The new convenient synthesis of 6-fluoropurine and its 7-/9-unsubstituted analogues

Article abstract of DOI:10.3987/COM-12-12583

6-Fluoropurine and its 7-/9-unsubstituted analogues have good biological activity and serve as important pharmaceutical intermediates. This paper describes a new and convenient synthesis of 6-fluoropurine and its 7-/9-unsubstituted analogues, by first replacing the chlorine atoms with trimethylammonio groups through the reaction of 6-chloropurine and its 7-/9-unsubstituted analogues with trimethylamine, and then replacing the trimethylammonio groups with fluorine atoms using safe and cheap TBAF·3H₂O as fluorinating agent at room temperature. Compared with reported methods, the new synthesis has milder conditions, shorter reaction times, simpler post-processing and higher (or similar) yields.

Full text of DOI:10.3987/COM-12-12583

HETEROCYCLES, Vol. 85, No. 12, 2012
2999
HETEROCYCLES, Vol. 85, No. 12, 2012, pp. 2999 - 3006. © 2012 The Japan Institute of Heterocyclic Chemistry
Received, 10th September, 2012, Accepted, 5th October, 2012, Published online, 12th October, 2012
DOI: 10.3987/COM-12-12583
THE NEW CONVENIENT SYNTHESIS OF 6-FLUOROPURINE AND
ITS 7-/9-UNSUBSTITUTED ANALOGUES
Mei Deng, Ningyu Wang, Guangming Xiang, and Luoting Yu*
State Key Laboratory of Biotherapy, West China Hospital, West China Medical
School,
Sichuan
University,
Chengdu
610041,
China;
E-mail:
yuluot@scu.edu.cn
Abstract – 6-Fluoropurine and its 7-/9-unsubstituted analogues have good
biological activity and serve as important pharmaceutical intermediates. This
paper describes a new and convenient synthesis of 6-fluoropurine and its
7-/9-unsubstituted analogues, by first replacing the chlorine atoms with
trimethylammonio groups through the reaction of 6-chloropurine and its
7-/9-unsubstituted analogues with trimethylamine, and then replacing the
trimethylammonio groups with fluorine atoms using safe and cheap TBAF·3H2O
as fluorinating agent at room temperature. Compared with reported methods, the
new synthesis has milder conditions, shorter reaction times, simpler
post-processing and higher (or similar) yields.
6-Fluoropurine and its 7-/9-unsubstituted analogues have good biological activity and serve as important
pharmaceutical intermediates.1,2 Purines are integral parts of DNA and RNA. Purine analogues are a
very important class of nucleoside pharmaceutical intermediates and have special effect on cancer, AIDS,
leukemia and others.3-9 Fluorine-substituted compounds such as Fludarabine, show remarkable
differences in biological activities and pharmacological properties compared to their parent molecules,
as introduction of fluorine can improve the metabolic stability, modulate the physicochemical properties
and increase binding affinity to a target protein.10,11
According to the literature,12-16 6-fluoropurine and its 7-/9-unsubstituted analogues can be obtained by
the following methods: (i) 6-chloropurine and its 7-/9-unsubstituted analogues react with dry potassium

