molecules
Article
Copper Ion Attenuated the Antiproliferative Activity
of Di-2-pyridylhydrazone Dithiocarbamate
Derivative; However, There Was a Lack of
Correlation between ROS Generation and
Antiproliferative Activity
Tingting Wang 1,2,†, Yun Fu 1,†, Tengfei Huang , Youxun Liu , Meihao Wu , Yanbin Yuan ,
1
1
1
3
3
,
1,2,
Shaoshan Li * and Changzheng Li
*
1
Department of Molecular Biology & Biochemistry, Xinxiang Medical University,
Xinxiang 453003, Henan, China; wangting2855@sina.com (T.W.); fuyun9801@163.com (Y.F.);
htengfei@yahoo.com (T.H.); liuyouxun@126.com (Y.L.); meihaowu1995@163.com (M.W.)
Henan Collaborative Innovation Center of Molecular Diagnostics and Laboratory Medicine,
Xinxiang Medical University, Xinxiang 453003, Henan, China
2
3
Department of Surgery, The Third Affiliated Hospital of Xinxiang Medical University,
Xinxiang 453003, Henan, China; yuanyanbingo@yahoo.com
*
Correspondence: shaoshanlioo1@sina.com (S.L.); changzhengli@xxmu.edu.cn (C.L.);
Tel.: +86-373-302-9642 (S.L.); +86-373-383-1739 (C.L.)
†
These authors contributed equally to this work.
Academic Editor: Jean Jacques Vanden Eynde
Received: 14 July 2016; Accepted: 16 August 2016; Published: 20 August 2016
Abstract: The use of chelators for cancer treatment has been an alternative option.
Dithiocarbamates have recently attracted considerable attention owning to their diverse biological
activities; thus, the preparation of new dithiocarbamate derivatives with improved antitumor activity
and selectivity as well as probing the underlying molecular mechanism are required. In this study,
di-2-pyridylhydrazone dithiocarbamate S-propionic acid (DpdtpA) and its copper complex were
prepared and characterized, and its antiproliferative activity was evaluated. The proliferation
inhibition assay showed that DpdtpA exhibited excellent antiproliferative effect in hepatocellular
carcinoma (IC50 = 1.3
±
0.3
µ
M for HepG2, and 2.5
±
0.6 µM for Bel-7402). However, in the presence
of copper ion, the antiproliferative activity of DpdtpA was dramatically attenuated (20–30 fold) owing
to the formation of copper chelate. A preliminarily mechanistic study revealed that reactive oxygen
species (ROS) generation mediated the antiproliferative activity of DpdtpA, and accordingly induced
apoptosis, DNA cleavage, and autophagy. Surprisingly, the cytotoxicity of DpdtpA copper complex
(DpdtpA–Cu) was also involved in ROS generation; however, a paradoxical relation between cellular
ROS level and cytotoxicity was observed. Further investigation indicated that DpdtpA could induce
cell cycle arrest at the S phase; however, DpdtpA–Cu lacked this effect, which explained the difference
in their antiproliferative activity.
Keywords: di-2-pyridylhydrazone dithiocarbamate S-propionic acid; antiproliferative activity;
apoptosis; autophagy; cell cycle arrest; antagonistic effect; copper complex; ROS-uncorrelated
cytotoxicity; tumor microenvironment; antitumor mechanism
1
. Introduction
Hepatocellular carcinoma (HCC) is the third leading cause of cancer-related deaths worldwide,
and the incidence of HCC is the highest in Asia and Africa. Certain patients may benefit from resection,
Molecules 2016, 21, 1088; doi:10.3390/molecules21081088
www.mdpi.com/journal/molecules

Molecules 2016, 21, 1088
2 of 15
though mostly transiently. Tumor metastasis is responsible for approximately 90% of all cancer-related
deaths [ ]. It has been recognized that a metastatic tumor stems from a primary tumor that acquires
1
an additional ability to invade the extracellular matrix (ECM). In the early expansion of primary tumors,
tumor cells secrete signaling molecules to recruit myeloid cells that provide a platform of chemokines,
growth factors, and matrix-degrading enzymes [
It has been demonstrated that tumor microenvironment plays an important role in the metastasis
process [ ]; therefore, targeting the tumor microenvironment for cancer therapy is an interesting
2], which constitute the tumor microenvironment.
1,3
topic for medicinal research [4].
Trace metal elements, such as copper, iron, or zinc, are essential for most organisms for cell
growth. The metal ions are present in the biological system, either in the metalloproteins or in
metal-labile pools. Cytochrome oxidase, zinc-copper superoxide dismutase, lysyl oxidase, and several
transcription factors require copper for activity [
copper directly result in inhibition of angiogenesis and cancer cell growth, which is dependent on
angioproliferation [ ]. It is well known that cancer cells have an increased demand for iron and
5]. Increasing data also showed that low levels of
6,7
copper to maintain robust cell proliferation and metastasis; thus, the use of chelators for cancer
treatment has been an alternative option.
Dithiocarbamates constitute a group of sulfur-containing compounds with a strong chelating
ability toward metal ions [
such as apoptosis, oxidative stress, transcription, and degradation of proteins [
an interest to explore their potent applications both as anticancer agents and for treatment of many other
disease conditions [10 13]. Owing to their versatile biological activities, many novel dithiocarbamate
derivatives have been synthesized and their anticancer activities have been evaluated [14 18].
8], which can modulate the key proteins involved in biological processes,
9
]. This aroused
–
–
Moreover, many metal complexes, such as cisplatin, exhibited a significant antiproliferative activity,
and it is known that dithiocarbamates exhibit a marked affinity to metal ions, especially transition
metals. Thus, many complexes of dithiocarbamates have been prepared and investigated for
their antitumor activity. Some of them, such as gold, platinum, and palladium complexes,
showed a prospective use in cancer therapy and were eligible for preclinical observation [17
Preliminary mechanistic studies revealed that dithiocarbamate derivatives could act as nuclear factor
kappa B (NF- B) inhibitors [21], proteasome inhibitors [18], DNA intercalators [22], and inactivators of
–20].
κ
numerous metal-containing enzymes [23]; however, the detailed underlying molecular mechanisms
are still largely unknown.
We aimed to target the molecules whose functions depend on the transition metals in the tumor
microenvironment, such as matrix metalloproteinases, lysyl oxidase, and vascular endothelial growth
factor, which can be used as drug targets to inhibit tumor growth or metastasis. As mentioned above,
dithiocarbamates’ excellent biological activities correlated, at least partly, with their great affinity
to metal ions; however, a very strong affinity toward transition metals may also bring undesirable
consequences, such as direct inactivation of enzymes required for cell growth. Neutralization of their
affinity to metals by introduction of heterozygous coordination atoms into the structural unit may
be a good option. In this study, we introduced 2-dipyridylketone, which has nitrogen coordination
atoms, into the dithiocarbamate system, to develop a novel hydrazone-derived dithiocarbamate.
Next, the novel di-2-pyridylhydrazone dithiocarbamate derivative was preliminarily evaluated for
its antitumor activity against hepatocellular carcinoma, and showed excellent antitumor activity.
