Effect of different amino acids and heating conditions on the formation of 2-Amino-1-methyl-6-phenylimidazo[4,5-b]pyridine (PhIP) and its kinetics formation using chemical model system

Article abstract of DOI:10.3390/molecules24213828

The formation of 2-amino-1-methyl-6-phenylimidazo[4,5-b]pyridine (PhIP) was investigated using a kinetic study approach as described by first-order, Arrhenius, and Eyring equations. Chemical model systems with different amino acid precursors (proline, phenylalanine, and glycine) were examined at different times (4, 8, 12, and 16 min) and temperatures (150, 180, 210, 240, and 270 °C). PhIP was detected using high-performance liquid chromatography equipped with fluorescence detector (HPLC-FLD). The good fit in first-order suggested that PhIP formation was influenced by the types of amino acids and PhIP concentration significantly increased with time and temperature (up to 240 °C). PhIP was detected in proline and phenylalanine model systems but not in the glycine model system. The phenylalanine model system demonstrated low activation energy (Ea) of 95.36 kJ/mol that resulted in a high rate of PhIP formation (great amount of PhIP formed). Based on the DSz values both proline and phenylalanine demonstrated bimolecular rate-limiting steps for PhIP formation. Altogether these kinetic results could provide valuable information in predicting the PhIP formation pathway.

Full text of DOI:10.3390/molecules24213828

molecules
Article
Effect of Different Amino Acids and Heating
Conditions on the Formation of
2-Amino-1-methyl-6-phenylimidazo[4,5-b]pyridine
(PhIP) and Its Kinetics Formation Using Chemical
Model System
Ainaatul Asmaa Ishak 1, Jinap Selamat 1,2,
* ,
, Rabiha Sulaiman 3, Rashidah Sukor 1,2
Emilia Abdulmalek 4 and Nuzul Noorahya Jambari 1,2
1
Department of Food Science, Faculty of Food Science and Technology, Universiti Putra Malaysia, Serdang
43400, Selangor, Malaysia; aina17ain@gmail.com (A.A.I.); syidahsukor@gmail.com (R.S.);
noorahya@upm.edu.my (N.N.J.)
2
3
4
Laboratory of Food Safety and Food Integrity, Institute of Tropical Agriculture and Food Security, University
Putra Malaysia, Serdang 43400, Selangor, Malaysia
Department of Food Technology, Faculty of Food Science and Technology, Universiti Putra Malaysia,
Serdang 43400, Selangor, Malaysia; rabiha@upm.edu.my
Department of Chemistry, Faculty of Science, Universiti Putra Malaysia, Serdang 43400, Selangor, Malaysia;
emilia@upm.edu.my
*
Correspondence: sjinap@gmail.com or jinap@upm.edu.my
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 16 July 2019; Accepted: 27 September 2019; Published: 24 October 2019
Abstract: The formation of 2-amino-1-methyl-6-phenylimidazo[4,5-b]pyridine (PhIP) was investigated
using a kinetic study approach as described by first-order, Arrhenius, and Eyring equations. Chemical
model systems with different amino acid precursors (proline, phenylalanine, and glycine) were
examined at different times (4, 8, 12, and 16 min) and temperatures (150, 180, 210, 240, and 270
◦C). PhIP was detected using high-performance liquid chromatography equipped with fluorescence
detector (HPLC-FLD). The good fit in first-order suggested that PhIP formation was influenced by
the types of amino acids and PhIP concentration significantly increased with time and temperature
(up to 240 ◦C). PhIP was detected in proline and phenylalanine model systems but not in the glycine
model system. The phenylalanine model system demonstrated low activation energy (Ea) of 95.36
kJ/mol that resulted in a high rate of PhIP formation (great amount of PhIP formed). Based on the
∆
S‡ values both proline and phenylalanine demonstrated bimolecular rate-limiting steps for PhIP
formation. Altogether these kinetic results could provide valuable information in predicting the PhIP
formation pathway.
Keywords: kinetic study; chemical model system; amino acids and 2-amino-1-methyl-6-
phenylimidazo[4,5-b]pyridine (PhIP)
1. Introduction
Heterocyclic amines (HCAs) are known as food mutagens/carcinogens that are formed when
heat is introduced to muscle food such as meat, poultry, and fish during food preparation [
HCAs are formed in cooked food when the cooking temperature reaches greater than 150 ◦C [
HCAs can be divided into two classes based on their formation and chemical conformation,
namely the aminoimidazo-azaarenes (IQ-types) and the amino-carboline (non-IQ-types) [ ].
1–3]. The
2,4].
4,5
Molecules 2019, 24, 3828; doi:10.3390/molecules24213828
www.mdpi.com/journal/molecules

