Synthesis of novel derivatives of (benz)imidazo[2,1-b]pyrimido[4,5-d][1,3]
thiazine
Marzieh Akbarzadeh, Mehdi Bakavoli*, Hossein Eshghi and Ali Shiri
Department of Chemistry, Faculty of Science, Ferdowsi University of Mashhad, 91775-1436 Mashhad, Iran
Several derivatives of the novel heterocyclic systems 2-substituted-imidazo- and benzimidazo-[2,1-b]pyrimido[4,5-d][1,3]thiazine have
been synthesised through the one-pot cyclocondensation of 2,4-dichloro-5-(chloromethyl)-6-methylpyrimidine with imidazolidine-2-
thione and 1H-benzimidazole-2(3H)-thione and subsequently substituted by various secondary amines in moderately good yields.
Keywords: pyrimidothiazine, imidazolidine, benzimidazole, one-pot cyclocondensation
The1,3-thiazinestructureplaysacrucialroleinpharmacological
and biologically active compounds.1–4 Among the 1,3-thiazine-
containing heteroaryl-fused structures, pyrimidothiazine
derivatives have attracted wide interest due to their considerable
biological activities, such as anti-inflammatory, antitumour,
antibacterial, antiallergic and antipyretic activity.5–9 Examples
of synthetic methods to prepare pyrimidothiazine-containing
compounds include the reaction of 4-methoxy- and 4-ethoxy-
5-amino-6-mercaptopyrimidines with diethyl bromomalonate
in the presence of potassium hydroxide,10 cyclisation of
mercaptopyrimidine with benzylidine malononitrile in ethoxide
solution,11 the treatment of ethyl-2-cyano-3,3-bis(methylthio)
acrylate and thiourea in the presence of potassium
carbonate in dimethylformamide,12 condensation reaction of
thioxopyrimidine derivatives and 3-bromopropionic acid,13
one-pot multicomponent reaction of aryl isocyanides, dialkyl
acetylenedicarboxylates and thiouracils14 and condensation of
5-amino-4-thiopyrimidines with desyl chloride in the presence
of sodium acetate.15
Moreover, imidazothiazines, as other thiazine-fused structures,
have often been used as scaffolds in medicinal chemistry. Some
medicinal properties of imidazothiazine derivatives consist
of anticancer, anti-leukemia, antifungal, anti-inflammatory
and antisecretory activities.16–19 There are various methods
reported for the synthesis of imidazothiazines, including the
reaction of 5,5-diphenyl-2-thiohydantoin with α,β-unsaturated
nitriles,20 cyclisation of 5,5-diphenyl-2-thiohydantoins with
1,3-dibromopropane under phase-transfer catalysis conditions,21
the reaction of 3,3-dichloro-2-phenylacryloyl chloride with
mercaptoimidazoles,22 one-step reaction of benzimidazoline-
2-thione with cinnamoyl chloride23 and cyclisation of
benzimidazolethiones with ethyl 3-chloro-but-2-enoate.24
Considering the pharmacological and biological activities
of pyrimidothiazines and imidazothiazines and as part of
our ongoing studies dealing with the synthesis of various
fused pyrimidines,25–31 we describe here a facile synthesis
and structural elucidation of 2-substituted-imidazo- and
benzimidazo-[2,1-b]pyrimido[4,5-d][1,3]thiazines 8a–e and
9a–e as novel heterocyclic systems that may be good candidates
in designing new biologically active compounds.
Results and discussion
Initially, the reaction of 6-methylpyrimidine-2,4-(1H,3H)-
dione 1 with formaldehyde in aqueous NaOH solution gave
5-(hydroxymethyl)-6-methylpyrimidine-2,4-(1H,3H)-dione
2, which was subsequently treated with POCl3 to produce
2,4-dichloro-5-(chloromethyl)-6-methylpyrimidine 3.32 In
addition, imidazolidine-2-thione 4 and 1H-benzimidazole-
2(3H)-thione 5, used as binucleophiles, were prepared in
quantitative yield according to the previously published
methods.33,34 The reaction of 2,4-dichloro-5-(chloromethyl)-6-
methylpyrimidine 3 with binucleophiles 4 and 5 in CHCl3 at
−15 °C gave 2-chloro-4-methyl-8,9-dihydro-5H-imidazo[2,1-b]
pyrimido[4,5-d][1,3]thiazine
6 and 2-chloro-4-methyl-5H-
benzimidazo[2,1-b]pyrimido[4,5-d][1,3]thiazine
7 as new
heterocyclic systems (Scheme 1).
This reaction goes forward through combined nucleophilic
substitution and an addition–elimination reaction involving the
nitrogen and sulfur atoms in the binucleophiles followed by
elimination of two molecules of HCl. The evidence in support of
initial halide displacement from the chloromethyl group, rather
than the 4-Cl substituent was obtained from the comparison of
1
the H chemical shifts of methylene groups bonded to sulfur
in thiazine moieties with the SCH2–Ar function reported in
H
N
N
S
l
C
N
N
N
H
4
N
S
CHCl3 , -15 oC
Et3N
H
C
3
H
N
H
N
l
C
N
l
C
6
O
O
O
O
H
2CO
P
l
OC 3
H
N
N
l
C
HN
HN
H
O
S
N
H
C
3
H
H
3
C
C
N
3
l
C
N
N
H
5
1
2
3
N
S
CHCl3 , -15 oC
Et3N
H
C
3
7
Scheme 1
* Correspondent. E-mail: mbakavoli@um.ac.ir; mbakavoli@yahoo.com

JOURNAL OF CHEMICAL RESEARCH 2017 731
N
N
l
C
N
C
N
R2N
N
C
N
R2NH
N
N
S
EtOH, reflux
S
H
H
3
3
6
8a-e
N
N
l
C
N
N
R2N
N
N
R2NH
EtOH, reflux
N
N
S
S
H
C
H
C
3
3
7
9a-e
Entry
R2N-
8a,9a
8b,9b
8c,9c
8d,9d
3C
8e,9e
H
3C
H
Ph
O
N
N
N
N
N
N
N
Scheme 2
