Synthesis, crystal structure and catalytic property of a highly stable 3D Cu(II)-organic framework

Article abstract of DOI:10.1016/j.molstruc.2020.127923

A three-dimensional (3D) Cu(II)-based MOF, [CuL·Cl]_n (namely complex 1), was successfully generated through the in-situ reaction of CuCl₂, NaN₃, and 4-(4-cyanostyryl)pyridine. Notably, –CN and N₃ ^? ca

Full text of DOI:10.1016/j.molstruc.2020.127923

Journal Pre-proof
Synthesis, crystal structure and catalytic property of a highly stable 3D Cu(II)-organic
framework
Chunyan Chen
PII:
S0022-2860(20)30247-7
DOI:
https://doi.org/10.1016/j.molstruc.2020.127923
MOLSTR 127923
Reference:
To appear in: Journal of Molecular Structure
Received Date: 19 January 2020
Revised Date: 16 February 2020
Accepted Date: 16 February 2020
Please cite this article as: C. Chen, Synthesis, crystal structure and catalytic property of a highly stable
3D Cu(II)-organic framework, Journal of Molecular Structure (2020), doi: https://doi.org/10.1016/
j.molstruc.2020.127923.
This is a PDF file of an article that has undergone enhancements after acceptance, such as the addition
of a cover page and metadata, and formatting for readability, but it is not yet the definitive version of
record. This version will undergo additional copyediting, typesetting and review before it is published
in its final form, but we are providing this version to give early visibility of the article. Please note that,
during the production process, errors may be discovered which could affect the content, and all legal
disclaimers that apply to the journal pertain.
© 2020 Published by Elsevier B.V.

Chunyan Chen: Supervision and writing this article.

Graphical Abstract
A 3D Cu(II)-based MOF was successfully synthesized and used as a heterogeneous
catalyst for the CO2 cycloaddition reaction and Knoevenagel condensation reaction.

1
Synthesis, crystal structure and catalytic property of a
highly stable 3D Cu(II)-organic framework
Chunyan Chen,a*
a
School of Materials & Food Engineering, Zhongshan Institute, University of
Electronic Science & Technology of China, China.
Corresponding Author: Chunyan Chen
E-mail address: yannanfei800@126.com

2
Abstract
A three-dimensional (3D) Cu(II)-based MOF, [CuL·Cl]n (namely complex 1), was
successfully generated through the in-situ reaction of CuCl2, NaN3, and
–
4-(4-cyanostyryl)pyridine. Notably, –CN and N3 can directly react to form a
tetrazolate group during the crystal growth process. This reaction was further proved
by single crystal X-ray diffraction data. Thanks to the excellent stability, various
N-donors as Lewis basic sites and Cu(II) centres as Lewis acid sites, the as-made
complex 1 has a potential application as a bifunctional heterogeneous catalyst for the
CO2 cycloaddition reaction and Knoevenagel condensation reaction. In addition,
complex 1 has the excellent recyclability for both reactions at least six cycles.
Keywords: In situ reaction; heterogeneous catalyst; CO2 cycloaddition reaction;
Knoevenagel condensation reaction; recyclability.
1. Introduction
Recently, metal–organic frameworks (MOFs) [1,2] are organic-inorganic hybrid
crystalline materials, which have been developed rapidly thanks to their various
structures and greatly potential applications in small gas sorption [3-5], bio-carrier
[6,7], luminescent detector [8-10], optical device [11,12], and catalysis [13,14].
Compared with other solid materials, MOFs have lots of unique features, including
structural diversity, designability, multifunctional site, and adjustability [15-17].
Taking into account of some previous reports, diversiform MOFs can be tuned and
constructed by rationally choosing metal centres and organic building blocks with
various coordination sites to achieve excellent properties [18-20]. Among all
properties, MOFs exhibit greatly potential applications as heterogeneous catalysts for
many catalytic reactions because of their catalytic centres, including Lewis acid sites
(open metal site) [21-23], Brønsted acidic sites (–COOH and –OH) [24-26], and
Lewis basic sites (–NH2) [27-29]. However, the poor stability of MOFs greatly limits
the development of these materials as heterogeneous catalysts in practical applications.
Up to now, some useful approaches have been developed to enhance the stability of

