A three-enzyme-system to degrade curcumin to natural vanillin

Article abstract of DOI:10.3390/molecules20046640

The symmetrical structure of curcumin includes two 4-hydroxy-3-methoxyphenyl substructures. Laccase catalyzed formation of a phenol radical, radical migration and oxygen insertion at the benzylic positions can result in the formation of vanillin. As vanillin itself is a preferred phenolic substrate of laccases, the formation of vanillin oligomers and polymers is inevitable, once vanillin becomes liberated. To decelerate the oligomerization, one of the phenolic hydroxyl groups was protected via acetylation. Monoacetyl curcumin with an approximate molar yield of 49% was the major acetylation product, when a lipase from Candida antarctica (CAL) was used. In the second step, monoacetyl curcumin was incubated with purified laccases of various basidiomycete fungi in a biphasic system (diethyl ether/aqueous buffer). A laccase from Funalia trogii (LccFtr) resulted in a high conversion (46% molar yield of curcumin monoacetate) to vanillin acetate. The non-protected vanillin moiety reacted to a mixture of higher molecular products. In the third step, the protecting group was removed from vanillin acetate using a feruloyl esterase from Pleurotus eryngii (PeFaeA) (68% molar yield). Alignment of the amino acid sequences indicated that high potential laccases performed better in this mediator and cofactor-free reaction.

Full text of DOI:10.3390/molecules20046640

Molecules 2015, 20, 6640-6653; doi:10.3390/molecules20046640
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
A Three-Enzyme-System to Degrade Curcumin to
Natural Vanillin
Vida Esparan *, Ulrich Krings, Marlene Struch and Ralf G. Berger
Institut für Lebensmittelchemie im Zentrum Angewandte Chemie, Gottfried Wilhelm Leibniz
Universität Hannover, Callinstraße 5, D-30167 Hannover, Germany;
E-Mails: krings@lci.uni-hannover.de (U.K.); marlene.struch@lci.uni-hannover.de (M.S.);
rg.berger@lci.uni-hannover.de (R.G.B.)
* Author to whom correspondence should be addressed; E-Mail: vida.esparan@lci.uni-hannover.de;
Tel.: +49-511-762-4581; Fax: +49-511-762-4547.
Academic Editor: Luca Forti
Received: 18 February 2015 / Accepted: 7 April 2015 / Published: 14 April 2015
Abstract: The symmetrical structure of curcumin includes two 4-hydroxy-3-methoxyphenyl
substructures. Laccase catalyzed formation of a phenol radical, radical migration and
oxygen insertion at the benzylic positions can result in the formation of vanillin. As
vanillin itself is a preferred phenolic substrate of laccases, the formation of vanillin
oligomers and polymers is inevitable, once vanillin becomes liberated. To decelerate the
oligomerization, one of the phenolic hydroxyl groups was protected via acetylation.
Monoacetyl curcumin with an approximate molar yield of 49% was the major acetylation
product, when a lipase from Candida antarctica (CAL) was used. In the second step,
monoacetyl curcumin was incubated with purified laccases of various basidiomycete fungi
in a biphasic system (diethyl ether/aqueous buffer). A laccase from Funalia trogii (LccFtr)
resulted in a high conversion (46% molar yield of curcumin monoacetate) to vanillin
acetate. The non-protected vanillin moiety reacted to a mixture of higher molecular
products. In the third step, the protecting group was removed from vanillin acetate using a
feruloyl esterase from Pleurotus eryngii (PeFaeA) (68% molar yield). Alignment of the
amino acid sequences indicated that high potential laccases performed better in this
mediator and cofactor-free reaction.
Keywords: vanillin; curcumin; lipase; laccase; esterase

