Discovery of novel quinazoline-based covalent inhibitors of KRAS G12C
with various cysteine-targeting warheads as potential anticancer agents
Ling Li, Huiting Zhao, Hui Liao, Jingxuan Chen, Jin Liu, Jianjun Chen*
School of Pharmaceutical Sciences, Guangdong Provincial Key Laboratory of New Drug Screening, Southern Medical University, Guangzhou 510515, China
A R T I C L E I N F O
A B S T R A C T
Keywords:
A series of novel quinazoline analogs with a variety of cysteine-targeting warheads (electrophiles) were designed
and synthesized based on ARS-1620 as covalent KRAS G12C inhibitors. Among them, compounds LLK10 and
LLK14 exhibited similar or better antiproliferative activity than ARS-1620. LLK10 was used for subsequent
biological studies due to the higher selectivity towards KRAS G12C-mutated cells than LLK14. LLK10 maintained
the mechanism of action by forming a covalent bond with KRAS G12C protein, thus decreasing the level of
phosphorylated Mek and Erk, and leading to tumor cell apoptosis. In addition, LLK10 was able to suppress the
formation of H358 tumor colonies. Molecular modeling study indicated that LLK10 binds with high affinity to
the SWII binding site in KRAS G12C and overlaps well with ARS-1620. The high binding affinity of LLK10 was
further confirmed by the isothermal titration calorimetry (ITC) assay in which LLK10 exhibited a KD of 115 nM
for binding to KRAS G12C. These results suggest that the novel covalent inhibitors of KRAS G12C with different
warheads deserve further investigation as potential anticancer agents.
KRAS G12C
Covalent inhibitors
Anticancer
Cysteine-targeting warheads
1. Introduction
able to compete for binding to the GTP-site of KRAS. Additionally, the
absence of deep and hydrophobic binding pockets on the surface of
RAS proteins are GTPases controlling the activity of several critical
signaling pathways that regulate cell differentiation, proliferation, and
survival [1,2]. RAS gene family comprises three members (KRAS, HRAS,
and NRAS), which function as a binary switch transitioning between the
active (GTP-bound) state and the inactive (GDP-bound) state [3].
Mutated RAS is constitutively activated and constantly turned “on”, thus
resulting in accretion of GTP-bound activated RAS and activation of
downstream signaling pathways (e.g. RAS-Raf-Mek-Erk), eventually
leading to the development of cancer (Fig. 1) [4]. KRAS is the most
frequently mutated oncogene in human cancer, occurring in 30% of
human tumors. Among KRAS mutant tumors, 80% of all oncogenic
mutations occur within codon 12, especially p.G12C, where glycine was
substituted by cysteine residue [5].
oncogenic KRAS protein also hindered the discovery of effective inhib-
itor molecules. Furthermore, KRAS activation and signaling is accom-
plished through protein–protein interactions (PPIs), which are
challenging to target because of the relatively featureless and flat to
pologies of the surfaces involved [7].
In 2013, Shokat and co-workers reported a novel strategy to target
the reactive cysteine 12 (Cys12) of KRAS G12C using covalent inhibitors
[8]. They proposed that covalently modifying Cys12 could disrupt KRAS
G12C-driven signaling pathway by forming a covalent bond between the
inhibitor and Cys12 of KRASG12C. They developed a series covalent
inhibitors (e.g.ARS-1620 and ARS-917, Fig. 2A), which covalently
bound to Cys12 of the GDP-bound form of KRAS, with the quinazoline
core of the molecule occupying an allosteric pocket (the “switch II
pocket” (S-IIP)) (Fig. 2B) [9].
Although KRAS mutations are common in a large number of cancer
patients, to date, there is no effective therapy that specifically targets
mutant KRAS available in clinic, despite the intensive efforts made by
researchers [6]. KRAS is conventionally deemed “undruggable” due to
the extremely high binding affinity (picomolar) to GDP and GTP within
the cells, along with the high micromolar concentrations of intracellular
Recently, there has been a growing interest in the development of
irreversible and reversible covalent inhibitors targeting the catalytic or
noncatalytic amino acids (e.g. cysteine) of KRAS [10]. In an effort to
identify more effective and selective KRAS G12C inhibitors for cancer
treatment, we designed a series of quinazoline-based molecules (LLK1-
14) by varying the covalent warheads (the electrophiles) of ARS-1620
GTP (~500 μM) [3], making it unlikely that a drug molecule would be
* Corresponding author.
E-mail address: jchen21@smu.edu.cn (J. Chen).
https://doi.org/10.1016/j.bioorg.2021.104825
Received 16 January 2021; Received in revised form 3 March 2021; Accepted 9 March 2021
Available online 13 March 2021
0045-2068/© 2021 Elsevier Inc. All rights reserved.

