A novel carbazolyl GFP chromophore analogue: Synthesis strategy and acidic pH-activatable
View Article Online
DOI: 10.1039/D0NJ01477J
lysosomal probe for tracing endogenous viscosity changes
Xu Zhi, Baoxing Shen, Ying Qian*
School of Chemistry and Chemical Engineering, Southeast University, Nanjing, Jiangsu 211189, China
Corresponding author E-mail address: yingqian@seu.edu.cn
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Abstract
Intracellular viscosity changes of the internal microenvironment will lead to many diseases, including
cancer, inflammation, neurodegenerative diseases. A novel carbazolyl GFP chromophore analogue Lys-
CzFP with acidic pH-activatable was designed for tracing lysosomal viscosity changes. The synthesis
developed is a new efficient, novel, one-pot procedure. Lys-CzFP, as a fluorescent molecular rotor, the
internal carbazole and benzazole moieties of Lys-CzFP are served as rotators, which could rotate around
the single C—C bond in the π-conjugated bridge. Lys-CzFP had a long emission wavelength at 560 nm and
a large Stokes shift of 78 nm. The fluorescence intensity of Lys-CzFP exhibited a significant enhancement
with increasing viscosity. The fluorescence intensity increased by 98-fold within 5 s from 1.0 cP to 1412
cP, with the fluorescence quantum yield (ϕF) increasing from 0.003 to 0.253 as well as the fluorescence
lifetime increasing from 0.25 ns to 1.12 ns, respectively. Furthermore, interference experiments indicated
that Lys-CzFP could respond to viscosity particularly. Besides, Lys-CzFP had excellent biocompatibility,
low cytotoxicity, and lysosomal localization. Together, Lys-CzFP was successfully applied for tracing
endogenous viscosity changes in living cells.
Keywords: Fluorescent protein; Viscosity probe; Excellent biocompatibility; Lysosome labelling; Living
cell imaging

New Journal of Chemistry
Page 2 of 21
1
2
3
4
5
View Article Online
DOI: 10.1039/D0NJ01477J
1．Introduction
6
7
8
9
Abnormal changes of intracellular viscosity are closely related to various diseases of
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2
humans,1,
such as Alzheimer’s disease(AD),3 diabetes,4 and amyloid beta-peptide.5
Traditional mechanical viscometers cannot measure the viscosity changes of cells or
organelles in real-time.6 In contrast, the fluorescence probe plays a vital role in tracing
viscosity changes in living cells.7-10 Therefore, the development of fluorescence platform for
tracing viscosity in cells or subcellular levels is crucial.11-14 Lysosomes play a critical role in
maintaining intracellular secretion, digestion organelles, and plasma membrane repair.15
Viscosity changes in lysosomes can bring about the dysfunction of lysosomes.16 Tons of
evidence have shown that lysosomes are the pathogenesis of diseases such as cancer, storage
disorders, neurodegenerative disorders.17, 18 Therefore, the development of probes that
accurately trace viscosity in living cells is in urgent demand.
Green Fluorescent Protein (GFP) has been applied as a bio-optical marker for tracing
numerous analytes.19-22 Liu et al. reported a series of GFP molecule derivatives detected
protein conformational collapse and demonstrated that they could fluoresce in protein
aggregates.23 Li et al. reported a viscosity probe of GFP derivative, the probe has two C=C
double bonds between phenol and imidazolidinone, which showed a maximum of about 10-
fold fluorescence response and successful traced lysosomal viscosity changes in living cells.
However, the probe was not sensitive to pH and lacked the characteristic of lysosomal-
activated fluorescence. The background fluorescence interference could not be ignored under
physiological conditions, and the fluorescence intensity did not change significantly.24
Besides, there are various classical fluorophores, including Pyrrolic,25 Carbazole,26
BODIPY,27, 28 Cyanine,29 Naphthalene,30 and the like (Table S1 and Scheme 1a),
they
31-36
also serve as molecular rotor fluorophores applied in viscosity probe field. Whereas the
2

Page 3 of 21
New Journal of Chemistry
1
2
3
4
5
development of viscosity probe with highly sensitive, fast response, low cytotoxicity, and
View Article Online
DOI: 10.1039/D0NJ01477J
large stokes shift as well as the targeted organelle-specific release is a prerequisite. Compared
6
7
8
9
to conventional fluorophores, the GFP chromophore is extracted from the organism, which
has natural biocompatibility.37 Its fluorescence is extremely weak in a free state that attributed
to the rotation of intra-molecule, which lead to a quick non-radiative transition and
deactivation from the fluorescent state, short fluorescence lifetime, and vice versa.38
In the exploitation of the viscosity probe, sensitivity, response time, and background
luminescent noise signal that might influence the reliability of viscosity tracing. Therefore, a
novel GFP chromophore analogue Lys-CzFP with acidic pH-activatable was first designed for
tracing lysosomal viscosity in living cells (Scheme 1b). Here, the carbazolyl GFP
chromophore analogue was synthesized firstly. Further, indole moiety was introduced via
Knoevenagel condensation. Thus, Lys-CzFP has a larger molecular plane and viscosity
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
sensitivity than two-sided phenols. Morpholine moiety was attached to the GFP structure to
40
localize the lysosomes.39,
Besides, the electron-rich morpholine moiety weakened
fluorescence of the GFP fluorophore via photoinduced electron transfer (PET). However, after
diffused into the lysosomal microenvironment (pH 3.8−6.6), morpholine moiety can be
protonated for the moderate alkalinity (pKa 5−6), the morpholine moiety will be converted to
be electron-withdrawing. After that, the PET process will be cut off, and the fluorescence
released,41 which endued Lys-CzFP with an acidic pH-activatable lysosome-targeting
fluorescence characteristic that eliminated the background fluorescence outside of
lysosomes,42 allowed a low background luminescent noise signal to be obtained. After
obtaining the Lys-CzFP, its structure was confirmed by 1H NMR, 13C NMR, and HRMS (Fig.
S3–S5).
53
54
55
56
57
58
59
60
3

