RESEARCH ARTICLE
The Toluene o-Xylene Monooxygenase
Enzymatic Activity for the Biosynthesis of
Aromatic Antioxidants
1
☯
1☯
1
1
Giuliana Donadio , Carmen Sarcinelli , Elio Pizzo , Eugenio Notomista ,
2
3
1
1
Alessandro Pezzella , Carlo Di Cristo , Federica De Lise , Alberto Di Donato ,
1
,4
Viviana Izzo
*
1
Department of Biology, University of Naples Federico II, Via Cinthia I, 80126, Napoli, Italy, 2 Department of
Chemical Sciences, University of Naples Federico II, via Cinthia I, 80126, Napoli, Italy, 3 Department of
Sciences and Technologies, University of Sannio, Via Port'Arsa, 11, Benevento, Italy, 4 Department of
Medicine and Surgery, University of Salerno, via S. Allende, 84081, Baronissi (SA), Italy
☯
These authors contributed equally to this work.
vizzo@unisa.it
*
Abstract
OPEN ACCESS
Monocyclic phenols and catechols are important antioxidant compounds for the food and
pharmaceutic industries; their production through biotransformation of low-added value
starting compounds is of major biotechnological interest. The toluene o-xylene monooxy-
genase (ToMO) from Pseudomonas sp. OX1 is a bacterial multicomponent monooxygen-
ase (BMM) that is able to hydroxylate a wide array of aromatic compounds and has already
proven to be a versatile biochemical tool to produce mono- and dihydroxylated derivatives
of aromatic compounds. The molecular determinants of its regioselectivity and substrate
specificity have been thoroughly investigated, and a computational strategy has been de-
veloped which allows designing mutants able to hydroxylate non-natural substrates of this
enzyme to obtain high-added value compounds of commercial interest. In this work, we
have investigated the use of recombinant ToMO, expressed in cells of Escherichia coli
strain JM109, for the biotransformation of non-natural substrates of this enzyme such as 2-
phenoxyethanol, phthalan and 2-indanol to produce six hydroxylated derivatives. The hy-
Citation: Donadio G, Sarcinelli C, Pizzo E, Notomista
E, Pezzella A, Di Cristo C, et al. (2015) The Toluene
o-Xylene Monooxygenase Enzymatic Activity for the
Biosynthesis of Aromatic Antioxidants. PLoS ONE 10
(
4): e0124427. doi:10.1371/journal.pone.0124427
Academic Editor: Jamshidkhan Chamani, Islamic
Azad University-Mashhad Branch, Mashhad, Iran,
IRAN, ISLAMIC REPUBLIC OF
Received: December 18, 2014
Accepted: March 13, 2015
Published: April 27, 2015
Copyright: © 2015 Donadio et al. This is an open
access article distributed under the terms of the
Creative Commons Attribution License, which permits droxylated products obtained were identified, isolated and their antioxidant potential was
unrestricted use, distribution, and reproduction in any
assessed both in vitro, using the DPPH assay, and on the rat cardiomyoblast cell line H9c2.
medium, provided the original author and source are
Incubation of H9c2 cells with the hydroxylated compounds obtained from ToMO-catalyzed
credited.
biotransformation induced a differential protective effect towards a mild oxidative stress in-
Data Availability Statement: All relevant data are
within the paper and its Supporting Information files.
duced by the presence of sodium arsenite. The results obtained confirm once again the ver-
satility of the ToMO system for oxyfunctionalization reactions of biotechnological
Funding: This research was supported by FARB
importance. Moreover, the hydroxylated derivatives obtained possess an interesting antiox-
2013 ORSA 132082. Dr. C. Sarcinelli was supported
idant potential that encourages the use of the enzyme for further functionalization reactions
by grant POR CAMPANIA FSE 2007/2013, Progetto
CARINA CUP B25B0900080007. The funders had no and their possible use as scaffolds to design novel bioactive molecules.
role in study design, data collection and analysis,
decision to publish, or preparation of the manuscript.
Competing Interests: The authors have declared
that no competing interests exist.
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
1 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
Introduction
In living organisms, aerobic metabolic processes such as respiration and photosynthesis cause
the generation of reactive species of either oxygen (ROS) or nitrogen (RNS) in specific organ-
elles such as mitochondria, chloroplasts, and peroxisomes. Both ROS and RNS share a well-
documented role in stimulating physiological events such as signaling and cell differentiation.
However, these molecules are also highly unstable and tend to acquire electrons from nucleic
acids, lipids, proteins, carbohydrates causing a sequence of chain reactions that are responsible
for cellular damage [1,2]. The correct balance inside the cell between the prooxidant action of
both ROS and RNS and the antioxidant activity of either enzymatic (such as superoxide dis-
mutase, catalase, glutathione peroxidase and glutathione reductase) or non-enzymatic (such as
vitamin C, vitamin E, selenium, zinc, taurine, hypotaurine, glutathione, β-carotene) systems is
indeed a very delicate equilibrium which is maintained through the activity of a complex array
of molecular mechanisms [1,3].
Evidence has been accumulating which shows that oxidative stress, the condition deriving
from an imbalance between prooxidants and antioxidants in the cell, might represent a com-
mon element for the onset of several pathologies such as cancer, neurodegenerative and cardio-
vascular diseases, and the occurrence of complications in diabetes [4,5].
The quest for novel natural and synthetic antioxidants has undoubtedly drawn the attention
of the scientific community in recent years. In this context, several antioxidant pharmaco-
phores have been identified, among which phenols and catechols have been given much atten-
tion as they are very susceptible to oxidation by acting as electron donors [6, 7].
Phenols are endowed with the property of suppressing or delaying spontaneous autoxida-
tion of organic molecules and might be useful to prevent in vivo the consequences of the autox-
idation of biomolecules [6,8]. Thus, it is not surprising that fruits and vegetables, which are
characterized by a high content of phenolic compounds such as phenolic acids and flavonoids,
have been so far the main suppliers of molecules analyzed as potential antioxidant drugs, and
their consumption in a healthy and varied diet has been demonstrated to significantly reduce
the risk of cancer [9,10–13]. In addition, synthetic phenolic antioxidants such as butylated hy-
droxyanisole (BHA), butylated hydroxytoluene (BHT), tert-butylhydroquinone (TBHQ) and
propyl gallate (PG) have been also studied and used, although the use of BHA and BHT has
been restricted by legislative rules due to uncertainties concerning their toxic and carcinogenic
effects [6].
Despite all the interest towards phenolic antioxidants, there are still many issues to unravel
concerning their biological activity. The analysis of kinetic and thermodynamic data available
so far in the literature indicates that the efficiency of phenols as inhibitors of the autoxidation
of organic matter depends on a variety of factors, and this becomes undoubtedly challenging in
complex systems such as living organisms [6].
Other antioxidant pharmacophores have been identified, among which catechols, 1,2-dihy-
droxybenzenes, have been given much attention [7]. It should be noted that the Comprehen-
sive Medicinal Chemistry (CMC) database shows the presence of many drugs containing the
catechol moiety for which several pharmacological effects have been described [14,7]. For these
molecules, it is commonly accepted that their antioxidant effect depends on the fact that the
semiquinone radical derived from H-atom donation of catechol can be stabilized by both an in-
tramolecular hydrogen bond and by the electron-donating properties of the ortho-OH [15–16].
Thus, the chemical versatility of both phenols and catechols and the numerous pharmacologi-
cal effects described for some of their derivatives, encourage their use as scaffolds to design
novel bioactive molecules where the different nature of the substituents bound to the aromatic
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
2 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
ring may influence the reactivity of these molecules towards oxidizing agents, their pharmaco-
kinetics, and their tissue and cellular distribution [14,7].
However, the synthesis of substituted phenols and catechols by chemical methods is often
complex and may involve severe reaction conditions, resulting in low yields and the formation
of racemic mixtures [17,18]. These complications have boosted the research for the develop-
ment of biotransformations, also known as bioconversions, which make use of the metabolic
versatility of either purified enzymes or whole microorganisms, for the selective hydroxylation
of commercially available, low-added-value, aromatic precursors [19].
The toluene o-xylene monooxygenase (ToMO) from Pseudomonas sp. OX1 is a bacterial
multicomponent monooxygenase (BMM) [19–23] that has been extensively characterized in
the last decade from both a biochemical and a biotechnological point of view [24–26]. The mo-
lecular determinants of its regioselectivity and substrate specificity have been thoroughly inves-
tigated, and a computational strategy has been developed which analyzes the interactions
between the active-site residues of its hydroxylase component ToMOA and the substrates [26–
3
1]. Recently, mutants of the ToMO multicomponent system were used to produce tyrosol
(
4-hydroxyphenylethanol, bearing a phenol moiety) and hydroxytyrosol (3,4-dihydroxypheny-
lethanol, bearing a catechol moiety), strong antioxidants commonly found in extra virgin olive
oil [32–36,13], using a cheap and commercially available aromatic precursor such as 2-pheny-
lethanol (S1 Fig) [18]. The results obtained showed the great versatility of ToMO and suggested
the potential use of this enzyme for the hydroxylation of other non-natural aromatic substrates
to produce antioxidant phenols and catechols of interest for both the food and pharmaceutical
industries.
