HPLC Analysis of Aliphatic Sulfonate Surfactants using Ion-
Pair Detection
Marek Zahrobsky, Davide Camporese, Øystein Rist and Per H.J. Carlsen *
Department of Chemistry, Norwegian University of Science and Technology, N-7491 Trondheim,
Norway. Tel. +47 73 59 3968, Fax +47 73 593985.
* Author to whom correspondence should be addressed. E-mail: per.carlsen@chem.ntnu.no
Received: 10 November 2004; in revised form: 29 August 2005 / Accepted: 30 August 2005 /
Published: 30 September 2005
Abstract. A method was developed for the analysis of a number of surfactants which
contained no UV-chromophores, using RP-HPLC with Indirect Photometric Detection,
IPD. Pyridinium salts such as N-methylpyridinium iodide, N-methyl-2,2'-dipyridinium
iodide and N,N'-dimethyl-2,2'-dipyridinium diiodide, were used as the visualization
reagents, forming ion-pair complexes with the sulfonate surfactants. This allowed
ordinary UV-detection. N-methylpyridinium iodide proved to be a suitable reagent, both
with respect to ease of preparation and response. The eluents consisted of mixtures of
acetonitrile and water, being 0.1 - 0.25 mM with respect to pyridinium salt. The method
was sensitive and exhibited good signal to noise ratios, as well as linear responses over a
wide concentration range. All of the analyzed surfactants were separated, including the
diastereomeric forms of some of the surfactants.
Keywords. Surfactant / Analysis / Ion-pair detection / HPLC
Introduction
Many modern surfactants are combinations of alkyl chains and a variety of polyether segments,
such as ethyleneoxy units (EO-units). In studies related to Enhanced Oil Recovery, EOR, and the
analysis of the composition of surfactants used for that purpose, our group has been involved with the
synthesis of a variety of such surfactants. We have conducted selective synthesis of a number of
hydroxysulfonate- and new bis sulfonate surfactants [1].The selectivity was an important aspect with

Molecules 2005, 10
1180
respect to Structure Activity Relationship studies. For that reason, the polar sulfonate groups were
introduced late in the preparations, allowing easy analysis of the intermediates by, e.g., GC analysis.
We needed, however, also chromatographic methods to analyze the final sulfonate products for purity.
We were preferably seeking direct methods that need no derivatization, to avoid the possibility of side
reactions or discrimination. The surfactants we have studied were of the general types 1 and 2, shown
in Figure 1.
Figure 1
O
n
SO3Na
O
O
1
O H
m
O
O
O
O
O
O
SO3Na
SO3Na
m
m
2
n
Results and Discussion
The sulfonate salts have for all practical purposes, no vapor pressure, and must therefore be
derivatized prior to GC analysis. The use of several different sulfonate derivatives have been
reported, e.g., as the corresponding sulfonyl chlorides [2] by reactions with SOCl2 [3] or PCl5 [4, 5].
Silyl ester formation has also been investigated [6,7]. On-line GC-esterification of sulfonates by co-
injection of a tetrabutylammonium salt has also been described [8]. When thionyl chloride was used
in combination with DMF, enhanced performance was observed due to formation of Vilsmeier-type
salts, and formation of the alkyl chlorides [9, 2]. We have investigated the use of these methods on
the surfactants studied in this work. The results, however, were not satisfactory as incomplete
conversion was often observed together with various side reactions.
HPLC analysis
Ionic surfactants are generally analyzed by reverse-phase high performance liquid
chromatography, RP-HPLC, which utilizes a non-polar stationary phase and a polar mobile phase. The
stationary phase is derivatized with alkyl groups, usually C8- or C18-groups. Such systems were also
applied for the surfactants in our study. HPLC analysis may, however, have limitations in detecting
compounds which are transparent to the detection method used. For HPLC work UV-detection is often
the method of choice [10]. The challenge in this case, however, was the detection of the compounds of
interest since these surfactants contained no chromophores.
