A convenient and efficient protocol for the synthesis of adipic acid catalyzed by ACC/silica gel under ultrasound irradiation

Article abstract of DOI:10.1155/2012/207692

Adipic acid was synthesized from cyclohexanol oxidized by ACC/silica gel in 89% yield within 3 h at 300C under ultrasound irradiation.

Full text of DOI:10.1155/2012/207692

ISSN: 0973-4945; CODEN ECJHAO
E-Journal of Chemistry
http://www.ejchem.net
2012, 9(3), 1035-103ꢀ
A Convenient and Efficient Protocol for the Synthesis
of Adipic Acid Catalyzed by ACC/Silica Gel under
Ultrasound Irradiation
ZHI-PING LIN
Department of Biology and Chemistry, Baoding University, Baoding 071000, P. R. China.
linzhiping888999@126.com
Received 10 November 2011; Accepted 15 January 2012
Abstract: Adipic acid was synthesized from cyclohexanol oxidized by
0
ACC/silica gel in 89% yield within 3 h at 30 C under ultrasound irradiation.
Keywords: adipic acid; ACC/silica gel; synthesis; ultrasound irradiation.
Introduction
Adipic acid is a most important organic synthetic intermediate, and mainly used for synthetic
fibers: nylon-66, other fields can also be widely used, for example polyurethane, synthetic
resin, leather, polyester foam, plastic plasticizers, lubricants, food additives, adhesives,
1
pesticides, dyes, spices, medicine .
The adipic acid was synthesized usually throughout the oxidation of cyclohexene,
2
cyclohexanol, cyclohexanone or a mixture of them or electro-oxidation of cyclohexanol , with
3
nitric acid, potassium permanganate, molecular oxygen, ozone, sodium hypochlorite as the
oxidant. Much attention has been paid for its green synthesis process because of disadvantages
in current technology. Hydrogen peroxide as a safe, gentle, clean, cheap and readily available
oxidant, can replace traditional high-polluting oxidants in organic synthesis. But in these
procedures, the expensive and complex catalysts for example, peroxotungstates and
4
peroxomolybdates , ZSM-5 supported metal ions (M/ZSM-5) and N-hydroxyphthalimide
5
6
7
(
NHPI) , heteropoly complexes , a carbon supported platinum catalyst , Ti-AlSBA15
8
9
10
catalysts , manganese diimine catalysts , Co-substituted β-zeolites catalysts , Iron-
phthalocyanine on zeolite Y , tungstic acid/acidic organic additive , phosphotungstic acid
etc. have to be added in.
11
12
13
Ammonium chlorochromate (ACC) is a good oxidizing of secondary alcohols and has
a wide range of applications in organic synthesis. It also has advantages of low price, easy
preparation, stable, selective, with less, and easy separation of product.
Reagents supported on inorganic substrates have been received increasing attention in
recent years as a means to develop convenient and environmentally friendly reagents. The