Molecules 2015, 20
6641
1. Introduction
Flavors and fragrances originate from traditional extraction or distillation of plant and animal
sources or from chemosynthesis, but the quality and the stability of the natural supplies are sometimes
limited. Effective law in Europe (EG 1334/2008) and in the U.S. (Code of Federal Regulation, Title
21) defines flavors with the preferred label ‘natural’ as compounds obtained by physical, enzymatic or
microbiological processes. As this disqualifies chemical synthesis, biotechnological approaches have
moved into focus [1]. Biocatalysis represents an economic alternative using either intact cells or
isolated enzymes, such as laccases [2], often resulting in the formation of products difficult to obtain
by conventional chemical means. Enzymes possess a long history of safe use in producing fermented
foods. They accelerate just one reaction without the ballast of an ongoing metabolism of a whole cell.
Technically well manageable, many technical enzymes have become amenable through recombinant
hosts expressing the target enzyme in good yield and purity [3].
With an annual consumption of an estimated 15,000 tons, vanillin (4-hydroxy-3-methoxybenzaldehyde)
is one of the most widely-used flavor compounds in baked goods, chocolates, dairy products, perfumes
and even pharmaceuticals. Only 0.2% of the total demand is provided from vanilla beans, while the
rest is supplied by chemical synthesis and a ferulic acid-based bioprocess. Natural vanilla flavor is a
complex of many components, but the aroma is largely determined by vanillin. Because of the scarcity
and high cost of natural vanilla extract, there has been a continuing interest in its biotechnological
production. There are different possibilities for the production of natural vanillin, such as
biotransformation of caffeic acid and veratryl aldehyde, or the fermentation of natural substrates, such
as ferulic acid, eugenol, isoeugenol, coniferyl alcohol, vanillin alcohol and stilbene, by bacteria and
fungi, such as Pseudomonas fluorescens, Escherichia coli, Amycolatopsis sp., Streptomyces setonii,
Pycnoporus cinnabarinus or Aspergillus niger [4–7]. Ferulic acid is available in abundance in plant cell
walls and has become the most popular precursor substrate. The increasing price of ferulic acid has
stimulated the search for other natural precursor molecules to obtain vanillin naturally.
Curcumin occurs in turmeric (Curcuma longa) rhizome powder, a common ingredient of curry
spice, in concentrations of up to 3%. It is a food colorant (E 100) and was claimed to exhibit numerous
wide biological functions, although the bioavailability of curcumin is low [8]. The two phenolic rings
at the molecule ends are connected by two α,β-unsaturated carbonyl moieties. A hypothetical cleavage
at the benzylic position would yield two moles of vanillin from one curcumin molecule. Because of
physico-chemical and structural features similar to lignin-related compounds, it was supposed that
lignin-degrading microorganism may also be able to degrade curcumin. Previously, Rhodococcus
strains have been reported as promising candidates, which degraded curcumin to (E)-6-(4'-hydroxy-3'-
methoxyphenyl)-2,4-dioxo-5-hexenal, feruloylmethane, ferulic acid and vanillin [9]. The aim of the
present study was to develop an enzyme-based route starting with curcumin and resulting in vanillin as
the most abundant reaction product.
2. Results and Discussion
For 20 years, the degradation of natural ferulic acid to vanillin using an optimized bacterial strain
(Amycolatopsis family) has been one of a few successful large-scale processes using whole cell

Molecules 2015, 20
6642
cultures for the production of a natural flavor compound [10]. Alternative precursors and routes to
natural vanillin have been intensively researched, including the symmetric cleavage of curcumin. Its
autoxidative degradation at physiological conditions led to the incorporation of oxygen into a curcumin
radical resulting in a bi-substituted bicyclopentadione structure, while vanillin, ferulic acid and
feruloylmethane occurred as minor degradation products [11]. A more concerted enzymatic cleavage at
both benzylic positions using either a whole cell system or an oxidoreductase could be envisaged.
One curcumin molecule would result in the formation of two molecules of vanillin, and a
cofactor-independent enzyme would be most preferred.
Abstraction of a hydrogen from a phenol with subsequent oxidation of the substrate is the
domain of fungal laccases. These multi-copper oxidases (E.C.1.10.3.2) form resonance-stabilized
phenol radicals directly or by the aid of mediators, such as caffeic acid, vanillin (natural) or
2,2'-azino-bis(3-ethylbenzthiazoline-6-sulphonic acid) (ABTS, non-natural), and reduce molecular
oxygen to water at the same time [12]. The cofactor and mediator-free direct incubation of curcumin
with various laccases of different redox potentials resulted in an immediate degradation of curcumin
(as measured by HPLC) and visible formation of a buffer-insoluble precipitate. However, the targeted
degradation products, mainly vanillin (and ferulic acid), were found in traces only. Being phenols
themselves, they were preferred substrates for the laccases, resulting in oligo-/polymerization of the
intermediate monomers. To arrive at the intended benzylic cleavage, a less reactive substrate was
required. A hypothetical mechanism would imply the delocalization of the unpaired electron of
the phenoxy radical into the side chain and, after tautomerization and insertion of molecular oxygen,
the generation of respective 1,2-endoperoxides; these, in turn, are well known to decay into two
carbonyl moieties (Figure 1) [13].
2.1. Acetylation of Curcumin
2.1.1. By a Chemical Route
To reduce the suitability of curcumin as a laccase substrate, it was aspired to achieve the acetylation
of at least one of the phenolic hydroxyl groups of the molecule. Chemical formation of acetyl
curcumins yielded two pairs of peaks with identical molecular masses, corresponding to monoacetyl,
m/z 409, ESI(−) with 50%, and diacetyl curcumins, m/z 451, ESI(−) 50% by mass of total reaction
products. The respective major peak of each pair was assigned to the phenolic acetyl/diacetyl ester
with 93% by mass, whereas the minor peaks (7% by mass) were assigned to the acetylated hydroxyl
group of the tautomeric form of curcumin. The reaction mixture was partially purified by means of
preparative TLC. A curcumin-free mixture after purification, which was composed of around 90%
monoacetyl curcumin and 10% of diacetyl curcumin, was used as the substrate for the following
cleavage by three fungal laccases possessing different redox potentials.