L. Li et al.
Bioorganic Chemistry 110 (2021) 104825
2.2. Biological evaluations
2.2.1. In vitro antiproliferative activity and structure–activity relationship
The antiproliferative activities of the newly synthesized compounds
(LLK1-14) against five human cancer cell lines were evaluated by using
the standard MTT assay with ARS-1620 as positive control. As shown in
Table 1, compounds LLK1 to LLK6 with an electron donating substituent
on the double bond (covalent warhead) showed low antiproliferative
activity on KRAS G12C mutated cancer cell lines (Miapanc2, H358),
with IC50 values of >30 μM. However, compounds with an electron
withdrawing group on the double bond, for example, LLK7-10 and
LLK14, displayed improved antiproliferative activities with IC50 values
in the low to medium micromolar range (1.20–25.1 μM). Among them,
LLK10 and LLK14 exhibited the highest antiproliferative potency with
IC50 values of 4.06 M and 1.50 M against Miapanc2 (KRAS G12C)
cells, and 2.34 M and 1.20 M against H358 (KRAS G12C) cells,
respectively, similar to that of ARS-1620 (IC50 = 2.81 and 0.18 M for
Miapanc2 and H358 cells, respectively). Notably, the activity of LLK14
in Miapanc2 cells (IC50 = 1.50 M) is better than that of ARS-1620 (IC50
= 2.81 M). In addition, compound LLK10 demonstrated good selec-
tivity towards KRAS G12C-mutated H358 cells (IC50 = 2.34 M) over
KRAS G12S-mutated A549 (IC50 = 8.60 M) and KRAS G12D-mutated
Panc1 cells (IC50 = 7.34 M) as well as the wild-type MCF7 cells
(IC50 = 7.48 M). However, for compounds with the unsaturated bond
(electrophilic warhead) replaced by a saturated bond (LLK11 and
μ
μ
μ
μ
Fig. 1. Overview of Ras signaling pathway. The mutation of RAS activates the
protein into a hyperexcitable state, thus resulting in accretion of GTP-bound
activated RAS and activation of downstream signaling pathways.
μ
μ
μ
(Fig. 3), and explored the impact of different electrophilic warheads on
the activity. Herein, we report the design, synthesis, and biological ac-
tivities of these covalent inhibitors of KRAS G12C.
μ
μ
μ
μ
2. Results and discussion
LLK12), a complete loss of activity was observed (e.g. IC50 > 50 μM),
2.1. Chemistry
indicating that the unsaturated bond (electrophilic warhead) is critical
for activity. Based on the high antiproliferative activity and good
selectivity towards KRAS G12C-mutated cancer cells, LLK10 was
selected for subsequent biological studies as detailed below.
The synthesis of target compounds LLK1 ~ 14 is outlined in Scheme
1. To a solution of 7-bromo-6-chloroquinazolin-4-ol in thionyl chloride,
DMF was added and the resulting mixture was stirred at 80 ◦C for 8 h to
obtain the chlorinated compound 2. Then, to a solution of compound 2
in DMF at 0 ◦C, DIPEA and tert-butyl piperazine-1-carboxylate were
added, and the resulting mixture was stirred at 50 ◦C for 2 h to generate
compound 3 via nucleophilic substitution. Compound 3 was subjected to
a Suzuki reaction with 2-fluoro phenyl boronic acid to produce the
quinazoline intermediate 4. Removal of the Boc-group from intermedi-
ate 4 under acidic conditions yielded compound 5, which was coupled
with various carboxylic acids using (Benzotriazol-1-yloxy) tris(dime-
thylamino) phosphonium hexafluorophosphate (BOP) as the coupling
reagent to give compound 6 (LLK12), or compounds LLK10 ~ 14.
Compounds LLK1 ~ 9 were synthesized by reacting compound 6
(LLK12) with different aldehydes under basic conditions.
2.2.2. Colony formation assay
Colony formation assay has been widely utilized for prediction of in
vivo antitumor efficacy of a drug molecule [11]. To further validate the
in vitro antiproliferative activities of the newly synthesized compounds,
we evaluated the ability of one of the best compounds, LLK10 (IC50
=
2.34
μM, Fig. 4A) to inhibit H358 tumor colony formation at five
different concentrations (2 μM, 4 μM, 6 μM, 8 μM, 10 μM). As shown in
Fig. 4B, LLK10 was able to suppress the formation of H358 tumor col-
onies in a dose-dependent manner, with the colony-forming ability of
H358 cells being totally suppressed after 24 h treatment with 2 μM of
LLK10.
2.2.3. LLK10 covalently bound to KRAS G12C
To determine whether compound LLK10 maintained the mechanism
of action by forming a covalent bond with KRAS G12C, we incubated
Fig. 2. A: The chemical structures of ARS-1620 and ARS-917; B: The crystal structure of ARS-1620 in complex with KRAS G12C (PDB code: 5V9U). The gray part
represents ARS-1620. The pink part represents GTP. (For interpretation of the references to colour in this figure legend, the reader is referred to the web version of
this article.)
2

L. Li et al.
Bioorganic Chemistry 110 (2021) 104825
KRAS G12C protein with LLK10 and observed the expected mass gain
(MS = 464) using mass spectrometry (Fig. 5A to F). This result indicated
that LLK10 binds through a covalent bond to KRAS G12C protein.
3. Conclusion
In summary, a series of novel quinazolines analog with different
electrophilic warheads were designed and synthesized based on ARS-
1620 as covalent KRAS G12C inhibitors and a focused SAR study was
conducted. These compounds exhibited high antiproliferative potency
against KRAS G12C mutated cancer cell lines with IC50 values at low
micromolar levels. Structure-activity relationships revealed that the
substituents on the acrylamide have great influence on the biological
activities of the compounds (e.g. electron withdrawing groups are more
favorable). Among the newly synthesized compounds, LLK10 and
LLK14 were identified as two of the most potent compounds against
KRAS G12C mutated cancer cells, with the activity being similar or
better than that of ARS-1620. LLK10 showed higher selectivity than
LLK14 and was chosen for subsequent biological studies. LLK10
demonstrated high inhibitory activity against H358 tumor colony for-
mation. Mass spectrometry, CD, and ITC studies indicated that LLK10
binds covalently to KRASG12C protein with high affinity (KD of 115 nM
by ITC) and changed the conformation of secondary structures of KRAS
G12C protein. In addition, western blot analysis revealed that LLK10
decreased the levels of phosphorylated Mek and Erk, similar to ARS-
series of compounds. Molecular docking study suggested that LLK10
binds well to and overlaps nicely with ARS-1620 in the SWII binding
pocket of KRAS G12C protein. These results suggest that LLK10, with the
novel acrylamide warhead for covalent binding, may serve as a starting
point for developing more effective KRAS G12C inhibitors for cancer
treatment.