3
MOFs to expand their real usability, such as surface hydrophobic coating, soft and
hard acid base theory, multi-wall and high connected multicore structure [30-32].
Bridging organic linkers have significantly important influences for the structures and
properties of MOFs. Most attentions have been still focused on carboxylic acid
organic ligands due to their excellent coordination abilities and easy preparation of
MOFs [33,34]. On the other hand, another sort of linkers focuses on the heterocyclic
nitrogen rings (pyridine, imidazole, triazole, and tetrazole) in the assemble process of
MOFs with transition metals [35-38]. Compared with the carboxylic acid linkers, such
linkers are always difficult to prepare MOFs, but the as-synthesized MOFs always
have the excellent stability. In addition, the free N-donors and metal centers in MOFs
can be served as Lewis basic sites and Lewis acid sites for different catalytic reactions
[39-41]. Hence, it is a significant change to construct highly stable MOFs based on
organic linkers with various N-donors to investigate their catalytic applications.
Based on the above discussion, we chosen an organic linker
4-(4-cyanostyryl)pyridine with pyridine and cyano groups as a bridging linker to
–
assemble with Cu(II) and NaN3. The cyano group can react with N3 to generate
tetrazole groups in suit, which was further assembled with Cu(II) to construct MOFs.
As we expect, a novel three-dimensional (3D) Cu(II)-organic framework, [CuL·Cl]n
(namely complex 1), has been successfully prepared via the solvothermal reaction;
meanwhile, the tetrazole groups are found in the structure of complex 1. The
as-prepared sample was detailly characterized and analysed by lots of testing methods.
More importantly, complex 1 exhibits the excellent catalytic performance for the CO2
cycloaddition reaction and Knoevenagel condensation reaction with the outstanding
recyclability.
2. Experimental
2.1. Materials and general methods
All chemicals and solvents were purchased and used directly. Powder X-ray
diffraction (PXRD) patterns were carried out on a Bruker D8 GADDS from 5° to 40°.

4
Thermogravimetric analyses (TGA) data were measured on a TGA Q500 under N2
from room temperature to 800 °C. The catalytic yield was obtained on a Thermo
Fisher Trace ISQ GC/MS. Elemental analysis of C, H and N was performed on a
CE-440 analyzer (Leeman Laboratories).
2.2. Synthesis of complex 1
CuCl2 (0.1 mmol), NaN3 (0.1 mmol), and 4-(4-cyanostyryl)pyridine (0.1 mmol) were
all added in a mixture solution of ethanol (1.2 mL) and H2O (2.8 mL) and carefully
sealed in a Teflon-lined steel. The mixture was putted and heated at 165 °C for 4 days.
Then, it was cooled slowly to room temperature at a decreasing rate of 5 °C h–1.
Finally, blue crystals with high quality were collected and washed with ethanol. These
crystals were dried in air with the yield of 61% based on the linker. Anal. Calc. (%)
for C14H10CuN5: C, 53.85; H, 3.21; N, 22.44. Found: C, 54.01; H, 3.26; N, 22.39.
2.3. Single crystal X-ray diffraction of complex 1
Single crystal X-ray diffraction of complex 1 was measured on a Bruker SMART
CCD diffractometer with Mo Kα (λ = 0.71073 Å) radiation. The structure of complex
1 can be well solved by using SHELXL-2015 [42,43] in the OLEX2 program [44]. All
non-H atoms were added by the anisotropic parameters. The crystal data and structure
refinement of complex 1 are summarized in Table 1.
2.4. The Knoevenagel condensation reaction
In a typical catalytic reaction, benzaldehyde with different substitutional groups (1.00
mmol) and malononitrile (1.05 mmol) were both dissolved in toluene (4 mL) in a
reaction bottle with complex 1 (100 mg). The reaction mixture was heated in an oil
bath at 100 °C for 4 hours under slowly stirring. The catalytic yields can be calculated
by using the GC method with biphenyl as an internal standard substance.
2.5. The CO2 cycloaddition reaction

5
In a typical reaction, epoxides (10 mmol), n-Bu4NBr (0.35 mmol), and complex 1
(100 mg) were all added in a high-pressure reaction equipment with CO2 (1 MPa) at
100 °C for 8 hours. The yields of cyclic carbonates can be obtained by the GC
approach with n-dodecane as an internal standard.
Table 1. Crystal data and structure refinement.
Sum formula
Formula weight
Crystal system
Space group
a (Å)
C14H10CuN5
311.82
monoclinic
P21/c
13.4232(12)
9.1569(9)
10.1126(9)
90
b (Å)
c (Å)
α (º)
β (º)
99.916(2)
90
γ (º)
Volume (Å3)
1224.4(2)
4
Z
Dx (g cm-3)
Mu (mm-1)
Nref
1.692
1.779
2621
R(int)
0.0336
Goodness-of-fit on F2 1.045
R1, wR2 [I > 2σ(I)]
R1, wR2 (all data)
0.0885, 0.0875
0.0467, 0.0915
3. Results and discussion
3.1. Structural description for complex 1
The as-synthesized crystals can be generated by mixing 4-(4-cyanostyryl)pyridine,