3000
HETEROCYCLES, Vol. 85, No. 12, 2012
fluoride in dry DMSO at 180 ˚C using tetraphenylphosphonium bromide as phase transfer catalyst; (ii)
6-chloropurine and its 7-/9-unsubstituted analogues react with dry potassium fluoride under microwave
using ionic liquid as solvent; (iii) a modified Schiemann Reaction on an aminopurine in which the
diazotization product is treated with fluoroboric acid; (iv) displacement of trimethylammonio groups
formed by the reaction of 6-chloropurine and its 7-/9-unsubstituted analogues with trimethylamine, on
treatment with hydrogen potassium fluoride; (v) fluorination of 6-chloropurine and its 7-/9-unsubstituted
analogues using "anhydrous" tetrabutylammonium fluoride (TBAFanh) in anhydrous DMSO at 20 ˚C.
But all the five methods have disadvantages: methods (i) and (ii) need high temperatures, and ionic
liquid used in method (ii) is hard to get; method (iii) gives low yields and needs harsh reaction
conditions; method (iv) uses hydrogen potassium fluoride which is corrosive, giving poor yields of
products (6-fluoropurine, 35% and 2-chloro-6-fluoropurine, 32%) and considerable amounts of
byproducts, and sometimes the reaction should be heated (6-fluoropurine, 60 ˚C); method (v) requires
long reaction times (6-fluoropurine, 14 days) ending up with low yields (6-fluoropurine, 65%), and high
vacuum (<0.1 mmHg) demanded in the preparation of TBAFanh is difficulty to achieve.
In order to find a new convenient synthesis of 6-fluoropurine and its 7-/9-unsubstituted analogues, we
first analyzed the causes leading to the long reaction times and low yields in method (v) which has the
mildest reaction conditions in the five methods. It was found that TBAFanh behaves not only as a good
source of nucleophilic fluoride but also a strong base and hydrolyzing agent,17 and it deprotonates
6-fluoropurine and its 7- or 9-unsubstituted analogues, generating an equivalent of bifluoride ion16 and
resulting in some degree of deactivation of the reactants.
It was reported that safe, commercially available and cheap trihydrate tetrabutylammonium fluoride
(TBAF·3H2O) is a powerful, nonbasic and nucleophilic fluorinating agent,17 but it could not fluorinate
6-chloropurine and its 7-/9-unsubstituted analogues (1a-1c), because of its weaker nucleophilicity of
fluoride ion than that in TBAFanh. To solve the problem, we first replaced the chlorine atoms with
trimethylammonio groups which are better leaving groups, through the reaction of 6-chloropurine and its
7-/9-unsubstituted analogues (1a-1c) with aqueous solution of trimethylamine15,18 in high yields (see
Table 1), and then replaced the trimethylammonio groups with fluorine atoms using TBAF·3H2O as
fluorinating agent (see Table 2).

HETEROCYCLES, Vol. 85, No. 12, 2012
3001
Table 1. Replacement of the chlorine atoms in 6-chloropurine and its 7-/9-unsubstituted analogues
(1a-1c) with trimethylammonio groups
Product
2a
R
X
N
N
C
Yield(%)b
H
Cl
H
90
90
90
2b
2c
art = 30 ˚C. bisolated yields.
Table 2. Preparation of 6-fluoropurine and its 7-/9-unsubstituted analogues (3a-3c)
Temp.
Time
(day)
Yield
(%)b
Byproduct
(%)c
Equiv.
Entry
Product
Solvent
4
(˚C)a
of 4
1
TBAF·3H2O
TBAF·3H2O
1.5
3
DMSO
DMSO
rt
rt
1
1
18.0
24.6
0
0
3a
2
3a