2.2.4. LLK10 exhibited high binding affinity to KRAS G12C protein
To further confirm whether the KRAS G12C inhibitor LLK10 can
bind to KRAS G12C, we assessed its binding affinity to KRAS G12C by
using isothermal titration calorimetry (ITC) and circular-dichroism
spectroscopy (CD) analysis. As shown in Fig. 6A, LLK10 exhibited
high binding affinity to KRAS G12C with a KD of 115 nM. Moreover, CD
spectroscopy also indicated that the conformation of secondary struc-
tures of KRAS G12C protein changed when LLK10 was mixed with KRAS
G12C (Fig. 6B), as compare to the control (KRAS G12C protein only).
Collectively, these results (ITC and CD) suggest that LLK10 binds to
KRAS G12C protein with high binding affinity.
2.2.5. LLK10 modulates Erk signaling in KRAS G12C mutant cell lines
To explore the mechanism of action for these newly synthesized
compounds, LLK10 was selected for evaluation of the effects on the
downstream signaling pathway (e.g. MeK, Erk) of KRAS by western blot
analysis. As shown in Fig. 7A and C, LLK10 decreased the levels of pMek
and pErk (phosphorylated Mek and Erk) at a concentration of 10
However, the levels of pMek and pErk rebound at a concentration of 15
M. This may because the negative feedback of RAS signaling. In addi-
tion, LLK10 didn’t alter the level of KRAS but decreased the level of
μM.
μ
phosphorylated Mek and Erk in a time-dependent manner at 10 μM
(Fig. 7B and D). These results are consistent with literature reports for
the mechanism of action of ARS-series of compounds.[9]
4. Experimental section
2.3. Molecular modeling study for LLK10 with KRAS G12C protein
4.1. Chemistry
To better understand how the compounds interact with KRASG12C,
covalent molecular docking simulation of LLK10 and ARS-1620 at the
SWII site in the KRASG12C was investigated using the covalent docking
protocol in the Schrodinger 2011 molecular modeling suite (Schro-
dinger, Inc., New York, NY) and the KRAS crystal structure (PDB code:
5V9U). The 3D model of LLK10 and ARS-1620 (Fig. 8A) showed that
LLK10 fitted nicely to the SWII site and overlapped well with ARS-1620
in the same pocket. Two hydrogen bonds were formed between the
Unless otherwise specified, all materials were obtained from com-
mercial sources and used without purification. The reference compound
ARS-1620 was purchased from InvivoChem (Libertyville, IL 60048,
USA). Reaction time and purity of the products were determined by thin-
layer chromatography (TLC) with fluorescent indicator visualizable at
254 nm and 365 nm. Column chromatography was performed on silica
gel (100–200 mesh). 1H NMR (400 MHz) spectra and 13C NMR (101
MHz) spectra were recorded on a Bruker Avance 400 MHz NMR spec-
trometer with CDCl3 as the solvent.
pyrimidine ring and HIS95, carbonyl and LYS16 (Fig. 8B). The
π-π
interaction between the pyrimidine ring and TYR 96 was also observed.
Collectively, these binding interaction may explain the high activity of
LLK10 against KRAS G12C mutated cells.
Fig. 3. Design of ARS-1620-based covalent inhibitors of KRAS G12C bearing different electrophilic warheads.
3

L. Li et al.
Bioorganic Chemistry 110 (2021) 104825
Scheme 1. Synthesis of compounds LLK1-14.
Table1
In vitro antiproliferative activity of compounds LLK1-14.
Structure
ID
R
IC50(μM)
Pancreatic cancer
Miapanc2 (G12C)
Lung cancer
H358(G12C)
Pancreatic cancer
Panc1(G12D)
Lungcancer
A549(G12S)
Breast cancer
MCF7 (WT)
LLK1
LLK2
>30
>30
>30
>50
>50
>50
>50
>50
>50
31.17 ± 4.72
LLK3
LLK4
>30
>30
>30
>30
>50
>50
>50
>50
>50
>50
LLK5
LLK6
LLK7
LLK8
LLK9
LLK10
>30
>30
>50
>50
>50
56.98 ± 4.83
25.11 ± 0.01
18.61 ± 1.26
14.78 ± 0.45
4.06 ± 0.91
>30
>50
>50
>50
>10
>50
>50
>50
22.41 ± 1.74
18.59 ± 0.36
2.34 ± 0.917
33.24 ± 0.36
>50
>50
>50
>50
>50
CF3
7.34 ± 0.20
8.60 ± 1.33
7.48 ± 1.19
LLK11
LLK12
LLK13
CH2CF3
CH2CN
>10
>10
>10
>10
>10
>10
>50
>50
>50
>50
>50
>50
>50
>50
>50
LLK14
1.50 ± 0.20
2.81 ± 0.99
1.20 ± 0.412
0.18 ± 0.073
2.31 ± 0.53
3.71 ± 0.06
7.10 ± 0.54
>100
ARS-1620
38.86 ± 2.48
38.86 ± 4.70
4.1.1. General procedure for preparation of compounds 2
mmol) in dichloromethane (100 mL) at 0 ◦C, N,N-Diisopropylethyl-
amine (3900 mg, 30 mmol) and tert-butyl piperazine-1-carboxylate
(1860 mg, 10 mmol) were added and the resulting mixture was stirred at
50 ◦C for 2 h. The mixture was allowed to cool to room temperature and
added water to separate out compound.
