Fluorescent Ethenyl- and Ethynyl-dimesitylboranes Derived
from 5-(Dimethylamino)-N-(prop-2-ynyl)naphthalene-
1-sulfonamide
Wai-Yeung Wong,A,B Suk-Yue Poon,A Mei-Fang Lin,A and Wai-Kwok WongA
ADepartment of Chemistry and Centre for Advanced Luminescence Materials, Hong Kong
Baptist University, Waterloo Road, Kowloon Tong, Hong Kong, ROC.
BCorresponding author. Email: rwywong@hkbu.edu.hk
Two new fluorescent ethenyl- and ethynyl-dimesitylboranes functionalized with a dansyl group 1 and 2 have been synthe-
sized in good yields. Compound 1 was prepared by the hydroboration of 5-(dimethylamino)-N-(prop-2-ynyl)naphthalene-
1-sulfonamide I with dimesitylborane (HB(Mes)2) in dry tetrahydrofuran at room temperature, and compound 2 was
synthesized by Pd-catalyzed cross-coupling of I with 4-I-C6H4B(Mes)2. Both organoborane compounds 1 and 2 have
been characterized by infrared spectroscopy, NMR spectroscopy, and mass spectrometry.The molecular structures of I and
1 were confirmed by X-ray crystallography. The electronic absorption and redox properties of 1 and 2 were investigated.
They both exhibit large positive solvatochromism and their emission spectra have been recorded in a range of organic
solvents with the fluorescence maxima exhibiting large bathochromic shifts in highly polar solvents, indicative of charge
transfer which leads to large dipole moments in the excited state. The application of 1 as a blue fluorescent dopant in
doped guest–host organic light-emitting diodes is also described.
Manuscript received: 16 July 2007.
Final version: Accepted without change.
Introduction
particularly effective, as steric congestion around boron results
in the formation of propeller-like structures where the ortho-
substituents on the aryl ligands form a cage around the vacant
pz orbital.
The current search for new luminescent materials is a result
in part of their potential for use in electroluminescent (EL)
displays.[1] In recent years, there has been considerable interest
in both academia and industry in developing blue organic light-
emitting devices (OLEDs), and the realisation of blue electro-
luminescence is an important step for possible application of
these materials in flat-panel full-colour displays.[2] It is well
known that the EL efficiency, colour, and operational stability
of blue OLEDs can be significantly improved with the use of
a guest–host doped emitter.[3] There have been several recent
developments in blue-doped emitter systems, including the uti-
lization of 2-methyl-9,10-di(2-napthyl)anthracene (MADN) as
a blue host.[4]
Electronic and electro-optical materials that contain electron-
rich organic molecules have attracted much attention.[5] New
routes to electron-deficient systems have also been devel-
oped, taking advantage of the fact that three-coordinate boron
is isoelectronic and isostructural with a carbocation.[6] These
organoboroncompoundshaveinterestingoptical, electronic, and
structural properties with a wide range of applications,[6] includ-
ing fluoride ion sensors,[7] non-linear optical materials,[8] and
both single and two-photon fluorescence.[9] They can also serve
as emissive and/or electron-transport layers in OLEDs.[10] As
with many other low-coordinate systems, a common strategy in
the synthesis of three-coordinate boranes is to provide kinetic
stability by blocking the approach of nucleophiles with ster-
ically demanding substituents while maintaining conjugation
with other unsaturated hydrocarbon substituents.[6,10] Bulky aryl
moieties such as the mesityl (2,4,6-trimethylphenyl) group are
Many endeavours have been made to employ fluorescent
labels such as anthracene,[8b,9c,11] acridone,[12] and fluorene[13]
for the design of various novel optoelectronic materials.
However, the 5-(dimethylamino)naphthalene-1-sulfonyl (dan-
syl) chromophore has been less explored.[14] In view of the high
luminescence quantum yield and high photochemical resistance
to bleaching of the auxiliary dansyl unit,[14] we expect that a
properly derivatized molecule, such as 5-(dimethylamino)-N-
(prop-2-ynyl)naphthalene-1-sulfonamide I could be employed
to attach a fluorescent label to the B(Mes)2 moiety through an
acetylide linkage, which is likely to exhibit rich photophysical
and optoelectronic properties. In the present article, we describe
the synthesis, spectroscopic, structural, and photophysical prop-
erties of two new fluorescent compounds that incorporate the
dansyl and dimesitylborane moieties. Preliminary studies of
such compounds as dopants in a guest–host blue-doped emitter
system will be discussed.
Results and Discussion
Synthesis and Characterization
Scheme 1 summarizes the reaction pathways to all the com-
pounds in this study. Ligand I was prepared by reacting
dansyl chloride and propargylamine in a NEt3/CH2Cl2 sol-
vent mixture according to the literature method.[14a] The
terminal acetylene was hydroborated using HB(Mes)2 in
THF to obtain the trans-ethenyldimesitylborane 1 in 60%
© CSIRO 2007
10.1071/CH07242
0004-9425/07/120915

916
W.-Y. Wong et al.