Molecules 2019, 24, 3828
2 of 12
The aminoimidazo-azaarenes, commonly known as AIA-type, are the major subclass of HCAs
found in human diet [6]. The AIA-type HCAs include:
i.
2-amino-3-methylimidazo[4,5-f]quinoline (IQ)
ii.
iii.
iv.
v.
2-amino-3,4-dimethyl-3H-imidazo[4,5-f]quinolone (MeIQ)
2-amino-3,8-dimethylimidazo[4,5-f]quinoxaline (MeIQx)
2-amino-3,7,8-trimethyl-3H-imidazo[4,5-f]quinoxaline (DiMeIQx)
2-amino-1-methyl-6-phenylimidazo[4,5-b]pyridine (PhIP)
All AIA-type HCAs have an imidazole ring in their structures that originates from
creatine/creatinine. The imidazole ring, however, is not found in amino-carboline as its formation
involves pyrolysis of amino acids at temperature above 300 ◦C [
]. PhIP, in particular, is abundant
among the AIA compounds in cooked food [ ]. According to the International Agency for Research on
Cancer (IARC), PhIP is classified as probable carcinogen and may cause human cancer (Class 2B) [
with its LD50 estimated to be 3 mg/kg [ ]. Epidemiological studies have demonstrated that high daily
intake of PhIP can cause colon, prostate, and breast cancers [10 12]. Evidence has shown that the
ability of PhIP forming DNA-adduct by altering the DNA sequence in human body is the main cause of
cancer [ 13]. Alarmingly, the estimated average daily intake of PhIP among the Malaysian population
is relatively high at 121.4 ng/g per capita day−1
], which is comparable to the mean daily intake of
PhIP in the USA that varies from 78.2 to 1029 ng/g per capita day−1, with the highest source of PhIP
intake from meat [ ]. Other countries such as Japan (5–300 ng/g), Sweden (72 ng/g), and Spain (344
ng/g) also exhibited a high daily intake of PhIP per capita day−1
]. These findings further indicate
5
7
8]
9
–
6,
[1
1
[1
the high exposure of PhIP in human diet regardless of country of origin.
Several external factors have been shown to contribute towards the formation of PhIP in food.
For example, meat types affect the amount of PhIP formed, as evidently demonstrated by a previous
study where a total of 5.27, 9.20, and 6.06 ng/g of PhIP was detected in fried beef, pork, and chicken
samples, respectively [14]. Moreover, levels of PhIP detected increased with doneness of chicken
and beef satays up to 7.7 and 11.30 ng/g, respectively. The use of different type of sugars during
marinating demonstrated different PhIP levels up to 6.26–7.44 ng/g using table sugar, 6.08–7.74 ng/g
using brown sugar, and 9.52–10.22 ng/g using honey for grilled marinated chicken [
3]. Food cooked
using a pan-frying method formed a higher PhIP level than roasting [15]. Moreover, Iwasaki et al. [16
]
reported high PhIP content of 47.3 and 31.8 ng/g, respectively in both chicken and beef grilled directly
over an open flame.
Other than meat types, the marinating process, and cooking conditions, the formation of PhIP in
cooked food can also be induced by the naturally occurring precursors in the food itself such as amino
acids, reducing sugars, and creatine/creatinine [17]. Chemical model and food model systems have
been widely used to study the chemical and physical conditions involved in the formation of PhIP. The
chemical model system that consists mainly of the major precursors such as reducing sugars, creatinine,
and amino acids has been used to study the precursor effects on PhIP formation. A study done by Skog
et al. reported that phenylalanine was the main amino acid responsible for PhIP formation [18] and
PhIP has also been successfully extracted from mixture of heated creatinine, glucose and phenylalanine
refluxed for 2 h at 128 ◦C in diethylene glycol with 14% water (DEG) [19]. A dry heated model system
comprised of phenylalanine and leucine pyrolysis for 1 h at 200 ◦C was proposed by Övervick et al. [20
]
to study PhIP formation. Besides that, other amino acids also have been demonstrated to involve
in PhIP formation [20]. Johanson et al. [21] successfully isolated PhIP from a tyrosine and leucine
model system.
In addition to the model system, kinetic study was used to examine the rate of reactions and
variables effect on HCA formation. Nonetheless, most of the model systems were based on a meat
and food model system. A meat juice and meat model system were used by Arvidsson et al. [22] and
Ahn and Grün [23], respectively, to study the kinetic formation of HCAs including PhIP. Hwang and
Ngadi [24] used meat emulsion with different fat contents to investigate the kinetic formation of HCAs

Molecules 2019, 24, 3828
3 of 12
compounds. However, there have been limited data on the use of a chemical model system in studying
the kinetic effect on PhIP or HCA formation. Moon and Shin [25] reported the kinetic formation of PhIP
using a chemical model system of phenylalanine heated at 125–200 ◦C. Moreover, Arvidsson et al. [26
]
demonstrated PhIP and other HCAs formation using a mixture of amino acids model system. Each
of the single precursors (amino acids, sugar, and creatinine) influences the rate formation of PhIP
in the meat systems. The chemical model system can be a useful technique to study the effects of
single precursor (amino acids, sugars, and creatinine) as no other food matrices are involved and
could interfere with the reaction. By adding the kinetic study in the chemical model system, the rate
formation of PhIP from an individual precursor can be determined and studied in more detail.
Therefore, the objective of this paper was to study the kinetic formation of PhIP by using single
amino acids with different chemical structures as the precursors heated at various temperatures
◦
(150–270 C). In this study, phenylalanine, proline, and glycine were selected as the amino acid
precursors mainly due to their linear, cyclic, and aromatic molecular structures. The data on the kinetic
parameter and model system could provide insights towards the role of phenylalanine, proline, and
glycine with different constituents on PhIP formation.
2. Results and Discussion
2.1. PhIP Identification and Quality Parameter
Figure 1 compares the HPLC-FLD chromatograms of standards and the three model systems at
240 ◦C for 4 min. A PhIP peak was detected in proline and phenylalanine model systems at 28.24–28.52
min but no PhIP peak was detected in the glycine model system. To examine the quality of the
method performance, the Limit of Detection (LOD) and Limit of Quantification (LOQ) of PhIP that
were calculated based from the standard deviation (SD) of response and slope were determined to be
0.0002 and 0.002 ng/mL, respectively. A linear calibration curve for PhIP was constructed based on the
peak area. The correlation coefficient (R2) for the calibration graph was 0.9921, indicating a strong
relationship between peak area ratio and the concentration of PhIP.
(a)
PhIP standard
(b)
PhIP
(c)
PhIP
(d)
Figure 1. Typical high performance liquid chromatography ◦(HPLC-FLD) chromatograms of
2-amino-1-methyl-6-phenylimidazo[4,5-b]pyridine (PhIP) at 210 C for 16 min: (a) PhIP standard;
(
b) PhIP in the proline model system; (c) PhIP in the phenylalanine model system; (d) PhIP in the
glycine model system.