6
CuCl2, and NaN3 in a mixture solution of water and ethanol. The large single crystal
of complex 1 with high-quality was used to collect the single crystal X-ray diffraction
data, illustrating that it crystalized in the P21/c space group of the monoclinic system
with the cell parameters of a = 3.4232(12) Å, b = 9.1569(9) Å, c = 10.1126(9) Å, α =
90°, β = 99.916(2)°, γ = 90°. The asymmetric structural unit of complex 1 has one Cu
atom and an organic linker, which evidently exhibits the formation of tetrazole in this
linker as the similar report [45] (Fig. 1a). Fig. 1b shows the coordination mode of the
bridging linker as µ4- : : : η
η1 η1 η1 1 to connect with four Cu atoms by one pyridine and
three N-donors from tetrazole rings. Each Cu atom links with four N-donors from
three different tetrazole rings and one pyridine. Interestingly, all Cu atoms and
tetrazole rings can generate a two-dimensional (2D) layer (Fig. 1c), which are further
connected with each other by pyridine rings from linkers to finally construct a 3D
structure. The 3D structure of complex 1 is shown in different directions (Figs. 1d-1f).
<Figure 1>
3.2. PXRD and thermal analysis
As displayed in Fig. 2a, the PXRD peaks of as-synthesized bulk samples were
measured at room temperature, which are consistent well with those of the simulated
pattern. The result clearly proves that the as-synthesized samples are purity as the
obtained single structure. The TGA data of as-synthesized complex 1 indicates that
the resultant sample has the outstanding stability before ~300 °C; meanwhile, the
skeleton of complex 1 shows a rapid weight loss with the increasing of heating
temperature (Fig. 2b). The TGA result shows that complex 1 has the excellent heating
stability.
<Figure 2>
3.3. Catalytic properties
Thanks to lots of Lewis base sites in complex 1, the as-synthesized sample may be
investigated and applied as a basic catalyst for the Knoevenagel condensation reaction

7
[46-51]. Prior these catalytic reactions, as-synthesized 1 was soaked in fresh toluene
for 1 hour, which was further filtered and dried in air. In the typical catalytic reaction,
the benzaldehyde containing various substitutional groups (1.00 mmol) and
malononitrile (1.05 mmol) were both dissolved in 4 mL toluene in a reaction bottle.
The addition of complex 1 (100 mg) in the reaction system is considered as a catalyst.
The reaction was heated in an oil bath at 100 °C for 4 hours under slowly stirring. The
yields can be obtained by the GC method with biphenyl as an internal standard
substance. All catalytic results in this work are summarized in Table 2. As seen in
entry 1, the product yield of 2-benzylidenemalononitrile is higher than 99% within 4
hours. This reaction was further selected as a reaction mode to investigate the kinetic
catalytic rate (Fig. 3). The catalytic result indicates that the catalytic reaction can be
almost completely reacted after 4 hours at 100 °C. To evaluate the necessity of
complex 1 for the reaction, the reaction will quickly stop once filtering complex 1
from the reaction system. In addition, the yield of this reaction is only 9% in the
absence of complex 1 (entry 2). The control experiments illustrate that complex 1 is
the necessary catalysis for the Knoevenagel condensation reaction. The catalytic
substrates were expanded with different sizes and functional groups under the same
reaction condition. It evidently exhibits that the catalytic results are also higher than
99% (entries 3 and 4), which is mainly attributed to the electron-withdrawing groups
of –F and –NO2 in aldehydes to facilitate the reaction. Contrastively, the aldehydes
with the electron-donor and large size group of –OMe show lower catalytic yields to
88% and 81% for one –OMe group (entry 5) and two –OMe groups (entry 6),
respectively. The catalytic performance is similar with some previous reports [46-51].
<Figure 3>
Table 2. All catalytic yields of different aldehyde reactants.
CN
CN
O
+
NC
CN
R
H
R

8
Entry
1
Substrate
Product
Yield (%)
>99
CN
CN
O
H
CN
CN
O
2
3
4
5
6
9
H
CN
CN
O
>99
>99
88
H
F
F
CN
O
CN
H
O2
N
O
N
2
O
CN
H
CN
O
O
CN
O
81
CN
H
O
O
O
O
The stability and recyclability of complex 1 are both important factors for
heterogeneous catalysts. After each reaction of benzaldehyde as the substrate,
complex 1 can be easily re-collected by centrifuging at 8000 r min-1 for 2 minutes.
The reused sample can be recovered after washing with toluene for 2 times. As seen
in Fig. 4a, the catalytic yields of reused samples can be well kept even after recycling
six times. The corresponding PXRD profile of complex 1 after reusing six times are
well preserved to prove the high stability of complex 1 for this reaction (Fig. 4b).
<Figure 4>
Because of the metal sites as Lewis acid catalytic centres, complex 1 can be
considered as a potential heterogeneous catalyst for the CO2 cycloaddition reaction
with epoxides to form cyclic carbonates [52-62]. The prepared samples after washing

