Oxidation of 5-Chloromethylfurfural (CMF) to
,5-Diformylfuran (DFF)
2
Ana I. Vicente , Jaime A. S. Coelho , Svilen P. Simeonov 1,2, Hristina I. Lazarova 2,
1
1
Margarita D. Popova 2 and Carlos A. M. Afonso *
1,
1
Research Institute for Medicines (iMed.ULisboa), Faculty of Pharmacy, Universidade de Lisboa,
Av. Prof. Gama Pinto, 1649-003 Lisboa, Portugal; ana_vicente@netc.pt (A.I.V.);
jaimeacoelho@gmail.com (J.A.S.C.); svilen.p.simeonov@gmail.com (S.P.S.)
Institute of Organic Chemistry with Centre of Phytochemistry Bulgarian Academy of Sciences,
2
Acad. G. Bonchev str., bl. 9, 1113, Sofia, Bulgaria; lazarova@orgchm.bas.bg (H.I.L.);
mpopova@orgchm.bas.bg (M.D.P.)
*
Correspondence: carlosafonso@ff.ulisboa.pt; Tel.: +351-217-946-400
Academic Editor: Artur Silva
Received: 15 January 2017; Accepted: 14 February 2017; Published: 20 February 2017
Abstract: 2,5-Diformylfuran (DFF) is an important biorenewable building block, namely for the
manufacture of new polymers that may replace existing materials derived from limited fossil fuel
resources. The current reported methods for the preparation of DFF are mainly derived from
the oxidation of 5-hydroxymethylfurfural (HMF) and, to a lesser extent, directly from fructose.
5
-Chloromethylfurfural (CMF) has been considered an alternative to HMF as an intermediate building
block due to its advantages regarding stability, polarity, and availability from glucose and cellulose.
The only reported method for the transformation of CMF to DFF is restricted to the use of DMSO
as the solvent and oxidant. We envisioned that the transformation could be performed using more
attractive conditions. To that end, we explored the oxidation of CMF to DFF by screening several
oxidants such as H O , oxone, and pyridine N-oxide (PNO); different heating methods, namely
2
2
thermal and microwave irradiation (MWI); and also flow conditions. The combination of PNO
(
4 equiv.) and Cu(OTf) (0.5 equiv.) in acetonitrile was identified as the best system, which lead to the
2
◦
formation of DFF in 54% yield under MWI for 5 min at 160 C. Consequently, a range of different
heterogeneous copper catalysts were tested, which allowed for catalyst reuse. Similar results were
also observed under flow conditions using copper immobilized on silica under thermal heating at
◦
0
1
60 C for a residence time of 2.7 min. Finally, HMF and 5,5 -oxybis(5-methylene-2-furaldehyde)
(OBMF) were the only byproducts identified under the reaction conditions studied.
Keywords: 5-chloromethylfurfural; 2,5-diformylfuran; 5-hydroxymethylfurfural; oxidation;
heterogeneous catalysis; catalyst reuse; flow chemistry
1
. Introduction
The pursuit of new biorenewable building blocks and/or more efficient synthetic routes has
intensified during the last few years. To date, several molecules including ethanol, glycerol, carboxylic
acids (lactic acid, succinic acid, 3-hydroxypropionic acid, itaconic acid, glutamic acid, levulinic
acid, fatty acids), furfural, 5-hydroxymethylfurfural (HMF) and terpenes (α-pinene, limonene, citral,
menthol) [ ] have been identified as alternatives to petroleum-based building blocks. The discovery
1–4
of new polymer monomers that may replace the current well established portfolio derived from
fossil fuel resources has been recognized as an important issue. 2,5-Furandicarboxylic acid (FDCA),
2
,5-dihydroxymethylfuran (DHMF) and 2,5-diformylfuran (DFF), among others, have been identified
as promising monomers [ ]. These furan derivatives are commonly obtained from HMF, which,
5,6
Molecules 2017, 22, 329; doi:10.3390/molecules22020329
www.mdpi.com/journal/molecules

Molecules 2017, 22, 329
2 of 14
in turn, is mainly derived from fructose [
7–
11]. Besides the intensive research and remarkable
achievements regarding the production of HMF, there are still limitations that arise from the specific
nature of HMF, namely, its thermal and chemical instability, high solubility in water, and low melting
point. On the other hand, as highlighted by the Mascal group, 5-chloromethylfurfural (CMF) is an
appealing alternative to HMF, due to its higher stability, lower polarity and higher accessibility from
glucose and cellulose [12–14].
In general, DFF is prepared by the oxidation of HMF [
8,11]. The selective oxidation of the
hydroxyl group into the aldehyde has been achieved using a variety of different methodologies
including homogeneous [
procedure from fructose (DMSO, NaBr (cat.), 150 C, 50%) [38], using molybdovanadophosphoric
heteropolyacids [39,40], using polyaniline-grafted vanadyl acetylacetonate [41], metal free
8
,
11
,
15
,
16] and heterogeneous [
8
,
11
,
17
–
37] metal catalysis, a one-step
◦
procedures [42–44] and enzyme catalysis [45]. The use of CMF as a starting material for the preparation
of DFF was previously described in 2014 by Estrine and Le Bras and later used by the Mascal
group. However, the use of DMSO as the solvent and oxidant makes this method less attractive
(
Scheme 1) [38,46]. To that end, we envisioned the possibility of performing such an oxidation without
using DMSO (Scheme 1).
Scheme 1. Reported methods by Estrine, Le Bras et al. [38] for the oxidation of CMF to DFF and in this
study on the search for alternative methods that avoid the use of DMSO and allow catalyst reuse.
2
. Results and Discussion
The oxidation of benzylic chlorides to the corresponding aldehydes has been reported
using different systems, namely CuCl/Kieselguhr/O2 [47], 2-dimethylamino-N,N-dimethylaniline
N-oxide [48], 3,6-bis(triphenylphosphonium)cyclohexene peroxodisulfate [49], NaIO -DMF [50],
4
H IO in [C mim][FeCl ] ionic liquid [51], TEMPO (cat)/KNO (cat)/O [52], NMO/KI (cat) in
5
6
12
4
2
2
[
emim]Cl ionic liquid, MW [53] and molybdate-based catalyst/H O [54]. Based on that, we started
2 2
this study by screening several oxidants (1.5 equiv.) for the oxidation of CMF in tetrabutylammonoium
◦
chloride (TBAC) as a reaction medium under basic conditions (K CO , 2 equiv.) at 110 C for 5 h.
2
3
Several oxidants such as urea hydrogen peroxide (UHP), NaBO , Ca(ClO) , NaIO , H O , Oxone,
3
2
4
2
2
KNO , and NMO yielded full conversion of CMF. However, very low NMR yields of DFF were
2
obtained (<10%, Table S1). In addition, HMF was identified as the single by-product (yields ranging
from 3% to 67%), whose formation may derive from the nucleophilic substitution of the chloride atom.
Those unsatisfactory results suggest that TBAC salt is not suitable for this transformation under the
tested reaction conditions, giving side reactions such as over oxidation and nucleophilic substitution.