Molecules 2015, 20
6643
Figure 1. Hypothetical pathway of laccase-catalyzed biotransformation of curcumin.
(1) Curcumin; (2) O-centered curcumin radical; (3) C-centered curcumin radical;
(4,5) C-centered radicals in the alkenyl chain of curcumin; (6,7) intermediate
1,2-endoperoxides of the curcumin radical; (8) Vanillin; (9) Ferulic acid.
2.1.2. By an Enzymatic Route
For the production of ‘natural’ vanillin, an enzyme-based formation of acetyl curcumin is
mandatory. Therefore, reverse hydrolysis was adapted for the acetylation of curcumin in organic
medium. A number of commercial lipases are available for acetate synthesis. CAL, a lipase from

Molecules 2015, 20
6644
Candida antarctica, was frequently used, and vinyl acetate served as the acyl donor, thus forcing the
equilibrium to the product side by tautomerization of the liberated vinyl alcohol. Yields were
semi-quantified by LC-MS, but remained unsatisfactory. Reaction solvent, temperature, time and the
molar ratio of the reactants were varied. A maximum yield of approximately 49% was eventually
achieved using geranyl acetate as the acyl donor and a molar ratio of 1:50 of curcumin to acetyl donor.
The yield of monoacetyl curcumin increased continuously over time until day three and decreased
again thereafter. Even after a long time of incubation, only traces of diacetyl curcumin were detected.
It may be speculated that the large and inflexible curcumin molecule does not fit well into the deep
substrate-binding site of this lipase. The larger monoacetyl curcumin fitted even less well, thereby
preventing diacetylation.
2.2. Transformation of Acetyl Curcumin by Laccases
The commercial laccase LccAbi of A. bisporus and two laccases, recovered and purified from
supernatants of cultivated fungal strains, LccMgi (M. giganteus) and LccFtr (F. trogii), were compared
(Table 1) [14]. Iso-active (1.19 U·mL−1 adjusted against ABTS as a substrate) laccase preparations in
buffered aqueous solution were added to acetyl curcumins in different solvent systems; these were
monophasic organic solvents, monophasic water/water miscible organic solvents and biphasic systems
composed of water/water immiscible organic solvents
Table 1. Characteristics of laccases used for the degradation of acetyl curcumin.
Temperature
Optimum b (°C )
Laccase
Origin
Redox Potential a
pI
pH Optimum b
LccAbi
LccMgi
LccFtr
A. bisporus
M. giganteus
F. trogii
Middle (0.47–0.71 V) 3.5
4.5–5
5–5.5
4.5–5
30–40
High (0.73–0.78 V)
High (0.73–0.78 V)
3.1
3.8
30–40
30–40
a
b
According to the literature; according to 2,2'-azino-bis(3-ethylbenzthiazoline-6-sulphonic acid) (ABTS)
enzyme activity.
The best reaction conditions were found to be a biphasic system consisting of water/diethyl ether.
Samples were taken after 20 h and analyzed by LC-MS for substrate transformation and possible
polymerization products and GC-MS for volatile degradation products. In all incubations in the
presence of a laccase, as well as in the controls, diacetyl curcumin remained stable and did not change
concentration over time. Monoacetyl curcumin concentration, in contrast, declined with time
depending on the laccase added. For LccAbi, no distinct degradation occurred, whereas for LccMgi, a
15% and for LccFtr a 46% decline of the monoacetyl curcumin concentration were observed. During
the reaction, the yellow bright reaction solution did not show visible alteration with LccAbi, but turned
into yellow/brownish with little precipitation with LccMgi and became cloudy with LccFtr. Several
molecular masses in the m/z range >600 Da were detected over a broad retention time window in the
LC-MS chromatograms of these samples, indicating the formation of oligomer phenols, but the
structural elucidation of these was no the aim of this study. GC-MS analysis of the volatile reaction
products showed just one major product, acetyl vanillin. This was expected, because other possible
degradation products, such as vanillin or ferulic acid, were good substrates for the laccases and