In the present study we have used the recombinant ToMO system, expressed in strain
JM109 of E.coli, to hydroxylate three commercially available aromatic monocyclic molecules
that are non-natural substrates of the enzyme, to obtain mono- and dihydroxylated derivatives
analogous to natural antioxidants tyrosol and hydroxytyrosol, but with some structural differ-
ences that might influence their antioxidant potential.
The three aromatic molecules used in this study as starting compounds are benzene deriva-
tives bearing one or two substituents in ortho (Fig 1B):
-
2-phenoxyethanol, is a benzene derivative with a-O-(CH ) -OH substituent bound to the
2 2
aromatic ring. This compound differs from 2-phenylethanol (Fig 1A), the starting sub-
strate used for the biosynthesis of tyrosol and hydroxytyrosol [18] (S1 Fig), for the pres-
ence of an additional oxygen atom directly linked to the aromatic ring;
Fig 1. Starting substrates. (A) Structures of 2-phenylethanol and o-xylene. (B) Substrates used for the
ToMO-catalyzed biotransformations presented in this study.
doi:10.1371/journal.pone.0124427.g001
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
3 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
-
-
2-indanol, is similar to 2-phenylethanol but with an additional methylene group, linking
the ethanol moiety to the ring, which makes the structure more rigid;
phthalan, which differs from o-xylene, a natural substrate of ToMO (Fig 1A), for the pres-
ence of an oxygen atom bridging the two methyl substituents.
Phenols and catechols obtained from the hydroxylation of these compounds were isolated,
purified and identified by NMR and mass spectrometry analysis. Their antioxidant potential
was first assessed in vitro using the DPPH chemical assay [37–38], and then on the rat cardio-
myoblast cell line H9c2 [39–40] to evaluate their effect during a mild oxidative stress induced
by sodium arsenite (SA). Exposure to SA inhibits protein synthesis in eukaryotic cells and acti-
vates multiple stress signaling pathways such as the generation of what is usually referred to as
“
stress granules” [4,41–43]. Confocal microscopy analysis suggested that in stressed H9c2 cells,
pretreatment with optimal concentrations of the hydroxylated compounds resulted in a lower
percentage of cells containing stress granules, thus highlighting a potential antioxidant activity
of these molecules in the cellular milieu, and paving the way to their future functionalization to
increase and diversify their biological activities.
Materials and Methods
Generals
Bacterial cultures, plasmid purifications, and transformations were performed according to
Sambrook et al [44]. E. coli strain JM109 was from Novagen. Plasmid pGEM3Z/Tou wt and
mutant E103G/F176A were prepared as already described [18]. 2-phenoxyethanol, phthalan,
and 2-indanol were purchased from Sigma-Aldrich. Water and methanol used for HPLC ex-
periments were from Romil. Formic acid was from Carlo Erba.
Docking of substrates in ToMOA active site
Reaction intermediates were docked into the active site of ToMO by using the Monte Carlo en-
ergy minimization strategy as previously described [18], except that the 2010 version of the
ZMM software was used, and the dielectric constant was calculated using the default option of
this version. The PDB files for the initial manually generated complexes and the ZMM instruc-
tion files containing the lists of mobile residues, constraints, and parameters used during calcu-
lations are available upon request.
ToMO-catalyzed bioconversion of 2-phenoxyethanol, phthalan and
2
-indanol: isolation and purification of the reaction products
Cells of E. coli strain JM109 transformed with either plasmid pBZ1260 or variant E103G/F176A,
were routinely grown in LB to which ampicillin was added to a final concentration of 100 μg/mL
(
1
LB/amp). Several well-isolated colonies were picked from LB/amp agar plates, inoculated into
2.5 mL of LB/amp in a sterile 50 mL Falcon Tube and incubated in constant shaking at 37°C up
to 0.6 OD600. The preinoculum was diluted 50-fold in two 500 mL Erlenmeyer flasks containing
each 250 mL of LB/amp, and incubated under constant shaking at 37°C up to 0.7–0.8 OD600. Ex-
pression of the recombinant ToMO proteins was induced with 0.2 mM IPTG at 37°C and in the
presence of 0.2 mM Fe(NH ) (SO ) ; this latter was necessary for the assembly of the iron-con-
4
2
4 2
taining catalytic center of the recombinant ToMO. After 1 hour of induction, cells were collected
by centrifugation (1,880 x g for 15’ at 4°C), resuspended in M9 medium containing 0.4% glucose
(
M9-G) at a final concentration of 6 OD600 and incubated with 2 mM of either 2-phenoxyetha-
nol, phthalan, or 2-indanol dissolved in methanol (final methanol concentration was 2%). After
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
4 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
a 16h incubation at 28°C under constant shaking at 230 rpm, cells were collected by centrifuga-
tion at 1,880 x g for 15’ at 4°C; an aliquot of the cell-free supernatants was loaded on HPLC to
check for the presence of hydroxylated products before their purification (S2 Fig). To this pur-
pose, an HPLC system equipped with a Waters 1525 binary pump coupled to a Waters photodi-
ode array detector was used. Substrates and hydroxylated derivatives were separated using a
Ultrasphere C reverse-phase column (4.6 x 250 mm; particle size 10 μm, pore size 100 Å). Sep-
18
aration was carried out at a flow rate of 1 mL/min by using a two-solvent system consisting of a
.1% formic acid solution in water (solvent A) and a 0.1% formic acid solution in methanol
solvent B). Compounds were separated using a 3-min isocratic elution with 10% solvent B, fol-
0
(
lowed by a 20-min linear gradient from 10 to 75% solvent B and an isocratic 5-min step at 98%
solvent B.
For the purification of the hydroxylated products identified by analytical HPLC, cell-free su-
pernatants, prepared as described above, were extracted twice with ethyl acetate added in a 1:2
ratio with respect to the aqueous phase. The organic phase was recovered, dried with a Rotava-
por apparatus, and the pellet was dissolved in 100% methanol and stored at -20°C. The sample
was then diluted to a final 10% concentration of methanol and loaded on HPLC using an Econ-
osil C18 reverse-phase semi-preparative column (10 x 250 mm, particle size 10 μm, pore size
1
00 Å). Separation was carried out at a flow rate of 2 mL/min by using a two-solvent system
consisting of a 0.1% formic acid solution in water (solvent A) and a 0.1% formic acid solution
in methanol (solvent B). Compounds were separated using a 10-min isocratic elution with 10%
solvent B, followed by a first 10-min linear gradient from 10 to 40%, a second 10-min linear
gradient from 40% to 75%, a third 5-min gradient from 75% to 90%, an isocratic 10-min step
at 90% of solvent B and a final 15-min step at 10% of solvent B. Each peak of interest was indi-
vidually collected, concentrated, and stored at -20°C.
Identification by NMR and mass spectrometry analysis
For NMR analysis, aliquots of the purified cell-free supernatants, prepared as described in the
previous paragraph and fractionated by HPLC, were lyophilized, and directly used for NMR
1
analysis in deuterated methanol. H NMR spectra were recorded at 600, 400, or 300 MHz, and
1
3
C NMR spectra were recorded at 75 MHz. 1H and 13C distortionless enhancement by polari-
zation transfer heteronuclear single-quantum correlation and 1H and 13C heteronuclear mul-
tiple-quantum correlation (HMBC) experiments were run at 600 and 400 MHz, respectively,
on instruments equipped with a 5 mm 1H/broadband gradient probe with inverse geometry
using standard pulse programs. The HMBC experiments used a 100-ms long-range coupling
delay. Chemical shifts are reported in δ values (ppm) downfield from tetramethylsilane. Regioi-
somers were distinguished according to the spin-coupling pattern in the aromatic region of the
1
H NMR spectra (S3 Fig). Compound eluting in peak 1 (S2 Fig), indicated from now on as
compound 1, showed only two signals featuring a doublet shape as a consequence of the ortho-
type coupling. On this basis, the direct attribution of the symmetric para-substituted structure
to compound 4HEP, recognized as the 4-(2-hydroxyethoxy)phenol, was allowed. In the case of
compounds eluting in peaks 2 and 3 (compounds 2 and 3) a more complex pattern in the aro-
1
matic region of the H NMR spectra was present, suggesting, respectively, a meta and an ortho
substitution of the aromatic rings (S3 Fig). The characterization of compounds 2 and 3 as 3-
(
2-hydroxyethoxy)phenol (3HEP) and 2-(2-hydroxyethoxy)phenol (2HEP), respectively, re-
1
sulted from the ratios of shielded and unshielded signals. Indeed, the H integration for com-
pound 3HEP is accounted with the two H atoms in ortho (H ) and the one H atom in para
o
(
H ) to the OH group. For compound 2HEP, the ratio H /H is 1 which is coherent with the
p o p
presence of only two shielded H atoms, the one in ortho and one in para to the OH group.
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
5 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
HR ESI+/MS spectra (S4 Fig) were obtained in 0.5% Formic Acid/methanol 1:1 v/v and
were recorded on a Agilent 1100 LC/MSD/ESI apparatus.