To a solution of 7-bromo-6-chloroquinazolin-4-ol (2600 mg, 10
mmol) in thionyl chloride (80 mL), one drop of N,N-dimethylformamide
was added and the resulting mixture was stirred at reflux for 8 h. The
mixture was allowed to cool to room temperature and concentrated in
vacuo to afford the crude product. The crude product was used directly
in the next step without purification.
4.1.3. General procedure for preparation of compounds 4
To a solution of tert-butyl 4-(7-bromo-6-chloroquinazolin-4-yl)
piperazine-1-carboxylate (1500 mg, 3.5 mmol) and 2-fluorophenylbor-
onic Acid (980 mg, 7 mmol) in 1,4-dioxane (60 mL) and water (20
4.1.2. General procedure for preparation of compounds 3
To a solution of7-bromo-4,6-dichloroquinazoline (2780 mg, 10
4

L. Li et al.
Bioorganic Chemistry 110 (2021) 104825
Fig. 4. LLK10 suppressed the formation of H358 tumor colonies. A: Antiproliferative activity of LLK10 against H358 cancer cells; B: Inhibition of H358 tumor colony
formation by LLK10.
Fig. 5. LLK10 bound covalently to KRAS G12C protein. Mass spectrometry (MS analysis) confirms covalent labeling of LLK10 with KRAS-G12C. After incubation of
protein with DMSO (A to C) or LLK10 (D to F), reactions were resolved by LC-MS. The mass spectra revealed a shift in protein mass corresponding to LLK10.
5

L. Li et al.
Bioorganic Chemistry 110 (2021) 104825
Fig. 6. A: The binding affinity of LLK10 to KRAS G12C as measured by ITC; B: Circular dichroism spectra of KRAS G12C in complex with LLK10.
Fig. 7. LLK10 modulates Erk signaling in H358 cancer cells. Each data point represents three independent experiments, *P < 0.05, **P < 0.01.
mL) under argon atmosphere, Pd(PPh3)4 (400 mg, 0.35 mmol) and
Na2CO3 (1110 mg, 10.5 mmol) were added and the resulting mixture
was stirred at 100 ◦C for 24 h. The mixture was allowed to cool to room
temperature and concentrated in vacuo. The residue was purified by
flash column chromatography on silica gel to afford the desired product.
4.1.4. General procedure for preparation of compounds 5
To a solution oftert-butyl 4-(6-chloro-7-(2-fluorophenyl)quinazolin-
4-yl)piperazine-1-carboxylate (880 mg, 2 mmol) in dichloromethane
(20 mL) at room temperature, HCl in MeOH (100 mL) was added and the
resulting mixture was stirred at room temperature for 1 h. The mixture
was concentrated in vacuo.
6

L. Li et al.
Bioorganic Chemistry 110 (2021) 104825
Fig. 8. The 3D model of LLK10 and ARS-1620 in SWII site (A) the red stick model represents ARS-1620, the green stick model represents LLK10. The 2D model of
LLK10 (B) and ARS-1620 (C). (For interpretation of the references to colour in this figure legend, the reader is referred to the web version of this article.)
4.1.5. General procedure for preparation of compounds LLK10-LLK14
To a solution of compound 5 (36.8 mg, 0.1 mmol) in DMF was added
TEA (20 mg, 0.2 mmol) , BOP (88 mg, 0.2 mmol) and substituted car-
boxylic acid acid (0.1 mmol) and stirred overnight. The reaction mixture
was added water and then purified by flash column chromatography on
silica gel and HPLC to afford the desired product.
4.1.6.6. 2-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazine-1-
carbonyl)-4-methylpent-2-enenitrile (LLK-3). Yellow oil. Yield: 1%. 1H
NMR (400 MHz, CDCl3) δ = 8.79 (s, 1H), 7.99 (s, 1H), 7.93 (s, 1H),
7.51–7.44 (m, 1H), 7.38 (t, J = 7.4 Hz, 1H), 7.29 (d, J = 7.5 Hz,
1H),7.24–7.18 (m, 1H), 7.04 (d, J = 10.3 Hz, 1H), 3.94–3.81 (m, 8H),
3.04–2.97 (m, 1H), 1.18 (d, J = 6.5 Hz, 6H).13C NMR (101 MHz, CDCl3)
δ166.90, 163.28, 162.53, 158.25, 154.38, 140.34, 131.61, 131.35,
131.20, 131.17, 130.73, 130.65, 124.60, 124.17, 115.88, 115.66,
115.40, 106.99, 49.23, 15.73, 10.86. HRMS calculated for
4.1.6. General procedure for preparation of compounds LLK1 to LLK9
To a solution of compound 6 (40 mg, 0.1 mmol) in EtOH was added
TEA (0.2 mmol), fatty aldehyde or aromatic aldehyde (0.1 mmol) was
added and stirred at 50 ◦C overnight. The mixture was concentrated
invacuo. The residue was purified by flash column chromatography on
silica gel and HPLC to afford the desired product.
C
25H23ClFN5O [M+H]+ 464.1653. found 464.1651. Purity: 98.08% by
HPLC (tR = 18.416, 19.215 min).