3002
HETEROCYCLES, Vol. 85, No. 12, 2012
3
TBAF·3H2O
TBAF·3H2O
TBAF·3H2O
TBAF·3H2O
TBAF·3H2O
KF·2H2O
4
3
3
3
3
3
3
3
3
3
3
DMSO
DMF
rt
rt
rt
rt
50
rt
rt
rt
rt
rt
rt
1
1
24.7
18.8
18.9
8.0
0
0
3a
3a
3a
3a
3a
3a
3a
3a
3a
3b
3c
4
5
THF
1
0
6
EtOH
1
4.0
10.0
1.1
0
7
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
DMSO
1
13.7
2.8
8
1
9
TBAF·3H2O
TBAF·3H2O
TBAF·3H2O
TBAF·3H2O
TBAF·3H2O
4
53.5
71.3
80.0
90.0
91.0
10
11
12
13
7
0
14
0.5
0.5
3.8
0
0
art = 30 ˚C. b,cdetermined by HPLC analysis.
In order to find the optimized reaction conditions we first studied the preparation of 6-fluoropurine 3a
from 2a. The results showed that 3a was produced in a good yield of 71.3% with no byproduct within 7
days using 3 equivalents of TBAF·3H2O as fluorinating agent in DMSO at room temperature (Entry 10).
And the overall yield of 3a (64.2%, Entry 10) was similar with that in method (v) (65%) but with a
shorter reaction time (7.5 days vs 14 days) and less fluorinating agent (3 eq vs 4 eq).16 In fact, our
method will save more time. Because the preparation of TBAFanh needs 2 days under high vacuum (<0.1
mmHg)16 which is hard to achieve, whereas TBAF·3H2O is commercially available and cheap. When
the reaction time prolonged to 14 days (Entry 11), the yield of 3a increased to 80.0% and 3.8%
byproduct was generated，probably by the hydrolysis of 3a. 3a was achieved in a better yield in DMSO
than in DMF, THF and EtOH (Entries 2 and 4-6), and in a higher yield with TBAF·3H2O than with
KF·2H2O (Entries 2 and 8), because of the good solubility of TBAF·3H2O in DMSO. The reaction in

HETEROCYCLES, Vol. 85, No. 12, 2012
3003
EtOH (Entry 6) gave a significant amount of byproduct, maybe because of EtOH also reacting with 2a.
When the temperature raised up to 50 ˚C (Entry 7), the reaction afforded 3a in a reduced yield and
byproduct in a considerable yield. And it was probably because of that 2a started to decompose, water
reacted with 2a and the hydrolysis of 3a was enhanced at 50 ˚C.
Then, we investigated the preparation of its 7-/9-unsubstituted analogues 3b and 3c, respectively.
Compared with 3a in Entry 10, 3b and 3c (Entries 12 and 13) were produced in better yields (90.0% and
91.0%), together with no byproducts within shorter reaction time (0.5 day) under the same reaction
conditions, probably due to that the R = Cl in 2b and X = C in 2c (Table 2) increased the electrophilicity
of the carbon atoms connecting to the trimethylammonio groups. We verified our point by the
preparation of 6-fluoro-9H-purin-2-amine from 6-chloro-9H-purin-2-amine (Table 1, R = NH2, X = N)
through our route, ending up with a high yield of intermediate and no product. The overall yields of 3b
and 3c in our report (Entries 12 and 13) were remarkably higher than reported. Because Entries 10, 12
and 13 produced no byproducts, the post-processing was simpler.
In conclusion, this paper described a new and convenient syntheses of 6-fluoropurine and its
7-/9-unsubstituted analogues, in which we first replaced the chlorine atoms with trimethylammonio
groups which are better leaving groups, through the reaction of 6-chloropurine and its 7-/9-unsubstituted
analogues with aqueous solution of trimethylamine, and then replaced the trimethylammonio groups
with fluorine atoms using safe, commercially available and cheap TBAF·3H2O as fluorinating agent in
DMSO at room temperature. The new method has advantages of milder conditions (compared with
methods (i)-(v)), shorter reaction times (compared with method (v)), simpler post-processing (compared
with methods (i)-(v)) and similar to higher yields (compared with methods (i)-(v)) compared with the
reported methods.
EXPERIMENTAL
The melting points were obtained on a SGW X-4 microscopic melting point apparatus and were
1
13
uncorrected. IR spectra were determined with a Bruker Tensor 27 spectrophotometer. The H and C
NMR spectra were determined in DMSO-d6 using TMS as an internal reference with a Bruker AscendTM
400 NMR spectrometer operating at 400 MHz and 100 MHz, respectively. Low-resolution MS spectra
(ESI) were measured by a Waters Quattro Premier XE spectrometer. High-resolution MS spectra (ESI)
were measured by a Waters Q-TOF Premier spectrometer. TLC was carried out on TLC silica gel 60