9
with CH2Cl2 were directly dried in air before the catalytic reaction of CO2 and
epoxides. The reaction condition is set as 1 MPa CO2 at 100 °C for 8 hours by mixing
epoxides (10 mmol), n-Bu4NBr (0.35 mmol), and complex 1 (100 mg) in a
high-pressure reaction equipment under slowly stirring. The yields of targeted cyclic
carbonates can be calculated by the GC approach with n-dodecane as an internal
standard substance. All catalytic results are concluded in Table 3. Only complex 1 or
n-Bu4NBr as the catalyst for epichlorohydrin and CO2 has a very low catalytic yields
of complex 1 (31%, entry 1) or n-Bu4NBr (~9%, entry 2), displaying that they can’t
catalyse this CO2 reaction by independent one. However, complex 1 is able to
catalyse this reaction with a high yield of >99% with n-Bu4NBr simultaneously (entry
3). All results claim that complex 1 and n-Bu4NBr can catalyse this reaction by the
synergy catalysis process. Different epoxides are selected as substrates for this CO2
reaction. The yields gradually reduce to 91% (entry 4), 82% (entry 5), and 79% (entry
6) for 1,2-epoxy-3-allyloxypropane, benzyl phenylglycidyl ether, and tert-butyl
glycidyl ether, which may be mainly ascribed to the different groups with different
size and electronic effects [52-62]. The recyclability is also investigated by the
reaction and the corresponding PXRD pattern. As shown in entry 7 and Fig. 5a, the
catalytic performance of recollected samples can be well preserved for the chemical
transformation of epichlorohydrin and CO2 for six times. The PXRD pattern can well
preserve the main diffraction peaks to illustrate the high stability of recycled complex
1 after the successive using six times (Fig. 5b).
Table 3. The yields of this CO2 cycloaddition reaction with epoxides.
O
O
CO2
O
O
1 MPa
R
R
Entry
Catalyst
Epoxide
Product
Yield%

10
O
1
complex
1
31
O
O
Cl
Cl
O
O
2
3
4
n
-Bu4NBr
9
O
O
O
O
Cl
Cl
Cl
Cl
O
O
complex
1
+
>99
91
n
-Bu4NBr
O
O
O
complex
1 +
O
O
n
-Bu4NBr
O
O
O
O
5
complex
1
+
82
O
O
n
-Bu4NBr
O
O
O
O
6
7
complex
1
+
79
O
O
n
-Bu4NBr
O
O
O
Reused complex
-Bu4NBr
>99
O
O
1
+ n
Cl
Cl
O
<Figure 5>
The assumptive catalytic mechanism can be deduced from the previous reports for
this CO2 fixating reaction (Fig. 6) [52-62]. This reaction can be caused by the weak
interaction between O atoms in epoxide rings and Cu(II) sites in complex 1. Epoxide
rings will rapidly attacked by Br– from n-Bu4NBr to open the epoxide rings. Then,
oxygen anions can be reacted with CO2 to form the ionic alkycarbonate intermediate.
The cyclic carbonate product will generate by the cyclization process of the
alkycarbonate anion. However, the accurate mechanism is also significantly far
beyond our research capabilities.
<Figure 6>
4. Conclusion

11
In summary, a 3D Cu(II)-organic framework based on 2D Cu-tetrazole layers can
be constructed and served as a bifunctional heterogeneous catalyst for the
Knoevenagel condensation reaction and chemical fixation of CO2 with epoxides. Due
to the excellent stability of complex 1, it has the excellent stability and recyclability
for both catalytic reactions at least six cycles.
Appendix A. Supplementary data
The luminescent spectra and crystal table are listed in the supporting information.
The CCDC reference number is 1977907.
Acknowledgements
This research did not receive any specific funding.
References
[1] P. Wu, L. Xia, M. Huangfu, F. Fu, M. Wang, B. Wen, Z. Yang, J. Wang,
Lanthanide-based
metal–organic
frameworks
containing
“V-shaped”
tetracarboxylate ligands: synthesis, crystal structures, “naked-eye” luminescent
detection, and catalytic properties, Inorg. Chem. 59 (2020) 264-273.
[2] B. He, M. M. Sadiq, M. P. Batten, K. Suzuki, M. Rubio-Martinez, J. Gardiner, M.
R. Hill, Continuous flow synthesis of a Zr magnetic framework composite for
post-combustion CO2 capture, Chem. Eur. J. 25 (2019) 13184-13188.
[3] H. He, D.-Y. Zhang, F. Guo, F. Sun, A Versatile microporous Zinc(II) metal–
organic framework for selective gas adsorption, cooperative catalysis, and
luminescent aensing, Inorg. Chem. 57 (2018) 7314-7320.
[4] J. Guo, Z. Li, L. Liu, Y. Ye, T. Chen, M. Zhang, Z. Ke, S. Xiang, Y. Lv, Z. Yao, A
metal-organic framework with double interpenetrated frameworks for effective
C2H2/CO2 separation, Inorg. Chem. Commun. 112 (2020) 107721.
[5] H. Cui, Y. Ye, H. Arman, Z. Li, A. Alsalme, R.-B. Lin, B. Chen, Microporous
copper isophthalate framework of mot topology for C2H2/CO2 separation, Cryst.