Molecules 2019, 24, 3828
4 of 12
2.2. Effects of Time and Temperature
The heating process of the mixture containing creatinine, glucose, and single amino acids
successfully formed PhIP in proline and phenylalanine model systems only (Figure 2) but not in the
glycine model system. These results were consistent with a previous study [25] where PhIP was
not formed in a model system containing a mixture of creatinine, glucose, and glycine. Proline and
phenylalanine model systems demonstrated a significant (p < 0.05) interaction between temperature
and time changes on PhIP formation.
0.5
0.4
0.3
0.2
0.1
0
A,a
(a)
A,a
A,b
A,b
B,d
B,b
B,c
B,a
C,d
C,a
C,b
C,b
D,c
150
180
210
Heating temperature (°C)
240
270
4
8
12
16
A,a
22
(b)
A,b
A,b
20
18
16
14
12
10
8
A,c
B,a
B,a
B,b
B,b
C,c
C,c
C,c
C,d
6
4
D,a
D,b
2
D,c
D,d
E,a
E,b
E,c
D,d
0
150
180
210
240
270
Heating temperature (°C)
8
4
12
16
Figure 2. Effects of time and temperature on PhIP formation in (a) proline model system and
(b
) phenylalanine model system. A–E: mean between samples for each temperature that share the same
letter are not significantly different (p > 0.05). a–d: mean between samples for each heating time that
share the same letter are not significantly different (p > 0.05).
At 150 ◦C, no formed PhIP was detected in the proline model system at any range of time. As the
temperature increased to 180 ◦C, 0.04
µ
g/mL of PhIP was detected after 8 min of heating. The amount
was significantly (p < 0.05) increased with increased time and temperature. At 210 ◦C, 0.23–0.43
g/mL
of PhIP was detected as the mixture was heated for 4–16 min. The highest amount of PhIP formed
was 0.47
g/mL at 240 ◦C after 4 min of heating. Nevertheless, as the heating continued to 8 min, the
µ
µ
amount of PhIP reduced with increased time and temperature. There was 11% reduction observed
between 4 to 8 min of heating at 240 ◦C. At 240 ◦C, no significant difference (p > 0.05) on the PhIP
amounts detected at 8, 12, and 16 min. These findings were in agreement with a previous study by

Molecules 2019, 24, 3828
5 of 12
Chiu and Chen [27] where they revealed that PhIP had the lowest thermal stability among 15 HCAs
compounds. Therefore, we concurred that the reduced concentration of PhIP observed in this study
was due to PhIP degradation.
PhIP demonstrated faster formation in the phenylalanine model system than the proline model
system where 0.15
significantly (p < 0.05) increased with increased time and temperature until 240 ◦C (8 min), which
recorded 21.41 g/mL as the highest amount. After 12 min of heating, 9% degradation of PhIP was
observed, which reduced the amount of PhIP formed to 19.50 g/mL. The PhIP amount continually
µ
g/mL of PhIP started forming after 4 min of heating at 150 ◦C. The amount was
µ
µ
reduced with increase in time and temperature. PhIP was not detected in control model systems
where there was no heat applied. This indicates the requirement of heat to initiate the reaction for
PhIP formation. Overall, temperature had a significant effect compared to time for PhIP formation
throughout the system.
2.3. Effects of Amino Acid Precursors
Table 1 demonstrates the comparison between PhIP formation in proline and phenylalanine model
systems detected at 12 min at all temperature. The results revealed the used of different amino acid
precursors gave significant effects on PhIP formation. The amount of PhIP formed was significantly
different between the proline and phenylalanine model systems. PhIP was significantly (p < 0.05)
formed in the phenylalanine model system, which indicates phenylalanine as the major precursor
for PhIP.
Table 1. PhIP formations in proline and phenylalanine model systems after 12 min of heating at 150,
180, 210, 240, and 270 ◦C.
Model System
Temperature, ◦C
Phenylalanine, µg/mL
Proline, µg/mL
150
180
210
240
270
0.28 ± 0.0004
1.57 ± 0.04 a
12.08 ± 0.19 a
19.50 ± 0.5 a
7.47 ± 0.43
ND
0.10 ± 0.0005 b
0.36 ± 0.001 b
0.41 ± 0.01 b
ND
a,b
Mean samples that share the same letter were significantly different (p < 0.05) between model systems. Mean
standard deviation.
±
All three amino acids have a unique chemical structure that might influence the formation of
PhIP. The pathway formations for PhIP from different amino acids are shown in Figure 3. PhIP
formed through the Maillard reaction involves three stages of reactions, namely the early stage (i),
the intermediate stage (ii), and the final stage (iii) [28,29]. The early stage (i) was the sugar-amino
condensation between the reducing sugar and the amino acids resulting in Amadori rearrangement
products. In the intermediate stage (ii), the Amadori products undergo sugar breakdown and amino
acids breakdown via Strecker degradation. The Strecker degradation steps involve the decarboxylation
of amino acids in the presence of
compounds, nitrogen containing compounds, small carbon fragments, and pyrazines [28
α
-dicarbonyl, thus transforming the compounds into related aldehyde
29]. In the
,
final stage (iii) of the Maillard reaction, the intermediate from Strecker degradation undergoes an array
of reactions including aldol condensation, dehydration, and cyclisation forming PhIP and other HCAs
compounds [28].