From the preliminary screening, pyridine N-oxide (PNO) in combination with CuCl (0.5 equiv.)
was identified as the most effective system, providing DFF in 12% yield. Further solvent screening
◦
using PNO (2 equiv.) as the oxidant at lower temperature (82 C) for 24 h produced DFF in up to 9%
yield. (Table 1, entries 1–5). Acetonitrile was identified as the most promising solvent, suppressing the
undesired formation of HMF (Table 1, entry 1). Furthermore, no conversion of CMF was observed in
the absence of the promoter CuCl (Table 1, entry 4). Increasing the amount of PNO to 4 equiv. resulted
in an increased yield of DFF to 37% (3% of unreacted CMF was detected). However, HMF was detected
in 26% yield (Table 1, entry 6). The use of both anhydrous acetonitrile and PNO was not beneficial
for the suppression of HMF formation probably due to trace amounts of water in the PNO (Table 1,

Molecules 2017, 22, 329
3 of 14
entry 7). The use of longer reaction times (55 h, 34%, Table 1, entry 8), higher excess of PNO (8 equiv.,
◦
◦
3
7% yield, Table 1, entry 9), or lower/higher temperatures (60 C: 13%; 110 C: 19%; Table 1, entries 10
and 11) were not beneficial for the transformation. In addition, Cu(OTf) provided comparable results
2
(35%; Table 1, entry 12). Interestingly, using HMF instead of CMF resulted in no formation of DFF,
which suggests that DFF is not formed via HMF oxidation (Table 1, entry 14).
Table 1. Optimization of reaction conditions for the oxidation of CMF using PNO as an oxidant under
thermal heating.
Yield (%)
◦
Entry
Solvent
Promoter
Oxidant (equiv.)
T ( C)
DFF CMF HMF Total
1
2
3
4
5
6
7
8
9
CH CN
t-BuOH
THF
CuCl
CuCl
CuCl
None
CuCl
CuCl
CuCl
CuCl
CuCl
CuCl
2
2
2
2
2
4
4
4
8
4
4
4
4
4
82
82
82
82
82
82
82
82
82
60
110
82
82
82
9
5
6
49
47
n.d.
100
n.d.
3
3
14
8
2
n.d.
5
2
100
n.d.
48
96
n.d.
100
26
53
n.d.
4
58
100
100
100
100
66
81
48
49
60
19
40
38
100
3
CH CN
n.d.
n.d.
37
25
34
37
13
19
35
32
n.d.
3
CH CN:H O 1:1
3
2
CH CN
3
a
CH CN
3
b
CH CN
3
CH CN
3
10
11
12
13
14
CH CN
45
3
CH CN
CuCl
n.d.
n.d.
4
3
CH CN
Cu(OTf)2
Cu(OTf)2
CuCl
3
c
CH CN
3
d
CH CN
n.d.
3
Reaction conditions: CMF (50 mg, 0.35 mmol), promoter (0.5 equiv.), pyridine N-oxide as oxidant, in a concentration
◦
of 0.5 M at 82 C for 24 h in a glass pressure tube (Aldrich Ref. Z181064-1EA); the yields were determined by
1
a
CN; b reaction time is
H-NMR using 1,3,5-trimethoxybenzene as an internal standard. Using dry PNO and CH
5 h instead of 24 h; c using0.25 equiv. of promoter; d reaction performed using HMF (0.35 mmol) instead of CMF;
n.d. = not detected.
3
5
The use of microwave irradiation (MWI) using 4 equiv. of PNO and 0.5 equiv. of Cu(OTf) in
2
◦
acetonitrile (0.5 M) at 82 C lead to the formation of DFF in 49% yield after 6 h, together with 24% of
unreacted CMF (Table 2, entry 1). Remarkably, the formation of HMF was not observed under these
conditions, which is considerably better than the best results achieved under thermal heating (37%
◦
of DFF after 24 h, Table 1, entry 6). Further optimization of the reaction conditions to 160 C and
only 5 min of reaction time resulted in the formation of DFF in up to 51% yield (isolated yield of 50%,
Table 2, entries 9 and 10, see complete data in Table S3). In addition, the reaction performed in the
absence of the promoter Cu(OTf) yielded only 6% of DFF (Table 2, entry 11). Finally, no formation of
2
DFF was observed in the absence of the PNO oxidant, resulting in the complete decomposition of the
CMF substrate instead (Table 2, entry 15).
Table 2. Selected reaction conditions and yields of DFF, CMF, and HMF for the oxidation reactions of
CMF performed under microwave irradiation (MWI).
Time
Temp.
( C)
Oxidant Promoter
Yield (%)
CMF
Entry
◦
(min)
(equiv.)
(equiv.)
DFF
Total
1
2
3
4
5
6
7
360
120
60
5
15
30
60
82
4
4
4
4
4
4
4
0.5
0.5
0.5
0.5
0.5
0.5
0.5
49
39
39
44
46
47
49
24
4
7
5
5
73
43
46
49
51
53
53
100
120
140
140
140
140
6
4

Molecules 2017, 22, 329
4 of 14
Table 2. Cont.
Time
Temp.
( C)
Oxidant Promoter
Yield (%)
CMF
Entry
◦
(min)
(equiv.)
(equiv.)
DFF
Total
8
9
1
5
5
5
5
5
5
5
30
1
160
160
160
160
160
160
160
160
160
170
4
4
4
4
4
4
2
0
4
4
0.5
0.5
0.5
0
0.25
1
0.5
0.5
0.5
0.5
47
51
50
6
39
37
40
18
8
8
59
8
8
65
59
58
65
47
45
40
a
1
1
1
1
1
1
1
1
0
1
2
3
4
5
6
7
n.d.
dark crude
45
49
4
3
49
52
2 3
Reaction conditions: CMF (0.35 mmol, 50 mg), Cu(OTf) , pyridine N-oxide as oxidant, in CH CN (0.5 M) under
1
microwave irradiation (MWI); the yields were determined by H-NMR using 1,3,5-trimethoxybenzene as an internal
a
standard and HMF was not detected. Isolated yield were obtained by column chromatography purification using
hexane:ethyl acetate (2:1) as an eluent; n.d. = not detected.
◦
The study of the reaction time was carried out following the general procedure at 140 C with
0
.5 equiv. of Cu(OTf) . The results shown in Figure 1a indicate that there is no pronounced advantage
2
for both the DFF yield and CMF conversion by running the reaction for more than 5 min. Regarding
the promoter loading, it was observed that 0.5 equiv. of Cu(OTf) is the optimal amount, yielding the
2
product DFF in 51% yield.
◦
Figure 1. Oxidation of CMF for (
a
) different reaction times at 140 C using 0.5 equiv. of Cu(OTf) ;
2
◦
(
b
) different promoter loading at 160 C for 5 min. Reaction conditions: microwave irradiation (MWI),
CMF (0.35 mmol, 50 mg), 4 equiv. of pyridine N-oxide, in CH CN (0.5 M). Yields were determined by
3
1
H-NMR analysis of the crude reaction mixture using 1,3,5-trimethoxybenzene as internal standard.