New Journal of Chemistry
Page 4 of 21
1
2
3
4
View Article Online
DOI: 10.1039/D0NJ01477J
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 1 （a）Previous work for tracing viscosity.（b）Carbazolyl GFP chromophore analogue
was modulated to serve as a fluorescence probe for tracing lysosomal viscosity changes.
4

Page 5 of 21
New Journal of Chemistry
1
2
3
4
2. Experimental
View Article Online
DOI: 10.1039/D0NJ01477J
5
6
2.1 Materials and methods
7
8
9
Reagents. All chemicals are commercially available, and the solvents used in the reactions
were the anhydrous solution. The reaction was monitored by TLC plate using Silicycle® glass
sheets precoated with silica gel 60 Å with detection by UV-absorption (254 nm or 365 nm).
Flash column chromatography was performed using Silica Flash® F60 silica gel in the
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
-
2-
indicated solvent mixture. Stock solutions of the probe in DMSO and of F-, HCO3 , CO3 , I-,
2-
-
SO3 , S2-, Cl-, HSO3 , ClO-, Ca2+, Cu2+, Zn2+, Mg2+, Glucose, H2O2, H2S, Cys, Aln, Ala, Asp,
Pro, Tyr, Lys, GSH, Arg, Hcy, Phe, Thr, Gln, Val, Gly in distilled water were prepared. All
amino acids and ions were purchased from Macklin Biochemical Co., Ltd, Tokyo Chemical
industry Co., Ltd and Sinopharm Chemical Reagent Co., Ltd.
Apparatus. 1H NMR and 13C NMR spectra were obtained on a Bruker NMR (600 /150 MHz)
and (300/75 MHz) spectrometer in the given solvents. Chemical shifts are reported as δ-values
in ppm relative to the CDCl3, DMSO-d6 residual solvent peak or tetramethylsilane (TMS) as
an internal standard. Coupling constants are provided in Hz. All given 13C spectra are proton-
decoupled. High-resolution mass spectra were recorded with a Waters Q-TOF Premier
quadrupole/time-off flight (TOF) mass spectrometer. Fluorescent images were observed using
confocal laser scanning microscopy (FLUOVIEW FV3000. OLYMPUS).
General procedure for viscosity determination and spectral measurements
The solvents were acquired by mixing water-glycerol systems in different proportions.
Viscosity values of solutions were obtained according to Table S2. The stock solution of Lys-
CzFP (2 mM) was prepared in DMSO. The test solutions contained Lys-CzFP (10 μM), water-
glycerol systems in different proportions. These solutions were sonicated for 10 min to remove
air bubbles. After standing at room temperature for 1 h at 20 °C, then measured in a UV
5

New Journal of Chemistry
Page 6 of 21
1
2
3
4
spectrophotometer and a fluorescence spectrophotometer.
View Article Online
DOI: 10.1039/D0NJ01477J
5
6
Fluorescence lifetime measurements43
7
8
9
The solutions of Lys-CzFP (10 μM) in different viscosity were prepared in the solvent mixture
(water–glycerol). These solutions were sonicated for 10 min to eliminate air bubbles. After
standing for 1 h at 20 °C, the solutions were measured in a fluorescence lifetime measuring
equipment with the excitation wavelength at 460 nm.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Cell culture.
MTT cytotoxicity assay
Cytotoxicity of the probe Lys-CzFP was carried out by a standard MTT assay. The logarithmic
phase of Bel-7402 cells was seeded into a 96-well cell culture plate (1× 104 cells per well) and
incubated under 95% air and 5% CO2 at 37°C for 24 h. Next, the cells were incubated with
different concentrations (0 mM, 5 mM, 10 mM, 15 mM, 20 mM, and 25 mM) of the probe
Lys-CzFP for another 24 h. Then, each cytotoxicity experiment was repeated three times by
the standard method.
Co-location experiment44
Bel-7402 and Hela cells line were used in this work from the American type culture collection
(ATCC). Cells were incubated using the standard method and incubated in 95% air and 5%
CO2 at 37°C. Then, the cells were split into a 35 mm diameter confocal dishes, the density of
cells should keep around 3 × 105 cells in each dish, then incubated in 1640 medium for 24 h
under standard culture conditions. The probe Lys-CzFP (10 μM) and Lyso-Tracker Red (10
μM) were added and incubated for 30 min under standard culture conditions. After that, the
imaging sample was washed with PBS three times to remove the free probe. Then, the cells
were imaged using confocal laser scanning microscopy. (FLUOVIEW FV3000. OLYMPUS)
6