Evaluation of the concentration of the hydroxylated derivatives of
2
-phenoxyethanol, phthalan and 2-indanol
To evaluate the concentration of the compounds obtained from the ToMO-catalyzed hydroxyl-
ation reaction we selected, for each of them, a similar compound whose UV-vis spectrum and
corresponding extinction coefficient was available in the literature (S5 Fig). All the spectro-
scopic data used for calculations were obtained from the “Organic Electronic Spectral Data”
book series (Analitical chemistry. 58. 1886. G. Norwitz et al Wiley eds).
DPPH assay
2
,2-diphenyl-1-picrylhydrazyl (DPPH) is a stable free radical with λ
at 515 nm (purple, ε515
max
-
1
-1
in methanol = 12 mM cm ). The neutralization of the DPPH radical is responsible for the dis-
appearance of the absorbance at 515 nm and is commonly used as a readout of radical scaveng-
ing of an antioxidant compound [37–38]. The reaction mixture contained, in a final volume of
1
mL of methanol, different concentrations of our hydroxylated compounds and 0.1 mM of a
freshly prepared DPPH solution in methanol. It is important to note that, as recommended by
Kedare and coauthors [38] the initial DPPH concentration should give an absorbance ꢀ 1.0.
The reaction was allowed to proceed at RT until completion, and was followed at λ = 515nm.
Cell cultures and treatments
H9c2 cells (Rat Embryonic Myocardium Cells, CRL-1446) were purchased from American
Type Culture Collection (ATCC) and grown in Dulbecco’s modified Eagle medium (DMEM)
supplemented with 10% fetal bovine serum (FBS), 4 mM L-glutamine, 1% v/v penicillin/strep-
tomycin solution (100 U/mL) and 1mM sodium pyruvate (Euroclone, Milano, Italy) at 37°C in
5
% CO incubator. Oxidative stress was induced by adding sodium arsenite (Sigma Aldrich),
2
freshly prepared in stock aqueous solutions and added to the conditioned medium at a final
concentration of 0.25 mM.
MTT assay
3
H9c2 cells were seeded on 96-well plates at a density of 2.5×10 cells/well in 0.1 mL of DMEM
2
4 h prior to the treatment with the different compounds. As control, cells were incubated with
buffer diluted in medium.
After 72 h of incubation, cell viability was evaluated by MTT assay, adding tetrazolium
MTT (3-(4,5-dimethylthiazol-2-yl)-2,5-diphenyltetrazolium bromide) diluted at 0.5 mg/mL in
DMEM without red phenol (0.1 mL/well). After 4 h of incubation at 37°C, the resulting insolu-
ble formazan salts were solubilized in 0.04 M HCl in anhydrous isopropanol, and quantified by
measuring the absorbance at λ = 570nm, using an automatic plate reader spectrophotometer
3
(
VICTOR Multilabel Counter; Perkin Elmer, Shelton, CA, USA). Cell survival was expressed
as means of the percentage values compared to control. Standard deviations were always < 5%
for each repeat (values in quadruplicate of at least three experiments).
The hydroxylated derivatives of 2-phenoxyethanol, phthalan and 2-indanol were used at a
concentration close to their EC50 value (5 to 10 μM higher) obtained from the DPPH assay.
When the EC50 was not available, as in the case of tyrosol, 3HEP, DHI, and DHiBF (S4 Fig),
two arbitrary concentrations were initially tested, 40 and 80 μM. As results obtained with these
two concentrations were comparable, the lower concentration (40 μM) was used to test the
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
6 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
potential antioxidant activity of these compounds in the following experiments such as the ap-
optosis assay and the analysis of stress granules.
The non-hydroxylated precursors, when assayed, were used at a concentration equal to the
higher concentration used for any of their hydroxylated derivatives. In conclusion, the concen-
trations used in the experiments with H9c2 cells presented in the “Results and Discussion” sec-
tion of this manuscript were: 25 μM for hydroxytyrosol, 40 μM for phenylethanol, tyrosol,
4
2
HEP, 3HEP, phthalan, DHiBF, 2-indanol, DHI, THI, and 90 μM for 2-phenoxyethanol and
HEP (S4 Fig).
EB and AO staining assay
Apoptotis was evaluated by ethidium bromide (EB) and acridine orange (AO) staining of nu-
clei [45]. AO is a fluorescent DNA binding dye that permeates all the cells staining the nuclei
green, whereas EB is only taken up by the cells when cytoplasmic membrane integrity is com-
promised, staining apoptotic nuclei red. H9c2 cells were seeded in 6-well plates at a density of
5
1
.5 ×10 cells/well in 2 mL of DMEM and grown up to nearly 60% confluence. The cells were
then incubated at 37°C for 3 h in the presence of the tested compounds. Afterwards, the SA-in-
duced oxidative stress (0.25 mM for 90 min) was performed. Cells were trypsinized, collected
by centrifugation, and washed with ice-cold PBS. Cells were re-suspended in 50 μL of PBS con-
taining the EB/AO dye mixture (5 μg/mL) and incubated at 37°C for 20 min. Stained cells were
placed on a microscope slide and covered with coverslips. Images were taken at a 100 X magni-
fication. Both apoptotic (red) and live (green) cells were counted in five microscopic fields for
each sample, to estimate the percentage of apoptotic cells.
Immunofluorescence analysis and confocal microscopy
4
H9c2 cells were seeded onto coverslips in 24-well plates at a density of 2.5×10 cells/well in
0
3
.5 mL of DMEM and grown for 48 h, up to nearly 60% confluence. Cells were incubated at
7°C for 3 h with either the starting aromatic compounds or their hydroxylated derivatives. Af-
terwards, an incubation with 0.25 mM SA for 90 min was performed. As negative and positive
controls of the stress effect, cells were treated with either buffer or 0.25 mM SA, respectively, in
the absence of any exogenous compound. Cells were then fixed in 4% paraformaldehyde in
PBS 1X at room temperature for 15 min and rinsed three times with PBS 1X. Quenching of
free aldehydic sites of the fixative was performed by adding 50 mM NH Cl in PBS 1X, at room
4
temperature for 15 min. After washing with PBS 1X, cells were permeabilized using 0.1% Tri-
ton X-100 in PBS 1X at room temperature for 30 min, then rinsed in PBS 1X for three times.
After incubating the cells in a blocking solution consisting of 5% bovine serum albumin (BSA)
in PBS 1X at room temperature for 1 hour under constant shaking, PABP monoclonal antibody
(
Sigma Aldrich), a specific marker used to evidence the presence of stress granules in the cell,
was used at 2 μg/mL in blocking buffer at 4°C overnight. After washing in PBS 1X, cells were
incubated with secondary antibody Cy3 conjugated goat anti-mouse F(ab’)2 (1:1,000 dilution
in blocking buffer) (Jackson Immuno Research Laboratories, UK), at room temperature for 1
hour. For nuclear counterstaining, cells were incubated with DAPI, diluted at 0.1μg/mL in PBS
1
X, at room temperature for 10 min. After washing, coverslips were mounted in 50% glycerol
in PBS 1X. Images were captured using a Zeiss confocal laser-scanning microscope LSM 510
using suitable lasers. Image analyses on stress granules was performed using “Stress granule
counter” and “Analyze particles” ImageJ (http://rsbweb.nih.gov/ij/index.html) plugins. Nuclear
counterstaining was used to count the total number of cells. Statistical analyses were performed
using GraphPad (Prism) software ver. 5.0.
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
7 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
Results and Discussion
ToMO-catalyzed hydroxylation of 2-phenoxyethanol, phthalan and
-indanol
2
The aromatic substrates used in this study (Fig 1B) were used without any further purification.
For each compound the corresponding UV-vis spectrum was recorded after dilution in metha-
nol; λmax of 2-phenoxyethanol, phthalan and 2-indanol were respectively 269.7, 270.9 and
2
72.1 nm. ToMO-catalyzed biotransformation of these aromatic substrates, used at a final con-
centration of 2 mM in the incubation medium M9-G, was performed by using recombinant
cells of E.coli, strain JM109, transformed with the plasmid coding for the complete ToMO wt
enzymatic system, as described in detail in Materials and Methods.
After incubation for different time intervals (0, 30 min, 1 h, and 16 h) at 30°C under con-
stant shaking (220 rpm), samples were withdrawn, cells were collected by centrifugation, and
an aliquot of the exhausted medium was loaded on HPLC to check for the presence of hydrox-
ylated products (Materials and Methods, and S2 Fig). As evident from the chromatographic
profiles obtained, ToMO wt was able to hydroxylate 2-phenoxyethanol and phthalan. Three
different peaks eluting respectively at 10.4 min (compound 1, λmax = 287.5 nm), at 12.6 min
(
compound 2, λmax = 273.5nm) and 15.2 min (compound 3, λmax = 275.3nm) were evident
when using 2-phenoxyethanol as the substrate (Panel A in S2 Fig). Formation rates of com-
-
1
pounds 1, 2 and 3 were of 0.89(±0.04), 1.15(±0.20) and 0.510(±0.001) μM min , respectively.