4.1.6.7. 2-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazine-1-
carbonyl)-3-phenylacrylonitrile (LLK-4). Yellow oil. Yield: 10%. 1H NMR
(400 MHz, CDCl3) δ = 8.75 (s, 1H), 7.90 (d, J = 7.4 Hz, 2H), 7.51–7.40
(m, 5H), 7.38–7.33 (m, 1H), 7.31–7.26 (m, 1H), 7.24–7.17 (m, 1H),
7.16–7.11 (m, 1H), 6.82 (d, J = 8.8 Hz, 1H), 3.97–3.89 (m, 2H),
3.87–3.80 (m, 2H), 3.65–3.58 (m, 2H), 3.56–3.48 (m, 2H).13C NMR
(101 MHz, CDCl3) δ 163.38, 163.34, 153.36, 132.67, 132.02, 131.61,
131.23, 131.20, 130.84, 130.77, 130.24, 129.32, 129.29, 129.26,
124.66, 124.25, 124.21, 116.07, 115.99, 115.94, 115.72, 105.45, 49.34,
49.31. HRMS calculated for C28H21ClFN5O [M+H]+ 498.1497. found
498.1498. Purity: 98.96% by HPLC (tR = 17.667, 18.406 min).
4.1.6.1. tert-butyl
4-(7-bromo-6-chloroquinazolin-4-yl)piperazine-1-
carboxylate (3). White solid. Yield: 80%. 1H NMR (400 MHz, CDCl3) δ =
8.877 (s, 1H), 7.810 (s, 1H), 7.805 (s, 1H), 3.80–3.82 (m, 4H),
3.65–0.368 (m, 4H), 1.519 (s, 9H).
4.1.6.2. tert-butyl 4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)pipera-
1
zine-1- carboxy late (4). White solid. Yield: 80%. H NMR (400 MHz,
CDCl3): δ8.786 (s, 1H), 8.011 (s, 1H), 7.930 (s, 1H), 7.479–7.515 (m,
1H), 7.412–7.479 (m, 1H), 7.298–7.394 (m, 1H), 7.207–7.286 (m, 1H),
3.816–3.839 (m, 4H), 3.690–3.714 (m, 4H), 1.533 (s, 9H).
4.1.6.8. 2-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazine-1-
carbonyl)-3-(thiophen-2-yl)acrylonitrile (LLK-5). Yellow oil. Yield: 7%.
1H NMR (400 MHz, CDCl3) δ = 8.78 (s, 1H), 7.97 (s, 1H), 7.93 (s, 1H),
7.59 (d, J = 5.2 Hz, 1H), 7.53 (s, 1H), 7.50–7.43 (m, 1H), 7.40–7.34 (m,
2H), 7.29 (d, J = 7.6 Hz, 1H), 7.24–7.17 (m, 1H), 7.13–7.10 (m, 1H),
3.97 (d, J = 16.6 Hz, 4H), 3.82 (s, 4H). HRMS calculated for
4.1.6.3. 1- (4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazin-1-yl)
prop-2-en-1-one(5). White oil. Yield: 80%. 1H NMR (400 MHz, DMSO): δ
8.909 (s, 1H), 8.836(s, 1H), 7.979 (s, 1H), 7.623–7.718 (m, 1H),
7.525–7.607 (m, 1H), 7.449–7.507 (m, 1H), 7.395–7.430 (m, 1H), 4.227
(m, 8H).
C
29H19ClFN5OS [M+H]+ 540.1061. found 540.1058.
4.1.6.4. (4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazine-1-
carbonyl)-3-cyclopropylacrylonitrile (LLK-1). White oil. Yield: 1%. 1H
NMR (400 MHz, CDCl3) δ = 8.78 (s, 1H), 8.00 (s, 1H), 7.93 (s, 1H),
7.51–7.42 (m, 1H), 7.41–7.34 (m, 1H), 7.29 (d, J = 7.4 Hz, 1H),
7.24–7.19 (m, 1H), 6.70 (d, J = 11.2 Hz, 1H), 3.98–3.80 (m, 8H),
2.18–2.07 (m, 1H), 1.34–1.26 (m, 2H), 0.97–0.90 (m, 2H). HRMS
calculated for C25H21ClFN5 [M+H]+462.1497. found 462.1495. Purity:
96.34% by HPLC (tR = 17.393 min, 17.586 min).
4.1.6.9. 2-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazine-1-
carbonyl)-3-(furan-2-yl)acrylonitrile(LLK-6). Yellow oil. Yield: 3%. 1H
NMR (400 MHz, CDCl3) δ = 8.78 (s, 1H), 7.95 (d, J = 18.7 Hz, 2H), 7.58
(s, 1H), 7.51–7.44 (m, 1H), 7.41–7.34 (m, 1H), 7.29 (d, J = 7.6 Hz, 1H),
7.25–7.18 (m, 1H), 7.13 (s, 1H), 6.85 (d, J = 3.4 Hz, 1H), 6.60–6.54 (m,
1H), 3.88 (dd, J = 75.3, 16.9 Hz, 8H). MS calculated for C26H19ClFN5O2
[M+H]+ 488.1, found 487.9.