12
Growth Des. 19 (2019) 5829-5835.
[6] Y. Wang, N. Zhang, E. Zhang, Y. Han, Z. Qi, M. B. Ansorge-Schumacher, Y. Ge,
C. Wu, Heterogeneous metal–organic–framework–based biohybrid catalysts for
cascade reactions in organic solvent, Chem. Eur. J. 25 (2019) 1716-1721.
[7] H. He, H. Han, H. Shi, Y. Tian, F. Sun, Y. Song, Q. Li, G. Zhu, Construction of
thermophilic lipase-embedded metal–organic frameworks via biomimetic
mineralization: a biocatalyst for ester hydrolysis and kinetic resolution, ACS Appl.
Mater. Interfaces 8 (2016) 24517-24524.
[8] R. Rajak, M. Saraf, S. K. Verma, R. Kumar, S. M. Mobin, Dy(III)-based metal–
organic framework as a fluorescent probe for highly selective detection of picric
acid in aqueous medium, Inorg. Chem. 58 (2019) 16065-16074.
[9] L. Zhang, J. Wang, T. Du, W. Zhang, W. Zhu, C. Yang, T. Yue, J. Sun, T. Li, J.
Wang, NH2-MIL-53(Al) metal–organic framework as the smart platform for
simultaneous high-performance detection and removal of Hg2+, Inorg. Chem. 58
(2019) 12573-12581.
[10]H. He, Y. Song, F. Sun, Z. Bian, L. Gao, G. Zhu, A porous metal–organic
framework formed by a V-shaped ligand and Zn(II) ion with highly selective
sensing for nitroaromatic explosives, J. Mater. Chem. A 3 (2015) 16598-16603.
[11]L. Qiu, C. Yu, X. Wang, Y. Xie, A. M. Kirillov, W. Huang, J. Li, P. Gao, T. Wu, X.
Gu, Q. Nie, D. Wu, Tuning the solid-state white light emission of postsynthetic
lanthanide-encapsulated double-layer MOFs for three-color luminescent
thermometry applications, Inorg. Chem. 58 (2019) 4524-4533.
[12]Y. Sun, N. Zhang, Q. L. Guan, C. H. Liu, B. Li, K. Y. Zhang, G. H. Li, Y. H. Xing,
2–
F. Y. Bai, L. X. Sun, Sensing of Fe3+ and Cr2O7 in water and white light:
synthesis, characterization, and fluorescence properties of a crystalline
bismuth-1,3,5-benzenetricarboxylic acid framework, Cryst. Growth Des. 19
(2019) 7217-7229.
[13]A. Muñoz, P. Leo, G. Orcajo, F. Martínez, G. Calleja, URJC-1-MOF as new
heterogeneous recyclable catalyst for C-heteroatom coupling reactions,
ChemCatChem 11 (2019) 3376-3380.

13
[14]H. He, J. A. Perman, G. Zhu, S. Ma, Metal–organic frameworks for CO2 chemical
transformations, Small 12 (2016) 6309-6324.
[15]J. Zhou, Z. Zhang, L.-F. Xu, R.-J. Li, R.-D. Bao, L. Du, M.-J. Xie, Y.-F. Qiao,
Q.-H. Zhao, Mixed-ligand strategy affording two 6-connected 3-fold
interpenetrated metal-organic frameworks with binuclear CoII /NiII subunits:
2
2
synthesis, crystal structures and magnetic properties, Inorg. Chem. Commun. 111
(2020) 107624.
[16]K. Roztocki, M. Szufla, M. Hodorowicz, I. Senkovska, S. Kaskel, D. Matoga,
Introducing a longer versus shorter acylhydrazone linker to a metal–organic
framework: parallel mechanochemical approach, nonisoreticular structures, and
diverse properties, Cryst. Growth Des. 19 (2019) 7160-7169.
[17]H. He, Q,-Q. Zhu, F. Sun, G. Zhu, Two 3D metal–organic frameworks based on
CoII and ZnII clusters for Knoevenagel condensation reaction and highly selective
luminescencesensing, Cryst. Growth Des. 18 (2018) 5573-5581.
[18]J. Li, T.-J. Chen, S. Han, L.-F. Song, Four Zn(II)–organic frameworks as
luminescent probe for highly selectivity detection of CrVI ions and antibiotics, J.
Solid State Chem. 277 (2019) 107-114.
[19]S. Ju, M. Yusuf, S. Jang, H. Kang, S. Kim, K. H. Park, Simple transformation of
hierarchical hollow structures by reduction of metal–organic frameworks and
their catalytic activity in the oxidation of benzyl alcohol, Chem. Eur. J. 25 (2019)
7852-7859.
[20]S. Mistry, A. Sarkar, S. Natarajan, New bifunctional metal–organic frameworks
and their utilization in one-pot tandem catalytic reactions, Cryst. Growth Des. 19
(2019) 747-755.
[21]S. Chand, S. C. Pal, M. Mondal, S. Hota, A. Pal, R. Sahoo, M. C. Das,
Three-dimensional Co(II)-metal–organic frameworks with varying porosities and
open metal sites toward multipurpose heterogeneous catalysis under mild
conditions, Cryst. Growth Des. 19 (2019) 5343-5353.
[22]X.-X. Wang, J. Yang, X. Xu, J.-F. Ma, Highly stable copper(I)–thiacalix[4]arene–
based frameworks for highly efficient catalysis of click reactions in water, Chem.