Compounds 1, 2 and 3 accounted respectively for the 37.8(± 3.1), the 43.8(±1.3) and the 18.3
(
±1.8)% of the total yield of product which was of 15.3(±1.3)% (total μM products/μM sub-
strate) and was calculated after 2h of incubation, the maximum time at which the products
yield was still proportional to the time of incubation (data not shown). When using phthalan
as substrate a single peak of product was eluted at 14.3 min (compound 4, λ
= 279.2 nm)
max
-
1
(
Panel B in S2 Fig) with a formation rate of 1.79(±0.03) μM min and a yield of 10.8(±0.2)%
after 2h of incubation. No evident hydroxylation product was instead observed when the sub-
strate used for the ToMO-catalyzed bioconversion was 2-indanol (data not shown).
The exhausted media obtained from the ToMO wt-catalyzed bioconversion of 2-phenox-
yethanol and phthalan were further purified through organic extraction, as described in detail
in Materials and Methods. Samples were then loaded on a semi-preparative HPLC C-18 col-
umn. Each peak was manually collected, lyophilized and analyzed by NMR and mass spec-
trometry analysis (Materials and Methods, and S3 and S4 Figs). Fig 2A and 2B show the
starting compounds 2-phenoxyethanol and phthalan and the corresponding products identi-
fied through these analyses.
Selection of an efficient catalyst for the hydroxylation of 2-indanol
The conversion of 2-phenoxyethanol to a mixture of the three mono-hydroxylated products is
not surprising as this result is very similar to what previously observed in the case of 2-pheny-
lethanol [18]. As for phthalan, the most similar substrate we have previously tested, o-xylene is
converted to a mixture of 3,4-dimethylphenol (80%) and 2,3-dimethylphenol (20%) [27]. We
have previously suggested that this result is due to the fact that the site for the ortho substitu-
ents is more hindered than the site for the para substituents [26]. Likely, in the case of phthalan
the steric hindrance caused by the additional oxygen atom (Fig 1B) further disfavors the proxi-
mal hydroxylation of this compound, thus providing exclusively the hydroxylation product
corresponding to 3,4-dimethylphenol i.e. 1,3-dihydro-5-hydroxyisobenzofuran (DHiBF),
(Fig 2B and S4 Fig).
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
8 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
Fig 2. Hydroxylated products. Starting substrates and corresponding hydroxylated products obtained
through ToMO-catalyzed biotransformation of (A) 2-phenoxyethanol and (B) phthalan.
doi:10.1371/journal.pone.0124427.g002
In order to identify a ToMO variant able to hydroxylate 2-indanol, we have analyzed the in-
teraction of 2-indanol and phthalan (this latter considered as our positive control) with the ac-
tive site of ToMO using a Monte Carlo modelling strategy previously applied to ToMO natural
substrates and to 2-phenylethanol [26, 18]. Briefly, this strategy is based on the docking of a
crucial intermediate of the hydroxylation reaction i.e. the “arenium intermediate”. By compar-
ing the geometrical parameters for any desired complex ToMO (ToMO-variant)/intermediate
to those found for the complex ToMO wt/arenium intermediate for para-hydroxylation of the
optimal substrate toluene (the “reference complex”), it is possible to predict if an aromatic
compound will be a good substrate and which product(s) will be produced. As described previ-
ously [26,18], two geometrical parameters defining the orientation of the arenium ring with re-
spect to the diiron cluster were used for the comparison: (i) the distance between the carbon
atom of the substrate that accepts the oxygen atom from the diiron cluster during the hydroxyl-
ation reaction (herein called C ) and the C4 atom of the reference complex, and (ii) Δθ, a pa-
n
rameter that measures the angle deviation of the plane of the arenium ring in a ToMO mutant/
intermediate complex with respect to the plane of the arenium ring in the reference structure. θ
is the torsion angle Fe2-O-C -C where C is the carbon atom of the substrate adjacent to C
n
m
m
n
closer to the substituent bound to the benzene ring (Fig 3). In the reference structure, θ angle
Fe2-O-C4-C3) is 103.6°. Previously [26, 18] we have demonstrated that C -C4 distances lower
(
n
than about 0.2 Å, and Δθ values in the range -10°/+5° are predictive of high kcat values (similar
to or even higher than those measured for ToMO wt on its natural substrate toluene).
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
9 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
Fig 3. Docking of intermediates in ToMO active site. Docking of the two possible arenium intermediates
(
4PT and 5PT) deriving from phthalan in the active site of ToMOA. In the case of 4PT, θ is the torsion angle
Fe(2)-O-C4-C9, whereas, in the case of 5PT, θ is the torsion angle Fe(2)-O-C4-C5. Similar arenium
intermediates can be hypothesized for the hydroxylation of 2-indanol.
doi:10.1371/journal.pone.0124427.g003
Data in Table 1 show that in the case of phthalan only the arenium intermediate leading to
1
,3-dihydro-5-hydroxyisobenzofuran (DHiBF) docks in an orientation very similar to that of
the reference structure suggesting that this isomer can be efficiently produced by ToMO. On
the contrary, the arenium intermediate leading to 1,3-dihydro-4-hydroxyisobenzofuran adopts
an orientation very different from that of the reference intermediate described above. Accord-
ing to our model this would indicate poor or none production of the 4-hydroxy isomer in spite
of a non-covalent binding energy value (ncBE in Table 1) more negative than that of the 5-hy-
droxy isomer. Overall, data in Table 1 allow to predict that ToMO can convert phthalan only
to 1,3-dihydro-5-hydroxyisobenzofuran in agreement with the experimental finding. In the
case of 2-indanol both arenium intermediates 24I and 25I leading to the two possible products,
Table 1. Geometrical parameters and non covalent binding energies (ncBE) of the complexes between ToMO or E103G/F176A-ToMO and the are-
nium intermediates for the phthalan/1,3-dihydro-4-hydroxyisobenzofuran (4PT), the phthalan/1,3-dihydro-5-hydroxyisobenzofuran (5PT), the
2-indanol/2,4-dihydroxyindan (24I) and the 2-indanol/2,5-dihydroxyindan (25I) reactions.
Arenium intermediate
Geometrical parameters
ToMO
wild type
E103G/F176A
C4-C4 (Å)
Δθ (°)
0.42
+36.7
-42.4
0.25
- a
4
5
2
2
PT
PT
4I
-
-
1
ncBE (kcal mol )
C4-C5 (Å)
-
-
Δθ (°)
-6.7
-
-
1
ncBE (kcal mol )
C4-C4 (Å)
-33.5
0.49
-
0.45
+35.6
-39.6
0.25
-7.6
-35.3
Δθ (°)
+28.8
-40.0
0.43b
+36.1c
-23.6
-
1
ncBE (kcal mol )
C4-C5 (Å)
5I
Δθ (°)
-
1
ncBE (kcal mol )
a
b
c
not determined.
in the case of phenylethanol we previously found C4-C4 distances of 0.3 and 0.23 Å for the para- and meta-hydroxylation, respectively.
in the case of phenylethanol we previously found Δθ values of +41° and +22° for the para- and meta-hydroxylation, respectively.
doi:10.1371/journal.pone.0124427.t001
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
10 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
2
,4-dihydroxyindan and 2,5-dihydroxyindan respectively, dock into the active site with orien-
tations very different from that adopted by the natural substrate toluene. An accurate examina-
tion of the complex ToMO/25I showed that the steric hindrance of phenylalanine 176 prevents
the correct accommodation of the intermediate in a manner similar to that previously de-
scribed for the meta- and para-hydroxylation of phenylethanol [18]. However, in the case of
2
-indanol the presence of the additional methylene group and the rigidity caused by the ring
structure markedly increase the deviation from the ideal geometry (Table 1) in agreement with
the fact that ToMO slowly converts phenylethanol to tyrosol isomers but seems to be almost
completely inactive on 2-indanol.
Since we have previously demonstrated that mutations F176A and E103G, removing the
hindrance at the “para site”, allow the accommodation of large substituents in para, we have
modeled the complexes between the double mutant and the arenium intermediates 24I and
2
5I. Data in Table 1 and the models in S6 Fig show that the two mutations selectively improve
the geometrical parameters calculated for the intermediate 25I. The two mutations also in-
crease the non-covalent binding energy of 25I indicating that this intermediate not only could
dock with a better geometry but could bind more tightly to the active site.
According to the analysis described above, the ToMO variant E103G/F176A was used for
the bioconversion of 2-indanol under the same experimental conditions used for the recombi-
nant ToMO wt system (Materials and Methods). The HPLC chromatogram in Fig 4 shows in
this case the presence of two peaks of products eluting respectively at 13 min (compound 5,
λmax = 280.3 nm) and 10 min (compound 6, λmax = 288 nm). It is worth noting that the pres-
ence of compound 6 was evident only after at least 16h of incubation (Panel C in S2 Fig). Due
to a partial loss of viability of E.coli cells strain JM109 after this time, neither the formation rate
nor the yield of this compound were calculated. Rate of formation of compound 5 was of 5.77
-
1
(
±1.35) μM min ; the yield after 2h of incubation was of 28.9(±0.4)%. By NMR and mass spec-
trometry analysis (Materials and Methods, and S3 and S4 Figs) compound 5 was identified as
,5-dihydroxyindan (DHI) in agreement with the docking analysis. Moreover, compound 6
2
was identified as 2,5,6-trihydroxyindan (THI, Fig 4 and S4 Fig), thus indicating that in the
ToMO variant E103G/F176A the active site is wide enough not only to accommodate 2-inda-
nol in a catalytically productive orientation, but also to permit a second hydroxylation at the
position adjacent to the first hydroxyl group, as usually observed when ToMO wt acts on its
natural substrates toluene and o-xylene which are respectively converted to 3-/4-methylcate-
chol and 4,5-dimethylcatechol [27].