Molecules 2015, 20
6645
polymerized in situ, as discussed above. The highest concentration of acetyl vanillin was analyzed for
LccFtr, which agreed with the rapid degradation of monoacetyl curcumin (Table 2).
Table 2. Yield of vanillin acetate after cleavage of monoacetyl curcumin in a biphasic
system: 2 mL of 0.5 mM monoacetyl curcumin in diethyl ether and 2 mL aqueous buffer of
laccases (each set to 1.19 U·mL−1) under continuous mixing for 20 h at 20 °C.
Laccase
LccAbi
LccMgi
LccFtr
Vanillin Acetate (mg·L−1) Vanillin Acetate (mM) Molar Product Yield (%) *
6.4
15.1
45.02
0.032
0.078
0.23
6.4
15.6
46
* Calculated according to the concentration of the actual precursor, monoacetyl curcumin.
2.3. Alignment of the Laccases
Different amino acid substituents near the substrate binding site and copper T1 coordination of
laccases result in different potentials of the redox centers, thus affecting the catalytic properties of
bacterial [15] and fungal laccases [16]. To better explain the observed differences in reactivity, the
respective parts of amino acid sequences were aligned (Figure 2). According to previous studies, the
T1 copper shows a trigonal bipyramidal coordination with three highly-conserved trigonal ligands
(H,C,H) and two weakly coordinated ligands in axial position, of which one is invariable Ile, whereas
the second is variable. There is a modest correlation between this axial ligand and the redox potential
of T1 copper, with Phe consistently producing high, Leu middle and Met low potentials. An adjacent
tripeptide (LEA in terms of high potential laccases), which is part of the T1 pocket, also serving as part
of the substrate-binding pocket, is indicative of the respective redox potential of laccases, as well [16,17].
The comparison of the sequences of the laccases from Ftr, Mgi and Abi with literature data showed
that with Phe, the axial ligand located in position 460 for Laccase Ftr and 480 for laccase Mgi; both
had to be classified as high redox potential-type enzymes and LccAbi, having leucine in the axial
position 485, as a midrange potential enzyme. The different oxidation rates of the laccases with
monoacetyl curcumin as the substrate may be explained by these differences in the amino acid
sequences and, consequently, redox potential. High potential laccases appear to be more suitable for
the cleavage of C = C bonds in the side chain of curcumin.
Figure 2. Partial amino acid alignment of LccFtr (Funalia trogii), LccMgi (Meripilus
giganteus) and LccAbi (Agaricus bisporus). Bold letters show three out of four invariable
T1 copper ligands, bold and italic letters the variable axial ligand and letters highlighted in
grey a characteristic tripeptide of the binding site of T1 copper indicative of the redox
potential of the respective laccases.

Molecules 2015, 20
6646
2.4. Enzymatic Deacetylation of Acetyl Vanillin
Vanillin acetate was obtained as the major volatile compound of the laccase-catalyzed degradation
of monoacetyl curcumin. To achieve the enzyme-catalyzed deacetylation of acetyl vanillin, three
different esterases were compared (Table 3). At an optimum reaction temperature of 37 °C, the
esterase PeFaeA deacetylated 68% of acetyl vanillin to vanillin after five hours of incubation, as
calculated by external standard-based GC-flame ionization detection (FID) and GC-MS analyses.
Table 3. Yield of vanillin after deacetylation of vanillin acetate in a biphasic system:
2 mL of 1 mM vanillin acetate in diethyl ether and hexane (5:95) and 2 mL aqueous buffer
of esterases (each set to 1 U·mL−1) under continuous mixing for 5 h at 37 °C.
Esterase
UmChlE
Vanillin (mg·L−1) * Vanillin (mM) Molar Product Yield (%)
0
0
0
Porcine liver
PeFaeA
75.5
103
0.50
0.68
50
68
* Calculated according to the external standard (3,4-dimethoxybenzaldehyde).
In summary, many different possibilities for the biotechnological production of vanillin have been
investigated in the past. Most processes were primarily affected by the high chemical reactivity and
toxicity of vanillin. Thus, three-step enzymatic reactions are a novel approach to produce natural
vanillin from curcumin (Figure 3).
Figure 3. Three-step enzymatic bioconversion of curcumin to natural vanillin.