Molecules 2019, 24, 3828
6 of 12
CH3
N
(a)
CH2OH
O
NH2
heat
+
NH2
+
OH
OH
OH
N
i-Sugar-amino
condensation
ii- Strecker
O
OH
OH
O
Creatinine
O
Phenylacetaldehyde
Phenylalanine
Glucose
degradation
iii- Aldol codensation
CH3
CH3
N
N
NH2
NH2
iii- Condensation
OH
N
PhIP
N
N
O
CH3
N
NH2
(b)
O
N
CH2OH
H
O
O
CH3
N
Heat
O
N
O
Creatinine
OH
N
+
i-Sugar-amino
condensation
ii- Strecker degradation
iii- Aldol condensation/cyclisation
OH
OH
OH
OH
OH
NH2
OH
OH
OH
N
Proline
1-[(2-carboxyl)pyrrolidinyl]-1-deoxy-D-fructose
(Amadori compound)
N
Glucose
PhIP
(c)
HO
OH
CH2OH
O
O
NH
O
heat
+
H2N
i-Sugar-amino
condensation
OH
OH
ii- Strecker degradation
iii- Aldol condensation/cyclisation
OHHO
O
OH
OH
OH
OH
Glucose
fructosylglycine
(Amadori compound)
Glycine
HO
N
O
PhIP
O
N
OH
1,4-di(carboxymethyl)pyrazine
Figure 3. Formation of PhIP: (
) PhIP formation in the proline model system (modified) [32] and (
model system (modified) [33 34]. (i) Initial stage of the Maillard reaction, (ii) intermediate stage of the
a
) PhIP formation in the phenylalanine model system (modified) [30
,31],
(
b
c) PhIP formation in the glycine
,
Maillard reaction, and (iii) final stage of the Maillard reaction.
Based on Figure 3, the aromatic structure of phenylalanine (C6H5CH2CH(NH2)COOH)
that is formed by the benzyl side chain provides a pathway for forming phenylacetaldehyde
(C6H5CH2C(O)H), an intermediate product that is required for PhIP formation [30]. The formation
of phenylacetaldehyde occurred in the intermediate stage (ii) of the Maillard reaction via Strecker
degradation. Throughout the Strecker degradation, phenylalanine undergoes decarboxylation and
transforms into a structurally related aldehyde, which is phenylacetaldehyde [
creatinine, phenylacetaldehyde undergoes an aldol reaction (iii) and forms an intermediate product.
The subsequent condensation of the intermediate product leads to the formation of PhIP [ 30]. Other
7,29]. In the presence of
7
,
amino acids that share a similar molecular structure of R-CH(NH2)COOH with phenylalanine such
as leucine (2(CH3)CHCH2CH(NH2)COOH), isoleucine (CH3CH2CH(CH3)CH(NH2)COOH), and
tyrosine (OH(C6H4)CH2CH(NH2)COOH) were also shown previously to be able to form PhIP [25].
This may explain why PhIP was not formed in the glycine model system due to the short linear
structure of glycine (NH2CH2COOH) [25]. Although there was no sign of PhIP formation, glycine was
suspected to be the precursor for other HCAs compounds. Based on Figure 3, Kato et al. [33] identified
1,4-di(carboxymethyl)pyrazine cation radical from heating glycine with glucose. The compound was
an important intermediate for formation of imidazoquinoxaline type-HCAs [33]. Formation of PhIP in
the proline model system was in contrast with previous studies [21,35]. Nevertheless, previous studies

Molecules 2019, 24, 3828
7 of 12
have used different conditions for their model systems e.g., heating in water for 10 min at 180 ◦C, reflux
in diethylene glycol at 128 ◦C for 2 h, and dry heating at 180 ◦C for 2 h. In this study, we showed that
the cyclic structure of proline (NH(CH2)3CHCOOH) was able to form PhIP at higher temperature
◦
of 210 and 240 C. Britt et al. [32] identified 1-[(2-carboxyl)pyrrolidinyl]-1-deoxy-d-fructose as the
Amadori product from heating proline with glucose. Further cyclization or aldol condensation from
the Amadori product causes PhIP formation.
Amino acids and reducing sugar are also the precursors for other HCAs and polycyclic aromatic
hydrocarbons (PAHs). Besides PhIP, other compounds were also formed in proline and glycine model
systems. This was the reason for the low amount of PhIP formed in the proline model system and no
PhIP formation in the glycine model system.
2.4. Kinetic Formation of PhIP
Table 2 demonstrates the calculated constant for unknown intermediate (A), reaction rate constant
(k), lag time (to) and correlation coefficient (R2) using Equations (1) and (2). Based on the R2 values
the good fit suggests the rate-limiting steps for the formation and degradation of PhIP in proline and
phenylalanine model systems follows the first order model. As such, this result indicates that the
reaction involving PhIP formation is influenced by the reactant molar concentration in which one of the
reactants should be in excess [22]. Evidence has shown that many intermediates including imidazole
and pyrazines were involved in HCA formation [7,17]. Therefore, many reaction steps are involved in
the rate-limiting steps for the intermediates formation [22]. Both proline and phenylalanine model
systems had to of 4.0951 min (180 ◦C) and 0.6403 min (150 ◦C), respectively. The to value continued to
decrease rapidly to 0.00 min and 0.0334 min as the reaction temperature increased to 210 ◦C in proline
and phenylalanine model systems. Ahn and Grün [23] also reported a decrease in PhIP concentration
using a meat (beef) model system to study the kinetic formation of HCAs. The decrease of to value
with increasing temperatures in proline and phenylalanine model systems indicates rapid reactions for
PhIP formation at higher reaction temperature [24].
Table 2. The value of unknown intermediate (A), rate constant of formation (k), lag time (to), and
correlation coefficient (R2) from first-order model.
Temperature
(◦C)
A
to
(min)
k
Model System
R2
(min−1
)
(ng/µL)
150
nd
nd
nd
nd
180 *
210 *
240 **
270 **
0.5098
0.4371
0.0268
1.1757
0.0122
0.2897
4.0951
0.00
0.99
0.99
0.99
0.99
Proline
-
-
-
-
150 *
180 *
210 *
240 **
270 **
10.4238
24.2223
21.4828
0.0024
0.0059
0.0710
0.0258
0.0738
0.6403
0.3715
0.0334
0.98
0.99
0.99
0.97
0.95
Phenylalanine
-
-
-
-
* Values are calculated based on first order of C = A(1
k = −ln (A/Ao)/t; nd = not detected, there was no sign of PhIP formation based on HPLC analysis.
−
e
−k(t − to)); ** Values are calculated based on first order of
The rate constants (k) of PhIP formation were increased with increased heating temperature from
180 ◦C (0.0268 min−1) to 210 ◦C (1.1757 min−1) for the proline model system and 150 ◦C (0.0024 min−1
to 210 ◦C (0.0710 min−1) for the phenylalanine model system. The increase of k values showed fast PhIP
formation in proline and phenylalanine model systems as mixtures were heated from 150 to 210 ◦C. At
210 ◦C, the proline model system showed rapid PhIP formation compared to the phenylalanine model
system by having a k value of 1.175 min−1. The rapid formation was supported by the to value of 0.00
min. This result was in agreement with Moon and Shin [25] findings which reported an increase of k
)