Page 7 of 21
New Journal of Chemistry
1
2
3
4
Tracking viscosity changes experiment
View Article Online
DOI: 10.1039/D0NJ01477J
5
6
7
8
Bel-7402 cells seeded in a 35 mm petri dish with a glass cover slide. After culturing overnight,
a specific concentration of the Lys-CzFP (10 μM) solution prepared in DMSO was added to
the above petri dish. And it was incubated with the cells for 30 minutes under standard culture
conditions. Then, dexamethasone (20 μM) was added and incubated for 60 min. Before
imaging, the cells were washed three times with PBS solution (pH 7.4) to remove the free
probe. Recording real-time living cells images every 20 min under confocal laser scanning
microscopy. (FLUOVIEW FV3000. OLYMPUS)
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
2.2 Synthesis
Synthesis of Compound M1:
Glycine tert-butyl ester hydrochloride (1500 mg, 8.95 mmol) and NaOH (1500 mg, 8.40
mmol) were added to 2-methylpropan-2-ol (30 mL), which was stirred at room temperature
for 1 h. Then, N-ethyl-3-carbazolecarboxaldehyde (1000 mg, 4.48 mmol) was added and
stirred overnight. (E)-2-((1-ethoxyethylidene)amino)acetate (1800 mg, 8.97 mmol) was
prepared and added. The mixture was stirred at room temperature for 36 h and then the
reaction was quenched by water. The mixture was diluted with DCM and washed with water
three times. The organic layer was collected and evaporated. The crude product was further
purified by silica gel column to get yellow solid. Yield: 91.3%.
1H NMR (600 MHz, CDCl3) δ 8.87 (s, 1H), 8.37 (d, J = 8.6 Hz, 1H), 8.17 (d, J = 7.6 Hz, 1H),
7.49 (t, J = 7.6 Hz, 1H), 7.42 (dd, J = 8.3, 2.6 Hz, 2H), 7.37 (s, 1H), 7.28 (t, J = 7.4 Hz, 1H),
4.37 (q, J = 7.3 Hz, 2H), 4.31 (s, 2H), 2.38 (s, 3H), 1.49 (s, 9H), 1.45 (t, J = 7.3 Hz, 3H).
Synthesis of Compound M2:
N-(2-chloroethyl) morpholine hydrochloride (3000 mg, 16.21 mmol), Indole-3-
7

New Journal of Chemistry
Page 8 of 21
1
2
3
4
5
carboxaldehyde (1180 mg, 8.11 mmol) and potassium carbonate (2240 mg, 16.21 mmol) was
View Article Online
DOI: 10.1039/D0NJ01477J
added to DMF (50 mL). The mixture was stirred at 50°C for 48 h. After reaction, the mixture
6
7
8
9
was extracted with DCM and the organic layer was washed with water three times. The DCM
was evaporated and the crude product was further purified by silica gel column to afford
yellow oil. Yield: 95.4%.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
1H NMR (600 MHz, DMSO-d6) δ 9.91 (s, 1H), 8.32 (s, 1H), 8.11 (d, J = 7.8 Hz, 1H), 7.64 (d,
J = 8.2 Hz, 1H), 7.32 – 7.29 (m, 1H), 7.26 – 7.24 (m, 1H), 4.39 (t, J = 6.3 Hz, 2H), 3.53 (t, J
= 6.3 Hz, 4H), 2.70 (t, J = 6.3 Hz, 2H), 2.43 (s, 4H).
Synthesis of Compound Lys-CzFP:
Compound M1 (110 mg, 0.26 mmol) and compound M2 (56.71 mg, 0.22 mmol) were
dissolved in benzene. Acetic acid (30 μL) and piperidine (50 μL) were added and the mixture
was refluxed overnight at 110°C. After reaction, The organic layer was washed with water
(150 mL × 3), dried over anhydrous MgSO4 and filtered. The benzene was evaporated and the
crude product was further purified by silica gel column to get red solid. Yield: 78.2%.
1H NMR (300 MHz, DMSO-d6) δ 9.08 (s, 1H), 8.59 (d, J = 8.6 Hz, 1H), 8.36 (d, J = 15.6 Hz,
1H), 8.26 (d, J = 7.7 Hz, 1H), 8.14 (s, 1H), 8.07 (d, J = 7.7 Hz, 1H), 7.71 (d, J = 8.8 Hz, 1H),
7.64 (t, J = 7.1 Hz, 2H), 7.51 (t, J = 7.9 Hz, 1H), 7.35 – 7.23 (m, 3H), 7.19 (s, 1H), 6.79 (d, J
= 15.6 Hz, 1H), 4.69 (s, 2H), 4.54 – 4.47 (m, 2H), 4.36 (s, 2H), 3.56 (s, 4H), 2.72 (s, 2H), 2.45
(s, 4H), 1.43 (s, 9H), 1.35 (s, 3H). 13C NMR (75 MHz, DMSO-d6) δ 169.77, 167.46, 159.01,
140.32, 140.08, 137.44, 136.95, 135.24, 134.11, 130.15, 126.24, 125.96, 125.29, 124.89,
124.78, 122.74, 122.63, 122.32, 121.04, 120.53, 120.41, 119.56, 112.55, 110.94, 109.52,
106.76, 81.96, 66.16, 57.35, 53.23, 43.14, 41.79, 37.19, 27.59, 13.69. HRMS: [M+H]+ Calcd:
658.3388, Obsd: 658.3385.
8