The preliminary mechanistic study revealed that the new dithiocarbamate derivative could induce
reactive oxygen species (ROS) generation, cell cycle arrest, apoptosis, and autophagy. To evaluate
its copper-chelating ability that can be potently used to disturb the tumor microenvironment when
administered intravenously, the antiproliferative activity of the dithiocarbamate derivative in the
presence of copper chloride was also evaluated. Surprisingly, the addition of copper chloride
significantly decreased the antiproliferative activity of the dithiocarbamate derivative and was further
attributed to the formation of copper complex. Interestingly, it is the first study to find that there was no
correlation between the antiproliferative activity and ROS generation by the dithiocarbamate copper

Molecules 2016, 21, 1088
3 of 15
complex. Besides, the attenuated antiproliferative activity of the new dithiocarbamate derivative
upon chelation with copper ion could be favorable in the animal model studies owing to the lower
cytotoxicity to other cells, both in the normal tissues and in the tumor microenvironment.
2
. Results
2
.1. Antiproliferative Effect of DpdtpA
Dipyridylhydrazone dithiocarbamate S-propionic acid (DpdtpA) was prepared by a three-step
reaction as described in Figure 1. First, hydrazine was reacted with carbon disulfide to form hydrazine
dithiocarbamate (HdtC); after the addition of dipyridylketone, dipyridylhydrazone dithiocarbamate
(DpdtC) was prepared. DpdtpA was prepared by the reaction of DpdtC with 3-bromopropionic acid.
DpdtpA copper complex was obtained by mixing the DpdtpA solution with copper chloride. The new
compounds, except the non-isolated intermediates of each step, were traced by TLC, and purified
by flash chromatography. Finally, the chemical structures of the new compounds were determined
by NMR, IR, and HRMS spectra. HPLC and NMR showed that the compounds have adequate
purity (>95%, see Supplementary Materials), indicating that the compounds can be used for the
biological assay.
Figure 1. The synthetic rout of DpdtpA and its copper complex.
Next, we screened the cytotoxicity of DpdtpA against hepatocellular carcinoma (Figure 2e).
The dose–response curves are depicted in Figure 2. As shown in Figure 2f,g, DpdtpA caused significant
inhibition of the growth of HepG2 and Bel-7402 cells (IC50 < 3
inhibition of both cell types was obvious. For HepG2 cells, the inhibition percentage was only
about 60% at 50 M (Figure 2g), whereas the inhibition percentage was higher for Bel-7402 cells
µM); however, the difference in maximal
µ
at the same concentration of DpdtpA (Figure 2f). In view of the critical physiological functions of
copper, such as vascularization, and the excellent copper-chelating ability of DpdtpA, the inhibition of
proliferation by DpdtpA was also investigated in the presence of copper ion. Unexpectedly, the growth
inhibition dramatically decreased for both cell lines, and approximately a 20- to 30-fold decrease in
the proliferation inhibition was observed based on the IC50 value compared to that of DpdtpA.
For a detailed explanation, a morphological analysis was conducted. As shown in Figure 2a–d,
DpdtpA caused the cells to be round; however, the addition of copper ion significantly attenuated this
action, showing a protective effect or an “antagonistic effect” that is rarely reported.

Molecules 2016, 21, 1088
4 of 15
Figure 2. The chemical structures of DpdtpA and the proliferation inhibition assay. The effect of
DpdtpA and DpdtpA–Cu on the morphology of HepG2 cells: ( ) 5 M DpdtpA after 16-h treatment;
) 5 M DpdtpA–Cu after 16-h treatment; ( ) 2.5 M DpdtpA after 48-h treatment; ( ) 2.5
DpdtpA after 48-h treatment; ( ) structure of DpdtpA; ( ) proliferation inhibition by DpdtpA or its
copper complex in Bel-7402 cells, IC50 = 1.3 0.3 M for DpdtpA, 45.7 3.6 M for its copper
complex, respectively; and ( ) proliferation inhibition by DpdtpA or its copper complex in HepG2
a
µ
(
b
µ
c
µ
d
µM
e
f
±
µ
±
µ
g
cells, IC50 = 2.5 ± 0.6 µM for DpdtpA, 47.2 ± 4.1 µM for its copper complex, respectively.
2
.2. New Species Determined by the Spectral Study
The “antagonistic effect” of copper ion on the antitumor activity motivated us to reveal the
underlying detail. We speculated that the “antagonistic effect” could stem from a newly formed species.
To support this hypothesis, the absorption spectra of various concentrations of DpdtpA in Tris-HCl
buffer (pH 7.2) at a fixed copper concentration were obtained as previously reported [24]. As shown
in Figure 3a, the copper(II) solution had no absorption in the investigated range of wavelengths
(
300–500 nm); after addition of DpdtpA to the copper solution, a new absorption reading appeared
at approximately 420 nm, which was different from the absorption of DpdtpA (approximately at
53 nm). The bathochromic shift indicated the formation of a new species due to a reaction between
3
DpdtpA and copper ion. For further determination of the composition of the new species (and the
molar ratio of DpdtpA:Cu), various amounts of DpdtpA were added to the copper chloride solution.
The new peak gradually increased until the molar ratio of DpdtpA:Cu = 2. The absorbance (at 420 nm)
2+
at each addition vs. the molar ratio of DpdtpA:Cu was plotted (Figure 3b). A 1:2 molar ratio of
2+
Cu /DpdtpA was determined. The DpdtpA copper complex was further prepared in ethanol based
on this molar ratio, and characterized by IR. The structure of the complex was tentatively proposed as
shown in Figure S5.
Figure 3. UV-visible spectra of DpdtpA copper complex and the relation between the absorbance and
the molar ratio. (
a) Spectra of CuCl alone and in the presence of various concentrations of DpdtpA;
2
the molar ratio is indicated in the figure; (
b
) Plot of the absorbance of the copper complex at 420 nm vs.
the molar ratio of DpdtpA:Cu2+, a 2:1 ratio. The red line was regressive line of molar ration below 2
and the blue was regressive line of molar ration over 2.

Molecules 2016, 21, 1088
5 of 15
2
.3. DpdtpA and Its Copper Complex (DpdtpA–Cu) Induced ROS Generation
It is a prevailingly accepted concept that the antiproliferative activity (or cytotoxicity) of many
drugs stems from their ability to generate ROS. DpdtpA may chelate iron except copper, thus it is
involved in Fenton-like reaction. The assessment of ROS production in vitro is shown in Figure 4a,
the fluorescence intensities of dichlorofluorescein (DCF) in the presence of DpdtpA were higher
than those in the absence of DpdtpA, indicating that iron DpdtpA complex produced more ROS
via a Fenton-like reaction. In contrast, DpdtpA–Cu has a weaker ability to generate ROS; however,
in the reduced environment (in the presence of ascorbic acid (Vc)), DpdtpA–Cu resulted in the highest
production of ROS. To further confirm these results, an in vitro study was carried out to investigate
the drug-induced intracellular ROS production. As shown in Figure 4b, both DpdtpA and its copper
complex induced ROS generation in a concentration-dependent manner. The fluorescence intensities
of DCF in copper complex-treated cells were significantly greater than those of DpdtpA, which might
be related to the redox feature of Cu2
+/1+
complexes, because the copper(I) complex could also react
with an oxygen molecule to form the superoxide radical except with H O [25].