1
054 ZHI-PING LIN
concept of utilizing reagents adsorbed on inert inorganic supports has been reported and
14
applied, especially to chromium compounds . Ammonium chlorochromate (ACC) adsorbed
on silica gel was another convenient oxidant recently reported. The use of silica gel as solid
support has become very useful in synthetic organic chemistry because of the enhanced
selectivity resulting from its large surface area. These reagents can oxidize various alcohols
and have many advantages such as mild conditions, easy workup procedures, and good yields.
Ultrasound has increasingly been used in organic synthesis in the last three decades. A
large number of organic reactions can be carried out in higher yields, shorter reaction time or
milder conditions under ultrasound irradiation.
In this paper we wish to report an efficient and practical procedure for the synthesis of
adipic acid with the oxidation of cyclohexanol by ACC/silica gel in CH2Cl2 under ultrasound
irradiation (Scheme 1).
OH
ACC/silica gel
u.s.
COOH
COOH
Scheme 1. Synthesis of adipic acid under ultrasound irradiation.
Experimental
Liquid substrates were distilled prior to use. Melting points were uncorrected. Sonication was
performed in Shanghai BUG40-06 or BUG25-06 ultrasonic cleaner (with a frequency of 25
kHz, 40 kHz, 59 kHz and a nominal power 250 W).
15
Preparation of Ammonium Chlorochromate/Silica Gel
To a solution of chromium trioxide (20 g, 0.2 mol) in water (50 mL) is added ammonium
0
chloride (10.7 g, 0.2 mol) within 15 min at 40 C. The mixture is cooled until yellow–orange
0
solid forms. Reheating to 40 C, silica gel (100 g) is then added to the solution with stirring.
0
After evaporation in a rotary evaporator the orange solid is dried for 2.5 h at 50 C. The content
of ACC in ACC/silica gel is about 15.3%.
Typical Procedure for the Preparation of Adipic Acid
A 50-mL round flask was charged with cyclohexanol (2 mmol), ACC/silica gel (2.62 g,
including ACC 4 mmol), and CH2Cl2 (8mL) in one portion. The reaction flask was located in
the cleaner bath, where the surface of reactants was slightly lower than the level of the water.
The mixture was irradiated 3h (the reaction was monitored by TLC). The reaction products
were isolated by filtration from the reaction mixture. Then the solvent was poured into crushed
ice. The precipitate was separated by filtration, washed with water, and crystallized from water
0
to obtain the adipic acid 256 mg, 89%, Mp: 152-153 C.
Results and Discussion
In a preliminary experiment, the influence of the amount of ACC/silica gel on the yield was
studied. It was found that a molar ratio of cyclohexanol: ACC/silica gel of 1:2 gave the best
yield (89%). By changing the molar ratio to 1:1, 1:1.5, 1:2.25, and 1:2.5 the yields decreased to
66%, 70%, 82% and 80% respectively (Table 1). The results showed that changing the molar

A Convenient and Efficient Protocol for the Synthesis of Adipic Acid 1055
ratio had a significant effect on the yield, and the optimum molar ratio of cyclohexanone:ACC/
silica gel was 1:2.
In the absence of ultrasound, on the oxidation of cyclohexanol to adipic acid by ACC/silica gel
proceeded in only 40% yield within 3h by stirring alone (Table 2). The oxidation gave adipic
acid in 89% yield within 3h under the ultrasonication of 25 kHz. While under 40 kHz and 59
kHz ultrasound irradiation, the reaction was completed in 3h with 73% and 70% yield
respectively. It is apparent that the ultrasound can accelerate the oxidation, and lower
frequency of ultrasound irradiation improves the yield. Therefore, the reaction was carried out
with 25 kHz ultrasound irradiation.
Table 1 The effects of the amount of ACC/silica gel on the oxidation of cyclohexanol to
adipic acid under ultrasound irradiation*
Amount of ACC/silica gel, g 1.31
Yield, % 66
1.97
70
2.62
89
2.95
3.28
80
82
0
*
ultrasound frequency: 25 kHz; reaction time: 3h; reaction temperature: 30 C.
Table 2 The effect of ultrasound frequency on the oxidation of cyclohexanol to adipic acid*.
Ultrasound frequency, kHz
Yield, %
25
89
40
73
59
70
stiring
40
0
*
amount of ACC/silica gel: 2.62g; reaction time: 3h; reaction temperature: 30 C.
As shown in Table 3, adipic acid gave a lower yield from the oxidation of cyclohexanol when
the reaction time prolonged from 3.0 h to 4.0 h. The reason may be that the prolonged reaction
time would cause many other by-products within the reaction system.
Table 3 The effect of reaction time on the oxidation of cyclohexanol to adipic acid under
ultrasound irradiation*.
Reaction time , h
2.5
71
3.0
89
3.5
82
4.0
75
Yield, %
*
3
ultrasound frequency: 25 kHz; amount of ACC/silica gel: 2.62g; reaction temperature:
0 C.
0
It was also found that reaction temperature has some effects on the oxidation of cyclohexanol
0
0
0
0
to adipic acid. By changing the reaction temperature from 30 C to 25 C, 35 C and 40 C the
yields decreased from 89% to 75%, 81% and 73% respectively (Table 4). This may be that the
lower reaction temperature caused the lower reactivity, but the higher reaction temperature
would cause other complex oxidation by-products and difficult workup procedures. Therefore,
0
the reaction was carried out at 30 C under ultrasound irradiation.

