2. Experimental details
The nanocomposites were synthesized by first mixing the
raw materials inside an argon filled glove box. The mix-
tures were then milled in a Spex 8000 model shaker mill
using a vial and balls made of stainless steel, with a ball to
powder weight ratio of 8:1. Magnesium hydride from Th.
Goldschmidt (95 wt.% MgH2, 5 wt.% Mg), calcium (Alfa,
98.8%), and CaH2 powder (Aldrich, 95%) were used. In an
earlier work on ball-milled magnesium hydride, it was found
that the milled powder contains a significant (8 wt.%) frac-
tion of magnesium oxide [9]. Because this oxide does not
participate in the hydrolysis reaction, it was subtracted in all
calculations of the theoretical yields of the reaction.
The hydrolysis reactions were carried out in a 1 l glass re-
actor with four openings used for hydrogen exhaust, water
addition, thermometer, and purge gas. Water addition was
made using a 250 ml ampoule provided with a bypass duct
to prevent gas flow during water addition. The exhaust gas
was flown through a condenser followed by drierite in or-
der to remove all water vapors. The dry hydrogen gas was
then directed to a flow meter (ADM 2000, Agilent Tech-
nologies) where the flow was measured. In each experiment,
a mass of about 250 mg of nanocomposite was loaded into
the flask and allowed to react with 100 ml of deionized wa-
ter. The water addition was performed at t = 1 min in order
to establish a background reading of the flow meter. This
background (≈0.29 ml min−1) was subsequently subtracted
from the raw data. For all measurements, a magnetic stirrer
was used to continuously stir the mixture. In order to eas-
ily compare the different measurements, hydrogen releases
is given as reacted fraction, F, defined as the ratio of the
volume of released hydrogen over the theoretical volume of
hydrogen that should be released assuming that all material
is hydrolyzed. For each experiment, the mass of reactant is
250 5 mg and water volume is 100 ml.
The pH was measured with a pH meter from VWR Scien-
tific model 2000, using an Accumet 13-620-108 electrode.
The specific surface area was measured with an Autosorb 1
gas sorption system from Corporation Quantachrome using
the BET method with nitrogen gas.
X-ray powder diffraction was carried out on a Bruker AXS
D8 diffractometer using Cu K␣ radiation. Crystallite size of
magnesium hydride was evaluated using TOPAZ 2 software
to fit the (1 1 0) peak of magnesium hydride.
Fig. 1. Hydrogen released during hydrolysis of (A) polycrystalline MgH2,
(B) MgH2 milled 10 h, MgH2–X mol% Ca nanocomposite milled 10 h
with (C) X = 4.7 mol%, (D) X = 8.9 mol%, (E) X = 20.3 mol%, and
(F) pre-milled MgH2–20.3 mol% Ca milled 10 h.
this first step is given by examination of the pure MgH2
curves. In this case, the reaction stops after about 1 min.
Independent measurements of the solution pH show that it
reaches 10.5 in the first few minutes of hydrolysis. From
the potential–pH equilibrium diagram, the concentration
of the soluble species (Mg2+) of reaction (1) is only 10−4
molar at pH 10.5 [10]. Therefore, after only 1 min of hy-
drolysis, the pH of the solution is already high enough
to reduce the solubility of Mg2+ to negligible value. This
may explain the sudden stop of the initial burst of the re-
action, as the formation of insoluble magnesium hydroxide
at the surface of the grains will prevent the solution from
reaching un-reacted MgH2. There is almost twice as much
hydrogen liberated from MgH2 milled during 10 h com-
pared to polycrystalline MgH2. This most probably arises
as a consequence of the former material having a higher
effective surface area than the later one (9.7 and 1.2 m2 g−1
respectively).
,
With calcium addition, the fast initial step is followed by
a constant hydrogen flow regime and the reacted fraction
increases with time. In this regime, the calcium addition al-
lows a sustained reaction of magnesium hydride, thus giv-
ing a faster kinetics and higher yield. From Fig. 1, we could
see that the second slope is proportional to the calcium con-
tent, with higher calcium proportion producing higher flow
rates and higher yield. However, at the highest calcium con-
tents (8.9 and 20.3 wt.%), a third regime appears where the
flow rate seems to be inversely proportional to the calcium
content and the reacted fraction seems to level off. More-
over, the inflexion point, where the hydrogen release curve
switches from the second to the third regime, is appearing
sooner for higher calcium proportion. For calcium content
of 8.9 and 20.3 mol%, the inflexion points are estimated to
be 50 and 35 min, respectively. The curve with 4.7 mol% Ca
does not show the third regime.