4.1.6.10. 2-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazine-1-
carbonyl)-3-(pyridin-4-yl)acrylonitrile(LLK-7). Yellow oil. Yield: 5%. 1H
NMR (400 MHz, CDCl3) δ = 8.83–8.79 (m, 2H), 8.00 (s, 1H), 7.95 (s,
1H), 7.76 (s, 1H), 7.71 (d, J = 5.9 Hz, 2H), 7.49–7.45 (m, 1H), 7.44–7.35
(m, 2H), 7.29 (d, J = 7.3 Hz, 1H), 7.25–7.17 (m, 1H), 3.98–3.86 (m,8H).
4.1.6.5. 2-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazine-1-
carbonyl)-3-cyclohexylacrylonitrile (LLK-2). Yellow oil. Yield: 6%. 1H
NMR (400 MHz, CDCl3) δ = 8.79 (s, 1H), 7.99 (s, 1H), 7.93 (s, 1H),
7.50–7.44 (m, 1H), 7.37 (t, J = 5.7 Hz, 1H), 7.29 (d, J = 7.5 Hz, 1H),
7.23–7.18 (m, 1H), 7.05 (d, J = 10.3 Hz, 1H), 4.05–3.75 (m, 8H),
2.74–2.66 (m, 1H), 1.47–1.22 (m,10H). HRMS calculated for
HRMS calculated for
499.1442.
C
27H20ClFN6O [M+H]+ 499.1449. found
C
28H27ClFN5O [M+H]+ 504.1966. found 504.1967. Purity: 99.15% by
HPLC (tR = 17.467 min, 17.406 min).
7

L. Li et al.
Bioorganic Chemistry 110 (2021) 104825
4.1.6.11. 4-(3-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazin-
130.67, 124.52, 124.18, 116.75, 115.88, 115.66, 79.90, 75.03, 49.67,
49.27, 46.42, 41.21. HRMS calculated for C23H19ClFN5O [M+H]+
436.0838. found 436.0839.
1-yl)-2-cyano-3-oxoprop-1-en-1-yl)benzonitrile
(LLK-8). Yellow
oil.
Yield: 5%. 1H NMR (400 MHz, CDCl3) δ = 8.80 (s, 1H), 8.02–7.98 (m,
3H), 7.94 (s, 1H), 7.84–7.77 (m, 3H), 7.64–7.56 (m, 1H), 7.51–7.43 (m,
1H), 7.41–7.33 (m, 1H), 7.29 (d, J = 7.5 Hz, 1H), 7.21 (t, J = 9.0 Hz,
1H), 3.93 (s, 8H).13C NMR (101 MHz, CDCl3). 13C NMR (101 MHz,
CDCl3) δ 163.35, 162.15, 158.24, 154.47, 150.38, 150.30, 140.41,
135.79, 132.81, 131.81, 131.50, 131.18, 131.15, 130.77, 130.69,
130.22, 124.47, 124.19, 117.69, 116.74, 115.88, 115.67, 115.44,
115.12, 109.40, 49.23, 45.87. HRMS calculated for C29H20ClFN6O
[M+H]+ 523.1449. found 523.1443.
4.2. Cell culture and cytotoxicity assay
The antiproliferative activity of all compounds was evaluated against
the human pancreatic cancer cell line miapanc2, panc1, human lung
cancer cell line H358, A549 and human breast cancer cells line MCF7 by
using the standard MTT assay in vitro, with ARS-1620 as the positive
control. All the cancer cell lines were cultured in DMEM medium sup-
plemented with 10% fetal bovine serum (FBS). Cells were seeded into
96-well plates at a density of 5 × 103 cells/well and then treated with
4.1.6.12. 2-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazine-1-
carbonyl)-3-(4-(trifluoromethyl)phenyl)acrylonitrile(LLK-9). Yellow oil.
Yield: 10%. 1H NMR (400 MHz, CDCl3) δ = 8.80 (s, 1H), 8.05–7.98 (m,
3H), 7.94 (s, 1H), 7.87 (s, 1H), 7.77 (d, J = 8.2 Hz, 2H), 7.50–7.44 (m,
1H), 7.38 (t, J = 7.4 Hz, 1H), 7.29 (d, J = 7.4 Hz, 1H), 7.21 (t, J = 9.0 Hz,
1H), 3.95 (s, 8H).13C NMR (101 MHz, CDCl3) δ = 163.36, 162.47,
154.48, 154.41, 151.12, 150.30, 140.39, 135.07, 131.79, 131.47,
131.16, 130.75, 130.67, 130.16, 129.54, 126.17, 126.13, 124.49,
124.18, 124.15, 116.75, 115.88, 115.67, 115.34, 108.47, 49.25, 41.76.
0.1% DMSO, ARS-1620 or test compounds for 24 h.100 μL of MTT was
added to each well, and incubated with cells at 37 ◦C for 4 h. The for-
mazan crystals were dissolved in 100 mL DMSO each well, and the ab-
sorbency at 490 nm (for absorbance of MTT formazan). All of the
compounds were tested three times in each of the cell lines. The IC50
(inhibitory concentration 50%) value were presented as mean ± stan-
dard deviation (SD).
C
29H20ClF4N5O [M+H]+ 566.1371. found
4.3. Mass spectrometry analysis (MS)
HRMS calculated for
566.1374.
RAS G12C protein was treated with DMSO or a 10-fold molar excess
of compound LLK10 for 2 h at room temperature. Reactions were
directly analyzed by LC-MS.
4.1.6.13. 1-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazin-1-
yl)-2-(trifluoromethyl)prop-2-en-1-one (LLK-10). Yellow oil. Yield: 10%.