Molecules 2015, 20
6647
3. Experimental Section
3.1. Materials
All chemicals were analytical grade. Curcumin (>90%, natural) was purchased by Roth (Karlsruhe,
Germany). 3,4-dimethoxybenzaldehyde and geranyl acetate from Sigma-Aldrich (Taufkirchen,
Germany). 2,2'-Azino-bis (3-ethylbenzthiazoline-6-sulfonic acid) diammonium salt (ABTS) and
p-nitrophenyl butanoate were obtained from ICN Biochemicals (Muenchen, Germany). Diethyl ether,
ethyl acetate, toluene and n-pentane were from Karl Roth (Karlsruhe, Germany), and solvents (all MS
grade) used for HPLC-MS were from Carlo Erba Reactifs (Peypin, France).
3.2. Enzymes
Immobilized lipase (triacylglycerol hydrolase, EC 3.1.1.3 (Novozyme_435, 5000 U·g−1)) from
Candida antarctica and laccase from Agaricus bisporus (6.8 U·mg−1) were from Sigma-Aldrich
(Taufkirchen, Germany), and esterase from porcine liver (lyophilisate, 15 U·mg−1) was from Sigma
Aldrich (Taufkirchen, Germany). Recombinant feruloyl esterase from Pleurotus eryngii (PeFaeA) and
chlorogenic acid esterase from Ustilago maydis (UmChlE) were selected from our own stocks. Two
further laccases were isolated from fungal culture supernatants, as described below. The strains were
purchased from the Centraalbureau voor Schimmelcultures (Meripilus giganteus CBS 561.86) and from
the German Collection of Microorganisms and Cell Cultures (Funalia trogii, DSMZ), respectively.
3.3. Cultivation of Fungi
The culture supernatant of M. giganteus was provided according to the paper of Schmidt et al. [18].
Submerged pre-culture of F. trogii was inoculated with the same structure of M. giganteus, except that
for the main cultures, the expression of laccases was induced either by the addition of three grams per
100 mL−1 wheat bran and CuSO4 (300 µM final concentration) to the culture medium of F. trogii or
300 µM CuSO4 solely in the case of M. giganteus. At the time of maximum laccase activity (ABTS
activity, pH 3.0), cultivation was stopped and the culture supernatant harvested and stored at −20 °C,
unless used immediately for laccase isolation and purification.
3.4. Laccase Isolation and Purification
The laccase from M. giganteus was isolated according to the protocol of Schmidt et al. [18]. In
brief, the supernatant was frozen at −20 °C, thawed and centrifuged at 25,000× g. After filtration using
a 0.45-µM polyester filter (CHROMAFIL PET-45/25, Macherey-Nagel, Dueren, Germany) and
concentration using an ultra-filtration module (30-kDa cut-off, PES, Sartorius, Goettingen, Germany),
the laccase was purified using fast protein liquid chromatography (Biologic Duoflow TM, Bio-Rad,
Hercules, CA, USA) at 4 °C. First, a weak anion exchange column was applied (HiPrep 16/10 DEAE,
16 × 100 mm fast flow, GE Healthcare, Munich, Germany). Concentrated laccase fractions were submitted
to a second purification using size exclusion chromatography (Superdex 75 10/300 GL column, GE
Healthcare, Munich, Germany). Active fractions were pooled and adjusted to the activity required.

Molecules 2015, 20
6648
Laccase from F. trogii was purified as follows: The culture supernatant was frozen at −20 °C,
thawed and centrifuged at 5000× g at 4 °C for 15 min. The supernatant was filtered (0.45 µM,
Chromafil Pet-45/25, Dueren, Germany), concentrated using an ultrafiltration module (30-kDa cut-off,
PES, Sartorius, Goettingen, Germany) and subjected to fast protein liquid chromatography (Biologic
Duoflow TM, Bio-Rad, Hercules, United States) at 4 °C. Twenty five milliliters of concentrated
solution were purified on a HiPrep 16/10 DEAE, 16 × 100 mm fast flow column with a flow rate of
3 mL·min−1 (GE Healthcare, Munich, Germany) with 20 mL running Buffer A (50 mM, potassium
phosphate, pH 6.5) and eluted with 5% Buffer B (50 mM potassium phosphate, pH 6.5 + 1 M NaCl).
Purification was controlled using SDS-PAGE electrophoresis.
SDS-PAGE was performed using 12% (w/v) polyacrylamide gels. Samples were diluted in native
loading buffer (0.05 M Tris/HCl pH 6.8, 0.1% bromophenol blue, 10% glycerol, 2% SDS) and applied
to electrophoresis. Proteins were stained with ready-to-use Instant Blue solution (0.1%, Expedeon,
Cambridge, UK). Laccase activity staining was performed directly on the gel using ABTS (5 mM in
100 mM sodium phosphate buffer pH 4.5).
3.5. Analysis of Amino Acid Sequence
The identity of the purified laccases, as well as the sequence of lccAbi were deduced from the
amino acid sequence of tryptic peptides of cut out protein bands from SDS gel electrophoresis.
De-staining and tryptic digestions of the respective protein bands were carried out as described
elsewhere [19]. Tryptic peptides were analyzed by means of nano-LC EASY-nLC II (Bruker
Daltronik, Bremen, Germany) equipped with a 20-mm pre-column (C18-A1 3PCS; ThermoFisher
Scientific, Dreieich, Germany) and a capillary column (0.1 mm × 150 mm) packed with Magic C18
AQ (3-mm particle size, 200-Å pore size; Michrom Bioresources, Inc., Auburn, CA, USA) eluted by a
linear gradient (300 nL·min−1) of water and acetonitrile, each with 0:1% formic acid v/v from 95%
water to 95% acetonitrile within 25 min and held for 15 min. The amino acid sequences elucidated
were subjected to protein database (NCBI, Mascot search algorithm). Sequences were aligned using
the ClustalW2 multiple sequence alignment database.
3.6. Enzyme Assays
3.6.1. Laccase Activity
The activity of each laccase was determined with ABTS as the substrate. The change in the
absorbance was recorded at 420 nm using a Biotek Eon 2 Microplate reader (Biotek, Winooski, VT,
USA) at 30 °C. In brief, 15 µL of enzyme solution were mixed with 0.5 mM substrate in
50 mM phosphate buffer at pH 3.0 in a total volume of 300 µL. The change in the absorbance was
monitored over ten minutes. One unit of enzyme activity was defined as 1 µmol of substrate
(ɛ = 36,000 L·mol−1·cm−1) oxidized per minute under the experimental conditions [20].
3.6.2. Esterase Activity
Esterase activity was assayed using p-nitrophenyl butanoate as the substrate and monitoring the
change in absorbance at 410 nm (15,000 L·mol−1·cm−1, pH 8.0) over ten minutes with a Biotek Eon 2