14
Eur. J. 25 (2019) 16660-16667.
[23]H. He, Q. Sun, W. Gao, J. A. Perman, F. Sun, G. Zhu, B. Aguila, K. Forrest, B.
Space, S. Ma, A stable metal–organic framework featuring a local buffer
environment for carbon dioxide fixation, Angew. Chem., Int. Ed. 57 (2018),
4657-4662.
[24]R. A. Agarwal, A. K. Gupta, D. De, Flexible Zn-MOF exhibiting selective CO2
adsorption and efficient Lewis acidic catalytic activity, Cryst. Growth Des. 19
(2019) 2010-2018.
[25]Q.-Q. Zhu, W.-W. Zhang, H.-W. Zhang, Y. Yuan, R. Yuan, F. Sun, H. He, A
double-walled porous metal–organic framework as a highly efficient catalyst for
chemical fixation of CO2 with epoxides, Inorg. Chem. 58 (2019) 15637-15643.
[26]Y.-Z. Li, H.-H. Wang, H. Y. Yang, L. Hou, Y.-Y. Wang, Z. Zhu, An uncommon
carboxyl-decorated metal–organic framework with selective gas adsorption and
catalytic conversion of CO2, Chem. Eur. J. 24 (2018) 865-871.
[27]X. Zhang, R. Zhang, Y. Jin, T. Li, Two PbII-based coordination polymers based on
5-aminonicotinic acid and 5-hydroxynicotinic acid for Knoevenagel condensation
reaction and luminescent sensor, J. Solid State Chem. 278 (2019) 120927.
[28]C. Yao, S. Zhou, X. Kang, Y. Zhao, R. Yan, Y. Zhang, L. Wen, A cationic Zinc–
organic framework with Lewis acidic and basic bifunctional sites as an efficient
solvent-free catalyst: CO2 fixation and Knoevenagel condensation reaction, Inorg.
Chem. 57 (2018) 11157-11164.
[29]Y. Kim, S. Huh, Pore engineering of metal–organic frameworks: introduction of
chemically accessible Lewis basic sites inside MOF channels, CrystEngComm,
18 (2016) 3524-3550.
[30]M. Ding, X. Cai, H.-L. Jiang, Improving MOF stability: approaches and
applications, Chem. Sci. 10 (2019) 10209-10230.
[31]H. He, Q.-Q. Zhu, C.-P. Li, M. Du, Design of a highly-stable pillar-layer Zinc(II)
porous framework for rapid, reversible, and multi-responsive luminescent sensor
in water, Cryst. Growth Des. 19 (2019) 694-703.
[32]X. Qian, R. Zhang, L. Chen, Y. Lei, A. Xu, Surface hydrophobic treatment of