Bulk-property detectors, which measure differences in physical properties of the mobile phase with
or without the solute, such as the refractive index (RI) detectors and conductivity detectors [11,12,13],

Molecules 2005, 10
1181
are universal. They usually respond to all compounds, but generally suffer from poor sensitivity and
limited dynamic ranges (10 ng -1 µg), and are affected by changes in the mobile phase composition
and temperature. The detector responses are not always linear with respect to concentration and not
compatible with solvent gradient HPLC methods. The application of refractive index and conductivity
detection was investigated, but exhibited unacceptable noise levels and poor sensitivity and the results
were not reproducible. For these reasons derivatization, conductivity- and RI detection was ruled out.
Solute property detectors on the other hand respond to a physical or chemical property of the
solute, and are ideally independent of the mobile phase. Examples are spectrophotometry, fluorescence
and electrochemical detectors. Even though mobile phase independence is not always fulfilled in
practice, high sensitivity with a wide linear response range (10 pg - 1 ng) can usually be achieved. A
disadvantage with HPLC methods is that all impurities will not necessarily be detected and they should
therefore be used in combination with other methods, e.g., GC and spectroscopic methods.
Surfactants
In this study we were using the surfactants shown in Figure 2 as a test set. They were either single
chain hydroxy-sulfonates, 1a-e or bisdisulfonate surfactants, 2a-b.
Figure 2
O
O
SO3Na
SO3Na
OH
1a
O
SO3Na
O
OH
1b
O
O
O
OH
1c
1e
O
SO3Na
O
1d
OH
O
O
SO3Na
O
OH
O
O
O
O
SO3Na
O
O
O
SO3Na
SO3Na
2a
SO3Na
2b
Indirect Photometric Detection, IPD
For the detection of surfactants 1a-e and 2a-b methods other than direct detection must be used.
An alternative UV-detection method is indirect photometric detection, IPD. When a solute gives an
insufficient detector response, adding an auxiliary to the mobile phase can enhance sensitivity. The
auxiliary can be a UV-absorbing salt, and may work by two different mechanisms; either formation of
ion-pairs with the ionic surfactants, resulting in positive signals, or negative signals due to local

Molecules 2005, 10
1182
depletion of the amount of the UV-active salts required for maintaining electroneutrality. This method
has all the advantages of UV-detection and avoids derivatization. Common visualization reagents
described in the literature are methylene blue [14], naphthalene sulfonate or disulfonates [15,16],
copper, cerium or silver salts [17] and N-alkyl pyridinium salts [18,19]. The pyridinium salts reported
in the literature were N-methylpyridinium chloride, N-butylpyridinium bromide, N-octylpyridinium
bromide, N-dodecylpyridinium bromide, and N-cetylpyridinium bromide. One of the studies concluded
that the alkyl moiety should preferably consist of a methyl group [18] as use of longer alkyl groups
resulted in variations of the retention time of a system peak as a function of eluent composition.
Although IPD-based RP-HPLC methods are reported to be efficient, they have some limitations, e.g.,
neutral impurities in most cases remain undetected.
A pyridinium salt frequently used for this application is N-methylpyridinium chloride. In the
development of a HPLC method, detection of 1a-e and 2a-b was studied using a variety of pyridinium
iodides, 3- 5, Figure 3. They were readily obtained by the reaction of the corresponding pyridines with
methyl iodide in dichloromethane.
Figure 3
CH3
N
CH3
N
CH3
N
CH3
N
I
I
I
N
I
MDPI, 4
MPI, 3
DMDPI, 5
In this study C -18 reverse phase columns were preferably used. Mixtures of water and acetonitrile
were used as eluents. The concentration of the visualization reagent was in the range 0.10-0.25 mM.
The salts shown in Figure 3 were tested as visualization agents. The injected sample volume was
10.0 µL of samples that consisted of surfactants dissolved in the eluent in the concentration range 0.05
- 1.0 mg/mL. Wavelengths between 258 and 300 nm was used for UV-detection depending on the ion-
pair reagent used.
