SYNTHETIC COMMUNICATIONS
Vol. 32, No. 19, pp. 3041–3045, 2002
MULTIGRAM-SCALE
STEREOSELECTIVE SYNTHESIS OF
MESO-1,3-BUTADIENE BISEPOXIDE
David J. Claffey
University of Colorado Health Sciences Center,
Dept. of Pharmaceutical Sciences, 4200 E.
Ninth Avenue, Box C238, Denver, CO 80262, USA
E-mail: david.claffey@uchsc.edu
ABSTRACT
meso-1,3-Butadiene bisepoxide, a potential building block for
natural product synthesis and of interest as a toxic metabolite
of butadiene, was synthesized in multi-gram scale in two steps
from meso-erythritol in good overall yield.
Key Words: Mesobutadiene bisepoxide; Synthesis; Metabo-
lite; Butadiene
INTRODUCTION
meso-1,3-Butadiene bisepoxide (meso-BBO) is a small symmetrical
reactive compound that has significant potential as a building block for
natural product synthesis.[1] It, along with its diastereoisomers, is also of
great interest to toxicologists at present.[2,3] BBO is a highly toxic metabolite
of butadiene, a widely used monomer in the polymer industry. Several
epidemiological studies have suggested an excess mortality for lymphatic
and hematopoetic cancers in the 65,000 workers that are potentially
3041
DOI: 10.1081/SCC-120012996
Copyright & 2002 by Marcel Dekker, Inc.
0039-7911 (Print); 1532-2432 (Online)
www.dekker.com

MARCEL DEKKER, INC. • 270 MADISON AVENUE • NEW YORK, NY 10016
©2002 Marcel Dekker, Inc. All rights reserved. This material may not be used or reproduced in any form without the express written permission of Marcel Dekker, Inc.
3042
CLAFFEY
exposed to butadiene in the United States.[4] Arange of oxygenated
butadiene metabolites, including meso-BBO were synthesized in our labora-
tory by Sharpless epoxidation of 1-tosyloxy-2-hydroxy-3-butene, followed
by treatment with base.[5,6] This procedure sufficed for the milligram quan-
tities of meso-BBO needed for in vitro studies.[6,7] However, it was not
practical to scale-up these reactions for the multi-gram quantities needed
for in vivo inhalation exposure studies, or indeed for multistep organic
syntheses. Asuitable alternative synthesis of meso-BBO could not be
found in the literature. It has been produced as an isomeric mixture,
generally through the epoxidation of butadiene[8] or butadiene monoxide,[9]
or from base catalyzed cyclization of dichlorobutanediol.[10] This commu-
nication will describe a practical synthesis of gram quantities of meso-BBO
in good yield starting from meso-erythritol.
RESULTS AND DISCUSSION
meso-Erythritol 1 was treated with 1.9 equivalents of tosyl chloride in
pyridine. Larger amounts of tosylate generally gave reduced yields. The
reaction easily afforded a mixture of the bis-tosylate 2 in good yield and
adequate purity along with small amounts of mainly mono-, tri-, and tetra-
tosylate (Sch. 1). The reaction mixture did not require any further purifica-
tion, as these by-products would ultimately give non-volatile products
upon reaction with potassium hydroxide. The final step was safely carried
out, by suspending the bis-tosyl reaction mixture in dichloromethane, and
adding 2 equivalents of freshly powdered potassium hydroxide. The result-
ing insoluble potassium tosylate was easily filtered to give a dichloro-
methane solution of the bis-epoxide. The former was concentrated by
evaporation in a fumehood, leaving a more manageable volume of the
epoxide, with trace dichloromethane. The remaining solvent was removed
from the reaction mixture by fractional distillation. The product distilled as
a clear liquid. Its diastereomeric purity (95%) was determined by integration
of the 13C signals of the meso-BBO with those of the diastereomeric
D,L-BBO at ꢀ 43.9 and 50.9 ppm. The identity of the signals of its diaste-
Scheme 1.

MARCEL DEKKER, INC. • 270 MADISON AVENUE • NEW YORK, NY 10016
©2002 Marcel Dekker, Inc. All rights reserved. This material may not be used or reproduced in any form without the express written permission of Marcel Dekker, Inc.
MESO-1,3-BUTADIENE BISEPOXIDE
3043
reoisomers were confirmed by comparison with an NMR spectrum of
D,L-butadiene bisepoxide (Aldrich Chemical Co., Milwaukee, WI). Much
of the D,L-BBO may have been produced as a result of the reaction of the
by-product, 1,3-O-tosyl-erythritol, with KOH. If higher diastereomeric
purity is required, the crude bis-tosylate could be further purified
by recrystallization before reaction with base. meso-BBO required storage
at ꢀ20ꢁC.
Though established synthetic steps were used in this synthesis,[11,12] the
strength of this procedure is that it allows for the synthesis and isolation to a
high degree of physical and optical purity of this highly volatile and toxic
compound to be achieved relatively economically, in good yield, and with a
relatively high degree of safety.
EXPERIMENTAL
Note: meso-BBO is a suspected carcinogen. All operations must be
conducted with adequate safety precautions.
Asolution of meso-erythritol (100 g, 0.82 mol) in pyridine (3000 mL)
was cooled to 5ꢁC with stirring (magnetic). Tosyl chloride (296 g, 1.56 mol)
was added portionwise over 4 h while maintaining the temperature at
5–7ꢁC. Aclear solution resulted which became opaque, 30 min after the
last portion of chloride was added. The mixture was stirred for 12 h at
3–5ꢁC then was allowed to warm to room temperature. The resulting thick
suspension was evaporated under reduced pressure at 50ꢁC to give a thick
orange syrup (ca. 500 mL). This was dissolved in ethyl acetate (2000 mL)
and 5 M HCl was added dropwise with vigorous stirring (magnetic) until
the aqueous solution became acidic. The mixture was poured into a sepa-
rating funnel, the organic portion was removed and washed once with
distilled water (200 mL). The ethyl acetate solution was dried over magne-
sium sulfate, filtered, and evaporated under reduction pressure to give the
crude bis-tosylate as a thick orange syrup (223 g). This was suspended in
dichloromethane (1500 mL) and freshly powdered KOH (56 g, 1 mol) was
added over 30 min with vigorous stirring (magnetic). The mixture was
stirred for 2 h until TLC (silica; ethyl acetate : hexanes 1 : 1) showed that
no bis-tosylate (2) remained (Rf 0.5). The suspension was filtered and the
solid washed with dichloromethane. The dichloromethane was allowed to
evaporate in a fume hood (under a dry ice trap) to give an orange liquid.
This material was distilled under reduced pressure with vigorous stirring
using a fractionating column. meso-BBO (3) distilled as a clear liquid
between 26 and 28ꢁC (30 mmHg) (26 g, 37% yield). H NMR (300 MHz,
1
CDCl3): ꢀ 2.57 (2H, m), 2.70 (2H, m), 2.86 (2H, m). 13C NMR (75 MHz,
CDCl3): ꢀ 44.5, 50.42.