2
2
Figure 4. DpdtpA and its copper complex induced ROS production in vitro and in vivo. (
ROS generation by iron or copper via a Fenton-like reaction; the ROS content was measured by DCF
fluorescence; ( In vivo, the ROS production after exposure of DpdtpA and its copper complex.
a) In vitro
b
)
DMSO was used as a control.
2
.4. Cellular DNA Fragmentation by DpdtpA and Its Copper Complex
It has been demonstrated that ROS cause oxidative damage of DNA and proteins, which correlates
with the cytotoxicity. To investigate the correlation between ROS generation and DNA fragmentation,
the comet tail induced by DpdtpA and its copper complex was measured. As shown in Figure 5,
the abundance of the comet tail or DNA damage in the presence of DpdtpA (or DpdtpA–Cu) was
higher than that of the control and was concentration-dependent (Figure 5b–e). However, there was no
obvious difference between the DpdtpA- and DpdtpA–Cu-treated groups. Generally, DNA damage
is directly related to the extent of ROS production; however, this correlation was not evident in our
in vitro and in vivo studies, at least for DpdtpA–Cu.

Molecules 2016, 21, 1088
6 of 15
Figure 5. In vivo ROS generation and DNA fragmentation (comet tail) induced by DpdtpA and its
copper complex. Comet tail: ( ) control; ( ) 0.78 M DpdtpA; ( ) 1.56 M DpdtpA; ( ) 0.78
DpdtpA–Cu; and (e) 1.56 µM DpdtpA–Cu.
a
b
µ
c
µ
d
µM
2
.5. DpdtpA and Its Copper Complex Induced Cellular Apoptosis
ROS as a messenger that plays a crucial role in the cell growth, and excessive ROS production
induces apoptosis. The previous experimental results implied that apoptosis might be involved.
To support this hypothesis, apoptosis-related proteins were monitored by Western blotting. As shown
in Figure 6, upregulation of caspase-3, caspase-8, and bax was observed; however, bcl-2 was
downregulated. This supported that an apoptotic process was involved, and indicated that both
DpdtpA and DpdtpA–Cu shared similar mechanisms; however, the weaker growth inhibitory effect of
DpdtpA–Cu was not explained.
Figure 6. Western blotting analysis of the changes of apoptosis-related genes: 1, 1.5
, 3.12 µM DpdtpA–Cu; 3, 1.56 µM DpdtpA; 4, 3.12 µM DpdtpA; and 5, DMSO control.
µM DpdtpA;
2
2
.6. The Effect of DpdtpA and Its Copper Complex on the Cell Cycle
ROS induce cell cycle delay at the G1/S boundary [26]. Therefore, we evaluated the effect of
DpdtpA and its copper complex on the cell cycle distribution using propidium iodide staining and flow
cytometry. As shown in Figure 7, DpdtpA caused an accumulation of the HepG2 cells in the S-phase,
and the percentage of the cells at the S-phase significantly increased from 17.70% to 20.90% or 35.3%
upon exposure of the cells to DpdtpA for 24 h (Figure 7b,c). However, it is interesting that treatment
with DpdtpA–Cu complex (Figure 7d,e) did not alter the cell cycle of the host cell, indicating that there
was a difference in the induced cell cycle arrest.

Molecules 2016, 21, 1088
7 of 15
Figure 7. Cell cycle distribution of HepG2 cells following treatment with various concentrations of
DpdtpA and its Cu complex: ( ) Control; ( ) 1.56 M DpdtpA; ( ) 3.12 M DpdtpA; ( ) 1.56
DpdtpA–Cu; and (e) 3.12 µM DpdtpA–Cu.
a
b
µ
c
µ
d
µM
2
.7. The Change in Lysosomal (Autophagosome) Membrane Permeability (LMP) in Cells upon Exposure to
DpdtpA and Its Copper Complex
As mentioned above, the upregulation of bax may also be involved in the translocation from
the cytosol to the lysosomal membrane, which can regulate the lysosomal membrane integrity [27].
To test this hypothesis, LysoTracker Red, which can accumulate within the lysosomes, was employed
to assess the LMP [28]. As shown in Figure 8a–c, the red fluorescence density in HepG2 cells
significantly increased in the DpdtpA- and DpdtpA–Cu-treated groups compared to that in the control,
indicating that LMP was altered. Furthermore, the changes in LMP may be a response to autophagy;
thus, the formation of autophagosomes was measured by acridine orange staining. As shown in
Figure 8d–h, the red granular fluorescence in the acidic vacuoles was observed in the treated groups
and follows a concentration-dependent pattern, which implied that autophagy occurred. For further
determination of the involvement of autophagy, LC3 (microtubule-associated protein light chain 3),
an autophagosome marker, was measured by Western blotting analysis. As expected, an increase in
the cleaved LC3-II and a decrease in LC3-I were observed in the treated groups compared to that in the
control, indicating that autophagy was involved in cellular death after exposure to the test compounds
(Figure 8i). The results demonstrated the DpdtpA and its copper complex could induce autophagy
in the same manner. However, it was clear that the stronger autophagy induction and destruction of
LMP by DpdtpA–Cu did not correlate with its antiproliferative activity.
Figure 8. DpdtpA and its copper complex induced autophagy (or changes in LMP) in HepG2 cells:
(
a
) LysoTracker Red-stained HepG2 cells (control); (
) control; ( ) 0.78 M DpdtpA; ( ) 1.56 M DpdtpA; (
) Western blotting: 1, 0.78 M DpdtpA; 2, 1.56
DpdtpA–Cu; and 5, control.
b
g
) 0.78
) 0.78
M DpdtpA; 3, 0.78
µ
M DpdtpA; (
M DpdtpA–Cu; (
M DpdtpA–Cu; 4, 1.5 µM
c
) 0.78
µ
M DpdtpA–Cu;
(d
e
µ
f
µ
µ
µ
h
) 1.5
µM DpdtpA–Cu;
and (
i
µ
µ

Molecules 2016, 21, 1088
8 of 15
3
. Discussion
Although many methods have been developed for cancer therapy and diagnosis, cancer treatment
is still a challenge. This can be attributable to the lack of both a diagnostic method that can identify
the early phase of the disease and a highly selective drug that can target the cancer cells. However,
recent studies revealed that the tumor microenvironment plays a critical role in the cancer growth,
metastasis, and treatment responses [29]. Targeting the tumor microenvironment was recently
proposed as a strategy for cancer therapy [
ECM, molecules in the ECM, and other cells, such as fibroblasts and immune cells [
4
]. The tumor microenvironment consists of tumor cells,
]. The molecules
2
in the ECM contain many metalloenzymes and cytokines, which can be used as drug targets. Thus,
the involvement of metal ions in the ECM in homeostasis can be used as a target for chelating therapy.
In this strategy, the decrease of chelator in cytotoxicity upon binding to the metal may be a good sign.