It should be noted that HPLC using the ion-pair IPD-method of detection exhibits a characteristic
behavior. Thus, in reverse phase HPLC-experiments early in the run, a positive peak will be observed,
with the same retention time as the ion-pair reagent (here ca. 2 min) which may be induced by
equilibration of the local eluent composition upon injecting the sample [20]. Later in the
chromatogram a large, broad, negative peak is observed, referred to as the system peak. The area of the
system peak is basically equal to the collected area of the peaks of the sample, and is caused by
depletion of the UV-active reagent from the mobile phase, when the sample is injected. These two
peaks will always appear in the IPD chromatograms.
N-Methylpyridinium iodide (MPI, 3).
Use of MPI, 3, as the ion-pair reagent (0.25 mM) and a 30:70 water-acetonitrile eluent solution,
gave good separation and peak intensity. The capacity was investigated and the capacity factor, k', was
calculated for surfactants 1a, 1c, 2a, and 2b [21]. The k'- value indicates to what extend a solute is
retained on the column, and is a function of the composition of the eluent. The capacity factor as a
function of eluent composition is illustrated in Figure 4.

Molecules 2005, 10
1183
Figure 4
Increasing the amount of acetonitrile in the eluent (from 25 to 40 %) resulted in shorter retention
times for all the surfactants. However, for the bis surfactants, 2a-2b, the retention time decreased more
readily, and therefore also the k' values. When the acetonitrile concentration approached 25 %, the
retention times exceeded 1 hour, resulting in peak broadening. This effect can be rationalized by the
higher lipophilicity of bis surfactant ion-pair complexes. Thus, the two tails influenced the hydrophile-
lipophile balance, HLB, more than the presence of the two ionic head groups. Mixtures of surfactants
1a-e and 2a-b were readily separated into the corresponding components, Figure 5.
Figure 5
Changing concentrations of MPI, 3, in the range 0.10 - 0.30 mM appeared to have no significant
influence on the retention times. The start of the system peak is observed in the chromatogram in
Figure 5, starting at approximately 24 min. Table 1 shows the results and the assignment of the peaks,
which was also confirmed by analysis of the authentic compounds. We note that compounds 1b, 1d, 1e
and 2a each gave rise to two peaks. These compounds all contain two stereogenic carbon atoms, giving
rise to two sets of diastereomers, each of which gave separated peaks in the chromatogram.

Molecules 2005, 10
Table 1. Retention times for surfactants 1a-e and 2a-b, using a 30:70 water-acetonitrile
1184
mixture as eluent and MPI, 3, as the ion-pair auxiliary. Detection at
λ = 258 nm.
Surfactant
Retention times [minutes]
1a
1b
1c
1d
1e
2a
2b
5.2
6.4
7.1
7.3 / 8.7 *
10.8 / 12.0 *
18.9 / 21.3 *
16.7
* Two signals appeared due to the presence of diastereomers.
Increased lipophilicity of a compound with a reversed-phase stationary phase usually increased the
retention time. Results from the 1a-e series of surfactants showed that introduction of a PO-unit
influenced the retention time more than the introduction of an EO-unit. Contributing to this, is the fact
that branching of the tail usually give a more lipophilic compound compared to the unbranched
compound with the same number of carbon atoms. The semi-polar side-chain in addition contained an
extra methyl group. Important for quantitative measurements, the detector response was found to be
linear with respect to the amount of compound injected, over a range covering approximately one
order of magnitude. This is illustrated in Figure 6 for surfactants 1a, 1c, 2a, 2b.
Figure 6
The eluent consisted here of a 35:65 mixture of acetonitrile-water. Quantitative analysis using
vanillin as an internal standard (retention times 4.52 minutes) with different molar ratios of the
surfactants and vanillin keeping a constant concentration of vanillin also gave a linear relationship
between the responses and the molar ratio. This confirms the methods application for quantitative
analysis.

Molecules 2005, 10
1185
N-Methyl-2,2'-bipyridinium iodide (MDPI, 4).