We envisioned that this procedure would be more effective under heterogeneous conditions. Based
on that, several different catalysts, namely commercially available CuCl or CuSO as well as supported
4
Cu catalysts, were tested under the conditions optimized using the promoter Cu(OTf) (0.5 mol %,
2
◦
PNO (4 equiv.), acetonitrile (0.5 M), MWI, 160 C, 5 min). The adsorption of CuSO in silica (CuSO
·
Si)
4
4
and neutral (CuSO4
·
AN) or basic alumina (CuSO4
·
AB) was performed by simple evaporation of the
solid support suspension in an aqueous solution of CuSO . TheCu/SiO catalysts were prepared
4
2
according to the reported procedure [55] by dispersion of the copper complex in silica followed by
◦
water evaporation and calcination (400 C, 4 h). The SBA-16 catalysts were synthesized according to
the procedure of Hu et al. [56]. The XRD data of the Cu, Mn, and V modified SBA-16 silica materials in
the lower two theta regions (not shown) confirm the preservation of the mesoporous structure after the
impregnation process. In the higher two theta regions, reflections with low intensity, characteristic of

Molecules 2017, 22, 329
5 of 14
CuO, were detected in the Cu/SBA-16 material. No reflections typical of Mn and V oxide species could
be observed by XRD (Figure 2), which is due to the formation of finely dispersed metal oxide species
in them. The crystallite size of the copper oxide particles was determined by the Scherrer method to be
around 20 nm. The calculated textural parameters from the nitrogen physisorption measurements of
the metal-containing silica materials are listed in Table 3. No significant pore size reduction can be
observed in SBA-16 supported catalysts either in the spherical pores (~8 nm) or in the interconnecting
channels (2.5 nm). These data support that a portion of the metal oxides penetrated into the channels
and cavities of the mesoporous supports, but no significant pore blocking occurred.
Cu/SBA-16
Mn/SBA-16
V/SBA-16
10
20
30
40
50
60
70
Bragg angle, 2Theta
Figure 2. XRD temperature-programmed reduction of the Cu/SBA-16, V/SBA-16 and Mn/
SBA-16 catalysts.
Table 3. Textural properties of the studied SBA-16 samples.
2
PD a (nm)
3
Samples
SBET (m /g)
Pore Volume (cm /g)
SBA-16
CuSBA-16
MnSBA-16
VSBA-16
1128
695
630
570
7.90 (2.5)
7.55 (2.5)
7.86 (2.5)
7.83 (2.5)
0.64
0.50
0.39
0.37
a
Pore diameter calculated by the Non-Local Density Functional Theory (NLDFT) method (adsorption branch).
The temperature-programmed reduction (TPR) data (Figure 3) show the total reduction of CuO to
◦
Cu(o) in the Cu/SBA-16 sample which occurred at low temperature (around 210 C). Partial reduction
◦
of the Mn oxide species was detected in the Mn/SBA-16 sample at higher temperature (275 C).
180
Mn/SBA-16
275
Cu/SBA-16
210
100
200
300
400
500
600
o
Temperature, C
Figure 3. TPR of the Cu/SBA-16 and Mn/SBA-16 catalysts.

Molecules 2017, 22, 329
6 of 14
Oxidation of CMF in the presence of different heterogeneous catalysts indicated that CuSBA-16
10%) is the most efficient promoter, leading to a similar yield of DFF as the homogeneous promoter
(
Cu(OTf) . Remarkably, CuSO , which is the cheapest catalyst tested, gave 42% yield of DFF (Figure 4).
2
4
Using a higher amount of CuSO (1%), longer reaction time (up to 30 min), or higher temperature (up
4
◦
to 170 C) gave lower yields of DFF (38%, 41%, and 35%, respectively), together with the formation of
small amounts of HMF (up to 7%, see full results in Table S4).
60
50
40
30
20
10
0
51
50
DFF
CMF
HMF
4
2
3
5
3
1
31
26
21
1
2
1
1
10
8
4
4
0
2
2
1
0
0
0 0
0
0
Cu(OTf)2
CuCl
CuSBA-16 CuSO4
0%
CuSO4.Si CuSO4.Si CuSO4.AN CuSO4.AB
10% 5% 10% 10%
1
Figure 4. Effect of the promoter nature on the oxidation of CMF under microwave irradiation (MWI).
◦
Reaction conditions: CMF (0.35 mmol, 50 mg), catalyst, PNO (4 equiv.) in CH CN (0.5 M) and 160 C for
5
3
1
min under MWI; yields were determined by H-NMR analysis of the crude reaction mixture using
1
,3,5-trimethoxybenzene as an internal standard.
In order to facilitate the flow process, several ethers were tested as solvents for the oxidation
of CMF using Cu(OTf) as the promoter, including those with high boiling points (b.p. higher
2
◦
than 160 C) such as dioctyl ether, PEG-6 and triethylene glycol dimethyl ether (TGDE) (Figure 5).
Remarkably, TGDE gave a better yield of DFF (54%) than acetonitrile, together with 16% of unreacted
CMF. In addition, the oxidation is also feasible using CuSO or supported CuSO on silica (CuSO4·Si
4
4
(10%)) in TGDE, yielding DFF in 33% and 44%, respectively (Table S5).
60
50
40
30
20
10
0
54
DFF CMF
51
51
24
23
17
16
8
5
0
CH3CN
THF
dioctyl ether
PEG-6
TGDE
Figure 5. Effect of the solvent on the oxidation of CMF under microwave irradiation (MWI). Reaction
conditions: CMF (0.35 mmol, 50 mg), Cu(OTf) (0.5 equiv.), PNO (4 equiv.) in a concentration of 0.5 M
2
◦
1
at 160 C for 5 min under MWI; yields were determined by H-NMR analysis of the crude reaction
mixture using 1,3,5-trimethoxybenzene as an internal standard.

Molecules 2017, 22, 329
7 of 14
The heterogeneous catalyst CuSO4
Remarkably, only a slight erosion of the DFF yield was observed over seven cycles. (1st cycle: 43%; 7th
cycle: 38%). In addition, the amount of unreacted CMF increased from cycle to cycle (1st cycle: none;
·
Si (10%) was selected to explore catalyst reuse (Figure 6).
7
th cycle: 57%). Interestingly, for the cycles in which the formation of HMF was observed, formation
of the dimer OBMF was also observed, which could arise from the reaction of HMF with CMF.
57
60
50
40
30
20
10
0
DFF CMF HMF OBMF
47
46
43
40
37
38
38
38
36
33
2
9
22
13
1
2
6
10
6
4
4
0
0
0 0
0 0
0 0
1
2
3
4
5
6
7
Cycles
Figure 6. Catalyst reuse for the oxidation of CMF. Reaction conditions for each cycle: CMF (0.35 mmol,
◦
5
0 mg), 0.5 equiv. of CuSO4
·
Si 10%, 4 equiv. of PNO in TGDE (0.5 M) at 160 C for 5 min under
1
microwave irradiation; yields were determined by H-NMR analysis of the crude reaction mixture
using 1,3,5-trimethoxybenzene as an internal standard. OBMF: 5,5 -oxybis(5-methylene-2-furaldehyde).
0
Finally, the oxidation of CMF was explored under flow conditions. Initially, the flow study started
by testing the efficiency of the catalyst by performing four oxidation reactions in continuous flow
conditions. The selected conditions to perform the flow experiments were based on the best conditions
◦
obtained under microwave irradiation and using TGDE (b.p. = 216 C) as the solvent because it
◦
allows the reaction to be performed at 160 C without causing pressure issues. The other reaction
parameters used were: 0.5 mL/min flow rate and 10% (wt/wt) CuSO adsorbed on silica catalyst.
