KF/Al2O3 catalyzed one-pot three-component process for the synthesis of some 2-thioxoquinazolin-4(1h)-one derivatives

Article abstract of DOI:10.14233/ajchem.2013.14214

Three component one-pot reaction for synthesis of 2-thioxoquinazolin-4(1H)- ones are given by the condensation of isatoic anhydride, primary amine and phenyl isothiocyanate by using KF/Al2O3 as a environmentally friendly catalyst.

Full text of DOI:10.14233/ajchem.2013.14214

Asian Journal of Chemistry; Vol. 25, No. 11 (2013), 5975-5977
http://dx.doi.org/10.14233/ajchem.2013.14214
KF/Al2O3 Catalyzed One-Pot Three-Component Process for the
Synthesis of Some 2-Thioxoquinazolin-4(1H)-one Derivatives
*
FARHAD HATAMJAFARI, FARZAD ALIJANICHAKOLI and MOHAMMADJAVAD MOHAMMADMOHTASHAM
Department of Chemistry, Faculty of Science, Tonekabon Branch, Islamic Azad University, Tonekabon, Iran
*Corresponding author: E-mail: farzadalijanichakoli@yahoo.com
(Received: 19 June 2012;
Accepted: 22 April 2013)
AJC-13381
Three component one-pot reaction for synthesis of 2-thioxoquinazolin-4(1H)-ones are given by the condensation of isatoic anhydride,
primary amine and phenyl isothiocyanate by using KF/Al2O3 as a environmentally friendly catalyst.
Key Words: 2-Thioxoquinazolin-4(1H)-one, One-pot, Three component, KF/Al2O3, Microwave.
O
O
INTRODUCTION
R2
N
O
KF/Al2O3,
Ph NCS
Today multicomponent reactions (MCRs) emphasizes the
development of organic compounds as drug precursor on
environmentally friendly when synthesized compounds
without solvent and catalyst or water solvent and non-toxic
catalyst. Multicomponent reactions aid to play a key role in
the development of synthetic compounds because of their
possible generation of an adduct in a single step from multi
reactants usually used by bond-forming efficiency1. Applica-
tion of multicomponent reaction is on the high chemoselectivity
in the presence of all the reactants2.
+
R2
NH2
N
H
S
N
H
O
R1
R1
Scheme-I
IR spectral data of 3-benzyl-2,3-dihydro-2-thioxoquina-
zoline-4(1H)-one (4b) shows the characteristic single broad
N-H peak in the range 3280 cm-1, a sharp C=O peak at 1698
cm-1 and C=S peak at 1185 cm-1. 1H NMR shows characteristic
broad singlet for N-H at δ 12.01 in addition to those due to
aromatic protons at d 7.33-7.86 ppm13. In 13C NMR C=S appears
at δ 170 C=O appears at δ 161 ppm. Therefore in the present
investigation we have used KF/Al2O3 is a widely used solid
supported reagent which is cheap and easy for catalysis of a variety
of reactions. Due to its strongly basic nature it has been used as
a replacement for organic bases in a number of organic reactions18.
Variously substituted isothiocyanates were condensed isatoic
anhydride, primary amine and phenyl isothiocyanate in water
by using KF/Al2O3 as a environmentally friendly catalyst to
afford the desired 2-thioxoquinazolin-4(1H)-one derivatives in
60-79 % yields and was completed within 90-140 min (Table-1).
All chemicals were obtained from Merck or Fluka without
further purification. Melting points were determined on an
Electrothermal 9100 melting point apparatus and are uncor-
rected. IR spectra were measured on a Shimadzu IR-470
spectrophotometer. 1H and 13C NMR spectra were determined
on Bruker 500 DRXAVANCE instrument at 500 and 125 MHz,
respectively. The element analyses (C, H, N) were obtained
from a Carlo ERBA Model EA 1108 analyzer carried out on
Perkin-Elmer 240c analyzer.
Quinazolinones are very important structure in the field
of drug chemistry with wide range of biological and pharma-
cological activity3. The quinazolinones scaffold are important
class of fused heterocycles with a show promise such as anti-
inflammatory4, antimalarial5, anti HIV6 and anti cancer7 and
dihydrofolate reductase inhibitors8. Moreover, few methods
are reported for the synthesis of 2-thioxoquinazolin-4-ones,
as most of the methods reported are for quinazolin-2,4(1H,3H)-
diones9,10
.
Several methods have been proposed for quinazolinones
over the years, provide a simple method with the environ-
mentally friendly catalyst for synthesis of 2-thioxo-
quinazolinones. As part of our ongoing interest in
developing new methods for the synthesis of various
heterocyclic scaffolds11-17, therefore in this study, we have
synthesized derivatives of 2-thioxoquinazolin-4(1H)-one
with the condensation of isatoic anhydride, primary amine
and phenyl isothiocyanate by using KF/Al2O3 as a catalyst
(Scheme-I).