MARCEL DEKKER, INC. • 270 MADISON AVENUE • NEW YORK, NY 10016
©2002 Marcel Dekker, Inc. All rights reserved. This material may not be used or reproduced in any form without the express written permission of Marcel Dekker, Inc.
3044
CLAFFEY
ACKNOWLEDGMENTS
This work was supported in part by agreement 99-5 from the Health
Effects Institute and Lovelace Respiratory Research Institute, Albuquerque,
New Mexico 87185, USA.
REFERENCES
1. Hanesian, S. Total Synthesis of Natural Products: The Chiron Approach;
Pergamon Press: Oxford, 1983.
2. Henderson, R.F.; Barr, E.B.; Belinsky, S.A.; Benson, J.M.; Hahn, F.F.;
Menache, M.G. 1,3-Butadiene: Cancer, Mutations, and Adducts. Part I:
Carcinogenicity of 1,2,3,4-diepoxybutane. Research Report-H.E.I.
2000, 92(11–43), 45–48.
3. Saranko, C.J.; Meyer, K.G.; Pluta, L.J.; Henderson, R.F.; Recio, L.
Lung-Specific Mutagenicity and Mutational Spectrum in B6C3F1 1acI
Transgenic Mice Following Inhalation Exposure to 1,2-Epoxybutene.
Mutat. Res. 2001, 473(1), 37–49.
4. IARC. Occupational Exposures to Mists and Vapors from Strong
Inorganic Acids and Other Industrial Chemicals, 1,3-Butadiene. IARC
Monogr. 1992, 54, 237–287.
5. Neagu, C.; Tapio, H. Synthesis of Enantiomerically Pure 3-Butene-
1,2-Diol Derivatives via a Sharpless Asymmetric Epoxidation Route.
Tetrahedron Lett. 1993, 34(10), 1629–1630.
6. Nieusma, J.L.; Claffey, D.J.; Ruth, J.A.; Ross, D. Stereochemical
Aspects of the Conjugation of Epoxide Metabolites of Butadiene with
Glutathione in Rat Liver Cytosol and Freshly Isolated Rat Hepatocytes.
Tox. Sci. 1998, 43, 102–109.
7. Irons, R.D.; Pyatt, D.W.; Stillman, W.S.; Som, D.B.; Claffey, D.J.;
Ruth, J.A. Comparative Toxicity of Known and Putative Metabolites
of 1,3-Butadiene in Human CD34þ Bone Marrow Cells. Toxicology
2000, 150, 99–106.
8. Monnier, J.R. The Selective Epoxidation of Non-Allylic Olefins Over
Supported Silver Catalysts. 3rd World Congress on Oxidation
Catalysis: Studies in Surface Science and Catalysis. 1997, 110,
135–149.
9. Melnik, L.V.; Nozhnin, N.A.; Grechina, N.V.; Kryukov, S.I.;
Yegorova, L.M.; Danilova, A.S. Synthesis of 1,2,3,4-diepoxybutane
from 1,3-Butadiene Monoxide. Petroleum Chem. 1996, 36(5),
455–459.

MARCEL DEKKER, INC. • 270 MADISON AVENUE • NEW YORK, NY 10016
©2002 Marcel Dekker, Inc. All rights reserved. This material may not be used or reproduced in any form without the express written permission of Marcel Dekker, Inc.
MESO-1,3-BUTADIENE BISEPOXIDE
3045
10. Stojanowa-Antoszczyszyn, M.; Myszkowski, J.; Wisnik, I.;
Gawronska, A. Synthesis of Diepoxybutane from Dichloro-
butanediols. Przem. Chem. 1977, 56(5), 246–250. Chem. Abs. 88:6620r.
11. Kabalka, G.W.; Varma, M.; Varma, R.S. Tosylation of Alcohols.
J. Org. Chem. 1986, 51, 2386–2388.
12. Larock, R.C. Comprehensive Organic Transformations, 2nd Ed.; Wiley-
VCH: New York, 1999.