Pyrrolidine dithiocarbamate (PDTC), one of the members of the dithiocarbamate family, displays a dual
action, including an antioxidant and radical scavenging activity [30–32] and apoptosis induction
capability. It is a well accepted concept in antitumor drug design that excess ROS can cause oxidative
damage of proteins and nucleic acids, and accordingly can result in cell death. Our data showed
that DpdtpA exhibited the ability to generate ROS both in vitro and in vivo, which correlated with its
cytotoxicity. ROS production induced by DpdtpA may be due to Fenton-like reaction (redox-active
2+
DpdtpA-Fe ) and catalase inhibition (data not shown). We speculated that DpdtpA could chelate
ferrous iron from the iron labile pool, and form the redox-active DpdtpA-Fe2+ species to produce
excess ROS that cause lipid oxidation and DNA fragmentation [33]. To determine the correlation
between ROS production and DNA cleavage, the comet assay was also conducted. It showed that
DpdtpA induced cellular DNA breakage in a concentration-dependent manner. Further evidence
from Western blotting analysis supported the hypothesis that apoptosis was involved because bax
and caspases were upregulated, whereas bcl-2 was downregulated after exposure of the HepG2 cells
to DpdtpA. These changes are frequently observed together in the cells subjected to anticancer drug
treatment [34]. In addition, DpdtpA can induce cell cycle arrest at the S phase as reported [35,36].
To gain insight into the detailed mechanism, cyclin D1, an S phase cell cycle gatekeeper protein,
was measured. Cyclin D1 was downregulated (Figure 7), which implied that suppressed cyclin D1
favored the entry into the S phase because it inhibits DNA synthesis by virtue of its binding to the
regulator of DNA synthesis [37].
Copper is an essential element for cell growth. Many drugs, used in clinical practice,
have metal-chelating ability and display cytotoxicity. In vitro copper complexes generally show
an enhanced antiproliferative activity [24
Dithiocarbamates are known to act as inhibitors of the canonical NF-
,
25
,
38
,
39] and an antagonistic effect was rarely reported.
B pathway since 1992 [21],
κ
whereas dithiocarbamate copper complexes exhibit a distinct biological activity compared to
dithiocarbamates [40]. It has been demonstrated that proteasome inhibition by dithiocarbamate
copper complexes contributes to their cytotoxicity [41–44]; however, these studies reported that
dithiocarbamates showed an enhanced cytotoxicity upon chelation with copper. In the present study,
we showed that copper ion dramatically attenuated the antiproliferative activity of DpdtpA against
the given cell lines, an effect which has not been reported for any dithiocarbamate derivative (Figure 1).
The “antagonistic effect” was confirmed to be due to the formation of new species (copper chelate)
by spectral titration of DpdtpA against copper ion solution. The new species was formed at a ratio
of DpdtpA:Cu = 2. The possible structure of the new species was proposed based on the IR and
other spectral data. Second, we observed a paradoxical relation between the cellular ROS level and
cytotoxicity. DpdtpA–Cu exhibited a stronger ROS-inducing ability in vitro and in vivo compared to
DpdtpA; however, the changes in the expression of apoptotic proteins and DNA fragmentation were
not evident, which violated the currently accepted concept in ROS-based cancer therapy. Similarly,
Zhu et al. recently reported that no dose–response relationship was evident between the cellular ROS
level and cytotoxicity [45]. It was noted that although DpdtpA–Cu and DpdtpA had similar effects
regarding apoptosis induction, the difference in the cell cycle delay was distinct. DpdtpA caused cell

Molecules 2016, 21, 1088
9 of 15
cycle arrest at the S phase, whereas DpdtpA–Cu did not exhibit this effect, which may be an important
contributor to its weaker antiproliferative activity.
Autophagy functions to degrade the damaged proteins and/or organelles and to recycle the
materials to maintain the quality of cellular components [46]. The formation of acidic vesicular
organelles (AVOs) is a characteristic marker of the autophagy process [47]. ROS-triggered autophagy
has been widely realized [48]. In view of the higher ROS level reported in vivo, we speculated
that the antiproliferative activity of DpdtpA or its copper complex might be due to autophagy.
As expected, the granular red fluorescence in AVOs was observed after treatment of HepG2 cells
with the test compounds (Figure 7d–h), suggesting that autophagy was involved. Further supporting
evidence was from the immunofluorescence detection of LC3, a marker of autophagy. LC3-I levels
decreased, whereas LC3-II levels increased (Figure 8i). DpdtpA–Cu exhibited a marked ability to form
autophagosomes and lysosomes than DpdtpA, which correlated with ROS production, but not with its
antiproliferative activity. The underlying reason was not clear.
In conclusion, DpdtpA exhibited a significant antiproliferative activity against hepatocellular
carcinoma cells via ROS-meditated apoptosis, autophagy, and cell cycle arrest. However, the addition
of copper dramatically decreased its antiproliferative activity due to the formation of a chelate.
Although ROS production due to DpdtpA–Cu cytotoxicity was obvious, the correlation between
ROS production and cytotoxicity was not established. This was similar to the results of recent reports.
The difference between DpdtpA and DpdtpA–Cu regarding the antiproliferative activity could be
explained based on the observation that the former had a distinct ability to disturb the cell cycle,
but the latter did not. Additionally, the attenuated antiproliferative activity of DpdtpA upon copper
chelation is considered as an advantage for animal studies to target the tumor microenvironment.
However, the paradoxical relationship between ROS production and cytotoxicity of DpdtpA–Cu
requires further investigation.
4
. Materials and Methods
4
.1. General Information
MTT (3-(4,5-dimethylthiazol-2-yl)-2,5-diphenyltetrazolium bromide), ethidium bromide (EB),
di-2-pyridylketone, RPMI-1640, and other chemicals were purchased from Sigma-Aldrich (Shanghai,
China). LC3 antibody was obtained from Proteintech Group (Wuhan, China). Antibodies against
cyclin D1, caspase 3, β-actin, Bax, and Bcl-2 were purchased from Boster (Wuhan, China).
4
.2. Preparation of Di-2-pyridylhydrazone Dithiocarbamate S-propionic Acid (DpdtpA)
DpdtpA (chemical name generated by ACDLabs: 3-[({2-[di(pyridin-2-yl)methylidene]hydrazinyl}
carbonothioyl)sulfanyl]propanoic acid) was prepared via a three-step reaction as indicated in Figure 1.
First, the hydrazine dithiocarbamate was synthesized by the reaction of equimolar carbon disulfide
(1 mmol) with hydrazine (1 mmol) in KOH-containing ethanol (10 mL) on an ice bath for 1 h [49].
Then, the reaction mixture, without further separation, was mixed with an equimolar amount of
di-2-pyridylketone (1 mmol). The resulting mixture was refluxed for 1 h. After cooling, the red-brown
solid was filtered and washed with cold ethanol. Thin-layer chromatography (TLC) showed one spot
(
mobile phase:ethyl acetate/petroleum ether = 3:1). The unpurified product showed a yield of 80% and
◦
a melting point (mp) of 140.5 C. The di-2-pyridylhydrazone dithiocarbamate was characterized by:
1
H-NMR (Bruker, DMSO-d , ppm): 13.35 (s, NH), 8.85 (d, H, J = 4 Hz), 8.63 (d, H, J = 4 Hz), 8.03 (m, 2H,
6
J = 8 Hz), 7.95 (d, H, J = 8 Hz), 7.63 (dd, H, J = 4 Hz), 7.59 (d, H, J = 8 Hz), 7.54 (dd, H, J = 4 Hz);
−
1
IR (PerkinElmer, Life and Analytical Sciences, Beaconsfield, UK; KBr, cm ): 3430, 1624, 1587, 1519,
461, 1430, 1217, 1187, 1133, 1051, 1012, 992, 800, 753, 731, 712, 648, 618, and 590; ESI-MS (microTOF-Q
1
III, Bruker, m/z): 350.9540 (M − H + 2K, calcd: 350.9525).