Page 9 of 21
New Journal of Chemistry
1
2
3
4
3. Results and discussion
View Article Online
DOI: 10.1039/D0NJ01477J
5
6
3.1 Design of carbazolyl GFP chromophore analogue
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 2. Design of acidic pH-activatable lysosomal probe Lys-CzFP.
Lys-CzFP, as a fluorescent molecular rotor, the fluorescence of the probe in aqueous solutions
was extremely weak that could be attributed to the free rotations of through the single C—C
bonds in the π-conjugated bridge.45 In contrast, these rotations could be inhibited under
increasing viscosity solutions, its fluorescence released with the ϕF and lifetime increased
(Scheme 2), which was very rare compared to most known lysosomal probes (Table. S1).
Besides, the low cytotoxicity of the GFP chromophore was a promising performance for
applications in living cells. Finally, Pearson’s correlation of lysosomal co-labeling was 0.974
that provided specifically lysosomal localization used for tracing viscosity changes in living
cells.
9

New Journal of Chemistry
Page 10 of 21
1
2
3
4
View Article Online
DOI: 10.1039/D0NJ01477J
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Scheme 3. Synthetic route to afford the Lys-CzFP with high viscosity response.
The existed literature for synthesizing GFP chromophore, and its analogue existed by-
products that were difficult in the separation.46-49 In this work, carbazolyl GFP chromophore
analogue was first reported by the following method; the imidate was replaced with tert-butyl
(E)-2-((1-ethoxyethylidene)amino)acetate; alcohol was replaced with 2-methylpropan-2-ol,
resulting in yield improved remarkably (Scheme 3), which may ascribe the hydrolysis of t-
butoxy moiety was inhibited. It will be of great significance for the development of numerous
GFP chromophore and its analogue.
3.2 Sensitive responses of Lys-CzFP to viscosity within 5 s
As exhibited in Fig. 1 and Table 1, the maximum absorption wavelength of Lys-CzFP was
located at 482 nm, and the corresponding emission peak was located at 560 nm with a large
stokes shift of 78 nm (10 μM, pH = 7.4, 25 oC). The molar extinction coefficient of absorption
peaks at 482 nm was 2.2×104 cm-1M-1. Besides, the fluorescence quantum yield of Probe Lys-
CzFP was measured. Fluorescence quantum yield of Lys-CzFP was calculated to be 0.253 in
glycerol relative to fluorescein in 0.1 M NaOH (ϕF = 0.95 in EtOH).
10

Page 11 of 21
New Journal of Chemistry
1
2
3
4
View Article Online
DOI: 10.1039/D0NJ01477J
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Fig. 1 (a) Molar Extinction Coefficient (ε) and fluorescence spectra of Lys-CzFP (10 μM) in glycerol.
(pH 7.4, 20 °C). (b) Fluorescence spectra of Lys-CzFP (10 μM) in glycerol-water mixed solvents
(1.00-1412 cP, pH 7.4, 20 °C). Inset line: Linear relationship of fluorescence intensity (560 nm) with
viscosity values. (c) Fluorescence quantum yield (ϕF) of Lys-CzFP (10 μM) under different viscosity
solutions (η). (d) Fluorescence lifetime spectra of Lys-CzFP (10 μM) under different viscosity
solutions. Inset line: Linear relationship of fluorescence lifetime with viscosity values.
Fluorescence responses of Lys-CzFP were investigated under different viscosity solutions.
As glycerol was gradually added to the solutions mixture, the water and glycerol viscosity
gradients increased from 1.00cP to 1412cP; consequently, the fluorescence of Lys-CzFP
maximally increased by about 98 - fold at 560 nm (Fig. 1a and Fig. 1b). Moreover, the
fluorescence of probe exhibited an excellent linear relationship (R2 = 0.987, slope = 0.67) by
fitting the Förrster–Hoffmann equation. This may be ascribed to the fact that the internal
rotation of through the single C—C bonds in the π-conjugated bridge was inhibited in the
11