Molecules 2015, 20
6649
Microplate reader (Biotek, Winooski, VT, USA) at 37 °C. Twenty microliters of sample were mixed
with 175 μL of 100 mM sodium phosphate buffer (pH 6.0) and 5 μL of 50 mM p-nitrophenyl
butanoate in ethanol. The increase of absorbance was monitored at 37 °C at 410 nm for 20 min. One
unit of enzyme activity was defined as the release of 1 μmol nitrophenol per minute under the specified
conditions [21].
3.6.3. Lipase Activity
This assay was performed by measuring the increase in absorbance at 410 nm produced by
p-nitrophenol released from 0.4 mM p-nitrophenyl butanoate in sodium phosphate buffer (50 mM,
pH 7.0) at 37 °C. To start the reaction, the lipase solution or suspension (20 µL) was added to the
substrate solution (175 µL buffer, 5 µL p-nitrophenyl butanoate). One international unit of activity was
defined as the amount of enzyme that hydrolyzed one µmol of p-nitrophenol butanoate per minute
under the conditions [22]. All enzyme assays were performed in duplicate, and the standard deviation
was found below 5%.
3.7. Curcumin Transformation
3.7.1. Chemical Acetylation of Curcumin
Acetylated curcumins were synthesized chemically as reference compounds using acetic anhydride.
One mmol of curcumin was dissolved in 150 mL ethyl acetate and mixed for 20 min. After dissolving
was completed, four mmol acetic anhydride were carefully added. After six hours, the reaction was
stopped by adding one drop H2O2. Reaction yield (consumption of curcumin) and product
identification were carried out by LC-MS.
3.7.2. Lipase-Catalyzed Acetylation of Curcumin
Before each experiment, ethyl acetate and toluene as the solvent and the acyl donor (vinyl or
geranyl acetate) were stored over Na2SO4. The reaction was carried out in 2 mL ethyl acetate and
toluene (10:90) in sealed 30-mL glass vials at 40 °C with continuous stirring using a glass magnetic stir bar
(150 rpm). The powdered CAL was added to a final concentration of five mg·mL−1. Sodium acetate
buffer 50 mM, pH 6, was added at 4% to the reaction solution. Over the incubation, time samples were
taken, filtered using 0.45-µm filter (Chromafil PET-45/25, Macherey-Nagel) and then analyzed
directly by LC-MS.
3.7.3. Monoacetyl Curcumin Degradation
The two-phase reaction system was made up of 2.0 mL of 0.5 mM monoacetyl curcumin
(concentration calculated according to a curcumin standard) together with a minor impurity of diacetyl
curcumin (concentration not affected by the laccase present) in 2.0 mL diethyl ether and 2.0 mL
respective enzyme solution (1.19 U·mL−1, ABTS-assay, 30 °C, pH 3) in 50 mM sodium phosphate
buffer, pH 5.5, under continuous vortexing at 1300 rpm (Heidolph, Germany) for 20 h at room
temperature. A control sample with the buffer, but without enzyme, was treated under the same

Molecules 2015, 20
6650
conditions. After separation of the diethyl ether phase, the aqueous buffer was re-extracted three times
with 2.0 mL diethyl ether, and the combined organic phases were dried over night with Na2SO4. The
degradation rate of acetyl curcumin was determined by LC-MS, and volatile degradation products,
such as vanillin acetate, were analyzed by GC-MS.
3.7.4. Esterase-Catalyzed Deacetylation of Vanillin Acetate
Three esterases were used for the hydrolysis of vanillin acetate. The hydrolysis was carried out in a
glass vial containing 2 mL of 1 mM vanillin acetate dissolved in diethyl ether/hexane and 2 mL sodium
phosphate buffer 50 mM, pH 5 and 6.5. The reactions were initiated by adding enzyme solution with
an activity of one U·mL−1 to the reaction mixture and placed in a vortex shaker at 37 °C for five hours.
The samples were extracted three times with diethyl ether, and the combined fractions were dried over
sodium sulfate and analyzed by GC-MS using the external standard, 3,4-dimethoxybenzaldehyde (final
concentration 125 mg·L−1). The reproducibility of three repeated transformations showed a relative
standard deviation of typically 3%.
3.8. Gas Chromatography
3.8.1. Gas Chromatography/Flame Ionization Detection
For each sample, 1 μL was injected on-column in an Agilent 7890A gas chromatograph (Agilent,
Waldbronn, Germany) equipped with a cool on-column injection port and a 30 m × 0.32 mm i. d. ×
0.25 μm CP-Wax 52 CB column (Varian, Darmstadt, Germany). The oven temperature program was
40 ° C for 3 min, raised at 3 °C per minute to 230 °C and held for 10 min. Hydrogen was used as the
carrier gas at a flow rate of 2 mL per minute. Quantification was carried out according to the external
standard (3,4-dimethoxybenzaldehyde).
3.8.2. Gas Chromatography/Mass Spectrometry
Gas chromatography-mass spectrometry (GC-MS) was conducted using a GC 8000 coupled to an
MD 800 mass-selective detector (Fisons, Mainz-Kastel, Germany) equipped with a cool-on-column
injection port and a 30 m × 0.32 mm i.d. × 0.25 μm CP-Wax 52 CB column (Varian). The samples were
injected using the same oven program as for GC/FID, but helium at a flow rate of 1.2 mL per minute
was the carrier gas. Mass spectra were acquired using electron impact ionization at 70 eV and a 200 °C
source temperature. Reaction products were identified by comparing their RIs (Resonance-ionization)
and mass spectra with those of authentic standards.
3.9. Liquid Chromatography/Mass Spectrometry
For the identification of vanillin, curcumin and acetylated curcumins, as well as for the determination
of the molar mass of the expected oxidation/polymerization products thereof, high performance liquid
chromatography coupled to a triple quadrupole mass analyzer was used (Varian 212 LC pump, Pro
Star 325 UV-Vis detector, 320 TQ-MS mass spectrometer). The MS was conducted simultaneously in
the ESI positive and negative mode with a scan range of m/z 110–500 or m/z 300–1200, respectively.