3004
HETEROCYCLES, Vol. 85, No. 12, 2012
F254 plates. Column chromatography was performed using silica gel (300-400 mesh, Qingdao Marine
Chemical Ltd., Qingdao, China). HPLC was carried out on Agela Technologies LC-10F. All the
commercially available reagents were used without further purification.
General Procedure for the Preparation of 2. To a solution of 1 (10 mmol) in THF (3 mL) at rt was
slowly added 33% trimethylamine water solution (~3 mL, 30 mmol). When TLC (eluent: EtOAc)
monitoring indicated that the reaction was completed (ca. 0.5 day) the crystalline precipitate was washed
with ether and recrystallized from aqueous acetone (rt) giving 2.
N,N,N-Trimethyl-9H-purin-6-aminium chloride (2a): a pale-yellow solid; yield 90%; mp 201.5-202.5
˚C (decomp.) (lit.,15 191-193 ˚C (decomp.)); IR (KBr) 1617, 1578 cm-1; 1H NMR δ 14.70 (s, 1H), 9.06 (s,
13
1H), 8.97 (s, 1H), 3.84 (s, 9H); C NMR δ 156.6, 151.5, 150.4, 147.5, 123.3, 54.2; MS (ESI) m/z 178
[M-Cl]+. HRMS (ESI) Calcd for C8H12N5 [M-Cl]+: 178.1093; Found: 178.1092.
2-Chloro-N,N,N-trimethyl-9H-purin-6-aminium chloride (2b): a pale-yellow solid; yield 90%; mp >
300 ˚C (lit.,15 > 300 ˚C); IR (KBr) 1612, 1561 cm-1; 1H NMR δ 14.88 (s, 1H), 8.98 (s, 1H), 3.81 (s, 9H);
13C NMR δ 154.5, 152.3, 152.1, 138.4, 117.9, 54.4; MS (ESI) m/z 212 [M-Cl]+. HRMS (ESI) Calcd for
C8H11N5Cl [M-Cl]+: 212.0703; Found: 212.0702.
N,N,N-Trimethyl-7H-pyrrolo[2,3-d]pyrimidin-4-aminium chloride (2c): a white solid; yield 90%,
mp 191.2-192.2 ˚C; IR (KBr) 1604, 1565 cm-1; 1H NMR δ 13.21 (s, 1H), 8.89 (s, 1H), 8.00 (d, 1H, J =
3.4 Hz), 7.22 (d, 1H, J =3.4 Hz), 3.76 (s, 9H); 13C NMR δ 155.1, 154.7, 148.7, 130.4, 107.2, 99.6, 54.2.
MS (ESI) m/z 177 [M-Cl]+. HRMS (ESI) Calcd for C9H13N4 [M-Cl]+: 177.1140; Found: 177.1141.
General Procedure for the Preparation of 3. As indicated in Table 2, to a solution of 2 (1.2 mmol) in
solvent (3 mL) at the temperature was added fluorinating agent. The reaction was maintained at that
temperature for the time indicated in Table 2 and was monitored by HPLC. When the reaction was
terminated, add water (30 mL) into the reaction mixture and extract it with EtOAc five times (10 mL
each). The combined extracts were washed with water and brine and dried over anhydrous magnesium
sulfate. After filtration, the solvent was removed in vacuum. In Entries 6, 7, 8 and 11, the residue was
purified by silica gel column chromatography.
6-Fluoro-9H-purine (3a): a white solid; mp 125.5-126.6 ˚C (lit.,13 122-124 ˚C); IR (KBr) 1634, 1578
cm-1; 1H NMR δ 13.98 (s, 1H), 8.68 (s, 1H), 8.65 (s, 1H); 13C NMR δ 158.4 (J = 214.7 Hz), 151.1, 151.0,
145.7, 118.7; MS (ESI) m/z 137 [M-H]-. HRMS (ESI) Calcd for C5H4N4F [M+H]+: 139.0420; Found:
139.0422.