1H NMR (400 MHz, CDCl3) δ = 8.79 (s, 1H), 7.96 (d, J = 19.2 Hz, 2H),
7.51–7.43 (m, 1H), 7.37 (t, J = 7.3 Hz, 1H), 7.29 (d, J = 7.5 Hz, 1H),
7.21 (t, J = 9.1 Hz, 1H), 6.14 (s, 1H), 5.76 (s, 1H), 4.00–3.72 (m, 8H).
13C NMR (101 MHz, CDCl3) δ 163.45, 162.95, 154.45, 150.23, 140.38,
131.73, 131.47, 131.17, 131.15, 130.75, 130.67, 124.48, 124.18,
124.14, 123.18, 123.12, 116.78, 115.86, 115.65, 49.52. MS calculated
for C22H17ClF4N4O [M+H]+ 466.1. found 466.4. Purity: 95.26% by
HPLC (tR = 17.584 min).
4.4. ITC and CD analysis
All the proteins were obtained from commercial source: KRAS G12C
(Cat No:CR63) The ITC experiment was performed using a MicroCal
PEAQ-ITC (Malvern Panalytical Ltd., UK), ITC experiments were per-
formed according to the manufacturer’s guidelines. CD spectra were
recorded on a Chirascan plus ACD (Applied Photophysics Ltd, England).
Briefly, KRAS G12C protein were incubated with sterile water or LLK-10
at 25 ◦C for 30 min, the CD wave scans were measured from 180 to 260
nm at 4 ◦C with the band width of 2 nm and the step size of 1 nm.
4.1.6.14. 6-chloro-7-(2-fluorophenyl)-4-(4-(2,2,2-trifluoroethyl)piper-
azin-1-yl)quinazoline (LLK-11). Yellow oil. Yield: 9%.1H NMR (400
MHz, CDCl3) δ 8.78 (s, 1H), 8.01 (s, 1H), 7.92 (s, 1H), 7.47 (t, J = 6.4 Hz,
1H), 7.39 (t, J = 7.4 Hz, 1H), 7.27–7.16 (m, 3H), 3.83–3.61 (m, 10H).
4.5. Immunoblotting
Cells were washed once with 1x phosphate buffered saline (PBS) and
then lysed in RIPA buffer supplemented with protease and phosphatase
inhibitors. Protein concentrations were determined by using the Pierce
BCA protein assay kit. Equal amount of protein was resolved on SDS-
PAGE, and was subsequently transferred onto nitrocellulose mem-
brane. The membrane was blocked with 5%non-fat milk in TBST and
was then incubated with primary antibodies overnight at 4 ◦C with
gentle rotating. After washing, the membrane was incubated with sec-
ondary antibodies for 1 hr at room temperature. The membrane was
then washed and scanned with an Odyssey Infrared scanner (Li-Cor
Biosciences). Primary antibodies include anti-KRAS(Cell Signaling
Technology #SAB1404011), anti-phospho-p44/42 MAPK (Erk1/2) (Cell
Signaling Technology # 9101S), anti- p44/42 MAPK (Erk1/2) (Abacam
#ab178876), anti-phospho-MEK1/2 (Ser217/221) (Cell Signaling
Technology # 9154P), anti-MEK1/2 (abacam #ab178876), and anti-
Tubulin (Cell Signaling Technology # 3873S).
4.1.6.15. 3-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazin-1-
yl)-3-oxopropanenitrile (LLK-12). Yellow oil. Yield: 9%. 1H NMR (400
MHz, CDCl3) δ = 8.80 (s, 1H), 7.99 (s, 1H), 7.94 (s, 1H), 7.50–7.45 (m,
1H), 7.40–7.34 (m, 1H), 7.29 (d, J = 7.5 Hz, 1H), 7.21 (t, J = 9.1 Hz,
1H), 3.95–3.84 (m, 6H), 3.78–3.73 (m, 2H), 3.57 (s, 2H).MS calculated
for C21H17ClFN5O [M+H]+ 411.1. found 411.2
4.1.6.16. 1-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piperazin-1-
yl)prop-2-yn-1-one (LLK-13). Yellow oil. Yield: 5%. Purity: 95.26%.1H
NMR (400 MHz, CDCl3) δ = 8.79 (s, 1H), 7.99 (s, 1H), 7.93 (s, 1H),
7.50–7.44 (m, 1H), 7.40–7.34 (m, 1H), 7.29 (d, J = 7.4 Hz, 1H), 7.21 (t,
J = 9.1 Hz, 1H), 4.05–3.98 (m, 2H), 3.92–3.86 (m, 4H), 3.85–3.80 (m,
2H), 3.00 (s, 1H).13C NMR (101 MHz, CDCl3) δ165.91, 163.66, 163.32,
154.45, 140.34, 133.11, 131.70, 131.60, 131.37, 131.19, 131.16,
130.74, 130.66, 124.55, 124.17, 124.14, 115.88, 115.66, 52.21, 49.66,
49.22, 45.47, 41.82. HRMS calculated for C21H16ClFN4O [M+H]+
395.1080. found 395.1081. Purity: 95.12% by HPLC (tR = 16.411 min).