Molecules 2019, 24, 3828
8 of 12
values with increased heating temperature in the phenylalanine model system. Ahn and Grün [23
]
reported a similar finding where k values were increased with increased temperature in a meat model
system heated at a temperature ranging between 180 and 220 ◦C.
Degradation of PhIP was observed at high temperatures of 240 and 270 ◦C in both model systems.
The rate of degradation (k) was determined by using the first-order model of k = ln (A/Ao)/t [27]. The
−
degradation rate (k) increased from 0.0122 min−1 at 240 ◦C to 0.2897 min−1 at 270 ◦C in the proline
model system and from 0.0258 min−1 at 240 ◦C to 0.0738 min−1 at 270 ◦C in the phenylalanine model
system. Arvidsson et al.◦[22] discovered HCAs degradation using standard HCAs heated at 200 ◦C
for 100 min and at 225 C heated for 30 min. Chiu and Chen [27] reported PhIP degradation at
100, 150, and 200 ◦C by heating HCAs standard. The rate of degradation increased with increased
heating temperature.
The temperature dependence on PhIP formation in each model system was predicted using
Arrhenius, Equation (3) and Eyring equation, Equation (4). Table 3 demonstrates the calculated value
H‡), and activation entropy ( S‡) for each model
of activation energy (Ea), activation enthalpy (∆ ∆
system. Based on PhIP kinetic formation from Table 3, the proline model system had the highest
Ea (114.12 kJ/mol) compared to the phenylalanine model system (95.36 kJ/mol). The low Ea in the
phenylalanine model system indicates that the system requires a low energy level to initiate PhIP
formation. Furthermore, the reaction was a non-temperature sensitive reaction as the reaction can
proceed smoothly at low energy without increasing the temperature [25]. This was in contrast to the
proline model system, which required high energy to initiate PhIP formation. The reaction was a
temperature sensitive reaction where slight increase in temperature can influence the reaction as the
molecules in the system had sufficient energy to form any reaction [22].
Table 3. The calculated value of activation energy (Ea), activation enthalpy (
entropy (∆S‡) of PhIP formation and degradation from proline and phenylalanine model systems.
∆
H‡), and activation
∆H‡
(kJ/mol)
∆S‡
(J/mol/K)
Ea
(kJ/mol)
Model System
Proline
Phenylalanine
114.12
95.36
110.23
91.61
−35.25
−83.95
The change of energy from the reactant to the transition state was described by the Eyring equation,
Equation (4). The
H‡ obtained for each model system was nearly equal to the Ea. This finding was
in agreement with a previous study [23]. Proline and phenylalanine model systems reported
H‡ of
110.23 and 91.61 kJ/mol, respectively. Previous studies have reported
H‡ values for PhIP formation
ranged from 72.4 to 134.4 kJ/mol using meat juice, meat, and chemical model systems [22,23,25,26].
Previous studies reported that the assumption on the mechanism can be estimated via
S‡ such
as bimolecular ( 25 26]. Based on Table 2,
S‡ < 0) reaction or monomolecular ( S‡ > 0) reaction [23
both proline and phenylalanine model systems yielded negative 35.25 and 83.95 J/mol/K,
S‡ of
∆
∆
∆
∆
∆
∆
, ,
∆
−
−
respectively. The rate liming steps for the formation of PhIP through proline and phenylalanine as
precursor was a pseudo-first-order (bimolecular), which involved two reactants with one reactant in
an excessive amount [25]. The finding can be used to predict PhIP formation in foods as the result was
in agreement with a previous study where a bimolecular reaction was identified in a meat juice model
system (−213.08 J/mol/K) and phenylalanine model system (−145.49 J/mol/K) [23,25].
3. Materials and Methods
3.1. Chemicals
All solvents used in this study were of HPLC grade. Acetonitrile, methanol, phosphoric acid, and
trimethylamine (99.5%) were purchased from Merck (Darmstadt, Germany). Glycerol, D(+)-glucose,
L-proline (99%), glycine (99%), l-phenylalanine (99%), and creatinine were obtained from R&M (R&M