HETEROCYCLES, Vol. 85, No. 12, 2012
3005
2-Chloro-6-fluoro-9H-purine (3b): a white solid; mp 146.0-148.2 ˚C (lit.,15 146 ˚C); IR (KBr) 1656,
1634, 1565 cm-1; 1H NMR δ 14.01 (s, 1H), 8.72 (s, 1H); 13C NMR δ 157.8 (J = 207.1 Hz), 149.9, 149.8,
146.9, 117.8; MS (ESI) m/z 171 [M-H]-. HRMS (ESI) Calcd for C5H3N4FCl [M+H]+: 173.0030; Found:
173.0029.
4-Fluoro-7H-pyrrolo[2,3-d]pyrimidine (3c): a white solid; mp 172.8-173.8 ˚C; IR (KBr) 1629, 1594,
1576 cm-1; 1H NMR δ 12.61 (s, 1H), 8.49 (s, 1H), 7.66 (d, 1H, J = 3.0 Hz), 6.66 (d, 1H, J = 3.0 Hz). 13C
NMR δ 161.4 (J = 197.8 Hz), 155.5 (J = 9.9 Hz), 149.8 (J = 11.1 Hz), 127.5, 103.1 (J = 26.2 Hz), 96.9
(J = 4.1 Hz); MS (ESI) m/z 136 [M-H]-. HRMS (ESI) Calcd for C6H5N3F [M+H]+: 138.0468; Found:
138.0465.
ACKNOWLEDGEMENT
This work was supported by National Science and Technology Major Project of China
(2012ZX09103101079). We thank Mr Ming-Hai Tang of this lab for determining both low- and
high-resolution mass spectra and thank Analytical & Testing Center of Sichuan University for
determining infrared spectroscopy.
REFERENCES
1. J.-Q. Liu and M. J. Robins, J. Am. Chem. Soc., 2007, 129, 5962.
2. T. Shirasaka, K. M. Happy-Ford, and J. Kelly, Proc. Natl. Acad. Sci. U.S.A., 1990, 87, 9426.
3. A. Van-Aerschot, M. Petros, and A. Piet, J. Med. Chem., 1993, 36, 2938.
4. K. G. Estep and K. A. Josef, J. Med. Chem., 1995, 38, 2582.
5. X.-Y. Luo, H. X. S. J., 2001, 23, 184.
6. J. Xu, Chinese J. New Drugs, 1992, 1, 63.
7. L. Zhang, Y.-Q. Chen, G.-Q. Qian, H.-H. Wu, L.-Y. Dai, and L.-P. Yang, Chinese J. Pharm., 1999, 30,
93.
8. A. Graul and P. A. Leeson, Drugs Fut., 1998, 23, 1155.
9. Farina and Paolo, EP: 1464708A1.
10. H. J. Böhm, D. Banner, S. Bendels, M. Kansy, B. Kuhn, K. Müler, U. Obst-Sander, and M. Stahl,
Chem. Biol. Chem., 2004, 5, 637.
11. W. R. Dolbier Jr., J. Fluorine Chem., 2005, 126, 157.

3006
HETEROCYCLES, Vol. 85, No. 12, 2012
12. H.-F. Lu, G.-F. Han, and M. Lu, Chinese J. Org. Chem., 2008, 28, 1462.
13. S.-H. Xu and P. Yao, H. X. S. J., 2010, 32, 862.
14. J. A. Montgomery and K. Hewson, J. Org. Chem., 1969, 34, 1396.
15. J. Kiburis and J. H. Lister, J. Chem. Soc. (C), 1971, 3942.
16. H.-R. Sun and S. G. DiMagno, Angew. Chem. Int. Ed., 2006, 45, 2720.
17. D. Albanese, D. Landini, and M. Penso, J. Org. Chem., 1998, 63, 9587.
18. H.-C. Cai, D.-Z. Yin, L. Zhang, and Y.-X. Wang, J. Fluorine Chem., 2006, 127, 837.