New Journal of Chemistry
Page 12 of 21
1
2
3
4
5
viscous environment, resulting in an excited state relaxation of the fluorescent emission.
View Article Online
DOI: 10.1039/D0NJ01477J
Sequentially, a strong fluorescence emission occurred. The quantum yield of the probe Lys-
6
7
8
9
CzFP was further measured in different solvents. The quantum yield was relatively low (ϕF =
0.003) in water. Correspondingly, as the viscosity gradients increasing, the fluorescence
quantum yield reached 0.253 maximally (pH 7.4, 20 °C), allowing for observation by the
naked eye (Fig. 1c). These results indicated that Lys-CzFP was sensitive to the viscosity
changes of the solvents and could be used for tracing viscosity changs.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Fig. 2 (a, b) Fluorescence spectra of Lys-CzFP (10 μM) at different pH in ethanol/water/glycerol
mixtures at two viscosities: (a) 219 cP and (b) 22.5 cP. (c) Fluorescence quantum yields of Lys-CzFP
(10 μM) at different pH.
The fluorescence intensity of Lys-CzFP was very sensitive to both viscosity and pH (Fig 2).
For example, a particular viscosity (e.g., 219 cP or 22.5 cP), pH from 7.42 to 4.15; at a viscosity of
22.5 cP, the fluorescence quantum yield (
pH 7.42 (ϕF = 0.057). Also, at a fixed pH, the fluorescence intensity increased with increasing
viscosity. For instance, at a viscosity of 219 cP , F was 0.556, at pH = 4.15, which was 3.1 times
than 22.5 cP ( F = 0.179). Notably, Lys-CzFP’s fluorescence was very weak for pH > 6.86, and
ϕF) at pH 4.15 was 0.179, which is almost 18 times that at
ϕ
ϕ
negligible at lysosomal microenvironment (pH 3.8−6.6, 47−190 cP) (Fig. S10 and S11), which
ascribe the effect of PET, the molecule accepted electron from the neutral morpholine,
fluorescence was very weak. Whereas in the lysosomal microenvironment (pH 3.8−6.6), it
12

Page 13 of 21
New Journal of Chemistry
1
2
3
4
5
released a strong fluorescence. Meanwhile, the background fluorescence was eliminated
View Article Online
DOI: 10.1039/D0NJ01477J
outside of lysosomes, and that was very conducive to trace the lysosomal locations (pH
6
7
8
9
3.8−6.6) using confocal microscopy. Besides, the effects of various bio-ions and
macromolecules on Lys-CzFP also be studied. As seen in Fig. S9a, in a series of viscosity
systems, when 5 eq dexamethasone was added to various viscosities containing 10 μM Lys-
CzFP, the fluorescence intensity of the Lys-CzFP was not change significantly, which
indicated that the probe was not affected by excessive dexamethasone from outside.
According to Fig. S9b, there were no significant effects among water and glycerol (containing
10% water as co-solvent) in bio-ions, responding to viscosity particularly. All of the above
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
characteristics indicated that Lys-CzFP could be used for tracing viscosity changes
, and
provided acidic pH-activatable property in complex physiological environments.
3.3 Fluorescence spectrums of Lys-CzFP in the different solvents
Fig. 3 Fluorescence Intensity in various solvents with different polarities.
Due to the complex cellular environment and numerous influencing factors, solvents polarity could
13

New Journal of Chemistry
Page 14 of 21
1
2
3
4
5
be one of the factors affecting probe fluorescence. Therefore, the effect of solvent polarity was also
View Article Online
DOI: 10.1039/D0NJ01477J
evaluated. According to Fig. 3, the probe Lys-CzFP exhibited strong fluorescence emission at 560
6
7
8
9
nm in glycerol, which was much higher than those in other solvents. Similarly, in the mixtures of
ethanol-glycerol, or ethanediol-glycerol, with different viscosity, Lys-CzFP displayed almost the
same fluorescence response in viscous solution. (Figures S6 and S7). In contrast, in other solvents
with different polarities, the probe fluorescence was very weak; its fluorescence intensity effects were
not obvious in different polar solvents. The quantum yields of the probe Lys-CzFP in various solvents
were also calculated. (Table S3 and S4). The quantum yields of the probe Lys-CzFP in other solvents
were meager, from 0.003 to 0.026. However, the quantum yield of the probe Lys-CzFP reached to
0.253 in glycerol. Besides, we can see that an obvious upward trend towards the fluorescence intensity
of probe occurred as the viscosity of the solvent increases, but the fluorescence had no similar
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
relationship with the increase of polarity. These results indicated that the probe fluorescence intensity
response was highly sensitive and selective compared to solvent polarity and that it could be used to
trace viscosity changes in complex biological environments.
3.3 Lifetime of Lys-CzFP in various viscosity mixtures
Fluorescence lifetime decays of Lys-CzFP were carried out in a series of viscosity gradient
media composed of glycerol and water in a variety of ratios. As shown in Fig. S12a-c, along
with solutions viscosity from 6 cP to 523 cP (10 μM, pH 7.4, 20 °C), the lifetime gradually
prolonged from 0.25 ns to 1.0 ns. The probe exhibited excellent linear relationship (R2 = 0.99,
Slop = 0.33) by fitting the Förrster–Hoffmann equation (Fig. S12d). Hence, these results
indicated that the fluorescence lifetime of Lys-CzFP was a sensitive and promising viscosity
probe under fluorescence lifetime imaging microscope (FLIM) to trace changes of cells
viscosity and focus on alterations in the internal state of the cells in real-time. It is an important
significance for future research on in vivo pathology.
14