Molecules 2019, 24, 3828
9 of 12
Marketing, Essex, U.K). 2-amino-1-methyl-6-phenylimidazo[4,5-b]pyridine (PhIP) was obtained from
Toronto Research Chemicals (Toronto, Canada). A stock solution of 100 ppm PhIP standard was
prepared in methanol and kept at 4 ◦C.
3.2. Model Systems
The chemical model system as described by Skog and Jägerstad [36] was used with a number of
modifications. Glycerol with 14% water was used as the solvent to maintain the reaction temperature
◦
at various points (150, 180, 210, 240, and 270 C). The solvent was placed in a porcelain crucible
and heated on a hot plate. Water was allowed to evaporate until the designated temperature was
achieved. A thermocouple (Fluke, US) was used to monitor the temperature. A total of glucose (2
mmol), creatinine (4 mmol), and proline (4 mmol) were added into the crucible and mixture was heated
for 4, 8, 12, and 16 min. The heated mixture (100 uL) was diluted in methanol and filtered through
0.22 µm nylon filter (Chromafil, Germany). The same experiment was repeated using phenylalanine
and glycine precursors. The control sample was prepared by using the same set of aforementioned
chemical model system without any heat treatment. All experiments were performed in duplicates.
3.3. Instrument
High-performance liquid chromatography, HPLC-FLD (Waters, Milford, USA) was equipped with
fluorescence detector (Waters 2475, Milford, USA). The method was applied as described by a previous
study [37]. The reversed phase TSK-gel column ODS 80-TM (5
µ
m particle size, 4.6 mm id
×
250
mm) purchased from Tosoh Bioscience GmBH (Stuttgart, Germany) was used in this study. Detection
of PhIP was performed at flow rate of 1.0 mL/min with 0.01 M trimethylamine at pH 3.2 (adjusted
with phosphoric acid) as solvent A, 0.01 M trimethylamine at pH 3.6 (adjusted with phosphoric acid)
as solvent B and acetonitrile as solvent C. The gradient program used was: 0–10 min, 5–15% C in
A; 10–10.1 min, exchange A with B; 10.1–20 min, 15–25% C in B; 20–33 min, 25–55% C in B and at
33–55 min, column was rinsed with 55–5% C in A. PhIP peak was identified at ex307 and em370 using
ambient temperature.
3.4. Reaction Kinetics
The kinetic formation of PhIP was described using different reaction equations. The formation of
PhIP was described using the first-order reaction model [22,24]:
C = A(1 − e−k(t − to)),
(1)
where C is the concentration of PhIP (ng/mL), A is estimated maximum concentration of PhIP (ng/mL),
k is the rate constant for the formation of PhIP (min−1), t is the heating time (min), and to is the lag time
(min). Data were fitted into a non-linear regression model using Excel Solver to obtain the values of A,
k, and to. Degradation of PhIP at a specific temperature was determined using the following formula:
k = −ln(CA/CAo)/t,
(2)
where CA is the concentration of PhIP after heating, CAo is the initial concentration of PhIP and t is the
heating time (min). The effect of temperature on PhIP formation was analyzed using the Arrhenius
equation [23]:
k = Ae−Ea/RT
,
(3)
where k is the rate constant (min−1), A is pre-exponential factor, Ea is the activation energy (KJ/mol) for
the formation of PhIP, R is the gas constant (8.3145 J/(mol/K)) and T is the temperature (Kelvin). The

Molecules 2019, 24, 3828
10 of 12
rate-limiting steps for the formation of PhIP in the different amino acids model system was determined
by the activation entropy (∆S) using the Eyring equation [23]:
k = kbT/he∆S‡/R e−∆H‡/RT
,
(4)
where k is the rate constant (min−1), kb is the Boltzmann constant (1.381
×
10−23 J/K), h is the Plank
constant (6.626
×
10−34 Js), R is the gas constant (8.3145 J/(mol K)),
∆
S‡ is the activation entropy (J/mol
K),
∆
H‡ is the activation enthalpy (J/mol) and T is the temperature (K). Data were fitted into the Eyring
equation by non-linear regression. The formation of PhIP was described by the calculated kinetic
parameters including reaction rate constant, activation energy, entropy, and enthalpy.
3.5. Statistical Analysis
Minitab Version 16 (Minitab Inc. PA, USA) was used to analyze the data. A two-way analysis of
variance (ANOVA) with Tukey test was used to evaluate the mean differences among the treatments
applied for PhIP formation. The statistical significance was set at (p < 0.05) [38,39].
4. Conclusions
The formation of PhIP was significantly influenced by the reaction time, temperature, and
types of amino acids. The increase in time and temperature significantly increased the PhIP
◦
concentration. However, at higher temperatures of 240 and 270 C, PhIP formation was reduced
in proline and phenylalanine model systems due to degradation. The results revealed that meat
with high phenylalanine content had the highest tendency to form PhIP in high concentration. The
formation of PhIP followed the first-order reaction suggesting the formation was influenced by the
amino acids (reactant). Based on the kinetic parameters, the predicted pathway of PhIP formation was
a bimolecular reaction, which involved a reaction between amino acids and sugar through the Maillard
reaction. The results provide meaningful information on PhIP formation during heating. Several
precaution steps can be taken by consumers to control PhIP formation during meat preparation or
cooking which may help improve food quality and safety. Using a low temperature between 150 and
210 ◦C during cooking helps to reduce PhIP amount in cooked meat. Although PhIP amount reduces
at high temperature (240–270 ◦C) due to degradation, using high temperature was not recommended
as it may promote other HCAs and PAHs compounds. The kinetic result revealed PhIP formation
was a bimolecular reaction, indicating that amino acids and sugar are required for PhIP formation.
However, it is impossible to change the amino acids content in meat. Adding antioxidant ingredients
during meat marinating such as exchanging sugar with honey may help to control PhP amount by
neutralizing the intermediate and free radicals involved in PhIP formation.
AuthorContributions: Conceptualization and experimental design, J.S.; performed the experiment and HPLC-FLD
analysis, A.A.I.; statistical analysis, A.A.I., J.S., R.S. (Rashidah Sukor) and N.N.J.; kinetic identification and
description, R.S. (Rabiha Sulaiman), A.A.I. and E.A.; writing—original draft preparation, A.A.I.; writing—review
and editing, J.S., R.S. (Rabiha Sulaiman), E.A., R.S. (Rashidah Sukor) and N.N.J.; supervision, J.S.
Funding: This research was funded by Ministry of Higher Education, Malaysia for the Fundamental Research
Grant Scheme, FRGS [FRGS/2/2013/SG01/UPM/01/1] and Higher Institution Centre of Excellence research grant,
HICoE [ITAFoS/2017/.
Acknowledgments: The authors would like to acknowledge the contribution to the Faculty of Food Science
and Technology, Universiti Putra Malaysia (UPM) and Institute of Tropical Agriculture and Food Security for
the facilities.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Jahurul, M.H.A.; Jinap, S.; Ang, S.J.; Abdul-Hamid, A.; Hajeb, P.; Lioey, H.N.; Zaidul, I.S.M. Dietary exposure
to heterocyclic amines in high-temperature cooked meat and fish in Malaysia. Food Addit. Contam. Part A
2010, 27, 1060–1071. [CrossRef] [PubMed]