15
water-sensitive DUT-4 metal–organic framework to enhance water stability for
hydrogen storage, ACS Sustain. Chem. Eng. 7 (2019) 16007-16012.
[33]Q. Sun, X. Zhu, N. Zhang, B. Zhang, J. Lu, H. Liu, Auxiliary ligand-assisted
structural variation of two Co(II) metal-organic frameworks: Syntheses, crystal
structure and magnetic properties, Inorg. Chem. Commun. 99 (2019) 172-175.
[34]Q.-Q. Zhu, H. He, Y. Yan, J. Yuan, D.-Q. Lu, D.-Y. Zhang, F. Sun, G. Zhu, An
exceptionally stable TbIII-based metal−organic framework for selectively and
sensitively detecting antibiotics in aqueous solution, Inorg. Chem. 58 (2019)
7746-7753.
[35]L. Zhao, J. Zhang, J. Wang, X.-Y. Niu, X.-Q. Wang, L.-M. Fan, T.-P. Hu,
Structural diversity, gas sorption properties, luminescent sensing of three Cd(II)
complexes based on 3, 5-Di(2′, 5-dicarboxylphenyl)pyridine, J. Solid State Chem.
268 (2018) 1-8.
[36]M.-X. Yang, L.-J. Chen, R. Ma, J.-N. Cai, Y.-D. Shi, S. Lin, Three 3D Co(II)
cluster-based MOFs constructed from polycarboxylate acids and bis(imidazole)
ligands and their derivatives: magnetic properties and catalytic performance for
the ORR, Dalton Trans. 48 (2019) 13369-13377.
[37]H. Benaissa, M. Wolff, K. Robeyns, G. Knor, K. Van Hecke, N. Campagnol, J.
Fransaer, Y. Garcia, Syntheses, crystal structures, luminescent properties, and
electrochemical synthesis of group 12 element coordination polymers with
4-substituted 1,2,4-triazole ligands, Cryst. Growth Des. 19 (2019) 5292-5307.
[38]Y. Li, X. Zhang, J. Lan, P. Xu, J. Sun, Porous Zn(Bmic)(AT) MOF with abundant
amino groups and open metal sites for efficient capture and transformation of
CO2, Inorg. Chem. 58 (2019) 13917-13926.
[39]S. Kousik, S. Velmathi, Engineering metal–organic framework catalysts for C−C
and C−X coupling reactions: advances in reticular approaches from 2014–2018,
Chem. Eur. J. 25 (2019) 1716-1721.
[40]F. G. Cirujano, E. Lopez-Maya, M. Rodriguez-Albelo, E. Barea, J. A. R. Navarro,
D. E. De Vos, Selective one-pot two-step C−C bond formation using metal–
organic frameworks with mild basicity as heterogeneous catalysts,

16
ChemCatChem 9 (2017) 4019-4023.
[41]H. He, F. Sun, B. Aguila, J. A. Perman, S. Ma, G. Zhu, A bifunctional metal–
organic framework featuring the combination of open metal sites and Lewis basic
sites for selective gas adsorption and heterogeneous cascade catalysis, J. Mater.
Chem. A 4 (2016) 15240-15246.
[42]G. M. Sheldrick, A short history of SHELX, Acta Cryst. A 64 (2008) 112-122.
[43]G. M. Sheldrick, Crystal structure refinement with SHELXL, Acta Cryst. C 71
(2015) 3-8.
[44]O. V. Dolomanov, L. J. Bourhis, R. J. Gildea, J. A. K. Howard, H. Puschmann,
OLEX2: a complete structure solution, refinement and analysis program, J. Appl.
Cryst. 42 (2009) 339-341.
[45]H. Jia, Y. Qi, X. Wang, J. Xie, W. Yu, Water-stable CdII-based metal–organic
framework as a reversible luminescent sensor for NFT with excellent
recyclability and selectivity, Inorg. Chem. Commun. 111 (2020) 107668.
[46]A. Das, N. Anbu, S. K. Mostakim, A. Dhakshinamoorthy, S. Biswas, A
functionalized UiO-66 MOF for turn-on fluorescence sensing of superoxide in
water and efficient catalysis for Knoevenagel condensation, Dalton Trans. 48
(2019) 17371-17380.
[47]S. A. A. Razavi, A. Morsali, Function-structure relationship in metal–organic
frameworks for mild, green, and fast catalytic C–C bond formation, Inorg. Chem.
58 (2019) 14429-14439.
[48]F. Guo, C. Su, Z. Chu, M. Zhao, A highly stable 3D metal−organic framework for
selectively luminescent sensing and knoevenagel condensation reaction, J. Solid
State Chem. 277 (2019) 25-31.
[49]A. Dhakshinamoorthy, N. Heidenreich, D. Lenzen, N. Stock, Knoevenagel
condensation reaction catalysed by Al-MOFs with CAU-1 and CAU-10-type
structures, CrystEngComm. 19 (2017) 4187-4193.
[50]M. Polozij, M. Rubes, J. Cejka, P. Nachtigall, Catalysis by dynamically formed
defects in a metal–organic framework structure: Knoevenagel reaction catalyzed
by copper benzene-1,3,5-tricarboxylate, ChemCatChem 6 (2014) 2821-2824.