Page 15 of 21
New Journal of Chemistry
1
2
3
4
5
View Article Online
DOI: 10.1039/D0NJ01477J
Table 1 The photophysical properties of Lys-CzFP in different solvents
6
7
8
9
max [b]
max [d]
Viscosity value (cP) [a]
λabs
ε[c]
λem
Δλ[e]
B[g]
τ[h]
[f]
ФF
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Solvents
(nm)
482
(M-1cm-1) (nm)
(nm)
(M-1cm-1) (ns)
1.01
25286
24850
25324
27308
29080
35300
563
567
567
564
563
560
83
84
85
81
81
78
0.003 76
—
(H2O)
3.72
483
482
483
482
482
0.054 1342
0.059 1494
0.116 3168
0.139 4042
0.253 8931
0.24
0.25
0.50
0.75
1.12
(H2O/Glycerol = 3/2)
6.00
(H2O/Glycerol = 1/1)
60.10
(H2O/Glycerol= 1/4)
219
(H2O/Glycerol = 1/9)
1412
(Glycerol)
[a] Viscosity values with different proportions of water–glycerol systems were obtained from Table
S2. [b] Maximum absorbance wavelength. [c] Molar extinction coefficient. [d] Maximum emission
wavelength. [e] Stokes shift. [f] Fluorescence quantum yield. Fluorescein in 0.1 M NaOH used as the
standard reference with a quantum yield of 0.95 in ethanol. [g] Brightness. Brightness was calculated
using B = ε* ϕF. [h] Fluorescence lifetime was tested by the method of time-correlated single-photon
counting.
3.4 Visualize the viscosity changes in Bel-7402 cells
The desirable fluorescence characteristic of Lys-CzFP for detecting viscosity was
15

New Journal of Chemistry
Page 16 of 21
1
2
3
4
5
conducive to trace viscosity changes intracellularly. Hence, the capability of the probe for
View Article Online
DOI: 10.1039/D0NJ01477J
cell-viscosity fluorescence imaging was further evaluated. Before the cell experiment, the
6
7
8
9
cytotoxicity of Lys-CzFP was performed by MTT assay in Bel-7402 cells and Fig. S13
revealed that the cell viability was more than 91.5% after 24 h with the negligible cytotoxicity,
indicating a favorable property for tracing lysosomal viscosity changes.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
The lysosomal localization experiment of Lys-CzFP in Bel-7402 was performed, Bel-7402
cells were co-stained with Lys-CzFP and Lyso-Tracker red, a commercial lysosomal dye, for
30 min at 37 °C. The fluorescence image was obtained under a confocal microscope (Fig. 3a-
c). The green and red luminance signals were detected by the green and red channels,
respectively, and the yellow signal was the result of the overlap between the Lys-CzFP and
Lyso-Tracker red signals. The merged image results showed that two channels tended toward
synchronization, and the images overlapped very well (Fig. 4d). In addition, the fluorescence
of the cells was extracted, correlation scatters plot and intensity profile showed that the two
channels have an excellent relationship (Fig. 4e-f), Pearson’s correlation 50 reached to 0.974. All
the above results indicated that Lys-CzFP was an excellent lysosomal bio-tracer reagent that could
stain lysosomes specifically.
As an essential parameter, the photostability of Lys-CzFP was also investigated under
excitation of 482 nm. After 60 min of continuous irradiation, the emission at 560 nm barely
changed, which suggested that the Lys-CzFP was very stable. Besides, the photostability of the
probe in living cells is a prerequisite for cell viscosity measurement. It can be seen from Fig.
S15 that the 10 μM probe was incubated in HeLa cells for 8h, 16h, and 24h. The experimental
results showed that there was no apparent change in fluorescence intensity, which indicated
that the probe has excellent photostability in cells.
16

Page 17 of 21
New Journal of Chemistry
1
2
3
4
View Article Online
DOI: 10.1039/D0NJ01477J
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Fig. 4 Colocalization imaging of Bel-7402 cells stained with 10 μM Lys-CzFP and 10 μM Lyso-
Tracker Red for 30 min at 37 °C. (a) Confocal image from Lys-CzFP on the green channel; (b)
Confocal image from Lyso-Tracker Red on the red channel. (c) Bright-field image. (d) Merged image
of (a) and (b). Scale bar is 20 μm. (e) Correlation scatters plot of Lys-CzFP and Lyso-Tracker
intensities. (f) Intensity profile obtained from regions of interest.
As shown in Fig. 5, to verify whether lysosomal viscosity changes in living cells could be
detected using Lys-CzFP by fluorescence imaging. Dexamethasone, a stabilizer for
51
membranes of lysosomes and an inhibitor of lysosomal enzymatic release, was proved to
be effective in stimulating lysosomal viscosity changes in cells.52 Fig. 5a showed that Bel-
7402 cells were treated with 10μM Lys-CzFP for 30 min. The fluorescence was observed in
the green channel. Then, dexamethasone (20μM) was added and incubated at 37°C for 60 min.
Real-time living cellular images were recorded every 20 min; the fluorescence was
significantly enhanced (Fig. 5b-e). To quantify the fluorescence intensity, the relative pixel
intensities of each plot were extracted. The results showed that the fluorescence of the cells
was significantly increased within 60 min after incubation with dexamethasone. These results
17