Next, the red-brown solid (di-2-pyridylhydrazone dithiocarbamate, 1 mmol) was dissolved in
absolute ethanol (5 mL), and reacted with 3-bromopropionic acid at room temperature for 1 h. Then, the

Molecules 2016, 21, 1088
10 of 15
yellow solid was filtered and washed with ethanol. TLC tracing (ethyl acetate/petroleum ether = 3:1
)
◦
1
showed that the reaction is complete. The yield was 90% and mp was 155 C. H-NMR (DMSO-d ,
6
ppm): 15.0 (s, NH), 8.85 (d, H, J = 4 Hz), 8.63 (d, H, J = 4 Hz), 8.03 (m, 2H, J = 8 Hz), 7.95 (d, H, J = 8 Hz),
7
.63 (dd, H, J = 4 Hz), 7.59 (d, H, J = 8 Hz), 7.54 (dd, H, J = 4 Hz), 3.43 (tri, 2H, J = 8 Hz), 2.71 (tri, H,
−
1
J = 8 Hz). IR (KBr, cm ): 3404, 1701, 1587, 1458, 1356, 1329, 1288, 1234, 1207, 1133, 1061, 1034, 1014,
8
03, 753, 701, 654, and 593. ESI-MS (m/z): 385.0203 (M + K, calcd: 385.01954).
DpdtpA copper complex (DpdtpA–Cu) was prepared by two methods: (1) During the cytotoxicity
assay: DpdtpA–Cu was formed by mixing 100 mM DpdtpA in dimethylformamide (DMSO, 100
µL)
with 1 M copper chloride in water (5 L); (2) DpdtpA–Cu was prepared by mixing 0.1 mmol DpdtpA
µ
in ethanol with 0.05 mmol copper chloride solution with stirring, the resulting solution was further
stirred overnight at room temperature (protected from light), then after filtration, the powder was
◦
−1
dried in a vacuum desiccator. The yield was 70% and mp was 198.4 C. IR (cm ): 3404, 1731, 1708,
593, 1476, 1438, 1407, 1385, 1327, 1185, 1118, 1095 and 996. IR and HPLC analyses are shown in
1
Figures S3 and S4). The comparison between the IR of DpdtpA and DpdtpA–Cu is shown in Figure S5.
Accordingly, the possible coordination structure of DpdtpA–Cu is tentatively proposed in Figure S6.
4
.3. Cytotoxicity Assay (MTT Assay)
DpdtpA (10 mM) in 80% DMSO was diluted to the required concentration with the culture
medium. The copper complex was prepared by mixing DpdtpA with CuCl (at high concentration)
2
based on a 1:2 molar ratio and diluted to the required concentration with water. The MTT assay was
3
conducted as previously described [25]. Briefly, 5
×
10 /mL Bel-7402 cells (or HepG2 cells) in the
exponential phase were seeded equally into a 96-well plate and various amounts of DpdtpA (or its
copper complex) were added after the cells adhered. After 48-h incubation at 37 C in a humidified
◦
atmosphere containing 5% CO , 10
µL of MTT solution (5 mg/mL) was added to each well followed
2
by additional 4-h incubation. The cell culture medium was removed and 100 L of DMSO was
µ
added to each well to dissolve the formazan crystals. The measurement of the absorbance of the
solution, which is related to the number of living cells, was performed using a microplate reader
(MK3, Thermo Scientific) at 570 nm. Growth inhibition percentage was defined as percentage of
absorbance inhibition within appropriate absorbance in each cell line. The assay was performed
in triplet. A morphological study was conducted using an inverted microscope (Shanghai Batuo
Instrument Co., Ltd., Shanghai, China), and the photographs of HepG2 cells exposed to DpdtpA (2.5 or
5
.0 µM DpdtpA or DpdtpA–Cu) for 16 or 48 h were recorded (objective lens size: 10 × 20).
4
.4. Determination of the Molar Ratio of DpdtpA to Copper(II) Involved in the Formation of the Complex
The stoichiometry of the reaction between DpdtpA and copper chloride was determined as
previously described [25]. Briefly, solutions of 1 mM DpdtpA in 50% DMSO and 1 mM CuCl in
2
water were prepared. Next, 0.04 mL of the CuCl solution was added to a series of 5 mL-volumetric
2
flasks, and then a different volume of DpdtpA (10, 20, 30, 40, 50, 60, 70, 80, 85, and 90 µL) was added
to each flask. Finally, 50 mM Tris-HCl buffer (pH 7.4) was added to total 5 mL. After mixing and
equilibrium, the UV spectra were recorded on a Shimadzu-UV-2450 spectrophotometer (Shimadzu Co.,
Ltd., Suzhou, China).
4
.5. ROS Detection in Vitro and in Vivo
Assessment of ROS production was conducted as previously reported [25]. Briefly, H DCF-DA was
2
first converted to DCF by NaOH, and the neutralized hydrolysate was used for the in vitro assay.
The reaction system contained either a single reagent or multiple components in 50 mM sodium
phosphate buffer (pH 7.4) with a total volume of 4 mL (i.e., 0.4
µM DCF, 6.25 µM NH FeSO
4 4
(
or CuCl or DpdtpA) and 200 M H O (1 mM) for Fenton reaction). The fluorescence was
µ
2
2
2
detected by a FC-960 spectrofluorometer (excitation wavelength at 488 nm and emission wavelength

Molecules 2016, 21, 1088
11 of 15
at 525 nm, Shanghai Lengguang Technology Co., Ltd., Shanghai, China) within a 10-min time course
at room temperature.
The intracellular ROS assay was carried out in accordance with the company’s recommendations
6
(
Beyotime Biotechnology, Beijing, China). Approximately 10 HepG2 cells were used in the
assay. After washing with phosphate-buffered saline (PBS), the cells were re-suspended in
H DCF-DA-containing serum-free culture medium and incubated for 30 min. Next, the stained
2
cells were washed with serum-free culture medium. Then, 100 µL of the cell culture was transferred to
individual PCR tubes and the test compound (or positive control) was added. After 1-h incubation,
the cell suspension was used directly for ROS detection by a FC-960 spectrofluorometer (excitation
wavelength at 488 nm and emission wavelength at 525 nm, Shanghai Lengguang Technology Co., Ltd.,
Shanghai, China).
4
.6. Comet Assay
DNA fragmentation was determined by the comet assay as previously described [24]. HepG2 cells
were treated with or without the investigated compounds (0.78 and 1.56 µM) and incubated for 24 h in a
humidified atmosphere of 5% CO . The harvested cells were then embedded in 0.5% low-melting point
2
4
agarose at 10 cells/mL. Forty microliters of this cellular suspension was spread onto duplicate frosted
slides that were covered with 1% normal-melting point agarose. Upon solidification, the slides were
placed in a lysis buffer (2.5 M NaCl, 0.1 M ethylenediaminetetraacetic acid (EDTA), 0.01 M Tris-HCl
,
◦
1% Triton X-100, 10% DMSO, pH 10) for 1 h at 4 C. After lysis, the slides were transferred to
an alkaline buffer for 40 min (0.001 M EDTA, 0.3 M NaOH, pH > 13) to allow the DNA to unwind
before migration at 0.66 V/cm and 300 mA for 30 min. All of these steps were performed in the
◦
dark. After neutralization in 0.4 M Tris-HCl, pH 7.4, the slides were stored at 4 C until analysis
within the following 24 h. Before analysis, the slides were stained with ethidium bromide (20 µg/mL)
and covered with coverslips. Images were captured using a fluorescent microscope (Shanghai Batuo
Instrument Co. Ltd., Shanghai, China).