H3C
H3C
CH3
CH3
N
N
Et3N
ϩ
H
CH2NH2
O
S
O
O
S
O
HN
Cl
H
Dansyl chloride
Propargylamine
HB(Mes)2
I
Me
Me
Me
B(Mes)2
N
N
N
THF
O
O
ϩ
Me
N
H
S
N
H
S
O
O
1 (60%)
B(Mes)2
Me
Me
O
S
Pd(PPh3)2Cl2
CuI, Et3N
Me
Me
B(Mes)2
ϩ
I
N
H
N
O
O
N
H
S
O
2 (46%)
Scheme 1. Synthetic routes to compounds I, 1, and 2.
yield.[15] (p-Iodophenyl)dimesitylborane, prepared by reacting
1,4-diiodobenzene with BunLi followed by reaction with dime-
sitylboron fluoride, was used in a Pd-catalyzed cross-coupling
reaction with I to yield the dimesitylborylalkynyl compound
2 in moderate yield (46%).[16] Compound 1 was purified by
repeated recrystallization and compound 2 was purified by
preparative TLC on silica plates followed by recrystalliza-
tion. Both mesitylboranes are organic soluble and have been
fully characterized by NMR and infrared (IR) spectroscopies
and matrix-assisted laser desorption–ionization time-of-flight
(MALDI-TOF) high-resolution mass spectrometry (MS). Com-
pounds 1 and 2 are thermally stable solids with onset decom-
position temperatures of 296 and 328◦C, respectively, as shown
by thermogravimetric analysis (TGA).The crystalline borane, 1,
did not exhibit a discernable glass transition. When 2 was heated,
an endotherm as a result of melting was observed at 181◦C, and
upon cooling and re-heating, a glass transition was observed
at 72◦C.
structurally similar molecules in the unit cell. The propynyl
group is attached to N(2) by a CH2 bridge in I and has a typ-
ical C≡C bond length of 1.163(5) Å. The B–C bond lengths
of 1 are 1.573(5) and 1.574(5) Å for the B–mesityl bonds and
1.577(5) Å for the boron–vinyl bond.
Photophysical and Redox Properties
The photophysical properties of boranes 1 and 2 have been
studied in toluene at room temperature and the results are
summarized in Table 2. Both 1 and 2 show similar struc-
tured absorption bands (∼322–324 nm).The absorption maxima
exhibit negligible bathochromic solvatochromic shifts in sol-
vents of increasing polarity, which is consistent with very small
ground-state dipole moments. Fluorescence occurs in the blue
region for compounds 1 and 2. Excitation of 1 and 2 in toluene
solutions gave strong emission peaks located at 477 and 487 nm,
respectively. The emission wavelengths of 1 and 2 are slightly
red-shifted with respect to that of I (454 nm in toluene). These
featureless luminescence spectra are independent of the excita-
tion wavelength used. Because of their similar emission pattern,
it is considered that the emission features in I and the dansy-
lated boranes should have the same origin. In contrast to their
absorption behaviour, 1 and 2 exhibit pronounced positive sol-
vatochromism in their fluorescence spectra (Table 3), which can
be attributed to highly polarized excited states. In other words,
their emission spectra shift towards longer wavelengths with
increasing polarity of the solvents. Solvent-dependent emission
in solution has been frequently observed for three-coordinate
organoboron compounds.[15] As shown in Fig. 2, the shift of the
emission maximum with solvents is dramatic in each case. For
example, in the non-polar solvent, hexane, the emission maxima
of 1 and 2 are located at 448 and 450 nm, while in dimethyl sul-
foxide (DMSO), the emission maxima appear at 515 and 516 nm,
respectively (Table 3). The fluorescence lifetimes of 1 and 2 are
14 and 12 ns, respectively.
Spectroscopic data (IR, 1H and 13C NMR, and MS) for these
newfluorophore-anchoredmesitylboranesareinagreementwith
their formulation. The disappearance of the IR ν(C≡C) and
ν(≡C–H) bands in 1 confirms that hydroboration of the alkyne
unit occurred to give a vinyl boron compound. The IR spectrum
of 2 displays a strong ν(C≡C) absorption band at 2238 cm−1
,
but absorption as a result of the terminal acetylenic C–H group
1
of the ligand is absent. The H NMR spectra of the new com-
pounds show resonances that stem from the coordinated dansyl
group, but the signals attributable to −C≡CH for I (∼1.92 ppm)
are not observed. The 13C NMR spectroscopic data also give
precise information about the structure of the compounds. In
each case, the carbon resonances of the mesityl methyl group
are clearly identified at ∼21 and 23 ppm for both compounds.
Notably, there are two distinct 13C NMR signals for the indi-
vidual sp carbons in 2, in accordance with the formulation. The
MALDI-TOF MS and elemental analytical data further support
the formulation of these compounds. For 1 and 2, molecular ion
peaks are observed at m/z 537 and 611 amu, respectively.
Single-crystal X-ray diffraction studies for I and 1 confirm
their structures (Fig. 1). Important bond parameters are listed
in Table 1. For both I and 1, there are two independent but
The electrochemical properties of 1 and 2 were inves-
tigated by cyclic voltammetry in THF. The potentials were
measured against Ag/AgCl as the reference electrode and each
measurement was calibrated with the ferrocene/ferrocenium
(Fc/Fc+) redox system as an internal standard. The reduction