Fig 4. E103G/F176A ToMO-catalyzed biotransformation of 2-indanol. HPLC chromatogram at λ = 280
nm of an aliquot of the exhausted medium deriving from the 16 hrs, E103G/F176A ToMO-catalyzed
biotransformation of 2-indanol.
doi:10.1371/journal.pone.0124427.g004
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
11 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
In vitro antioxidant potential of the hydroxylated derivatives of
-phenoxyethanol, phthalan and 2-indanol
2
The capacity of the isolated hydroxylated compounds to scavenge the stable radical 2,2-diphe-
nyl-1-picrylhydrazyl (DPPH) was determined spectrophotometrically by measuring the loss of
absorbance of DPPH at λ = 515 nm (see Materials and Methods for details). 0.1 mM DPPH
and different concentrations of each hydroxylated compound were added, in a final volume of
1
mL of methanol, in the range 1–200 μM, and the loss of absorbance at 515 nm (from now on
indicated as ABS515) was monitored for 30 min. At this time, the percentage of DPPH effective-
ly reduced (%DPPHred) was calculated evaluating the initial DPPH concentration at t = 0, indi-
cated as [DPPH]t = 0, and the final DPPH concentration at t = 30, referred to as [DPPH]t = 30
,
and using the following formula:
%
DPPHred ¼ ½1ꢁð½DPPHꢂt¼30=½DPPHꢂt¼0Þꢂ x 100
The concentration of hydroxylated compound used in each experiment was plotted against
DPPHred (S7 Fig). The concentration that caused a decrease in the initial DPPH concentra-
%
tion of 50% was defined as EC50 and was obtained by a non-linear regression of the experi-
mental curves using the Graphpad Prism software (http://www.graphpad.com/). Each EC50 is
the result of at least three independent experiments.
Once obtained the EC50 value for a specific compound we estimated also-at that specific
concentration- the time (expressed in minutes) needed to reach a stable value of the ABS515, a
parameter indicated in literature as TEC50 [37,46]. At this point we calculated what has been
defined [46] as the “antiradical efficiency” (AE) a parameter that is expressed by the following
formula: AE = 1/(EC50 x TEC50). The AE value, taking into account not only the EC50 but
also the reaction time, is more informative than the EC50 value alone on the antioxidant be-
havior of a compound tested with this specific assay [46].
In all the experiments, described in this and in the following paragraphs, natural aromatic
antioxidants such as tyrosol and hydroxytyrosol have also been tested [32–36] as reference
molecules, in parallel with the hydroxylated compounds obtained by ToMO-catalyzed bio-
transformation of 2-phenoxyethanol, phthalan and 2-indanol.
Results are shown in Table 2, where it is evident that some among the phenols and catechols
produced by the ToMO-catalyzed reaction on non-natural aromatic substrates show an AE
value comparable to the strong natural phenolic antioxidant hydroxytyrosol. Interestingly,
compounds such as tyrosol, which has been reported to have antioxidant activity in vivo [47],
3HEP, DHiBF, and DHI (S4 Fig) were almost non responsive to the DPPH assay causing neg-
ligible losses of ABS515 even when used at concentrations up to 2mM (data not shown).
DPPH reduction curves obtained for each compound tested (S7 Fig) and the AE values cal-
culated (Table 2) clearly demonstrate the relevant reducing potential of 2HEP, 4HEP and of
THI compared to hydroxytyrosol activity. Although this could be expected in the case of THI,
Table 2. Evaluation of the antioxidant activity using the DPPH assay.
Compound
EC50 (μM Antioxidant/μM DPPH)
TEC50 (min)
AE
Hydroxytyrosol
0.21 (±0.01)
0.40 (±0.04)
1.00 (±0.02)
0.40 (±0.01)
18.0 (±2.0)
19.0 (±1.0)
25.3 (±2.1)
15.3 (±2.5)
0.27 (±0.01)
4
HEP
HEP
THI
0.140 (±0.006)
0.040 (±0.002)
0.15 (±0.03)
2
EC50, TEC50 and antioxidant efficiencies (AE) values of hydroxytyrosol, 4 HEP, 2HEP and THI. Standard deviations (SD) are reported in parentheses.
doi:10.1371/journal.pone.0124427.t002
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
12 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
as it shares a catechol moiety with the hydroxytyrosol structure, results obtained from 2HEP
and 4HEP (phenols like tyrosol, DHiBF, and DHI) deserve some comments. In both struc-
tures the aromatic ring hosts two oxygens either in ortho (2HEP) or para (4HEP); thus these
two molecules share an important structural similarity with catechol and hydroquinone, re-
spectively, two known antioxidants [48]. 3HEP, instead, shows the additional atom oxygen in a
meta position respect to the-OH already present on the aromatic ring, thus resembling resor-
cinol. Compared to catechol and hydroquinone, where the-OH group in either ortho or para
position has an electron donating effect, the reaction of resorcinol with a radical such as DPPH
would theoretically be reduced by the electron-withdrawing effect of the-OH group in the meta
position [9]. The same rational seems to apply to the three hydroxylated derivatives we ob-
tained from the biotransformation of 2-phenoxyethanol.
Interestingly, the THI plot shows a sigmoidal profile that was not observed for the other
compounds tested. Although a more detailed investigation would be necessary to account for
such a behaviour, it may be argued that a two-step oxidation path is available for THI as a con-
sequence of the-OH substituted five member ring condensed with the catechol system (S8 Fig
and explicative notes).
Antioxidant potential of 4HEP, 3HEP, 2HEP, DHiBF, DHI, THI in cultured
H9c2 cells
The potential antioxidant activity of the hydroxylated compounds described in this study was
also evaluated testing their effect in a eukaryotic cell system such as the rat cardiomyoblast cell
line H9c2. These latter are non-malignant cardiac-like cells, commonly used to study the mo-
lecular response to oxidative damage [39–40]. We first examined the effect of the hydroxylated
compounds on cell viability, by using the MTT assay (Panel A in S9 Fig), to verify that a cyto-
toxic effect did not occur. To this purpose, cells were cultured for 72 hours under normal
growth conditions in the presence of each purified hydroxylated compound, previously diluted
in the growth medium at optimized concentrations (Materials and Methods). The percentage
of viable cells, compared to the control, never significantly decreased as shown in Panel A in S9
Fig, thus showing that the compounds tested are not cytotoxic on this specific cell line. Indeed,
in the presence of the non-hydroxylated precursors (Panel A in S9 Fig, dark white bars) used as
substrates in the ToMO-catalyzed biotransformations, the percentage of viable cells was almost
close to the 100%. It is worth to note that hydroxytyrosol and tyrosol induced a significant in-
crease of cell survival (Panel A in S9 Fig, black bars) (p value < 0.01). A slight positive effect on
cell viability was also observed when using the hydroxylated products obtained from 2-phenox-
yethanol, with a significant increase of the viable cells number (p value < 0.01 for 4HEP, p
value < 0.05 for 3HEP and 2HEP). Conversely, DHiBF, DHI and THI did not produce any
apparent change in cell viability.
Optimized concentrations obtained in this assay were used in all subsequent experiments
(
Materials and Methods). In order to validate the data obtained on cell viability, we investigated
whether the tested compounds had any effect on cell apoptosis. Apoptotic cells were identified
by acridine orange (AO) and ethidium bromide (EB) staining of nuclei [45], as described in
Materials and Methods; results are presented in Panel B and C in S9 Fig When cells were cul-
tured under normal growth conditions, the hydroxylated compounds did not induce an in-
crease in cell apoptosis (Panel C in S9 Fig, white bars). This is consistent with the results
obtained from the MTT assay. Moreover, tyrosol, 3HEP, DHI and THI induced a significant
decrease of the number of apoptotic cells (p value < 0.05 for DHI, p value ꢀ 0.01 for the other
compounds; Panel C in S9 Fig). Exposure of H9c2 to 0.25 mM of SA for 90 min induced, per
se, a 37% increase in the percentage of apoptotic nuclei (Panel C in S9 Fig, first black bar).
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
13 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
Since this stress condition was sufficient to elicit a detectable but still sub-lethal cell stress re-
sponse, it was considered suitable for further experiments aimed at investigating the potential
protective effect of our compounds towards the SA-induced effect. Pretreatment for 3h with
4HEP, 2HEP, DHI and THI resulted in a significant reduced percentage of apoptotic nuclei,
which decreased from 37% of the control to around 20% (Panel C in S9 Fig, black bars) (p
value < 0.05 for 2HEP and DHI, ꢀ 0.01 for 4HEP and THI). The other hydroxylated com-
pounds did not significantly alter the sodium arsenite (SA)-induced apoptotic effect.