4
.7. Western Blotting Analysis
7
Briefly, 1
×
10 HepG2 cells treated with or without DpdtpA or DpdtpA–Cu were scraped off
in a lysis buffer (50 mM Tris-HCl, pH 8.0, 150 mM NaCl, 1.0% NP-40, 10% glycerol, and protease
inhibitors) and subjected to sonication followed by spinning down by centrifugation at 14,000
×
g.
◦
The clear supernatant was stored at
−
80 C. The protein concentration was determined using the
colorimetric Bio-Rad DC protein assay on a microplate reader, MK3, at 570 nm. Proteins (50 µg) were
separated on a 13% sodium dodecyl sulfate-polyacrylamide gel at 200 V for 1 h. Then, the separated
proteins were subsequently transferred onto a polyvinylidene difluoride (PVDF) membrane at 60 V
for 1 h. The membrane was washed three times with tris-buffered saline (TBS), and was then blocked
for 2 h in TBS containing 0.1% Tween-20 and 5% skimmed milk. The membrane was incubated
◦
at 4 C overnight with the primary monoclonal antibody used at a dilution of 1:300 in TBS plus
0
.1% Tween-20 (TBST). The membrane was washed several times with TBST and was subsequently
incubated with horseradish peroxidase (HRP)-conjugated secondary antibody (1:2000 in TBST) for
h at room temperature. After another wash of the membrane with TBST, the protein bands were
1
detected using a super-sensitive ECL solution (Boster Biological Technology Co., Ltd., Wuhan, China),
and visualized using an Amersham imager 600 (GE Healthcare Life Sciences, Fairfield, CT, USA).
4
.8. Cell Cycle Analysis
HepG2 cells (1
The medium was replaced with fresh medium supplemented or not (control) with the test compounds
5
◦
10 ) were seeded in a 6-well plate and incubated for 24 h at 37 C (5% CO ).
2
×
(
1.5 and 3.12
µ
M). After 24-h incubation, the cells were harvested with trypsin, followed by washing
◦
with PBS, and were fixed in 70% ethanol and stored at
using propidium iodide (PI). Briefly, after removing the 70% ethanol, the cells were washed with
−
20 C. The cellular nuclear DNA was stained

Molecules 2016, 21, 1088
12 of 15
PBS and then suspended in 0.5 mL PBS containing 50 g/mL PI and 100
µ
g/mL RNase. The cell
◦
suspension was incubated at 37 C for 30 min. DNA flow cytometry was performed in duplicate using
a FACSCalibur flow cytometer (Becton-Dickinson, San Jose, CA, USA). For each sample, 10,000 events
were collected, and the fluorescence signal intensity was recorded and analyzed by CellQuest and
ModiFit (Becton-Dickinson).
4
.9. DpdtpA and Its Copper Complex Induced Autophagy
Cells were seeded into a 24-well flask and treated as previously described for the cell viability
assay. The cells were treated with different concentrations of the test compounds (0.78 and 1.56
DpdtpA or DpdtpA–Cu) for 24 h. For detection of the acidic cellular compartment, acridine orange
Genview, Jacksonville, FL, USA) was used, which emits bright red fluorescence in the acidic vesicles,
whereas it emits green fluorescence in the cytoplasm and nucleus. After treatment of the cells with the
test compounds, acridine orange was added at a final concentration of 1 g/mL (the concentration of
µM
(
µ
LysoTracker Red (Beyotime Biotechnology, Shanghai, China), as recommended) for 15 min. After PBS
washing, the fluorescence micrographs were captured using an inverted fluorescence microscope.
Supplementary Materials: The following are available online at http://www.mdpi.com/1420-3049/21/8/1088/s1.
Acknowledgments: The present study was supported by grants awarded by the Natural Science Foundation
of China (No. 21571153), the Henan Science and Technology Agency (Nos. 114300510012, 132102310250 and
1
52300410118), the Plan of Health Scientific and Technological Innovation Talents of Henan Province (No. 2109901)
to Shaoshan Li and Graduate innovation project of Xinxiang Medical University (YJSCX201503Z).
Author Contributions: Tingting Wang and Yun Fu performed the experiments; they contributed equally to this
work; Changzheng Li conceived and designed the experiments; Tengfei Huang, Meihao Wu, and Youxun Liu
synthesized and purified DpdtpA; Yanbin Yuan and Shaoshan Li analyzed the data; Changzheng Li prepared and
wrote the paper.
Conflicts of Interest: The authors declare no conflicts of interest.
Abbreviations
The following abbreviations are used in this manuscript:
MTT
3-(4,5-dimethylthiazole-2-yl)-2,5-diphenyl tetrazoliumbromide
Di-2-pyridylhydrazone dithiocarbamate S-propionic acid
Copper complex of di-2-pyridylhydrazone dithiocarbamate S-propionic acid
Reactive oxygen species
DpdtpA
DpdtpA–Cu
ROS
ECM
Extracellular matrix
NMR
Nuclear magnetic resonance
Infrared
IR
References
1
.
Spano, D.; Zollo, M. Tumor microenvironment: A main actor in the metastasis process. Clin. Exp. Metastasis
012, 29, 381–395. [CrossRef] [PubMed]
2
2
.
Hiratsuka, S.; Watanabe, A.; Aburatani, H.; Maru, Y. Tumourmediated upregulation of chemoattractants and
recruitment of myeloid cells predetermines lung metastasis. Nat. Cell Biol. 2006, 8, 1369–1375. [CrossRef]
[PubMed]
3.
4.
5.
6.
Catalano, V.; Turdo, A.; Di Franco, S.; Dieli, F.; Todaro, M.; Stassi, G. Tumor and its microenvironment:
A synergistic interplay. Semin. Cancer Biol. 2013, 23, 522–532. [CrossRef] [PubMed]
Sounni, N.E.; Noel, A. Targeting the tumor microenvironment for cancer therapy. Clin. Chem. 2013, 59, 85–93.
[
CrossRef] [PubMed]
Goodman, V.L.; Brewer, G.J.; Merajver, S.D. Copper deficiency as an anti-cancer strategy. Endocr. Relat. Cancer
004, 11, 255–263. [CrossRef] [PubMed]
2
Khan, G.; Merajver, S. Copper chelation in cancer therapy using tetrathiomolybdate: An evolving paradigm.
Expert Opin. Investig. Drugs 2009, 18, 541–548. [CrossRef] [PubMed]

Molecules 2016, 21, 1088
13 of 15
7
.
Bogaard, H.J.; Mizuno, S.; Guignabert, C.; Al Hussaini, A.A.; Farkas, D.; Ruiter, G.; Kraskauskas, D.;
Fadel, E.; Allegood, J.C.; Humbert, M.; et al. Copper dependence of angioproliferation in pulmonary arterial
hypertension in rats and humans. Am. J. Respir. Cell Mol. Biol. 2012, 46, 582–591. [CrossRef] [PubMed]
Orrenius, S.; Nobel, C.S.I.; van den Dobbelsteen, D.J.; Burkitt, M.J.; Slater, A.F.G. Dithiocarbamates and the
redox regulation of cell death. Biochem. Soc. Trans. 1996, 24, 1032–1038. [CrossRef]
8
.