4
The yields obtained for each identified product or starting material are presented in Table 4 for four
consecutive flow experiments using the same catalyst. It is worth mentioning that in contrast to the
results obtained under batch conditions (thermal and MWI), the mass balance is almost complete for
all of the experiments, indicating that there are no side products besides the formation of HMF and
OBMF. For the first reaction, the yields of DFF and CMF are similar to the ones obtained under MWI
or batch conditions using the same solvent, temperature and catalyst, 43% vs. 44% and 15% vs. 22%,
respectively (Table 4 vs. Table S5). Under flow conditions, the formation of HMF leading to an almost
complete mass balance was observed, while under MWI conditions, the mass balance was only 66%,
which suggests that the flow may minimize further transformations such as over oxidation. These
polar products are probably absorbed on the silica when the reaction solution is filtered to separate
the catalyst from the crude and this could explain the incomplete mass balance for the microwave
reactions. Through the consecutive reactions, the yields of DFF, CMF and HMF decrease while the
formation of a new product was observed in up to 77%—the dimer OBMF. These results indicate that
decreasing the activity of the catalyst results in the formation of HMF that consequently leads to the
formation of OBMF.
Since CMF was not totally consumed, we tried to improve the yield of DFF by using the same
◦
flow conditions as previously described, but at 180 C. However, a lower performance was observed
providing yields of 20%, 16%, 43% and 20% of DFF, CMF, HMF and OBMF, respectively, indicating
that these conditions are detrimental for the formation of DFF (Table 4 in brackets).

Molecules 2017, 22, 329
8 of 14
Table 4. Oxidation of CMF for four consecutive flow reactions using CuSO ·Si 10%.
4
Consecutive
Reactions
Yield (%)
HMF
DFF
CMF
OBMF
Total
1
2
3
4
st
nd
rd
th
43 (20)
22
11
15 (16)
16
5
n.d.
40 (43)
20
20
0 (20)
36
56
98 (98)
95
92
17
n.d.
77
94
Reaction conditions for each flow experiment: Each solution of CMF (225 mg, 1.56 mmol) and pyridine N-oxide (4 equiv.)
in TGDE (0.5 M) was passed at a flow rate of 0.5 mL/min through the column totally filled with CuSO4·Si 10% at
◦
1
1
60 C; yields were determined by H-NMR analysis of the crude reaction mixture using 1,3,5-trimethoxybenzene as
◦
an internal standard; the results obtained for a fresh catalyst at 180 C are provided in brackets; n.d. = not detected.
In order to minimize the side reaction of HMF formation, which appeared to be promoted under
◦
flow conditions and was probably due to the presence of water, the catalyst was dried for 24 h at 130 C.
However, there was no improvement in the results (Table 5, entry 2 vs. 1). Since the TGDE solvent
is highly hygroscopic, the solvent was changed to tetraethylene glycol dimethyl ether (TEGDME,
◦
b.p. = 275 C), that is less hygroscopic, providing only a slightly higher yield of DFF (40% vs. 36% for
TGDE, Table 5, entry 3 vs. 2) and only a 17% yield reduction of HMF, although with the formation of
OBMF in a 10% yield. Milled hydrated CuSO was also tested, resulting in a lower yield of DFF (17%),
4
together with a higher yield of HMF (71%). In addition, an increase in the pressure was observed,
which was due to column blocking during operation. In order to circumvent this limitation, a lower
amount (5%) of CuSO immobilized in silica was tested, resulting in comparable results to the ones
4
observed for 10% CuSO in silica (Table 5, entry 5 vs. entry 1). A 1:1 mixture of Cu O/silica gave
4
2
only a 37% yield of DFF as the only detected product (Table 5, entry 6). The use of Cu/SiO prepared
2
according to a reported procedure [55], gave a 29% yield of DFF and a 49% yield of undesired HMF,
which was less efficient then CuSO supported in silica. In order to reduce subsequent over oxidation,
4
lower residence times were tested (Table 5, entries 9–10) by increasing the flow rate from 0.5 to
1
mL/min. This condition allowed for the formation of DFF with 42% yield. In addition, increasing
the amount of promoter to 1 equiv. gave a 54% yield of DFF (Table 5 entry 10). The CMF loading was
also increased by passing 1 g through the column containing the immobilized catalyst Cu/SiO and all
2
CMF was consumed, yielding 27% of DFF and 54% of HMF (Table S10).
Table 5. Oxidation of CMF under flow conditions using different heterogeneous catalysts.
Flow Rate
Residence
Time (min)
Yield (%)
Entry
Catalyst
(mL/min)
DFF
CMF
HMF OBMF Total
a,b
1
2
3
4
5
6
7
8
9
CuSO ·Si 10%
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
1.0
1.0
5.3
5.3
5.3
5.3
5.3
5.3
5.3
5.3
2.7
2.7
40
36
40
17
40
37
24
29
42
54
16
26
20
n.d.
10
n.d.
n.d.
n.d.
n.d.
n.d.
42
36
25
71
32
n.d.
58
49
13
n.d.
n.d.
10
n.d.
n.d.
n.d.
n.d.
n.d.
18
98
98
94
88
82
37
82
70
73
72
4
a,c
c
CuSO ·Si 10% dry
4
CuSO ·Si 10% dry
4
d
CuSO
4
c
CuSO ·Si 5%
4
e
Cu O/silica (1:1)
2
a,f
Cu-SBA16
2
c
c
Cu/SiO (0.5 mol equiv.)
Cu/SiO (0.5 mol equiv.)
Cu/SiO (1 mol equiv.)
2
c
1
0
19
n.d.
2
Reaction conditions for each flow experiment: Each solution of CMF (225 mg, 1.56 mmol) and pyridine N-oxide (4 equiv.)
in TEGDME (0.5 M) was passed at a specific flow rate through the column containing the heterogeneous Cu based
◦
1
catalyst at 160 C; the yields were determined by H-NMR using 1,3,5-trimethoxybenzene as an internal standard;
a
TGDE: amount of catalyst was 2.08 g; column completely filled with catalyst; d column filled with 150 mg of
silica and CuSO
triturated (4.28 g); e column filled with 360 mg of silica and the rest was completely filled with
catalyst (1:1 weight mixture of CuO
/Silica); f column filled with 1.05 g of silica and the remaining volume was
completely filled with catalyst; n.d. = not detected.
b
c
4
2

Molecules 2017, 22, 329
9 of 14
3
. Materials and Methods
3
.1. General Materials and Methods
Tetrabutylammonium chloride (TBAC), 1,3,5-trimethoxybenzene, urea hydrogen peroxide (UHP),
sodium perborate tetrahydrate (NaBO3
·
4H O), calcium hypochlorite (Ca(ClO) ), sodium periodate
2
2
(
NaIO ), hydrogen peroxide (H O ), oxone (2KHSO
·
KHSO4
·
K SO ), potassium nitrite (KNO ),
4
2
2
5
2
4
2
N-methylmorpholine-N-oxide (NMO), potassium carbonate (K CO ), potassium bromide (KBr),
2
3
pyridine N-oxide (PNO), (2,2,6,6-tetramethylpiperidin-1-yl)oxyl (TEMPO), sodium nitrite (NaNO2),
p-tolyl sulfoxide, chlorotrimethylsilane, copper(I) chloride (CuCl), copper(II) triflate (Cu(OTf)2),
copper(I) triflate toluene complex (Cu(OTf)), copper oxide (Cu O), and copper(II) sulphate (CuSO )
2
4
were purchased from Sigma-Aldrich (Lisboa, Portugal) and used as received unless otherwise stated.
