New Cyclic Peptide Assemblies with Hydrophobic Cavities: The Structural
and Thermodynamic Basis of a New Class of Peptide Nanotubes
Manuel Amor´ın, Luis Castedo, and Juan R. Granja*
Departamento de Qu´ımica Orga´nica e Unidade Asociada o´ C.S.I.C., Facultade de Qu´ımica,
UniVersidade de Santiago, 15782 Santiago de Compostela, Spain
Received December 7, 2002 ; E-mail: qojuangg@usc.es
In recent years, considerable effort has been devoted to the
synthesis of organic and inorganic nanotubes.1 Self-assembling
peptide nanotubes (SPN) made from cyclic D,L-R-peptides2 or from
cyclic â-peptides3 have structural and functional properties that may
be suitable for various applications in biology and materials
science.1b,4-6 Here we describe a new member of self-assembling
peptides with novel structural and internal cavity, validating the
possibility of expanding the SPN class to other hybrid systems.
The present structures are based on a hybrid of R-γ-cyclic peptides7
subunits and have been characterized by NMR, FT-IR, and X-ray
crystallography.
Cyclic peptides in which (1R,3S)-3-aminocyclohexanecarboxylic
acid (γ-Acc-OH) alternates with a D-R-amino acid, such as 1a, can
adopt a conformation in which the peptide backbone is essentially
flat and the CdO and NsH groups lie roughly perpendicular to
the plane of this cyclic backbone (Figure 1). This flat ring-shaped
conformation may facilitate antiparallel â-sheetlike hydrogen bond-
ing between oppositely oriented rings and the formation of
hydrogen-bonded nanotubes composed of rings of alternating
orientation, in which one face of each ring is hydrogen-bonded via
γ-Acc CdO and NsH groups to the similar face of the neighbor
(Figure 1, frame A), while the other face is hydrogen-bonded via
CdO and NsH groups of the R-amino acid to the similar face of
the other neighbor (Figure 1, frame B). In such structures, the
â-methylene moiety of each cyclohexane is projected into the lumen
of the cylinder, creating a partial hydrophobic cavity.
ically, cyclopeptide 1b, in which the R-amino acids are N-
methylated, was used to prepare dimer 2b, which features A-type
hydrogen-bonding (Figure 1), and cyclopeptide 1c, in which all
γ-Acc are N-methylated (MeN-γ-Acc), was used to prepare staked
dimeric ensemble 2c, which features Figure 1B-type hydrogen
bonding.
The cyclo peptides cyclo-[(1R,3S)-γ-Acc-D-MeNAla]3 (1b, R )
Me) and cyclo-[D-Phe-(1R,3S)-MeN-γ-Acc]3 (1c, R ) Bn) were
synthesized by standard procedures and characterized by NMR and
1
MS. The H NMR spectra of the peptide 1b, in both polar and
nonpolar solvents (CCl4, CDCl3, MeOH, or DMSO), are well
defined, highly symmetrical, and show a JNH,γH coupling constant
of 7.5-8.2 Hz, indications that the peptide exists in an all-trans
conformation with a flat-ring-shaped backbone. In nonpolar sol-
vents, the formation of dimers is reflected by the downfield shift
upon increasing the concentration of the N-H resonance of γ-Acc
from δ 6.6 to 7.8 ppm;9 the corresponding association constant,
determined at 298 K by dilution experiments, is 230 M-1 in CDCl3
and 2.5 × 104 M-1 in 2:3 CDCl3/CCl4. Van’t Hoff plots for the
range 273-313 K afford values of -34.1 KJ mol-1 for ∆H°298
and -69.8 J/K‚mol for ∆S°298 that, like the fall in Ka with increasing
solvent polarity, are consistent with dimerization being essentially
an enthalpy-driven10 hydrogen-bonding process.8a,c The â-sheet
nature of the hydrogen bonding is also supported by the chemical
shift of MeN-Ala CR undergoing a concentration-dependent down-
field shift of > 0.1 ppm11 and by FT-IR spectra recorded in CHCl3,
To establish and evaluate the feasibility and the thermodynamic
properties of such nanotubes, we prepared dimers featuring each
of the two hydrogen-bonding patterns described above, using cyclic
peptides in which hydrogen bond donation from one face of the
ring structure was blocked by N-methylation (Figure 2).8 Specif-
which show amide I and amide IIii bands at 1626 and 1538 cm-1
,
respectively (positions that are typical of â-sheets and similar to
those found for nanotubes and dimers composed of cyclic D,L-
peptides). Hydrogen bonding by N-H is further supported by amide
A bands near 3325 cm-1, while a band that appears at 3400 cm-1
Figure 1. Design for self-assembling peptide nanotubes composed of cyclo-[(1R,3S)-γ-Acc-D-Aa]3 units (for clarity, amino acid side chains have been
omitted in the representation of the nanotube and dimers). The two different H-bonding patterns (A and B) are shown in different colors. Dimers used to
study the basic parameters of the proposed self-assembling nanotube are shown at the right.