.
9
Buac, D.; Schmitt, S.; Ventro, G.; Kona, F.R.; Dou, Q.P. Dithiocarbamate-based coordination compounds as
potent proteasome inhibitors in human cancer cells. Mini Rev. Med. Chem. 2012, 12, 1193–1201. [CrossRef]
[PubMed]
1
1
0. Fang, I.M.; Yang, C.H.; Lin, C.P.; Yang, C.M.; Chen, M.S. Effects of pyrrolidine dithiocarbamate, an NF-κB
inhibitor, on cytokine expression and ocular inflammation in experimental autoimmune anterior uveitis.
J. Ocul. Pharmacol. Ther. 2005, 21, 95–106. [CrossRef] [PubMed]
1. Si, X.; McManus, B.M.; Zhang, J.; Yuan, J.; Cheung, C.; Esfandiarei, M.; Suarez, A.; Morgan, A.;
Luo, H. Pyrrolidine dithiocarbamate reduces coxsackievirus B3 replication through inhibition of the
ubiquitin-proteasome pathway. J. Virol. 2005, 79, 8014–8023. [CrossRef] [PubMed]
1
1
1
2. Ozkirimli, S.; Apak, T.I.; Kiraz, M.; Yegenoglu, Y. Synthesis of new triazolyl-N, N-dialkyldithiocarbamates as
antifungal agents. Arch. Pharm. Res. 2005, 28, 1213–1218. [CrossRef] [PubMed]
3. Reisinger, E.C.; Kern, P.; Ernst, M.; Bock, P.; Flad, H.D.; Dietrich, M. Inhibition of HIV progression by
dithiocarb. German DTC Study Group. Lancet 1990, 335, 679–682. [CrossRef]
4. Li, Y.H.; Qi, H.X.; Li, X.B.; Hou, X.L.; Lu, X.Y.; Xiao, X.W. A novel dithiocarbamate derivative induces cell
apoptosis through p53-dependent intrinsic pathway and suppresses the expression of the E6 oncogene of
human papillomavirus 18 in HeLa cells. Apoptosis 2015, 20, 787–795. [CrossRef]
1
5. Wang, X.J.; Xu, H.W.; Guo, L.L.; Zheng, J.X.; Xu, B.; Guo, X.; Zheng, C.X.; Liu, H.M. Synthesis and in vitro
antitumor activity of new butenolide-containing dithiocarbamates. Bioorg. Med. Chem. Lett. 2011, 21,
3
074–3077. [CrossRef] [PubMed]
1
6. Huang, W.; Ding, Y.; Miao, Y.; Liu, M.Z.; Li, Y.; Yang, G.F. Synthesis and antitumor activity of novel
dithiocarbamate substituted chromones. Eur. J. Med. Chem. 2009, 44, 3687–3696. [CrossRef]
1
7. Mansouri-Torshizi, H.; Saeidifar, M.; Khosravi, F.; Divsalar, A.; Saboury, A.A.; Hassani, F. DNA Binding
and Antitumor Activity of
α-Diimineplatinum(II) and Palladium(II) Dithiocarbamate Complexes.
Bioinorg. Chem. Appl. 2011, 2011, 394506. [CrossRef]
1
1
2
8. Milacic, V.; Chen, D.; Ronconi, L.; Landis-Piwowar, K.R.; Fregona, D.; Dou, Q.P. A novel anticancer gold (III)
dithiocarbamate compound inhibits the activity of a purified 20S proteasome and 26S proteasome in human
breast cancer cell cultures and xenografts. Cancer Res. 2006, 66, 10478–10486. [CrossRef]
9. Nardon, C.; Schmitt, S.M.; Yang, H.; Zuo, J.; Fregona, D.; Dou, Q.P. Gold(III)-dithiocarbamato
peptidomimetics in the forefront of the targeted anticancer therapy: Preclinical studies against human
breast neoplasia. PLoS ONE 2014, 9, e84248. [CrossRef] [PubMed]
0. Cattaruzza, L.; Fregona, D.; Mongiat, M.; Ronconi, L.; Fassina, A.; Colombatti, A.; Aldinucci, D.
Antitumor activity of gold(III)-dithiocarbamato derivatives on prostate cancer cells and xenografts.
Int. J. Cancer 2011, 128, 206–215. [CrossRef] [PubMed]
2
1. Schreck, R.; Meier, B.; Männel, D.N.; Dröge, W.; Baeuerle, P.A. Dithiocarbamates as potent inhibitors of
nuclear factor kappa B activation in intact cells. J. Exp. Med. 1992, 175, 1181–1194. [CrossRef]
2. Ronconi, L.; Marzano, C.; Zanello, P.; Corsini, M.; Miolo, G.; Maccà, C.; Trevisan, A.; Fregona, D.
Gold(III) Dithiocarbamate Derivatives for the Treatment of Cancer: Solution Chemistry, DNA Binding,
and Hemolytic Properties. J. Med. Chem. 2006, 49, 1648–1657. [CrossRef] [PubMed]
2
2
3. Nobel, C.S.I.; Burgess, D.H.; Zhivotovsky, B.; Burkitt, M.J.; Orrenius, S.; Slater, A.F. Mechanism of
dithiocarbamate inhibition of apoptosis: Thiol oxidation by dithiocarbamate disulfides directly inhibits
processing of the caspase-3 proenzyme. Chem. Res. Toxicol. 1997, 10, 636–643. [CrossRef] [PubMed]
4. Yang, Y.; Li, C.; Fu, Y.; Liu, Y.; Zhang, Y.; Zhang, Y.; Zhou, P.; Yuan, Y.; Zhou, S.; Li, S.; Li, C. Redox cycling of
a copper complex with benzaldehyde nitrogen Mustard-2-pyridine carboxylic acid hydrazone contributes to
its enhanced antitumor activity, but no change in the mechanism of action occurs after chelation. Oncol. Rep.
2
2
016, 35, 1636–1644.

Molecules 2016, 21, 1088
14 of 15
2
5. Huang, T.; Li, C.; Sun, X.; Zhu, Z.; Fu, Y.; Liu, Y.; Yuan, Y.; Li, S.; Li, C. The antitumor mechanism of
di-2-pyridylketone 2-pyridine carboxylic acid hydrazone and its copper complex in ROS generation and
topoisomerase inhibition, and hydrazone involvement in oxygen-catalytic iron mobilization. Int. J. Oncol.
2
015, 47, 1854–1862. [CrossRef] [PubMed]
2
2
2
6. Brodská, B.; Holoubek, A. Generation of reactive oxygen species during apoptosis induced by
DNA-damaging agents and/or histone deacetylase inhibitors. Oxid. Med. Cell. Longev. 2011, 2011, 253529.