Column chromatography was performed using silica gel 60 GF254 Merck Ref. 1.07730.1000 (Darmstadt,
Germany). Catalysts were adsorbed or immobilized in silica gel 60 GF254 MercK Ref. 1.07730.1000,
aluminium oxide 90 active basic MercK Ref. 101076 (AB), or aluminium oxide 90 active neutral MercK
Ref. 101077 (AN). The reagents dioctyl ether (Ref. 249599), tetraethylene glycol dimethyl ether (Ref.
1
72405) (TEGDME), and triethylene glycol dimethyl ether (Ref. 8.08249.0250) (TGDE) were purchased
from Sigma Aldrich and polyglycol 300 (PEG-6) was obtained from Clariant (Artziniega, Spain). All
solvents, tetrahydrofuran (THF), acetonitrile, tert-butyl alcohol (t-BuOH), chloroform, ethyl acetate,
dichloromethane, and n-hexane were used without further purification.
5-(Hydroxymethyl)furfural (HMF) was synthetized from fructose using the procedure previously
reported by our group [57 58]. 5-(chloromethyl)furan-2-carbaldehyde (CMF) was prepared from HMF
,
following a reported procedure [59].
Nuclear magnetic resonance (NMR) spectra were recorded using a Bruker MX300 spectrometer
(
Rheinstetten, Germany). The microwave experiments were performed on a CEM Discover Benchmat
apparatus (CEM Corporation, Matthews, NC, USA) using a glass pressure vessel (10 mL).
3
.2. Preparation of Heterogeneous Catalysts
General procedure for the adsorption of CuSO in silica, basic alumina or neutral alumina is as
4
follows: the desired solid support (10 g) was added to CuSO (1 g) in water (50 mL). After stirring for
4
◦
1
0 min, water was removed under vacuum in a rotary evaporator and left in an oven at 130 C for 24 h.
The resulting solid was used without further treatment.
General procedure for the preparation of the Cu/SiO immobilized catalysts: the Cu/SiO
2
2
catalysts were prepared according to a reported procedure [55]. Briefly, to prepare a catalyst with
x%, NH OH was added to a solution of Cu(NO )
·
2.5H O until pH 9. The silica was added and
4
3 2
2
◦
stirred for 20 min. The solution was submerged in an ice bath at 0 C and diluted with water in order
to hydrolyze the copper complex and precipitate the dispersed product. The solid was filtered and
◦
◦
washed with water, dried overnight at 110 C and calcined at 400 C for 4 h.
Synthesis of SBA-16 and its Mn-, Cu- and V-modified analogs: the parent silica SBA-16 material
was synthesized according to the procedure of Hu et al. [56]. Pluronic F127 triblock copolymer and
cetyl trimethyl ammonium bromide (CTAB) were used as templates and tetraethylortosilicate (TEOS)
was used as a silica source. In a typical synthesis, F127 (1.0 g) and CTAB (0.12 g) were completely
dissolved into a solution of 130 mL water and 10 mL concentrated HCl, followed by the addition of
◦
◦
4
.0 mL of TEOS under stirring. After 1 h of stirring at 40 C, the mixture was heated at 80 C for 24 h
under static conditions. The solid product was filtered, washed with water three times and dried at
◦
◦
◦
5
0 C. The template was removed by calcination in air at 550 C for 5 h with a heating rate of 1 C/min.
Mn, Cu, V-containing (5–20 wt %) SBA-16 materials were prepared by incipient wetness
impregnation with manganese (II) acetylacetonate, copper (II) acetylacetonate and vanadyl(VI)
sulphate as salt precursors, respectively.
Characterization of the initial and modified SBA-16 materials: the X-ray powder diffraction
(XRD) patterns were recorded on a PANalytical X´Pert PRO (HTK) high-resolution diffractometer

Molecules 2017, 22, 329
10 of 14
◦ ◦
The Netherlands) using Cu Kα1 radiation (1.5406 Å) in the 2 θ range from 5 to 80 (100 s per 0.016
step) for the samples and from 10 to 70 (100 s per 0.016 step) for the sample holder using a fully
◦
(
◦
◦
◦
opened X´Celerator detector.
Nitrogen physisorption measurements were carried out at
Micromeritics volumetric adsorption analyzer (Ense, Germany). Before the adsorption analysis,
◦
−
196 C using a Tristar 3000
◦
the samples were outgassed under vacuum for 2 h at 200 C in the port of the adsorption analyzer.
The Brunauer–Emmett–Teller (BET) specific surface area was calculated from adsorption data in the
relative pressure range from 0.05 to 0.21. The pore size distributions (PSDs) were calculated from the
nitrogen adsorption data using an algorithm based on the ideas of Barrett, Joyner and Halenda (BJH).
The reducibility of the Cu, Mn, and V-modified samples were investigated by the
temperature-programmed reduction (TPR) technique in H /Ar flow (10:90, 20 mL/min) using a
2
conventional TPR apparatus equipped with a heat conductivity cell and a trap for the removal of
◦
released water. Before TPR, run samples were pretreated in oxygen at 350 C for 1 h.
General procedure for the oxidation of CMF under microwave irradiation (MWI): CMF (0.35 mmol,
5
0 mg), pyridine N-oxide (4 equiv., 1.4 mmol), Cu(OTf) (0.5 equiv.) and CH CN (0.5 M) were added
2 3
to a microwave pressure vessel (10 mL). The resulting mixture was allowed to stir at the desired
temperature and time. The mixture was filtered through a pad of silica gel using a mixture of
hexane/ethyl acetate (1:1) and the solvents were evaporated. Quantification of CMF, DFF, and HMF
1
was performed by H-NMR analysis of the crude reaction mixture by using 1,3,5-trimethoxybenzene
as an internal standard. DFF and CMF were isolated by column chromatography purification using
hexane:ethyl acetate (2:1).
Procedure for the oxidation of CMF and catalyst reuse: CMF (0.35 mmol, 50 mg), pyridine
N-oxide (4 equiv., 1.4 mmol), CuSO4
·
Si (10% w/w, 0.5 equiv.) and TGDE (0.5 M) was added
◦
to a microwave pressure vessel (10 mL). The resulting mixture was stirred for 5 min at 160 C
under microwave irradiation. The mixture was filtered first through cotton using a Pasteur
pipette (to collect the catalyst) followed by filtration through silica using a mixture of hexane/ethyl
acetate 1:1 and the solvents were removed under vacuum. Quantification of CMF, DFF, HMF and
0
1
(
5,5 -(oxybis(methylene))bis(furan-5,2-diyl))dimethanol (OBMF) was performed by H-NMR analysis
of the crude mixture using 1,3,5-trimethoxybenzene as an internal standard. The collected catalyst was
then reused in the next cycle using the same reaction conditions.