Molecules 2015, 20
6651
The MS parameters for ESI(+)/ESI(−) were: capillary voltage +30 V/−40 V, needle voltage
5000 V/−4500 V, nebulizer gas (N2) 379 kPa, drying gas 207 kPa at 350 °C. For HPLC, water and
acetonitrile (MS-grade), both containing 0.1% formic acid, were used as the mobile phase, and the
following linear gradient was used: 10% acetonitrile for three minutes, up to 90% acetonitrile within
20 min, hold for five minutes and back to start conditions. The separation was performed on an RP-18
HD column (Eurosphere 100-C18-5-HD, 250 × 4 mm, 5 µm, Macherey-Nagel) at a flow rate of
0.3 mL per minute. Additionally, UV absorption was monitored at 280 and 425 nm.
4. Conclusions
During the coming years, the flavor market is expected to increase, and biotechnology will contribute
to guaranteeing the supply [1,23]. This work showed that laccases are suitable for the oxidative
cleavage of acetyl curcumin in a cofactor- and mediator-independent reaction. A three-enzyme system
provided protection/deprotection chemistry, with the selective acetylation of one of the two phenolic
hydroxyl groups of curcumin as the key step. As a result, one phenol moiety of the symmetric
molecule was protected against attack of the laccase, while the other vanillin moiety was inevitably
lost to oligomerization.
Laccase-catalyzed reactions are governed by the structure of the phenolic substrate, the redox potential
of the enzyme (high, middle or low), the presence and choice of a mediator and the usual parameters,
such as reaction pH, temperature and solvent composition [24]. A refined system, including a food-grade
mediator, might convert both acetyl vanillin moieties of an enzymatically-synthesized diacetyl curcumin
into ‘natural’ vanillin. To this end, the first enzymatic step must be made more efficient by using a
lipase able to accept both curcumin and monoacetyl curcumin as substrates. Some representatives out
of the large set of lignolytic enzymes of higher fungi might be even more suitable for the acetylation,
cleavage and hydrolysis of phenolic substrate molecules to yield ‘natural’ flavor compounds.
Acknowledgments
The authors thank Gunnar Schmidt, Annabel Nieter and Julia Kolwek for providing enzyme isolates
and valuable advice.
Author Contributions
Vida Esparan conducted most of the laboratory work, evaluated the data and wrote major sections
of the paper. Ulrich Krings operated the mass spectrometers and interpreted the data. Marlene Struch
contributed a purified and characterized laccase from Funalia trogii. Ralf G. Berger supervised the
work and edited the manuscript. All authors have read and approved the manuscript.
Conflicts of Interest
The authors declare no conflicts of interest.