5976 Hatamjafari et al.
Asian J. Chem.
TABLE-1
SYNTHESIS OF VARIOUS 2-THIOXOQUINAZOLIN-4(1H)-ONES FROM DIFFERENT
ISATOIC ANHYDRIDE, PRIMARY AMINE AND ISOTHIOCYANATE
Entry
R1
R2–NH2
m.p. (ºC)
Yields (%)
Reaction time (min)
100
NH2
H
307-309
76
4a
NH2
H
meta-Cl
H
253-256
324-325
264-266
70
65
60
120
120
140
4b
4c
4d
NH2
Cl
H
317-319
76
90
4e
NH2
Typical synthesis of compounds (4a-e): A mixture of
KF/Al2O3 (0.2 g), isatoic anhydride (1 mmol), primary amine
(2 mmol) and phenyl isothiocyanate (1 mmol) was refluxed
in ethanol (5 mL) for 90-140 min. The progress of reaction
was monitored by TLC. The mixture was extracted with 3 cm
× 30 cm CH2Cl2, filtered and dried with anh. Na2SO4 sulphate.
The solution was dried under high vacuum and the resulting
solid residue recrystallized from ethanol to give the pure crysta-
lline solid (4a-e).
νmax, cm-1): 3291 (N-H), 3036 (C-Harom), 1677 (C=O), 1179
(C=S); 1H NMR (500 MHz, DMSO): δ = 1.79 (d, J = 7.1 Hz,
3H), 2.02 (q, J = 7.1 Hz, H), 7.15-7.82 (m, 9H , CHarom), 11.96
(s, 1H, NH); 13C NMR (125 MHz, DMSO): 27.7, 46.5, 58.2,
113.8, 114.5, 115.8, 118.6, 121.9, 125.6, 128.5, 132.4, 134.9,
138.0, 145.4, 147.3, 160.1, 171.9, ppm. MS (m/z, %): 282
(M+). Anal. calcd. (%) for C16H14N2OS: C, 68.06; H, 5.00; N,
9.92. Found (%): C, 67.81; H, 4.76; N, 9.71.
3-(4-Chlorobenzyl)-2,3-dihydro-2-thioxoquinazolin-
4(1H)-one (4e): White powder, m.p. 317-319 ºC; IR (KBr,
νmax, cm-1): 3122 (N-H), 3032 (C-Harom), 1681 (C=O), 1209
(C=S); 1H NMR (500 MHz, DMSO): δ = 5.16 (s, 2H), 7.16-
7.79 (m, 8H , CHarom), 12.02 (s, 1H, NH); 13C NMR (125 MHz,
DMSO): 46.4, 115.8, 122.4, 125.0, 126.7, 127.7, 130.6, 133.2,
134.5, 140.8, 145.8, 157.1, 172.3 ppm. MS (m/z, %): 302 (M+).
Anal. calcd. (%) for C15H11N2OSCl: C, 59.50; H, 3.66; N, 9.25.
Found (%): C, 59.33; H, 3.50; N, 9.18.
2,3-Dihydro-3-phenyl-2-thioxoquinazolin-4(1H)-one
(4a): White powder, m.p. 307-309 ºC; IR (KBr, νmax, cm-1):
1
3239 (N-H), 3091 (C-Harom), 1676 (C=O), 1189 (C=S); H
NMR (500 MHz, DMSO): δ = 7.29-7.96 (m, 9H , CHarom),
12.03 (s, 1H, NH); 13C NMR (125 MHz, DMSO): 118.6, 119.1,
121.3, 124.6, 125.0, 128.8, 129.9, 132.8, 137.1, 138.6, 158.8,
177.0 ppm. MS (m/z, %): 254 (M+). Anal. calcd. (%) for
C14H10N2OS: C, 66.12; H, 3.96; N, 11.02. Found (%): C, 65.71;
H, 3.81; N, 10.74.
Conclusion
3-Benzyl-2,3-dihydro-2-thioxoquinazolin-4(1H)-one
(4b): White powder, m.p. 253-256 ºC; IR (KBr, νmax, cm-1):
We have developed an efficient, one-pot synthesis of
2-thioxoquinazolin-4(1H)-ones by the condensation of isatoic
anhydride, primary amine and phenyl isothiocyanate by using
KF/Al2O3 in providing increased yields. KF/Al2O3 can act as
heterogeneous catalyst which is low cost and environmentally
friendly.
1
3280 (N-H), 3080 (C-Harom), 1698 (C=O), 1185 (C=S); H
NMR (500 MHz, DMSO): δ = 5.59 (s, 2H), 7.33-7.86 (m, 8H,
CHarom), 12.01 (s, 1H, NH); 13C NMR (125 MHz, DMSO):
44.8, 111.5, 114.4, 122.8, 125.1, 126.7, 127.8, 128.9, 134.1,
135.7, 138.1, 161.0, 170.0 ppm. MS (m/z, %): 268 (M+).Anal.
calcd. (%) for C15H12N2OS: C, 67.14; H, 4.51; N, 10.44. Found
(%): C, 66.89; H, 4.21; N, 10.26.
ACKNOWLEDGEMENTS
The authors gratefully acknowledged the financial support
from the Research Council of Tonekabon Branch IslamicAzad
University, Iran.
7-Chloro-2,3-dihydro-3-phenyl-2-thioxoquinazolin-
4(1H)-one (4c): White powder, m.p. 324-326 ºC; IR (KBr,
νmax, cm-1): 3188 (N-H), 3010 (C-Harom), 1700 (C=O), 1200
(C=S); 1H NMR (500 MHz, DMSO): δ = 7.30-7.92 (m, 8H,
CHarom), 12.06 (s, 1H, NH); 13C NMR (125 MHz, DMSO):
20.1, 55.5, 113.1, 115.2, 123.9, 124.2, 125.7, 126.5, 129.2,
131.9, 135.6, 138.8, 153.7, 169.3 ppm. MS (m/z, %): 288 (M+).
Anal. calcd. (%) for C14H9N2OSCl: C, 58.23; H, 3.14; N, 9.70.
Found (%): C, 57.95; H, 2.85; N, 9.58.
REFERENCES
1. K.C. Nicolaou, D.J. Edmonds and P.G. Bulger, Angew. Chem. Int. Ed.,
45, 7134 (2006).
2. F. Hatamjafari and N. Montazeri, Turkish J. Chem., 33, 797 (2009).
3. G.P. Ellis, Synthesis of Fused Heterocycles., John Wiley & Sons, Ltd.:
Chichester, 47 (1987).
2,3-Dihydro-3-(1-phenylethyl)-2-thioxoquinazolin-
4(1H)-one (4d): White powder, m.p. 264-266 ºC; IR (KBr,
4. K. Tereshima, H. Shimamura, A. Kawase, Y. Tanaka, T. Tanimura, T.
Kamisaki, Y. Ishizuka and M. Sato, Chem. Pharm. Bull., 45, 2021
(1995).