General procedure for CMF oxidation using flow conditions: an empty HPLC column
(i.d. = 3.9 mm; L = 300 mm) was filled with the respective modified silica and/or promoter and
placed inside a gas chromatography (GC) oven. The desired solvent was passed through the column at
room temperature using an HPLC pump until the column was completely filled. The temperature of
the GC oven was then raised to the desired value and stabilized for 30 min. A solution of CMF
(1.56 mmol, 225 mg) and pyridine N-oxide (4 equiv.) in the respective solvent (0.5 M in CMF)
was passed through the column under constant flow and the output was sequentially collected
in different vials.
1
Note 1: Quantification by H-NMR was performed taking into account the weight of the collected
fraction and by adding a specific amount of the internal standard (1,3,5-trimethoxybenzene).
Note 2: The promoter amount was calculated by weighing the column before and after filling with
the modified silica. When necessary, the resulting empty volume of the column was filled with silica.
For the cases in which the column was blocked during the operation, the experiment was repeated
by filling the end of the column with silica followed by the supported catalyst.
4
. Conclusions
This study describes the oxidation of CMF to DFF by exploring a range of oxidants, promoters
and reaction conditions. Pyridine N-oxide (PNO) in combination with the Cu based promoter under
homogeneous and heterogeneous conditions was identified as the best system. In addition, the

Molecules 2017, 22, 329
11 of 14
heterogeneous catalyst can be reused and applied under flow conditions providing similar performance
as obtained under homogeneous conditions.
Supplementary Materials: Supplementary materials are available online.
Acknowledgments: The authors acknowledge the Fundação para a Ciência e a Tecnologia (FCT) (ref.
SFRH/BPD/100433/2014, SFRH/BPD/109476/2015, and UID/DTP/04138/2013), and the European Research
Area Network; ERANet LAC (ref. ELAC2014/BEE-0341) for financial support; REDE/1518/REM/2005 (FF-UL)
for the mass service; Jorge M. C. Sousa e Silva for performing preliminary non-conclusive experiments using gas
chromatography; Ágnes Szegedi from the Institute of Materials and Environmental Chemistry, Research Centre
for Natural Sciences, Hungarian Academy of Sciences for the XRD and N physisorption analysis.
2
Author Contributions: C.A.M. Afonso, J.A.S. Coelho, and S.P. Simeonov conceived and designed the experiments;
J.A.S. Coelho and S.P. Simeonov performed the preliminary experiments; A.I. Vicente performed the main
experiments; H.I. Lazarova and M.D. Popova synthesized and characterized the Cu, V, and Mn SBA-16 catalysts.
All authors contributed to the manuscript preparation.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
5.
6.
7.
8.
Corma, A.; Iborra, S.; Velty, A. Chemical Routes for the Transformation of Biomass into Chemicals. Chem. Rev.
007, 107, 2411–2502. [CrossRef] [PubMed]
Vispute, T.P.; Zhang, H.; Sanna, A.; Xiao, R.; Huber, G.W. Renewable Chemical Commodity Feedstocks from
Integrated Catalytic Processing of Pyrolysis Oils. Science 2010, 330, 1222–1227. [CrossRef] [PubMed]
Takagaki, A.; Nishimura, S.; Ebitani, K. Catalytic Transformations of Biomass-Derived Materials into
Value-Added Chemicals. Catal. Surv. Asia 2012, 16, 164–182. [CrossRef]
Christensen, C.H.; Rass-Hansen, J.; Marsden, C.C.; Taarning, E.; Egeblad, K. The Renewable Chemicals
Industry. ChemSusChem 2008, 1, 283–289. [CrossRef] [PubMed]
Dutta, S.; De, S.; Saha, B. A Brief Summary of the Synthesis of Polyester Building-Block Chemicals and
Biofuels from 5-Hydroxymethylfurfural. ChemPlusChem 2012, 77, 259–272. [CrossRef]
Gandini, A. The irruption of polymers from renewable resources on the scene of macromolecular science
and technology. Green Chem. 2011, 13, 1061–1083. [CrossRef]
2
Lewkowski, J. Synthesis, chemistry and applications of 5-hydroxymethyl-furfural and its derivatives.
ARKIVOC 2001, 17–54. [CrossRef]
Rosatella, A.A.; Simeonov, S.P.; Frade, R.F.M.; Afonso, C.A.M. 5-Hydroxymethylfurfural (HMF) as a building
block platform: Biological properties, synthesis and synthetic applications. Green Chem. 2011, 13, 754–793.
[CrossRef]
9
1
1
.
Teong, S.P.; Yi, G.; Zhang, Y. Hydroxymethylfurfural production from bioresources: Past, present and future.
Green Chem. 2014, 16, 2015–2026. [CrossRef]
0. Mukherjee, A.; Dumont, M.-J.; Raghavan, V. Review: Sustainable production of hydroxymethylfurfural and
levulinic acid: Challenges and opportunities. Biomass Bioenergy 2015, 72, 143–183. [CrossRef]
1. van Putten, R.-J.; van der Waal, J.C.; de Jong, E.; Rasrendra, C.B.; Heeres, H.J.; de Vries, J.G.
Hydroxymethylfurfural, A Versatile Platform Chemical Made from Renewable Resources. Chem. Rev.
2
013, 113, 1499–1597. [CrossRef] [PubMed]
2. Mascal, M.; Nikitin, E.B. Direct, High-Yield Conversion of Cellulose into Biofuel. Angew. Chem. Int. Ed. 2008
7, 7924–7926. [CrossRef] [PubMed]
3. Mascal, M.; Nikitin, E.B. Dramatic Advancements in the Saccharide to 5-(Chloromethyl)furfural Conversion
Reaction. ChemSusChem 2009, 2, 859–861. [CrossRef] [PubMed]
4. Mascal, M. 5-(Chloromethyl)furfural is the New HMF: Functionally Equiv.alent But More Practical in Terms
of its Production From Biomass. ChemSusChem 2015, 8, 3391–3395. [CrossRef] [PubMed]
5. Hansen, T.S.; Sádaba, I.; García-Suárez, E.J.; Riisager, A. Cu catalyzed oxidation of 5-hydroxymethylfurfural
1
1
1
1
,
4
to 2,5-diformylfuran and 2,5-furandicarboxylic acid under benign reaction conditions. Appl. Catal. A 2013
56, 44–50. [CrossRef]
,
4
1
6. Kompanets, M.O.; Kushch, O.V.; Litvinov, Y.E.; Pliekhov, O.L.; Novikova, K.V.; Novokhatko, A.O.;
Shendrik, A.N.; Vasilyev, A.V.; Opeida, I.O. Oxidation of 5-hydroxymethylfurfural to 2,5-diformylfuran with
molecular oxygen in the presence of N-hydroxyphthalimide. Catal. Commun. 2014, 57, 60–63. [CrossRef]

Molecules 2017, 22, 329
12 of 14
1
1
7. Le, N.-T.; Lakshmanan, P.; Cho, K.; Han, Y.; Kim, H. Selective oxidation of 5-hydroxymethyl-2-furfural into
2
4
,5-diformylfuran over VO2+ and Cu2+ ions immobilized on sulfonated carbon catalysts. Appl. Catal. A 2013
64–465, 305–312. [CrossRef]
,
8. Saha, B.; Gupta, D.; Abu-Omar, M.M.; Modak, A.; Bhaumik, A. Porphyrin-based porous organic
polymer-supported iron(III) catalyst for efficient aerobic oxidation of 5-hydroxymethyl-furfural into
2
,5-furandicarboxylic acid. J. Catal. 2013, 299, 316–320. [CrossRef]
1
2
2
9. Nie, J.; Xie, J.; Liu, H. Efficient aerobic oxidation of 5-hydroxymethylfurfural to 2,5-diformylfuran on
supported Ru catalysts. J. Catal. 2013, 301, 83–91. [CrossRef]
0. Jia, X.; Ma, J.; Wang, M.; Du, Z.; Lu, F.; Wang, F.; Xu, J. Promoted role of Cu(NO ) on aerobic oxidation of
3
2
5
-hydroxymethylfurfural to 2,5-diformylfuran over VOSO . Appl. Catal. A 2014, 482, 231–236. [CrossRef]
4
1. Yadav, G.D.; Sharma, R.V. Biomass derived chemicals: Environmentally benign process for oxidation of
-hydroxymethylfurfural to 2,5-diformylfuran by using nano-fibrous Ag-OMS-2-catalyst. Appl. Catal.
