müller, K., Bachmann, R., Bisping, M., Born, A.-R., Cortesi, R., Guiglia, G.,
Jeker, H., Klein, R., Ramseier, U., Schmid, J., Schreiber, G., Seltenmeyer, Y., Green, J.R. (2002). Highly
potent geminal bisphosphonates from pamidronate disodium (aredia) to zoledronic acid (zometa). Journal of
Medicinal Chemistry, 45, 3721-3738. doi:10.1021/jm020819i
Xu, X.J., Lv, F., Liu, Y., Wang, J.Y., Ma, D.D., Asan, Wang, J.W., Song, L.J., Jiang, Y., Wang, O., Xia, W.B., Xing,
X.P., Li, M. (2017). Novel mutations in FKBP10 in Chinese patients with osteogenesis imperfecta and their
treatment with zoledronic acid. Journal of Human Genetics, 62, 205-211. doi:10.1038/jhg.2016.109
Yamanaka, Y., Clohisy, J.C., Ito, H., Matsuno, T., Abu-Amer, Y. (2013). Blockade of JNK and NFAT pathways
attenuates orthopedic particle-stimulated osteoclastogenesis of human osteoclast precursors and murine
calvarial osteolysis. Journal of Orthopaedic Research, 31, 67-72. doi:10.1002/jor.22200
Zhao, Q., Wang, X., Liu, Y., He, A., Jia, R. (2010). NFATc1: Functions in osteoclasts. The International Journal of
Biochemistry & Cell Biology, 42, 576-579. doi:10.1016/j.biocel.2009.12.018
Ziebart, T., Halling, F., Heymann, P., Neff, A., Blatt, S., Jung, J., Pabst, A., Righesso, L., Walter, C. (2016). Impact of
Soft Tissue Pathophysiology in the Development and Maintenance of Bisphosphonate-Related Osteonecrosis
of the Jaw (BRONJ). Dentistry Journal, 4. doi:10.3390/dj4040036
This article is protected by copyright. All rights reserved