Molecules 2019, 24, 3828
11 of 12
2.
3.
4.
5.
Oz, F.; Kaban, G.; Kaya, M. Effects of cooking techniques and levels on the formation of heterocyclic aromatic
amines in chicken and fish. J. Anim. Vet. Adv. 2010, 9, 1259–1264. [CrossRef]
Hasnol, N.D.; Jinap, S.; Sanny, M. Effect of different types of sugars in a marinating formulation on the
formation of heterocyclic amines in grilled chicken. Food Chem. 2014, 145, 514–521. [CrossRef] [PubMed]
Murkovic, M. Formation of heterocyclic aromatic amines in model systems. J. Chromatogr. B 2004, 802, 3–10.
[CrossRef] [PubMed]
Jägerstad, M.; Skog, K.; Arvidsson, P.; Solyakov, A. Chemistry, formation and occurrence of genotoxic
heterocyclic amines identified in model systems and cooked foods. Zeitschrift für Lebensmitteluntersuchung
und-Forschung A 1998, 207, 419–427. [CrossRef]
6.
7.
8.
Schut, H.A.J.; Snyderwine, E.G. DNA adducts of heterocyclic amine food mutagens: Implications for
mutagenesis and carcinogenesis. Carcinogenesis 1999, 20, 353–368. [CrossRef] [PubMed]
Gibis, M. Heterocyclic aromatic amines in cooked meat products: Causes, formation, occurrence, and risk
assessment. Compr. Rev. Food Sci. Food Saf. 2016, 15, 269–302. [CrossRef]
IARC Some Naturally Occurring Substances: Food Items and Constituents, Heterocyclic Aromatic Amines
and Mycotoxins. In IARC Monographs on the Evaluation of Carcinogenic Risk of Chemicals to Human; International
Agency for Research on Cancer: Lyon, France, 1993; Volume 56, pp. 245–395.
9.
Regulatory Summaries. Regul. Chem. Dir. 1995, 1647–1648. [CrossRef]
10. Voutsinas, J.; Wilkens, L.R.; Franke, A.; Vogt, T.M.; Yokochi, L.A.; Decker, R.; Marchand, L.L. Heterocyclic
amine intake, smoking, cytochrome P450 1A2 and N-acetylation phenotypes, and risk of colorectal adenoma
in a multiethnic population. Gut 2013, 62, 416–422. [CrossRef]
11. John, E.M.; Stern, M.C.; Sinha, R.; Jocelyn, K. Meat consumption, cooking practices, meat mutagens, and risk
of prostate cancer. Nutr. Cancer 2011, 63, 525–537. [CrossRef]
12. Kabat, G.C.; Cross, A.J.; Park, Y.; Schatzkin, A.; Hollenbeck, A.R.; Rohan, T.E.; Sinha, R. Meat intake and
meat preparation in relation to risk of postmenopausal breast cancer in the NIH-AARP diet and health study.
Int. J. Cancer 2009, 124, 2430–2435. [CrossRef] [PubMed]
13. Cheng, K.W.; Zhang, X.C.; Wang, M.F. Chemistry and safety of maillard reaction products III: Heterocyclic
amines and amino acids derivatives. In Food Safety Chemistry: Toxicant Occurrence, Analysis and Mitigation;
Yu, L., Wang, S., Sun, B.-G., Eds.; CRC Press: Boca Raton, FL, USA, 2014; pp. 69–88.
14. Puangsombat, K.; Gadgil, P.; Houser, T.A.; Hunt, M.C.; Smith, J.S. Occurrence of heterocyclic amines in
cooked meat products. Meat Sci. 2012, 90, 739–746. [CrossRef] [PubMed]
15. Skog, K.; Augustsson, K.; Steineck, G.; Stenberg, M.; Jägerstad, M. Polar and non-polar heterocyclic amines in
cooked fish and meat products and their corresponding pan residues. Food Chem. Toxicol. 1997, 35, 555–565.
[CrossRef]
16. Iwasaki, M.; Kataoka, H.; Ishihara, J.; Takachi, R.; Hamada, G.S.; Sharma, S.; Le Marchand, L.; Tsugane, S.
Heterocyclic amines content of meat and fish cooked by Brazilian methods. J. Food Compos. Anal. 2010, 23,
61–69. [CrossRef] [PubMed]
17. Jägerstad, M.; Skog, K.; Grivas, S.; Olsson, K. Formation of heterocyclic amines using model systems. Mutat.
Res. 1991, 259, 219–233. [CrossRef]
18. Skog, K.I.; Johansson, M.A.E.; Jägerstad, M.I. Carcinogenic heterocyclic amines in model systems and cooked
foods: A review on formation, occurrence and intake. Food Chem. Toxicol. 1998, 36, 879–896. [CrossRef]
19. Shioya, M.; Wakabayashi, K.; Sato, S.; Nagao, M.; Sugimura, T. Formation of a mutagen,
2-amino-1-methyl-6-phenylimidazo [4,5-b]-pyridine (PhIP) in cooked beef, by heating a mixture containing
creatinine, phenylalanine and glucose. Mutat. Res. 1987, 191, 133–138. [CrossRef]
20. Overvik, E.; Kleman, M.; Berg, I.; Gustafsson, J.A. Influence of creatine, amino acids and water on the
formation of the mutagenic heterocyclic amines found in cooked meat. Carcinogenesis 1989, 10, 2293–2301.
[CrossRef]
21. Johansson, M.A.E.; Laurent, B.F.; Gross, G.A.; Olsson, K.; Jägerstad, M. Influence of amino acids on the
formation of mutagenic/carcinogenic heterocyclic amines in a model system. Carcinogenesis 1995, 16,
2553–2560. [CrossRef]
22. Arvidsson, P.; Van Boekel, M.A.J.S.; Skog, K.; Solyakov, A.; Jägerstad, M. Formation of heterocyclic amines in
a meat juice model system. J. Food Sci. 1999, 64, 216–221. [CrossRef]
23. Ahn, J.; Grün, I.U. Heterocyclic amines: 1. kinetics of formation of polar and nonpolar heterocyclic amines
as a function of time and temperature. J. Food Sci. 2005, 70, C173–C179. [CrossRef]