5
B Environ. 2014, 147, 293–301. [CrossRef]
2
2
2
2
2
2
2
2
2. Zhang, Z.; Yuan, Z.; Tang, D.; Ren, Y.; Lv, K.; Liu, B. Iron Oxide Encapsulated by Ruthenium Hydroxyapatite
as Heterogeneous Catalyst for the Synthesis of 2,5-Diformylfuran. ChemSusChem 2014, 7, 3496–3504.
[CrossRef] [PubMed]
3. Wang, Y.; Liu, B.; Huang, K.; Zhang, Z. Aerobic Oxidation of Biomass-Derived 5-(Hydroxymethyl)furfural
into 2,5-Diformylfuran Catalyzed by the Trimetallic Mixed Oxide (Co–Ce–Ru). Ind. Eng. Chem. Res. 2014, 53,
1
313–1319. [CrossRef]
4. Wang, S.; Zhang, Z.; Liu, B.; Li, J. Environmentally Friendly Oxidation of Biomass Derived
-Hydroxymethylfurfural into 2,5-Diformylfuran Catalyzed by Magnetic Separation of Ruthenium Catalyst.
5
Ind. Eng. Chem. Res. 2014, 53, 5820–5827. [CrossRef]
5. Artz, J.; Palkovits, R. Base-Free Aqueous-Phase Oxidation of 5-Hydroxymethylfurfural over Ruthenium
Catalysts Supported on Covalent Triazine Frameworks. ChemSusChem 2015, 8, 3832–3838. [CrossRef]
[
PubMed]
6. Han, X.; Geng, L.; Guo, Y.; Jia, R.; Liu, X.; Zhang, Y.; Wang, Y. Base-free aerobic oxidation of
-hydroxymethylfurfural to 2,5-furandicarboxylic acid over a Pt/C-O-Mg catalyst. Green Chem. 2016
8, 1597–1604. [CrossRef]
7. Guo, Y.; Chen, J. Bicomponent Assembly of VO and Polyaniline-Functionalized Carbon Nanotubes for the
5
,
1
2
Selective Oxidation of Biomass-Based 5-Hydroxymethylfurfural to 2,5-Diformylfuran. ChemPlusChem 2015
0, 1760–1768. [CrossRef]
8. Neat,u, F.; Marin, R.S.; Florea, M.; Petrea, N.; Pavel, O.D.; Pârvulescu, V.I. Selective oxidation of
-hydroxymethyl furfural over non-precious metal heterogeneous catalysts. Appl. Catal. B Environ. 2016
80, 751–757. [CrossRef]
9. Mittal, N.; Nisola, G.M.; Malihan, L.B.; Seo, J.G.; Kim, H.; Lee, S.-P.; Chung, W.-J. One-pot synthesis of
,5-diformylfuran from fructose using a magnetic bi-functional catalyst. RSC Adv. 2016, 6, 25678–25688.
CrossRef]
0. Li, S.; Su, K.; Li, Z.; Cheng, B. Selective oxidation of 5-hydroxymethylfurfural with H O catalyzed by a
,
8
5
,
1
2
[
3
3
2
2
molybdenum complex. Green Chem. 2016, 18, 2122–2128. [CrossRef]
1. Lv, G.; Wang, H.; Yang, Y.; Li, X.; Deng, T.; Chen, C.; Zhu, Y.; Hou, X. Aerobic selective oxidation of
-hydroxymethyl-furfural over nitrogen-doped graphene materials with 2,2,6,6-tetramethylpiperidin-oxyl
5
as co-catalyst. Catal. Sci. Tech. 2016, 6, 2377–2386. [CrossRef]
3
3
3
2. Nea ¸t u, F.; Petrea, N.; Petre, R.; Somoghi, V.; Florea, M.; Parvulescu, V.I. Oxidation of 5-hydroxymethyl
furfural to 2,5-diformylfuran in aqueous media over heterogeneous manganese based catalysts. Catal. Today
2
016, 278, 66–73. [CrossRef]
3. Liao, L.; Liu, Y.; Li, Z.; Zhuang, J.; Zhou, Y.; Chen, S. Catalytic aerobic oxidation of 5-hydroxymethylfurfural
into 2,5-diformylfuran over VO2+ and Cu2+ immobilized on amino-functionalized core-shell magnetic
Fe O @SiO . RSC Adv. 2016, 6, 94976–94988. [CrossRef]
3
4
2
4. Baruah, D.; Hussain, F.L.; Suri, M.; Saikia, U.P.; Sengupta, P.; Dutta, D.K.; Konwar, D. Bi(NO3)3 5H O and
·
2
cellulose mediated Cu-NPs—A highly efficient and novel catalytic system for aerobic oxidation of alcohols
to carbonyls and synthesis of DFF from HMF. Catal. Commun. 2016, 77, 9–12. [CrossRef]

Molecules 2017, 22, 329
13 of 14
3
3
3
5. Ghosh, K.; Molla, R.A.; Iqubal, M.A.; Islam, S.S.; Islam, S.M. Ruthenium nanoparticles supported on
N-containing mesoporous polymer catalyzed aerobic oxidation of biomass-derived 5-hydroxymethylfurfural
HMF) to 2,5-diformylfuran (DFF). Appl. Catal. A 2016, 520, 44–52. [CrossRef]
(
6. Wang, F.; Jiang, L.; Wang, J.; Zhang, Z. Catalytic Conversion of Fructose and 5-Hydroxymethylfurfural
into 2,5-Diformylfuran over SBA-15 Supported Ruthenium Catalysts. Energy Fuels 2016, 30, 5885–5892.