Vol. 25, No. 11 (2013)
KF/Al2O3 Catalyzed One-Pot Three-Component Synthesis of 2-Thioxoquinazolin-4(1H)-one Derivatives 5977
5. D. Gueyrard, V. Gurnel, O. Leoni, S. Palmieri and P. Rollin, Heterocycles,
32, 827 (2000).
12. J.Azizian, M. Shaabanzadeh, F. Hatamjafari and M.R. Mohammadizadeh,
Arkivoc, 47 (2006).
6. S.N. Pandeya, D. Sriram, G. Nath and E. Declerca, Pharm. Acta Helv.,
74, 11 (1999).
13. F. Hatamjafari, Synth. Commun., 36, 3563 (2006).
14. J. Azizian, F. Hatamjafari and A.R. Karimi, J. Heterocycl. Chem., 43,
1349 (2006).
7. J.F. Wolfe, T.L. Rathman, M.C. Sleevi, J.S.A. Campbell and T.D. Green-
wood, J. Med. Chem., 33, 161 (1990).
15. F. Hatamjafari, N. Montazeri and K. Pourshamsian, Asian J. Chem.,
23, 3287 (2011).
8. A. Rosowsky, C.E. Mota, J.E. Wright and S.F. Queener, J. Med. Chem.,
37, 4522 (1994).
16. F. Hatamjafari, Orient. J. Chem., 28, 141 (2012).
17. F. Hatamjafari, Asian J. Chem., 25, 2339 (2013).
18. B.E. Blass, Tetrahedron, 58, 9301 (2002).
9. N.D. Moirangthem and W.S. Laitonjam, Beilstein J. Org. Chem., 6,
1056 (2010).
10. A. Saeed and U. Flörke, Crystals, 1, 254 (2011).
11. J. Azizian, F. Hatamjafari, A.R. Karimi and M. Shaabanzadeh, Synthesis,
765 (2006).