9
2844
J. AM. CHEM. SOC. 2003, 125, 2844-2845
10.1021/ja0296273 CCC: $25.00 © 2003 American Chemical Society

C O MMU N I C A T I O N S
to nanotubes with greater selectivity as ion channels, catalysts,
receptors, or molecule containers. Work is in progress to this end.
Acknowledgment. This work was supported by Ministerios de
Educacio´n y Ciencia and Ciencia y Tecnolog´ıa and the Xunta de
Galicia under Projects PB97-0524, SAF2001-3120, and
PGIDT00PXI20912PR, respectively, and through a research grant
to M.A.
Supporting Information Available: Detailed descriptions of the
synthesis and characterization of key compounds and crystal data,
atomic coordinates, bond lengths and angles, and anisotropic displace-
ment coefficients of 1c. This material is available free of charge via
the Internet at http://pubs.acs.org.
Figure 2. Crystal structures of dimeric assemblies 2c with five molecules
of chloroform, one of which occupies the central cavity of the dimer: (left)
top view; (right) side view.
in more dilute (0.5 M) solutions may correspond to the N-H band
References
of the monomer.8e
(1) (a) Patzke, G. R.; Krumeich, F.; Nesper, R. Angew. Chem., Int. Ed. 2002,
41, 2446-2461. (b) Bong, D. T.; Clark, T. D.; Granja, J. R.; Ghadiri, M.
R. Angew. Chem., Int. Ed. 2001, 40, 988-1011. (c) Ajayan, P. M.; Zhou,
O. Z. Top. Appl. Phys. 2001, 80, 391-425.
(2) Ghadiri, M. R.; Granja, J. R.; Milligan, R. A.; McRee, D. E.; Khazanovich,
N. Nature 1993, 366, 324-327. Khazanovich, N.; Granja, J. R.; McRee,
D. E.; Milligan, R. A.; Ghadiri, M. R. J. Am. Chem. Soc. 1994, 116, 6011-
6012. Ghadiri, M. R.; Granja, J. R.; Buehler, L. K. Nature 1994, 369,
301-304. Hartgerink, J. D.; Granja, J. R.; Milligan, R. A.; Ghadiri, M.
R. J. Am. Chem. Soc. 1996, 118, 43-50.
1
A flat, all-trans conformation is also indicated by the H NMR
spectra of 1c in polar and nonpolar solvents (JNH-RH ) 9.0-9.5
Hz). However, the chemical shift of Phe NH in nonpolar solvents
is a constant 8.7 ppm at concentrations down to 2 × 10-4 M and
with heating or addition of up to 20% of methanol, showing that if
dimers are formed the association constant for dimerization must
be at least 105 M-1 (larger than for any peptide nanotube reported
hitherto). Solution (CHCl3) FT-IR studies showed the characteristic
features of â-sheet structure of peptide nanotubes and dimers: amide
(3) Seebach, D.; Matthews, J. L.; Meden, A.; Wessels, T.; Baerlocher, C.;
McCusker, L. B. HelV. Chim. Acta 1997, 80, 173-182. Clark, T. D.;
Buehler, L. K.; Ghadiri, M. R. J. Am. Chem. Soc. 1998, 120, 651-656.
(4) Steinem, C.; Janshoff, A.; Vollmer, M. S.; Ghadiri, M. R. Langmuir 1999,
15, 3956-3964. Ferna´ndez-Lo´pez, S.; Kim, H.-S.; Choi, E. C.; Delgado,
M.; Granja, J. R.; Khasanov, A.; Kraehenbuehl, K.; Long, G.; Weinberger,
D. A.; Wilcoxen, K.; Ghadiri, M. R. Nature 2001, 412, 452-455.
(5) For a recent example of nanotubes made of δ-amino acids, see: Gauthier,
D.; Baillargeon, P.; Drouin, M.; Dory, Y. L. Angew. Chem., Int. Ed. 2001,
40, 4635-4638.
I (1625 cm-1), amide IIii (1523 cm-1), and amide A (3309 cm-1
)
bands. Dimer formation was also supported by FAB-MS, showing
a signal arising from single charged species corresponding to proton
dimer 2c (1718).
Colorless prismatic crystals suitable for X-ray were obtained from
the solutions of peptide 1c in chloroform by vapor-phase equilibra-
tion with hexane. The crystal structure characterized by X-ray
crystallography shows an unsymmetrical dimeric ensemble that
corroborates the nanotube structure. The two peptide subunits are
closely stacked in an antiparallel orientation with the â-sheetlike
cyclindical ensemble stabilized by six intersubunit hydrogen-
bonding interactions with an intersubunit N-O distance ranging
between 2.78 and 2.94 Å and distorted by the presence of five
chloroform molecules hydrogen-bonded to the peptide backbone.