Molecules 2015, 20
6652
References
1. Berger, R.G. Biotechnology as a source of natural volatile flavours. Curr. Opin. Food Sci. 2015,
1, 38–43.
2. Mayer, A.M.; Staples, R.C. Laccase new functions for an old enzyme. Phytochemistry 2002, 60,
551–556.
3. Copeland, R.A. Enzymes: A Practical Introduction to Structure, Mechanism, and Data Analysis;
Wiley-VCH: New York, NY, USA, 2000; pp. 1–11.
4. Negishi, O.; Sugiura, K.; Negishi, Y. Biosynthesis of vanillin via ferulic acid in Vanilla planifolia.
J. Agric. Food Chem. 2009, 57, 9956–9961.
5. Sindhwani, G.; Uk, I.; Aeri, V. Microbial transformation of eugenol to vanillin. J. Microbiol.
Biotechnol. Res. 2012, 2, 313–318.
6. Walton, N.J.; Narbad, A.; Faulds, C.B.; Williamson, G. Novel approach to the biosynthesis of
vanillin. Curr. Opin. Biotechnol. 2000, 11, 490–496.
7. Korthou, H.; Verpoorte, R. Vanilla. Flavours and Fragrances; Berger, R.G., Ed.; Springer:
Berlin/Heidelberg, Germany, 2007; pp. 203–217.
8. Kumar Singh, P.; Wani, K.; Kaul-Ghanekar, R.; Prabhune, A.; Ogale, S. From micron to
nano-curcumin by sophorolipid co-processing highly enhanced bioavailability, fluorescence and
anti-cancer efficacy. RSC Adv. 2014, 4, 60334–60341.
9. Bharti, A.; Nagpour, A.L.; Gupta, R.K. Biotransformation of curcumin to vanillin. Indian J. Chem.
2011, 50B, 1119–1122.
10. Priefert, H.; Rabenhorst, J.; Steinbuechel, A. Biotechnological production of vanillin.
Appl. Microbiol. Biotechnol. 2001, 56, 296–314.
11. Gordon, O.N.; Schneider, C. Vanillin and ferulic acid: Not the major degradation products of
curcumin. Trends Mol. Med. 2012, 18, 361–363.
12. Diaz-Godinez, G.; Tellez-Tellez, M.; Diaz, R.; Sanchez, C. Applications of Microbial Genes in
Enzyme Technology, 1st ed.; Gupta, V.K., Touhy, M.G., Eds.; Nova Science Publishers Inc:
New York, NY, USA, 2013; pp. 19–47.
13. Kruegener, S.; Schaper, C.; Krings, U.; Berger, R.G. Pleurotus species convert monoterpenes to
furanoterpenoids through 1,4-endoperoxides. Bioresour. Technol. 2009, 100, 2855–2860.
14. Strong, P.P.; Claus, H. Laccase a review of its past and its future in bioremediation. Crit. Rev.
Env. Sci. Technol. 2011, 41, 373–434.
15. Gunne, M.; Hoeppner, A.; Hagedoorn, P.L.; Urlacher, V.B. Structural and redox properties of the
small laccase Ssl1 from Streptomyces sviceus. FEBS J. 2014, 281, 4307–4318.
16. Uzan, E.; Nousiainen, P.; Balland, V.; Sipila, J.; Piumi, F.; Navarro, D.; Asther, M.; Record, E.;
Lomascolo, A. High redox potential laccases from the ligninolytic fungi Pycnoporus coccineus
and Pycnoporus sanguineus suitable for white biotechnology from gene coning to enzyme
characterization and application. J. Appl. Microbiol. 2010, 108, 2199–2213.
17. Rodgers, C.J.; Blanford, C.F.; Giddens, S.R.; Skamnioti, P.; Armstrong, F.A.; Gurr, S.J. Designer
laccases: A vogue for high-potentail fungal enzyme. Trends Biotechnol. 2009, 28, 63–72.
18. Schmidt, G.; Krings, U.; Nimtz, M.A.; Berger, R.G. A surfactant tolerant laccase of Meripilus
giganteus. World J. Microbiol. Biotechnol. 2012, 28, 1623–1632.

Molecules 2015, 20
6653
19. Plagemann, I.; Krings, U.; Berger, R.G. Isolation and characterization of wild-type lipoxygenase
LOXPsa1 from Pleurotus sapidus. Z. Naturforschung 2014, 69c, 149–154.
20. Linke, D.; Matthes, R.; Nimtz, M.; Zorn, H.; Bunzel, M.; Berger, R.G. An esterase from the
basidiomycetes Pleurotus sapidus hydrolyzes feruloylated saccharides. Appl. Microbiol. Biotechnol.
2013, 97, 7241–7251.
21. Haase-Aschoff, P.; Linke, D.; Berger, R.G. Detection of feruloyl- and cinnamoyl esterases from
basidiomycetes in the presence of interfering laccase. Bioresour. Technol. 2013, 130, 231–238.
22. Escorcia, A.M.; Molina, D.; Daza, M.C.; Doerr, M. Acetylation of (R,S)-propranolol catalyzed by
Candida antarctica lipase B, An experimental and computational study. J. Mol. Catal. B Enzym.
2013, 98, 21–29.
23. Wells, A.; Meyer, H.P. Biocatalysis as a Strategic Green Technology for the Chemical Industry.
ChemCatChem 2014, 6, 918–920.
24. Kunamneni, A.; Polu, F.J.; Ballesteros, A.; Alcalde, M. Uses of laccases in food industry.
Pat. Biotechnol. 2008, 2, 10–24.
Sample Availability: Acetylated curcumin, vanillin acetate and vanillin are available.
© 2015 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/4.0/).