Similar studies were done with MDPI, 4, using a 30:70 water-acetonitrile solvent system.
Retention times were slightly longer, but the system peak came earlier (after 20 min). The variations
were ascribed to differences in the structures of the ion-pairs and equilibrium constants. For this
system, the system peak coincided with the signals for surfactants, 2a and 2b.
Table 2. Retention times of the different surfactants using MDPI, 4.
Surfactant
Retention times [min]
1a
1b
1c
1d
1e
2a
2b
7.1
8.9
10.2
11.2 / 12.7 *
15.6 / 17.1 *
**
**
* Two signals due to the presence of diastereomers.
** No signals were detected due to concealment by the system peak.
This illustrates one of the characteristic problems often encountered when using the IPD-method.
For this reason, with this IPM-system, we could not analyze for compounds 2. However, at the same
time it illustrates that changing the properties of the visualization reagents represented an additional
parameter in creating methods suitable for specific purposes. Table 2 shows the observed data for this
system. The MDPI system also exhibited strict linearity of detector response versus the amounts of
surfactant injected on the column.
The response curves, e.g., as in Figure 6, exhibited different slopes for the different surfactants. For
the same surfactant, but with different ion-pair salts, slopes were also different. Thus, surfactant 2b
with MPI showed a larger response than did 2a, while the opposite was the case when using MDPI as
the ion-pair salt. These effects can be ascribed to the differences in stability of the surfactant-
pyridinium complexes:
[Surfactant -]aq + [MP+]aq
[Surfactant - MP+]aq
i.e., the equilibrium for the complex formation is sensitive to structural factors. Thus, it appears that
the equilibrium lies further to the right for 2b than for 2a with MPI as the ion-pair salt, while the
opposite is the case using MDPI.
N,N'-Dimethyl-2,2-bipyridinium diiodide (DMDPI, 5).
Similar experiments were carried out with the surfactants but using DMDPI, 5. This reagent
exhibited higher background absorption. This was compensated for, by changing the detector

Molecules 2005, 10
1186
wavelength from 258 nm to 290 nm, and the concentration of the visualization reagent was reduced to
0.15 mM. The ion-pair complexes appeared to be rather lipophilic. Without changing the mobile
phase, retention-times therefore became very long, resulting in broader peaks. Increasing the amount
of acetonitrile to a 50:50 acetonitrile-water solution compensated for this. Otherwise, the detection and
response of the surfactants was as for the previous examples. However, since DMDPI, 5, did not
display any significant advantages over the MPI-system, further work on this system will not be
described.
Structure of the surfactant-ion pair complexes.
Because different types of ion-pair complexes appeared to have different HPLC-characteristics,
and therefore depended on the pyridinium salt employed, we studied the effect of the charge ratios in
the ion-pair complexes. The mono-sulfonate surfactants 1 with a mono-cationic salt, for example MPI,
3, presumably formed what was basically a 1:1 ion-pair complex. The disulfonates 2, on the other
hand, may form either a 1:1 complex with one negative charge, or a 1:2 complex with MPI, 3,. The
latter may not be so readily formed, due to kinetic, entropy or steric effects. If the visualization reagent
was doubly positive charges, for example DMDPI, 5, neutral 1:1 complexes with 2 can be envisioned.
The nature of the ion-pair complexes was studied in parallel experiments with the single-chain
surfactant, 1a, and the bis surfactant, 2b. Thus, equal amounts (10.0 µL of solutions being 0.0232 mM
in 1a and 2b) were injected on the column, both in separate experiments and as mixtures. As mobile
phase was used a 40:60 acetonitrile-water solution being 0.15 mM in MPI, 3, and the detector set at
258 nm. Virtually equal responses were obtained for the two surfactants, Table 3. Assuming that the
single-chained surfactant 1a with MPI formed a 1:1 ion-pair, the bis surfactant 2b, must similarly form
a 1:1 ion-pair.