[CrossRef]
7. Zhang, W.; Xie, J.; Hou, W.; Liu, Y.; Zhou, Y.; Wang, J. One-Pot Template-Free Synthesis of Cu–MOR
Zeolite toward Efficient Catalyst Support for Aerobic Oxidation of 5-Hydroxymethylfurfural under Ambient
Pressure. ACS Appl. Mater. Interfaces 2016, 8, 23122–23132. [CrossRef] [PubMed]
3
8. Laugel, C.; Estrine, B.; Le Bras, J.; Hoffmann, N.; Marinkovic, S.; Muzart, J. NaBr/DMSO-Induced Synthesis of
2
,5-Diformylfuran from Fructose or 5-(Hydroxymethyl)furfural. ChemCatChem 2014, 6, 1195–1198. [CrossRef]
3
9. Liu, R.; Chen, J.; Chen, L.; Guo, Y.; Zhong, J. One-Step Approach to 2,5-Diformylfuran from Fructose by
Using a Bifunctional and Recyclable Acidic Polyoxometalate Catalyst. ChemPlusChem 2014, 79, 1448–1454.
[CrossRef]
4
0. Liu, Y.; Zhu, L.; Tang, J.; Liu, M.; Cheng, R.; Hu, C. One-pot, One-step Synthesis of 2,5-Diformylfuran from
Carbohydrates over Mo-Containing Keggin Heteropolyacids. ChemSusChem 2014, 7, 3541–3547. [CrossRef]
[PubMed]
4
4
4
1. Xu, F.; Zhang, Z. Polyaniline-Grafted VO(acac) : An Effective Catalyst for the Synthesis of 2,5-Diformylfuran
from 5-Hydroxymethylfurfural and Fructose. ChemCatChem 2015, 7, 1470–1477. [CrossRef]
2. Mittal, N.; Nisola, G.M.; Malihan, L.B.; Seo, J.G.; Lee, S.-P.; Chung, W.-J. Metal-free mild oxidation of
2
5
-hydroxymethylfurfural to 2,5-diformylfuran. Korean J. Chem. Eng. 2014, 31, 1362–1367. [CrossRef]
3. Mittal, N.; Nisola, G.M.; Seo, J.G.; Lee, S.-P.; Chung, W.-J. Organic radical functionalized SBA-15 as a
heterogeneous catalyst for facile oxidation of 5-hydroxymethylfurfural to 2,5-diformylfuran. J. Mol. Catal.
A Chem. 2015, 404–405, 106–114. [CrossRef]
4
4
4
4. Lv, G.; Wang, H.; Yang, Y.; Deng, T.; Chen, C.; Zhu, Y.; Hou, X. Graphene Oxide: A Convenient Metal-Free
Carbocatalyst for Facilitating Aerobic Oxidation of 5-Hydroxymethylfurfural into 2, 5-Diformylfuran.
ACS Catal. 2015, 5, 5636–5646. [CrossRef]
5. Qin, Y.-Z.; Li, Y.-M.; Zong, M.-H.; Wu, H.; Li, N. Enzyme-catalyzed selective oxidation of
5-hydroxymethylfurfural (HMF) and separation of HMF and 2,5-diformylfuran using deep eutectic solvents.
Green Chem. 2015, 17, 3718–3722. [CrossRef]
6. Dutta, S.; Wu, L.; Mascal, M. Production of 5-(chloromethyl)furan-2-carbonyl chloride and
furan-2,5-dicarbonyl chloride from biomass-derived 5-(chloromethyl)furfural (CMF). Green Chem. 2015, 17,
3
737–3739. [CrossRef]
4
4
4
7. Hashemi, M.M.; Beni, Y.A. Copper(I) Chloride/Kieselguhr: A Versatile Catalyst for Oxidation of Alkyl
Halides and Alkyl Tosylates to the Carbonyl Compounds. J. Chem. Res. Synop. 1999, 434–435. [CrossRef]
8. Chandrasekhar, S.; Sridhar, M. A bifunctional approach towards the mild oxidation of organic halides:
2
-Dimethylamino-N,N-dimethylaniline N-oxide. Tetrahedron Lett. 2000, 41, 5423–5425. [CrossRef]
9. Badri, R.; Soleymani, M. Selective Oxidation of Benzylic Substrates to Their Corresponding Carbonyl
Compounds with 3,6-Bis(Triphenylphosphonium)cyclohexene Peroxodisulfate. Synth. Commun. 2003, 33,
1
325–1332. [CrossRef]
5
5
5
0. Das, S.; Panigrahi, A.K.; Maikap, G.C. NaIO –DMF: A novel reagent for the oxidation of organic halides to
carbonyl compounds. Tetrahedron Lett. 2003, 44, 1375–1377. [CrossRef]
1. Hu, Y.L.; Liu, Q.F.; Lu, T.T.; Lu, M. Highly efficient oxidation of organic halides to aldehydes and ketones
4
with H IO in ionic liquid [C mim][FeCl ]. Catal. Commun. 2010, 11, 923–927. [CrossRef]
5
6
12
4
2. Liu, Q.; Lu, M.; Yang, F.; Wei, W.; Sun, F.; Yang, Z.; Huang, S. Aerobic Oxidation of Benzylic Halides
to Carbonyl Compounds with Molecular Oxygen Catalyzed by TEMPO/KNO2 in Aqueous Media.
Synth. Commun. 2010, 40, 1106–1114. [CrossRef]
5
5
3. Khumraksa, B.; Phakhodee, W.; Pattarawarapan, M. Rapid oxidation of organic halides with
N-methylmorpholine N-oxide in an ionic liquid under microwave irradiation. Tetrahedron Lett. 2013
4, 1983–1986. [CrossRef]
,
5
4. Bayat, A.; Shakourian-Fard, M.; Ramezanpour, S.; Hashemi, M.M. A green procedure for direct oxidation of
organic halides to aldehydes and ketones catalyzed by a molybdate-based catalyst. New J. Chem. 2015, 39,
3
845–3851. [CrossRef]

Molecules 2017, 22, 329
14 of 14
5
5. Carniti, P.; Gervasini, A.; Modica, V.H.; Ravasio, N. Catalytic selective reduction of NO with ethylene over a
series of copper catalysts on amorphous silicas. Appl. Catal. B Environ. 2000, 28, 175–185. [CrossRef]
6. Hu, Y.; Zhi, Z.; Zhao, Q.; Wu, C.; Zhao, P.; Jiang, H.; Jiang, T.; Wang, S. 3D cubic mesoporous silica
microsphere as a carrier for poorly soluble drug carvedilol. Microporous Mesoporous Mater. 2012, 147, 94–101.
5
[
CrossRef]
7. Simeonov, S.P.; Coelho, J.A.S.; Afonso, C.A.M. An Integrated Approach for the Production and Isolation of
-Hydroxymethylfurfural from Carbohydrates. ChemSusChem 2012, 5, 1388–1391. [CrossRef] [PubMed]
8. Svilen, P.; Simeonov, J.A.S.C.; Afonso, C.A.M. Synthesis of 5-(Hydroxymethyl)furfural (HMF). Org. Synth.
016, 93, 29–36.
5
5
5
5
2
9. Sanda, K.; Rigal, L.; Gaset, A. Synthèse du 5-bromométhyl-et du 5-chlorométhyl-2-furannecarboxaldéhyde.
Carbohydr. Res. 1989, 187, 15–23. [CrossRef]
Sample Availability: Samples of the compounds HMF, CMF, DFF and OBMF are available from the authors.
©
2017 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
CC BY) license (http://creativecommons.org/licenses/by/4.0/).
(