4.6. Colony formation assay
4.1.6.17. Methyl-4-(4-(6-chloro-7-(2-fluorophenyl)quinazolin-4-yl)piper-
azin-1-yl)-4-oxobut-2-enoate (LLK-14). Yellow oil. Yield: 7%. Purity:
95.12%. 1H NMR (400 MHz, CDCl3) δ = 8.79 (s, 1H), 7.99 (s, 1H), 7.93
(s, 1H), 7.51–7.42 (m, 2H), 7.40–7.33 (m, 1H), 7.29 (d, J = 7.5 Hz, 1H),
7.21 (t, J = 9.0 Hz, 1H), 6.86 (d, J = 15.3 Hz, 1H), 3.97–3.91 (m, 2H),
3.90–3.84 (m, 6H), 3.83 (s, 3H).13C NMR (101 MHz, CDCl3) δ163.42,
154.45, 152.00, 140.38, 131.72, 131.44, 131.19, 131.16, 130.75,
H358 cells (1000 units) were counted and seeded in 6-wells plates for
colony formation assay. Cells were cultured for 24 h at 37 ◦C and then
the media were replaced with media added with LLK-10 at the indicated
concentration. After 24 h treatment, the media were changed to normal
and cells were cultured for 7 days. The colonies were fixed with 4%
paraformaldehyde for 30 min and stained with 0.1% Crystal Violet for
15 min and washed. The colonies were then photographed and counted
8

L. Li et al.
Bioorganic Chemistry 110 (2021) 104825
by the Image J.
References
[1] D.K. Simanshu, D.V. Nissley, F. McCormick, RAS proteins and their regulators in
human disease, Cell 170 (2017) 17–33, https://doi.org/10.1016/j.
cell.2017.06.009.
4.7. Molecular modeling
The molecular modeling studies were performed with Schrodinger
Molecular Modeling Suite 2011 (Schrodinger LLC, New York, NY)
running on a Philips window workstation. The crystal structure of KRAS
G12C complexed with ARS 1620 (PDB:5V9U) was retrieved from the
RCSB Protein Data Bank (http://www.rcsb.Org/pdb). ARS-1620 and
LLK10 was prepared using the Ligprep module, and they were docked
into the SWII site by the covalent docking protocol in the Schrodinger
Suite.
[2] D. Uprety, A.A. Adjei, KRAS: From undruggable to a druggable Cancer Target,
Cancer Treat. Rev. 89 (2020) 102070, https://doi.org/10.1016/j.
ctrv.2020.102070.
[3] J.G. Christensen, P. Olson, T. Briere, C. Wiel, M.O. Bergo, Targeting Krasg12c-
mutant cancer with a mutation-specific inhibitor, J. Intern. Med. 288 (2020)
183–191, https://doi.org/10.1111/joim.v288.210.1111/joim.13057.
[4] A.D. Cox, S.W. Fesik, A.C. Kimmelman, J.i. Luo, C.J. Der, Drugging the
undruggable RAS: Mission Possible? Nat. Rev. Drug Discovery 13 (2014) 828–851,
https://doi.org/10.1038/nrd4389.
[5] H. Adderley, F.H. Blackhall, C.R. Lindsay, KRAS-mutant non-small cell lung cancer:
Converging small molecules and immune checkpoint inhibition, EBioMedicine 41
(2019) 711–716, https://doi.org/10.1016/j.ebiom.2019.02.049.
[6] A. Mullard, K.R.A.S. Cracking, Nat. Rev. Drug Discovery 18 (2019) 887–891,
https://doi.org/10.1038/d41573-019-00195-5.
Declaration of Competing Interest
[7] Y. Wang, C.E. Kaiser, B. Frett, H.-y. Li, Targeting mutant KRAS for anticancer
therapeutics: a review of novel small molecule modulators, J. Med. Chem. 56
(2013) 5219–5230, https://doi.org/10.1021/jm3017706.
The authors declare that they have no known competing financial
interests or personal relationships that could have appeared to influence
the work reported in this paper.
[8] J.M. Ostrem, U. Peters, M.L. Sos, J.A. Wells, K.M. Shokat, K-Ras(G12C) inhibitors
allosterically control GTP affinity and effector interactions, Nature 503 (2013)
548–551, https://doi.org/10.1038/nature12796.
Acknowledgement
[9] M.R. Janes, J. Zhang, L.-S. Li, R. Hansen, U. Peters, X. Guo, Y. Chen, A. Babbar, S.
J. Firdaus, L. Darjania, J. Feng, J.H. Chen, S. Li, S. Li, Y.O. Long, C. Thach, Y. Liu,
A. Zarieh, T. Ely, J.M. Kucharski, L.V. Kessler, T. Wu, K.e. Yu, Y.i. Wang, Y. Yao,
X. Deng, P.P. Zarrinkar, D. Brehmer, D. Dhanak, M.V. Lorenzi, D. Hu-Lowe, M.
P. Patricelli, P. Ren, Y.i. Liu, Targeting KRAS mutant cancers with a covalent G12C-
specific inhibitor, Cell 172 (2018) 578–589.e17, https://doi.org/10.1016/j.
cell.2018.01.006.
This work was supported by scientific research project of high level
talents (No. C1051008) in Southern Medical University of China;
Thousand Youth Talents Program (No. C1080092) from the Organiza-
tion Department of the CPC Central Committee, China; and International
Science and Technology Cooperation Projects of Guangdong Province
(No. G819310411).
[10] C.-U. Lee, T.N. Grossmann, Reversible covalent inhibition of a protein target,
Angew. Chem. Int. Ed. 51 (2012) 8699–8700, https://doi.org/10.1002/anie.
v51.3510.1002/anie.201203341.
[11] S.E. Salmon, Human tumor clonogenic assays: growth conditions and applications,
Cancer Genet Cytogene. 19 (1986) 21–28, https://doi.org/10.1016/0165-4608
(86)90367-5.
Appendix A. Supplementary material
Supplementary data to this article can be found online at https://doi.
org/10.1016/j.bioorg.2021.104825.
9