[CrossRef] [PubMed]
7. Johansson, A.C.; Appelqvist, H.; Nilsson, C.; Kågedal, K.; Roberg, K.; Ollinger, K. Regulation of
apoptosis-associated lysosomal membrane permeabilization. Apoptosis 2010, 15, 527–540. [CrossRef]
[PubMed]
8. Rehman, S.U.; Zubair, H.; Sarwar, T.; Husain, M.A.; Ishqi, H.M.; Nehar, S.; Tabish, M. Redox cycling of Cu(II)
by 6-mercaptopurine leads to ROS generation and DNA breakage: Possible mechanism of anticancer activity.
Tumour Biol. 2015, 36, 1237–1244. [CrossRef] [PubMed]
2
3
3
3
9. Chen, F.; Zhuang, X.; Lin, L.; Yu, P.; Wang, Y.; Shi, Y.; Hu, G.; Sun, Y. New horizons in tumor
microenvironment biology: Challenges and opportunities. BMC Med. 2015, 5, 45. [CrossRef] [PubMed]
0. Komarov, A.M.; Mak, I.T.; Weglicki, W.B. Iron Potentiates Nitric Oxide Scavenging by Dithiocarbamates in
Tissue of Septic Shock Mice. Biochim. Biophys. Acta 1997, 1361, 229–234. [CrossRef]
1. Moellering, D.; McAndrew, J.; Jo, H.; Darley-Usmar, V.M. Effects of Pyrrolidine Dithiocarbamate on
En-dothelial Cells: Protection against Oxidative Stress. Free Radic. Biol. Med. 1999, 26, 1138–1145. [CrossRef]
2. Nicuolo, F.D.; Serini, S.; Boninsegna, A.; Palozza, P.; Calviello, G. Redox Regulation of Cell Proliferation by
Pyrrolidine Dithiocarbamate in Murine Thymoma Cells Transplanted in Vivo. Free Radic. Biol. Med. 2001, 31,
1
424–1431. [CrossRef]
3
3. Fussell, K.C.; Udasin, R.G.; Gray, J.P.; Mishin, V.; Smith, P.J.; Heck, D.E.; Laskin, J.D. Redox cycling and
increased oxygen utilization contribute to diquat-induced oxidative stress and cytotoxicity in Chinese
hamster ovary cells overexpressing NADPH-cytochrome P450 reductase. Free Radic. Biol. Med. 2011, 50,
8
74–882. [CrossRef] [PubMed]
3
3
3
4. Gillardon, F.; Wickert, H.; Zimmermann, M. Up-regulation of bax and down-regulation of bcl-2 is associated
with kainate-induced apoptosis in mouse brain. Neurosci. Lett. 1995, 192, 85–88. [CrossRef]
5. Chatterjee, S.; Kundu, S.; Sengupta, S.; Bhattacharyya, A. Divergence to apoptosis from ROS induced cell
cycle arrest: Effect of cadmium. Mutat. Res. 2009, 663, 22–31. [CrossRef] [PubMed]
6. Kumar, R.; Dwivedi, P.D.; Dhawan, A.; Das, M.; Ansari, K.M. Citrinin-generated reactive oxygen species
cause cell cycle arrest leading to apoptosis via the intrinsic mitochondrial pathway in mouse skin. Toxicol. Sci.
2
011, 122, 557–566. [CrossRef] [PubMed]
3
3
7. Xiong, Y.; Zhang, H.; Beach, D. D type cyclins associate with multiple protein kinases and the DNA replication
and repair factor PCNA. Cell 1992, 71, 505–514. [CrossRef]
8. Fu, Y.; Yang, Y.; Zhou, S.; Liu, Y.; Yuan, Y.; Li, S.; Li, C. Ciprofloxacin containing Mannich base and its copper
complex induce antitumor activity via different mechanism of action. Int. J. Oncol. 2014, 45, 2092–2100.
[CrossRef] [PubMed]
3
9. Yang, Y.L.; Huang, T.F.; Zhou, S.F.; FU, Y.; Liu, Y.X.; Yuan, Y.B.; Zhang, Q.Q.; Li, S.S.; Li, C.Z.
Antitumor activity of a 2-pyridinecarboxaldehyde 2-pyridinecarboxylic acid hydrazone copper complex and
the related mechanism. Oncol. Rep. 2015, 34, 1311–1318. [CrossRef] [PubMed]
4
0. Cvek, B.; Milacic, V.; Taraba, J.; Dou, Q.P. Ni(II), Cu(II), and Zn(II) diethyldithiocarbamate complexes show
various activities against the proteasome in breast cancer cells. J. Med. Chem. 2008, 51, 6256–6258. [CrossRef]
[PubMed]
4
4
1. Cvek, B.; Dvorak, Z. Targeting of Nuclear Factor-kB and Proteasome by Dithiocarbamate Complexes with
Metals. Curr. Pharm. Des. 2007, 13, 3155–3167. [CrossRef]
2. Yu, Z.; Wang, F.; Milacic, V.; Li, X.; Cui, Q.C.; Zhang, B.; Yan, B.; Dou, Q.P. Evaluation of copper-dependent
proteasome-inhibitory and apoptosis-inducing activities of novel pyrrolidine dithiocarbamate analogues.
Int. J. Mol. Med. 2007, 20, 919–925. [CrossRef] [PubMed]
4
3. Skrott, Z.; Cvek, B. Diethyldithiocarbamate complex with copper: The mechanism of action in cancer cells.
Mini Rev. Med. Chem. 2012, 12, 1184–1192. [CrossRef] [PubMed]
4
4. Zhang, H.; Wu, J.S.; Peng, F. Potent anticancer activity of pyrrolidine dithiocarbamate-copper complex
against cisplatin-resistant neuroblastoma cells. Anticancer Drugs 2008, 19, 125–132. [CrossRef] [PubMed]

Molecules 2016, 21, 1088
15 of 15
4
4
5. Zhu, C.P.; Hu, W.; Wu, H.; Hu, X. No evident dose-response relationship between cellular ROS level and its
cytotoxicity—A paradoxical issue in ROS-based cancer therapy. Sci. Rep. 2014, 4, 5029. [CrossRef] [PubMed]
6. Chen, Y.; Azad, M.B.; Gibson, S.B. Methods for detecting autophagy and determining autophagy-induced
cell death. Can autophagy and determining autophagy-induced cell death. Can. J. Physiol. Pharmacol. 2010,
8
8, 285–295. [CrossRef] [PubMed]
7. Paglin, S.; Hollister, T.; Delohery, T.; Hackett, N.; McMahill, M.; Sphicas, E.; Domingo, D.; Yahalom, J. A novel
response of cancer cells to radiation involves autophagy and formation of acidic vesicles. Cancer Res. 2001
1, 439–444. [PubMed]
4
,
6
4
8. Li, L.; Ishdorj, G.; Gibson, S.B. Reactive oxygen species regulation of autophagy in cancer: Implications for
cancer treatment. Free Radic. Biol. Med. 2012, 53, 1399–1410. [CrossRef] [PubMed]
4
9. Zhen, H.B.; Xu, Q.; Hu, Y.Y.; Cheng, J.H. Characteristics of heavy metals capturing agent dithiocarbamate
(DTC) for treatment of ethylene diamine tetraacetic acid–Cu (EDTA–Cu) contaminated wastewater.
Chem. Eng. J. 2012, 209, 547–557. [CrossRef]
Sample Availability: Samples of the compounds are available from the authors.
©
2016 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC-BY) license (http://creativecommons.org/licenses/by/4.0/).