For the subsequent experiments with DMDPI, 5, the detector wavelengths were adjusted so that, at
the concentrations chosen for the pyridinium salts 3 and 5 (0.15 mM), similar absorbance values were
obtained for the two mobile phases (it happened to be A = 1.40). Thus, the detector wavelength was
chosen as 258 and 280 nm, respectively. The signals of similar molar ion-pair composition for the MPI
and DMDPI systems, respectively, should result in equal detector responses. Thus, with the molar
concentrations of the surfactants being the same (for both was applied 10.0 µL of 0.0232 mM stock
solutions), any 1:1-complex should always give the same integrated peak area, independent on the
actual identity components in the complexes. E.g., the peak area measured for a 1:1 1a-MPI complex
should be equal to that of a 1:1 ratio in the 2b-DMDPI complex.
Table 3. Comparison of peak areas of single- and double-chain surfactants.
Measured Relative Peak Area Values
Surfactant
MPI-system, 3.
(258 nm)
10.20
DMDPI-system, 5.
(280 nm)
5.58
Single-chain, 1a
Double-chain, 2b
10.00
5.50

Molecules 2005, 10
1187
The results for DMDPI, 5, showed that the peak areas were similar for the single- and double-chain
surfactants, indicating similar compositions of the ion-pairs. However, with the DMDPI salt, the peak
area of both surfactant 1a and 2b was essentially half of that observed in the corresponding MPI
experiments, even though all concentrations were equal, Table 3. This indicates a 2:1 relationship, with
two surfactant molecules associated with one molecule of DMDPI, 5. These results indicate the ion-
pair compositions illustrated in Figure 7.
Figure 7
CH3
+
CH3
+
SO3-
-O3S
SO3-
N
N
CH3
+
CH3
+
SO3-
-O3S
SO3-
N
N
SO3-
N
+
N
+
-O3S
SO3-
CH3
CH3
Conclusions
A method was developed for the analysis of a number of surfactants using RP-HPLC with Indirect
Photometric Detection (IPD), using pyridinium salts as the visualization reagents. These formed ion-
pair complexes with the sulfonate surfactants, allowing detection by an ordinary UV-detector.
N-methylpyridinium iodide, MPI, proved to be the reagent of choice, both with respect to its ease of
preparation and its excellent response factor. The eluents consisted of mixtures of acetonitrile and
water, 0.1 - 0.25 mM in MPI. The method was highly sensitive with good signal to noise ratios, as well
as linear responses over a wide concentration range. All of the analyzed surfactants could be separated,
including the diastereomeric forms of some of the surfactants.
Acknowledgements
The authors wish to express their gratitude to STATOIL and the Norwegian Research Council for
financial support.
Experimental
General
NMR spectra were recorded on a JEOL JNM-EX 400 FT NMR System instrument. HPLC analysis
was performed on a Perkin-Elmer instrument consisting of a LC 250 binary pump, LC-600
autosampler equipped with a 10 µL sample loop, LC 30 refractive index detector and a LC 290 BIO
UV variable wavelength absorbance detector (190 - 360 nm). A conductivity detector (Conductivity

Molecules 2005, 10
1188
Monitor, Pharmacia) was also used. As integrator a PE-Nelson Model 1020 instrument was used. The
columns used were ChromSphere C18 or C8, 4.6 x 250 mm, from Chrompack. All solvents were of
HPLC-grade.
N-methylpyridinium iodide (3) was prepared by the reaction of pyridine with methyl iodide at room
temperature in dichloromethane. After recrystallization from ethanol the product was obtained in 71 %
yield; 1H-NMR (D2O): δ 8.8 (m, 2H), 8.5 (m, 1H), 8.0 (m, 2H), 4.4(s, 3H) ppm; UV (H2O): λ 226 (ε
11700), 257 (ε 4180) nm.