Molecules 2019, 24, 3828
12 of 12
24. Hwang, D.K.; Ngadi, M. Kinetics of heterocyclic amines formation in meat emulsion at different fat contents.
LWT Food Sci. Technol. 2002, 35, 600–606. [CrossRef]
25. Moon, S.E.; Shin, H.S. Formation of genotoxic 2-amino-1-methyl-6-phenylimidazo [4,5-b] pyridine (PhIP)
and its kinetics in a model system. Food Sci. Biotechnol. 2013, 22, 137–145. [CrossRef]
26. Arvidsson, P.; Van Boekel, M.A.J.S.; Skog, K.; Jägerstad, M. Kinetics of formation of polar heterocyclic amines
in a meat model system. J. Food Sci. 1997, 62, 911–916. [CrossRef]
27. Chiu, C.P.; Chen, B.H. Stability of heterocyclic amines during heating. Food Chem. 2000, 68, 267–272.
[CrossRef]
28. Parker, J.K. Thermal generation or aroma. In Flavour Development, Analysis and Perception in Food and Beverages;
Parker, J., Elmore, J., Methven, L., Eds.; Elsevier Ltd.: London, UK, 2015; pp. 151–185. ISBN 9781782421030.
29. Rizzi, G.P. The strecker degradation of amino acids: Newer avenues for flavor formation. Food Rev. Int. 2008
,
24, 416–435. [CrossRef]
30. Zochling, S.; Murkovic, M. Formation of the heterocyclic aromatic amine PhIP: Identification of precursors
and intermediates. Food Chem. 2002, 79, 125–134. [CrossRef]
31. Linghu, Z.; Karim, F.; Smith, J.S. Amino acids inhibitory effects and mechanism on
2-amino-1-methyl-6-phenylimidazo[4,5-b] pyridine (PhIP) formation in the maillard reaction model systems.
J. Food Sci. 2017, 82, 3037–3045. [CrossRef]
32. Britt, P.F.; Buchanan, A.C.; Owens, C.V., Jr.; Skeen, J.T. Does glucose enhance the formation of nitrogen
containing polycyclic aromatic compounds and polycyclic aromatic hydrocarbons in the pyrolysis of proline.
Fuel 2004, 83, 1417–1432. [CrossRef]
33. Kato, T.; Harashima, T.; Moriya, N.; Kikugawa, K.; Hiramoto, K. Formation of the mutagenic/carcinogenic
imidazoquinoxaline-type heterocyclic amines through the unstable free radical Maillard intermediates and
its inhibition by phenolic antioxidants. Carcinogenesis 1996, 17, 2469–2476. [CrossRef]
34. Jokic, A.; Zimpel, Z.; Huang, P.M.; Mezey, P.G. Molecular shape analysis of a maillard reaction intermediate.
SAR QSAR Environ. Res. 2001, 12, 297–307. [CrossRef] [PubMed]
35. Yoshida, D.; Saito, Y.; Mizusaki, S. Isolation of 2-amino-3-methyl-imidazo-[4,5-f]quinoline as mutagen from
the heated product of a mixture of creatine and proline. Agric. Biol. Chem. 1984, 48, 241–243.
36. Skog, K.; Jägerstad, M. Effects of monosaccharides and disaccharides on the formation of food mutagens in
model systems. Mutat. Res. 1990, 230, 263–272. [CrossRef]
37. Gross, G.A.; Grüter, A. Quantitation of mutagmic/carcinogenic heterocyclic aromatic amines in food products.
J. Chromatogr. 1992, 592, 271–278. [CrossRef]
38. Jinap, S.; Mohd-Mokhtar, M.S.; Farhadian, A.; Hasnol, N.D.S.; Jaafar, S.N.; Hajeb, P. Effects of varying degrees
of doneness on the formation of heterocyclic aromatic amines in chicken and beef satay. Meat Sci. 2013, 94,
202–207. [CrossRef] [PubMed]
39. Ahmad Kamal, N.H.; Selamat, J.; Sanny, M. Simultaneous formation of polycyclic aromatic hydrocarbons
(PAHs) and heterocyclic aromatic amines (HCAs) in gas-grilled beef satay at different temperatures. Food
Addit. Contam. Part A 2018, 35, 848–869. [CrossRef]
Sample Availability: Not available.
©
2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