1
056 ZHI-PING LIN
Table 4 The effect of reaction temperature on the oxidation of cyclohexanol to adipic acid
under ultrasound irradiation*.
0
Reaction temperature, C 25
30
89
35
81
40
73
Yield, %
75
*ultrasound frequency: 25 kHz; amount of ACC/silica gel: 2.62g; reaction time: 3h.
Ammonium chlorochromate (ACC) adsorbed on silica gel have many advantages such as mild
conditions, easy workup procedures, and good yields. The most important was that the
oxidizing agent could recycle and the oxidizing power has no significant decrease after
recycled two times (Table 5).
Table 5 The effect of recycled times of ACC/silica gel on the oxidation of cyclohexanol to
adipic acid under ultrasound irradiation *.
Recycled times
Yield, %
0
1
2
3
89
79
74
60
*ultrasound frequency: 25 kHz; amount of ACC/silica gel: 2.62g; reaction time: 3h.
Wang et al. 16 reported that the adipic acid was synthesized from cyclohexene oxidized by 30
0
%
H2O2 in 55% yield at 90 C within 6 h which catalyzed by H3PW12O40/TiO2. While in our
system, the ACC/silica gel-oxidation reaction was given adipic acid in 89 % yields under
0
ultrasound irradiation within 3 h at 30 C.
In summary, we have found an efficient and practical procedure for the synthesis of
adipic acid via the oxidized by ACC/silica gel of cyclohexanol under ultrasound irradiation.
The present procedure has many advantages such as short reaction time, mild conditions, easy
operation procedures, and high yields.
References
1
2
3
4
．
．
．
．
Sato K, Aoki M and Noyori R, Science, 1998, 281, 1646.
Liang Z H, Cui Y Q and Sun H Y, Electrochemistry, 2008, 14, 40.
Rothenberg G and Sasson Y, Tetrahedron, 1996, 52, 13641.
Zhu W S, Li H M, He X Y, Zhang Q, Shu H M and Yan Y S, Catal. Commun., 2008,
9
, 551.
5
6
．
．
Yang D H, Liu M D, Zhao W J and Gao L, Catal. Commun., 2008, 9, 2407.
Ren S Y, Xie Z F, Cao L Q, Xie X P, Qin G F and Wang J D, Catal. Commun., 2009,
1
0, 464.
7
8
．
．
Béziat J C, Besson M and Gallezot P, Appli. Catal. A: General, 1996, 135, L7-L11.
Lapisardi G, Chiker F, Launay F, Nogier J P and Bonardet J L, Catal. Commun.,
2
004, 5, 277.

A Convenient and Efficient Protocol for the Synthesis of Adipic Acid 1057
9
1
1
．
Knops-Gerrits P P, Thibault-Starzyk F and Jacobs P A, Studies in Surface Science
and Catalysis, 1994, 84, 1411.
0． Belkhir I, Germain A, Fajula F and Fache E, Studies in Surface Science and
Catalysis, 1997, 110, 577.
1． Thibault-Starzyk F, Parton R F and Jacobs P A, Studies in Surface Science and
Catalysis, 1994, 84, 1419.
1
1
1
2． Cao F B, Jiang H and Gong H, Chin. J. Org. Chem., 2005, 25, 96.
3． Meng Q Z, Dong Y H, Qin B Y and Zhou C S, Chem. World, 2005, (4), 226.
4． (a) Heravi M M, Hydar K T and Kiakojoori R, J. Chem. Res., Synop., 1998, 10, 656;
(
b) Hajipour A R, Imanzadeh G and Mallakpour S E, Chem. Lett., 1999, 2, 99; (c)
Lou J D and Xu Z N, Tetrahedron Lett., 2002, 43, 6149; (d) Lou J D and Xu Z N,
Tetrahedron Lett., 2002, 43, 6095.
1
1
5． Zhang G S, Shi Q Z, Chen M and Cai K, Synth. Commun., 1997, 27, 953.
6． Wang Y H, Dong J H and Tang X H, Journal of Nanchang Institute of Aeronautical
Technology (Natural Science Edition), 2006, 20, 28.
