Kim et al.
Steam Reforming of Glycerol Over Nano Size Ni–Ce/LaAlO3 Catalysts
and low availability of these metals have led to a search
for alternative metals, which are cheaper and more readily
available. For that reason, nickel based catalysts are widely
used due to their high activity at much lower cost.
However, the main problem encountered was the forma-
tion of carbon deposits and deactivation by of the catalyst
due to Ni sintering. It is hence highly desirable to develop
catalyst that is inexpensive, active and stable during the
glycerol reforming reaction. According to the literature,
Ce and La have been described to inhibit the growth of
metal particles and favor the removal of carbon deposits
from metal surface.4
The aim of the present work was to investigate the
hydrogen production in steam reforming of glycerol over
Ni based catalysts. The Ni–Ce and Ni–La catalysts sup-
ported on LaAlO3 perovskite employed Ce and La loading
amount 5 wt%, respectively. Catalyst of Ni supported on
LaAlO3 perovskite was also prepared for a comparative
analysis. The physicochemical properties of both the cata-
lysts were characterized and correlated with their catalytic
performance.
located inside an electric oven of low thermal inertia. The
temperature inside the reactor is measured by means of a
thermocouple, located inside the catalytic bed. Typically,
1 g of catalyst was loaded in the reactor and an aque-
ous solution containing glycerol was fed into the reactor
by an HPLC (high-pressure liquid chromatography) pump.
The product stream was separated into a liquid phase and
a gas phase in a condenser connected to the reactor out-
let. The gaseous products were analyzed on-line by gas
chromatography using a Shimatzu-14B model chromato-
graph equipped with a TCD (thermal conductivity detec-
tor). Finally H2, CH4, CO and CO2 were separated in a
Hayesep D column (ꢁ1/8ꢁꢁ × 7 m, 100/120 mesh) using
Ar as the carrier gas.
3. RESULTS AND DISCUSSION
3.1. Characterization of Catalysts
The XRD measurements of prepared LaAlO3 supported Ni
catalyst and Cerium, Lanthanum promoted Ni/LaAlO3 cat-
alysts are shown in Figures 1(A) and (B), respectively. All
the catalysts exhibit strong diffraction peaks that appear
around 2ꢂꢀ = 33ꢀ, corresponding to perovskite structures.
For the calcined catalysts (Fig. 1(A)), the diffraction
lines of nickel phases were presented at 2ꢂꢀ = 37ꢃ2ꢀ, 43.4ꢀ
and 63ꢀ for NiO in all catalysts.6 Figure 1(B) shows the
2. EXPERIMENTAL DETAILS
2.1. Catalyst Preparation
The used perovskite was in the form of ABO3, with La in
the A sites and Al in the B sites. This LaAlO3 perovskite
ꢀ
550 C for 2 hours. The diffraction lines show that NiO
Delivered by Publishing Technology to: McMaster University
was prepared by means of the citric acid-method, in which
IP: 62.99.78.206 On: Mon, 12 Oct 2015 08:49:18
citric acid was added to the sol–gel method.5 The mix-
Copyright: Amerꢀican Scientific Publishers
ture was obtained in the form of a gel, dꢀried at 110 C
overnight in an oven and calcined at 400 C for 2 h and
ꢀ
850 C for 11 h in air.
The catalysts of 15Ni/LaAlO3, 15Ni–5Ce/La–AlO3 and
15Ni–5La/LaAlO3 were prepared by means of a precip-
itation method using Na2CO3, in which the Ni loading
amount was 15 wt% and the Ce, La loading amounts were
5 wt%, respectively.
The precipitate was stirred at 80 ꢀC for 1 h, then repeat-
edly washed and filtereꢀd with distilled water and finally
dried overnight at 110 C in oven. Subsequently, all the
ꢀ
synthesized catalysts were calcined at 500 C for 5 h.
2.2. Catalysts Characterization and Reaction Test
Catalysts were characterized by X-ray diffraction (XRD)
instrument (Rigaku, Japan, DMAX100, Cu-Kꢀ, Ni filter),
Scanning electron microscope (SEM) instrument (JEOL,
JSM-5400A), Transmission electron microscope (TEM)
instrument (JEOL, JEN-2000FXII), H2-chemisorption and
Temperature-programmed reduction (TPR) instrument
(Chemisorption Analyzer, BEL-CAT, BEL, Japan).
The steam reforming of glycerol was carried out under
atmospheric pressure in a fixed-bed reactor. Prior to the
reaction, the catalyst was reduced in situ at 550 ꢀC for 2 h
in a mixture of H2 (3 ml/min) and Ar (27 ml/min). The
reactor consisted of a stainless steel (i.d. = 16 mm), (L =
400 mm) tubular reactor to hold the catalyst and it was
Figure 1. XRD patterns of calcined catalysts (A) and reduced catalysts
(B): (a) Ni/LaAlO3, (b) Ni–Ce/LaAlO3, (c) Ni–La/LaAlO3.
J. Nanosci. Nanotechnol. 15, 522–526, 2015
523