17
[51]Z. Miao, Y. Luan, C. Qi, D. Ramella, The synthesis of a bifunctional copper metal
organic framework and its application in the aerobic oxidation/Knoevenagel
condensation sequential reaction, Dalton Trans. 45 (2016) 13917-13924.
[52]D. J. Darensbourg, M. W. Holtcamp, Catalysts for the reactions of epoxides and
carbon dioxide, Coord. Chem. Rev. 153 (1996) 155-174.
[53]H. He, Q.-Q. Zhu, C. Zhang, Y. Yan, J. Yuan, J. Chen, C.-P. Li, M. Du,
Encapsulation of an ionic metalloporphyrin into a zeolite imidazolate framework
in situ for CO2 chemical transformation via host–guest synergistic catalysis,
Chem. Asian J. 14 (2019) 958-962.
[54]T. Jing, L. Chen, F. Jiang, Y. Yang, K. Zhou, M. Yu, Z. Cao, S. Li, M. Hong,
Fabrication of a robust lanthanide metal–organic framework as a multifunctional
material for Fe(III) detection, CO2 capture, and utilization, Cryst. Growth Des. 18
(2018) 2956-2963.
[55]B. Ugale, S. S. Dhankhar, C. M. Nagaraja, Exceptionally stable and 20-connected
lanthanide metal–organic frameworks for selective CO2 capture and conversion at
atmospheric pressure, Cryst. Growth Des. 18 (2018) 2432-2440.
[56]B. Parmar, P. Patel, R. S. Pillai, R. K. Tak, R. I. Kureshy, N.-U. H. Khan, E.
Suresh, Cycloaddition of CO2 with an epoxide-bearing oxindole scaffold by a
metal–organic framework-based heterogeneous catalyst under ambient conditions,
Inorg. Chem. 58 (2019) 10084-10096.
[57]M. Singh, P. Solanki, P. Patel, A. Mondal, S. Neogi, Highly active ultrasmall Ni
nanoparticle embedded inside a robust metal–organic framework: remarkably
improved adsorption, selectivity, and solvent-free efficient fixation of CO2, Inorg.
Chem. 58 (2019) 8100-8110.
[58]S. Cheng, Y. Wu, J. Jin, J. Liu, D. Wu, G. Yang, Y.-Y. Wang, New multifunctional
3D porous metal–organic framework with selective gas adsorption, efficient
chemical fixation of CO2 and dye adsorption, Dalton Trans. 48 (2019) 7612-7618.
[59]H. He, Q.-Q. Zhu, J.-N. Zhao, H. Sun, J. Chen, C.-P. Li, M. Du, Rational
Construction of an exceptionally stable MOF catalyst with metal-adeninate
vertices toward CO2 cycloaddition under mild and cocatalyst-free conditions,

18
Chem. Eur. J. 25 (2019) 11474-11480.
[60]Y.-S. Xue, W. Cheng, J.-P. Cao, Y. Xu, 3D enantiomorphic Mg-based metal–
organic frameworks as chemical sensor of nitrobenzene and efficient catalyst for
CO2 cycloaddition, Chem. Asian J. 14 (2019) 1949-1957.
[61]P. Patel, B. Parmar, R. I. Kureshy, N.-U. Khan, E. Suresh, Efficient solvent-free
carbon dioxide fixation reactions with epoxides under mild conditions by
mixed-ligand Zinc(II) metal–organic frameworks, ChemCatChem 10 (2018)
2401-2408.
[62]H. He, Q.-Q. Zhu, M.-T. Guo, Q.-S. Zhou, J. Chen, C.-P. Li, M. Du, Doubly
interpenetrated Zn4O based metal−organic framework for CO2 chemical
transformation and antibiotic sensing, Cryst. Growth Des. 19 (2019) 5228-5236.
Fig. 1. (a) The asymmetrical unit; (b) the coordination mode of this organic linker; (c)
the 2D Cu(II)-based layer; and (d-f) the 3D structure of complex 1 (H atoms are
removed for clarity).
Fig. 2. (a) The PXRD pattern of simulated (bottom, black) and as-synthesized
complex 1 (up, red); and (b) the TGA curve of as-synthesized complex 1.
Fig. 3. The kinetic catalytic rates of benzaldehyde as the substrat in complex 1 (black),
after filtering complex 1 (blue), and without any catalyst (pink).
Fig. 4. Recyclability (a) and PXRD profiles (b) of complex 1.
Fig. 5. The recyclability (a) and the corresponding PXRD profiles (b) of complex 1.
Fig. 6. The assumptive catalytic mechanism for this CO2 fixating reaction.

1
Synthesis, crystal structure and catalytic property of a
highly stable 3D Cu(II)-organic framework
Chunyan Chen,a*
a
School of Materials & Food Engineering, Zhongshan Institute, University of
Electronic Science & Technology of China, China.
Corresponding Author: Chunyan Chen
E-mail address: yannanfei800@126.com

2
Figure 1
Figure 2

3
Figure 3
Figure 4
Figure 5

4
Figure 6

1. A Cu(II)-organic framework was successfully synthesized via the solvothermal
reaction.
2. It can catalyse the Knoevenagel condensation reaction and chemical fixation of
CO2 with epoxides.
3. The as-synthesized sample has the excellent stability and recyclability.

Declaration of interests
☒ The authors declare that they have no known competing financial interests or personal relationships
that could have appeared to influence the work reported in this paper.
☐The authors declare the following financial interests/personal relationships which may be considered
as potential competing interests:
