Synthesis and Characterization of ReS2 and ReSe2 Layered Chalcogenide Single Crystals

Article abstract of DOI:10.1021/acs.chemmater.6b00364

We report the synthesis of high-quality single crystals of ReS₂ and ReSe₂ transition metal dichalcogenides using a modified Bridgman method that avoids the use of a halogen transport agent. Comprehensive structural characterization using X-ray diffraction and electron microscopy confirm a distorted triclinic 1T′ structure for both crystals and reveal a lack of Bernal stacking in ReS₂. Photoluminescence (PL) measurements on ReS₂ show a layer-independent bandgap of 1.51 eV, with increased PL intensity from thicker flakes, confirming interlayer coupling to be negligible in this material. For ReSe₂, the bandgap is weakly layer-dependent and decreases from 1.31 eV for thin layers to 1.29 eV in thick flakes. Both chalcogenides show feature-rich Raman spectra whose excitation energy dependence was studied. The lower background doping inherent to our crystal growth process results in high field-effect mobility values of 79 and 0.8 cm²/(V s) for ReS₂ and ReSe₂, respectively, as extracted from FET structures fabricated from exfoliated flakes. Our work shows ReX₂ chalcogenides to be promising 2D materials candidates, especially for optoelectronic devices, without the requirement of having monolayer thin flakes to achieve a direct bandgap.

Full text of DOI:10.1021/acs.chemmater.6b00364

Subscriber access provided by SUNY DOWNSTATE
Article
2
Synthesis and characterization of ReS and
2
ReSe layered chalcogenide single crystals
Bhakti Jariwala, Damien Voiry, Apoorv Jindal, Bhagyashree A. Chalke, Rudheer Bapat,
Thamizhavel Arumugam, Manish Chhowalla, Mandar Deshmukh, and Arnab Bhattacharya
Chem. Mater., Just Accepted Manuscript • DOI: 10.1021/acs.chemmater.6b00364 • Publication Date (Web): 25 Apr 2016
Downloaded from http://pubs.acs.org on April 28, 2016
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a free service to the research community to expedite the
dissemination of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts
appear in full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been
fully peer reviewed, but should not be considered the official version of record. They are accessible to all
readers and citable by the Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered
to authors. Therefore, the “Just Accepted” Web site may not include all articles that will be published
in the journal. After a manuscript is technically edited and formatted, it will be removed from the “Just
Accepted” Web site and published as an ASAP article. Note that technical editing may introduce minor
changes to the manuscript text and/or graphics which could affect content, and all legal disclaimers
and ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors
or consequences arising from the use of information contained in these “Just Accepted” manuscripts.
Chemistry of Materials is published by the American Chemical Society. 1155 Sixteenth
Street N.W., Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 24
Chemistry of Materials
1
2
3
4
5
6
7
8
9
2
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
†
‡
†
†
†
†
‡
†
∗ †
†
‡
2
2
2
2
2
ACS Paragon Plus Environment

Chemistry of Materials
Page 2 of 24
1
2
3
2
4
5
6
2
2
2
7
8
2
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
2
2
2
2
2
2
2
2
ACS Paragon Plus Environment

Page 3 of 24
Chemistry of Materials
1
2
3
4
5
6
2
2
7
8
9
2
2
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
2
2
2
2
2
2
2
−
×10−6
2
◦
◦
◦
ACS Paragon Plus Environment

Chemistry of Materials
Page 4 of 24
1
2
3
4
◦
5
6
µ
7
2
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
2
2
2
¯
1
3
2
2
2
(00l)
(00l)
(hkl)
ACS Paragon Plus Environment

Page 5 of 24
Chemistry of Materials
1
2
3
4
5
6
7
8
Side view
(a)
(b)
Re
S(Se)
Top view
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
b
a
2
(001)
2θ = 14.5◦
2θ = 13.5◦
2
◦
2
2
ACS Paragon Plus Environment

Chemistry of Materials
Page 6 of 24
1
2
3
o
4
5
6
o
FWHM = 0.06
FWHM = 0.1
(a)
(b)
ReS2
ReSe2
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
13.6
13.8
2 (degree)
13θ.7
14.3 14.4 14.5 14.6 14.7
2θ(degree)
10 15 20 25 30 35 40 45 50 55 60 65 70 75 80
10 15 20 25 30 35
45
70
80
75
40
50 55 60 65
2θ (degree)
2θ (degree)
2θ
2
2
2
2
◦
◦
(001)
2
2
2
2
2
2
2
2
ACS Paragon Plus Environment

Page 7 of 24
Chemistry of Materials
1
2
3
4
5
6
7
8
(2h2k0)
9
(hk0)
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
2
2
2
2
ACS Paragon Plus Environment

Chemistry of Materials
Page 8 of 24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
ReS2
(b) Zone axis:[-1 2 1]
(a)
(b)
(0-1 2)
(2 0 2)
(-2 0-2)
1 / n m
5
(0 1-2)
Zone axis: [-1 0 0]
(c)
(0 1 0)
(0 0 1)
5 1/nm
2 nm
(c)
Zone axis:[0 0 1]
(d)
(1-1 0)
(1 0 0)
(0 1 0)
2 1/nm
2 nm
2
2
ACS Paragon Plus Environment

Page 9 of 24
Chemistry of Materials
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
ReSe2
(a)
Zone axis:[2 1 0]
(b)
(0 0 1)
(1 -2 1)
5 1 / n m
2 nm
Zone axis:[1 0 0]
(c)
(d)
(0 1 0)
(0 0 1)
(0 1 -1)
2 nm
5 1 / n m
2
ACS Paragon Plus Environment

Chemistry of Materials
Page 10 of 24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
7/2
5/2
7/2
5/2
2
2
2
3/2
1/2
5/2
3/2
2
ACS Paragon Plus Environment

Page 11 of 24
Chemistry of Materials
1
2
3
4
5
ReS2
Re4f7/2
(b)
(a)
6
7
8
S2p3/2
S2p1/2
Re4f5/2
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
47 46 45 44 43 42 41 40
165 164 163 162 161 160 159 158
Binding energy (eV)
Binding energy (eV)
ReSe2
Re4f7/2
(c)
(d)
Se3d5/2
Re4f5/2
Se3d3/2
47
46 45
44
43
42 41
40 58
57
56
55
54
Binding energy (eV)
Binding energy (eV)
2
2
2
7/2
3/2
5/2
1/2
2
5/2
3/2
2
2
µ
2
2
ACS Paragon Plus Environment

Chemistry of Materials
Page 12 of 24
1
2
3
4
2
2
5
6
−1
7
8
9
2g1
2g2
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
−1
≤
2
2
−1
−1
−1
−1
2
2
−1
−1
−1
−1
−1
−1
−1
−1
−1
−1
−1
−1
2
2
ACS Paragon Plus Environment

Page 13 of 24
Chemistry of Materials
1
2
3
4
5
(a)
ReS
(b)
ReSe2
2
514 nm
514 nm
6
7
8
9
532 nm
633 nm
532 nm
633 nm
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
400
100
150
200
250
300
100
150
200
250
300
350
400
450
350
(
cm-1
)
(
cm-1
)
Raman Shift
Raman Shift
2
2
2
∼
∼
2
∼
2
2
≈
≈
≈
ACS Paragon Plus Environment

Chemistry of Materials
Page 14 of 24
1
2
3
4
5
6
7
8
9
2
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
2
(a)
(b)
Thick flake
Thin flake
ReS2
Thick flake
Thin flake
ReSe2
1.51 eV
1.31 eV
1.29 eV
1. 40
1. 5
1. 6
1. 7
1. 1
1. 2
1. 3
1. 4
1. 5
Energy (eV)
Energy (eV)
∼
∼
2
2
2
2
2
++
2
2
2
ACS Paragon Plus Environment

Page 15 of 24
Chemistry of Materials
1
2
3
4
5
6
ds
ds
7
8
2
2
2
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
µFE
(dIds/dVg)×
×
ꢀoxVbias
ꢀox
2
ꢀox
×10−4
2
2
2
2
2
2
2
2
×103
×104
on off
2
2
µ
µ
2
2
10
5
4
3
2
1
0
(b)
3
2
1
ReSe2
(a)
ReS2
10
1
1
0.1
0.1
0.01
1E-3
0.01
1E-3
1E-4
0
-2
0
2
4
6
8
10
5
10
15
20
25
V
(V)
V
(V)
bg
bg
ds
bg
ds
2
2
µ
2
ACS Paragon Plus Environment

Chemistry of Materials
Page 16 of 24
1
2
3
4
2
2
5
6
7
On
Off
ds
8
9
2
µ
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
3
7
7
6
2
⊥
2
4
8
5
2
2
4
2
2
2
2
2
2
2
2
ACS Paragon Plus Environment

Page 17 of 24
Chemistry of Materials
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
2
2
◦
α
α
ACS Paragon Plus Environment

Chemistry of Materials
Page 18 of 24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
6
◦
◦
µ
µ
2
∼
∼
2
2
2
ACS Paragon Plus Environment

Page 19 of 24
Chemistry of Materials
1
2
3
4
5
6
7
8
9
≈
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
≤ 10−5
2
2
2
2
2
ACS Paragon Plus Environment

Chemistry of Materials
Page 20 of 24
1
2
3
4
2
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
2
2
2
2
2
2
ACS Paragon Plus Environment

Page 21 of 24
Chemistry of Materials
1
2
3
4
5
6
7
8
2
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
2
2
2
2
2
2
2
ACS Paragon Plus Environment

Chemistry of Materials
Page 22 of 24
1
2
3
4
2
2
5
6
7
8
9
2
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
2
2
2
2
2
2
ACS Paragon Plus Environment

Page 23 of 24
Chemistry of Materials
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
2
2
2
ACS Paragon Plus Environment

Chemistry of Materials
Page 24 of 24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
10
1
Thick flake 1.51eV
3
I-V curve
Thin flake
PL
2 nm
10 µm
2
1
0.1
0.01
1E-3
0
1. 40
1. 5
Energy (eV)
1. 6
1. 7 -2
0
2
4
bg
6
8
10
V
(V)
ACS Paragon Plus Environment
