SCHEME 1. Cycloaddition of Alkynes and Azides
Click Chemistry with
O-Dimethylpropargylcarbamate for Preparation
of pH-Sensitive Functional Groups. A Case Study
Philippe Bertrand* and Jean Pierre Gesson
Laboratoire Synthe`se et Re´actiVite´ des Substances Naturelles,
UMR CNRS 6514, 40 AVenue du Recteur Pineau,
86022 Poitiers Cedex, France
polyphenylacetylenes6 for material development, and in the field
of combinatorial chemistry.7 Biocompatible and biodegradable
polymers for therapeutic usage have been developed for many
decades8 either as carrier systems or to improve physical
properties such as solubility. Several strategies were developed
to incorporate bioactive molecules into polymers to produce
slow releasing systems based on biological transformations such
as enzymatic hydrolysis or pH variations,9 the polymer carrier
being usually decomposed. Poly(ethylene oxide) (PEO) poly-
mers have been known for a long time to be biocompatible,
nonimmunogenic, and hydrophilic, increasing water solubility,
and are approved by the FDA.10 They are themselves the major
polymeric material when higher molecular weight derivatives
are used11 or are integrated in more complex systems as
intermediate chains.12 A PEG-asparaginase bioconjugate has
been developed for the treatment of acute lymphoblastic
leukaemia.13 In a project devoted to the development of
functional PEO polymers for drug delivery, we were interested
in biodegradable modified branched PEO with a moiety
designed for the introduction of multipurpose functional groups
by click chemistry and also for drug release in biological systems
under acidic conditions.9 Polymer biodegradability can also be
obtained by integration of pH-sensitive groups (orthoesters,14
acetals15) in the polymer structure.
philippe.bertrand@uniV-poitiers.fr
ReceiVed February 1, 2007
Click chemistry has became an important tool for molecular
constructs such as biopolymers. During the development of
biodegradable multifunctional poly(ethylene oxide) (PEO)
polymers suitable for click chemistry in water, an unexpected
reaction leading to a mixture of triazole cycloadducts was
observed. This result was attributed to an intramolecular
ligand effect, and alternative conditions were evaluated. An
efficient method was then implemented allowing the access
in high yields to the expected triazolylcarbamate. pH
sensitivity of the obtained isopropyltriazolylcarbamate was
demonstrated at acidic pH.
Model compound 3 was designed (Scheme 2) to integrate
these several requirements. In this study, a minimal methoxy-
protected ethylenoxide motif is used and linked to a benzoate
ester, for the purpose of biodegradability. The phenyl ring of
the benzoate group can also be the central point of multipurpose
functionality, provided multiple substitutions. In this work we
limited these substitutions by selecting salicylic acid, the phenol
group being converted to an azidoether necessary for the click
In 1963, Huisgen reviewed the [3 + 2] cycloaddition reactions
between 1,3 dipoles and unsaturated bonds.1 When realized
under thermal conditions, this reaction generally led to two
possible regioisomeric adducts limiting the possible applications
of this reaction (Scheme 1), the ratio being governed by steric
and electronic factors. Applied to terminal alkynes and azides,
this reaction allows access to [1,4] and [1,5] disubstituted 1,2,3-
triazoles. In 2001, Sharpless showed in this latter case that the
use of Cu(I) salts gave only [1,4] cycloadducts in high yields.2
As this reaction can be realized in several solvents, including
water, and supports many functional groups, it has been widely
used in several ways as “click chemistry”. A selective [1,5]
cycloadduct formation was also proposed.3 Click chemistry has
been applied to several types of polymers such as modified
carbohydrates4 or polyamides5 for biocompatible purposes,
(5) Jang, H.; Fafarman, A.; Holub, J.; Kirshenbaum, K. Org. Lett. 2005,
7, 1951.
(6) Englert, B. C.; Bakbak, S.; Bunz, U. H. F. Macromolecules 2005,
38, 5868.
(7) (a) Tornøe, C. W.; Sanderson, S. J.; Mottram, J. C.; Coombs, G. H.;
Meldal, M. J. Comb. Chem. 2004, 6, 312. (b) Su, S.; Giguere, J. R.; Schaus,
S. E.; Porco, J. A., Jr. Tetrahedron 2004, 60, 8645. (c) Bettinetti, L.; Lo¨ber,
S.; Hu¨bner, H.; Gmeiner, P. J. Comb. Chem. 2005, 7, 309-316.
(8) (a) Ringsdorf, H. J. Polym. Sci. Polym. Symp. 1975, 51, 135. (b)
Duncan, R.; Gac-Breton, S.; Keane, R.; Musila, R.; Sat, Y. N.; Satchi, R.;
Searle, F. J. Controlled Release 2001, 74, 135. (c) Nori, A.; Kopecek, J.
AdV. Drug DeliVery ReV. 2005, 57, 609.
(9) Ulbrich, K.; Subr, V. AdV. Drug DeliVery ReV. 2004, 56, 1023.
(10) Israelachvili, J. Proc. Natl. Acad. Sci. U.S.A. 1997, 94, 8378.
(11) Conover, C. D.; Greenwald, R. B.; Pendri, A.; Gilbert, K. W.; Shum,
K. L. Cancer Chemother. Pharmacol. 1998, 42, 407.
(12) Bafaloukos, D.; Papadimitriou, C.; Linardou, H.; Aravantinos, G.;
Papakostas, P.; Skarlos, D.; Kosmidis, P.; Fountzilas, G.; Gogas, H.;
Kalofonos, C.; Dimopoulos, A. M. Br. J. Cancer 2004, 91, 1639.
(13) Mu¨ller, H.-J.; Beier, R.; da Palma, J. C.; Lanvers, C.; Ahlke, E.;
von Schu¨tz, V.; Gunkel, M.; Horn, A.; Schrappe, M.; Henze, G.; Kranz,
K.; Boos, J. Cancer Chemother. Pharmacol. 2002, 49, 149.
(14) Guo, X.; Szoka, F. C., Jr. Bioconjugate Chem. 2001, 12, 291.
(15) (a) Asokan, A.; Cho, M. J.; Bioconjugate Chem. 2004, 15, 1166.
(b) Heffernan, M. J.; Murthy, N. Bioconjugate Chem. 2005, 16, 1340.
(1) Huisgen, R. Angew. Chem., Int. Ed. 1963, 2, 565. (b) Huisgen, R.
Angew. Chem., Int. Ed. 1963, 2, 633.
(2) Kolb, H. C.; Finn, M. G.; Sharpless, K. B. Angew. Chem., Int. Ed.
2001, 40, 2004.
(3) Majireck, M. M.; Weinreb, S. M. J. Org. Chem. 2006, 71, 8680.
(4) (a) Wan, Qian.; Chen, J.; Chen, G.; Danishefsky, S. J. J. Org. Chem.
2006, 71, 8244. (b) Srinivasachari, S.; Liu, Y.; Zhang, G.; Prevette, L.;
Reineke, T. M. J. Am. Chem. Soc. 2006, 128, 8176.
10.1021/jo070131j CCC: $37.00 © 2007 American Chemical Society
Published on Web 03/27/2007
3596
J. Org. Chem. 2007, 72, 3596-3599
