Copper Nanoparticles Decorated Inside or Outside Carbon Nanotubes Used for Methyl Acetate Hydrogenation
of deionized water was orderly dropped in. Then a dry
sample could be obtained after further 30 min ultrasound
treatment. Subsequently, the obtained sample was dried
at 373 K in air for 10 h, and calcined at 623 K under
Ar atmosphere for 3 h. The final sample was defined as
Cu-inside-CNTs.
The Cu-outside-CNTs was obtained by the similar
impregnation method to that of Cu-inside-CNTs, but hav-
ing a specific pre-filling procedure on CNTs. Here, the
pre-filling way used on CNTs by filling xylene in its chan-
1
1
nels are similar to the precursor report. Briefly, before the
Cu(NO ꢀ solution impregnation process, the acid treated
3
2
CNTs with opened ends were first pre-impregnated with
ml xylene at the assistance of ultrasound, inhibiting the
entrance of Cu(NO ꢀ solution into its inner wall. After
1
3
2
that, the CNTs were impregnated with Cu(NO ꢀ solution,
3
2
following by drying at 353 K in air for 2 h and calcining
at 623 K in Ar atmosphere for 3 h. The final samples were
defined as Cu-outside-CNTs. Both of these two types of
Cu loaded CNTs, Cu-outside-CNTs and Cu-inside-CNTs,
have the same Cu-content of 10 wt%. Moreover, another
two samples with higher Cu loading amount, 20 wt% and
4
0 wt%, as reference, were also prepared by the same
method to that of 10 wt% Cu-inside-CNTs.
The microstructures of carbon nanotubes samples
were characterized with transmission electron microscopy
Fig. 1. TEM photos of (a) Cu-outside-CNTs after reduction, (b) Cu-
inside-CNTs after reduction and (c) XRD patterns of Cu-outside-CNTs
(
TOPCON EM-002B working at 120 kV). The crystal
Delivered by Publishing Technologyat fot e:r Mr e ad ui nc ti Co nI Da n ids C8 u0 - i0n 0s i 4d e8- C0 N5 T (s J Pa f Pt e r) reduction. (Reduction with
structure of the materials was confirmed by X-ray diffrac-
tion (XRD) with a Rigaku D/max-2550 V diffractometer
IP: 128.135.12.127 On: Fri ,1 01 0 0% OH c
ta t2 507 13 4K 0f o2 r: 13 01 h: 5) .6
2
Copyright: American Scientific Publishers
employing Cu Kꢁ radiation (ꢂ = 1ꢃ54056 Å).
illustration of the preparation process of Cu-outside-CNTs
was showed in Figure 2. The xylene, here, was used to
lock the CNTs channels temporarily before the decora-
tion of the exterior CNTs surface with Cu clusters, which
can effectively prevent the access of Cu(NO ꢀ solution
All the catalytic reactions were conducted with a fixed-
bed stainless steel reactor (9.5 mm OD). 0.5 g catalyst
was loaded into the reactor. Before the reaction, the cata-
lysts were reduced in situ by a flow of pure hydrogen at
5
73 K for 10 h. After being cooled to the reaction tem-
3 2
1
1
infiltrating into CNTs channels. Furthermore, the higher
boiling point of xylene than that of water can also allows
the preferential evaporation of water on the outside of
nanotubes, leading to the unique copper loading only on
the external surfaces of CNTs. Different from Cu-outside-
CNTs, almost all of the Cu nanoparticles of Cu-inside-
CNTs were filled inside the channel of CNTs shown in
Figure 1(b). The formation of Cu nanoparticles inside
CNTs should be attributed to the following reasons: First,
the bigger size of CNTs channels was beneficial for solu-
tion entering to the inner cavities of CNTs. Second, most
of the ends of CNTs have been opened after the concen-
trated nitric acid treatment. Relatively low surface tension
of water and the capillary force donated by CNTs chan-
nels ensured that an equal volume liquid can be sucked
by CNTs channels entirely. Third, the additional water
added in the second step for Cu-inside-CNTs preparation
shown in Figure 2 helped to wash the residual copper
salt, shifting them into CNTs channels. For these two type
catalysts, Cu-outside-CNTs and Cu-inside-CNTs, their Cu
nanoparticles size are in the range from 10 to 18 nm
perature, the flow rate of pure hydrogen was changed to
−1
8
0 ml · min and the reaction pressure were maintained
at 3 MPa. Then, the MA was injected by a pump with
−1
the flow rate of 0.9 g·h . The liquid MA was evaporated
to MA gas by heater band, and carried into the reactor
by the hydrogen flow. The CO, CH , CO and Ar were
4
2
analyzed online by the gas chromatograph equipped with
TCD detector. The liquid products after catalytic reaction
were collected with an ice water trap using 1-butanol as
solvent, and analyzed by another gas chromatograph with
flame-ionization detector (FID), in which 1-propanol was
employed as the internal standard.
3. RESULTS AND DISCUSSION
Figures 1(a) and (b) exhibit TEM images of Cu-outside-
CNTs and Cu-inside-CNTs catalysts after reduction at
5
73 K with 100% H2 for 10 h, respectively. For Cu-
outside-CNTs catalyst, Cu nanoparticles with the size from
0 to 15 nm had been deposited evenly on the outer sur-
1
face of CNTs, as shown in Figures 1(a). The schematic