N-methyl-2,2'-bipyridinium iodide (4) was prepared in 77% yield from 2,2'-dipyridine (8 g) and methyl
iodide (10 g) in dichloromethane (30 mL) at room temperature, followed by recrystallization from
1
ethanol; H-NMR (D2O): δ 8.9 (m, 1H), 8.7 (m, 1H), 8,6 (m, 1H), 8.1 (m, 3H), 7.8 (m, 1H), 7.7 (m,
1H), 4.2 (s, 3H) ppm; UV (H2O): λ 225 (ε 17500), 272 (ε 9900) nm.
N,N'-dimethyl-2,2’-dipyridyl diiodide (5) was prepared in 69% yield from 2,2'-dipyridine (8 g) and
methyl iodide (25 g) in refluxing dichloromethane (40 mL) and subsequent recrystallization from
ethanol; 1H-NMR (D2O): δ 8.9 (m, 2H), 8.7 (m, 2H), 8.6 (m, 2H), 4.3(s, 6H) ppm; UV (H2O): λ 225
(ε 29000), 265 (ε 11100) nm.
References and Notes
1. Rist, Ø.; Carlsen, P. H. J. Molecules 2005, 10, 1169.
2. Kirkland, J. J.; Anal. Chem. 1960, 32, 1388.
3. Noller, C. R.; Hearst, P. J.; J. Am. Chem. Soc. 1948, 70, 3955.
4. Hein, D. W.; Pierce, E. S.; J. Am. Chem. Soc. 1954, 76, 2725.
5. Barber, H. J.; Smiles, S.; J. Chem. Soc. 1928, 1141.
6. Ng, L.-K.; Hupe', M. J. Chromatogr. 1990, 51, 361.
7. Stokke, O.; Helland, P. J. Chromatogr. 1978, 146, 132.
8. Field, J. A.; Miller, J. M.; Field, T. M.; Hawthorne, S. B.; Giger, W. Anal. Chem. 1992, 64, 3161.
9. a) Bosshard, H. H.; Mory, R.; Schmid, M.; Zollinger, H. Helv. Chem. Acta. 1959, 42, 1653; b)
Carlsen, P.H.J.; Rist, Ø; Lund, T.; Helland, I. Acta Chem. Scand. 1995, 49, 701.
10. Marquez, N.; Antón, R. E.; Usubillaga, A.; Salager, J. L. Sep. Sci.Tech. 1993, 28, 2387.
11. Williams, R. J. J. Chromatogr. Sci. 1982, 20, 560.
12. Zhou, D.; Pietrzyk, D. J. Anal. Chem. 1992, 64, 1003.
13. Chiu, G. Anal. Chem. 1980, 53, 1157.
14. Lienado, R. A.; Neubecker, T. A. Anal. Chem. 1983, 55, 933.
15. Denkert, M.; Hackzell, I.; Schill, G.; Sjögren, E. J. Chromatogr. 1981, 218, 31.
17. Shamsi, S. A.; Danielson, N. D. J. Chromatogr. Sci. 1995, 33, 505.
17. Eppert, G.; Liebscher, G. J. Chromatogr. Sci. 1991, 29, 21.

Molecules 2005, 10
1189
18. Eppert, G.; Liebscher, G. J. Chromatogr. 1986, 356, 372.
19. Liebscher, G.; Eppert, G.; Oberender, H.; Berthold, H.; Hauthal, H. G. Tenside Surf. Det. 1989,
26, 195.
20. a) Shamsi, S. A.; Danielson, N. D. J. Chromatogr. Sci. 1995, 33, 505; b) Maki, A. S.; Wangsa, J.;
Danielson, N. D. Anal. Chem. 1992, 64, 582; c) Sachok, B.; Deming, S. N.; Bidlingmeyer, B. A.
J. Liq. Chromatogr. 1982, 5, 389.
tR' tR − tm
21. k' =
=
tm
tm
k' = capacity factor; tR' = adjusted retention time;
tm = column dead time; tR = solute retention time
Sample availability: Samples may be obtained by contacting the corresponding author:
per.carlsen@chem.ntnu.no
© 2005 by MDPI (http://www.mdpi.org). Reproduction is permitted for noncommercial purposes.