To better assess a potential antioxidant activity of our hydroxylated compounds, a cell stress
response was analyzed, which is activated under mild stress conditions when a transient trans-
lational arrest occurs. As underlined in the Introduction section, exposure to SA inhibits pro-
tein synthesis and activates multiple stress signaling pathways, including the formation of
stress granules (SGs) [4,41–43]. SGs are cytoplasmic foci composed of 40S ribosomal subunits,
initiation translation factors and their associated mRNA transcripts, which aggregate when
translation initiation is stalled. The SGs formation is reversible and the protein synthesis can be
restored, if the stress condition is recovered. To investigate the potential antioxidant effect of
our hydroxylated compounds, we examined the occurrence and the number of stress granules
(
SGs) in H9c2 cells both under normal growth and SA-induced stress conditions. SGs were de-
tected by immunofluorescence and confocal microscopy analysis using the marker PABP
poly-A binding protein) (Materials and Methods and Fig 5). To estimate the antioxidant
(
Fig 5. Immunofluorescence assay. Effect of sodium arsenite on the formation of stress granules:
immunofluorescence and statistical analysis. PABP mAb and Cy3-conjugated goat anti-mouse F(ab’)
2
were
used to detect SGs in H9c2 cells cultured under normal growth (A) and SA-stress conditions (B). Nuclei are
stained with DAPI. Scale bars: 10μm. (C) Effect of pretreatment with hydroxylated compounds in SA-treated
H92c cardiomyoblasts. The table reports SGs number for cell (Mean ± SEM) that was obtained by using
“Analyze Particles” plugin of the image software ImageJ (pixel unit: 1,5–2,0; Circularity: 0,99–1,00). Statistical
analysis (unpaired t test, two tailed; (*, p ꢀ 0.05; **, p ꢀ 0.01). Tyr: tyrosol; Hyd: hydroxytyrosol.
doi:10.1371/journal.pone.0124427.g005
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
14 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
activity, SGs number per cell was calculated by using a statistical analysis, applied to at least
three images acquired analyzing a minimum of 350–400 cells. When H9c2 cells were cultured
under normal growth conditions, in the presence of the hydroxylated compounds, no signifi-
cant change in SGs formation was observed (11.7 ± 4.4) when compared to the control, con-
firming that the compounds tested do not alter the cellular status (data not shown). In SA-
treated cells, SGs were instead easily identified and the statistical analysis revealed the presence
of 55.3 ± 3.7 SGs per cell (Fig 5). When pre-treatment with the hydroxylated compounds was
performed before the SA-induced oxidative stress, a strong and statistically significant decrease
in SGs number was observed (Fig 5). 2HEP and THI, again, showed a higher antioxidant activ-
ity compared to the other hydroxylated compounds. A putative antioxidant activity of the aro-
matic non-hydroxylated substrates used was also evaluated. Their effect on SGs in stressed
H9c2 cells was analyzed (data not shown), and no significant decrease in SGs number was ob-
served, when compared to the control.
Conclusions
Aromatic nuclei are, for their chemical versatility, ideal candidates to create molecules with
multiple pharmacological effects. Phenols and catechols, in particular, are promising starting
points to merge with other pharmacophores thus obtaining multipotent agents with antioxi-
dant effects and beyond. The different studies presented on the ToMO multicomponent system
in more than a decade [18,20–21,23–31] described the unique versatility of the catalytic activity
of this enzyme, which allows to obtain hydroxylated derivatives from a wide array of aromatic
substrates, highlighting its role as a potential resource for the biosynthesis of phenolic and
catecholic compounds.
We have previously shown that a fine-tuning of the regioselectivity and of the catalytic effi-
ciency of ToMO on 2-phenylethanol, a non-natural substrate, to produce known antioxidants
such as tyrosol and hydroxytyrosol could be achieved by using an optimized computational
model that allows a careful alteration of the shape of the active site [26,18].
In this work we investigated the use of ToMO for the biosynthesis of six aromatic antioxi-
dants, starting from three commercially available aromatic compounds that are non-natural
substrates of the enzyme. By using either the wt enzyme or ToMO mutant E103G/F176A-cata-
lyzed biotransformations, six hydroxylated compounds were obtained. Although not all of
them were able to reduce the DPPH stable radical, a common test system for determining the
scavenging properties of putative antioxidants in vitro, all hydroxylated compounds shared a
common, although differential, antioxidant effect on eukaryotic cells of the H9c2 cell line sub-
jected to a mild oxidative stress induced by sodium arsenite. The discrepancy between the two
assays showed from one side a possible limitation in the use of the DPPH assay as the unique
methodology to assess the in vitro antioxidant potential of hydroxylated aromatic compounds,
and on the other hand confirms that the antioxidant effect of phenols and catechols frequently
observed in cells might not be due to a simple scavenge of free radicals, but might be dependent
on other molecular events that have not been completely elucidated yet.
The availability of the molecules produced under the present study undoubtedly opens new
possibilities for obtaining a whole new set of antioxidant molecules by using the ToMO multi-
component system as biocatalyst using a wide array of commercially available monocyclic aro-
matic compounds as starting substrates.
Supporting Information
S1 Fig. Bioconversion of 2-phenylethanol. Natural antioxidants tyrosol and hydroxytyrosol
produced from the hydroxylation of 2-phenylethanol catalyzed by ToMO mutants E103G/
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
15 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
F176T and E103G/F176I (Notomista E., Scognamiglio R., Troncone L., Donadio G., Pezzella
A., Di Donato A., and Izzo V. Tuning the specificity of the recombinant multicomponent tolu-
ene o-xylene monooxygenase from Pseudomonas sp. strain OX1 for the biosynthesis of tyrosol
from 2-phenylethanol. Appl. Environ. Microbiol. 2011.77(15): 5428–37. http://aem.asm.org/
content/77/15/5428.full).
(
TIF)
S2 Fig. Time course chromatograms. Time course formation of the hydroxylated products
deriving from the ToMO-catalyzed bioconversion of: (Panel A) 2-phenoxyethanol, (Panel B)
phthalan and (Panel C) 2-indanol. Chromatograms were extracted at λ = 280 nm. The 2-inda-
nol bioconversion was performed by using ToMO mutant E103G/F176A.
(
TIF)
S3 Fig. NMR analysis. NMR analysis of the isolated products deriving from the ToMO-cata-
lyzed bioconversion of: 2-phenoxyethanol (Compounds 1, 2 and 3), phthalan (Compound 4)
and 2-indanol (Compounds 5 and 6). The structures deduced for each new compound ob-
tained are also presented.
(
TIF)
S4 Fig. Mass spectrometry analysis. Mass spectrometry analysis and molecular weights ob-
tained for the isolated products deriving from the ToMO-catalyzed bioconversion of: 2-phe-
noxyethanol (Compounds 1, 2 and 3), phthalan (Compound 4) and 2-indanol (Compounds 5
and 6).
(
TIF)
S5 Fig. Estimation of extinction coefficients. For each hydroxylated compound isolated, the
εat λmax of a similar model compound is reported which was used for the determination of the
concentration throughout this study.
(
TIF)
S6 Fig. Modelling. Monte Carlo minimized models of the complexes between ToMO or
E103G,F176A)-ToMO and the arenium intermediates for the toluene/p-cresol (S4M) and the
-indanol/2,5-dihydroxyindan (25I) reactions. Carbon atoms are shown in green (ToMO/
(
2
S4M), magenta (ToMO/25I) and yellow [(E103G,F176A)-ToMO/25I]. Oxygen atoms are
shown in red, nitrogen atoms in blue, sulphur atoms in dark yellow. Hydrogen atoms are not
shown. Iron ions are shown as orange spheres.
(
TIF)
S7 Fig. DPPH assay. DPPH reduction (expressed as the percentage of the DPPH effectively
reduced, Y axis) as a function of the μM concentration of the compound tested (X axis). 4-
(
2-Hydroxyethoxy)phenol (4HEP); 2-(2-Hydroxyethoxy)phenol (2HEP); 2,5,6-trihydroxyin-
dan (THI); Hydroxytyrosol.
TIF)
(
S8 Fig. Oxidation pathway. Two-step oxidation pathway proposed for THI as a consequence
of its peculiar structure showing an-OH substituted five member ring condensed with the cate-
chol moiety. First oxidation step results in the formation of expected orthoquinone moiety
which can itself undergoes tautomerization affording-via transient quinone methides- a cyclo-
pentanone condensed catechol, again susceptible to act as reductant (Pezzella A., Lista L., Na-
politano A., and d’Ischia M. Tyrosinase-catalyzed oxidation of 17beta-estradiol: structure
elucidation of the products formed beyond catechol estrogen quinones. Chem.Res. Toxicol.
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
16 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
2
005.18(9): 1413–9. http://pubs.acs.org/doi/abs/10.1021/tx050060o).
(
TIF)
S9 Fig. MTT viability assay and apoptosis assay. (Panel A) H9c2 cells were cultured under
normal growth conditions, incubated in the presence of either the substrates (dark white bars)
or the hydroxylated derivatives (black bars) for 72 hours. Cell viability was determined by
means of ABS570 compared to the control (white bar), that is cells without any treatment. Data
shown are the means ± s.d of at least three repeats, of a representative experiment. A statistical
analysis by two-tailed Student’s t was performed. (Panel B) and (Panel C) Acridine orange
(
AO) and ethidium bromide (EB) staining of nuclei to identify apoptotic nuclei. H9c2 cells
were cultured under either normal growth conditions (image on the left, panel B, and white
bars in panel C), or SA-induced oxidative stress (image on the right, panel B, and black bars in
panel C).