The cyclindical dimer has an approximate van der Waals internal
diameter of 5.4 Å and a volume of 165 Å3, which is filled with
one molecule of chloroform, showing the partial hydrophobic
character of the inner face of the nanotube which is distinct from
previously reported hydrophilic nanotubes.2,8,12
In conclusion, NMR, FT-IR, MS, and X-ray diffraction data show
conclusively that the cyclic peptides 1b and 1c form dimers in which
antiparallel peptide rings are linked by a â-sheetlike set of six
hydrogen bonds. These dimers (one of which, 2c, is extremely stable
in nonpolar solvents) may be considered as essentially the basic
units of a new class of peptide nanotubes, in which the inner-cavity
properties are due in part to the cyclohexane C2. Cyclic peptides
containing C2-modified γ-Acc should endow SPN with a func-
tionalized inner surface, something that is precluded in the R- or
â-nanotubes because all amino acid side chains lie on the exterior
of the ensemble and additional modification in CR or Câ would
disrupt the assembling.2 Appropriate functionalization should lead
(6) For a recent review on supramolecular chemistry and self-assembly, see:
Science 2002, 295, 2395-2421 (special issue).
(7) For some studies with peptides made of alternating R-amino acid and
3-aminobenzoic acid derivatives, see: (a) as cation receptors, Kubik, S.;
Goddard, R. J. Org. Chem. 1999, 64, 9475-9486. Kubik, S. J. Am. Chem.
Soc. 1999, 121, 5846-5855. Pohl, S.; Goddard, R. Kubik, S. Tetrahedron
Lett. 2001, 42, 7555-7558. (b) As ion channels: Ishida, H.; Qi, Z.;
Sokabe, M.; Donowaki, K.; Inoue, Y. J. Org. Chem. 2001, 66, 2978-
2989.
(8) (a) Ghadiri, M. R.; Kobayashi, K.; Granja, J. R.; Chadha, R. K.; McRee,
D. E. Angew. Chem., Int. Ed. Engl. 1995, 34, 93-95. (b) Kobayashi, K.;
Granja, J. R.; Ghadiri, M. R. Angew. Chem., Int. Ed. Engl. 1995, 34, 95-
98. (c) Clark, T. D.; Buriak, J. M.; Kobayashi, K.; Isler, M. P.; McRee,
D. E.; Ghadiri, M. R. J. Am. Chem. Soc. 1998, 120, 8949-8962. (d) Bong,
D. T.; Ghadiri, M. R. Angew. Chem., Int. Ed. 2001, 40, 2163-2166. (e)
Saviano, M.; Zaccaro, L.; Lombardi, A.; Pedone, C.; Di Blasio, B.; Sun,
X.; Lorenzi, G. P. J. Incl. Phenom. 1994, 18, 27-36. (f) Sun, X.; Lorenzi,
G. P. HelV. Chim. Acta 1994, 77, 1520-1526.
(9) Slow monomer-dimer equilibration was observed in NMR spectra of 1b
(0.5 mM in CH2Cl2) obtained at 189 K, which showed NH signals for
1
both the dimer (at 7.84 ppm) and the monomer (at 6.54 ppm), H NMR
spectrum is available in the Supporting Information.
(10) (a) Searle, M. S.; Westwell, M. S.; Williams, D. H. J. Chem. Soc., Perkin
Trans. 2 1995, 141-151. (b) Dunitz, J. D. Chem. Biol. 1995, 2, 709-
712.
(11) Downfield shifts of CRH signals with respect to random coil values are
reliable indicators of â-sheet structure (for recent examples concerning â
hairpin models in aqueous solution, see: (a) Maynard, A. J.; Sharman,
G. J.; Searle, M. S. J. Am. Chem. Soc. 1998, 120, 1996-2007. (b) Haque,
T. S.; Gellman, S. H. J. Am. Chem. Soc. 1997, 119, 2303-2304; also ref
8c. The 1H NMR spectrum of 1b recorded in CH2Cl2 at 189 K, showing
the CRH signals of both the monomer and the dimer (at 4.85 and 5.36
ppm, respectively), is available in the Supporting Information, as are room-
temperature spectra showing the CRH signal shifting with increasing
concentration.
(12) Engels, M.; Bashford, D.; Ghadiri, M. R. J. Am. Chem. Soc. 1995, 117,
9151-9158.
JA0296273
9
J. AM. CHEM. SOC. VOL. 125, NO. 10, 2003 2845