New Journal of Chemistry
Page 18 of 21
1
2
3
4
5
indicated that Lys-CzFP with morpholine moiety could be used to detect lysosomal viscosity
View Article Online
DOI: 10.1039/D0NJ01477J
changes in living cells.
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Fig. 5 (a) Real-time living cell images of Bel-7402 stained by Lys-CzFP (10μM) for 30 min. (b - d)
Lys-CzFP treated with dexamethasone (20 μM), fluorescence images were taken every 20 min until
60 min later. Scale bar is 50 μm. (e) The average intensity of images a-d.
4. Conclusion
In summary, a novel molecular rotor based on carbazolyl GFP chromophore analogue has
been designed for tracing lysosomal viscosity changes. Lys-CzFP showed a remarkable
response to viscosity with maximum emission at 560 nm and a large stokes shift of 78 nm.
The fluorescence response was maximally increased by about 98 - fold within 5s, with the ϕF
increasing from 0.003 to 0.253 and the lifetime increasing from 0.25 ns to 1.12 ns, which
indicated that using Lys-CzFP via fluorescence lifetime imaging microscope to trace the
changes of cells viscosity was allowed. Besides, the electron-rich morpholine moiety
weakened fluorescence of the GFP fluorophore via PET, which endued Lys-CzFP with an
18

Page 19 of 21
New Journal of Chemistry
1
2
3
4
5
acidic pH-activatable lysosome-targeting fluorescence characteristic that was conducive to
View Article Online
DOI: 10.1039/D0NJ01477J
eliminate the background fluorescence outside of lysosomes. Lys-CzFP was stable in various
6
7
8
9
bio-ions and small molecules, which showed that the probe has high sensitivity and specificity
to viscosity in lysosomes. Finally, the probe Lys-CzFP has been successfully used for tracing
lysosomal viscosity changes in living cells. We expect that Lys-CzFP could be exploited as a
potential platform to trace viscosity changes in complex biological systems.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Acknowledgements
This work was financially supported by the Fundamental Research Funds for the National
Natural Science Foundation of China (No.61178057).
Conflicts of interest
There are no conflicts to declare.
Notes and references
1.
2.
H. Li, W. Shi, X. Li, Y. Hu, Y. Fang and H. Ma, J Am Chem Soc, 2019, 141, 18301-18307.
B. Chen, C. Li, J. Zhang, J. Kan, T. Jiang, J. Zhou and H. Ma, Chem Commun (Camb), 2019,
55, 7410-7413.
3.
4.
F. Xin, Y. Tian, J. Jing and X. Zhang, Analytical Methods, 2019, 11, 2969-2975.
P. Zhang, H. Chen, H. Huang, K. Qiu, C. Zhang, H. Chao and Q. Zhang, Dalton Trans, 2019,
48, 3990-3997.
5.
A. M. Aleardi, G. Benard, O. Augereau, M. Malgat, J. C. Talbot, J. P. Mazat, T. Letellier, J.
Dachary-Prigent, G. C. Solaini and R. Rossignol, J Bioenerg Biomembr, 2005, 37, 207-225.
K. Zhou, M. Ren, B. Deng and W. Lin, New Journal of Chemistry, 2017, 41, 11507-11511.
Y. He, J. Shin, W. Gong, P. Das, J. Qu, Z. Yang, W. Liu, C. Kang, J. Qu and J. S. Kim, Chem
Commun (Camb), 2019, 55, 2453-2456.
6.
7.
8.
9.
10.
T. Chen, Z. Chen, R. Liu and S. Zheng, Org Biomol Chem, 2019, 17, 6398-6403.
X. Dai, B. Dong, M. Ren and W. Lin, J Mater Chem B, 2018, 6, 381-385.
R. Guo, J. Yin, Y. Ma, G. Li, Q. Wang and W. Lin, Sensors and Actuators B: Chemical, 2018,
271, 321-328.
11.
R. Guo, J. Yin, Y. Ma, Q. Wang and W. Lin, Journal of Materials Chemistry B, 2018, 6, 2894-
2900.
12.
13.
14.
J. Yin, M. Peng and W. Lin, Anal Chem, 2019, 91, 8415-8421.
M. Peng, J. Yin and W. Lin, New Journal of Chemistry, 2019, 43, 16945-16949.
W. Wang, Y. Liu, J. Niu and W. Lin, Analyst, 2019, 144, 6247-6253.
19