(
TIF)
Acknowledgments
Authors are indebted to Dr. Giovanna Benvenuto at the Microscopy Service of Stazione Zoolo-
gica “A. Dohrn” (Naples, Italy) for technical assistance.
Author Contributions
Conceived and designed the experiments: GD CS EN VI. Performed the experiments: GD CS
AP FDL. Analyzed the data: GD CS FDL EP CDC AP ADD VI. Contributed reagents/materi-
als/analysis tools: EN EP AP. Wrote the paper: EN AP CDC ADD VI.
References
1.
Agarwal A, Gupta S, Sharma RK. Role of oxidative stress in female reproduction. Reprod. Biol Endocri-
nol. 2005; 3:28–48. Available: http://www.ncbi.nlm.nih.gov/pmc/articles/PMC1215514/. PMID:
16018814
2.
Apel K, Hirt H. Reactive oxygen species: metabolism, oxidative stress, and signal transduction. Annu
Rev Plant Biol. 2004.; 55:373–399. Available: http://www.annualreviews.org/doi/abs/10.1146/annurev.
arplant.55.031903.141701?url_ver=Z39.88-2003&rfr_dat = cr_pub%3Dpubmed&rfr_id = ori%3Arid%
3Acrossref.org&journalCode = arplant. PMID: 15377225
3.
Marco S, Rullo R, Albino A, Masullo M, De Vendittis E, Amato M. The thioredoxin system in the dental
caries pathogen Streptococcus mutans and the food-industry bacterium Streptococcus thermophilus.
Biochimie. 2013; 95(11):2145–56. Available: http://www.ncbi.nlm.nih.gov/pubmed/23954859. doi: 10.
1016/j.biochi.2013.08.008 PMID: 23954859
4
.
.
Anderson P, Kedersha N. Stressful initiations. J Cell Sci. 2002; 115:3227–34. Available: http://jcs.
biologists.org/content/115/16/3227.long. PMID: 12140254
5
Conti V, Corbi G, Russomanno G, Simeon V, Ferrara N, Filippelli W, et al. Oxidative stress effects on
endothelial cells treated with different athletes' sera. Med Sci Sports Exerc 2012; 44(1):39–49. Avail-
able: http://journals.lww.com/acsm-msse/pages/articleviewer.aspx?year=2012&issue=01000&article=
00006&type = abstract. doi: 10.1249/MSS.0b013e318227f69c PMID: 21659898
6.
7.
8.
9.
Foti MC. Antioxidant properties of phenols. J Pharm Pharmacol. 2007; 59(12):1673–85. Available:
http://onlinelibrary.wiley.com/doi/10.1211/jpp.59.12.0010/abstract. PMID: 18053330
Yang DP, Ji HF, Tang GY, Ren W, Zhang HY. How many drugs are catecholics. Molecules. 2007; 12
(
4):878–84. Available: http://www.mdpi.com/1420-3049/12/4/878. PMID: 17851440
Ingold KU. Inhibition of the autoxidation of organic substances in the liquid phase. Chem. Rev. 1961;
1: 563–589.
6
Gülçin I. Antioxidant activity of food constituents: an overview. Arch. Toxicol. 2012; 86:345–391. Avail-
able: http://link.springer.com/article/10.1007%2Fs00204-011-0774-2. doi: 10.1007/s00204-011-0774-
2
PMID: 22102161
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
17 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
1
1
1
0. Kelsey NA, Wilkins HM, Linseman DA. Nutraceutical antioxidants as novel neuroprotective agents.
Molecules. 2010; 15:7792–7814. Available: http://www.mdpi.com/1420-3049/15/11/7792. doi: 10.
3
390/molecules15117792 PMID: 21060289
1. Liu RH. Health-promoting components of fruits and vegetables in the diet. Adv. Nutr. 2013; 4(3):384S–
92S. Available: http://advances.nutrition.org/content/4/3/384S.long. doi: 10.3945/an.112.003517
3
PMID: 23674808
2. Raederstorff D. Antioxidant activity of olive polyphenols in humans: a review. Int Jvitam Nutr Res. 2009;
79(3):152–65. Available: http://www.ncbi.nlm.nih.gov/pubmed/20209466) doi: 10.1024/0300-9831.79.
3.152 PMID: 20209466
1
3. Visioli F, Bernardini E. Extra virgin olive oil's polyphenols: biological activities Curr Pharm Des. 2011;
7(8):786–804. Available: http://www.ncbi.nlm.nih.gov/pubmed/21443485. PMID: 21443485
1
1
4. Schweigert N, Zehnder AJ, Eggen RI. Chemical properties of catechols and their molecular modes of
toxic action in cells, from microorganism to mammals. Environ Microbiol 2001; 3(2):81–91. Available:
http://www.ncbi.nlm.nih.gov/pubmed/11321547. PMID: 11321547
15. Zhang HY. Theoretical Investigation on Free Radical Scavenging Activity of 6,7-Dihydroxyflavone.
Quant Struct-Act Relat. 2000; 19:50–53. Available: http://onlinelibrary.wiley.com/doi/10.1002/%28SICI
%291521-3838%28200002%2919:1%3C50::AID-QSAR50%3E3.0.CO;2-%23/abstract.
1
1
6. Zhang HY. Structure-activity relationships and rational design strategies for radical-scavenging dihy-
droxyflavone. Curr Comput-Aided Drug Des. 2005; 1:257–273.
7. Huang C, Ghavtadze N, Chattopadhyay B, Gevorgyan V. Synthesis of catechols from phenols via Pd-
catalyzed silanol-directed C-H oxygenation. J Am Chem Soc. 2011; 133(44):17630–3. doi: 10.1021/
ja208572v PMID: 21999512
1
8. Notomista E, Scognamiglio R, Troncone L, Donadio G, Pezzella A, Di Donato A et al. Tuning the speci-
ficity of the recombinant multicomponent toluene o-xylene monooxygenase from Pseudomonas sp.
strain OX1 for the biosynthesis of tyrosol from 2-phenylethanol. Appl. Environ. Microbiol. 2011; 77
(
15):5428–37. Available: http://aem.asm.org/content/77/15/5428.full. doi: 10.1128/AEM.00461-11
PMID: 21666013
1
9. Torres Pazmino DE, Winkler M, Glieder A, Fraaije MW. Monooxygenases as biocatalysts: classifica-
tion, mechanistic aspects and biotechnological applications. J Biotechnol 2010; 146:9–24. Available:
http://www.ncbi.nlm.nih.gov/pubmed/?term=Monooxygenases+as+biocatalysts%3A+classi%EF%AC
%81cation%2C+mechanistic+aspects+and+biotechnological+applications.+J.+Biotechnol.+146%
3A9-24. doi: 10.1016/j.jbiotec.2010.01.021 PMID: 20132846
2
2
2
0. Brouk M, Fishman A. Protein engineering of toluene monooxygenases for synthesis of hydroxytyrosol.
Food Chem 2009; 116:114–121. Available: http://www.sciencedirect.com/science/article/pii/
S0308814609002064.
1. Dror A, Fishman A. Engineering non-heme mono- and dioxygenases for biocatalysis. Comput. Struct.
Biotechnol. 2012;J. doi: 10.5936/csbj.201209011 Available: http://www.ncbi.nlm.nih.gov/pmc/articles/
PMC3962191/.
2. Murray LJ, Lippard SJ. Substrate trafficking and dioxygen activation in bacterial multicomponent mono-
oxygenases. Acc Chem Res. 2007; 40:466–474. Available: http://www.ncbi.nlm.nih.gov/pubmed/?
term=Substrate+traf%EF%AC%81cking+and+dioxygen+activation+in+bacterial+multicomponent
+monooxygenases.+Acc.+Chem.+Res.+40%3A466%E2%80%93474. PMID: 17518435
2
3. Notomista E, Lahm A, Di Donato A, Tramontano A. Evolution of bacterial and archaeal multicomponent
monooxygenases. J. Mol Evol. 2003; 56:435–44. Available: http://www.ncbi.nlm.nih.gov/pubmed/?
term=Evolution+of+bacterial+and+archaeal+multicomponent+monooxygenases.+J.+Mol.+Evol.+56%
3A435%E2%80%9344. PMID: 12664163
2
4. Cafaro V, Scognamiglio R, Viggiani A, Izzo V, Passaro I, Notomista E et al. Expression and purification
of the recombinant subunits of toluene/o-xylene monooxygenase and reconstitution of the active com-
plex. Eur. J. Biochem 2002; 269:5689–5699. Available: http://onlinelibrary.wiley.com/doi/10.1046/j.
1432-1033.2002.03281.x/abstract;jsessionid=6559BDA93C647648DB9B27607AE64321.f04t02.
PMID: 12423369
2
5. Cafaro V, Izzo V, Scognamiglio R, Notomista E, Capasso P, Casbarra A, et al. Phenol hydroxylase and
toluene/o-xylene monooxygenase from Pseudomonas stutzeri OX1: interplay between two enzymes.
Appl Environ Microbiol. 2004; 70:2211–2219. Available: http://aem.asm.org/content/70/4/2211.long.