New Journal of Chemistry
Page 20 of 21
1
2
3
4
15.
L. Hou, P. Ning, Y. Feng, Y. Ding, L. Bai, L. Li, H. Yu and X. Meng, Anal Chem, 2018, 90,
View Article Online
7122-7126.
DOI: 10.1039/D0NJ01477J
16.
17.
18.
19.
20.
21.
J. L. Zhu, Z. Xu, Y. Yang and L. Xu, Chem Commun (Camb), 2019, 55, 6629-6671.
H. Zhu, J. Fan, J. Du and X. Peng, Acc Chem Res, 2016, 49, 2115-2126.
B. Shen, L. F. Wang, X. Zhi and Y. Qian, Sensors and Actuators B-Chemical, 2020, 304.
F. H. J. a. O. Shimomura and J. C. C. Y. Saiga, Comp. Physiol, 1962, 59, 223–229.
B. Shen and Y. Qian, Dyes and Pigments, 2019, 166, 350-356.
L. Yuan, W. Lin, H. Chen, S. Zhu and L. He, Angew Chem Int Ed Engl, 2013, 52, 10018-
10022.
B. Shen, W. Zhu, X. Zhi and Y. Qian, Talanta, 2020, 208, 120461.
Y. Liu, C. H. Wolstenholme, G. C. Carter, H. Liu, H. Hu, L. S. Grainger, K. Miao, M. Fares,
C. A. Hoelzel, H. P. Yennawar, G. Ning, M. Du, L. Bai, X. Li and X. Zhang, J Am Chem Soc,
2018, 140, 7381-7384.
X. Li, R. Zhao, Y. Wang and C. Huang, Journal of Materials Chemistry B, 2018, 6, 6592-
6598.
S. C. Lee, J. Heo, J. W. Ryu, C. L. Lee, S. Kim, J. S. Tae, B. O. Rhee, S. W. Kim and O. P.
Kwon, Chem Commun (Camb), 2016, 52, 13695-13698.
F. Liu, Y. Luo and M. Xu, Tetrahedron Letters, 2018, 59, 4540-4544.
I. Lopez-Duarte, T. T. Vu, M. A. Izquierdo, J. A. Bull and M. K. Kuimova, Chem Commun
(Camb), 2014, 50, 5282-5284.
S. Toliautas, Chemistry a European journal, 2019, 25, 10342 – 10349.
H. Y. Tan, Y. T. Qiu, H. Sun, J. W. Yan and L. Zhang, Chem Commun (Camb), 2019, 55,
2688-2691.
B. Guo, J. Jing, L. Nie, F. Xin, C. Gao, W. Yang and X. Zhang, Journal of Materials
Chemistry B, 2018, 6, 580-585.
Y. Baek, S. J. Park, X. Zhou, G. Kim, H. M. Kim and J. Yoon, Biosens Bioelectron, 2016, 86,
885-891.
P. Ning, P. Dong, Q. Geng, L. Bai, Y. Ding, X. Tian, R. Shao, L. Li and X. Meng, Journal of
Materials Chemistry B, 2017, 5, 2743-2749.
R. Guo, Y. Ma, Y. Tang, P. Xie, Q. Wang and W. Lin, Talanta, 2019, 204, 868-874.
Y. Y. Ma, Y. P. Zhao, R. Guo, L. L. Zhu and W. Y. Lin, Journal of Materials Chemistry B,
2018, 6, 6212-6216.
M. Ren, B. Deng, K. Zhou, X. Kong, J. Y. Wang and W. Lin, Anal Chem, 2017, 89, 552-555.
M. Ren, K. Zhou, L. Wang, K. Liu and W. Lin, Sensors and Actuators B: Chemical, 2018,
262, 452-459.
T. Nakatani, N. Yasui, I. Tamura and A. Yamashita, Sci Rep, 2019, 9, 4722.
J. Chang, M. G. Romei and S. G. Boxer, J Am Chem Soc, 2019, 141, 15504-15508.
H. Yu, Y. Xiao and L. Jin, J Am Chem Soc, 2012, 134, 17486-17489.
C. Wang, B. Dong, X. Kong, N. Zhang, W. Song and W. Lin, Luminescence, 2018, 33, 1275-
1280.
L. L. Li, K. Li, M. Y. Li, L. Shi, Y. H. Liu, H. Zhang, S. L. Pan, N. Wang, Q. Zhou and X. Q.
Yu, Anal Chem, 2018, 90, 5873-5878.
L. Wang, Y. Xiao, W. Tian and L. Deng, J Am Chem Soc, 2013, 135, 2903-2906.
W. Becker, A. Bergmann, M. A. Hink, K. Konig, K. Benndorf and C. Biskup, Microsc Res
Tech, 2004, 63, 58-66.
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36.
37.
38.
39.
40.
41.
42.
43.
44.
45.
C. Wang and Y. Qian, Org Biomol Chem, 2019, 17, 8001-8007.
S.-C. Lee, J. Heo, H. C. Woo, J.-A. Lee, Y. H. Seo, C.-L. Lee, S. Kim and O. P. Kwon,
Chemistry - A European Journal, 2018, 24, 13706-13718.
H. Deng, Y. Su, M. Hu, X. Jin, L. He, Y. Pang, R. Dong and X. Zhu, Macromolecules, 2015,
48, 5969-5979.
46.
20

Page 21 of 21
New Journal of Chemistry
1
2
3
4
5
6
7
8
9
47.
48.
49.
J. Kowalik, A. Baldridge and L. Tolbert, Synthesis, 2010, 14, 2424-2436.
H. Deng and X. Zhu, Materials Chemistry Frontiers, 2017, 1, 619-629.
K. H. Jung, M. Fares, L. S. Grainger, C. H. Wolstenholme, A. Hou, Y. Liu and X. Zhang, Org
Biomol Chem, 2019, 17, 1906-1915.
X. Xie, F. Tang, X. Shangguan, S. Che, J. Niu, Y. Xiao, X. Wang and B. Tang, Chem Commun
(Camb), 2017, 53, 6520-6523.
B. Hinz and R. Hirschelmann, Pharmaceutical Research, 2000, 17, 1489-1493.
N. R. Ackerman and J. R. Beebe, Journal of Pharmacology and Experimental Therapeutics,
1975, 193, 603-613.
View Article Online
DOI: 10.1039/D0NJ01477J
50.
51.
52.
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
21