PMID: 15066815
26. Notomista E, Cafaro V, Bozza G, Di Donato A. Molecular determinants of the regioselectivity of tolu-
ene/o-xylene monooxygenase from Pseudomonas sp. strain OX1. Appl Environ Microbiol. 2009;
75:823–836. Available: http://www.ncbi.nlm.nih.gov/pubmed/?term=Molecular+determinants+of+the
+
+
regioselectivity+of+toluene%2Fo-xylene+monooxygenase+from+Pseudomonas+sp.+strain+OX1.
Appl.Environ.Microbiol.75%3A823%E2%80%93836. doi: 10.1128/AEM.01951-08 PMID: 19074607
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
18 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
2
7. Cafaro V, Notomista E, Capasso, Di Donato A. Mutation of glutamic acid 103 of toluene o-xylene mono-
oxygenase as a means to control the catabolic efficiency of a recombinant upper pathway for degrada-
tion of methylated aromatic compounds. Appl Environ Microbiol 2005; 71:4744–4750. Available: http://
aem.asm.org/content/71/8/4744.long. PMID: 16085871
2
8. Feingersch R, Shainsky J, Wood TK, Fishman A. Protein engineering of toluene monooxygenases for
synthesis of chiral sulfoxides. Appl Environ Microbiol. 2008; 74:1555–1566. (http://www.ncbi.nlm.nih.
gov/pmc/articles/PMC2258606/. doi: 10.1128/AEM.01849-07 PMID: 18192418
2
9. Sazinsky MH, Bard J, Di Donato A, Lippard SJ. Crystal structure of the toluene/o-xylene monooxygen-
ase hydroxylase from Pseudomonas stutzeri OX1. Insight into the substrate specificity, substrate
channeling, and active site tuning of multicomponent monooxygenases. J. Biol Chem 2004;
279:30600–30610. Available: http://www.jbc.org/content/279/29/30600.full. PMID: 15096510
3
0. Vardar G, Wood TK. Protein Engineering of Toluene-o-Xylene Monooxygenase from Pseudomonas
stutzeri OX1 for Synthesizing 4-Methylresorcinol, Methylhydroquinone, and Pyrogallol. Appl Environ
Microbiol. 2004; 70(6):3253–3262. Available: http://aem.asm.org/content/70/6/3253. PMID: 15184119
3
1. Vardar G, Ryu K, Wood TK. Protein engineering of toluene-o-xylene monooxygenase from Pseudomo-
nas stutzeri OX1 for oxidizing nitrobenzene to 3-nitrocatechol, 4-nitrocatechol, and nitrohydroquinone.
J Biotechnol. 2005; 115(2):145–56. Available: http://www.ncbi.nlm.nih.gov/pmc/articles/PMC427803/.
PMID: 15607233
3
2. Bernini R, Merendino N, Romani A, Velotti F. Naturally occurring hydroxytyrosol: synthesis and antican-
cer potential. Curr Med Chem 2013; 20(5):655–70. Available: http://www.eurekaselect.com/106829/
article. PMID: 23244583
3
3. Granados-Principal S, Quiles JL, Ramirez-Tortosa CL, Sanchez-Rovira P, Ramirez-Tortosa MC.
Hydroxytyrosol: from laboratory investigations to future clinical trials.Nutr Rev. 2010; 68(4):191–206.
Available: http://nutritionreviews.oxfordjournals.org/content/68/4/191. doi: 10.1111/j.1753-4887.2010.
00278.x PMID: 20416016
3
3
3
4. Manna C, Migliardi V, Sannino F, De Martino A, Capasso R. Protective effects of synthetic hydroxytyro-
sol acetyl derivatives against oxidative stress in human cells. J. Agric Food Chem. 2005; 53:9602–
9607. Available: http://www.ncbi.nlm.nih.gov/pubmed/?term=Protective+effects+of+synthetic
+
+
hydroxytyrosol+acetyl+derivatives+against+oxidative+stress+in+human+cells.+J.+Agric.+Food
Chem.+53%3A9602%E2%80%939607. PMID: 16302783
5. Rietjens SJ, Bast A, Haenen GR. New insights into controversies on the antioxidant potential of the
olive oil antioxidant hydroxytyrosol. J. Agric Food Chem. 2007; 55:7609–7614. Available: http://www.
ncbi.nlm.nih.gov/pubmed/?term = .+New+insights+into+controversies+on+the+antioxidant+potential
+of+the+olive+oil+antioxidant+hydroxytyrosol.+J.+Agric.+Food+Chem.+55%3A7609%E2%80%
937614. PMID: 17683140
6. Waterman E, Lockwood B. Active components and clinical applications of olive oil. Altern Med Rev.
007; 12:331–342. Available: http://www.ncbi.nlm.nih.gov/pubmed/?term=Active+components+and
clinical+applications+of+olive+oil.+Altern.+Med.+Rev.+12%3A331%E2%80%93342. PMID:
8069902
2
+
1
3
7. Huang D, Ou B, Prior RL. The Chemistry behind Antioxidant Capacity Assays. J. Agric Food Chem.
005; 53(6):1841–1856. PMID: 15769103
2
3
8. Kedare SB, Singh RP. Genesis and development of DPPH method of antioxidant assay. J. Food Sci
Technol. 2011; 48(4):412–422. Available: http://www.ncbi.nlm.nih.gov/pmc/articles/PMC3551182/?
report = reader. doi: 10.1007/s13197-011-0251-1 PMID: 23572765
3
4
4
9. Watkins SJ, Borthwick GM, Arthur HM. The H9c2 cell line and primary neonatal cardiomyocyte cells
show similar hypertrophic responses in vitro. In Vitro Cell Dev Biol Anim. 2011; 47, 125–31. Available:
http://www.ncbi.nlm.nih.gov/pubmed/21082279. doi: 10.1007/s11626-010-9368-1 PMID: 21082279
0. Zordoky BN, El-Kadi AO. H9c2 cell line is a valuable in vitro model to study the drug metabolizing en-
zymes in the heart. J. Pharmacol Toxicol Methods. 2007; 56:317–22. Available: http://www.ncbi.nlm.
nih.gov/pubmed/17662623. PMID: 17662623
1. Anderson P, Kedersha N. Stress granules: the Tao of RNA triage. Trends Biochem Sci. 2008; 33
(
3):141–50. Available: http://www.cell.com/trends/biochemical-sciences/abstract/S0968-0004(08)
0
2
0026-?_returnURL=http%3A%2F%2Flinkinghub.elsevier.com%2Fretrieve%2Fpii%
FS0968000408000261%3Fshowall%3Dtrue. doi: 10.1016/j.tibs.2007.12.003 PMID: 18291657
4
4
2. Buchan JR, Parker R. Eukaryotic stress granules: the ins and outs of translation. Mol Cell. 2009;
36:932–41. Available: http://www.ncbi.nlm.nih.gov/pmc/articles/PMC2813218/. doi: 10.1016/j.molcel.
2009.11.020 PMID: 20064460
3. Kedersha N, Ivanov P, Anderson P. Stress granules and cell signaling: more than just a passing
phase? Trends Biochem Sci. 2013; 38(10):494–506. Available: http://www.ncbi.nlm.nih.gov/pmc/
articles/PMC3832949/. doi: 10.1016/j.tibs.2013.07.004 PMID: 24029419
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
19 / 20

Monooxygenase Mediated Biosynthesis of Aromatic Antioxidants
44. Sambrook J, Fritsch E, Maniatis T. Molecular Cloning. A Laboratory Manual. Cold Spring Harbor Labo-
ratory Press, Cold Spring Harbor, New York. 1989; (http://trove.nla.gov.au/work/13615226.
4
5. Ribble D, Goldstein NB, Norris DA, Shellman YG. A simple technique for quantifying apoptosis in 96-
well plates. BMC Biotechnol. 2005; 5:12. Available: http://www.biomedcentral.com/1472-6750/5/12.
PMID: 15885144
46. Jimenez-Escrig A, Jimenez-Jimenez I, Sanchez-Moreno C, Saura-Calixto F. Evaluation of free radical
scavenging of dietary carotenoids by the stable radical 2,2-diphenyl-1-picrylhydrazyl. J. Sci Food Agric.
2
2
000; 80(11):1686–1690. Available: http://onlinelibrary.wiley.com/doi/10.1002/1097-0010%
820000901%2980:11%3C1686::AID-JSFA694%3E3.0.CO;2-Y/abstract.
4
7. Owen RW, Giacosa A, Hull WE, Haubner R, Würtele G, Spiegelhalder B, et al. Olive-oil consumption
and health: the possible role of antioxidants. Lancet Oncol. 2000; 1:107–12. Available: http://www.ncbi.
nlm.nih.gov/pubmed/11905662. PMID: 11905662
4
8. Mohajeri A, Somayeh Asemani S. Theoretical investigation on antioxidant activity of vitamins and phe-
nolic acids for designing a novel antioxidant. J. Mol Struct. 2009; 930 (1–3): 15–20. Available: https://
www.infona.pl/resource/bwmeta1.element.elsevier-ddbabf11-45d3-374b-9151-f3e89cb0a36a.
PLOS ONE | DOI:10.1371/journal.pone.0124427 April 27, 2015
20 / 20
